USER’S MANUAL
Wireless Optical Mouse
RX-525
Silent
Wireless
Page 2
2
2
2
3
3
6
6
Congratulations on your purchase of the SVEN PC mouse!
Please read the following instructions carefully before connecting, operating
or adjusting this product. Besides, please keep this Manual in a safe place
for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information in this Manual is given on «as is»
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SPECIAL FEATURES ..................................................
2. PACKAGE CONTENTS ................................................
3. SYSTEM REQUIREMENTS ..........................................
4. DESCRIPTION .........................................................
5. INSTALLATION .........................................................
6. TROUBLESHOOTING ................................
.................
7. TECHNICAL SPECIFICATIONS ...........................
...........
Technical support is on www.sven.fi
ENG
1
User’s Manual
RX-525 Silent
Wireless
Page 3
ENG
2
Wireless Optical Mouse
1. SPECIAL FEATURES
• Silent buttons
• Full-sized mouse
• BlueLED advanced optical technology
• Power saving wireless technology
• Effective on most surfaces
• High operating speed
• 2.4GHz USB nano receiver included (range – up to 10 m)
• Two additional Forward and Back navigation buttons
• 800/1200/1600 dpi resolution switch
• Power on/off switch
• USB interface
• 2 AA type batteries
• Soft Touch coating
• No drivers required for Windows XP/Vista/7/8
• Natural shape of the mouse convenient for the hand
2. PACKAGE CONTENTS
• Optical mouse — 1 рс
• 2.4 GHz USB nano receiver — 1 рс
• AA type batteries — 2 рсs
• User’s Мanual — 1 рс
• Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8.
• Free USB port.
Page 4
e
f
g
d
AA
AA
g
h
a
b
c
4. DESCRIPTION
a Scroll wheel
b Resolution switch
c Additional Forward and Back
navigation buttons
d Power on/off switch
e Optical sensor
f Battery compartment
g Nano receiver
h USB connector
Fig. 1. Top view
Fig. 2. Bottom view
Fig. 3. Nano receiver
5. INSTALLATION
• Open the cover of the mouse battery compartment f, insert two AA
type batteries into the battery compartment, matching the polarity, and
close the cover of the battery compartment (see Fig. 4).
• Pull out the nano receiver g from the mouse (Fig. 5) and connect it to an
available PC USB port without switching off the PC (Fig. 6).
ENG
3
User’s Manual
RX-525 Silent
Wireless
Page 5
ENG
4
Wireless Optical Mouse
• Turn on the mouse with the Power on/off switch d. To activate the mouse,
press any button of the mouse or turn the scroll wheel. If the mouse is
connected correctly, it will turn on automatically.
Fig. 4. Batteries installation
Fig. 5. Extraction of the receiver
from the mouse case
Fig. 6. Receiver connection
2 × AA type batteries
Battery
compartment
Battery cover
Improper installation of
batteries can result in failure
of the mouse!
Page 6
ENG
5
User’s Manual
• After finishing your work, shift the Power on/off switch d back to the Off
position. Then take the nano receiver out of the USB port and insert it back
into the mouse. (Fig. 7).
• Do not place the receiver in a metal confined space (table drawer, box,
safe), as a metal screen does not transmit radio signals.
• If the batteries run down, the mouse works in jerks. It means that the batteries should be replaced with new ones, as it is shown in Fig. 4. Always
install only identical new batteries.
Fig. 7. Fitting the receiver
into the mouse case
This device meets the highest standards of energy conservation.
Use the switch d on the bottom of the mouse to switch it on/off –
it will help you extend the mouse battery life.
Important
RX-525 Silent
Wireless
Page 7
ENG
6
Wireless Optical Mouse
6. TROUBLESHOOTING
Solution
1. Make sure that the nano receiver has been
inserted into the USB port and its distance to the
mouse is less than 10 m.
2. Check if the batteries have been installed correctly.
3. Check if the batteries have run down, replace the
batteries with new ones if necessary.
4. Check the position of the switch. Shift it to the
necessary position if needed.
5. Address nearest authorized service center.
Problem
The mouse doesn’t
work.
7.
TECHNICAL SPECIFICATIONS
Parameter, measurement unit
OS compatibility
Type of mouse
Resolution, dpi
Q-ty of buttons
Interface
Operating range, m
Dimensions, mm
Weight, g
Value
Windows XP/Vista/7/8
Wireless 2.4 GHz
800/1200/1600
5 + 1 (scroll wheel)
USB
10
85 × 40 × 120
85
Notes:
• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to
the improvement of SVEN production.
