Swingline EX10-06 User Manual

TM/MC
EX10-06 / EM07-06
Instruction Manual Manuel d’utilisation Manual de instrucciones
To register this product go to www.swingline.com
Pour enregistrer ce produit allez sur www.swingline.com
Para registrar este producto vaís en www.swingline.com
TM/MC
E
D
B
C
a
F
G
Safety Icons Icônes de sécurité Iconos de seguridad
a Safety icons
Icônes de sécurité Iconos de seguridad
B AUTO/OFF Button
Touche de mise en marche Botón de encendido
C FORWARD Button
Touche de démarrage automatique
Botón de puesta en marcha automática
D Reverse Button
Touche de marche arrière Botón de retroceso
E Anti-jam Indicator
Voyant anti-bourrage Indicador del sistema antiatascos
F Pull-out Bin
Corbeille amovible Gabinete extraíble
G ON/OFF switch (not shown)
Interrupteur marche/arrêt (non illustré) Interruptor Encendido/Apagado (no mostrado)
Specifications Specifications
Models
Sheet Capacity -
Duty Cycle -
Volts / Hz
Amperage
EX10-06
10 sheets (20# / 75 gsm)
4 mins on / 30 mins off
120V / 60Hz
2.5A
Models
Sheet Capacity -
Duty Cycle -
Volts / Hz
Amperage
Caractéristiques Caractéristiques
Modèles
Capacité de feuilles
Cycle de rendement -
Volts / Hz
Intensité
EX10-06
10 feuilles (20# / 75 gsm)
4 min de marche / 30 min d’arrêt
120V / 60Hz
2,5A
Modèles
Capacité de feuilles
Cycle de rendement -
Volts / Hz
Intensité
Especificaciones Especificaciones
Modelos
Capacidad de hojas -
Ciclo de trabajo -
Volts / Hertz
Amperage
EX10-06
10 hojas (20 kg / 75 gsm)
4 min encendido / 30 min apagado
120V / 60Hz
2.5A
Modelos
Capacidad de hojas -
Ciclo de trabajo -
Volts / Hertz
Amperage
EM07-06
7 sheets (20# / 75 gsm)
4 mins on / 30 mins off
120V / 60Hz
3.0A
EM07-06
7 feuilles (20# / 75 gsm)
4 min de marche / 30 min d’arrêt
120V / 60Hz
3,0A
EM07-06
7 hojas (20 kg / 75 gsm)
4 min encendido / 30 min apagado
120V / 60Hz
3.0A
TM/MC
Lights and Icons Explained
Illumination Cool down Auto
Color of LED Green Red Orange Blue Power on switch Auto button pushed light light Bin Removed flash light Motor overheat flash light Jam-Free (too much paper) light light Reverse mode light light After 2 mins no use
Introduction
Thank you for choosing this shredder from Swingline. We are sure it will serve you well, but please take a little time to study these instructions to ensure you get the best out of your machine.
Swingline Jam-Free Technology*
Swingline Shredders will only shred stacks of paper that are within the shredders sheet capacity.
Sensors in the paper feed area measure the thickness of paper about to be shredded. The ability to shred or not is communicated through red and green lighting. Green means that the stack of paper is within the shredder’s sheet capacity and OK to shred. Red means that you have too much paper, remove some sheets in order to shred.
Given that you are unable to shred more sheets of paper than the shredder is capable of shredding, paper jams are prevented.
This prevents time wasted through reversing paper and unblocking jams not to mention the mess it can create.
IMPORTANT! Do not attempt to shred more paper while paper is already being shredded. By attempting to force paper down the front or back of a batch of paper that is being pulled into the machine, you can jam the shredder. The anti-jam technology will work reliably if used as instructed.
*Jam Free when used in accordance with this instruction manual.
Safety First
Shredders are safe to use as long as you take a few safety precautions.
• Ensure the machine is plugged into an easily accessible power outlet,
and ensure the cable is not likely to trip up a passer by.
• Any attempt to repair this unit by unqualied personnel will invalidate
the warranty. Please return to supplier.
• Unplug your shredder before moving it or when it is not in use for an
extended period of time.
• Do not operate with a damaged power supply cord or plug, after it
malfunctions, or after it has been damaged in any manner.
• Do not overload electrical outlets beyond capacity as this can result in
fire or electrical shock.
• The socket-outlet should be installed near the equipment and shall be
easily accessible.
• Do not alter the attachment plug. The plug is congured for the
appropriate electrical supply.
• Do not use near water.
• Do not use aerosol dusters or cleaners.
• Do NOT Spray anything into the shredder.
Although this shredder has been designed to be child safe, it is not advised to operate the machine near children.
