Swingline stack-and-shred60x, STACK-AND-SHRED80X Start Here Manual
start here
démarrez ici
empieza aquí
comece aqui
SHREDDERS
™
STACK-AND-SHRED60X
2min
MAX
1
4
3
5
2
SHREDDERS
™
STACK-AND-SHRED60X
English instruction manual 6
Francais manuel d’utilisation 12
Español manual de instrucciones 18
Português manual de instruções 24
6 register this product online at www.accobrands.com
To guard against injury, the following basic safety precautions must be observed in the set-up of this
product.
• Ensure the machine is plugged into an easily accessible power outlet, and ensure the cable is not
likely to trip up a passer by.
• Any attempt to repair this unit by unqualied personnel will invalidate the warranty. Please return to
supplier.
• Unplug your shredder before moving it or when it is not in use for an extended period of time.
• Do NOT operate with a damaged power supply cord or plug, after it malfunctions, or after it has
been damaged in any manner.
• Do NOT overload electrical outlets beyond capacity as this can result in re or electrical shock.
• The socket-outlet should be installed near the equipment and shall be easily accessible.
• Do NOT alter the attachment plug. The plug is congured for the appropriate electrical supply.
• Do NOT use near water.
• Do NOT use aerosol dusters or cleaners.
• Do NOT spray anything into the shredder.
• Do NOT load the auto-feed chamber with unopened junk mail, magazines, bound documents etc.
Although this shredder has been designed to comply with UL 60950-1 EN 60950-1 safety standards
including the “probe accessibility tests”, do not operate the shredder near children or pets.
autofeed technology
The Stack and Shred 60X has been designed to automatically shred up to 60 sheets from the
auto-feed chamber and up to 5 sheets through the manual feed slot. The auto-feed mechanism has
been designed to handle paper fastened with staples and paper clips and to only pull a few sheets
of paper into the cutting mechanism to minimise the risk of paper jams.
Sheet capacity:
Manual feed slot
5 sheets (80gsm)
Sheet capacity:
Autofeed chamber
60 sheets (80gsm)
Duty Cycle 6 min ON / 40 min OFF
technical specifications
Swingline Stack and Shred 60X
Run time from cold 8 minutes
Volts / Hz 120V / 60Hz
Amperage 0.8 Amps
Motor Watts 180 Watts
English
STACK-AND-SHRED 60X™ SHREDDERS 7
control panel and indicators
Continuous Jam BoostReverse
Auto
warning symbols
This means no aerosols.
This means keep children away
from shredder.
This means you should be careful
because long hair can become
entangled in the cutting head.
This means don’t reach into the
feed opening of the cutting head.
This means be careful of loose
jewellery which could become
entangeld in the cutting head.
This means no oil lubrication,
use Swingline oil sheets only.
This means be careful of ties and
other loose clothing which could
become entangled in the cutting
head.
This means the shredder can
accept small paperclips.
This means the shredder can
accept small staples.
Safety First
Sheet capacity of manual feed
entry slot.
5
English
Cool Down indicator – This means
the machine is cooling down.
8 register this product online at www.accobrands.com
Stack and Shred 60X shredding capability
Stack and Shred 60X CAN shred the following:
• 60 sheets
• Stapled paper, 25mm within the corner
• 26/6 and 24/6 or smaller staples
• Small sized paper loaded centrally
• 60 sheets
• Paper clip paper, 25mm within the corner
• Capable of shredding small/medium paper clips (max. wire thickness = 0.9 mm)
• >100gsm paper (through manual feed slot ONLY)
• A3 folded in half max. 2 sheets
• 60 sheets
• 80 gsm paper
- Letter and Legal
- A3 single sheet folded in half to make A4
Stack and Shred 60X CAN shred (through the manual feed slot):
Thick paper or
card.
Multiple folded
sheets (e.g. A3
sheets folded in
half).
Unopened mail
(e.g. junk mail).
Glossy paper or
a sheet covered
with print on both
sides.
Stack and Shred 60X CANNOT shred the following:
Large clips.
Check the length
of the paperclip
is not longer than
32mm.
Heavy duty
staples. Check
the staple leg
length is not
greater than
6mm.
Bound
documents
Bulldog clips
Magazines or
other documents
bound by multiple
staples or clips.
Adhesive labels.
Plastic sheets,
laminated
documents,
plastic folders.
English
STACK-AND-SHRED 60X™ SHREDDERS 9
1. operation
1 Unpack the product.
2 Connect the shredder to mains supply.
3 Ensure the on/o switch on the back of the shredder is in the ‘ON’ position.
4 To commence shredding, move the slide switch to the Auto position (
) which sets the
shredder into auto mode. You are now ready to shred.
5 To load the shredder, simply lift the loading door catch to open the loading door and insert
documents. You can open the door further to 90 degrees for easier access if required. Load
up to 60 sheets at a time into the feed chamber. Do NOT ll above the MAX level, this could
damage the shredder.
6 The shredder will start shredding automatically ONLY after closing the loading door.
7 If there is still paper in the Autofeed tray after rst attempt, open and re-close paper loading door
a second time.
8 If you only have up to 5 sheets to shred, you can use the manual feed slot, provided the auto
feed chamber is empty.
2. reverse function
1 Should you wish to reverse paper out whilst shredding, a reverse button (
) has been tted for
your convenience.
2 Reverse the paper out then turn the shredder o using the ON/OFF switch at the rear of the
shredder. Remove the paper from the manual feed slot (if being used) or open the loading door,
remove the remaining stack of paper, then pull the jammed paper free of the cutting mechanism.
3 To resume shredding return the slide switch to the auto position (
) and turn on the machine by
using the ON/OFF switch at the rear of the shredder.
Swingline encourages customers to recycle shredded paper.
Please note that shredded paper cannot be recycled if mixed with credit card shards.
If recycling, please separate shredded paper and credit cards.
3. credit card shredding
The Stack and Shred 60X can shred credit cards. Switch the shredder to auto mode and insert the
credit card between the markings in the manual feed slot. Only shred one credit card at a time.
English
