SUPER MICRO Computer X8DTG-DF User Manual

X8DTG-DF

USER’S MANUAL

Revision 1.0

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTW ARE, OR DA TA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall
be the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all
claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision 1.0
Release Date: July 6, 2009

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2009 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

About This Manual

This manual is written for system integrators, PC technicians and knowledgeable PC
users. It provides information for the installation and use of the X8DTG­DF motherboard.

About This Motherboard

The X8DTG-DF motherboard supports the Intel 5500 Series Processor
platform and the QuickPath Interconnect (QPI) Technology, providing the next gen­eration point-to-point system interface that replaces the current Front Side Bus. With
the 5500 Series Processor built in, the X8DTG-DF substantially enhances system
performance with increased bandwidth and unprecedented scalability optimized
for HPC/Cluster and high-end IU servers. Please refer to our web site (http://www.
supermicro.com/products/) for updates on supported processors. This product is
intended to be installed and serviced by professional technicians.

Preface

Manual Organization

Chapter 1 describes the features, specifi cations and performance of the mother-

board and provides detailed information about the chipset.
Chapter 2 provides hardware installation instructions. Read this chapter when in-

stalling the processor, memory modules and other hardware components into the
system. If you encounter any problems, see Chapter 3, which describes trouble­shooting procedures for video, memory and system setup stored in the CMOS.

Chapter 4 includes an introduction to BIOS and provides detailed information on
running the CMOS Setup utility.

Appendix A lists BIOS POST Error Codes. Appendix B and Appendix C provide
the Windows OS and Other Software Installation Instructions.

Conventions Used in the Manual

Special attention should be given to the following symbols for proper installation
and to prevent product damage or bodily injury:

Warning: Important information given to ensure proper system installation
or to prevent damage to the components.

Note: Additional Information given to differentiate various models or to
ensure correct system setup.

iii

X8DTG-DF User's Manual

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.
San Jose, CA 95131 U.S.A.

Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Web Site: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands

Tel: [phone]
Fax: [phone]
Email: [e-mail] (General Information)

[e-mail] (Technical Support)
[e-mail] (Customer Support)

Asia-Pacifi c

Address: Super Micro Computer, Inc.

4F, No. 232-1, Liancheng Rd.
Chung-Ho 235, Taipei County
Taiwan, R.O.C.

Tel: [phone]
Fax: [phone]
Web Site: www.supermicro.com.tw
Technical Support:
Email: [e-mail]
Tel: [phone], ext.132 or 139

iv

Notes

Contacting Supermicro

v

X8DTG-DF User's Manual

Table of Contents

Preface

About This Manual ........................................................................................................iii

About This Motherboard ................................................................................................iii

Manual Organization .....................................................................................................iii

Conventions Used in the Manual ..................................................................................iii

Contacting Supermicro ..................................................................................................iv

Chapter 1 Introduction

1-1 Overview ........................................................................................................1-1

Checklist ..........................................................................................................1-1

Motherboard Features ...................................................................................1-6

1-2 Chipset Overview ............................................................................................1-9

Main Features of the 5500 Series Processor and the 5520 Chipset .............1-9

1-3 Special Features ...........................................................................................1-10

Recovery from AC Power Loss ..................................................................... 1-10

1-4 PC Health Monitoring .................................................................................... 1-10

Fan Status Monitor with Firmware Control ..................................................1-10

Environmental Temperature Control .............................................................1-10

System Resource Alert ................................................................................. 1-10

1-5 ACPI Features ................................................................................................1-11

Slow Blinking LED for Suspend-State Indicator ............................................1-11

Main Switch Override Mechanism .................................................................1-11

1-6 Power Supply .................................................................................................1-11

1-7 Overview of the Winbond WPCM450 Controller .......................................... 1-12

Chapter 2 Installation

2-1 Static-Sensitive Devices ..................................................................................2-1

\

2-2 Motherboard Installation ..................................................................................2-2

Precautions .....................................................................................................2-1

Unpacking .......................................................................................................2-1

Tools Needed .................................................................................................. 2-2

Installation Instructions ....................................................................................2-2

2-3 Processor and Heatsink Installation................................................................2-3

Installing a CPU Heatsink ............................................................................... 2-5

2-4 Memory Installation ........................................................................................ 2-7

2-5 Control Panel Connectors/IO Ports...............................................................2-10

Back Panel Connectors/IO Ports .................................................................. 2-10

Back Panel Connector Pin Defi nitions ...........................................................2-11

vi

Table of Contents

Universal Serial Bus (USB) .......................................................................2-11

Ethernet Ports .......................................................................................... 2-12

Serial Ports ............................................................................................... 2-13

Video Connector .......................................................................................2-13

Unit Identifi er Switches .............................................................................2-14

Front Control Panel ....................................................................................... 2-15

Front Control Panel Pin Defi nitions............................................................... 2-16

Power LED .............................................................................................. 2-16

HDD/FP UID Switch ................................................................................. 2-16

NIC1 LED Indicator .................................................................................. 2-17

NIC2 LED Indicator .................................................................................. 2-17

Overheat (OH)/Fan Fail/PWR Fail/UID LED ............................................ 2-18

Power Fail LED ........................................................................................2-18

Reset Button ........................................................................................... 2-19

Power Button ........................................................................................... 2-19

2-6 Connecting Cables ........................................................................................ 2-20

20-pin Proprietary Main Power and 8-pin PCI-E Graphic Card Power

Connectors ...............................................................................................2-20

Fan Headers ............................................................................................. 2-21

NMI Header .............................................................................................. 2-22

Internal Buzzer ......................................................................................... 2-22

T-SGPIO Headers .................................................................................... 2-23

PWR I

IPMB I

2

C (SMB) Connector ...................................................................... 2-24

2

C SMB .........................................................................................2-24

2-7 Jumper Settings ............................................................................................2-25

Explanation of Jumpers ................................................................................ 2-25

GLAN Enable/Disable ..............................................................................2-25

CMOS Clear ............................................................................................. 2-26

Watch Dog Enable/Disable ...................................................................... 2-26

VGA Enable .............................................................................................. 2-27

J_UID_OW (-Overwriting) ........................................................................ 2-28

2-8 Onboard Indicators ........................................................................................2-29

GLAN LEDs .............................................................................................. 2-29

Onboard Power LED

.....................................................................2-30

BMC Activity LED ..................................................................................... 2-30

2-9 Serial ATA Connections ................................................................................. 2-31

Serial ATA Ports........................................................................................ 2-31

Chapter 3 Troubleshooting

3-1 Troubleshooting Procedures ........................................................................... 3-1

vii

X8DTG-DF User's Manual

Before Power On ............................................................................................ 3-1

No Power ........................................................................................................ 3-1

No Video ......................................................................................................... 3-2

Losing the System’s Setup Confi guration ....................................................... 3-2

Memory Errors ...............................................................................................3-2

3-2 Technical Support Procedures ........................................................................3-3

3-3 Frequently Asked Questions ........................................................................... 3-3

3-4 Returning Merchandise for Service.................................................................3-4

Chapter 4 BIOS

4-1 Introduction ...................................................................................................... 4-1

Starting BIOS Setup Utility ..............................................................................4-1

How To Change the Confi guration Data ......................................................... 4-1

Starting the Setup Utility ................................................................................. 4-2

4-2 Main Setup ......................................................................................................4-2

4-3 Advanced Setup Confi gurations...................................................................... 4-4

4-4 Security Settings ...........................................................................................4-22

4-5 Boot Confi guration ........................................................................................4-24

4-6 Exit Options ................................................................................................... 4-25

4-7 BIOS Recovery ............................................................................................. 4-26

How to Recover the AMIBIOS Image (-the Main BIOS Block) ..................... 4-26

4.7.1 Boot Sector Recovery from a USB Device ..........................................4-26

4.7.2 Boot Sector Recovery from an IDE CD-ROM ..................................... 4-27

4.7.3 Boot Sector Recovery from a Serial Port ("Serial Flash") ................... 4-27

Appendix A BIOS Error Beep Codes

A-1 BIOS Error Beep Codes ................................................................................. A-1

Appendix B Installing the Windows OS

B-1 Installing the Windows OS for a RAID System ..............................................B-1

B-2 Installing the Windows OS for a Non-RAID System ....................................... B-2

Appendix C Software Installation Instructions

C-1 Installing Software Programs .........................................................................C-1

C-2 Confi guring Supero Doctor III ......................................................................... C-2

viii

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged
leader in the industry. Supermicro boards are designed with the utmost attention to
detail to provide you with the highest standards in quality and performance. Check
that the following items have all been included with your motherboard. If anything
listed here is damaged or missing, contact your retailer.

The following items are included in the bulk package.

One (1) Supermicro Mainboard

•

One (1) Supermicro CD containing drivers and utilities•

1-1

X8DTG-DF User's Manual

X8DTG-DF Motherboard Image

Note: The drawings and pictures shown in this manual were based on the

latest PCB Revision available at the time of publishing of the manual. The
motherboard you’ve received may or may not look exactly the same as
the graphics shown in the manual.

1-2

Chapter 1: Introduction

X8DTG-DF Motherboard Layout

J11

I-SATA6

SBX 1B

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

LE4

SW1

JWD1

SBX 1A

JSPK1

PCI-E 2.0

x4 in x16 Slot

JPCIE1

JNMI1

J_UID_OW

JPCIE3

USB2/3

VGA

Intel
ICH10R
(South Bridge)

CPU2

COM1

LE2

Winbond
450R
BMC

CMOS

CLEAR

BIOS

X8DTG-DF

IPMB

JLPC80

LAN2

JPG1

JPL1

Intel
5520
IOH-36D

P2 DIMM1A

P2 DIMM1B

LAN1

Intel
82576
LAN CTRL

P2 DIMM2B

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

PHY

J12

SBX 2A

+

SBX 2B

JPCIE2

Notes:

Jumpers not indicated are for test purposes only. For more information on 1.
jumpers or components, refer to Chapter 2.

" " indicates the location of Pin 1.2.

FAN7

JPW1

FAN4

JPI2C (PWR I2C)

P1 DIMM3B

P1DIMM3A

P1 DIMM2A

P1 DIMM2B

P1 DIMM1B

P1 DIMM1A

JBAT1

Battery

FAN3

CPU1

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

4

FAN2

JL1

1

When LE1 LED is on, the onboard power connection is on. Make sure to 3.
unplug the power cables before removing or installing components.

1-3

X8DTG-DF User's Manual

X8DTG-DF Quick Reference

VGA

Intel
ICH10R
(South Bridge)

I-SATA6

I-SATA4I-SATA5

LE4

J11

SBX 1A

JPCIE1

SBX 1B

SW1

JWD1

JNMI1

JSPK1

J_UID_OW

JPCIE3

PCI-E 2.0

x4 in x16 Slot

USB2/3

COM1

IPMB

LE2

Winbond
450R
BMC

CMOS

CLEAR

BIOS

X8DTG-DF

JLPC80

JPL1

LAN2

JPG1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

LAN1

USB0/1

IPMI_LAN

PHY

J12

SBX 2A

+

JPCIE2

FAN7

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

P1 DIMM3B

P1DIMM3A

P1 DIMM2A

P1 DIMM2B

CPU2

P1 DIMM1B

P1 DIMM1A

JBAT1

Battery

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

FAN4

JPI2C (PWR I2C)

FAN3

1-4

JPW3

FAN2

JL1

FAN1

4

1

Chapter 1: Introduction

X8DTG-DF Quick Reference (See Chapter 2 for Details)

Jumper Description Default Setting

JBT1 CMOS Clear (See Section 2-8)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 LAN1/2 Enable Pins 1-2 (Enabled)
J_UID_OW Red LED OW (Pins 7/8 of JF1) (Page 2-31) Off (Overwrites)
JWD1 Watch Dog Pins 1-2 (Reset)

Connector Description

COM1 COM1 Serial Port
FAN 1-8 System/CPU Fan Headers
IPMB IPMB (SMB I

2

C) Header (for IPMI)
JF1 Front Panel Connector
JL1 Chassis Intrusion
JLPC80 JLPC80 Connector
JNMI1 NMI (Non-Maskable Interrupt) Header
JPSK1 Internal Speaker/Buzzer Header
JPW1 12V 20-pin Power Connector (See Chpt. 2)
JPW2/JPW3 12V 8-pin PCI-Exp. Power Connectors (See Chpt. 2)
LAN1/2 Gigabit Ethernet (RJ45) Ports
(IPMI dedicated) LAN LAN (RJ45) Port for IPMI 2.0
PCI-E Slot PCI-Express 2.0 x4 in x 16 slot (JPCIE3)
PWR I

2

C (JPI2C) Power SMB (System Management Bus) I2C Header
SATA1 ~ SATA6 (Intel South Bridge) SATA Ports
SBX 1A/2A Slots PCI-E slots GPU for (Graphics Processing Unit) support

(J11/J12)
SBX 1B/2B Slots PCI-E slots for GPU support (JPCIE1/JPCIE2)
SW1 Unit Identifi er Switch
T-SGPIO-0/T-SGPIO-1 Serial General Purpose Input/Output Headers
USB0/1, USB 2/3 Universal Serial Bus (USB) Ports 0/1, 2/3
VGA Video Port

LED Description

LE1 Onboa rd Stan dby PWR war ning LE D Indic ator
LE2 BMC LED Indicator
LE4 (Rear) Unit Identifi er (UID) LED Indicator

Warning: To avoid possible system overheating, please be sure to provide
adequate airfl ow to your system.

1-5

X8DTG-DF User's Manual

Motherboard Features

CPU

Two Intel•
two full-width Intel QuickPath Interconnect (QPI) links with a total of up to 51.2
GT/s Data Transfer Rate (6.4 GT/s per direction)

®

5500 Series (LGA 1366) processors with each processor supporting

Memory

Twelve 240-pin DIMM sockets support up to 96 GB of Registered ECC or 24 •
GB of Unbuffered ECC/Non-ECC DDR3 1333/1066/800 MHz Memory. (For
Unbuffered ECC/Non-ECC memory, maximum of 2 GB per DIMM is supported.
See Pages 2-7, 2-8 in Chapter 2 for memory Population.)

Chipset

Intel 5520 chipset, including: the 5520 (IOH-36D) and the ICH10R (South •
Bridge).

Expansion Slot

One PCI-E x4 Gen. 2.0 in x16 slot•

SMC Proprietary Slots

Four SBX slots (SBX 1A/2A & SBX 1B/2B) for riser cards (Refer to www.super-•
micro.com/support/resources/riser/ for details.)

BIOS

32 Mb AMI SPI Flash ROM•
ACPI 1.0/2.0/3.0, Plug and Play (PnP), DMI 2.3, SMBIOS 2.3, and USB Key-•

board support

PC Health Monitoring

Onboard voltage monitors for CPU1 VCore, CPU2 VCore, +5Vin, • 12Vcc (V),
V P1 DIMM, V P2 DIMM, +3.3Vcc (V), and Battery Voltage

Fan status monitor with fi rmware control

•

CPU/chass is temper ature moni tors•
Platfo rm Enviro nment Co ntrol Inte rf ace (PECI) read y•
CPU fan auto - of f in sle ep mode•
CPU slow- dow n on tempe rature over heat•
Pulse Wi dth Mo dulati on (PW M) Fan Contro l•
CPU ther mal tr ip supp or t for pro ces sor pr otecti on, power L ED•
Power-up mod e cont rol for r ecover y fr om AC power l oss•
Auto- switc hing vol tage r egulato r for CPU c ore s•
System over heat /Fan Fail LED I ndic ator and c ontr ol•
System re sourc e aler t vi a Super o Doc tor III•

1-6

Chapter 1: Introduction

ACPI Features

Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Pow er Ma nag eme nt•
Keyboard Wakeup from Soft-off •

Onboard I/O

Intel ICH10R supports six SA T A ports (RAID0, RAID1, RAID10, RAID5 supported •
in the Windows OS Environment and RAID 0, RAID 1, RAID 10 supported by
the Linux OS)

Winbond WPCM450 BMC (Baseboard Management Controller) supports IPMI

•

2.0 with K V M supp or t
Intel 82576 Du al-L A N Gi gabi t Ether net C ontr oll er sup por t s dual G ig a- bi t L AN

•

ports
Onboar d PHY Chip su ppor ts IP MI dedic ated L AN

•

One CO M por t•
Up to four U SB 2.0 (Univer sal Serial Bu s) c onnecti ons (2 Ports and 2 Fro nt •

Headers)
Super I/ O: Winbo nd W83 527HG

•

Other

Console redirection•
Onboa rd Fan Spee d Contr ol by Ther mal Ma nagem ent via BI OS•

CD/Diskette Utilities

BIOS fl ash upgrade utility and device drivers•

Dimensions

Propr ietar y 16.6 4" (L) x 7.71" (W) (422.6 6 mm x 195.8 3 mm)•

1-7

X8DTG-DF User's Manual

#1

#1

#1

#2

DDR3 DIMM

PCI-E x16

#2

#2

DDR3 DIMM

PCI-E x16

PCI-E x16

AA
BB

PROCESSOR#0

CC

PCI-E x16

PCI-E x4

PCI-E x16

PCI

Port1

Ports

#3-6

Ports

#7-10

Ports

#1-2

QPI

QPI

Intel 5520

IOH

36D

ESI

CLINK

DMI

ICH10R

PROCESSOR#1

QPI

Port0

Ports

2,1

CLINK

LPC

SATA #1
SATA #2
SATA #3
SATA #4
SATA #5

SATA #6

VF016
SST25

SPI

PE

4-1
PE

5

SATA

#2

#2

#2

DDR3 DIMM

Intel

82576

RJ45

RJ45

#1

#1

#1

DD
EE
FF

DDR3 DIMM

LPCIO W83527
ACPI

KBC

DDR II

Winbond

BMC/VGA

RMII

VGA CONN

RTL8201N PHY

Dedicated LAN

Block Diagram of the 5500 Series Processor Platform

Note: This is a general block diagram. Please see the previous Mother-

board Features pages for details on the features of each motherboard.

1-8

Chapter 1: Introduction

1-2 Chipset Overview

Built up on the func tionalit y and the c apabilit y of the 55 00 Seri es Proce ssor, the
X8DTG- DF mother board provide s the perf ormance and f eature set require d for
dual-processor-based systems with confi guratio n opti mized f or inten sive ap plic a -
tions, H igh Per fo rma nce C omput ing (H PC)/Cluste r IU ser ver p latf orms . The Inte l
5520 plat f or m c ons ist s of th e 55 0 0 S er ie s (LGA 1366) pro c es so r, the 5520 (IO H ­36D), and the ICH10R (South Bridge). With the Intel QuickPath interconnect (QPI)
contr olle r buil t in, the 5 5 00 S er ies P roc es sor p lat for m is t he fi rst dual-processing
platform to offer the next generation point-to-point system interconnect that re­places the current Front Side Bus Technology, substantially enhancing system
performance by utilizing serial link interconnections with increased bandwidth
and scalability.

The IOH connects to each processor through an independent QPI (QuickPath
interconnect) link. Each link consists of 20 pairs of unidirectional differential lanes
for tra nsmis sio n and re cei ving i n addit ion t o a dif fer entia l for wa rded c lo ck. A f ull ­width Q PI link pair p rovide s 84 si gnals. Ea ch proc ess or suppo rt s two Q uickPat h
links, one g oing to th e other pr oce ssor an d the othe r to the 5 520 chip s.

The 552 0 chip set supp or ts PC I Exp ress G en2 la nes pe er-to -pe er read a nd wr ite
transactions. The ICH10R provides multiple PCI-Express SATA and USB con­nections.

In additi on, the 5 520 plat for m also of fers a w ide ran ge of R AS (Relia bilit y, Avail­ability and Serviceability) features. These features include memory interface ECC,
x4/x8 S ingle Devic e Data C orrec tion (SDD C), Cyclic Redund ancy Chec k (CRC),
parity protection, out-of-band register access via SMBus, memory mirroring,
memor y spa ring, a nd Hot- plug su ppor t on t he PCI -E xpre ss Inter f ace.

Main Features of the 5500 Series Processor and the 5520
Chipset

Four processor cores in each processor with 8MB shared cache among cores•

Two full-width Intel QuickPath interconnect links, up to 6.4 GT/s of data transfer •
rate in each direction

Virtualization Technology, Integrated Management Engine supported

•

Point-to-point cache coherent interconnect, Fast/narrow unidirectional links, and •
Concurrent bi-directional traffi c

1-9

X8DTG-DF User's Manual

1-3 Special Features

Recovery from AC Power Loss

BIOS provides a setting for you to determine how the system will respond when AC
power is lost and then restored to the system. You can choose for the system to
remain powered off (in which case you must press the power switch to turn it back
on) or for it to automatically return to a power- on state. See the Advanced BIOS
Setup section to change this setting. The default setting is Last State.

1-4 PC Health Monitoring

This section describes the PC health monitoring features of the X8DTG-DF. All have
an onboard System Hardware Monitor chip that supports PC health monitoring.
An onboard voltage monitor will scan these onboard voltages continuously: CPU1
VCore, CPU2 VCore, +5Vin, 12Vcc (V), V P1 DIMM, V P2 DIMM, +3.3Vcc (V),
and Battery Voltage. Once a voltage becomes unstable, a warning is given or an
error message is sent to the screen. Users can adjust the voltage thresholds to
defi ne the sensitivity of the voltage monitor.

Fan Status Monitor with Firmware Control

The PC health monitor can check the RPM status of the cooling fans. The onboard
CPU and chassis fans are controlled by Thermal Management via BIOS (under
Hardware Monitoring in the Advanced Setting).

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn
on the thermal control fan whenever the CPU temperature exceeds a user-defi ned
threshold. The overheat circuitry runs independently from the CPU. Once it detects
that the CPU temperature is too high, it will automatically turn on the thermal fan
control to prevent any overheat damage to the CPU. The onboard chassis thermal
circuitry can monitor the overall system temperature and alert users when the chas­sis temperature is too high.

To avoid possible system overheating, please be sure to provide adequate
airfl ow to your system.

System Resource Alert

This feature is available when used with Supero D octor III in the Windows OS
environment or used with Supero Doctor II in Linux. Supero Doctor is used to
notif y the user of cer tain system events. For example, you can also confi gure

1-10

Chapter 1: Introduction

Supero Doctor to provide you with warnings when the system temperature, CPU
temperat ures, volt ages a nd fan spe eds go beyon d a pre- defi ned range.

1-5 ACPI Features

ACPI stands for Advanced Confi guration and Power Interface. The ACPI specifi ca-
tion defi nes a fl exible and abstract hardware interface that provides a standard
way to integrate power management features throughout a PC system, including
its hardware, operating system and application software. This enables the system
to automatically turn on and off peripherals such as CD-ROMs, network cards, hard
disk drives and printers.

In addition to enabling operating system-directed power management, ACPI
provides a generic system event mechanism for Plug and Play and an operating
system-independent interface for confi guration control. ACPI leverages the Plug
and Play BIOS data structures while providing a processor architecture-independent
implementation that is compatible with Windows XP/Windows 2003/Windows 2008/
Windows Vista Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking
to indicate that the CPU is in suspend mode. When the user presses any key, the
CPU will wake-up and the LED will automatically stop blinking and remain on.

Main Switch Override Mechanism

When an ATX power supply is used, the power button can function as a system
suspend button to make the system enter a SoftOff state. The monitor will be
suspended and the hard drive will spin down. Pressing the power button again
will cause the whole system to wake-up. During the SoftOff state, the ATX power
supply provides power to keep the required circuitry in the system "alive." In case
the system malfunctions and you want to turn off the power, just press and hold
the power button for 4 seconds. This option can be set in the Power section of the
BIOS Setup routine.

1-6 Power Supply

As with all computer products, a stable power source is necessary for proper and
reliable operation. It is even more important for processors that have high CPU
clock rates.

It is strongly recommended that you use a high quality power supply that meets ATX
power supply Specifi cation 2.02 or above. It must also be SSI compliant (For more

1-11

X8DTG-DF User's Manual

information, please refer to the web site at http://www.ssiforum.org/). Additionally, in
areas where noisy power transmission is present, you may choose to install a line
fi lter to shield the computer from noise. It is recommended that you also install a
power surge protector to help avoid problems caused by power surges.

Note 1. For the proprietary 20-pin main power connector (JPW1) and the
8-pin PCI-Exp. Graphic card power connectors (JPW2/JPW3) to work prop­erly , please customize your power cables based on the SMC PWR Connec­tor Pin-Out Defi nitions listed in the tables on Page 2-20 in Chapter 2.

2. For the PCI-Exp. Graphic cards to work properly, please connect the
PCI-E graphic card power connectors (JPW2/JPW3) to the power sup­ply.

1-7 Overview of the Winbond WPCM450 Controller

The Winbond WPCM450, a Baseboard Management Controller (BMC), supports
the 2D/VGA-compatible Graphics Core with the PCI interface, Virtual Media, and
Keyboard/Video/Mouse (KVM) Redirection modules.

The WPCM450 BMC interfaces with the host system via a PCI interface to com­municate with the graphics core. It supports USB 2.0 and 1.1 for remote keyboard/
mouse/virtual media emulation. It also provides LPC interface to control Super IO
functions. The WPCM450 is connected to the network via an external Ethernet
PHY module.

The WPCM450 communicates with onboard components via six SMBus interfaces,
fan control, Platform Environment Control Interface (PECI) buses.

Note: For more information on IPMI confi guration, please refer to the
Embedded IPMI User's Guide posted on our website @ http://www.super­micro.com/support/manuals/.

1-12

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. T o prevent dam­age to your system board, it is important to handle it very carefully. The following
measures are generally suffi cient to protect your equipment from ESD.

Precautions

Use a grounded wrist strap designed to prevent static discharge.•

Touch a grounded metal object before removing the board from the antistatic •
bag.

Handle the board by its edges only; do not touch its components, peripheral

•

chips, memory modules or gold contacts.

When handling chips or modules, avoid touching their pins.

•

Put the motherboard and peripherals back into their antistatic bags when not •
in use.

For grounding purposes, make sure your computer chassis provides excellent

•

conductivity between the power supply, the case, the mounting fasteners and
the motherboard.

Use only the correct type of onboard CMOS battery as specifi ed by the

•

manufacturer. Do not install the onboard battery upside down to avoid possible
explosion.

Unpacking

The motherboard is shipped in antist atic packag i n g t o avo id static da m a ge. When
unpacking the board, make sure the person handling it is static protected.

2-1

X8DTG-DF User's Manual

2-2 Motherboard Installation

All motherboards have standard mounting holes to fi t different types of chassis.
Make sure that the locations of all the mounting holes for both motherboard and
chassis match. Although a chassis may have both plastic and metal mounting
fasteners, metal ones are highly recommended because they ground the mother­board to the chassis. Make sure that the metal standoffs click in or are screwed in
tightly. Then use a screwdriver to secure the motherboard onto the motherboard
tray. Note: Some components are very close to the mounting holes. Please take
precautionary measures to prevent damage to these components when installing
the motherboard to the chassis.

Tools Needed

1. Phillips Screwdriver

2. Pan head #6 screws

Locations of Mounting Holes

Installation Instructions

X8DTG-DF

Install the IO shield into the chassis. 1.

Locate the mounting holes on the mother-2.
board. Refer to the layout above for mount­ing hole locations.

Locate the matching mounting holes on the 3.
chassis. Align the mounting holes on the
motherboard against the mounting holes on
the chassis.

Install standoffs in the chassis as needed.4.

Install the motherboard into the chassis carefully to avoid damage to mother-5.
board components.

Warning: To avoid damaging the motherboard and its components, please
do not apply any force greater than 8 lb/sq.in (8 lbs. per square inch) when
installing a screw into a mounting hole.

Insert a Pan head #6 screw into a mounting hole on the motherboard and its 6.
matching mounting hole on the chassis, using a Phillips screwdriver.

Repeat Step 4 to insert #6 screws to all mounting holes.7.

Make sure that the motherboard is securely placed on the chassis.8.

2-2

2-3 Processor and Heatsink Installation

!

When handling the processor package, avoid placing direct pressure on
the label area of the fan.

Notes:

Always connect the power cord last and always remove it before adding, re-1.
moving or changing any hardware components. Make sure that you install the
processor into the CPU socket before you install the CPU heatsink.

Make sure to install the motherboard into the chassis before you install the 2.
CPU heatsink and heatsink fans.

When purchasing a motherboard without the 5500 Series processor pre-3.
installed, make sure that the CPU socket plastic cap is in place, and none of
the CPU socket pins are bent; otherwise, contact the retailer immediately.

Chapter 2: Installation

Refer to the M B Features S ecti on for mo re deta ils on CPU s uppor t.4.

Installing an LGA 1366 Processor

Press the socket clip to release 1.
the load plate, which covers the
CPU socket, from its locking
position.

Gently lift the socket clip to 2.
open the load plate.

Hold the plastic cap at its north 3.
and south center edges to re­move it from the CPU socket.

Socket Clip

Plastic Cap

Load Plate

Hold the north & south edges of
the plastic cap to remove it

2-3

X8DTG-DF User's Manual

After removing the plastic cap, using 4.
your thumb and the index fi nger,
hold the CPU at the north and south
center edges.

Align the CPU key, the semi-circle 5.
cutout, against the socket key, the
notch below the gold color dot on
the side of the socket.

Once both the CPU and the socket 6.
are aligned, carefully lower the CPU
straight down into the socket. (Do
not rub the CPU against the surface
of the socket or its pins to avoid
damaging the CPU or the socket.)

Socket Keys CPU CPU SocketLoad Plate

With the CPU inside the socket, in-7.
spect the four corners of the CPU to
make sure that the CPU is properly
installed.

Once the CPU is securely seated 8.
on the socket, lower the CPU load
plate to the socket.

Use your thumb to gently push the 9.
socket clip down to the clip lock.

Warning: Please save the plas­tic ca p. The mot her board m ust
be shipped with the plastic cap
properly installed to protect the
CPU socket pins. Shipment
without the plastic cap properly
installed will cause damage to
the socket pins.

CPU Keys

2-4

Installing a CPU Heatsink

Do not apply any thermal 1.
grease to the heatsink or the
CPU die because the required
amount has already been ap­plied.

Chapter 2: Installation

Place the heatsink on top of the 2.
CPU so that the four mounting
holes are aligned with those on
the retention mechanism.

3. Install two diagonal screws (ie
the #1 and the #2 screws) and
tighten them until just snug (-do
not fully tighten the screws to
avoid possible damage to the
CPU.)

Screw#1

Screw#1

Install Screw#1

Screw#2

Screw#2

4. Finish the installation by fully
tightening all four screws.

2-5

X8DTG-DF User's Manual

Removing the Heatsink

Warni ng: We do not recommend that the CPU or the heatsink be re­moved. However, if you do need to remove the heatsink, please follow
the inst ructions be low to uninstall th e heatsink and prevent da mage to
the CPU or ot her co mpone nts.

Unplug the power cord from the 1.
power supply.

Disconnect the heatsink fan 2.
wires from the CPU fan header.

Using a screwdriver, loosen and 3.
remove the heatsink screws
from the motherboard in the se­quence as show in the picture
on the right.

Using a screwdriver to
remove Screw#1

Hold the heatsink as shown 4.
in the picture on the right and
gently wriggle the heatsink to
loosen it from the CPU. (Do not
use excessive force when wrig­gling the heatsink.)

Once the heatsink is loosened, 5.
remove it from the CPU socket.

To reinstall the CPU and the 6.
heatsink, clean the surface of
the CPU and the heatsink to get
rid of the old thermal grease.
Reapply the proper amount of
thermal grease on the surface
before reinstalling them on the
motherboard.

Remove Screw#2

2-6

Chapter 2: Installation

2-4 Memory Installation

Note: Check the S uper micro we b site for r ecom mende d memor y mo dules .

CAUTION

Exercise extreme care when installing or removing DIMM

module s to prevent any po ssib le damag e. Also n ote that th e

memor y is i nterl eaved to imp rove per fo rman ce (See ste p 1).

DIMM Installation

Insert the desired number of DIMMs into the memory slots, starting with 1.
P1-DIMM 1A. For best memory performance, please install memory modules
of the same type and same speed on the memory slots as indicated on the
tables below. (See the Memory Installation Table Below.)

Insert each DIMM module vertically into its slot. Pay attention to the notch 2.
along the bottom of the module to prevent inserting the DIMM module incor­rectly.

Gently press down on the DIMM module until it snaps into place in the slot. 3.
Repeat for all modules.

Memory Population for Optimal Performance

-For a motherboard with One CPU (CPU1) installed

Branch 0 Branch 1 Branch 2

3 DIMMs P1 DIMM1A P1 DIMM2A P1 DIMM3A
6 DIMMs P1 DIMM1A P1 DIMM1B P1 DIMM2A P1 DIMM2B P1 DIMM3A P1 DIMM3B

Memory Population for Optimal Performance

-For a motherboard with One CPU (CPU2) installed

Branch 0 Branch 1 Branch 2

3 DIMMs P2 DIMM1A P2 DIMM2A P2 DIMM3A
6 DIMMs P2 DIMM1A P2 DIMM1B P2 DIMM2A P2 DIMM2B P2 DIMM3A P2 DIMM3B

Memory Population for Optimal Performance

-For a motherboard with Two CPUs installed

CPU1 CPU2

Branch 0 Branch 1 Branch 3 Branch 0 Branch 1 Branch 3

6 DIMMs 1A 2A 3A 1A 2A 3A
12

DIMMs

1A 1B 2A 2B 3A 3B 1A 1B 2A 2B 3A 3B

2-7

X8DTG-DF User's Manual

Memory Support

The X8DTG-DF supports up to 96 GB of Registered ECC or up to 24 GB of Unbuf­fered ECC/Non-ECC DDR3 1333/1066/800 MHz Memory in 12 DIMMs.

Note1: With Unbuffered ECC/Non ECC memory, maximum of 2 GB of
memory is supported per DIMM slot.

Note 2: memory speed support is dependent on the type of CPU used
on the board.

DIMM Module Population Confi guration

For memor y to wor k pro perl y, follow the tab les be low for me mor y inst allati on:

DIMM Population Table

DIMM
Slots per
Channel

2 1 Reg. DDR3 ECC 800,1066,1333 SR or DR
2 1 Reg. DDR3 ECC 800,1066 QR
2 2 Reg. DDR3 ECC 800,1066 Mixing SR, DR
2 2 Reg. DDR3 ECC 800 Mixing SR, DR,QR

DIMMs
Populated
per Channel

DIMM Type (Reg.=
Registered)

Speeds (in MHz) Ranks per DIMM

(any combination;
SR=Single Rank,
DR=Dual Rank,
QR=Quad Rank)

Note 1: Due to OS limitations, some operating systems may not show

more than 4 GB of memory.
Note 2: Due to memory allocation to system devices, the amount of mem-

ory that remains available for operational use will be reduced when 4 GB
of R AM is us ed. The r educt ion in m emor y avai labili ty is di spro por tio nal.

Possible System Memory Allocation & Availability

System Device Size Physical Memory Available

Firmware Hub fl ash memory (System BIOS) 1 MB 3.99 GB
Local APIC 4 KB 3.99 GB
Area Reserved for the chipset 2 MB 3.99 GB
I/O APIC (4 Kbytes) 4 KB 3.99 GB
PCI Enumeration Area 1 256 MB 3.76 GB
PCI Express (256 MB) 256 MB 3.51 GB
PCI Enumeration Area 2 (if needed) -Aligned on 256-M

boundary­VGA Memory 16 MB 2.85 GB
TSEG 1 MB 2.84 GB
Memory available for the OS & other applications 2.84 GB

512 MB 3.01 GB

(4 GB Total System Memory)

2-8

Installing and Removing DIMMs

Chapter 2: Installation

X8DTG-DF

Release Tab

Notch

Release

Tab

DIMM DDR3

Note: Notch

should align

with the

receptive point

on the slot

Notch

Release

Tab

To Install :

Inser t m odul e ver tic all y and p res s down u ntil i t snap s
into plac e. Pay at tent ion to t he ali gnme nt notc h at
the bottom.

3

Release Tab

To Remove:

Use your thumbs to gently push the release tabs near both
ends of the module. This should release it from the slot.

2-9

X8DTG-DF User's Manual

1

2

3

4

5

6

7

8

2-5 Control Panel Connectors/IO Ports

The I/O p ort s are col or cod ed in co nforma nce wit h the PC 9 9 speci fi cation. See
the pic ture be low for t he co lors a nd loc atio ns of the var ious I /O por t s.

Back Panel Connectors/IO Ports

Back Panel Connectors

USB 01.
USB 12.
IPMI_Dedicated LAN3.
LAN 14.

X8DTG-DF

LAN 25.
COM Port 1 (Black)6.
VGA (Blue) 7.
UID Switch8.

2-10

Back Panel Connector Pin Defi nitions

1

2

3

Chapter 2: Installation

Universal Serial Bus (USB)

Two Universal Serial Bus ports (USB
0/1) are located on the I/O back panel.
Additional two USB connections: USB
2/3 are used to provide front chas­sis access. Connect USB cables to
these USB ports/headers to use USB
connections. (USB cables are not
included). See the tables on the right
for pin defi nitions.

Back Panel USB 0/1

Pin Defi nitions

Pin# Defi nition Pin# Defi nition
1 +5V 5 +5V
2 USB_PN1 6 USB_PN0
3 USB_PP1 7 USB_PP0
4 Ground 8 Ground

Front Panel USB 2/3

Pin Defi nitions

USB 2
Pin # Defi nition

1 +5V 6 +5V
2 USB_PN2 7 USB_PN3
3 USB_PP2 8 USB_PP3
4 Ground 9 Ground
5 No Con-

nection

USB 3
Pin # Defi nition

10 Key

1. USB 0

2. USB 1

3. USB 2/3

X8DTG-DF

2-11

X8DTG-DF User's Manual

1

2

3

Ethernet Ports

Two Ethernet ports are located next to
the USB 0/1 on the IO Backplane. In
addition, an IPMI Dedicated LAN is lo­cated above the USB ports 0/1. These
ports accept RJ45 type cables.

Note:
Please refer to the LED In-

dicator Section for LAN LED
information.

LAN Ports

Pin Defi nition

Pin# Defi nition
1 P2V5SB 10 SGND
2 TD0+ 11 Act LED
3 TD0- 12 P3V3SB
4 TD1+ 13 Link 100 LED

(Yellow, +3V3SB)

5 TD1- 14 Link 1000 LED

(Yellow, +3V3SB)
6 TD2+ 15 Ground
7 TD2- 16 Ground
8 TD3+ 17 Ground
9 TD3- 88 Ground

(NC: No Connection)

X8DTG-DF

1. LAN1

2. LAN2

3. IPMI dedicated LAN

2-12

Chapter 2: Installation

1

2

Serial Ports

A COM Port is located on the IO
Backplane. See the table on the right
for pin de fi nitions.

Video Connector

A Video (VGA) connector is located
next to the COM Port on the IO
backplane. This connector is used
to provide video and CRT display.
Refer to the board layout below for
the location.

Serial Port Pin Defi nitions

(COM1)

Pin # Defi nition Pin # Defi nition
1 CDC 6 DSR
2 RXD 7 RTS
3 TXD 8 CTS
4 DTR 9 RI
5 Ground 10 NC

X8DTG-DF

1. COM Port

2. VGA Port

2-13

X8DTG-DF User's Manual

1

123

Unit Identifi er Switches

Two Unit Identifi er (UID) Switches and LED
Indicators are located on the motherboard.
The Front Panel UID Switch is located at Pin
13 on the Front Control Panel (JF1). The Rear
UID Switch is located at SW1 next to the VGA
connector on the back panel. The Front Panel
UID LED is located at Pin 7 of JF1, and the
Rear UID LED is located at LE4. When you
press a UID switch on the front panel or on
the back panel, both Rear UID LED and Front
Panel UID LED Indicators will be turned on.
Press the UID switch again to turn off both LED
Indicators. These UID Indicators provide easy
identifi cation of a system unit that may be in
need of service.

Note: UID LED is supported by the
physical switch or the BMC. When it
is controlled by the physical switch, it
will stay solid. When it is controlled by
the BMC, it will blink.

UID Switch

Pin# Defi nition
1 Ground
2 Ground
3 Button In
4 Ground

FAN7

J11

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1

JWD1

SBX 1A

JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JPCIE1

USB2/3

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JNMI1

J_UID_OW

P1 DIMM2A

P1 DIMM3B

VGA

Intel
ICH10R
(South Bridge)

CPU2

P1 DIMM2B

P1 DIMM1A

COM1

LE2

Winbond
450R
BMC

CMOS
CLEAR

BIOS

X8DTG-DF

JBAT1

Battery

P1 DIMM1B

FAN3

IPMB

JLPC80

LAN2

JPG1

JPL1

P2 DIMM1A

P2 DIMM1B

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

LAN1

P2 DIMM2B

P2 DIMM2A

CPU1

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

PHY

J12

SBX 2A

+

JPCIE2

SBX 2B

LE1

JPW2

JPW3

FAN2

JL1

FAN6

FAN5

Front Panel CTRL

FAN1

4

1

1. Rear UID Switch

2. FP UID Switch & UID LED

3. Rear UID LED

2-14

Chapter 2: Installation

Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo­cated on a control panel at the front of the chassis. These connectors are designed
specifi cally for use with Supermicro server chassis. See the fi gure below for the
descriptions of the various control panel buttons and LED indicators. Refer to the
following section for descriptions and pin defi nitions.

JF1 Header Pins

1920

Ground

Key

Power LED

HDD LED

PWR Fail LED

Ground

Ground

No Connection

Key

3.3V

FP UID Switch/3.3V SB

NIC1 (Activity) LED

NIC2 (Activity) LED

Blue_LED_Cathode
(UID)/5V SB

3.3V

Reset

PWR

2

1

Reset Button

Power Button

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1
JWD1

J11

SBX 1A

JSPK1

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JPCIE3

USB2/3

JNMI1

J_UID_OW

P1 DIMM2A

P1 DIMM3B

VGA

Intel
ICH10R
(South Bridge)

CPU2

P1 DIMM2B

P1 DIMM1A

COM1

LE2

Winbond
450R
BMC

CMOS
CLEAR

BIOS

X8DTG-DF

JBAT1

Battery

P1 DIMM1B

FAN3

IPMB

JLPC80

JPL1

P2 DIMM1B

LAN2

JPG1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

P2 DIMM2B

P2 DIMM1A

CPU1

LAN1

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

J12

SBX 2A

PHY

+

NIC1(Link) LED

JPCIE2

NIC2 (Link) LED

OH/Fan Fail/PWR

4
1

Fail/UID LED

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

2-15

X8DTG-DF User's Manual

Front Control Panel Pin Defi nitions

Power LED

The Power LED connection is located on pins
15 and 16 of JF1. Refer to the table on the right
for pin defi nitions.

HDD/FP UID Switch

The HDD/UID Switch connections are located
on pins 13/14 of JF1. Attach a hard-drive LED
cable to display HDD or SATA activities. This
connection can also be used as a front panel
UID (Unit Identifi er) switch. The UID LED on
Pin 7 of JF1 works in conjunction with this UID
Switch. When the user presses and releases
the UID switch, the UID LED will be turned on
or off to indicate the location of the unit. (Refer
to Page 2-19 for more details.)

Power LED

Pin Defi nitions (JF1)

Pin# Defi nition
15 +3.3V SB
16 PWR LED

HDD/UID Switch

Pin Defi nitions (JF1)

Pin# Defi nition
13 UID Signal/3.3V
14 HDD Active

FAN7

J11

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1
JWD1

SBX 1A

JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JNMI1

J_UID_OW

USB2/3

P1 DIMM3B

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

VGA

LE2

Winbond
450R
BMC

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS
CLEAR

COM1

FAN3

JBAT1

Battery

LAN1

USB0/1

LAN2

IPMB

JLPC80

JPG1

JPL1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

IPMI_LAN

J12

SBX 2A

PHY

+

Ground

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

A

B

Key

Power LED

HDD LED

NIC1(Link) LED

NIC2 (Link) LED

FAN6

OH/Fan Fail/PWR

FAN5

Fail/UID LED

Front Panel CTRL

CPU1

LE1

JPW2

JPW3

FAN1

4

FAN2

JL1

1

PWR Fail LED

Ground

Ground

2

A. PWR LED
B. HDD LED/FP UID
Switch LED

1920

No Connection

Key

3.3V

FP UID Switch/3.3V SB

NIC1 (Activity) LED

NIC2 (Activity) LED

Blue_LED_Cathode
(UID)/5V SB

3.3V

Reset

PWR

1

Reset Button

Power Button

2-16

Chapter 2: Installation

NIC1 LED Indicator

The NIC (Network Interface Controller) LED
connections for GLAN port 1 are located on
pins 11 and 12 of JF1. Attach a NIC LED
cable to display LAN Port1 connections and
activities. Refer to the table on the right for pin
defi nitions.

NIC2 LED Indicator

The Network LED connections for GLAN port
2 are located on pins 9 and 10 of JF1. Attach
a NIC LED cable to display LAN Port2 connec­tions and activities. Refer to the table on the
right for pin defi nitions.

GLAN1 LED

Pin Defi nitions (JF1)

Pin# Defi nition
11 NIC1 Activity
12 NIC1 Link

GLAN2 LED

Pin Defi nitions (JF1)

Pin# Defi nition
9 NIC2 Activity
10 NIC2 Link

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

J11

SBX 1B

LE4

SW1
JWD1

JNMI1

SBX 1A

JSPK1

J_UID_OW

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JPCIE1

USB2/3

P1 DIMM3B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

VGA

LE2

Winbond
450R
BMC

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS
CLEAR

COM1

Battery

FAN3

LAN1

USB0/1

LAN2

IPMB

JLPC80

JPG1

JPL1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

P2 DIMM2B

P2 DIMM1A

P2 DIMM1B

JBAT1

CPU1

P2 DIMM3B

P2 DIMM2A

IPMI_LAN

PHY

P2 DIMM3A

+

J12

SBX 2A

SBX 2B

FAN2

JPCIE2

LE1

JPW2

JPW3

JL1

A

NIC1(Link) LED

NIC2 (Link) LED

B

OH/Fan Fail/PWR

FAN6

Fail/UID LED

FAN5

Front Panel CTRL

FAN1

4
1

Ground

Key

Power LED

HDD LED

PWR Fail LED

Ground

Ground

A. NIC1 LED
B. NIC2 LED

1920

No Connection

Key

3.3V

FP UID Switch/3.3V SB

NIC1 (Activity) LED

NIC2 (Activity) LED

Blue_LED_Cathode
(UID)/5V SB

3.3V

Reset

PWR

2

1

Reset Button

Power Button

2-17

X8DTG-DF User's Manual

Overheat (OH)/Fan Fail/PWR Fail/UID LED

Connect an LED cable to pins 7 and 8 of JF1 to
use the Overheat/Fan Fail/Power Fail and UID
LED con nec t io ns. T he Re d LED o n pi n 8 pro­vides war nings of an overheat, fan fail ure or
power failure. The Blue LED on pin 7 works as
the UID L ED indic ator fo r the fr ont pane l UID
switch located on pins 13~14 of JF1. When
Jumper J_UID_OW is set to off (default), the
Red LED takes precedence over the Blue
LED. (See Page 2- 31 for det ai ls.) Refer to the
table o n the ri ght for p in defi nitions.

Power Fail LED

The Power Fail LED c onne cti on is lo cate d on
pins 5 and 6 of J F1. Refer to the table on t he
right fo r pin defi nitions.

OH/Fan Fail/ PWR Fail/Blue_UID

LED Pin Defi nitions (JF1)

Pin# Defi nition
7 Blue_LED-Cathode(UID)/5.5V.SB
8 OH/Fan Fail/PWR Fail/UID LED

(Red)

OH/Fan Fail/PWR Fail

LED Status (Red LED)

State Defi nition
Off Normal
On Overheat
Flashing Fan Fail

PWR Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition
5 3.3V
6 PWR Fail LED

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1

JWD1

J11
SBX 1A

JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JNMI1

J_UID_OW

USB2/3

P1 DIMM3B

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

VGA

LE2

Winbond
450R
BMC

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS
CLEAR

COM1

Battery

FAN3

LAN1

USB0/1

LAN2

IPMB

JLPC80

JPG1

JPL1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

IPMI_LAN

J12

SBX 2A

PHY

+

Ground

JPCIE2

Key

SBX 2B

P2 DIMM1B

P2 DIMM2B

P2 DIMM1A

P2 DIMM3B

P2 DIMM2A

P2 DIMM3A

Power LED

HDD LED

NIC1(Link) LED

JBAT1

CPU1

LE1

JPW2

JPW3

FAN2

JL1

NIC2 (Link) LED

FAN6

OH/Fan Fail/PWR

FAN5

A

Fail/UID LED

Front Panel CTRL

B

FAN1

4

1

PWR Fail LED

Ground

Ground

2

A. OH/Fan Fail/PWR Fail/
UID LED
B. PWR Supply Fail

1920

No Connection

Key

3.3V

FP UID Switch/3.3V SB

NIC1 (Activity) LED

NIC2 (Activity) LED

Blue_LED_Cathode
(UID)/5V SB

3.3V

Reset

PWR

1

Reset Button

Power Button

2-18

Chapter 2: Installation

Reset Button

The Reset Button connection is located on pins
3 and 4 of JF1. Attach it to a hardware reset
switch on the computer case. Refer to the table
on the right for pin defi nitions.

Power Button

The Power Button connection is located on
pins 1 and 2 of JF1. Momentarily contacting
both pins will power on/off the system. This
button can also be confi gured to function as
a suspend button (with a setting in the BIOS

- see Chapter 4). To turn off the power when
set to suspend mode, press the button for at
least 4 seconds. Refer to the table on the right
for pin defi nitions.

Reset Button

Pin Defi nitions (JF1)

Pin# Defi nition
3 Reset
4 Ground

Power Button

Pin Defi nitions (JF1)

Pin# Defi nition

1 PWR
2 Ground

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1
JWD1

J11

SBX 1A

JSPK1

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JPCIE3

USB2/3

JNMI1

J_UID_OW

P1 DIMM2A

P1 DIMM3B

VGA

Intel
ICH10R
(South Bridge)

CPU2

P1 DIMM2B

P1 DIMM1A

COM1

LE2

Winbond
450R
BMC

CMOS
CLEAR

BIOS

X8DTG-DF

JBAT1

Battery

P1 DIMM1B

FAN3

IPMB

JLPC80

JPL1

P2 DIMM1B

LAN2

JPG1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

P2 DIMM2B

P2 DIMM1A

CPU1

LAN1

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

J12

SBX 2A

PHY

+

A. Reset Button
B. PWR Button

1920

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

NIC1(Link) LED

NIC2 (Link) LED

OH/Fan Fail/PWR
Fail/UID LED

PWR Fail LED

4

1

Ground

Key

Power LED

HDD LED

Ground

Ground

2

No Connection

Key

3.3V

FP UID Switch/3.3V SB

NIC1 (Activity) LED

NIC2 (Activity) LED
Blue_LED_Cathode

(UID)/5V SB

3.3V

Reset

PWR

Reset Button

Power Button

1

A

B

2-19

X8DTG-DF User's Manual

2-6 Connecting Cables

20-pin Proprietary Main Power and 8-pin
PCI-E Graphic Card Power Connectors

There are one 20-pin SMC Proprietary main
power connector (JPW1) and two 8-pin
PCI-Express graphic card power connectors
(JPW2/JPW3) on the motherboard. These
power connectors meet the SSI EPS 12V
specifi cation. See the tables on the right for
pin defi nitions.

Notes: 1. For the these proprietary
PWR Connectors to work properly,
please customize your PWR cables
based on the SMC PWR Connector
Pin-Out Defi nitions listed in the tables
on the right.

2. For the PCI-Exp. Graphic cards
to work properly, please connect the
PCI-E graphic card power connectors
(JPW2/JPW3) to the power supply.

20-pin Main Power Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition
11 PS On 1 Ground
12 5VSB 2 Ground
13 Ground 3 Ground
14 Ground 4 Ground
15 Ground 5 Ground
16 NC2 6 NC1
17 12V 7 12V
18 12V 8 12V
19 12V 9 12V
20 12V 10 12V

8-pin PCI-E Graphic Card Power

Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition
1 12V 5 Ground
2 12V 6 Ground
3 12V 7 Ground
4 Ground 8 Ground

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

A

JPW1

LE4

SW1

JWD1

J11

SBX 1A

JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JNMI1

J_UID_OW

USB2/3

P1 DIMM3B

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

VGA

LE2

Winbond
450R
BMC

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS

CLEAR

COM1

JBAT1

Battery

FAN3

IPMB

JLPC80

LAN2

JPG1

JPL1

P2 DIMM1A

P2 DIMM1B

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

LAN1

P2 DIMM2B

P2 DIMM2A

CPU1

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

J12
SBX 2A

PHY

+

A. 20- pin Main PWR connector (JPW1)
B/C. 8-pin PCI-E Graphic Card PWR

connectors (JPW2/JPW3)

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

B

JPW3

C

FAN1

4

FAN2

JL1

1

2-20

Chapter 2: Installation

D

G

F

E

Fan Headers

The X8DTG-DF has eight chassis/system fan
headers (Fan1 to Fan8) on the motherboard.
All these 4-pin fans headers are backward
compatible with the traditional 3-pin fans. 3-pin
fans do not support fan speed control. How­ever, fan speed control is available for 4-pin
fans. The fan speeds are controlled by Thermal
Management via Hardware Monitoring in the
Advanced Setting in the BIOS. (The Default
setting is Disabled.) See the table on the right
for pin defi nitions.

COM1

LE2

Winbond
450R
BMC

CMOS

CLEAR

BIOS

X8DTG-DF

IPMB

JLPC80

JPL1

LAN2

JPG1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

LAN1

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

JPCIE2

JNMI1

J_UID_OW

VGA

Intel
ICH10R
(South Bridge)

LE4

SW1

JWD1

J11

SBX 1A

JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

I-SATA6

JPCIE1

USB2/3

SBX 1B

I-SATA4I-SATA5

Fan Header

Pin Defi nitions

Pin# Defi nition
1 Ground
2 +12V
3 Tachometer
4 PWR Modulation

A. Fan1
B. Fan2
C. Fan3
D. Fan4
E. Fan5
F. Fan6
G. Fan7
H. Fan8

P2 DIMM3B

P2 DIMM3A

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

A

4

1

B

FAN7

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

H

P1DIMM3A

FAN4

JPI2C (PWR I2C)

P1 DIMM2A

P1 DIMM3B

CPU2

P1 DIMM2B

P1 DIMM1A

P1 DIMM1B

JBAT1

Battery

FAN3

C

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

2-21

X8DTG-DF User's Manual

NMI Header

The non-maskable interrupt header is located
at JNMI1. Refer to the table on the right for
pin defi nitions.

Internal Buzzer

The Internal Buzzer, located at JSPK1, can be
used to provide audible alarms for various beep
codes. See the table on the right for pin defi ni-
tions. Refer to the layout below for the locations
of the Internal Speaker/Buzzer.

JNMI1

A

J_UID_OW

VGA

LE4

SW1

JWD1

J11

SBX 1A

JSPK1

B

JPCIE3

LE2

Winbond
450R
BMC

COM1

IPMB

JLPC80

JPL1

LAN2

JPG1

LAN1

Intel
82576
LAN CTRL

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

NMI Button

Pin Defi nitions (JF1)

Pin# Defi nition
1 Control
2 Ground

Internal Buzzer

Pin Defi nitions

Pin# Defi nitions
Pin 1 Pos. (+) Beep In
Pin 2 Neg. (-) Alarm Speaker

A. NMI Header
B. Internal Speaker

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

JPCIE1

SBX 1B

PCI-E 2.0

x4 in x16 Slot

USB2/3

P1 DIMM3B

P1DIMM3A

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS

CLEAR

JBAT1

Battery

Intel
5520
IOH-36D

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

FAN4

JPI2C (PWR I2C)

FAN3

FAN2

JPW3

JL1

FAN1

4
1

2-22

Chapter 2: Installation

Chassis Intrusion

A Chassis Intrusion header is located at JL1 on
the motherboard. Attach an appropriate cable
from the chassis to inform you of a chassis
intrusion when the chassis is opened.

T-SGPIO Headers

Two SGPIO (Serial-Link General Purpose In­put/Output) headers (T-SGPIO-0/T-SGPIO-1)
are located on the motherboard. These
headers support serial link interfaces for the
onboard SATA connectors. See the table on
the right for pin defi nitions. Refer to the board
layout below for the location.

J11

SBX 1A

LE4

SW1
JWD1

JNMI1

JSPK1

J_UID_OW

JPCIE3

PCI-E 2.0

x4 in x16 Slot

VGA

Intel
ICH10R
(South Bridge)

LE2

Winbond
450R
BMC

BIOS

CMOS
CLEAR

COM1

IPMB

JLPC80

JPL1

JPG1

LAN2

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

LAN1

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

Chassis Intrusion

Pin Defi nitions (JL1)

Pin# Defi nition
1 Intrusion Input
2 Ground

T-SGPIO

Pin Defi nitions

Pin# Defi nition Pin Defi nition
1NC 2NC
3 Ground 4 Data

5 Load 6 Ground
7NC 8NC

Note: NC= No Connections

A. Chassis Intrusion
B. T-SGPIO0
C. T-SBPIO1

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

B

T-SGPIO1

C

FAN8

JPW1

JPCIE1

USB2/3

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

P1 DIMM2A

P1 DIMM3B

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM2B

P1 DIMM1A

JBAT1

Battery

FAN3

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

4

1

A

2-23

X8DTG-DF User's Manual

PWR I2C (SMB) Connector

Power System Management Bus (I
nector (JPI

2

C) monitors power supply, fan and

2

C) Con-

system temperatures. See the table on the right
for pin defi nitions.

IPMB I2C SMB

A System Management Bus (I

2

C) header for
the IPMI slot is located at IPMB. Connect the
appropriate cable here to use the IPMB I

2

connection on your system.

J11

SBX 1A

LE4

SW1

JWD1
JSPK1

VGA

JNMI1

J_UID_OW

JPCIE3

LE2

Winbond
450R
BMC

COM1

IPMB

B

JLPC80

JPL1

LAN2

JPG1

LAN1

Intel
82576
LAN CTRL

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

C

PWR I2C (SMB)
Pin Defi nitions

Pin# Defi nition
1 Clock
2 Data

3 PWR Fail
4 Ground

SMB for IPMI

Pin Defi nitions

Pin# Defi nition
1 Data
2 Ground
3 Clock
4 No Connection

A. PWR I2C (SMB)
B. IPMB SMB

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

JPCIE1

SBX 1B

PCI-E 2.0

x4 in x16 Slot

USB2/3

P1 DIMM3B

P1DIMM3A

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS

CLEAR

JBAT1

Battery

Intel
5520
IOH-36D

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

FAN4

A

JPI2C (PWR I2C)

FAN3

FAN2

JPW3

JL1

FAN1

4
1

2-24

VGA

COM1

2-7 Jumper Settings

Connector

Pins

Jumper

Cap

Setting

Explanation of Jumpers

To modify the operation of the motherboard,
jumpers can be used to choose between optional
settings. Jumpers create shorts between two pins
to change the function of the connector. Pin 1 is
identifi ed with a square solder pad on the printed
circuit board. See the motherboard layout pages for
jumper locations.

Note: On two pin jumpers, "Closed"
means the jumper is on and "Open"
means th e jumpe r is of f the pi ns.

Chapter 2: Installation

3 2 1

3 2 1

GLAN Enable/Disable

JPL1 enables or disa bles the GL AN Por ts 1/2 on
the motherboard. See the table on the right for
jumper settings.

Pin 1-2 short

GLAN Enable

Jumper Settings

Pin# Defi nition
1-2 Enabled (default)

LE4

SW1
JWD1

JNMI1

J11

SBX 1A

JSPK1

J_UID_OW

JPCIE3

PCI-E 2.0

x4 in x16 Slot

I-SATA6

JPCIE1

USB2/3

SBX 1B

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

Intel
ICH10R
(South Bridge)

CPU2

LE2

Winbond
450R
BMC

CMOS
CLEAR

BIOS

X8DTG-DF

IPMB

A

JLPC80

JPL1

P2 DIMM1B

LAN2

JPG1

Intel
5520
IOH-36D

P2 DIMM1A

Intel
82576
LAN CTRL

P2 DIMM2B

LAN1

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

J12

SBX 2A

PHY

+

2-3 Disabled

A. GLAN Port 1/2 Enable

JPCIE2

SBX 2B

FAN7

JPW1

FAN4

P1 DIMM3B

P1DIMM3A

JPI2C (PWR I2C)

P1 DIMM2A

P1 DIMM2B

P1 DIMM1B

P1 DIMM1A

JBAT1

Battery

FAN3

CPU1

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

4
1

2-25

X8DTG-DF User's Manual

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact pads
to prevent the accidental clearing of CMOS. To clear CMOS, use a metal object such
as a small screwdriver to touch both pads at the same time to short the connection.
Always remove the AC power cord from the system before clearing CMOS.

Note: For an ATX power supply, you must completely shut down the sys­tem, remove the AC power cord and then short JBT1 to clear CMOS.

Watch Dog Enable/Disable

Watch Dog (JWD1) is a system monitor that
reboots the system when a software applica­tion hangs. Close Pins 1-2 to reset the system
if an application hangs. Close Pins 2-3 to
generate a non-maskable interrupt signal for
the application that hangs. See the table on
the right for jumper settings. Watch Dog must
also be enabled in the BIOS.

COM1

JNMI1

B

J_UID_OW

JPCIE3

USB2/3

VGA

Intel
ICH10R
(South Bridge)

CPU2

LE2

Winbond
450R
BMC

CMOS
CLEAR

BIOS

X8DTG-DF

IPMB

A

JLPC80

JPL1

P2 DIMM1B

LAN2

JPG1

Intel
5520
IOH-36D

P2 DIMM1A

LAN1

Intel
82576
LAN CTRL

P2 DIMM2B

P2 DIMM3B

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3A

J12

SBX 2A

PHY

+

JPCIE2

SBX 2B

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

J11

SBX 1A

SBX 1B

LE4

SW1

JWD1
JSPK1

PCI-E 2.0

x4 in x16 Slot

JPCIE1

Watch Dog

Jumper Settings

Jumper Setting Defi nition
Pins 1-2 Reset

(default)
Pins 2-3 NMI
Open Disabled

A. Clear CMOS
B. Watch Dog Enable

FAN7

JPW1

FAN4

P1 DIMM3B

P1DIMM3A

JPI2C (PWR I2C)

P1 DIMM2A

P1 DIMM2B

P1 DIMM1B

P1 DIMM1A

JBAT1

Battery

FAN3

CPU1

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

4
1

2-26

Chapter 2: Installation

VGA Enable

JPG1 allows you to enable or disable the
onboard VGA connection supported by the
onboard VGA Controller. The default position is
on pins 1 and 2 to enable VGA. See the table
on the right for jumper settings.

J11

SBX 1A

LE4

SW1
JWD1

JSPK1

VGA

JNMI1

J_UID_OW

JPCIE3

LE2

Winbond
450R
BMC

COM1

IPMB

JLPC80

JPL1

JPG1

LAN2

Intel
82576
LAN CTRL

A

LAN1

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

VGA Enable/Disable

Jumper Settings (JPG1)

Both Jumpers Defi nition
Pins 1-2 Enabled
Pins 2-3 Disabled

A. VGA Enable

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

JPCIE1

SBX 1B

PCI-E 2.0

x4 in x16 Slot

USB2/3

P1 DIMM3B

P1DIMM3A

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

CMOS
CLEAR

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

JBAT1

Battery

Intel
5520
IOH-36D

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

FAN4

JPI2C (PWR I2C)

FAN3

FAN2

JL1

JPW3

FAN1

4

1

2-27

X8DTG-DF User's Manual

J_UID_OW (-Overwriting)

When the jumper J_UID_OW is set to Off (de­fault), the Red LED (Overheat/Fan Fail/PWR
Fail/UID LED) located on Pin 8 of the Front
Control Panel (JF1) will take precedence over
the Blue UID_LED located on Pin 7 of JF1. In
this case, when the Red LED is on, the Blue
LED will be turned off. When the RED LED
is off, the Blue UID_LED can be on or off. In
other words, the Red LED signal overwrites the
Blue UID_LED signal if J_UID-OW is set to off.
When the jumper J_UID_OW is On, the Red
LED (OH/Fan Fail/PWR Fail/UID LED) and the
Blue_UID_LED work independently. The Red
LED will have no effects on the Blue LED. See
the table on the right for jumper settings.

J_UID-OW (-Overwriting)

Jumper Settings

Jumper Defi nition
Off

(De­fault)

Red OH/Fan Fail/PWR Fail LED
(Pin 8 of JF1) takes precedence
over (overwrites) the Blue
UID_LED (Pin 7 of JF1).

Red LED: On, Blue LED: Off,
Red LED: Off, Blue LED: On
or Off

On Red LED (OH/Fan Fail/PWR

Fail LED) and the Blue UID_
LED function independently.
Red LED does not overwrite the
Blue LED. The Red LED has no
effects on the Blue_UID LED

Red LED: On, Blue LED: On,Off
Red LED: Off, Blue LED: On,
Off

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1
JWD1

J11

SBX 1A

JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JNMI1

J_UID_OW

USB2/3

P1 DIMM3B

A

Intel
ICH10R
(South Bridge)

P1 DIMM2A

VGA

X8DTG-DF

CPU2

P1 DIMM2B

P1 DIMM1B

P1 DIMM1A

LE2

BIOS

Winbond
450R
BMC

CMOS
CLEAR

COM1

JBAT1

Battery

FAN3

IPMB

JLPC80

LAN2

JPG1

JPL1

Intel
5520
IOH-36D

P2 DIMM1A

P2 DIMM1B

Intel
82576
LAN CTRL

P2 DIMM2B

CPU1

LAN1

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3B

P2 DIMM3A

PHY

J12

SBX 2A

+

JPCIE2

SBX 2B

NIC1(Link) LED

NIC2 (Link) LED

FAN6

B

OH/Fan Fail/PWR

FAN5

Fail/UID LED

Front Panel CTRL

FAN1

4

1

PWR Fail LED

LE1

JPW2

JPW3

FAN2

JL1

Ground

Key

Power LED

HDD LED

Ground

Ground

A. J_UID_LED

1920

No Connection

Key

3.3V

FP UID Switch/3.3V SB

NIC1 (Activity) LED

NIC2 (Activity) LED

Blue_LED_Cathode
(UID)/5V SB

3.3V

Reset

PWR

2

1

Reset Button

Power Button

2-28

2-8 Onboard Indicators

GLAN LEDs

There are two GLAN ports on the motherboard.
An additional IPMI dedicated LAN port is
also located above the USB 0/1 ports on the
backpanel. Each Gigabit Ethernet LAN port has
two LEDs. The yellow LED indicates activity,
while the Link LED may be green, amber or off
to indicate the speed of the connection. See the
tables at right for more information.

Note: IPMI dedicated LAN does not
operate at 1 Gbps.

Chapter 2: Installation

Link
LED

Rear View (when facing the
rear side of the chassis)

GLAN Activity Indicator

LED Settings

Color Status Defi nition
Yellow Flashing Active

GLAN Link Indicator

LED Settings

LED Color Defi nition
Off No Connection or 10 Mbps
Green 100 Mbps
Amber 1 Gbps

Activity
LED

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

LE4

SW1

JWD1

J11

SBX 1A

JSPK1

PCI-E 2.0

x4 in x16 Slot

JPCIE1

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

JNMI1

J_UID_OW

JPCIE3

USB2/3

P1 DIMM3B

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

VGA

LE2

Winbond
450R
BMC

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS

CLEAR

COM1

Battery

FAN3

JBAT1

IPMB

JLPC80

JPL1

P2 DIMM1B

B

LAN2

JPG1

Intel
5520
IOH-36D

P2 DIMM1A

A

LAN1

Intel
82576
LAN CTRL

P2 DIMM2B

CPU1

P2 DIMM3B

P2 DIMM2A

USB0/1

IPMI_LAN

P2 DIMM3A

PHY

J12

SBX 2A

C

+

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

A. LAN 1
B. LAN 2
C. IPMI dedicated LAN

C

A

4

1

B

2-29

X8DTG-DF User's Manual

Onboard Power LED

An Onb oard Power LED is l ocated at LE1
on the motherboard. When this LED is on,
the system power is on. Be sure to turn
off t he system and u nplug the p ower cor d
before removing or installing components.
See the tables at right for more informa­tion.

BMC Activity LED

A BMC Heartbeat LED is located at LE2
on the motherboard. When LE2 is on,
BMC (Ba seb oa rd M an ag eme nt C ont ro ll er)
is acti ve. See the table s at right for mo re
information.

Note: For Rear UID LED (LE4), please refer to Page 2-14.

COM1

JNMI1

J_UID_OW

VGA

B

LE2

Winbond
450R
BMC

IPMB

JLPC80

JPL1

LAN2

JPG1

LAN1

Intel
82576
LAN CTRL

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

J11

SBX 1A

LE4

SW1

JWD1
JSPK1

JPCIE3

Onboard PWR LED

Indicator Settings

LED Color Defi nition
Off System Off (PWR cable

not connected)
Green System On
Green:

ACPI S1 State
Flashing
Quickly

BMC Activity LED Indicator

LED Settings

Green: On BMC is active

A. LE1
B. LE2

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

I-SATA2

I-SATA1

T-SGPIO0

T-SGPIO1

FAN8

JPW1

SBX 1B

PCI-E 2.0

x4 in x16 Slot

JPCIE1

USB2/3

P1 DIMM3B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

Intel
ICH10R
(South Bridge)

P1 DIMM2A

P1 DIMM2B

BIOS

X8DTG-DF

CPU2

P1 DIMM1B

P1 DIMM1A

CMOS
CLEAR

JBAT1

Battery

FAN3

Intel
5520
IOH-36D

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

A

LE1

JPW2

JPW3

FAN1

FAN2

JL1

4
1

2-30

F

E

D

2-9 Serial ATA Connections

Chapter 2: Installation

Serial ATA Ports

Six Serial ATA Ports (I- SATA1~I- SATA6) are
located at JS1~JS6 on the motherboard.
These ports provide serial-link signal trans­mission, which is faster than that of the tradi­tiona l Parall el ATA. Se e the t abl e on the r igh t
for pin de fi nitions.

J11

SBX 1A

LE4

SW1

JWD1
JSPK1

JPCIE3

PCI-E 2.0

x4 in x16 Slot

JNMI1

J_UID_OW

VGA

Intel
ICH10R
(South Bridge)

LE2

BIOS

Winbond
450R
BMC

CMOS
CLEAR

COM1

IPMB

JLPC80

JPL1

LAN2

JPG1

Intel
82576
LAN CTRL

Intel
5520
IOH-36D

LAN1

USB0/1

IPMI_LAN

J12

SBX 2A

PHY

+

Serial ATA

Pin Defi nitions

Pin# Defi nition
1 Ground
2 TX_P
3 TX_N
4 Ground
5 RX_N
6 RX_P
7 Ground

A. I-SATA1
B. I-SATA2
C. I-SATA3
D. I-SATA4
E. I-SATA5
F. I-SATA6

FAN7

I-SATA6

I-SATA4I-SATA5

I-SATA3

C

I-SATA2

B

I-SATA1

A

T-SGPIO0

T-SGPIO1

FAN8

JPW1

JPCIE1

USB2/3

SBX 1B

P1DIMM3A

FAN4

JPI2C (PWR I2C)

P1 DIMM2A

P1 DIMM3B

X8DTG-DF

CPU2

P1 DIMM2B

P1 DIMM1B

P1 DIMM1A

JBAT1

Battery

FAN3

P2 DIMM1A

P2 DIMM1B

P2 DIMM2B

P2 DIMM2A

CPU1

P2 DIMM3B

P2 DIMM3A

JPCIE2

SBX 2B

FAN6

FAN5

Front Panel CTRL

LE1

JPW2

JPW3

FAN1

FAN2

JL1

4
1

2-31

X8DTG-DF User's Manual

Notes

2-32

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all
of the procedures below and still need assistance, refer to the ‘Technical Support
Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.
Note: Always disconnect the power cord before adding, changing or installing any
hardware components.

Before Power On

Make sure that there are no short circuits between the motherboard and 1.
chassis.

Disconnect all ribbon/wire cables from the motherboard, including those for 2.
the keyboard and mouse.

Remove all add-on cards.3.

Install CPU 1 fi rst (making sure it is fully seated) and connect the chassis 4.
speaker and the power LED to the motherboard. (Check all jumper settings
as well.)

No Power

Make sure that no short circuits between the motherboard and the chassis.1.

Make sure that all jumpers are set to their default positions.2.

Check that the 115V/230V switch on the power supply is properly set.3.

Turn the power switch on and off to test the system.4.

The battery on your motherboard may be old. Check to verify that it still sup-5.
plies ~3VDC. If it does not, replace it with a new one.

3-1

X8DTG-DF User's Manual

No Video

If the power is on but you have no video, remove all the add-on cards and 1.
cables.

Use the speaker to determine if any beep codes exist. Refer to the Appendix 2.
for details on beep codes.

Losing the System’s Setup Confi guration

Make sure that you are using a high quality power supply. A poor quality 1.
power supply may cause the system to lose the CMOS setup information.
Refer to Section 1-7 for details on recommended power supplies.

The battery on your motherboard may be old. Check to verify that it still sup-2.
plies ~3VDC. If it does not, replace it with a new one.

If the above steps do not fi x the Setup Confi guration problem, contact your 3.
vendor for repairs.

Memory Errors

When a No_Memory_Beep_Code is issued by the system, check the following:

Make sure that the DIMM modules are properly and fully installed. 1.

Check if different speeds of DIMMs have been installed. It is strongly recom-2.
mended to use the same RAM speed for all DIMMs in the system.

Make sure you are using the correct type of DDR3 Registered ECC or Unbuf-3.
fered ECC/Non-ECC 1333 MHz/1066 MHz/800 MHz SDRAM (recommended
by the manufacturer.)

Check for bad DIMM modules or slots by swapping a single module between 4.
all memory slots and check the results.

Make sure that all memory modules are fully seated in their slots. Make sure 5.
to follow the instructions given in Section 2-4 in Chapter 2.

Check the position of the 115V/230V switch on the power supply. 6.

Please follow the instructions given in the DIMM Population Tables listed on 7.
Pages 2-7 and 2-8 to install your memory modules.

3-2

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, please
note that as a motherboard manufacturer, Supermicro does not sell directly to end­users, so it is best to fi rst check with your distributor or reseller for troubleshooting
services. They should know of any possible problem(s) with the specifi c system
confi guration that was sold to you.

Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked 1.
Question' (FAQ) sections in this chapter or see the FAQs on our web site
(

http://www.supermicro.com/support/faqs/) before contacting Technical Sup-

port.

BIOS upgrades can be downloaded from our web site at 2.

supermicro.com/support/bios/

If you still cannot resolve the problem, include the following information when 3.
contacting Supermicro for technical support:

Motherboard model and PCB revision number

•

BIOS release date/version (this can be seen on the initial display when your •
system fi rst boots up)

System confi guration

•

An example of a Technical Support form is on our web site at • (http://www.

supermicro.com/support/contact.cfm).

Distributors: For immediate assistance, please have your account number ready

•

when placing a call to our technical support department. We can be reached by
e-mail at [e-mail] or by fax at: [phone], option 2.

).

(http://www.

3-3 Frequently Asked Questions

Que sti on: Wh at a re th e var iou s t ype s of m emo r y th at my mo th er boa rd c an
support?

Answer: The X8DTG-DF has 12 240-pin DIMM slots that support up to 96 GB of

Registered ECC or up to 24 GB of Unbuffered ECC/Non-ECC DDR3 1333/1066/800
MHz Memory. (With Unbuffered ECC/Non-ECC memory, maximum of 2 GB per
DIMM is supported.) See Pages 2-7, 2-8 in Chapter 2 for DIMM Slot Population.

3-3

X8DTG-DF User's Manual

Que stio n: How do I u pda te my BI OS?
Answer: It is recommended that you do not upgrade your BIOS if you are not

experiencing any problems with your system. Updated BIOS fi les are located on
our web site at
warning message and the information on how to update your BIOS on our web
site. Select your motherboard model and download the BIOS fi le to your computer.
Also, check the current BIOS revision and make sure that it is newer than your
BIOS before downloading. You can choose from the zip fi le and the .exe fi le. If you
choose the zip BIOS fi le, please unzip the BIOS fi le onto a bootable USB device.
Run the batch fi le using the format fl ash.bat fi lename.rom from your bootable USB
device to fl ash the BIOS. Then, your system will automatically reboot. Please note
that this process may take a few minutes to complete. Do not be concerned if the
screen is paused for a few minutes.

http://www.supermicro.com/support/bios/. Please check our BIOS

Warning: Do not s hut down or re set the syste m while up dating the B IOS

to prevent possible system boot failure!)

Note: The SPI BIO S chip used on thi s motherboa rd cannot be rem oved.

Send your motherboard back to our RMA Department at Supermicro for
repair.

Question: What's on the CD that came with my motherboard?
Answer: The supplied compact disc has quite a few drivers and programs that will

greatl y enhanc e your sys tem. We rec omme nd that you r eview th e CD and in stall
the appl icat ions you n eed. Ap plic ation s on the C D inclu de chip set dri vers fo r the
Window s OS, sec uri ty and a udio dr ivers.

3-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be­fore any warranty service will be rendered. You can obtain service by calling your
vendor for a Returned Merchandise Authorization (RMA) number. When returning to
the manufacturer, the RMA number should be prominently displayed on the outside
of the shipping carton, and mailed prepaid or hand-carried. Shipping and handling
charges will be applied for all orders that must be mailed when service is complete.
For faster service, You can also request a RMA authorization online (http://www.
supermicro.com/support/rma/).

This warranty only covers normal consumer use and does not cover damages in­curred in shipping or from failure due to the alternation, misuse, abuse or improper
maintenance of products.

During the warranty period, contact your distributor fi rst for any product problems.

3-4

Chapter 4: AMI BIOS

Chapter 4

BIOS

4-1 Introduction

This chapter describes the AMI BIOS Setup Utility for the X8DTG-DF. The AMI
ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter
describes the basic navigation of the AMI BIOS Setup Utility setup screens.

Starting BIOS Setup Utility

To enter the AMI BIOS Setup Utility screens, press the <Delete> key while the
system is booting up.

Note: In most cases, the <Delete> key is used to invoke the AMI BIOS
setup screen. There are a few cases when other keys are used, such as
<F1>, <F2>, etc.

Each main BIOS menu option is described in this manual. The Main BIOS setup
menu screen has two main frames. The left frame displays all the options that can
be confi gured. Grayed-out options cannot be confi gured. Options in blue can be con-
fi gured by the user. The right frame displays the key legend. Above the key legend is
an area reserved for a text message. When an option is selected in the left frame, it
is highlighted in white. Often a text message will accompany it. The AMI BIOS Setup
Utility uses a key-based navigation system called "hot keys". Most of the AMI BIOS
setup utility "hot keys" can be used at any time during the setup navigation process.
These keys include <F1>, <F10>, <Enter>, <ESC>, arrow keys, etc.

Note 1: Options printed in Bold are default settings.
Note 2: the AMI BIOS has default text messages built in. Supermicro re-

tains the option to include, omit, or change any of these text messages.)

How To Change the Confi guration Data

The confi guration data that determines the system parameters may be changed by
entering the AMI BIOS Setup utility. This Setup utility can be accessed by pressing
<Del> at the appropriate time during system boot.

4-1

X8DTG-DF User’s Manual

Starting the Setup Utility

Normally, the only visible Power-On Self-Test (POST) routine is the memory test.
As the memory is being tested, press the <Delete> key to enter the main menu of
the AMI BIOS Setup Utility. From the main menu, you can access the other setup
screens. An AMI BIOS identifi cation string is displayed at the left bottom corner of
the screen below the copyright message.

Warning! Do not upgrade the BIOS unless your system has a BIOS-related
issue. Flashing the wrong BIOS can cause irreparable damage to the
system. In no event shall Supermicro be liable for direct, indirect, special,
incidental, or consequential damages arising from a BIOS update. If you
have to update the BIOS, do not shut down or reset the system while the
BIOS is updating. This is to avoid possible boot failure.

4-2 Main Setup

When you fi rst enter the AMI BIOS Setup Utility , you will enter the Main setup screen.
You can always return to the Main setup screen by selecting the Main tab on the
top of the screen. The Main BIOS Setup screen is shown below.

System Overview: The following BIOS information will be displayed:

System Time/System Date

Use this option to change the system time and date. Highlight System Time or Sys­tem Date using the arrow keys. Enter new values through the keyboard and press

<Enter>. Press the <Tab> key to move between fi elds. The date must be entered in
Day MM/DD/YY format. The time is entered in HH:MM:SS format. (Note: The time
is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00.)

4-2

Chapter 4: AMI BIOS

Supermicro X8DTG-DF

BIOS Build Version: This item displays the BIOS revision used in your sys-

•

tem.

BIOS Build Date: This item displays the date when this BIOS was completed.

•

AMI BIOS Core Version: This item displays the revision number of the AMI BIOS •
Core upon which your BIOS was built.

Processor

The AMI BIOS will automatically display the status of the processor used in your
system:

CPU Type: This item displays the type of CPU used in the motherboard.

•

Speed: This item displays the speed of the CPU detected by the BIOS.•

Physical Count: This item displays the number of processors installed in your •
system as detected by the BIOS.

Logical Count: This item displays the number of CPU Cores installed in your

•

system as detected by the BIOS.

Microcode Revision: This item displays the revision number of the BIOS Micro-

•

code used in your system.

System Memory

This displays the size of memory available in the system:

Size: This item displays the memory size detected by the BIOS.

•

4-3

X8DTG-DF User’s Manual

4-3 Advanced Setup Confi gurations

Use the arrow keys to select the Boot Setup submenu, and hit <Enter> to access
the following items:

Boot Features

Quick Boot

If Enabled, this option will skip certain tests during POST to reduce the time needed
for system boot. The options are Enabled and Disabled.

Quiet Boot

This option allows the bootup screen options to be modifi ed between POST mes-
sages or the OEM logo. Select Disabled to display the POST messages. Select
Enabled to display the OEM logo instead of the normal POST messages. The op­tions are Enabled and Disabled.

AddOn ROM Display Mode

This sets the display mode for the Option ROM. Select Keep Current to use the cur­rent AddOn ROM Display setting. Select Force BIOS to use the Option ROM display
mode set by the system BIOS. The options are Force BIOS and Keep Current.

Bootup Num-Lock

This feature allows the user to select the Power-on state for the Numlock key. The
option s are Of f an d On.

Wait For 'F1' If Error

This for ce s the sys tem to wai t until t he ' F1' key is pressed i f an er ror o cc urs . The
option s are Dis able d and Enabled.

4-4

Chapter 4: AMI BIOS

Hit 'Del' Message Display

This feature displays "Press DEL to run Setup" during POST. The options are

Enabled and Disabled.

Interrupt 19 Capture

Interrupt 19 is the software interrupt that handles the boot disk function. When this
item is set to Enabled, the ROM BIOS of the host adaptors will "capture" Interrupt 19
at bootup and allow the drives that are attached to these host adaptors to function
as bootable disks. If this item is set to Disabled, the ROM BIOS of the host adap­tors will not capture Interrupt 19, and the drives attached to these adaptors will not
function as bootable devices. The options are Enabled and Disabled.

Power Confi guration

Power Button Function

If set to Instant_Off, the system will power off immediately as soon as the user hits
the power button. If set to 4_Second_Override, the system will power off when the
user presses the power button for 4 seconds or longer. The options are Instant_Off
and 4_Second_Override.

Restore on AC Power Loss

Use this feature to set the power state after a power outage. Select Power-Off for
the system power to remain off after a power loss. Select Power-On for the system
power to be turned on after a power loss. Select Last State to allow the system to
resume its last state before a power loss. The options are Power-On, Power-Off
and Last State.

Watch Dog Timer

If enable d, the Watch Do g Timer wil l a l l o w the system to reboot when i t i s i n a ctive
for more t han 5 minu tes. The o ption s are Enabl ed and Disabled.

Processor and Clock Options

This submenu allows the user to confi gure the Processor and Clock settings.

Ratio CMOS Setting

This option allows the user to set the ratio between the CPU Core Clock and the
FSB Frequency. The default setting depends on what type of CPU is installed. For
example, the default setting is [21]. Press "+" or "-" on your keyboard to change
this value.

Note: if an invalid ratio is entered, the AMI BIOS will restore the setting
to the previous state.

4-5

X8DTG-DF User’s Manual

C1E Support

Select Enabled to use the feature of Enhanced Halt State. C1E signifi cantly reduces
the CPU's power consumption by reducing the CPU's clock cycle and voltage during
a Halt State. The options are Disabled and Enabled.

Hardware Prefetcher (Available when supported by the CPU)

If this item is set to Enabled, the hardware prefetcher will pre fetch streams of data
and instructions from the main memory to the L2 cache in the forward or backward
manner to improve CPU performance. The options are Disabled and Enabled.

Adjacent Cache Line Prefetch (Available when supported by the CPU)

The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The
CPU fetches both cache lines for 128 bytes as comprised if Enabled.

Intel® Virtualization Technology (Available when supported by the CPU)

Selec t Enabled to use t he feature of V irtu alizati on Techno logy to allo w one plat­form to run multip le operat i n g sy s tems and app l i cation s i n i n depende nt partitions ,
creating multiple "virtual" systems in one physical computer. The options are

Enabled and Disabled.

Note: If there is any change to this setting, you will need to power off and

restar t the system for the change to take ef fect. Please refer to Intel’s
web site for detailed information.

Execute-Disable Bit Capability (Available when supported by the OS and
the CPU)

Set to Enabled to enable the Execute Disable Bit which will allow the processor
to designate areas in the system memory where an application code can execute
and where it cannot, thus preventing a worm or a virus from fl ooding illegal codes
to overwhelm the processor or damage the system during an attack. The default is

Enabled. (Refer to Intel and Microsoft Web Sites for more information.)

Simultaneous Multi-Threading (Available when supported by the CPU)

Set to Enabled to use the Simultaneous Multi-Threading Technology, which will
result in increased CPU performance. The options are Disabled and Enabled.

Active Processor Cores

Set to Enabled to use a processor's Second Core and beyond. (Please refer to
Intel's web site for more information.) The options are All, 1 and 2.

Intel® EIST Technology

EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically
adjust processor voltage and core frequency in an effort to reduce power consump-

4-6

Chapter 4: AMI BIOS

tion and heat dissipation. Please refer to Intel’s web site for detailed information.
The options are Disable (Disable GV3) and Enable (Enable GV3).

Intel® TurboMode Technology

Select Enabled to allow the processor cores to run faster than normal under special
circumstances to improve performance. The options are Disable and Enabled.

Intel® C-State Tech

If enabled, C-State is set by the system automatically to either C2, C3 or C4 state.
The options are Disabled and Enabled.

C-State package limit setting (Available when Intel® C-State Tech is
enabled)

If set to Auto, the AMI BIOS will automatically set the limit on the C-State package
register. The options are Auto, C1, C3, C6 and C7.

C1 Auto Demotion

When enabled, the CPU will conditionally demote C3, C6 or C7 requests to C1 based
on un-core auto-demote information. The options are Disabled and Enabled.

C3 Auto Demotion

When enabled, the CPU will conditionally demote C6 or C7 requests to C3 based
on un-core auto-demote information. The options are Disabled and Enabled.

Clock Spread Spectrum

Select Enable to use the feature of Clock Spectrum, which will allow the BIOS to
monitor and attempt to reduce the level of Electromagnetic Interference caused by
the components whenever needed. The options are Disabled and Enabled.

Advanced Chipset Control

The items included in the Advanced Settings submenu are listed below:

CPU Bridge Confi guration

QPI Links Speed

This feature selects QPI's data transfer speed. The options are Slow-mode, and

Full Speed.
QPI Frequency

This selects the desired QPI frequency. The options are Auto, 4.800 GT,

5.866GT, 6.400 GT.

4-7

X8DTG-DF User’s Manual

QPI L0s and L1

This enables the QPI power state to low power. L0s and L1 are automatically
selected by the motherboard. The options are Disabled and Enabled.

Memory Frequency

This feature forces a DDR3 frequency slower than what the system has detected
to run at the frequency as specifi ed. The available options are Auto, Force DDR-
800, Force DDR-1066, Force DDR-1333 and Force SPD.

Memory Mode

The options are Independent, Channel Mirror, Lockstep and Sparing.
Independent - All DIMMs are available to the operating system.
Channel Mirror - The motherboard maintains two identical copies of all data in

memory for redundancy.
Lockstep - The motherboard uses two areas of memory to run the same set of

operations in parallel.
Sparing - A preset threshold of correctable errors is used to trigger fail-over.

The spare memory is put online and used as active memory in place of the
failed memory.

Demand Scrubbing

A memory error-correction scheme where the Processor writes corrected data
back into the memory block from where it was read by the Processor. The op­tions are Enabled and Disabled.

Patrol Scrubbing

A memory error-correction scheme that works in the background looking for and
correcting resident errors. The options are Enabled and Disabled.

NUMA Support

Select Enabled to use the feature of Non-Uniform Memory Access to improve
CPU performance. The options are Enabled and Disabled.

Memory ECC Error Threshold

This feature allows the user to set the correctable memory ECC error limit for
AMI BIOS to handle it. The Default setting is 255.

Throttling - Closed Loop/Throttling - Open Loop

Throttling improves reliability and reduces power in the processor by automatic
voltage control during processor idle states. Available options are Disabled and
Enabled. If Enabled, the following items will appear:

4-8

Chapter 4: AMI BIOS

Hysteresis Temperature (Closed Loop Only)

Temperature Hysteresis is the temperature lag (in degrees Celsius) after the
set DIMM temperature threshold is reached before Closed Loop Throttling
begins. The options are Disabled, 1.5oC, 3.0

o

C, and 6.0oC.

Guardband Temperature (Closed Loop Only)

Use this feature to change the DIMM temperature threshold. Each step is

o

in 0.5

C increment. The default is [006].

Inlet Temperature

This is the temperature detected at the chassis inlet. Each step is in 0.5

o

C
increment. The default is [070]. Press "+" or "-" on your keyboard to change
this value.

Temperature Rise

This is the temperature rise to the DIMM thermal zone. Each step is in

o

0.5

C increment. The default is [020]. Press "+" or "-" on your keyboard to

change this value.

Air Flow

This is the air fl ow speed to the DIMM modules. Each step is one mm/
sec. The default is [1500]. Press "+" or "-" on your keyboard to change
this value.

Altitude

This feature defi nes how many meters above or below sea level the system
is located. The options are Sea Level or Below, 1~300, 301~600, 601~900,
901~1200, 1201~1500, 1501~1800, 1801~2100, 2101~2400, 2401~2700,
2701~3000.

DIMM Pitch

This is the physical space between each DIMM module. Each step is in
1/1000 of an inch. The default is [400]. Press "+" or "-" on your keyboard
to change this value.

Serial Debug Message Level

This feature allows the user to set the level of debug message to be displayed.
The default setting is None.

Margin Ranks

This feature allows the user to set the margin for each rank after confi guring
Rx DQ, TX DQ, Rx Vref, and Tx Vref settings. The options are Enabled, and
Disabled.

4-9

X8DTG-DF User’s Manual

North Bridge Confi guration

This feature allows the user to confi gure the settings for the Intel North Bridge
chip.

Crystal Beach/DMA (Direct Memory Access)

This feature works in conjunction with the Intel I/O AT (Acceleration Technology)
to accelerate the performance of TOE devices. (Note: A TOE device is a special­ized, dedicated processor that is installed on an add-on card or a network card to
handle some or all packet processing of this add-on card.) When this feature is set
to Enabled, it will enhance overall system performance by providing direct memory
access for data transferring. The options are Enabled and Disabled.

Coarse-Grained Clock Gating

Coarse Grained Clock Gating (CGCG) a power-saving technique used on an Intel
IO Hub (IOH). When this feature is set to Disabled, all clocks on the die of the IOH
chip will be disabled except for the Intel management engine (Intel ME) subsystem.
Any non ME clocks left running will detect events to restore clock to the whole die.
When this feature is set to Enabled, all clocks on the die will be enabled to maximize
power effi ciency. The options are Enabled and Disabled.

Intel VT-d

Select Enabled to enable Intel's Virtualization Technology support for Direct I/O VT-d
by reporting the I/O device assignments to VMM through the DMAR ACPI Tables.
This feature offers fully-protected I/O resource-sharing across the Intel platforms,
providing the user with greater reliability, security and availability in networking and
data-sharing. The settings are Enabled and Disabled.

IOH PCIE Port1 Link Select

This feature allows the user to confi gure the link setting for PCI-Express Port 1 that
is connected to the Intel IOH chip. The options are x4x4x4x4, x4x4x8, x8x4x4x,
x8x8 and x16.

IOH PCIE Max Payload Size

Some add-on cards perform faster with the coalesce feature, which limits the
payload size to 128 MB; while others, with a payload size of 256 MB by disabling
coalesce support. Please refer to your add-on card user guide for the desired set­ting. The options are 256 MB and 128MB.

South Bridge Confi guration

This feature allows the user to confi gure Intel ICH South Bridge settings.

4-10

Chapter 4: AMI BIOS

USB Functions

This feature allows the user to enable onboard USB support. The Options are:
Disabled and Enabled.

Legacy USB Support

Select Enabled to use Legacy USB devices. Select Auto to automatically enable
Legacy USB support if a legacy USB device is installed, and vise versa. Select
Disabled to disable Legacy USB support. The options are Disabled, Auto, and

Enabled.

USB 2.0 Controller

Select Enabled to activate the onboard USB 2.0 controller. The options are Enabled
and Disabled. (The manufacturer's default setting is Enabled. This setting cannot
be changed by the user.)

USB 2.0 Controller Mode

This setting allows you to select the USB 2.0 Controller mode. The options are

Hi-Speed (480 Mbps) and Full Speed (12 Mbps).

BIOS EHCI Hand-Off

Select Enabled to enable BIOS Enhanced Host Controller Interface support to
provide a workaround solution for an operating system that does not have EHCI
Hand-Off support. When enabled, the EHCI Interface will be changed from the BIOS­controlled to the OS-controlled. The options are Disabled and Enabled.

IDE/SATA/Floppy Confi guration

When this submenu is selected, the AMI BIOS automatically detects the presence
of the IDE devices and displays the following items:

SATA#1 Confi guration

Select Compatible to set SATA#1 to legacy compatibility mode. Select Enhanced
to set SATA#1 to native SATA mode. The options are Disabled, Compatible and
Enhanced.

Confi gure SATA#1 as

This feature allows the user to select the drive type for SATA#1. Select RAID
(Intel) to enable Intel's SATA RAID fi rmware to confi gure Intel's SATA RAID
settings. Select RAID (Adaptec) to enable Adaptec's SATA RAID fi rmware to
confi gure Adaptec's SATA RAID settings. Select AHCI to enable SATA Advanced
Host Interface. (Take caution when using this function. This feature is for ad­vanced programmers only.) The options are IDE, RAID (Intel), RAID (Adaptec)
and AHCI.

4-11

X8DTG-DF User’s Manual

SATA#2 Confi guration

Select Enhanced to set SATA#2 to native SATA mode. The options are Disabled,
and Enhanced.

Primary IDE Master/Slave, Secondary IDE Master/Slave, Third IDE Master,
and Fourth IDE Master

These settings allow the user to set the parameters of the IDE slots as specifi ed.
Hit <Enter> to activate the following submenu items. Set the correct confi gurations
accordingly.

Type

Select the type of device connected to the slot. Select Auto to allow the BIOS
to automatically select the device type as it is detected on the slot. Select CD/
DVD to confi gure the slot for CD/DVD devices. Select ARMD to use this slot for
removable devices. The options are Not Installed, Auto, CD/DVD and ARMD.

LBA/Large Mode

LBA (Logical Block Addressing) is a method of addressing data on a disk drive.
In the LBA mode, the maximum drive capacity is 137 GB. For drive capacities
over 137 GB, your system must be equipped with a 48-bit LBA mode addressing.
If not, contact your manufacturer or install an ATA/133 IDE controller card that
supports 48-bit LBA mode. The options are Disabled and Auto.

Block (Multi-Sector Transfer)

Block Mode boosts the IDE drive performance by increasing the amount of data
transferred. Only 512 bytes of data can be transferred per interrupt if Block Mode
is not used. Block Mode allows transfers of up to 64 KB per interrupt. Select
Disabled to allow data to be transferred from and to the device one sector at
a time. Select Auto to allow data transfer from and to the device occur multiple
sectors at a time if the device supports it. The options are Auto and Disabled.

PIO Mode

The IDE PIO (Programmable I/O) Mode programs timing cycles between the
IDE drive and the programmable IDE controller. As the PIO mode increases, the
cycle time decreases. The options are Auto, 0, 1, 2, 3, and 4.

Select Auto to allow the AMI BIOS to automatically detect the PIO mode. Use
this value if the IDE disk drive support cannot be determined.

Select 0 to allow the AMI BIOS to use PIO mode 0. It has a data transfer rate
of 3.3 MBs.

Select 1 to allow the AMI BIOS to use PIO mode 1. It has a data transfer rate
of 5.2 MBs.

4-12

Chapter 4: AMI BIOS

Select 2 to allow the AMI BIOS to use PIO mode 2. It has a data transfer rate
of 8.3 MBs.

Select 3 to allow the AMI BIOS to use PIO mode 3. It has a data transfer rate
of 11.1 MBs.

Select 4 to allow the AMI BIOS to use PIO mode 4. It has a data transfer band­width of 32-Bits. Select Enabled to enable 32-Bit data transfer.

DMA Mode

Select Auto to allow the BIOS to automatically detect IDE DMA mode when the
IDE disk drive support cannot be determined.

Select SWDMA0 to allow the BIOS to use Single Word DMA mode 0. It has a
data transfer rate of 2.1 MBs.

Select SWDMA1 to allow the BIOS to use Single Word DMA mode 1. It has a
data transfer rate of 4.2 MBs.

Select SWDMA2 to allow the BIOS to use Single Word DMA mode 2. It has a
data transfer rate of 8.3 MBs.

Select MWDMA0 to allow the BIOS to use Multi Word DMA mode 0. It has a
data transfer rate of 4.2 MBs.

Select MWDMA1 to allow the BIOS to use Multi Word DMA mode 1. It has a
data transfer rate of 13.3 MBs.

Select MWDMA2 to allow the BIOS to use Multi-Word DMA mode 2. It has a
data transfer rate of 16.6 MBs.

Select UDMA0 to allow the BIOS to use Ultra DMA mode 0. It has a data transfer
rate of 16.6 MBs. It has the same transfer rate as PIO mode 4 and Multi Word
DMA mode 2.

Select UDMA1 to allow the BIOS to use Ultra DMA mode 1. It has a data transfer
rate of 25 MBs.

Select UDMA2 to allow the BIOS to use Ultra DMA mode 2. It has a data transfer
rate of 33.3 MBs.

Select UDMA3 to allow the BIOS to use Ultra DMA mode 3. It has a data transfer
rate of 66.6 MBs.

Select UDMA4 to allow the BIOS to use Ultra DMA mode 4. It has a data transfer
rate of 100 MBs.

Select UDMA5 to allow the BIOS to use Ultra DMA mode 5. It has a data transfer
rate of 133 MBs.

Select UDMA6 to allow the BIOS to use Ultra DMA mode 6. It has a data transfer
rate of 133 MBs. The options are Auto, SWDMAn, MWDMAn, and UDMAn.

4-13

X8DTG-DF User’s Manual

S.M.A.R.T. For Hard disk drives

Self-Monitoring Analysis and Reporting Technology (SMART) can help predict
impending drive failures. Select Auto to allow the AMI BIOS to automatically de­tect hard disk drive support. Select Disabled to prevent the AMI BIOS from using
the S.M.A.R.T. Select Enabled to allow the AMI BIOS to use the S.M.A.R.T. to
support hard drive disk. The options are Disabled, Enabled, and Auto.

32Bit Data Transfer

Select Enable to enable the function of 32-bit IDE data transfer. The options are

Enabled and Disabled.

IDE Detect Timeout (sec)

Use this feature to set the time-out value for the BIOS to detect the ATA, ATAPI
devices installed in the system. The options are 0 (sec), 5, 10, 15, 20, 25, 30, and

35.

PCI/PnP Confi guration

Clear NVRAM
This feature clears the NVRAM during system boot. The options are No and Yes.

Plug & Play OS

Selecting Yes allows the OS to confi gure Plug & Play devices. (This is not required
for system boot if your system has an OS that supports Plug & Play.) Select No to
allow the AMI BIOS to confi gure all devices in the system.

PCI Latency Timer

This feature sets the latency Timer of each PCI device installed on a PCI bus. Select
64 to set the PCI latency to 64 PCI clock cycles. The options are 32, 64, 96, 128,
160, 192, 224 and 248.

PCI IDE Bus Master

When enabled, the BIOS uses PCI bus mastering for reading/writing to IDE drives.
The options are Disabled and Enabled.

Load Onboard LAN 1 Option ROM/Load Onboard LAN 2 Option ROM

Selec t Enabled to ena ble onboard L AN1/LA N2 Optio n ROMs suppo rt whic h will
allow you to boot your systems using a network interface. The options are Enabled
and Disabled.

4-14

Chapter 4: AMI BIOS

Super IO Device Confi guration

Serial Port1 Address/Serial Port2 Address (-Serial Port2 is used for BMC
Serial Over LAN support. It does not have physical Serial Port2 on the MB.)

This option specifi es the base I/O port address and the Interrupt Request address
of Serial Port 1 and Serial Port 2. Select Disabled to prevent the serial port from
accessing any system resources. When this option is set to Disabled, the serial port
physically becomes unavailable. Select 3F8/IRQ4 to allow the serial port to use 3F8
as its I/O port address and IRQ 4 for the interrupt address. The options for Serial
Port1 are Disabled, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3. The options for Serial Port2
are Disabled, 2F8/IRQ3, 3E8/IRQ4, and 2E8/IRQ3.

Remote Access Confi guration

Remote Access

This allows the user to enable Remote Access support. The options are Disabled
and Enabled. If Remote Access is set to Enabled, the following items will display:

Serial Port Number

This feature allows the user decide which serial port to be used for Console
Redirection. The options are COM 1 and COM2,

Base Address, IRQ

This item displays the base address and IRQ of the serial port used for
Console Redirection.

Serial Port Mode

This feature allows the user to set the serial port mode for Console Redirection.
The options are 115200 8, n 1; 57600 8, n, 1; 38400 8, n, 1; 19200 8, n, 1; and
9600 8, n, 1.

Flow Control

This feature allows the user to set the fl ow control for Console Redirection. The
options are None, Hardware, and Software.

Redirection After BIOS POST

Select Disabled to turn off Console Redirection after Power-On Self-Test
(POST). Select A lways to keep Console Redirection ac tive all the time af ter
POST. (Note: This settin g may not be sup por ted by so me oper ating sys tems.)
Select Boot Loader to keep Console Redirection active during POST and Boot
Loader. The opti ons are D isabl ed, Boot L oader, and Always.

4-15

X8DTG-DF User’s Manual

Terminal Type

This feature allows the user to select the target terminal type for Console Redi­rection. The options are ANSI, VT100, and VT-UTF8.

VT-UTF8 Combo Key Support

Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100
terminals. The ptions are Enabled and Disabled.

Sredir Memory Display Delay

This feature defi nes the length of time in seconds to display memory information.
The options are No Delay, Delay 1 Sec, Delay 2 Sec, and Delay 4 Sec.

Hardware Health Confi guration

This feature allows the user to monitor system health and review the status of each
item as displayed.

CPU Overheat Alarm

This option allows the user to select the CPU Overheat Alarm setting which de­termines when the CPU OH alarm will be activated to provide warning of possible
CPU overheat.

Warning!

1. Any temperature that exceeds the CPU threshold temperature pre-

defi ned by the CPU manufacturer may result in CPU overheat or system
instability. When the CPU temperature reaches this predefi ned threshold,
the CPU and system cooling fans will run at full speed.

2. To avoid possible system overheating, please be sure to provide ad­equate airfl ow to your system.

The options are:

The Early Alarm: Select this setting if you want the CPU overheat alarm (includ-

•

ing the LED and the buzzer) to be triggered as soon as the CPU temperature
reaches the CPU overheat threshold as predefi ned by the CPU manufacturer.

The Default Alarm

• : Select this setting if you want the CPU overheat alarm

(including the LED and the buzzer) to be triggered when the CPU temperature
reaches about 5
manufacturer to give the CPU and system fans additional time needed for CPU
and system cooling. In both the alarms above, please take immediate action
as shown below.

o

C above the threshold temperature as predefi ned by the CPU

4-16

Chapter 4: AMI BIOS

CPU Temperature/System Temperature

This feature displays current temperature readings for the CPU and the System.
The following items will be displayed for your reference only:

CPU 1 Temperature/CPU 2 Temperature

The CPU thermal technology that reports absolute temperatures (Celsius/Fahr­enheit) has been upgraded to a more advanced feature by Intel in its newer
processors. The basic concept is each CPU is embedded by unique temperature
information that the motherboard can read. This ‘Temperature Threshold’ or ‘Tem­perature Tolerance’ has been assigned at the factory and is the baseline on which
the motherboard takes action during different CPU temperature conditions (i.e., by
increasing CPU Fan speed, triggering the Overheat Alarm, etc). Since CPUs can
have different ‘Temperature Tolerances’, the installed CPU can now send informa­tion to the motherboard what its ‘Temperature Tolerance’ is, and not the other way
around. This results in better CPU thermal management.

Supermicro has leveraged this feature by assigning a temperature status to certain
thermal conditions in the processor (Low, Medium and High). This makes it easier
for the user to understand the CPU’s temperature status, rather than by just simply
seeing a temperature reading (i.e., 25

o

C). The CPU Temperature feature will display

the CPU temperature status as detected by the BIOS:
Low – This level is considered as the ‘normal’ operating state. The CPU temperature

is well below the CPU ‘Temperature Tolerance’. The motherboard fans and CPU will
run normally as confi gured in the BIOS (Fan Speed Control).

User intervention: No action required.
Medium – The processor is running warmer. This is a ‘precautionary’ level and

generally means that there may be factors contributing to this condition, but the CPU
is still within its normal operating state and below the CPU ‘Temperature Tolerance’.
The motherboard fans and CPU will run normally as confi gured in the BIOS. The
fans may adjust to a faster speed depending on the Fan Speed Control settings.

User intervention: No action is required. However, consider checking the CPU fans
and the chassis ventilation for blockage.

High – The processor is running hot. This is a ‘caution’ level since the CPU’s ‘Tem­perature Tolerance’ has been reached (or has been exceeded) and may activate
an overheat alarm.

User intervention: If the system buzzer and Overheat LED has activated, take action
immediately by checking the system fans, chassis ventilation and room temperature
to correct any problems.

Notes: 1. The system may shut down if it continues for a long period to
prevent damage to the CPU.

4-17

X8DTG-DF User’s Manual

2. The information provided above is for your reference only. For more
information on thermal management, please refer to Intel’s Web site at
www.Intel.com.

System Temperature: The system te mperat ure will b e displayed ( in degre es in
Celsiu s and Fahrenh eit) as it is detec ted by the BI OS.

Fan1 ~ Fan 8 Reading

This feature displays the fan speed readings from Fan1 through Fan8. (Fan7 is
CPU1 Fan and Fan8 is CPU2 Fan.)

System Fan Monitor

This feature allows the user to decide how the system controls the speeds of the
onboard fans. The CPU temperature and the fan speed are correlative. When
the CPU on-die temperature increases, the fan speed will also increase, and vice
versa. Select Workstation if your system is used as a Workstation. Select Server if
your system is used as a Server. Select “Disabled, (Full Speed @12V)” to disable
the fan speed control function and allow the onboard fans to constantly run at the
full speed (12V). The Options are: 1. Disabled (running @full-speed), 2. Server
Mode, and 3. Workstation Mode.

Voltage Monitoring

CPU1 Vcore, CPU2 Vcore, +5Vin, 12Vcc (V), V P1 DIMM, V P2 DIMM, 3.3V Vcc
(V) and Battery Voltage.

ACPI Confi guration

Use this feature to confi gure Advanced Confi guration and Power Interface (ACPI)
power management settings for your system.

ACPI Version Features

The options are ACPI v1.0, ACPI v2.0 and ACPI v3.0. Please refer to ACPI's website
for further explanation: http://www.acpi.info/.

ACPI APIC Support

Select Enabled to include the ACPI APIC Table Pointer in the RSDT (Root System
Description Table) pointer list. The options are Enabled and Disabled.

APIC ACPI SCI IRQ

When this item is set to Enabled, APIC ACPI SCI IRQ is supported by the system.
The options are Enabled and Disabled.

4-18

Chapter 4: AMI BIOS

Headless Mode

This feature is used to enable system to function without a keyboard, monitor or
mouse attached The options are Enabled and Disabled.

High Performance Event Timer

Select Enabled to activate the High Performance Event Timer (HPET) that produces
periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in
synchronizing multimedia streams, providing smooth playback and reducing the de­pendency on other timestamp calculation devices, such as an x86 RDTSC Instruc­tion embedded in the CPU. The High Performance Event Timer is used to replace
the 8254 Programmable Interval Timer. The options are Enabled and Disabled.

General WHEA Confi guration

WHEA Support

Select Enabled to enable Windows Hardware Error Architecture (WHEA) sup­port which will provide a common infrastructure for handling hardware errors on
Windows platforms in order to reduce system crashes due to hardware errors
and to improve system recovery and health monitoring. The default setting is

Enabled.

IPMI Confi guration

Intelligent Platform Management Interface (IPMI) is a set of common interfaces that
are used for hardware health monitoring and system management. For more infor­mation on the IPMI specifi cations, please visit Intel's web site at www.intel.com.

Status of BMC

Baseboard Management Controller (BMC) manages the interface between system
management software and platform hardware. This is an informational feature which
returns the status code of the BMC micro controller.

IPMI Firmware Revision

This item displays the IPMI fi rmware revision used in your system.

View BMC System Event Log

This feat ur e d i sp l ays t h e BMC Sys te m Event Lo g (SE L). It shows the total number
of entries of BMC System Events.

To view an event, select an Entry Number and pressing <Enter> to display the
information as shown in the screen.

SEL Entry Number

•

4-19

X8DTG-DF User’s Manual

SEL Record ID•

SEL Record Type•

Event•

Timestamp•

Generator ID•

Event Message Format Ver•

Event Sensor Type•

Event Sensor Number,•

Event Dir Type•

Event Data.•

Clear BMC System Event Log

Clear BMC System Log

Select OK and press the <Enter> key to clear the BMC system log. Select Cancel
to keep the BMC System log. The options are OK and Cancel.

Caution: Any cleared information is unrecoverable. Make absolutely sure
that you no longer need any data stored in the log before clearing the
BMC Event Log.

Set LAN Confi guration

Set this feature to confi gure the IPMI LAN adapter with a network address as shown
in the following graphics.

Channel Number
Enter the channel number for the SET LAN Confi g command. Channel Number

Status
This feature returns the channel status for the Channel Number selected above:

"Channel Number is OK" or "Wrong Channel Number".

4-20

Chapter 4: AMI BIOS

IP Address Confi guration

Parameter Selector

This item displays the parameter of your IP Address confi guration.

IP Address Source

Select the source of this machine's IP address. If Static is selected, you will need
to know and enter manually the IP address of this machine below. If DHCP is
selected, the BIOS will search for a DHCP (Dynamic Host Confi guration Protocol)
server in the network it is attached to, and request the next available IP address.
The options are DHCP and Static.

IP Address

This item displays the IP address for the IPMI connection detected.

Current IP Address in BMC

This item displays the current IP address used for your IPMI connection.

MAC Address Confi guration

This submenu displays the following MAC Address Confi guration information.

Parameter Selector

Use this feature to select the parameter of your Mac Address confi guration.

MAC Address

This item displays the MAC address of this computer used for your IPMI con­nection.

Current MAC Address in BMC

This item displays the current MAC address used for your IPMI connection.

Subnet Mask Confi guration

Subnet masks tell the network which subnet this machine belongs to. The value
of each three-digit number separated by dots should not exceed 255.

Parameter Selector

Use this feature to select the parameter of your Subnet Masks confi guration.

Subnet Mask

This item displays the current subnet mask setting for your IPMI connection.

4-21

X8DTG-DF User’s Manual

Current Subnet Mask in BMC

This item displays the current subnet mask setting for your IPMI connection.

Gateway Address Confi guration

Enter the gateway address for this machine. This should be in decimal and in
dotted quad form (i.e., 192.168.10.253). The value of each three-digit number
separated by dots should not exceed 255 as shown in the screen below.

Parameter Selector

Use this feature to select the parameter of your Gateway Address settings.

Gateway Address

The BIOS will automatically enter the Gateway address of this machine; however
it may be over-ridden. Gateway addresses are 6 two-digit hexadecimal numbers
separated by dots.

Current Gateway Address in BMC

This item displays the current Gateway address used for your IPMI connec­tion.

DMI Event Log

View Event Log

Use this option to view the System Event Log.

Mark all events as read

This option marks all events as read. The options are OK and Cancel.

Clear event log

This option clears the Event Log memory of all messages. The options are OK
and Cancel.

4-4 Security Settings

The AMI BIOS provides a Supervisor and a User password. If you use both pass­words, the Supervisor password must be set fi rst.

4-22

Supervisor Password

Chapter 4: AMI BIOS

This item indicates if a Supervisor password has been entered for the system. "Not
Installed" means a Supervisor password has not been used.

User Password

This item indicates if a user password has been entered for the system. "Not I n­stalle d" means that a u ser password has not been used.

Change Supervisor Password

Select this feature and press <Enter> to access the submenu, and then enter a
new Supervisor Password.

User Access Level (Available when Supervisor Password is set as above)
Use this feature to set the user's access level. Select Full Access to grant the

user full read and write access to the Setup Utility. Select View Only to allow the
user to view the Setup Utility displays without making any changes. Select Limited
to allow the user to make changes on limited items such as Date and Time, Select
No Access to prevent the user from entering the Setup Utility.

Change User Password

Select this feature and press <Enter> to enter a new User Password.

Clear User Password (Available only if User Password has been set)
This item allows you to clear a user password after it has been entered.

Password Check

This item allows you to check a password after it has been entered. The options
are Setup and Always.

4-23

X8DTG-DF User’s Manual

Boot Sector Virus Protection

When Enabled, the AMI BIOS displays a warning when any program (or virus) is­sues a Disk Format command or attempts to write to the boot sector of the hard
disk drive. The options are Enabled and Disabled.

4-5 Boot Confi guration

Use this feature to confi gure boot priority settings.

Boot Device Priority

Use this feature to specify the sequence of boot priority for onboard devices. The
settings are 1st boot device~5th boot device and Disabled.

1st Boot Device - 1st Floppy Drive/2nd Boot Device - [USB: XXXXXXXXX]

Hard Disk Drives

Use this feature to specify the boot sequence from all bootable HDD devices. The
settings are Disabled and a list of all hard disk drives that have been detected (i.e.,
1st Drive, 2nd Drive, etc).

Removable Drives

Use this feature to specify the boot sequence from available Removable Drives.
The settings are 1st boot device, 2nd boot device, and Disabled.

CD/DVD Drives

This feature allows the user to specify the boot sequence from available CD/DVD
Drives (i.e., 1st Drive, 2nd Drive, etc).

4-24

Chapter 4: AMI BIOS

4-6 Exit Options

Select the Exit tab from the AMI BIOS Setup Utility screen to enter the Exit BIOS
Setup screen.

Save Changes and Exit

When you have completed the system confi guration changes, select this option
to leave the BIOS Setup Utility and reboot the computer, so the new system con­fi guration parameters can take effect. Select Save Changes and Exit from the Exit
menu and press <Enter>.

Discard Changes and Exit

Select this option to quit the BIOS Setup without making any permanent changes
to the system confi guration, and reboot the computer. Select Discard Changes and
Exit from the Exit menu and press <Enter>.

Discard Changes

Select this option and press <Enter> to discard all the changes and return to the
AMI BIOS Utility Program.

Load Optimal Defaults

To set this feature, select Load Optimal Defaults from the Exit menu and press
<Enter>. Then, select OK to allow the AMI BIOS to automatically load Optimal De­faults to the BIOS Settings. The Optimal settings are designed for maximum system
performance, but may not work best for all computer applications.

Load Fail-Safe Defaults

To set this feature, select Load Fail-Safe Defaults from the Exit menu and press
<Enter>. The Fail-Safe settings are designed for maximum system stability, but not
for maximum performance.

4-25

X8DTG-DF User’s Manual

4-7 BIOS Recovery

Warning! Do not upgrade the BIOS unless your system has a BIOS-related

issue. Flashing the wrong BIOS can cause irreparable damage to the
system. In no event shall Supermicro be liable for direct, indirect, special,
incidental, or consequential damages arising from a BIOS update. If you
need to update the BIOS, do not shut down or reset the system while the
BIOS is updating. This is to avoid possible boot failure.

How to Recover the AMIBIOS Image (-the Main BIOS
Block)

An AMIBIOS fl ash chip consists of a boot sector block, and a main BIOS code block
(a main BIOS image). The boot sector block contains critical BIOS code, including
memory detection and recovery code to be used to fl ash a new BIOS image if the
original BIOS Image is corrupted. When the system is powered on, the boot sector
code executes fi rst. Once it is completed, the main BIOS code will continue with
system initialization and complete the bootup process.

Notes: BIOS Recovery described below is used when the main BIOS
block crashes. However, when the BIOS Boot sector crashes, you will need
to send the motherboard back to Supermicro for RMA repairs.

4.7.1 Boot Sector Recovery from a USB Device

This feature allows the user to recover a BIOS image using a USB device without
additional utilities needed. A user can download the BIOS image into a USB fl ash
device, and name the fi le "SUPER.ROM" for the recovery process to load the fi le.
A USB fl ash device such as a USB Flash Drive, a USB CDROM or a USB CDRW
device can be used for this purpose,

Insert the USB device that contains the new BIOS image (the ROM fi les) 1.
saved in a root directory into your USB drive.

While turning the power on, press and hold <Ctrl> and <Home> at the same 2.
time until the USB Access LED Indicator comes on. This might take a few
seconds.

Once the USB drive LED is on, release the <Ctrl> and <Home> keys. 3.
AMIBIOS will issue beep codes to indicate that the BIOS ROM fi le is being
updated.

When BIOS fl ashing is completed, the computer will reboot. Do not interrupt 4.
the fl ashing process until it is completed.

4-26

Chapter 4: AMI BIOS

4.7.2 Boot Sector Recovery from an IDE CD-ROM

This process is almost identical to the process of Boot Sector Recovery from a USB
device, except that the BIOS image fi le is loaded from a CD-ROM. Use a CD-R or
CD-RW drive to burn a CD with the BIOS image fi le in it, and name the fi le "SUPER.
ROM" for the recovery process to load the fi le.

4.7.3 Boot Sector Recovery from a Serial Port ("Serial
Flash")

This process, also known as "Serial Flash," allows the user to use a serial port to
load a BIOS image for Boot Sector recovery . This feature is usually used for embed­ded systems that rely on a serial port for remote access and debugging.

Requirements

In order to use Serial Flash for Boot Sector Recovery, you will need to meet the
following requirements.

The "Target system," the system that needs BIOS updates, must have a serial

•

port and "Serial Flash" support embedded in the BIOS image fi le.
The "Host system" should also have a serial port and a terminal program that

•

supports XModem Transfer protocol (Hyper Terminal for the Windows operating
systems, and minicom for Linux/FreeSBD, etc.).

A Null_modem serial cable

•

How to use Serial Flash for Boot Sector Recovery

Connect a Null_modem serial cable between the target system and the host 1.
system that runs the terminal program.

Make sure that the new BIOS Image fi le is accessible for the host system.2.

Start the terminal program on the host system and create a new connection. 3.
Use the following communication parameters for the new connection.

Bits per second: 115200 bits/sec.

•

Data Bits: 8•
Parity: None•
Stop Bit: 1•
Flow Control: None•

4-27

X8DTG-DF User’s Manual

4. Power on your system and click the <Connect> button in the Hyper Terminal.
The terminal screen will display the following messages.

Press <SpaceBar> to update BIOS.
Confirm update BIOS? (y/n) y
Begin remote BIOS flash? (y/n) y
Starting remote flash.
Upload new BIOS file using Xmodem protocol.

5. Following the instructions given on the screen to update the BIOS. These
instructions are also shown below.

a. At the prompt, press the <SpaceBar> to update the BIOS.
b. When asked to confi rm BIOS updating, press <y> to confi rm BIOS

updates.

c. Press <y> again to begin fl ashing BIOS remotely.

Note: Be sure to complete Steps a~c above quickly because
you have a second or less to do so.

6. Once you've completed the instructions given, a screen will display to indicate
that remote fl ashing is starting and the new BIOS fi le is being uploaded.

7. To use Hyper Terminal to transfer the XModem protocol by using the "Send
File" dialog under the "Transfer" menu, follow the instructions below to com­plete XModem transfers.

a. Select the "Transfer" menu and enter <Send>.

b. Specify the location of the ROM fi le and select the proper protocol (XMo-

dem).

c. Press <Send> to start ROM File extraction. (See the picture below.)

4-28

Chapter 4: AMI BIOS

d. Once the ROM fi le extraction is completed, the message: "New BIOS re-

ceived OK" will display.

8. Once remote BIOS fl ash is completed, the system will reboot.

Note: AMIBIOS Serial Flash will work with any terminal communications
program that supports VT-100 and XModem protocols, including protocols
designed for GNU/LINUX & BSD operating systems such as minicom. It
is recommended that the terminal program be confi gured to use the 'CR/
LF' style of line termination.

4-29

X8DTG-DF User’s Manual

Notes

4-30

Appendix A: BIOS POST Error Codes

Appendix A

BIOS Error Beep Codes

During the POST (Power-On Self-Test) routines, which are performed each time
the system is powered on, errors may occur.

Non-fatal errors are those which, in most cases, allow the system to continue the
boot-up process. The error messages normally appear on the screen.

Fatal errors are those which will not allow the system to continue the boot-up
procedure. If a fatal error occurs, you should consult with your system manufac­turer for possible repairs.

A-1 BIOS Error Beep Codes

BIOS Error Beep Codes

Beep Code Error Message Description

1 beep Refresh Circuits have been reset.

(Ready to power up)

5 short beeps + 1 long
beep

8 beeps Display memory

1 continuous beep
(with the front panel
OH LED on)

Memory error No memory detected in the

system
Video adapter missing or with

read/write error
System Overheat 1 continuous beep with the

faulty memory

front panel OH LED on

A-1

X8DTG-DF User's Manual

Notes

A-2

Appendix B: Installing the Windows OS

Appendix B

Installing the Windows OS

After all hardware components have been installed, you must fi rst confi gure Intel
South Bridge RAID Settings before you install the Windows OS and other software
drivers. T o confi gure RAID settings, please refer to RAID Confi guration User Guides
posted on our web site at www.supermicro.com/support/manuals.

Note: The following OS installation instructions are written for the Windows
XP/2003 OS only. If you have the Windows 2008 or Windows Vista OS,
please follow the instructions displayed on your screen to install the OS.

B-1 Installing the Windows OS for a RAID System

Insert Microsoft's Windows XP/Windows 2003 Setup CD in the CD Drive, and 1.
the system will start booting up from CD.

Press the <F6> key when the message-" Press F6 if you need to install a 2.
third party SCSI or RAID driver" displays.

When the Windows XP/Windows 2003 Setup screen appears, press "S" to 3.
specify additional device(s).

Insert the driver diskette-"Intel AA RAID XP/2003 Driver for ICH10R" into 4.
Drive A: and press the <Enter> key.

Choose the Intel(R) ICH10R 5. SATA RAID Controller from the list indicated in
the XP/2003 Setup Screen, and press the <Enter> key.

Press the <Enter> key to continue the installation process. (If you need to 6.
specify any additional devices to be installed, do it at this time.) Once all
devices are specifi ed, press the <Enter> key to continue with the installation.

From the Windows XP/Windows 2003 Setup screen, press the <Enter> key. 7.
The XP/2003 Setup will automatically load all device fi les and then, continue
the Windows XP/Windows 2003 installation.

After the Windows XP/Windows 2003 OS Installation is completed, the sys-8.
tem will automatically reboot.

B-1

X8DTG-DF User's Manual

B-2 Installing the Windows OS for a Non-RAID System

Insert Microsoft's Windows OS Setup CD in the CD Driver, and the system 1.
will start booting up from CD.

Continue with the OS installation. The Windows OS Setup screen will display.2.

From the Windows OS Setup screen, press the <Enter> key. The OS Setup 3.
will automatically load all device fi les and then continue with the Windows OS
installation.

After the Windows OS Installation is completed, the system will automatically 4.
reboot.

Insert the Supermicro Setup CD that came with your motherboard into the CD 5.
Drive during system boot, and the main screen will display.

B-2

Appendix C: Software Installation Instructions

Appendix C

Software Installation Instructions

C-1 Installing Software Programs

After you have installed the Windows Operating System, a screen as shown below
will appear. You are ready to install software programs and drivers that have not
yet been installed. To install these software programs and drivers, click the icons
to the right of these items.

Driver/Tool Installation Display Screen

Notes:

1. Click the icons showing a hand writing on the paper to view the readme
fi les for each item. Click on a computer icon to the right of an item to
install an item (from top to the bottom) one at a time. After installing each
item, you must reboot the system before proceeding with the next item
on the list. The bottom icon with a CD on it allows you to view the entire
contents of the CD.

2. When making a storage driver diskette from booting into a Driver CD,
please set the SATA Confi guration to "Compatible Mode" and confi gure
SATA as IDE in the BIOS Setup. After making the driver diskette, be sure
to change the SATA settings back to your original settings.

C-1

X8DTG-DF User's Manual

C-2 Confi guring Supero Doctor III

The Supero Doctor III program is a Web-base management tool that supports
remote management capability. It includes Remote and Local Management tools.
The local management is called the SD III Client. The Supero Doctor III program
included on the CDROM that came with your motherboard allows you to monitor
the environment and operations of your system. Supero Doctor III displays crucial
system information such as CPU temperature, system voltages and fan status. See
the Figure below for a display of the Supero Doctor III interface.

Note: 1 The default user name and password are ADMIN.
Note 2: In the Windows OS environment, the Supero Doctor III settings

take precedence over the BIOS settings. When fi rst installed, Supero Doc-
tor III adopts the temperature threshold settings previously set in BIOS. Any
subsequent changes to these thresholds must be made within Supero Doc­tor, since the SD III settings override the BIOS settings. For the Windows
OS to adopt the BIOS temperature threshold settings, please change the
SDIII settings to be the same as those set in BIOS.

Supero Doctor III Interface Display Screen-I (Health Information)

C-2

Appendix C: Software Installation Instructions

Supero Doctor III Interface Display Screen-II (Remote Control)

Note: SD III Software Revision 1.0 can be downloaded from our Web

site at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also
download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/
Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you
use Supero Doctor II.

C-3

X8DTG-DF User's Manual

Notes

C-4

(Disclaimer Continued)

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices,
aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in signifi cant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products for use in such ultra-hazardous applications, it does so
entirely at its own risk. Furthermore, buyer agrees to fully indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
