Sven RX-410W User Manual

www.sven.fi

USER’S MANUAL

Wireless Optical Mouse

RX-410W

2
2
2
3
3
6
6

Congratulations on purchasing the SVEN PC mouse!

Please read the following instructions carefully before connecting,
operating or adjusting this product. Besides, please keep this manual in a
safe place for future reference.

COPYRIGHT

© 2011. SVEN Company Ltd. Version 1.0 (V 1.0). This manual and information
contained in it are copyrighted. All rights reserved.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted efforts to make this manual more exact, some
discrepancies may occur. The information of this manual is given on «as is»
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damages which have arisen from the information
contained in the given manual.

CONTENTS

1. SPECIAL FEATURES ..................................................

2. PACKAGE CONTENTS ................................................

3. SYSTEM REQUIREMENTS ..........................................

4. DESCRIPTION .........................................................

5. INSTALLATION .........................................................

6. TROUBLE SHOOTING ................................................

7. TECHNICAL SPECIFICATION ........................................

Technical support is on www.sven.fi

ENG

1

User’s Manual

RX-410W

1. SPECIAL FEATURES

• RF2.4GHz USB nano receiver (range – up to 10 m)

• High-precision optical technology. Effective on most surfaces

• High-speed operation

• 2 + 1 buttons

• Scroll wheel

• Resolution 1000 dpi

• Interface USB

• 2 AAA alkaline batteries

• Rubberized mouse casing

• Drivers installation not required for Windows 2000/МE/XP/Vista/7

• Convenient for both right and left hand

• Perfect energy system increases battery life up to 6 months (see

comparison table)

2. PACKAGE CONTENTS

• Optical mouse — 1 рс

• 2.4 GHz USB nano receiver — 1 рс

• AAA type batteries — 2 рсs

• User’s manual — 1 рс

• Warranty card — 1 рс

3. SYSTEM REQUIREMENTS

• Windows 2000/XP/Vista/7 or higher, Mac OS 10.4 or higher, Linux

• Free USB port

Operating mode

During work 4.8 — 6 mА 10 mА

Motionless 0.5 — 0.55 mА 8 mА

Standby mode 0.1 — 0.12 mА 3 mА

Sleeping mode 0.03 — 0.05 mА 0.15 mА

Other miceRX-410W

2

ENG

Wireless Optical Mouse

4. DESCRIPTION

a Scroll wheel
b Optical sensor
c Battery compartment
d Nano receiver
e USB connector

Fig. 1. Top view

Fig. 2. Bottom view Fig. 3. Nano receiver

a

d

e

b

c

d

5. INSTALLATION

• Open cover of the mouse battery compartment c, insert two AAA type

batteries into the battery compartment matching polarity, and close the
cover of the battery compartment (see Fig. 4).

• Pull out the nano receiver d from the mouse (Fig. 5) and connect it to an
available PC USB port without switching off the PC (Fig. 6). To activate the
mouse, press any button of the mouse or turn the scroll wheel. If the mouse
is connected correctly, it will turn on automatically.

ENG

3

User’s Manual

RX-410W

ENG

Wireless Optical Mouse

4

Improper installa­tion of batteries can
result in failure of
the mouse!

Fig. 4. Batteries installation

Fig. 5. Extraction of the receiver

from the mouse case

Fig. 6. Receiver connection

Battery cover

Battery

compartment

2 х AAA type batteries

This device meets highest standards of energy conservation. During
long pauses in operation the mouse enters the economical Sleep
mode. To enter the working mode, just press any button or turn the
scroll wheel.

Important

• After finishing work, the receiver can be pulled out from the PC USB port

and inserted back into the mouse (Fig. 7).

• Do not place the receiver in a metal confined space (table drawer, box,
safe), as a metal screen does not transmit radio signals.

• If the batteries run down, the mouse works by fits. It means that batteries
should be replaced with new ones, as it is shown in Fig. 4. Always install
only identical new batteries.

Fig. 7. Fitting the receiver

into the mouse case

2,4 GHz

ENG

5

User’s Manual

RX-410W

Notes:

• Technical specification given in this table is supplemental informa-
tion and cannot give occasion to claims.

• Technical specification is subject to change without notice due to
improvement of SVEN production.

7.

TECHNICAL SPECIFICATION

Parameter

OS required

Type of mouse

Resolution

Q-ty of buttons

Interface

Conformity with

Value

Windows 2000/XP/Vista/7

Wireless 2.4 GHz

1000 dpi

2 + 1

USB

FCC, CE

6. TROUBLE SHOOTING

Solution

1. Make sure that the nano receiver has
been inserted into the USB port and its
distance to the mouse is less than 10 m.

2. Check if the batteries have been installed
correctly.

3. Check if the batteries have run down, re­place the batteries with new ones if neces­sary.

Install the software to coordinate the mouse
and the receiver. Software can be
downloaded from Support on www.sven.fi

Problem

The mouse does not work.

Batteries are in good order,
but the mouse still does not
work.

ENG

Wireless Optical Mouse

6

Модель:

RX-410W

Импортер в России: ООО «СКАНДИТРЕЛ»,
111024, РФ, г. Москва,

ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi
Гарантийный срок: 12 мес.
Срок службы: 2 года.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка

,

Котолахдентие, 15. Сделано в Китае.

Модель:

RX-410W

Постачальник/імпортер в Україні: ТОВ «СВЕН
Центр». Київська область, м. Переяслав­Хмельницький, вул. Героїв Дніпра, 31.
Призначення, споживчі властивості та відомості
про безпеку товару див. у керівництві
користувача.
Умови гарантійного обслуговування дивіться в
гарантійному талоні або на сайті www.sven.fi
Гарантійний термін: 12 міс.
Строк служби: 2 роки.
Товар сертифіковано/має гігієнічний висновок.
Шкідливих речовин не містить.
Зберігати в сухому місці.
Виготовлено під контролем «Свен Скандинавія
Лімітед», 48310, Фінляндія, Котка, Котолахдентіє,

15. Зроблено в Китаї.

Produced under the control of Oy Sven Scandinavia
Ltd. 15, Kotolahdentie, KOTKA, Finland, 48310.
Made in China.

® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
