Page 1
www.sven.fi
USER’S MANUAL
RX-310
Wireless
Wireless Optical Mouse
Page 2
2
2
2
3
3
6
6
Congratulations on your purchase of the SVEN PC mouse!
Please read the following instructions carefully before connecting, operating
or adjusting this product. Besides, please keep this Manual in a safe place
for future reference.
COPYRIGHT
© 2014. SVEN PTE. LTD. Version 1.0 (V 1.0).
This Manual and information contained in it are copyrighted. All rights
reserved.
TRADEMARKS
All trademarks are the property of their legal holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some
discrepancies may occur. The information in this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SPECIAL FEATURES ..................................................
2. PACKAGE CONTENTS ................................................
3. SYSTEM REQUIREMENTS ..........................................
4. DESCRIPTION .........................................................
5. INSTALLATION .........................................................
6. TROUBLESHOOTING ................................
.................
7. TECHNICAL SPECIFICATIONS ...........................
...........
Technical support is on www.sven.fi
ENG
1
User’s Manual
RX-310
Wireless
Page 3
ENG
2
Wireless Optical Mouse
1. SPECIAL FEATURES
• BlueLED advanced optical technology
• Power saving wireless technology
• Symmetric shape
• Effective on most surfaces
• High speed operation
• 2.4GHz USB nano receiver included (range up to 10 m)
• Resolution 1200 dpi
• USB interface
• Powered by AA battery
• Drivers installation is not required for Windows XP/Vista/7/8
• Symmetrical shape of the mouse
• Convenient for laptop operation
2. PACKAGE CONTENTS
• Optical mouse — 1 рс
• 2.4 GHz USB nano receiver — 1 рс
• AA battery — 1 рс
• User’s Мanual — 1 рс
• Warranty card — 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8.
• Free USB port.
Page 4
a
d
e
c
d
b
4. DESCRIPTION
a Scroll wheel
b Battery compartment
c Optical sensor
d Nano receiver
e USB connector
Fig. 1. Top view
Fig. 2. Bottom view Fig. 3. Nano receiver
5. INSTALLATION
• Open the cover of the mouse battery compartment b, insert the AA
battery into the battery compartment matching the polarity, and close the
cover of the battery compartment (see Fig. 4).
• Сonnect the included nano receiver d to a free PC USB port (Fig. 5). To
activate the mouse, press any button of the mouse or turn the scroll wheel.
If the mouse has been connected correctly, it will turn on automatically.
ENG
3
User’s Manual
RX-310
Wireless
Page 5
Fig. 4. Battery installation
Fig. 5. Receiver connection
AA battery
Battery
compartment
Improper installation of the
battery can result in failure
of the mouse!
Battery compartment
cover
ENG
4
Wireless Optical Mouse
Page 6
•
After finishing your work, you can pull out the receiver d from the PC
USB port and insert it into the mouse (Fig. 6).
When using the receiver
again, pull it out from the mouse (Fig. 7) and connect it to the PC USB port
again.
• Do not place the receiver into a confined metal space (table drawer, box,
safe), as a metal screen does not transmit radio signals.
• If the battery runs down, the mouse works by fits. It means that the
battery should be replaced with a new one, as it is shown in Fig. 4.
Fig. 6. Fitting the receiver
into the mouse case
Fig. 7. Extraction of the receiver
from the mouse case
This device meets the highest standards of energy conservation.
During long pauses in operation the mouse enters the economical
Sleep mode. To enter the working mode just press any button or
turn the scroll wheel.
Important
ENG
5
User’s Manual
RX-310
Wireless
Page 7
Notes:
• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications are subject to change without notice due to
the improvement of SVEN production.
7.
TECHNICAL SPECIFICATIONS
Parameter
OS compatibility
Type of mouse
Resolution, dpi
Q-ty of buttons
Interface
Dimensions, mm
Weight, g
Value
Windows XP/Vista/7/8
wireless 2.4 GHz
1200
2 + 1 (scroll wheel)
USB
62 × 40 × 101
54.5
6. TROUBLESHOOTING
Solution
1. Make sure that the nano receiver has been
inserted into the USB port and its distance to
the mouse is less than 10 m.
2. Check whether the battery has been
installed correctly.
3. Check if the battery has run down, replace
the battery with a new one if necessary.
4. Address nearest authorized service center.
Problem
The mouse does not
work.
ENG
6
Wireless Optical Mouse
Page 8
Модель:
RX-310 Wireless
Импортер в России: ООО «СКАНДИТРЕЛ», 111024,
РФ, г. Москва, ул. Авиамоторная, д. 65, стр. 1.
Уполномоченная организация в России:
ООО «РТ-Ф», 105082, г. Москва, ул. Фридриха
Энгельса, д. 75, стр. 5.
Условия гарантийного обслуживания смотрите
в гарантийном талоне или на сайте www.sven.fi.
Гарантийный срок: 12 мес. Срок службы: 2 года.
Производитель: «СВЕН ПТЕ. Лимитед»,
176 Джу Чиат Роуд, № 02-02, Сингапур, 427447.
Произведено под контролем «Свен Скандинавия
Лимитед», 48310, Финляндия, Котка,
Котолахдентие, 15. Сделано в Китае.
Manufacturer: SVEN PTE. LTD., 176 Joo Chiat Road,
№ 02-02, Singapore, 427447. Produced under the
control of Oy Sven Scandinavia Ltd. 15, Kotolahdentie, Kotka, Finland, 48310. Made in China.
® Registered Trademark of Oy SVEN
Scandinavia Ltd. Finland.
RX-310
Wireless
Wireless Optical Mouse
