SurgeX SU-1500-DC, XU315-DC User Manual
Ver 1.0 - Rev. A
The most trusted name in power protection.
™
USER MANUAL
UPS OPERATION
SU-1500-DC
1noitcudortnI.1
2. Controls and Indicators 5
8noitallatsnI.3
11noitarepO.4
41gnitoohselbuorT.5
51yrettaB eht gnicalpeR.6
81ecivreS gniniatbO.7
91snoitacificepS.8
9. Configurable Parameters & Settings 21
10. Limited Product Warranty 22
© 2011 SurgeX
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS !
Thank you for purchasing this power protection product. It has been designed
and manufactured to provide many years of trouble free service.
This symbol indicates "ATTENTION"
This symbol indicates "Risk of Electrical Shock"
This symbol indicates "Alternating Current Supply"
This symbol indicates "Alternating Current Supply Phase"
Please read this manual before installing your UPS, as it provides important
information that should be followed during installation and maintenance of the
UPS and batteries allowing you to correctly set up your system for the maximum safety and performance. Included is information on customer support
and factory service if it is required. If you experience a problem with the UPS
please refer to the Troubleshooting guide in this manual to correct the UPS
please refer to the Troubleshooting guide in this manual to correct the problem or collect enough information so that the Technical Support Department
can rapidly assist you.
INTRODUCTION
1
1
WARNING: Risk of Electrical Shock. Hazardous live parts inside
these power supplies are energized from the battery even when the
AC input is disconnected.
CAUTION! To de-energize the outputs of the UPS:
1. If the UPS is on press and release the Off button.
2. Disconnect the UPS from the AC wall outlet.
3. To de-energize the UPS completely, disconnect the battery.
CAUTION! To reduce the risk of electrical shock in conditions
where the load equipment grounding cannot be verified, disconnect
the UPS from the AC wall outlet before installing a computer interface
cable. Reconnect the power cord only after all signaling connections
are made.
CAUTION! Connect the UPS to a two pole, three wire grounding
AC wall outlet. The receptacle must be connected to the appropriate
branch protection (circuit breaker or fuse). Connection to any other
type of receptacle may result in a shock hazard and violate local
electrical codes. Do not use extension cords, adapter plugs, or surge
strips.
CAUTION! To reduce the risk of electrical shock with the installa-
tion of this UPS equipment and the connected equipment, the user
must ensure that the combined sum of the AC leakage current does
not exceed 3.5mA.
This symbol indicates "Direct Current Supply"
This symbol indicates "Equipment Grounding Conductor"
WARNING: This Uninterruptible Power Supply contains potentially
hazardous voltages. Do not attempt to disassemble the UPS beyond
the battery replacement procedure. This UPS contains no user serviceable parts. Repairs and Battery replacement must be performed
by QUALIFIED SERVICE PERSONNEL ONLY.
2
After removing your UPS from its carton, it should be inspected for damage that
may have occurred in shipping. Immediately notify the carrier and place of
purchase if any damage is found. Warranty claims for damage caused by the
carrier will not be honored. The packing materials that your UPS was shipped
in are carefully designed to minimize any shipping damage. In the unlikely
case that the UPS needs to be returned to the manufacturer, please use the
original packing material. Since the manufacturer is not responsible for shipping damage incurred when the system is returned, the original packing material is inexpensive insurance. PLEASE SAVE THE PACKING MATERIALS!
Receiving Inspection
NOTICE: This equipment has been tested and found to comply with the limits
for a Class A and/or Class B computing device in accordance with the specifications in Subpart J of Part 15 of FCC Rules and the Class A and/or Class B
limits for radio noise emissions from digital apparatus set out in the Radio
Interference of the Canadian Department of Communications. These limits are
designed to provide reasonable protection against such interference in a residential installation. This equipment generates and uses radio frequency and if
not installed and used properly, that is, in strict accordance with the
manufacturer's instructions, this equipment may cause interference to radio
and television reception. If this equipment does cause interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
Re-orient the receiving antenna.
Relocate the computer with respect to the receiver.
Move the computer away from the receiver.
Plug the computer into a different outlet so that the computer and receiver
are on different branch circuits.
Shielded communications interface cables must be used with this product.
WARNING: Changes or modifications to this unit not expressly ap-
proved by the party responsible for compliance could void the user's
authority to operate the equipment.
NOTE: These UPSs are shipped with the batteries disconnected. The batteries must be connected before putting these UPSs into service. Refer to Section 3 "Installation" for connecting the batteries.
3
Life Support Policy
As a general policy, we do not recommend the use of any of our products in life
support applications where failure or malfunction of the product can be reasonably expected to cause failure of the life support device or to significantly affect
its safety or effectiveness. We do not recommend the use of any of our products in direct patient care. We will not knowingly sell our products for use in
such applications unless it receives in writing assurances satisfactory to us
that (a) the risks of injury or damage have been minimized, (b) the customer
assumes all such risks, and (c) our liability is adequately protected under the
circumstances.
Examples of devices considered to be life support devices are neonatal oxygen
analyzers, nerve stimulators (whether used for anesthesia, pain relief, or other
purposes), auto transfusion devices, blood pumps, defibrillators, arrhythmia
detectors and alarms, pacemakers, hemodialysis systems, peritoneal dialysis
systems, neonatal ventilator incubators, ventilators for both adults and infants,
anesthesia ventilators, and infusion pumps as well as any other devices designated as “critical” by the United States FDA.
4
The ONLINE (green) LED illuminates in a steady state when the UPS is on and the
inverter is providing the output power. The ONLINE LED will extinguish when operating in the Battery mode.
The LINE (green) LED illuminates in a steady state when the UPS is connected to
Utility Power and there is an acceptable AC voltage present. The LINE LED will
extinguish when operating in the Battery mode and if the Utility voltage is not present.
The LINE LED will flash when the Utility voltage or frequency is out of the Bypass
mode range.
The BYPASS (yellow) LED will be flashing when the UPS is operating in the Bypass
mode. The BYPASS LED will extinguish when operating in the On-Line and the
Battery modes.
The FAULT (red) LED illuminates in a steady state when the UPS detects an internal
fault and is not functioning properly. The FAULT LED is extinguished when the UPS
is operating properly.
The LOAD (yellow) LED illuminates is a steady state when the UPS is operating in
the On-line or Bypass modes. The LOAD LED indicates the Battery/Load Capacity
bar graph (4-LEDs) represents the output load
capacity. The LOAD LED will extin-
guish in the Battery mode.
The OVERLOAD (red) LED illuminates in a steady state when the output load has
exceeded the full load rating of the UPS. The OVERLOAD LED will extinguish when
the output load has not exceeded the full load rating of the UPS.
The BATT (yellow) LED illuminates is a steady state when the UPS is operating in
the Battery mode. The BATT LED indicates the Battery/Load Capacity bar graph (4LEDs) represents the battery capacity. The BATT LED will extinguish in the On-Line
and the Bypass modes.
CONTROL PANEL
CONTROLS AND INDICATORS
2
5
The ON BATT (green) LED illuminates in a steady state when the UPS is operating in the Battery mode. The ON BATT LED will extinguish when operating in
the On-Line and the Bypass modes.
The BATT LOW (yellow) LED illuminates in a steady state when the UPS reaches
a low battery condition. The BATT LOW LED is extinguished when the UPS is
in the On-Line mode and when the battery is not in a low battery condition.
The REPLACE BATT (red) LED illuminates in a steady state when the UPS
detects a weak battery, bad battery or if the battery is disconnected. The
REPLACE BATT LED is extinguished when the battery's condition is good.
The Load Level Bar Graph operates as follows:
25% Load (green) LED will be illuminated when there is approximately 25% of
the rated capacity.
50% Load (green) LED will be illuminated when there is approximately 50% of
the rated capacity.
75% Load
(green) LED will be illuminated when there is approximately 75% of
the rated capacity.
100% Load (green) LED will be illuminated when there is approximately 100%
of the rated capacity.
The Battery Capacity Bar Graph operates as follows:
100% Battery Capacity (green) LED will be illuminated until the battery’s capacity drops below 100% capacity and then it will extinguish.
75% Battery Capacity (green) LED will be illuminated until the battery’s capacity drops below 75% capacity and then it will extinguish.
50% Battery Capacity (green) LED will be illuminated until the battery’s capacity drops below 50% capacity and then it will extinguish.
25% Battery Capacity (green) LED will be illuminated until the battery’s capacity drops below 25% capacity and then it will extinguish.
When the following events occurred, the corresponding LEDs will illuminate as
followings:
Battery Test: All of the LEDs will be constantly on.
EPO function: All of the LEDs will be off.
Output short circuit: The OVERLOAD LED will flash.
O
N/TEST Button has three functions:
1. Press for 1-beep (2-seconds) to turn the UPS on.
2. AC mode: Press for 1-beep (2-seconds) to perform a battery test.
3. Battery mode: Press for 1-beep (2-seconds) to silence the alarm.
OFF Button:
Press for 1-beep (2-seconds) to turn the UPS off.
6
