SWEETVI NYL
SweetVinyl
SugarCube SC-1 PLUS
Vinyl Click & Pop Remover with Surface Noise Reduction
The SC-1 Plus is a real-time,
integrated noise removal
platform that adds SweetVinyl’s
Surface Noise Reduction
software (SVNR) to all the
technology and features of the
revolutionary SC-1 along with
an improved A/D-D/A subsys-
tem, a more refined analog
path, improved power supply,
plus a variety of digital
interfaces.
The rear panel features
TOSLINK and SPDIF Digital
Outputs, a USB-B port to
capture digital output to a
computer, gold-plated RCA
connectors, Ethernet and
USB-A ports.
The front panel allows full
control of the basic functions
with push-buttons and a pairing
function that is integrated with
the strength knob, while an
LCD display provides status.
The SC-1 Plus’s flawless Click &
Pop Removal process benefits
from the latest algorithm updates
with version 2.0 software and
SweetVinyl’s Noise Reduction
(SVNR) software that provides up
to 8 dB of background noise
reduction with little to no
coloration of the musical content.
The iOS and Android apps and
web interface provide remote
control of Click & Pop and SVNR
reduction and full ‘Analog
Bypass’.
The SC-1 Plus transparently
removes noise from records or
tape and provides hours of
enjoyment from previously
unplayable media in any collection; SVNR is particularly effective
with 78’s and tape.
SC-1 PLUS In Brief
• 2.0 Click & Pop Algorithm
• SVNR Surface Noise Reduction
• 192K/24bit A/D-D/A
• Refined analog path
• Improved power supply
• Full Analog Bypass or Bridging
• Adjustable Click & Pop and SVNR
• Click & Pop Removal Monitor
• Gold Plated RCA Interconnects
• Front-Panel Pairing Function
• iOS, Android, and Web Apps
• LCD Front-panel Display
• New Front Panel Bezel
• USB-A and USB-B ports
• Gigabit Ethernet Port
• USB WiFi Adapter
• TOSLINK and SPDIF outputs
• Full Component Size
• Excellent Build Quality
• Available in Black and Silver
© Copyright SweetVinyl 2019 www.sweetvinyl.com
SWEETVI NYL
SugarCube SC-1 PLUS
SPECIFICATIONS
Electronics
Line-In max level = +22.7 dBu (10.6 Vrms; 30 Vp-p)
Line-Out level = Line-In level
THD+N = 0.0025% (A-weighted)
Frequency Response = 25Hz to 60kHz +/-0.1dB
Frequency Response = 15Hz to 75kHz -3dB
DC in = 5 volts, center-pin positive
Multi-stage +/- 15v internal power regulation
Average Power Dissipation = 9 watts
Connections
2x Line-In RCA (Left-Right)
2x Line-Out RCA (Left-Right)
2x USB type ‘A’ connector
1x USB type ‘B’ connector
1x SPDIF Output
1x TOSLINK Output
1x Ethernet: Gigabit
General
Dimensions - WxHxD: 12” x 14” x 2”
Weight: 8 pounds (9 lbs. in box)
© Copyright SweetVinyl 2019 www.sweetvinyl.com
