Swingline EX10-05 Users Guide
GBC EX10-05 10-Sheet
Level P-4 Cross-Cut
Shredder - 1757393
Instruction Manual
TM/MC
EX10-05
Instruction Manual
Manuel d’utilisation
Manual de instrucciones
To register this product go to www.swingline.com
Pour enregistrer ce produit allez sur www.swingline.com
Para registrar este producto vaís en www.swingline.com
English 4
Français 8
Español 12
2
A
D
C
B
F
G
E
3
TM/MC
Technical data
Swingline EX10-05
Cutting Type
Shred Size
Sheet Capacity @ 80 gsm paper
Sheet Capacity @ 75 gsm paper*
Entry Width
Product Dimensions
Rated Voltage/Frequency
Rated Current
Please read this instruction leaet carefully before use.
* 8.5” x 11”, 20lb., (75g) paper at 120V, 60Hz, 2.7 Amps; heavier paper,
humidity or other than rated voltage my reduce capacity.
Confetti Cut
4mm x 45mm
10 sheets
12 sheets
220mm
H370 x W340 x D230mm
120V~60Hz
2.7 amps
Introduction
Thank you for choosing this shredder from Swingline. We are sure it
will serve you well. Please take a little time to read these instructions to
ensure you get the best out of your machine.
Safety First
•
Lights and Icons Explained
LEDs
1 2
Power On Cool Down
Colour of LED Green Red
Power Off Position
Auto Mode light
Forward Mode light
Reverse Mode light
Cool Down Indicator light
Description of product parts
A
Important Safety Symbols
B
Paper & Credit Card slot
C
CD entry slot
D
Power cable
E
Bin
F
Slide switch
G
CD Bin
• Please store this instruction manual in a safe place for future
reference.
• Do not operate the shredder unless it is located on the waste bin
provided.
• Please pay close attention to the safety symbols on the top of the
shredder and operate the machine accordingly.
• If the shredder needs cleaning, unplug the unit from the power socket
and use a damp cloth. Do not use any cleaning products to clean
the unit.
• Do not position the unit near to an object that radiates heat.
• Do not place the unit in a damp environment.
• Take care not to splash any liquid onto the machine.
• Return the product and proof of purchase with receipt to the store at
which it was purchased if…
- The power cable or plug is broken.
- The shredder doesn’t operate despite following the guidelines in the
manual.
• Make sure the power cable isn’t a trip hazard.
• Please ensure the power supply is compatible with the requirements
of the machine (120V~60Hz).
• To avoid risk of injury, don’t open the machine’s casing to attempt DIY
repair. Any attempted repair by an unqualied person will invalidate
the warranty.
Preparation before use
How to use the shredder correctly:
• Take care not to insert ngers, ties or other objects into the entry slot
of the shredder.
• We recommend to remove staples and paperclips, avoid laminating
materials, plastic bags etc. from being passed through the shredder.
This will prevent damage to the cutters.
• Do not shred wet paper as it can tangle in the cutters.
• Do not shred more than 10 pieces of paper in one pass.
• Do not shred more than 200 sheets of paper at any one time. Running
the unit for too long may make the motor overheat. If the motor over
heats, allow it to cool down for at least 45 minutes before resuming
use.
• Do not use the reverse (
of the reverse (
jammed in the entry slot, which will adversely affect the performance
of the shredder.
• Unplug the product before moving or emptying the shredder basket.
) function can result in shredded paper becoming
) function if it’s not necessary.Over use
Warranty
The product is guaranteed for 24 months from the date of purchase –
please return the unit to your retailer if you experience any problems.
This does not affect your statutory rights.
