Swann NVR-7085 User Manual

720p High Definition
Network Video Recorder
NVR-7085 models
EN
INSTRUCTION MANUAL
1
Before You Begin
FCC Verification
with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna
Increase the separation between the equipment and the receiver
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
Consult the dealer or an experienced radio/T V technician for help
These devices comply with part 15 of the FCC Rules. Operation is subject to the following two conditions:
These devices may not cause harmful interference, and
These devices must accept any interference received, including interference that may cause undesired operation.
DEFAULT PASSWORD INFORMATION
To ensure your privacy, this NVR supports password protection.
The default, all-access username is ‘admin’, the default password is ‘12345’.
To ensure your ongoing privacy, we strongly recommend setting a password as soon as possible. Choose something that you’ll remember, but that others would be unlikely to guess.
IMPORTANT NOTICE - Do NOT lose or
forget your password. To ensure that
your NVR has the best security possible, password recovery has been designed to be a complicated and time consuming process.
Only a select number of staff at the Swann Technical Support Telephone Helpdesk can assist. Password retrieval can take several
days, which means you will NOT be able to
access your NVR during this time.
IMPORTANT NOTE:
All jurisdictions have specific laws and regulations relating to the use of cameras. Before using any camera for any purpose, it is the buyer’s responsibility to be aware of all applicable laws and regulations that prohibit or limit the use of cameras and to comply with the applicable laws and regulations.
FCC Regulation (for USA): Prohibition against eavesdropping
Except for the operations of law enforcement officers conducted under lawful authority, no person shall use, either directly or indirectly, a device operated pursuant to the provisions of this Part for the purpose of overhearing or recording the private conversations of others unless such use is authorized by all of the parties engaging in the conversation.
WARNING
Modifications not approved by the party responsible for compliance could void user’s authority to operate the equipment.
BATTERY INFORMATION
This product contains a removable battery. If you need to
replace or dispose of the internal battery. The battery is located on the mainboard of the NVR. It is a
primar y lithium CR2032 button cell.
To access, remove and/or replace the battery:
Ensure the NVR is turned OFF. NEVER open the NVR’s
case while power is connected.
Remove the five screws holding the cover on the NVR.
If replacing the battery, ensure that it is an exact match
for size, type and capacity.
Be sure to safely dispose of the battery. The process for battery disposal/recycling varies from location to location, please check with the relevant local authority for method.
BATTERY SAFETY INSTRUCTIONS
Do NOT attempt to open, puncture, disassemble or modify the battery in any way.
Do NOT subject it to sudden shock or heat.
Do NOT dispose of battery in fire.
IMPORTANT SAFETY INSTRUCTIONS
Make sure product is fixed correctly and stable if fastened in place
Do not operate if wires and terminals are exposed
Do not cover vents on the side or back of the NVR and allow adequate space for ventilation
2
Contents
Introduction
Before You Begin 2 Contents 3 Introduction 5
Basic Setup
Installation Guidelines 7 NVR Front Panel 7 NVR Rear Panel 8 Connection Diagram 9 Connecting Additional Devices 10 Controlling the NVR 11 Setup Wizard: General 12 Setup Wizard: Camera & Email 13 Setup Wizard: System Time 14 Setup Wizard: Account Configuration 15 Setting your Smartphone or Tablet 16 Setting up your PC 17 Basic NVR Operation 19
System: General 44 System: User 45 System: System Information 46 System: Maintenance 47
Reference
SwannView Link: Interface 49 SwannView Link: Local Settings 50 SwannView Link: Device Settings 51 Troubleshooting 55 Addendum: Third Party Hardware 56 Warranty Information 57 Helpdesk/Technical Support Details Rear Cover
Advanced Configuration
Advanced Configuration 22 IP Channel 23 Display: Camera  24 Display: Output  25 Recording: Encode 26 Recording: Option 27 Recording: Schedule 28 Search: Playback 29 Search: The Playback Interface 30 Specific Incident Backup 31 Search: Backup 31 Search: Event / Log Search 32 Network: General 33 Network: Advanced 34 Network: Advanced: DDNS 35 Network: Advanced: NTP 35 Network: Advanced: Email Settings 36 Network: Advanced: IP Filter 37 Network: Advanced: Network Status 37 Alarm: Motion 38 Alarm: Motion Detection Configuration 39 Alarm: Motion Detection Notes 40 Alarm: Motion Detection - Action 41 Alarm: Video Loss 41 Alarm: Exception 42 Device: HDD 43 Device: S.M.A.R.T 43
3
Chapter
1
Introduction
4
INTRODUCTION
EN
Introduction
Congratulations on your purchase of Swann’s latest network video recording security system with 720p high definition live viewing and playback in real-time. Let’s take a moment to talk about some of the features this NVR offers, and how to get the most out of them.
Oh my, this is a big manual. How long will this take?
Yes, but you won’t have to read all of it - you should be up and running by page 20!
It can take a few hours to connect everything and run through the setup procedure.
The latter part of this manual is for advanced users only - the NVR is seriously configurable - the out-of-the-box settings do a great job in 90% of situations, but some users will want to get into the nitty-gritty detail, so that information is presented for those who need it.
The Basic Setup
The default settings will cover most basic installation requirements of the NVR.
To get the most out of your hard drive, we’ve configured the NVR to record only when it detects motion - that way, you won’t fill the hard drive with video of nothing happening.
Before installing anything, connect the NVR and cameras and test your system.
We ensure everything is working properly when we ship them out , but sometim es things can b e damaged in tr ansport , and occasionally components can fail. Better to find out now, before everything is fixed in place!
Getting the NVR Setup
There are three stages to getting your NVR set up. If you want to use the default settings, you’ll only need to complete steps one and two.
Stage 1. Connecting the NVR (page 7 to page 10)
This section details what you can connect to the different inputs/outputs of the NVR.
Everyone’s setup will vary a little bit - it depends what cameras came with the NVR (if any) and what device(s) you’ve already got.
Stage 2. Basic NVR Setup (page 11 to page 20)
The NVR needs a few things to be set properly before it can do its thing. Follow the instructions from pag e 11 to page 20 to get everything working.
3. Optional: Advanced NVR Configuration
The lat ter part of th is manual covers a dvanced N VR operatio ns. This NVR comes with all the professional-grade capabilities
you’d expect from a qualit y Swann produc t, but many advanced capabilities require detailed setup to function correctly.
If you’re not an advanced user, don’t worry. The out-of-the-box settings really do work well, and we’d only suggest changing them if you’ve got a really specific plan in mind.
INTRODUCTION
Accessing this NVR from your Smartphone or Tablet
This NVR supports live viewing on your Smartphone or Tablet. We have developed an app called SwannView Link for the Andro id and iOS pl atform s. For And roid user s, please d ownloa d the app from Google Play. If you have an Apple device, please go to the Apple App Store. As we are continually improving the documentation that we include with our products, you can find the latest user guide for our app at www.swann.com.
5
Chapter
2
Basic Setup
6
BASIC SETUP
EN
Installation Guidelines
Do not expose the NVR to moisture. Water is the arch­enemy of electrical components and also poses a high risk of electric shock.
Avoid dusty locations. Dust has a tendency to build up inside the NVR case, leading to a high risk of failure or even fire.
Only install the NVR in a well ventilated space. Like all electronics, the circuitry and hard drive in the NVR produce heat, and this heat needs a way out.
Do not open the NVR case except to install/swap the hard drive inside. There are no user serviceable parts inside.
Do not cut or modify any cable for any reason. Doing so
NVR Front Panel
will void your warranty, as well as pose a great risk of fire or electrical shock.
Do not expose the NVR to sudden bumps or shocks (for example, being dropped). The NVR is as robust as possible, but many of the internal components are quite fragile.
Remember that the NVR is, in all likelihood, going to be left on 24 hours a day, 7 days a week. Keep this in mind when choosing a location for installation.
Never open the case whilst the NVR is plugged in, and never turn the NVR on whilst the case is open.
Name Function
1
2
3
Power LED
HDD LED
LAN LED
Solid red indicates the NVR is supplied power and turned on.
Blinking green indicates the NVR is writing to / reading from the installed hard drive.
Solid blue indicates the NVR is connected to the network.
BASIC SETUP
123
7
BASIC SETUP
2 4
3
5
6
1
EN
NVR Rear Panel
8-channel NVR7085 model shown below
BASIC SETUP
Name Function
1
VGA
2
HDMI
Network (LAN)
3
Port
4
USB 2.0
POE Camera
5
Ports
DC 48V
6
Power Input
For connecting a television or PC monitor with a VGA input (make sure the monitor you use supports the resolution you set in the menu).
The primary video output of the NVR.
Where you connect the NVR to your router or network switch for Internet connectivity.
For connecting the USB mouse or a USB storage device. The mouse will work in either port, use whichever one works for you.
Plug the Video and Power cable for each camera in to one of these sockets
Plug the DC power adapter into this socket to provide power to the NVR and Cameras
8
BASIC SETUP
EN
Connection Diagram
Connecting Cameras to the NVR
Connect the camera’s LAN Video port to any POE Camera port on the NVR using one of the long Ethernet cables provided. You can also create or purchase longer LAN cables if required, they are the same as the LAN cables used for connecting PCs, Laptops and other network devices to each other.
Ethernet plug
The camera’s Reset Button. It enables
you to reset the camera’s Admin password back to factory default. For more information, refer to the camera’s user manual.
If you’ve got a monitor with VGA but not HDMI, connect it to the VGA output on the NVR.
Power Plug (use is optional). Note: only 12volt DC 1amp power adapters are supported using this connection.
Supply power to the NVR using the included power adapter.
BASIC SETUP
Connect an Ethernet cable from the LAN port on the NVR to a spare port on your rou ter.
If you’ve got a TV or monitor with HDMI in, connect to the HDMI port on the NVR.
Connect the mouse to the USB port.
9
BASIC SETUP
EN
Connecting Additional Devices
The spare USB 2.0 port can be used for connecting a USB Hard Drive to store some of your recordings (we recommend 1TB maximum for USB compatibility). The HDD will need to have been formatted on a PC first before it will be recognised. Note: Not all HDDs are supported.
BASIC SETUP
10
The spare USB 2.0 port can be used for backing up incident videos to a USB Flash Drive and applying new firmware. USB Flash Drives up to 32GB are supported.
BASIC SETUP
EN
Controlling the NVR
Starting the NVR for the first time
When you first boot the NVR, it will automatically start the Setup Wizard which will guide you through the various setup options available.
The USB Mouse
The easiest way to operate the NVR is to use the included USB optical mouse - we put together the look and feel of the menu system specifically for mouse-friendly navigation.
The controls are pretty easy to remember - heck, there are only two buttons. It couldn’t be simpler.
Left click:
Selects an item or confirms a choice.
Right click:
Opens the menu bar from the live viewing screen. Returns one “step” from a submenu. Opens a context menu in some settings screens.
The Scroll Wheel:
Can be used to adjust the values of sliders and scales when highlighted by the mouse.
Note
Wireless Mice and Bluetooth devices are NOT compatible with the NVR. Please use the USB optical mouse supplied.
BASIC SETUP
11
BASIC SETUP
EN
Setup Wizard: General
The Setup Wizard will run automatically the first time you start the NVR.
The wizard will guide you through all the settings you need to get your NVR up and working, specifically:
Choosing your Language
Setting Video Format and Resolution
Setting the Date Format and your Time Zone
Configuring your email account settings so that the NVR can send you alerts and the NVR UID
Synchronizing the NVR’s time with an online server
Choosing the settings for Daylight Savings Time (DST)
Changing the NVR’s Admin account default password
General Configuration
BASIC SETUP
Language: Choose the language you’d like the menu system to be displayed in. Video Standard: Choose between NTSC (for the USA, Canada, Mexico, Japan, Korea and some other regions) or PAL (UK, Europe,
Australia and some other areas). If this is set incorrectly, images from your cameras will be distorted, black and white, or simply not appear at all.
Resolution: How many pixels the NVR will output. Typically, you’ll want to set this to be equal to the native resolution of your monitor/television (check the manufacturer’s documentation). If your monitor’s native resolution isn’t an option, then you’ll want to use the highest resolution possible without exceeding the maximum resolution of your monitor.
Time Zone: Choose the time zone you’re in. It’s really important to select the right time zone if you’re using NTP (Network Time Protocol).
Some common time zones: In the USA, EST (Eastern Standard Time) is GMT -5:00, where PST (Pacific Standard Time) is GMT -8:00. The UK is GMT +0:00, and the East Coast of Australia is GMT +10:00.
Menu Date Format: How you’d like the date to be displayed. Choose whichever format that’s standard in your region. UID: This is the NVR’s Unique IDentifier number which will be used later to connect your PC or SmartPhone to the NVR using
Swann’s Peer to Peer technology.
If you need to change any of these settings later, you can find these options here: Main Menu -> System -> General
12
BASIC SETUP
EN
Setup Wizard: Camera & Email
Camera
Here you can see a list of cameras that are connected to the NVR .
Note: The NVR automatically assigns cameras to channels in the order they were connected. Therefore, if there is a particular sequence that you want for your cameras, you will have to connect them one at a time. Or you can go to Main
Menu -> IP Camera -> Edit screen and order the
cameras manually. IP Address: Displays the unique IP number and
port number that is assigned to the network camera.
MAC Address: The Media Access Control address. This is a unique code which nothing else should share. You can’t change this one ­it’s hard set when the camera ships out.
Name: All cameras are by default named “C amer a1”. It’s very important that you change this to a name that will help you easily identify the camera (particularly helpful when there are multiple cameras with different IP addresses connected on the network). Also, whilst a camera IP address may sometimes change if the NVR or router was rebooted, the assigned camera name will always stay the same (unless if you change it).
Channel: The channel to which the camera has been assigned.
Email
If you want the NVR to send email alerts as alarm events are detected, then you’ll need to configure an outgoing email server for the NVR to use, and choose an email address for it to send to.
We recommend creating an account with Gmail (www.gmail.com) specifically for the NVR. These instructions assume you’re using a GMail account. If you’re using a different email, see “Network:
Advanced: Email Settings” on page 36 for
details.
Enable SSL or TLS: Enable. SMTP Server: The SMTP address of your email
server. There are 3 preset options to select from:
smtp.gmail.com, smtp.live.com or smtp.mail.yahoo. com
Other: Allows for custom definintion of an outgoing email server. See “Network: Advanced: Email
Settings” on page 36 if you want to use an email server other than ones provided. Recommended for advanced users ONLY.
SMTP Port: The SMTP port of your email server. Gmail’s is 465 (this value will self-populate) Sender Address: The email address you want your NVR to send alerts from. For example, your_email@gmail.com Sender Password: The password of your sending email address. Recipient Address : Enter an email address for the NVR to send alerts to (usually your personal email address). Attach Picture: When selected, the NVR will attach a still image to better illustrate what has caused the alarm/alert state. Interval: The minimum amount of time that must elapse after the NVR sends an email alert before it can be triggered again. Test: To check if you’ve set up email alerts properly, click the Test button. If your connection and email details are ok, you will see
a message on the NVR screen confirming the email was sent successfully. After a short delay, you will also receive an e-mail in your inbox (Recipient’s Address) informing you that email alerts from the NVR has been set up. If the test is unsuccessful, please check your sender’s address/password and recipient’s address(es) and try again.
UID: This is the NVR’s Unique IDentifier number. We will use this UID to configure the SwannView Link app & software and connect to your NVR. You can click the Send UID button to receive an email containing the UID (that’s assuming your email details are configured) or alternatively just make a note of the UID on a piece of paper or save it to a text file using NotePad application on your computer.
Send UID: When you’ve finished testing your email, click the Send UID button to send the NVR UID to your email address (Recipient’s Address) so you can use it for access from SwannView Link on your PC etc.
BASIC SETUP
13
BASIC SETUP
EN
Setup Wizard: System Time
NTP
NTP stands for “Network Time Protocol”. It’s a way for the NVR to connect to the Internet and automatically update and maintain
BASIC SETUP
accurate time. There’s no requirement to use NTP, but it’s easy to setup and free to use, so there’s really no reason not to. NTP Server: The server you’d like to use for NTP. They’re all quite comparable in terms of reliability and accuracy, so unless
you’ve got some kind of master plan for world domination (which is affected by the time, for some reason) then the default (pool.
ntp.org) works fine. NTP Port: The default is 123. You should only change this if you’re using a different NTP server, and you know they use a different
port. If you’re using pool.ntp.org, ensure the port is 123. Sync: Triggers the NVR to automatically synchronize its internal clock with the time server immediately. If your NVR is
connected to the Internet and the network is correctly configured, this will update almost instantly.
System Time: The NVR’s current date and time.
DST Configuration
If your time zone observes daylight saving time and you want your NVR’s clock to be updated automatically when daylight saving time starts and ends, make sure the Enable checkbox is selected.
Note: Make sure your time offset is set correctly or both your NVRs normal time and DST time may be out. Offset: The amount by which the time changes during DST. For the vast majority of locations, the offset is one hour, but
exceptions to this rule exist. Start Time / End Time: When DST begins and ends in your locale.
14
BASIC SETUP
EN
Setup Wizard: Account Configuration
Account Configuration
Here you can change the default password of the
Admin account. For on-going protection against
unauthorized access, we strongly suggest setting a new password for your Admin account.
User Name: The NVR’s default administration account, which is always called “Admin”. You can’t change the Admin user name.
Password: The password you’d like to be associated with the Admin account. A password can be between 1 and 8 characters in length, and consists of numbers only (no letters or symbols). The default password that’s masked on screen is “12345”.
Confirm Password: Re-enter the password to ensure accuracy.
Level: This field is greyed out because the Admin account always has the highest level of access. There are two additional access levels available - Guest and Operator.
Enable Password: Select this if you want to be prompted for the user account’s password when accessing the main menu. Display wizard when booting up (checkbox): Select this if you want the NVR to automatically run the configuration wizard when
it boots up. You can also run the wizard at any time by clicking the
icon on the NVR menu bar.
Default Password Information
To ensure your privacy, this NVR supports password protection.
The default, all-access username is “admin”. If the NVR asks you to log in before you’ve set a password, enter admin as your username and leave the password blank. This will give you access to all areas of the NVR.
The password function is disabled by default. However, if you’re asked for a password, the default is “12345”. To ensure your ongoing privacy, we strongly recommend setting a password as soon as possible. Choose something that
you’ll remember, but that others would be unlikely to guess. If you do manage to lock yourself out of the NVR, you’ll need to contact us at the Swann Technical Support Telephone
Helpdesk - the number is on the back cover.
Finishing the Setup Wizard
When you click Finish, the NVR will update and save your settings. It may reboot while doing so.
BASIC SETUP
15
BASIC SETUP
EN
Setting up your Smartphone or Tablet
Have a Smartphone or Tablet?
Then head to the respective Apple App Store or Google Play, download the SwannView Link app (or SwannView Link HD for tablets) for free and turn your iOS or Android device into a monitoring centre for your NVR. Have the peace of mind that you can monitor your home at any time from any place. With “SwannLink” Peer to Peer technology, connecting your smartphone, tablet or PC to your NVR is so easy - there’s practically no need to fiddle around with complicated network configuration. Best of all, it only takes minutes to get it all up and running!
Important Note: As the SwannView Link app is constantly under development to improve your user experience, the
following screens may differ slightly from the actual app.
Configuring the SwannView Link App
After you have downloaded and installed SwannView Link (HD) on your smartphone or tablet, locate the app and tap the icon to run. Take your smartphone/tablet to your NVR and follow the instructions below.
1. In the Live View screen, tap at the top left and then tap .
BASIC SETUP
2. In the Devices menu, tap + to add a new Device as shown below.
3. On the NVR you will see a sticker with a QR Code and your UID number (the sticker will be on the top or bottom of the NVR
On the app, tap the QR Code button and use your smartphone’s camera to scan the QR sticker on the NVR. This
4. Next, tap to automatically check the number of channels and then you will see your cameras on screen and
Remember to check the Swann website for updates and more information: www.swann.com
case depending on which NVR model you have).
automatically populates the UID box with the NVR’s UID. Enter a Device Name (anything you like), the username and password for your NVR as shown below and tap to save your settings.
that’s it, you’re connected!
16
BASIC SETUP
EN
Setting up your PC
SwannView Link Software
Your NVR comes with powerful remote access and interface software, called SwannView Link. You can setup and configure almost all aspects of the NVR from the SwannView Link interface.
The SwannView Link software will allow you to:
view images from your NVR in real-time,
playback recorded footage,
copy footage to your local PC and
adjust settings and configure the NVR. In fact, the SwannView Link software is so powerful, you don’t
even need to connect a monitor to the NVR if there’s a computer on the local network that you’re running SwannView Link on.
For quick and easy configuration of the NVR’s settings, recording quality and schedule, we suggest using the remote
interface in SwannView Link.
How to install SwannView Link:
Insert the included CD into your computer.
Locate the file called SwannView Link and run this file.
You may be asked by UAC (User Account Control) to allow SwannView Link to “make changes” to your system. Select Allow or Continue.
You’ll see an installation wizard. Simply follow the prompts to install the software.
Once the SwannView Link software is installed, it should automatically detect your NVR on your network.
Minimum PC Requirements:
2.0GHz or faster CPU (Dual-core recommended)
1GB or more RAM (2GB recommended) 10/100Mbps Network (1000Mbps recommended) Internet connection (512kbps+ recommended)
1024x768 resolution (1280x720 recommended)
Supported Operating Systems
Microsoft Windows XP, Microsoft Windows Vista, Microsoft Windows 7
NOTE: Windows XP, Windows Vista and Windows 7 are registered trademarks of Microsoft Corporation.
BASIC SETUP
Got a Mac?
Check out www.swann.com/myDVRmac for the latest Mac-based remote access software.
17
EN
Main Viewing
Area
Playback and Backup Links
Viewing Modes
& Volume Control
Image Controls
Preview / Playback / Setup
Channel List
Logging on to SwannView Link
To connect from your PC to your NVR, make sure your NVR is on and
On your PC, open the email that your NVR sent when you were
Copy the UID (highlight the text - right click with your mouse and
Then, enter your Username (the default of admin is already entered) and Password (default is 12345), then click Login.
BASIC SETUP
BASIC SETUP
Setting up your PC
all connections are ok.
setting up your email account during the Setup Wizard which should look something like this image and locate the the UID:
click “Copy”). In this example, start with the X and end with the T then paste it into the field marked UID as shown above right. If you made a note of the UID on a piece of paper or saved it to a text file using NotePad application on your computer, type or copy this into the UID field.
After a few seconds, you will see your cameras live on your PC.
Main Stream or SubStream?
Each video feed of the NVR is comprised of two components, the Main Stream and the SubStream. Main Stream is the higher quality of the two streams, and is what you’ll see on the NVR itself or via a local network. Substream is a fraction of the Main
Stream, and what you’ll see over the Internet or via a mobile device. Typically, the Substream will be of significantly lower
quality and bitrate than the Main Stream.
SwannView Link Interface
After you successful log on to SwannView Link, you will see the following screen:
Need more details?
Full explanation of the SwannView Link’s software interface and remote configuration options are detailed in the Appendix from page 49 onwards. SwannView Link’s software interface is functionally very similar to the NVR’s menu system, and you’ll find more detailed information about all menu options and settings there.
18
Loading...
+ 40 hidden pages
