Page 1
Wireless Optical Mouse
USER’S MANUAL
RX-360 Art
Wireless
www.sven.fi
Page 2
ENG
User’s Manual
Congratulations on your purchase of the SVEN PC mouse!
Please read the following instructions carefully before connecting, operating
or adjusting this product. Besides, please keep this Manual in a safe place
for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information in this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SPECIAL FEATURES ....................................................
2. PACKAGE CONTENTS ..................................................
3. SYSTEM REQUIREMENTS ............................................
4. DESCRIPTION ...........................................................
5. INSTALLATION ...........................................................
6. TROUBLESHOOTING ................................
7. TECHNICAL SPECIFICATIONS ...........................
RX-360 Art
Wireless
...................
.............
Technical support is on www.sven.fi.
1
2
2
2
3
3
6
6
Page 3
ENG
Wireless Optical Mouse
1. FEATURES
• Blue LED advanced optical technology
• Stylish ergonomic design
• 2.4 GHz USB nano receiver included (range of action up to 10 m)
• Effective on most surfaces
• High speed operation
• Resolution 1200 dpi
• USB interface
• Battery long service life (1 year)
• Installation drivers for Windows XP/Vista/7/8 are not required
• Сonvenient with laptops
2. PACKAGE CONTENTS
• Optical mouse — 1 рс
• 2.4 GHz USB nano receiver — 1 рс
• AA battery — 1 рс
• User’s Мanual — 1 рс
• Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8.
• Free USB port.
2
Page 4
User’s Manual
4. DESCRIPTION
a Scroll wheel
b ON/OFF power switch
c Battery compartment
d Optical sensor
e Nano receiver
f USB connector
ENG
RX-360 Art
Wireless
a
b
c
e
Fig. 2. Bottom view
5. PREPARATION TO OPERATION
• Open the cover of the mouse battery compartment c, insert the AA
battery into the battery compartment observing the polarity and close the
cover of the battery compartment (see Fig. 4).
• Сonnect the included nano receiver e to a free PC USB port (Fig. 5).
d
Fig. 1. Top view
f
e
Fig. 3. Nano receiver
3
Page 5
ENG
Wireless Optical Mouse
• Switch on the mouse with the power switch b (ON position). Press any
button of the mouse or rotate the scroll wheel to activate the mouse. If the
mouse has been connected correctly, it will be switched on automatically.
Improper installation of
batterу can result in failure
of the mouse!
Battery
compartment
AA battery
4
Battery compartment
Fig. 4. Battery installation
Fig. 5. Receiver connection
cover
Page 6
ENG
User’s Manual
finishing your work
• After
(OFF position)
port and insert it into the mouse (Fig. 6).
extract it from the mouse (Fig. 7) and connect it to the PC USB port again.
• Do not place the receiver in a metal confined space (table drawer, box,
safe), as metal screen does not transmit radio signals.
• If the battery is discharged, the mouse works by fits. It means that the
battery should be replaced with a new one, as it is shown in Fig. 4.
. After this you can extract the receiver e from the PC USB
switch off the mouse with the power switch b
RX-360 Art
Wireless
When using the receiver again,
Fig. 6. Fitting the receiver
into the mouse case
Important
This device meets the highest standards of energy conservation.
Use the switch
it will help you to extend the mouse battery life.
b on the bottom of the mouse to switch it on/off –
Fig. 7. Extraction of the receiver
from the mouse case
5
Page 7
ENG
Wireless Optical Mouse
6. TROUBLESHOOTING
Problem
The mouse does not
work.
7.
TECHNICAL SPECIFICATIONS
Parameter
OS compatibility
Mouse type
Resolution, dpi
Quantity of buttons
Interface
Dimensions, mm
Weight, g
Notes:
• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to
the improvement of SVEN production.
Solution
1. Make sure that the nano receiver has been
inserted into a USB port and its distance to
the mouse is less than 10 m.
2. Check whether the battery has been
installed correctly.
3. Check if the battery is charged, replace the
battery with new one if necessary.
4. Address the nearest authorized service center.
Value
Windows XP/Vista/7/8
wireless 2.4 GHz
1200
2 + 1 (scroll wheel)
USB
94 × 40 × 58
79
6
Page 8
Wireless Optical Mouse
Модель:
RX-360 Art Wireless
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD, 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
