Page 1
www.sven.fi
USER’S MANUAL
Wireless Optical Mouse
RX-350W
Page 2
Technical support: www.sven.fi
ENG
1
User’s Manual
2
2
2
3
3
6
6
Congratulations on purchasing the SVEN PC mouse!
Please read the following User’s Manual carefully before connecting,
operating or adjusting this product. Besides, please keep this Manual in a
safe place for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information of this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damages which have arisen from the information
contained in the given Manual.
СОДЕРЖАНИЕ
1. SPECIAL FEATURES ..................................................
2. PACKAGE CONTENTS ................................................
3. SYSTEM REQUIREMENTS ..........................................
4. DESCRIPTION .........................................................
5. INSTALLATION .........................................................
6. TROUBLESHOOTING ................................................
7. TECHNICAL SPECIFICATION ........................................
RX-350W
Page 3
Standby mode 0.1 — 0.12 mА 3 mА
Motionless 0.5 — 0.55 mА 8 mА
During work 48 — 6 mА 10 mА
1. SPECIAL FEATURES
• Power saving wireless technology
• Stylish ergonomic design
• 2.4 GHz USB Nano receiver included (range – up to 10 m)
• Resolution 1200/1800 dpi
• DPI resolution switch
• Two additional navigation buttons (Forward and Back)
• USB interface
• 2 AAA Alkaline type batteries
• Soft Touch coating
• Drivers installation is not required for Windows XP/Vista/7/8
• Energy saving system increases battery life up to 6 months (see compa-
rison table):
2. PACKAGE CONTENTS
• Optical mouse — 1 рс
• 2.4 GHz USB Nano-receiver — 1 рс
• AAA type batteries — 2 рсs
• User’s manual — 1 рс
• Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8, Mac OS 10.4 or higher, Linux
• Free USB port
Sleeping mode 0.03 — 0.05 mА 0.15 mА
Operating mode
Other mousesRX-420W
ENG
2
Wireless Optical Mouse
Page 4
f
g
c
a
b
d
e
f
4. DESCRIPTION
a Scroll wheel
b DPI switch
c Forward and Back navigation buttons
d Optical sensor
e Battery compartment
f Nano receiver
g Connector USB
Fig. 1. Top view
Fig. 2. Bottom view
Fig. 3. Nano receiver
5. INSTALLATION
• Open the cover of the mouse battery compartment e, insert two AAA type
batteries into the battery compartment, matching polarity, and close the
cover of the battery compartment (see Fig. 4).
• Pull out the nano receiver f from the mouse (Fig. 5) and connect it to a free
PC USB port without switching off the PC (Fig. 6). To activate the mouse,
press any button of the mouse or turn the scroll wheel. If the mouse has
been connected correctly, it will turn on automatically.
ENG
3
User’s Manual
RX-350W
Page 5
Improper installation of batteries can
result in failure of
the mouse!
Fig. 6. Receiver connection
ENG
4
SVEN
2 × AAA type batteries
Fig. 4. Batteries installation
Fig. 5. Extraction of the receiver
from the mouse case
Battery com-
partment cover
Battery
compartment
Wireless Optical Mouse
Page 6
SVEN
This device meets highest standards of energy conservation. During
long pauses in mouse operation it enters economical sleeping mode.
To enter working mode just press any button or turn the scroll wheel.
Important
• After finishing work, receiver can be pulled out from PC USB port and
inserted back into mouse (Fig. 7).
• Do not place receiver in a metal confined space (drawer of the table, box,
safe), as metal screen does not transmit radio signals.
• If batteries run down, mouse works in fits and starts. It means that bat-
teries should be changed for new ones, as it is shown in Fig. 4. Always
install only new and same batteries.
Fig. 7. Setting of receiver
in the corps of mouse
ENG
5
User’s Manual
RX-350W
Page 7
Notes:
• Technical specification given in this table is supplemental infor-
mation and can not give occasion to claims.
• Technical specification is subject to change without notice due to
improvement of SVEN production.
7.
TECHNICAL SPECIFICATION
Parameter
OS compatibility
Type of mouse
Resolution, dpi
Q-ty of buttons
Interface
Dimensions, mm
Weight, g
Value
Windows XP/Vista/7/8
Wireless 2.4 GHz
1200/1800
5 + 1 (scroll wheel)
USB
65 × 37 × 108
80
6. TROUBLESHOOTING
Solution
1. Make sure that Nano-receiver has been
inserted into USB port and its distance to
mouse does not exceed 10 m.
2. Check whether batteries have been
installed correctly.
3. Check whether batteries have not run down,
change batteries for new ones if necessary.
4. Address nearest authorized service
center.
Problem
Mouse is not working.
ENG
6
Wireless Optical Mouse
Page 8
Модель:
RX-350 Wireless
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
RX-350W
Wireless Optical Mouse
