Suunto Escape 203 Operation Manual

Escape203

Barometer Alarm Symbol

Barometer Trend Indicator

Altimeter/Barometer Alarm Symbol Field 4

Low Battery Warning

Field 3

Mode Indicator

Field 1

Field 2

[-] -Button

Altimeter Function Indicator

Weather Station Function Indicator

[+] -Button

Center Button

TABLE OF CONTENTS

1. INTRODUCTION .................................................................................................. 4

1.1. GENERAL INFORMATION .........................................................................4

1.2. LCD DISPLAY .............................................................................................4

1.3. BUTTON FUNCTIONS ................................................................................4

1.3.1. The Center Button ............................................................................ 4

1.3.2. The [-] Minus Button ......................................................................... 5

1.3.3. The [+] Plus Button ...........................................................................5

1.4. MAIN FUNCTIONS (MODES) ..................................................................... 5

1.4.1. Time [TIME] ......................................................................................5

1.4.2. Altimeter [ALTI] ................................................................................. 6

1.4.3. Altimeter Memory [LOG] ................................................................... 6

1.4.4. Barometer [BARO] ........... .................................................................6

1.4.5. Barometer Memory [MEM] ................................................................ 7

1.4.6. Other Functions ................................................................................7

1.5. CARE AND MAINTENANCE ....................................................................... 8

1.5.1. Battery Replacement ........................................................................8

2. TIME MODE [TIME] ............................................................................................10

2.1. SETTING THE TIME (WATCH FUNCTION) ............................................. 10

2.2. SETTING UNITS OF MEASUREMENT ....................................................12

3. ALTIMETER MODE [ALTI] .................................................................................14

3.1. SETTING THE ALTIMETER ........................... ..........................................15

3.1.1. Setting the Reference Altitude ........................................................ 15

3.1.2. Zeroing the Altitude Difference .......................................................16

3.1.3. Setting the Altitude Alarm ...............................................................16

3.1.4. Adjusting the Resolution ..................................................................17

3.2. ENTERING AN ALTITUDE POINT INTO MEMORY .................................17

4. ALTIMETER MEMORY MODE [LOG] .................................................................19

4.1. HOW TO START AND STOP A LOGBOOK ..............................................19

4.2. READING THE ALTIMETER MEMORY ....................................................20

4.3. CLEARING THE ALTIMETER MEMORY ..................................................21

4.3.1. To Clear the Altitude Points .............................................................22

4.3.2. To Clear the Altitude History ...........................................................22

5. BAROMETER MODE [BARO] .............................................................................23

5.1. THE BAROMETRIC TREND INDICATOR .................................................23

5.2. SETTING THE BAROMETER ...................................................................24

5.2.1. To Set the Sea Level Pressure .......................................................24

5.2.2. To Set the Barometer Alarm ............................................................25

5.3. WEATHER STATION FUNCTION .............................................................26

6. BAROMETER MEMORY MODE [MEM] .............................................................27

6.1. SCROLLING THROUGH THE BAROMETER MEMORY DISPLAYS .......27

6.1.1. To view the Summarized History Information ..................................28

6.1.2. Viewing the Pressure and Temperature Information .......................28

6.2. CLEARING THE BAROMETER MEMORY ...............................................29

7. ABBREVIATIONS ................................................................................. ..............30

8. COPYRIGHT AND TRADEMARK NOTICE ........................................................30

9. CE COMPLIANCE ...............................................................................................31

10. LIMITS OF LIABILITY AND ISO 9001 COMPLIANCE .....................................31

11. DISPOSAL OF THE DEVICE ............................................................................32

Congratulations on your newly purchased Escape203 Electronic Altimeter. The handheld electronic altimeter-barometer is an ideal instrument for outdoor enthusiasts. With this product, you will find a Warranty card, this User’s Guide, and a full service support team to give you the results you need anytime, anywhere, quickly and professionally. You can Find the User’s Guide in English, Fr ench, German, Spanish, Finnish and Swedish at www.suunto.com. We wish you many safe trips to new heights with your new Escape203 Electronic Altimeter.

1. INTRODUCTION

1.1. GENERAL INFORMATION

The Escape203 Electronic Altimeter is designed for the outdoor enthusiast combining state-of-the-art technology with practical altimeter-barometer functions. The Escape203 hand-held device, light and ergonomically comfortable, weighs approximately 55 g. or 2 oz. The LCD exhibits a large number display. The position of the triangle indicator clearly shows which main mode the user is viewing. The indicator bar displays all the main functions (modes).

1.2. LCD DISPLAY

The display is designed to offer the user maximum clarity and simplicity. The display is divided into several areas:

• A Barometric Trend Indicator provides a quick reference of the last 6 hours in the form of a graph.

• Fields 1-4 display values either number or text depending on the mode or sub mode you are in.

• A Mode Indicator Bar displays the main functions (a triangle arrow located just above the bar indicates the mode you are in).

1.3. BUTTON FUNCTIONS

Three buttons are used to operate the Escape203: the Center Button, the [-] Minus Button, and the [+] Plus Button.

1.3.1. The Center Button

• The Center Button is located in the center just below the LCD display.

• Pressing the Center Button and holding for 2 seconds will allow you t o enter and

exit the setup mode of the function (mode) you are viewing.

• In the setup process, the Center Button a llows you to move betw een settable units or values and determine preferences.

1.3.2. The [-] Minus Button

• The [-] Minus Button is located on the left just below the LCD display.

• Pressing the [-] Minus Button moves the indicator (triangle arrow) to the left along the indicator bar.

• In the setup process, pressing the [-] Minus Button will allow you to decrease a unit or value by scrolling numerically downward.

1.3.3. The [+] Plus Button

• The [+] Plus Button is located on the right just below the LCD display.

• Pressing the [+] Plus Button moves the indicator (triangle arrow) to the right along the indicator bar.

• In the setup process, pressing the [+] Plus Bu tton will allow you to increase a unit or value by scrolling numerically upward.

1.4. MAIN FUNCTIONS (MODES)

The Escape203 has five main features: Time [TIME], Altimeter [ALTI], Altimeter Memory [LOG], Barometer [BARO] and Barometer Memory [MEM].

1.4.1. Time [TIME]

• Shows the Day, Date and Time.

• User adjustable 12/24 hour clock.

• Calendar date, pre-programmed to the year 2089.

1.4.2. Altimeter [ALTI]

• Shows: altitude, altitude difference, time, ascent/descent rate in m/hour or ft/hour.

• Altitude range: -500 - 9,000 m; -1,600 - 29,500 ft.

• Resolution: adjustable by the user to 1 m/5 m; 3 ft/10 ft.

• Altitude alarm range up to 9,000 m; 29,500 ft.

• Difference measurement function enables zeroing of Altimeter to follow vertical progress from start of hike/climb.

• Up to 20 user-definable altitude points can be stored in memory for later viewing (information stored: # of point stored, altitude, date and time).

1.4.3. Altimeter Memory [LOG]

• Stores altitude information for one event (= log) as well as altitude points entered into the memory in the Altimeter mode.

• Information stored in the log is:

• the start date and time of log

• the altitude gain/loss for log

• the average ascent/descent rate for log

• the max/min altitude for log

• the cumulative altitude gain/loss since clearing the memory

• the date when memory was cleared

• the altitude points entered into the memory in the [ALTI] mode.

1.4.4. Barometer [BARO]

• Shows: temperature, sea level pressure, absolute pressure, time, barometric trend indicator.

• Atmospheric pressure range: 300 - 1,100 hPa; 8.90 - 32.40 inHg.

• Resolution: 1 hPa; 0.05 inHg.

• Temperature range: -20 to +60°C; -5 to +140°F.

• Temperature resolution: 1°C; 1°F.

• Pressure change alarm activated when pressure drops 4 hPa / 0.12 inHg or more during a 3-hour period.

• Altimeter-Barometer (use as altimeter or wea ther station) Locking Feature to use altimeter or barometer independently.

1.4.5. Barometer Memory [MEM]

• Stores pressure and temperature information (max/min) for the last 24 hours.

• Shows a summarized history of barometric pressure and temperature over the last 24 hours.

• Shows individual barometric pressure and temperature information for the last 24 hours in intervals of 30 minutes for the last three hours and thereafter in 3 hour intervals.

1.4.6. Other Functions

• Adjustable for metric or imperial units.

• User-replaceable battery.

• Neck lanyard.

• Temperature compensated altitude and barometer readings.

• Water resistant up to the depth of 5m; 15ft.

• Storage temperature range -20 to +60°C (+5 to 140°F).

• Low battery warning (When 5-15% battery power is left. Low battery indicator appears on the left in the LCD display.

1.5. CARE AND MAINTENANCE

Perform only the processes discussed in this manual. Never attempt to take the Escape203 apart or service it yourself (i.e. open the case or remove the buttons). Protect your Escape203 Electronic Altimeter from shocks, extreme heat and prolonged exposure to direct sunlight. When not in use the Escape203 should be stored in a clean, dry environment at room temperature when not in use. The Escape203 Electronic Altimeter can be wiped clean with a lightly moistened (use warm water) cloth. Apply a mild soap to clean stubborn stains or marks. Avoid exposing the Escape203 Electronic Altimeter to strong chemicals like gasoline, cleaning solvents, acetone, alcohol, adhesives, and paint. These will damage the unit's seals, case and finish. Make sure the area around the sensors (bottom front side of the instrument) is kept free of dirt and sand. Never insert any objects into the sensor openings.

1.5.1. Battery Replacement

The Escape203 Electronic Altimeter operates on a three-volt lithium cell. Type: CR

2450. The maximum life expectancy is approximately 2-3 years. A low battery-warning indicator is activated when 5-15 percent of the battery capacity is still available. When this occurs we recommend replacement of the battery. Extreme cold weather will activate the low battery-warning indicator. Though the indicator is activated, the battery may not need to be replaced due to this condition. In temperatures above 10°C (50°F), if the low battery warning indicator is showing, the battery will need to be replaced. To replace the battery:

1. Turn the Escape203 Electronic Altimeter over to view the backside.

2. Insert a coin in the coin slot located on the battery compartment cover.

3. Turn the coin counterclockwise gently to the open position marked on the back of the case.

4. Remove the battery compartment cover.

5. Remove the old cell from the battery compartment and ensure t he O-ring and all surfaces are clean and dry. Be careful not to pinch the O-ring. Do not use a knife or other sharp objects to open the battery housing. These will damage the o-ring. Do not stretch the O-ring.

6. Place the new cell into the battery compartment (negative side down, positive side up).

7. Ensure the O-ring is in place to keep the Escape203 Electronic Altimeter waterproof and replace the battery compartment cover back onto the backside of the instrument.

8. Insert a coin into the coin slot; and turn the coin clockwise to the closed position marked on the back of the case.

Note: Battery replacement should be performed with extreme care to ensure the Escape203 Electronic Altimeter continues to remain waterproof. It is the operator's responsibility to due care to ensure the instrument remains waterproof.
