Sureheat Pfislp Installation Template
wARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation and
maintenance instructions thoroughly
before installing or servicing this
equipment.
dANGER
Failure to follow these
insructions could result in re
or explosion that could cause
property damage, personal injury
or death.
dANGER
dO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. dO NOT use in or
on boats or recreational vehicles.
Modular Island Grill
- Main Grill Module
pROp 65 wARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of propane.
wARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(Outside any enclosure)
pFISLp
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT
FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM
OR HER TO SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SALESHELp@SUREHEAT.COM OR
CALL 1-800-229-5647 (TOLL-FREE) BETwEEN
8:00 AM ANd 5:00 pM EASTERN TIME, MONdAY
THROUGH FRIdAY
Grill Operation 1-2-3
Before Grilling.
Step 1 Keep your grill a safe distance away from your property.*
Step 2 Always Perform a Leak Test.*
Step 3 Keep children away from the grill.
during Grilling.
(To avoid tripping safety valves, please follow these instructions carefully!)
Step 1 First open lid and turn gas tank on slowly.
Step 2 Turn only one knob on at a time when lighting the grill.
Step 3 Use protective gloves when grill gets hot.
After Grilling.
Step 1 Burn grill for 10-15 minutes to burn off food residues.
Step 2 Wait until the grill is completely cooled before closing lid.
Step 3 Clean up grease build-up and cover your grill.
* please refer to the owner's manual for details.
dANGER
wARNING
▲!
1. Do not store or use gasoline or other
ammable liquids or vapors in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use
shall not be stored in the vicinity of this
or any other appliance.
Always read and understand the WARNINGS and INSTRUCTION that are contained in this manual before
attempting to use this gas barbecue grill, to prevent possible bodily injury or property damage.
▲!
If you smell gas:
1. Shut off gas to the appliance
2. Extinguish any open ame
3. Open lid
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your re department.
Always keep this manual for convenient future reference.
PFISLP
Owner's Manual
2
Table of Contents
For Your Safety....................................................................................................4
Grill Features.......................................................................................................6
Grill Assembly......................................................................................................7
Gas Requirements..............................................................................................11
pre Operation Leak Testing...............................................................................13
Grill Location......................................................................................................14
Lighting the Grill.................................................................................................15
Using the Rotisserie Burner............................................................................. 16
Rotisserie Lighting............................................................................................ 17
Bottom Infrared Cooking Tips.......................................................................... 18
Care and Maintenance...................................................................................... 19
Troubleshooting Guide..................................................................................... 22
warranty Information........................................................................................ 24
PFISLP
Owner's Manual
3
For Your Safety
Congratulations on your new barbecue grill purchase! You've made the right choice. In this manual, you will nd
assembly instructions, suggestions for grilling and helpful hints, as well as guidelines for the safe operations,
proper care and use of your grill. Our expert staff strives to provide you with an easy to assemble product.
Should you have any questions or problems with this product, please call our customer service department at
1-800-229-5647
NOTE: The use and installation of this product must conform to local codes. In the absence of local codes, use
the National Fuel Gas Code, ANSI Z223.1/NFPA54. Reference to Natural Gas and Propane Installation Code
CSA B 149 .1 or Propane Storage and Handling code B149.2
IMpORTANT NOTICE: REAd ALL INSTRUCTIONS pRIOR TO ASSEMBLY ANd USE
Safety First!
Read and understand all warnings and precautions prior to operating your grill.
wARNING
▲!
1. This grill is for outside use only. It should not be used in a building, garage or any other enclosed area.
2. The use of alcohol, prescription or non-prescription drugs may impair an individual’s ability to properly assemble or
safely operate this appliance.
3. Always open the grill lid carefully and slowly as heat and steam trapped within the grill could cause severe burns.
4. Always place your grill on a hard and level surface far away from combustible materials and structures. An asphalt
or blacktop surface may not be acceptable for this purpose.
5. Do not leave a lit grill unattended.
6. Keep children and pets away from the grill at all times.
7. This is not a tabletop grill. Do not place this grill on any type of tabletop surface.
8. Do not use the grill in high winds.
9. This grill must be used with propane gas only (propane gas cylinder not included).
10. Do not attempt to attach this grill to the self-contained propane system of a camper, trailer, motor home or house.
11. Do not use charcoal or lighter uid.
12. Do not use gasoline, kerosene or alcohol for lighting. The LP-gas supply cylinder must be constructed and marked
in accordance with the specications for propane gas cylinders of the U.S. Department of Transportation (DOT)
CFR 49.
13. This outdoor gas appliance is not intended to be installed in or on recreation vehicle s and/or boats.
14. Do not attempt to move the grill while it is lit.
15. Do not use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
16. Keep combustible items and surfaces at least 24 inches away from the grill at all times. DO NOT use this gas grill
or any gas product under any overhead enclosure or near any unprotected combustible constructions.
17. Do not use in an explosive atmosphere. Keep grill are a clear and free from combustible materials, gasoline and
other ammable vapors and liquids.
18. Do not attempt to use or assemble with missing or damaged parts. Contact customer service for a replacement.
8:00 am - 5:00 pm (Eastern Time), Monday through Friday.
CAUTION-prevention of Burns
▲!
1. To avoid burns, do not touch metal parts of the grill until they have completely cooled for at least 45 minutes or
unless you are wearing protective gear such as pot holders, protective gloves or mittens.
2. Do not alter the grill in any manner.
3. Clean and inspect the hose before each use. If there is evidence of abrasion, wear, cuts or leaks, the hose must
be replaced prior to operation. The replacement hose assembly should be in accordance with the manufacturer’s
specications .
4. Move gas hoses as far away as possible from hot surfaces and dripping hot grease.
5. Never keep a lled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could
open the relief valve and allow gas to escape.
PFISLP
Owner's Manual
4
Safe Locations For Use Of This Outdoor Grill
dANGER
▲!
Never use this outdoor grill inside any building, garage, shed or breeze way, or inside any boat, trailer or recreational
vehicle, to prevent a possible re and to prevent the possibility of carbon monoxide poisoning or asphyxiation.
wARNINGS
▲!
Do not use this appliance under overhead combustible surface or covered area (e.g., awnings, umbrellas, porches or
gazeboes).
Always conrm that this grill is not positioned under the overhang of a house, a garage or other structure before lighting
it. An overhang will serve to deect are-ups and radiated heat into the structure itself, which could result in a re.
Always conrm that this grill is positioned more than 24 inches (61 cm) away
from any combustible materials or surface before lighting it, and that no
gasoline or other volatile substances are stored in the vicinity of this grill. (See
diagram to right).
The temperature of a grease re or of the radiated heat might otherwise be
sufcient to ignite nearby combustible or volatile substances.
Always locate this grill where there will be ample combustion and ventilation
air, but never position it in the direct path of a strong wind.
Never allow the grill to operate while unattended, to prevent uncontrolled grease res from erupting.
Never attempt to move this grill while it is in operation or while it is still hot, to prevent possible personal injury.
Never store or use gasoline or other ammable or volatile substances in the vicinity of this grill or in the vicinity of any
other heat generating appliance, because of the danger of starting a re.
Always conrm that the installation of this grill conforms with the requirements of all local codes or, in the absence of
applicable local codes, with either the National Fuel Gas Code, ANSI Z223. NFPA 54 or CAN/CGA-B149.2.
24 Inches
24 Inches
▲!
Liquid propane (LP) gas is ammable and hazardous if handled improperly. Become aware of its characteristics before
using any propane product.
• Propane Characteristics: Flammable, explosive under pressure, heavier than air and settles in pools in low area.
• In its natural state, propane has no odor. For your safety, an odorant has been added.
• Contact with propane could cause freeze burns to the skin.
• This grill is shipped from the factory for propane gas use only.
• Never use a propane cylinder with a damaged body, valve, collar or footing.
• Dented or rusted propane cylinders maybe hazardous and should be checked by your propane gas supplier.
CAUTION
▲!
• It is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
• Inspect the grill before each use.
Step 1. Inspect all hoses and connections and make certain they are secure.
Step 2. Check and clean the burner tubes for insects and insect nests by removing the burner and inserting a bottle
brush cleaner into each tube to make sure the passage is clear.
*** A clogged tube can lead to a re beneath the grill. ***
Step 3. Ensure that the valve orice is pointing straight and completely inserted into the burner tube.
GENERAL INFORMATION
1. A propane gas cylinder is required for operation.
2. This gas grill is NOT intended for commercial use.
PFISLP
Valve Orice
Burner Tube
Burner Tube
Owner's Manual
5
Grill Features
1
2
3
4
5
8
9
10
11
12
13
6
7
1. Roll top grill hood
2. Rotisserie kit
3. Grilling/cooking surface
4. Control knob: Rear infrared burner
14
15
9. Bread warming rack
10. Rear Infrared burner
11. Inside Light
12. Granite working surface
5. Control knob: Main burner
6. Control knob: Searing burner
7. Grill cart with roll out LP tank tray
8. Hood Handle
13. Light switch
14. Push button igniter
15. Tilt out trash can
6
Grill Assembly
STEP 1
- Place the Searing Burner Heat Shield in position as shown.
Searing Burner
Heat Shield
STEP 2
- Place the Flavor Grids in position as shown.
Flavor Grids
7
