Page 1
www.sven.fi
USER’S MANUAL
Wireless Optical Mouse
RX-320
Wireless
Page 2
ENG
1
User’s Manual
RX-320
Wireless
2
2
2
3
3
6
6
Congratulations on your purchase of the SVEN PC mouse!
Please read the following instructions carefully before connecting, operating
or adjusting this product. Besides, please keep this Manual in a safe place
for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information in this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SPECIAL FEATURES ..................................................
2. PACKAGE CONTENTS ................................................
3. SYSTEM REQUIREMENTS ..........................................
4. DESCRIPTION .........................................................
5. INSTALLATION .........................................................
6. TROUBLESHOOTING ................................
.................
7. TECHNICAL SPECIFICATIONS ...........................
...........
Technical support is on www.sven.fi
Page 3
ENG
2
Wireless Optical Mouse
1. SPECIAL FEATURES
• Power efficient invisible sensor
• High-precision optical technology
• 2.4GHz USB nano receiver included (range up to 10 m)
• Effective on most surfaces
• High speed operation
• Optics construction prevents ingress of dust
• Resolution 1000 dpi
• USB interface
• Powered by 2 AAA batteries
• Drivers installation is not required for Windows XP/Vista/7/8
• Сonvenient with laptops
• Suitable for left-handers
2. PACKAGE CONTENTS
• Optical mouse — 1 рс
• 2.4 GHz USB nano receiver — 1 рс
• AAA batteries — 1 рс
• User’s Мanual — 1 рс
• Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8.
• Free USB port.
Page 4
ENG
3
User’s Manual
RX-320
Wireless
a
f
e
c
d
b
4. DESCRIPTION
a Scroll wheel
b Battery compartment
c Optical sensor
d ON/OFF: power switch
e USB connector
f Nano receiver
Fig. 1. Top view
Fig. 2. Bottom view Fig. 3. Nano receiver
5. INSTALLATION
• Open the cover of the mouse battery compartment b, insert 2 AAA
batteries into the battery compartment matching the polarity, and close the
cover of the battery compartment (see Fig. 4).
• Сonnect the included nano receiver f to a free PC USB port (Fig. 5).
Page 5
ENG
4
Wireless Optical Mouse
Fig. 4. Battery installation
Fig. 5. Receiver connection
AAA batteries
Battery
compartment
Improper installation of
batteries can result in failure
of the mouse!
• Turn on the mouse with the power switch d (the ON position). To acti-
vate the mouse, press any button of the mouse or turn the scroll wheel. If
the mouse has been connected correctly, it will turn on automatically.
Battery compartment
cover
Page 6
ENG
5
User’s Manual
RX-320
Wireless
This device meets the highest standards of energy conservation.
Use the switch
d on the bottom of the mouse to switch it on/off –
it will help you extend the mouse battery life.
Important
•
After finishing work
turn off the mouse with the power switch d (the OFF
position)
.
After this, you can pull out the receiver f from the PC USB port
and insert it into the mouse (Fig. 6).
When using the receiver again, pull it
out from the mouse (Fig. 7) and connect it to the PC USB port again.
• Do not place the receiver in a metal confined space (table drawer, box,
safe), as metal screen does not transmit radio signals.
• If the the battery runs down, the mouse works by fits. It means that the
battery should be replaced with a new one, as it is shown in Fig. 4.
Fig. 6. Fitting the receiver
into the mouse case
Fig. 7. Extraction of the receiver
from the mouse case
Page 7
ENG
6
Wireless Optical Mouse
Notes:
• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to
the improvement of SVEN production.
7.
TECHNICAL SPECIFICATIONS
Parameter
OS compatibility
Type of mouse
Resolution, dpi
Q-ty of buttons
Interface
Dimensions, mm
Weight, g
Value
Windows XP/Vista/7/8
wireless 2.4 GHz
1000
2 + 1 (scroll wheel)
USB
60 × 35 × 99
59
6. TROUBLESHOOTING
Solution
1. Make sure that the nano receiver has been
inserted into a USB port and its distance to
the mouse is less than 10 m.
2. Check whether the batteries have been
installed correctly.
3. Check if the batteries have run down, replace
the batteries with new ones if necessary.
4. Address nearest authorized service center.
Problem
The mouse does not
work.
Page 8
Модель:
RX-320 Wireless
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie,
Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
RX-320
Wireless
Wireless Optical Mouse
