Swann DVR8-2550 Setup Manual

Easy Setup Guide

8ch H.264 DVR

A

C

Remote

Control

8ch H.264 DVR

Power Adapter

Back of TV

INPUT

Easy Set Up Components

BNC to RCA Cable

Cable

DVR Power
Adapter

Cameras and Accessories Optional

Connecting the DVR to TV

Connect the RCA end of the
RCA to BNC cable to the

1

back of the TV INPUT

socket

Connect the BNC plug end
of the cable to the top

2

VIDEO INPUT socket on

the back of the DVR

B

Cameras Optional

Connect the camera cable’s BNC
socket & DC socket to the BNC

1

plug & DC plug on the extension cable.

Connect the other end of the BNC
plug of the extension cable to the

2

camera connections on the back of
the DVR.

Camera Connections

Connect the DC power sockets on the extension
cables to the power splitter’s DC plugs.

3

Connect the power
splitter’s DC socket

4

to the DC plug on
the power supply.

Tune your TV to the
correct INPUT - this is

3

sometimes labelled A/V,
input, source, L1, L2, etc.

- consult TV manual for details

Back of DVR

Plug in the DVR and
camera power adapter to

5

power outlets.

E82550H180111E
