SUPER MICRO Computer X7DWE User Manual

®

SUPER

X7DWE

USER’S MANUAL

Revision 1.0

The information in this User’s Manual has been carefully reviewed and is believed to be accurate.
The vendor assumes no responsibility for any inaccuracies that may be contained in this document,
makes no commitment to update or to keep current the information in this manual, or to notify any
person or organization of the updates. Please Note: For the most up-to-date version of this

manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product
described in this manual at any time and without notice. This product, including software, if any,
and documentation may not, in whole or in part, be copied, photocopied, reproduced, translated or
reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO
USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY
HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE
COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH
HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa
Clara County in the State of California, USA. The State of California, County of Santa Clara shall be
the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims
will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class
A digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your
own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate
warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate
Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used in this
product may expose you to lead, a chemical known to
the State of California to cause birth defects and other
reproductive harm.

Manual Revision 1.0
Release Date: April 9, 2008

Unless you request and receive written permission from Super Micro Computer, Inc., you may not
copy any part of this document.

Information in this document is subject to change without notice. Other products and companies
referred to herein are trademarks or registered trademarks of their respective companies or mark
holders.

Copyright © 2008 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

About This Manual

This manual is written for system integrators, PC technicians and knowledgeable

PC users. It provides information for the installation and use of the

motherboard. The

Xeon™ 5400/5300/5200/5100 Series processors with a front side bus speed of up to

1.6 GHz. With two 64-bit Quad-Core and Dual-Core processors built-in, the X7DWE

offers substantial functionality enhancements to the motherboards based on the Intel

Core Microarchitecture core while remaining compatible with the IA-32 software. The

features include Intel Virtualization Technology, Enhanced Intel SpeedStep technol-

ogy, Advanced Dynamic Execution, Advanced Transfer Cache, and Streaming SIMD

Extensions 4.1 (SSE4.1). These features allow the motherboard to operate at much

higher speeds with better power management in much safer thermal environments

than the traditional motherboards. The X7DWE is ideal for high performance quad-

processor or dual-processor (DP) workstation and enterprise server environments.

Please refer to our website (http://www.supermicro.com/products/) for updates on

supported processors. This product is intended to be professionally installed.

X7DWE supports dual Intel® Quad-Core and Dual-Core

Preface

X7DWE

Manual Organization

Chapter 1 describes the features, specifi cations and performance of the mother-

board and provides detailed information about the chipset.

Chapter 2 provides hardware installation instructions. Read this chapter when

installing the processor, memory modules and other hardware components into

the system. If you encounter any problems, see Chapter 3, which describes

troubleshooting procedures for the video, the memory and the system setup stored

in the CMOS.

Chapter 4 includes an introduction to BIOS and provides detailed information on

running the CMOS Setup utility.

Appendix A lists POST Error Beep Codes. Appendix B and Appendix C list

Windows OS and Other Software Installation Instructions.

Conventions Used in the Manual

Special attention should be given to the following symbols for proper installation and

to prevent damage done to the components or injury to yourself:

Danger/Caution: Instructions to be strictly followed to prevent catastrophic

system failure or to avoid bodily injury.

iii

X7DWE User's Manual

Warning: Important information given to ensure proper system installation

or to prevent damage to the components.

Note: Additional Information given to differentiate various models or to

ensure correct system setup.

iv

Notes

Preface

v

X7DWE User's Manual

Table of Contents

Preface

About This Manual ...................................................................................................... iii

Manual Organization ................................................................................................... iii

Conventions Used in the Manual .................................................................................. iii

Chapter 1: Introduction

1-1 Overview ............................................................................................................. 1-1

Checklist ................................................................................................... 1-1

1-2 Contacting Supermicro ....................................................................................... 1-2

X7DWE Image ........................................................................... 1-3

X7DWE Layout .......................................................................... 1-4

Quick Reference ...................................................................................... 1-5

Motherboard Features ................................................................................ 1-6

Intel 5400 Chipset: System Block Diagram ............................................. 1-8

1-3 Chipset Overview ............................................................................................... 1-9

1-4 Special Features .............................................................................................. 1-10

1-5 PC Health Monitoring ....................................................................................... 1-10

1-6 ACPI Features ................................................................................................. 1-11

1-7 Power Supply ................................................................................................... 1-12

1-8 Super I/O ............................................................................................................ 1-13

Chapter 2: Installation

2-1 Static-Sensitive Devices .................................................................................... 2-1

Precautions ................................................................................................ 2-1

Unpacking ................................................................................................ 2-1

2-2 Processor and Heatsink Installation .................................................................. 2-2

2-3 Installing DIMMs ................................................................................................ 2-6

2-4 Control Panel Connectors and IO Ports ............................................................ 2-8

1. Back Panel Connectors/IO Ports .............................................................. 2-8

2. Front Control Panel ................................................................................... 2-9

3. Front Control Panel Pin Defi nitions ......................................................... 2-10

NMI Button ............................................................................................. 2-10

Power LED ............................................................................................. 2-10

HDD LED .............................................................................................. 2-11

NIC1/NIC2 LED ..................................................................................... 2-11

Overheat/Fan Fail LED ......................................................................... 2-12

Power Fail LED ........................................................................................ 2-12

vi

Table of Contents

Reset Button ......................................................................................... 2-13

Power Button .......................................................................................... 2-13

2-5 Connecting Cables .......................................................................................... 2-14

ATX Power Connector .......................................................................... 2-14

Processor Power Connector ................................................................. 2-14

Universal Serial Bus (USB0/1) ................................................................ 2-15

Chassis Intrusion .................................................................................... 2-15

Fan Headers .......................................................................................... 2-16

Keylock ..................................................................................................... 2-16

ATX PS/2 Keyboard and Mouse Ports ..................................................... 2-17

Serial Ports ............................................................................................. 2-17

Wake-On-Ring .......................................................................................... 2-18

Wake-On-LAN .......................................................................................... 2-18

Speaker/Power LED/Keylock Header .................................................... 2-18

GLAN (Ethernet Ports) ............................................................................. 2-19

T-SGPIO Headers .................................................................................... 2-19

SMB Connector ........................................................................................ 2-20

Power SMB Connector ............................................................................. 2-20

2-6 Jumper Settings ............................................................................................... 2-21

Explanation of Jumpers ......................................................................... 2-21

GLAN Enable/Disable ............................................................................ 2-21

Clear CMOS ............................................................................................. 2-22

Watch Dog ................................................................................................ 2-22

VGA Enabled/Disabled ............................................................................. 2-23

2

I

C Bus to PCI-X/PCI-Exp. Slots Enable/Disable ..................................... 2-23

2-7 Onboard Indicators .......................................................................................... 2-24

GLAN LEDs .............................................................................................. 2-24

Onboard Power LED ................................................................................ 2-24

CPU1 VRM OH LED/CPU2 VRM OH LED .............................................. 2-25

2-8 Floppy, SIMLP, Serial ATA and Hard Disk Drive Connections ....................... 2-26

Floppy Connector .................................................................................... 2-26

Serial ATA Ports ....................................................................................... 2-27

SIMLP IPMI Slot ...................................................................................... 2-27

IDE Connectors ....................................................................................... 2-28

Chapter 3: Troubleshooting

3-1 Troubleshooting Procedures .............................................................................. 3-1

Before Power On ....................................................................................... 3-1

No Power ................................................................................................... 3-1

vii

X7DWE User's Manual

No Video .................................................................................................. 3-2

Losing the System’s Setup Confi guration ................................................ 3-2

Memory Errors ........................................................................................... 3-2

3-2 Technical Support Procedures ........................................................................... 3-3

3-3 Frequently Asked Questions .............................................................................. 3-3

3-4 Returning Merchandise for Service .................................................................... 3-4

Chapter 4: BIOS

4-1 Introduction .......................................................................................................... 4-1

4-2 Running Setup .................................................................................................... 4-2

4-3 Main BIOS Setup ................................................................................................ 4-2

4-4 Advanced Setup ................................................................................................... 4-7

4-5 Security Setup .................................................................................................. 4-23

4-6 Boot Setup ......................................................................................................... 4-25

4-7 Exit ..................................................................................................................... 4-26

Appendices

Appendix A: POST Error Beep Codes ....................................................................... A-1

Appendix B: Installing the Windows OS .................................................................... B-1

Appendix C: Installing Other Software and Drivers ...................................................C-1

viii

Chapter 1: Introduction

Chapter 1

Introduction

1-1 Overview

Checklist

Congratulations on purchasing your computer motherboard from an acknowledged

leader in the industry. Supermicro boards are designed with the utmost attention to

detail to provide you with the highest standards in quality and performance. Check

that the following items have all been included with your motherboard. If anything

listed here is damaged or missing, contact your retailer.

The following items are included in the retail box.

One (1) Supermicro Mainboard

•

One (1) ribbon cable for IDE devices (CBL-0036L-03)

•

One (1) fl oppy ribbon cable (CBL-0022L)

•

Six (6) Serial ATA cables (CBL-0044Lx6)

•

One (1) I/O backpanel shield (CSE-PT07L)

•

One (1) Supermicro CD containing drivers and utilities

•

One (1) User's/BIOS Manual (MNL#0999)

•

1-1

X7DWE User's Manual

1-2 Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Website: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Asia-Pacifi c

Address: Super Micro Computer, Inc.

4F, No. 232-1, Liancheng Rd.

Chung-Ho 235, Taipei County

Taiwan, R.O.C.

Tel: [phone]

Fax: [phone]

Website: www.supermicro.com.tw

Technical Support:

Email: [e-mail]

Tel: [phone], ext.132 or 139

1-2

X7DWE Image

Chapter 1: Introduction

Note: The drawings and pictures shown in this manual were based on the

latest PCB Revision available at the time of publishing of the manual. The

motherboard you’ve received may or may not look exactly the same as

the graphics shown in the manual.

1-3

X7DWE User's Manual

X7DWE Motherboard Layout

COM1

VGA

JLAN1

JLAN2

X7DWE

JPL1

JPL2

FAN5

FAN6

KB/MS

USB0/1

JP2

VGA

CTRL

LAN

CTRL

Super I/O

JPW3

8-Pin PWR

JPG1

JPW1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C3

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C1
JI2C2

Slot1 PCI-X 133MHz

J18

J17

SMB

PWR

Intel 5400

North Bridge

Intel ESB2

South Bridge

SPKR

LE1

JD1

JPT1

FAN1

JWOL1

BANK2

BANK1

I-SATA5

I-SATA4

J7

JP1

BIOS

J8

USB4/5

USB2/3

JBT

I-SATA3

I-SATA2

CPU1

CPU2

LED5

USB6

I-SATA1

I-SATA0

FAN2

FAN3

T-SGPIO1

T-SGPIO2

J22

JL1

JOH1

LED6

JF1

FLOPPY

FAN4

FP CTRL

IDE#1

Notes:

Jumpers not indicated are for test purposes only.

1.

See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front

2.

panel connections.

" " indicates the location of Pin 1.

3.

When LE1 LED is on, the onboard power connection is on. Make sure to

4.

unplug the power cables before removing or installing components.

1-4

Chapter 1: Introduction

X7DWE Quick Reference

Jumper Description Default Setting

JBT1 CMOS Clear (See Section 5-10)

2

JI

C1/JI2C2 SMB to PCI Slots Open (Disabled)

2

JI

C3/JI2C4 SMB to PCI-Express Slots Open (Disabled)

JPG1 VGA Enable/Disable Pins 1-2 (Enabled)

JPL1/JPL2 LAN1/2 Enable/Disable Pins 1-2 (Enabled)

JWD Watch Dog Pins 1-2 (Reset)

Connector Description

COM1/COM2 COM1/COM2 Serial Port/Header

FAN 1-6 Chassis/CPU Fan Headers

Floppy Floppy Disk Drive Connector

F/P USB2/3, 4/5, 6 Front Panel Accessible USB Headers

IDE IDE HDD Connector

JD1 Speaker Header

JF1 Front Panel Connector

JL1 Chassis Intrusion Header

JLAN1/2 Gigabit Ethernet (RJ45) Ports

JOH1 Overheat LED Header

JPW1 24-pin Main ATX Power Connector

JPW2 +12V 8-pin Secondary Power Connector

JWOL1 Wake-On-LAN Header

JWOR Wake-On-Ring Header

SATA0 ~ SATA5 SATA Ports

SIMLP (Low Profi le) SIMLP IPMI 2.0 Socket

SMB System Management Bus (I

2

C) Connector (J18)

PWR_SMB Power Supply SMBus Connector (J17)

T-SGPIO-1/T-SGPIO-2 Serial General Purpose Input/Output Headers

USB0/1 (Back Panel) Universal Serial Bus (USB) Ports

VGA VGA Connector

LED Description

LE1 Onboard Standby PWR warning LED Indicator

LED5 CPU1 VRM Overheat LED Indicator

LED6 CPU2 VRM Overheat LED Indicator

1-5

X7DWE User's Manual

Motherboard Features

CPU

Dual Intel

•

Series processors at a front side bus speed of up to 1.6 GHz

Memory

Four 240-pin DIMM sockets support up to 32 GB DDR2 FBD (Fully Buffered)

•

ECC 800/667/533 Memory (See Section 2-3 in Chapter 2 for DIMM Slot Popu-

lation.)

Chipset

Intel 5400 chipset, including: the 5400 Memory Control Hub (MCH) and the

•

Enterprise South Bridge 2 (ESB2).

Expansion Slots

Four PCI-E x8 (Gen 2) slot (Slot3~Slot6)

•

One PCI-E x4 slot (Slot2)

•

®

64-bit LGA 771 Quad-Core/Dual-Core Xeon 5400/5300/5200/5100

One 64-bit PCI-X 133 MHz slot (Slot1)

•

One PCI-U (Universal) slot (Slot0)

•

One SIMLP IPMI Slot (Slot 7)

•

BIOS

16 Mb Phoenix

•

PCI 2.2, ACPI 1.0/2.0, Plug and Play (PnP), USB Keyboard support and

•

SMBIOS 2.3

PC Health Monitoring

Onboard voltage monitors for CPU cores, chipset Memory voltage, +1.8V, +3.3V,

•

+3.3V Standby, +5V, +5V Standby, +12V, −12V and Vbatt

Fan status monitor with fi rmware control

•

CPU/chassis temperature monitors

•

Platform Environment Control Interface (PECI) ready

•

Thermal Monitor 2 (TM2) support

•

CPU fan auto-off in sleep mode

•

CPU slow-down on temperature overheat

•

®

Flash ROM

Pulse Width Modulation (PWM) Fan Control

•

CPU thermal trip support for processor protection, power LED

•

Power-up mode control for recovery from AC power loss

•

Auto-switching voltage regulator for CPU cores

•

System overheat/Fan Fail LED Indicator and control

•

Chassis intrusion detection

•

System resource alert via Supero Doctor III

•

1-6

Chapter 1: Introduction

ACPI Features

Slow blinking LED for suspend state indicator

•

Main switch override mechanism

•

ACPI Power Management

•

Keyboard Wakeup from Soft-off

•

Onboard I/O

Intel ESB2 supports Six SATA2 ports (with RAID0, RAID1, RAID10, RAID5 sup-

•

ported in the Windows OS Environment)

One SIMLP IPMI socket

•

Intel 82563 EB Gigabit Ethernet controller support dual Giga-bit LAN ports

•

One EIDE Ultra DMA /100 bus master interface

•

One fl oppy port interface

•

Two COM ports(1 header, 1 port)

•

PS/2 mouse and PS/2 keyboard ports

•

Up to 7 USB 2.0 (Universal Serial Bus) (3 ports, 4 Headers)

•

ATI ES1000 (32 MB) Graphic Controller supports one VGA connector

•

Super I/O: Winbond W83627HF w/Hardware Monitor support: W83793

•

Other

External modem ring-on

•

Wake-on-LAN (WOL)

•

Wake-on-Ring (WOR)

•

Console redirection

•

CD/Diskette Utilities

BIOS fl ash upgrade utility and device drivers

•

Dimensions

Ext. ATX 9.80" (L) x 12.00" (W) (248.92 mm x 304.80 mm)

•

1-7

X7DWE User's Manual

#3

AUTO FREQ. DETECT

#4

PORT#1.2

PCI-EX_X8_SLOT

RJ45

RJ45

#1

PORT#3.4

PCI-EX_X8_SLOT

AD17
REQ0

IRQ_N0

GNT0

PCI-X SLOT

Gilgal

PHY

#5

PCI-EX_X8_SLOT

AD17
REQ1
GNT1
IRQ_NB

VGA
XGI

VRM

ISL6307

#6

PORT#5,6

PCI-EX_X8_SLOT

#0

#2

PCI-EX_X8_SLOT

PCI 32/33MMZ

PROCESSOR#2

1067/1333/1600

MT/S

PCI-EXP II x16

PCI-EXP II x16

PORT#7,8

MAC

PCI-E x4

PCI-E x4

UIO

PCI-X 133

PORT

#1,2,3,4

PORT
#5,6,7,8

POR PORT

PORT PORT

MAC

PORT

#2

PORT

#0

PROCESSOR#1

MCH

ESI#9

PCIEx4

#4 #3

ESB2

1067/1333/1600

MT/S

FBD CHNL0

FBD CHNL1

FBD CHNL2

FBD CHNL3

PCIEx4

ATA 100

EXP. BUS

3.0 Gb/S

USB 2.0

#0

FBD DIMM

EBUS CONN

#4

#3

#2

#1

#0

SATA

33
#4

#3

#2

#1

#0

USB

VRM

ISL6307

#0

FBD DIMM

IDE CONN

#5

#0

FBD DIMM

#0

FBD DIMM

FRONT PANEL

CONN

SIMLP

LPC

AD18
REQ0

GNT0

IRQ_NA

FDD

SIO

W83627

EHF

MS

KB

FWH

COM1

COM2

System Diagram

Note: This is a general block diagram. Please see the previous Mother-

board Features pages for details on the features of each motherboard.

1-8

Chapter 1: Introduction

1-3 Chipset Overview

Built upon the functionality and the capability of the 5400 chipset, the X7DWE

motherboard provides the performance and feature set required for quad-proces-

sor or dual-processor-based high-end systems with confi guration options opti-

mized for complex storage platforms. The 5400 chipset supports single or dual

Intel Quad-Core/Dual-Core Xeon 5400/5300/5200/5100 Series processor with

front side bus speeds of up to 1.6 GHz. The chipset consists of the 5400 Memory

Controller Hub (MCH) for the host bridge and the 631xESB/632xESB I/O Controller

Hub (Enterprise South Bridge 2-ESB2) for the I/O subsystem.

The Intel 5400 MCH (North Bridge)

The 5400 MCH (North Bridge) provides two FSB processing interfaces, four fully

buffered (FBD) DIMM memory channels, PCI-Express bus interfaces confi gurable

to form x8 or x16 ports, an ESB2 South Bridge Interface (ESI) and SMBus Inter-

faces for system management, and DIMM Serial Presence Detect (SPD). The peak

bandwidth for each FBD channel is 8 GB/s for DDR2 800/667/533 FBD memory,

giving a total memory size of 32 GB.

The Intel 631xESB/632x ESB I/O Controller Hub-ESB2
(South Bridge)

The 631xESB/632xESB I/O Controller Hub (Enterprise South Bridge 2) integrates

an Ultra ATA 100 Controller, six Serial ATA host controller ports, one EHCI host

controller, seven external USB 2.0 ports, an LPC interface controller, and a fl ash

BIOS interface controller. Additionally, the ESB 2 chip also contains a PCI inter-

face controller, integrated LAN controller, and an ESI for communication with the

MCH. The Intel ESB2 offers the data buffering and interface arbitration capabili-

ties required for a high-end system to constantly operate effi ciently and maintain

peak performance.

Compliant with the ACPI platform, the ESB2 supports the Full-On, Stop-Grant,

Suspend-to-RAM, Suspend-to-Disk, and Soft-Off power management states.

Combined with the functionality offered by the onboard LAN controller, the ESB2

also supports alert systems for remote management.

With the 5400 chipset built in, the X7DWE offers a superb solution for intense com-

puting and complex I/O environments, and is ideal for high-end server systems.

1-9

X7DWE User's Manual

1-4 Special Features

Recovery from AC Power Loss

BIOS provides a setting for you to determine how the system will respond when

AC power is lost and then restored to the system. You can choose for the system

to remain powered off (in which case you must hit the power switch to turn it back

on) or for it to automatically return to a power- on state. See the Advanced BIOS

Setup section to change this setting. The default setting is Last State.

1-5 PC Health Monitoring

This section describes the PC health monitoring features of the X7DWE. All have

an onboard System Hardware Monitor chip that supports PC health monitoring. An

onboard voltage monitor will scan these onboard voltages continuously: CPU Core,

Chipset Voltage, Memory Voltage, +1.8V, +5V, +3.3V, +3.3V Standby, +5V Standby,

+12V, −12V and VBatt. Once a voltage becomes unstable, a warning is given or

an error message is sent to the screen. Users can adjust the voltage thresholds

to defi ne the sensitivity of the voltage monitor.

Fan Status Monitor with Firmware Control

The PC health monitor can check the RPM status of the cooling fans. The onboard

CPU and chassis fans are controlled by Thermal Management via BIOS (under

Hardware Monitoring in the Advanced Setting).

Environmental Temperature Control

The thermal control sensor monitors the CPU temperature in real time and will turn

on the thermal control fan whenever the CPU temperature exceeds a user-defi ned

threshold. The overheat circuitry runs independently from the CPU. Once it detects

that the CPU temperature is too high, it will automatically turn on the thermal fan

control to prevent any overheat damage to the CPU. The onboard chassis thermal

circuitry can monitor the overall system temperature and alert users when the chas-

sis temperature is too high.

CPU Fan Auto-Off in Sleep Mode

The CPU fan becomes active when the power is turned on. It continues to operate

when the system enters the Standby mode. When in the sleep mode, the CPU will

not run at full power, thereby generating less heat.

1-10

Chapter 1: Introduction

CPU Overheat LED and Control

This feature is available when the user enables the CPU overheat warning func-

tion in the BIOS. This allows the user to defi ne an overheat temperature. When

the CPU temperature passes this threshold, both the overheat fan and the warning

LED are triggered.

System Resource Alert

This feature is available when used with Supero Doctor III in the Windows OS

environment or used with Supero Doctor II in Linux. Supero Doctor is used to

notify the user of certain system events. For example, you can also confi gure

Supero Doctor to provide you with warnings when the system temperature, CPU

temperatures, voltages and fan speeds go beyond a pre-defi ned range.

1-6 ACPI Features

ACPI stands for Advanced Confi guration and Power Interface. The ACPI specifi ca-

tion defi nes a fl exible and abstract hardware interface that provides a standard

way to integrate power management features throughout a PC system, including

its hardware, operating system and application software. This enables the system

to automatically turn on and off peripherals such as CD-ROMs, network cards, hard

disk drives and printers.

In addition to enabling operating system-directed power management, ACPI

provides a generic system event mechanism for Plug and Play and an operating

system-independent interface for confi guration control. ACPI leverages the Plug

and Play BIOS data structures while providing a processor architecture-independent

implementation that is compatible with both Windows 2000 and Windows 2003

Operating Systems.

Slow Blinking LED for Suspend-State Indicator

When the CPU goes into a suspend state, the chassis power LED will start blinking

to indicate that the CPU is in suspend mode. When the user presses any key, the

CPU will wake-up and the LED will automatically stop blinking and remain on.

Main Switch Override Mechanism

When an ATX power supply is used, the power button can function as a system

suspend button to make the system enter a SoftOff state. The monitor will be

suspended and the hard drive will spin down. Pressing the power button again

will cause the whole system to wake-up. During the SoftOff state, the ATX power

supply provides power to keep the required circuitry in the system "alive." In case

1-11

X7DWE User's Manual

the system malfunctions and you want to turn off the power, just press and hold

the power button for 4 seconds. This option can be set in the Power section of

the BIOS Setup routine.

External Modem Ring-On

Wake-up events can be triggered by a device such as the external modem ringing

when the system is in the SoftOff state. Note that external modem ring-on can

only be used with an ATX 2.01 (or above) compliant power supply.

Wake-On-LAN (WOL)

Wake-On-LAN is defi ned as the ability of a management application to remotely

power up a computer that is powered off. Remote PC setup, up-dates and asset

tracking can occur after hours and on weekends so that daily LAN traffi c is kept to

a minimum and users are not interrupted. The motherboard has a 3-pin header

(WOL) to connect to the 3-pin header on a Network Interface Card (NIC) that has

WOL capability. In addition, an onboard LAN controller can also support WOL

without any connection to the WOL header. The 3-pin WOL header is to be used

with a LAN add-on card only.

Note: Wake-On-LAN requires an ATX 2.01 (or above) compliant power

supply.

1-7 Power Supply

As with all computer products, a stable power source is necessary for proper and

reliable operation. It is even more important for processors that have high CPU

clock rates.

The X7DWE can accommodate 24-pin ATX power supplies. Although most power

supplies generally meet the specifi cations required by the CPU, some are inad-

equate. In addition, the 12V 8-pin power connections are also required to ensure

adequate power supply to the system. Also your power supply must supply 1.5A

for the Ethernet ports.

Note: The + 12V 8-pin CPU Power Connector (JPW2) is also required to

support Intel 64-bit CPUs. Failure to provide this extra power will result in

CPU PWR Failure. See Section 2-5 for details on connecting the power

supply.

It is strongly recommended that you use a high quality power supply that meets ATX

power supply Specifi cation 2.02 or above. It must also be SSI compliant (For more

information, please refer to the website at http://www.ssiforum.org/). Additionally, in

areas where noisy power transmission is present, you may choose to install a line

1-12

Chapter 1: Introduction

fi lter to shield the computer from noise. It is recommended that you also install a

power surge protector to help avoid problems caused by power surges.

1-8 Super I/O

The disk drive adapter functions of the Super I/O chip include a fl oppy disk drive

controller that is compatible with industry standard 82077/765, a data separator,

write pre-compensation circuitry, decode logic, data rate selection, a clock genera-

tor, drive interface control logic and interrupt and DMA logic. The wide range of

functions integrated onto the Super I/O greatly reduces the number of components

required for interfacing with fl oppy disk drives. The Super I/O supports 360 K, 720

K, 1.2 M, 1.44 M or 2.88 M disk drives and data transfer rates of 250 Kb/s, 500 Kb/s

or 1 Mb/s. It also provides two high-speed, 16550 compatible serial communication

ports (UARTs). Each UART includes a 16-byte send/receive FIFO, a programmable

baud rate generator, complete modem control capability and a processor interrupt

system. Both UARTs provide legacy speed with baud rate of up to 115.2 Kbps

as well as an advanced speed with baud rates of 250 K, 500 K, or 1 Mb/s, which

support higher speed modems.

The Super I/O provides functions that comply with ACPI (Advanced Confi guration

and Power Interface), which includes support of legacy and ACPI power manage-

ment through an SMI or SCI function pin. It also features auto power management

to reduce power consumption.

1-13

X7DWE User's Manual

Notes

1-14

Chapter 2: Installation

Chapter 2

Installation

2-1 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To prevent dam-

age to your system board, it is important to handle it very carefully. The following

measures are generally suffi cient to protect your equipment from ESD.

Precautions

Use a grounded wrist strap designed to prevent static discharge.

•

Touch a grounded metal object before removing the board from the antistatic

•

bag.

Handle the board by its edges only; do not touch its components, peripheral

•

chips, memory modules or gold contacts.

When handling chips or modules, avoid touching their pins.

•

Put the motherboard and peripherals back into their antistatic bags when not

•

in use.

For grounding purposes, make sure your computer chassis provides excellent

•

conductivity between the power supply, the case, the mounting fasteners and

the motherboard.

Use only the correct type of onboard CMOS battery as specifi ed by the

•

manufacturer. Do not install the onboard battery upside down to avoid possible

explosion.

Unpacking

The motherboard is shipped in antistatic packaging to avoid static damage. When

unpacking the board, make sure the person handling it is static protected.

2-1

X7DWE User's Manual

!

2-2 Processor and Heatsink Installation

When handling the processor package, avoid placing direct pressure on

the label area of the fan.

Notes:

1.

Always connect the power cord last and always remove it before adding, re-

moving or changing any hardware components. Make sure that you install the

processor into the CPU socket before you install the CPU heatsink.

2.

Intel's boxed Xeon CPU package contains the CPU fan and heatsink assem-

bly. If you buy a CPU separately, make sure that you use only Intel-certifi ed

multi-directional heatsink and fan.

3.

Make sure to install the motherboard into the chassis before you install the

CPU heatsink and fan.)

4.

When purchasing an LGA 771 CPU or when receiving a motherboard with an

LGA 771 CPU pre-installed, make sure that the CPU plastic cap is in place,

and none of the CPU pins are bent; otherwise, contact the retailer immedi-

ately.

5.

Refer to the MB Features Section for more details on CPU support.

Installing an LGA771 Processor

Press the socket clip to release the

1.

load plate, which covers the CPU

socket, from its locking position.

Socket Clip

Gently lift the socket clip to open the

2.

load plate.

Use your thumb and your index fi nger

3.

to hold the CPU at the North Center

Edge and the South Center Edge of

the CPU.

Load Plate

North Center Edge

South Center Edge

2-2

Align CPU Pin1 (the CPU corner

!

4.

marked with a triangle) against the

socket corner marked with a triangle

cutout.

Align the CPU key, the semi-circle

5.

cutout below a gold dot, against the

socket key, which is the notch on

the same side of the triangle cutout

on the socket.

Chapter 2: Installation

gold dot

Socket Key

(Socket Notch)

CPU Key (semi-

circle cutout)

below the circle.

Pin 1 w/a Tri-

angle Corner

Once aligned, carefully lower the

6.

CPU straight down into the socket.

(Do not drop the CPU on the

socket. Do not move the CPU hori-

zontally or vertically. Do not rub the

CPU against the surface or against

any pins of the socket to avoid dam-

aging the CPU or the socket.)

With the CPU inside the socket, in-

7.

spect the four corners of the CPU to

make sure that the CPU is properly

installed.

Use your thumb to gently push the

8.

socket clip down to the clip lock.

If the CPU is properly installed into

9.

the socket, the plastic cap will be

automatically released from the load

plate when the clip is pushed in the

clip lock. Remove the plastic cap

from the motherboard.

Socket clip

CPU in the CPU socket

Plastic cap

is released

from the

load plate

if the CPU

is properly

installed.

Warning: Please save the plas-

tic cap. The motherboard must

be shipped with the plastic cap

properly installed to protect the

CPU socket pins. Shipment

without the plastic cap properly

installed will cause damage to

the socket pins.

2-3

X7DWE User's Manual

!

Installation of the Heatsink

CEK Heatsink Installation

Do not apply any thermal grease to

1.

the heatsink or the CPU die because

the required amount has already been

applied.

Place the heatsink on top of the CPU

2.

so that the four mounting holes are

aligned with those on the retention

mechanism.

3. Screw in two diagonal screws (ie the #1

and the #2 screws) until just snug (-do not

fully tighten the screws to avoid possible

damage to the CPU.)

4. Finish the installation by fully tightening

all four screws.

CEK Passive Heatsink

Screw#1 Screw#2

Screw#1

To Un-install the Heatsink

Warning: We do not recommend that the CPU or the heatsink be re-

moved. However, if you do need to uninstall the heatsink, please follow

the instructions below to uninstall the heatsink to prevent damage done

to the CPU or the CPU socket.

Unscrew and remove the

1.

heatsink screws from the mother-

board in the sequence as show in

the picture on the right.

Hold the heatsink as shown in

2.

the picture on the right and gently

wriggle the heatsink to loosen

it from the CPU. (Do not use

excessive force when wriggling

the heatsink.)

Screw#2

2-4

Chapter 2: Installation

3. Once the CPU is loosened, remove the

heatsink from the CPU socket.

4. Clean the surface of the CPU and the

heatsink to get rid of the old thermal grease.

Reapply the proper amount of thermal

grease on the surface before you re-install

the CPU and the heatsink.

Screw#1

Screw#2

Mounting the Motherboard in the Chassis

All motherboards have standard mounting holes to fi t different types of chassis.

Make sure that the locations of all the mounting holes for both motherboard and

chassis match. Make sure that the metal standoffs click in or are screwed in tightly.

Then, use a screwdriver to secure the motherboard onto the motherboard tray.

Note: some components are very close to the mounting holes. Please

take precautionary measures to avoid damaging these components when

you install the motherboard to the chassis.

2-5

X7DWE User's Manual

2-3 Memory Installation

Exercise extreme care when installing or removing DIMM

modules to prevent any possible damage. Also note that the

memory is interleaved to improve performance (See step 1).

DIMM Installation

Insert the desired number of DIMMs into the memory slots, starting with

1.

DIMM #1A. The memory scheme is interleaved, so you must install (a) pair(s)

of modules of the same type and same speed at a time, beginning with Bank

1, Bank 2 and so on. For optimal memory performance, please install two

modules at a time with the maximum of 4 modules as shown in the Table

below. (Refer to our website for additional memory information.)

Insert each DIMM module vertically into its slot. Pay attention to the notch

2.

along the bottom of the module to prevent inserting the DIMM module incor-

rectly. Gently press down on the DIMM module until it snaps into place in the

slot. Repeat for all modules.

DIMM Installation for Optimized Performance
# of DIMMs Bank 1 Bank 2
2 DIMMs 1A 2A
4 DIMMs 1A 1B 2A 2B
Notes: i. DIMM slot# specified: DIMM slot to be populated; “---“: DIMM slot

not to be populated. ii. FBD 533 MHz, 667MHz and 800MHz DIMMs are
supported; however, you need to use the memory modules of the same speed
and of the same type on a motherboard. iii. Interleaved memory is supported
when pairs of DIMM modules are installed. For optimal memory performance,
please install pairs of memory modules in both
memory to work properly, you need to follow the restrictions listed above.

Memory Support

CAUTION

Bank 1 and Bank 2. iv. For

The X7DWE supports up to 32 GB fully buffered (FBD) ECC DDR 2 800/667/533

in 4 DIMMs. Please note that DDR2 FBD 800 MHz memory is supported by the

processors with FSB 1333 MHz and 1066 MHz; however, it will run @667 MHz.

Note 1: Due to OS limitations, some operating systems may not show

more than 4 GB of memory.

Note 2: Different types of memory modules are supported by processors

with different front side bus speeds. Refer to the Table below.

DIMM Modules Supported by CPUs

CPU

DIMM

800 MHz Supported Supported, but runs @ 667MHz Supported, but runs @ 667MHz

667 MHz Supported Supported Supported

533 MHz Not Supported Supported Supported

FSB:

1600 MHz

FSB:

1333 MHz

FSB:

1066 MHz

2-6

Chapter 2: Installation

Note 3: Due to memory allocation to system devices, memory remaining

available for operational use will be reduced when 4 GB of RAM is used.

The reduction in memory availability is disproportional. (See the Memory

Availability Table below.)

Possible System Memory Allocation & Availability

System Device Size Physical Memory

Firmware Hub fl ash memory (System
BIOS)

Local APIC 4 KB 3.99 GB

Area Reserved for the chipset 2 MB 3.99 GB

I/O APIC (4 Kbytes) 4 KB 3.99 GB

PCI Enumeration Area 1 256 MB 3.76 GB

PCI Express (256 MB) 256 MB 3.51 GB

PCI Enumeration Area 2 (if needed)

-Aligned on 256-MB boundary-

VGA Memory 16 MB 2.85 GB

TSEG 1 MB 2.84 GB

Memory available for the OS & other
applications

1 MB 3.99 GB

512 MB 3.01 GB

Remaining (-Available)
(4 GB Total System Memory)

2.84 GB

Installing and Removing DIMMs

X7DWE

To Remove:

Use your thumbs
to gently push
the release tabs
near both ends of
the module. This
should release it
from the slot.

Note: Notch

should align

with the

on the slot

DIMM2 FBD

Notch

Release

Tab

receptive point

To I nstal l: Insert module vertically and press
down until it snaps into place. Pay attention to the
alignment notch at the bottom.

2 FBD

Notch

Release

Tab

2-7

X7DWE User's Manual

123

4

5

678

2-4 Control Panel Connectors/IO Ports

The I/O ports are color coded in conformance with the PC 99 specifi cation. See

Figure 2-3 below for the colors and locations of the various I/O ports.

1. Back Panel Connectors/IO Ports

X7DWE

Back Panel I/O Port Locations and Defi nitions

Back Panel Connectors

Keyboard (Purple)

1.

PS/2 Mouse (Green)

2.

Back Panel USB Port 0

3.

Back Panel USB Port 1

4.

COM Port 1 (Turquoise)

5.

VGA Port (Blue)

6.

Gigabit LAN 1

7.

Gigabit LAN 2

8.

(See Section 2-5 for details.)

2-8

Chapter 2: Installation

2. Front Control Panel

JF1 contains header pins for various buttons and indicators that are normally lo-

cated on a control panel at the front of the chassis. These connectors are designed

specifi cally for use with Supermicro server chassis. See the fi gure below for the

descriptions of the various control panel buttons and LED indicators. Refer to the

following section for descriptions and pin defi nitions.

JF1 Header Pins

1920

Ground

NMI

X7DWE

X

Power LED

HDD LED

NIC1 LED

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

PWR

2

1

Reset Button

Power Button

2-9

X7DWE User's Manual

3. Front Control Panel Pin Defi nitions

NMI Button

The non-maskable interrupt button

header is located on pins 19 and 20

of JF1. Refer to the table on the right

for pin defi nitions.

Power LED

The Power LED connection is located

on pins 15 and 16 of JF1. Refer to the

table on the right for pin defi nitions.

NMI Button

Pin Defi nitions (JF1)

Pin# Defi nition

19 Control

20 Ground

Power LED

Pin Defi nitions (JF1)

Pin# Defi nition

15 +5V

16 Ground

COM1

VGA

LAN1

LAN2

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

USB0/1

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

SMB

PWR

FAN1

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

LED5

CPU1

CPU2

FAN2

FAN3

JOH1

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

USB6

I-SATA1

I-SATA0

FLOPPY

JL1

FAN4

BIOS

I-SATA3

I-SATA2

J8

A. NMI

B. PWR LED

Power LED

NIC1 LED

FP CTRL

OH/Fan Fail LED

PWR Fail LED

IDE#1

Ground

B

HDD LED

NIC2 LED

Ground

Ground

1920

A

NMI

X

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

Reset Button

Power Button

PWR

2

1

2-10

HDD LED

Chapter 2: Installation

The HDD LED connection is located

on pins 13 and 14 of JF1. Attach a

hard drive LED cable here to display

disk activity (for any hard drive ac-

tivities on the system, including SAS,

Serial ATA and IDE). See the table on

the right for pin defi nitions.

NIC1/NIC2 LED Indicators

The NIC (Network Interface Control-

ler) LED connection for GLAN port 1 is

located on pins 11 and 12 of JF1, and

the LED connection for GLAN Port 2

is on Pins 9 and 10. Attach the NIC

LED cables to display network activity.

Refer to the table on the right for pin

defi nitions.

HDD LED

Pin Defi nitions (JF1)

Pin# Defi nition

13 +5V

14 HD Active

GLAN1/2 LED

Pin Defi nitions (JF1)

Pin# Defi nition

9/11 Vcc

10/12 Ground

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

SMB

PWR

FAN1

LED5

A. HDD LED

B. NIC1 LED

C. NIC2 LED

Ground

X

Power LED

A

HDD LED

1920

NMI

X

Vcc

Vcc

Intel 5400

North Bridge

BANK2

CPU1

BANK1

CPU2

B

NIC1 LED

C

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Intel ESB2

South Bridge

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGP IO2

USB4/5

J7

USB2/3

JP1

JBT

BIOS

USB6

FLOPPY

IDE#1

Ground

J18

JWOL1

I-SATA4

JPT1

JD1

I-SATA5

SPKR

LE1

I-SATA1

I-SATA3

I-SATA0

I-SATA2

J8

JL1

FAN4

2

Vcc

Vcc

Vcc

Vcc

Reset

Reset Button

Power Button

PWR

1

2-11

X7DWE User's Manual

Overheat (OH)/Fan Fail LED

Connect an LED Cable to the OH/Fan

Fail connection on pins 7 and 8 of

JF1 to provide advanced warnings

of chassis overheating or fan failure.

Refer to the table on the right for pin

defi nitions.

Power Fail LED

The Power Fail LED connection is

located on pins 5 and 6 of JF1. Re-

fer to the table on the right for pin

defi nitions.

OH/Fan Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition

7 Vcc

8 Ground

OH/Fan Fail Indicator

Status

State Defi nition

Off Normal

On Overheat

Flash-

Fan Fail

ing

PWR Fail LED

Pin Defi nitions (JF1)

Pin# Defi nition

5 Vcc

6 Ground

COM1

VGA

LAN1

LAN2

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

USB0/1

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

SMB

PWR

FAN1

LED5

A. OH/Fan Fail LED

B. PWR Supply Fail

BANK2

BANK1

CPU1

Ground

X

Intel 5400

North Bridge

CPU2

Power LED

HDD LED

NIC1 LED

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

USB6

I-SATA1

I-SATA0

FLOPPY

JL1

FAN4

BIOS

I-SATA3

I-SATA2

J8

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

IDE#1

A

B

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

Reset Button

Power Button

PWR

2

1

2-12

Reset Button

Chapter 2: Installation

The Reset Button connection is located

on pins 3 and 4 of JF1. Attach it to a

hardware reset switch on the computer

case. Refer to the table on the right for

pin defi nitions.

Power Button

The Power Button connection is located

on pins 1 and 2 of JF1. Momentarily con-

tacting both pins will power on/off the sys-

tem. This button can also be confi gured

to function as a suspend button (with a

setting in the BIOS - see Chapter 4). To

turn off the power when set to suspend

mode, press the button for at least 4

seconds. Refer to the table on the right

for pin defi nitions.

Reset Button

Pin Defi nitions (JF1)

Pin# Defi nition

3 Reset

4 Ground

Power Button

Pin Defi nitions (JF1)

Pin# Defi nition

1 Signal

2 +3V Standby

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

SMB

PWR

FAN1

LED5

A. Reset Button

B. PWR Button

BANK2

BANK1

CPU1

Ground

X

Intel 5400

North Bridge

CPU2

Power LED

HDD LED

NIC1 LED

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

Intel ESB2

South Bridge

BIOS

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

T-SGP IO2

USB4/5

J7

USB2/3

JP1

JBT

I-SATA3

I-SATA2

J8

USB6

I-SATA1

I-SATA0

IDE#1

FLOPPY

JL1

FAN4

NIC2 LED

OH/Fan Fail LED

PWR Fail LED

Ground

Ground

1920

NMI

X

Vcc

Vcc

Vcc

Vcc

Vcc

Vcc

Reset

PWR

2

1

A

Reset Button

B

Power Button

2-13

X7DWE User's Manual

2-5 Connecting Cables

ATX Power Connector

There are a 24-pin main power supply

connector(JPW1) and an 8-pin CPU

PWR connector (JPW3) on the moth-

erboard. These power connectors

meet the SSI EPS 12V specifi cation.

For the 8-pin PWR (JPW3), please

refer to the item listed below.

Processor Power Connector

In addition to the Primary ATX power

connector (above), the 12V 8-pin CPU

PWR connector at JPW3 must also

be connected to your power supply.

See the table on the right for pin

defi nitions.

ATX Power 24-pin Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

13 +3.3V 1 +3.3V

14 -12V 2 +3.3V

15 COM 3 COM

16 PS_ON 4 +5V

17 COM 5 COM

18 COM 6 +5V

19 COM 7 COM

20 Res (NC) 8 PWR_OK

21 +5V 9 5VSB

22 +5V 10 +12V

23 +5V 11 +12V

24 COM 12 +3.3V

12V 8-pin Power Con-

nector

Pin Defi nitions

Pins Defi nition

1 through 4 Ground

5 through 8 +12V

COM1

VGA

LAN1

LAN2

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

USB0/1

JP2

Super I/O

8-Pin PWR

JPG1

B

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

A

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

SMB

PWR

FAN1

LED5

A. 24-pin ATX PWR

B. 8-pin Processor PWR

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

BIOS

I-SATA3

I-SATA2

J8

USB6

I-SATA1

I-SATA0

IDE#1

FLOPPY

JL1

FAN4

2-14

Chapter 2: Installation

D

E

Universal Serial Bus (USB)

There are seven USB 2.0 (Universal

Serial Bus) ports/headers on the

motherboard. Back Panel USB Ports

0 and 1 are located at JUSB1. The

other fi ve are Front Panel Accessible

USB headers. USB Headers 2 and

3, USB Header 4 and 5, and USB6,

located next to the fl oppy drive, pro-

vide front panel USB access. See the

tables on the right for pin defi nitions.

Chassis Intrusion

A Chassis Intrusion header is located

at JL1 on the motherboard. Attach an

appropriate cable from the chassis to

inform you of a chassis intrusion when

the chassis is opened.

Back Panel USB

(USB0/1)

Pin# Defi nitions

1 +5V

2 PO-

3PO+

4 Ground

5N/A

Front Panel USB

Pin Defi nitions (USB 2/3/4)

USB2/4
Pin # Defi nition

USB3
Pin # Defi nition

1 +5V 1 +5V

2 PO- 2 PO-

3PO+ 3 PO+

4 Ground 4 Ground

5 Key 5 No connection

Chassis Intrusion

Pin Defi nitions (JL1)

Pin# Defi nition

1 Intrusion Input

2 Ground

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

A

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

SMB

PWR

FAN1

LED5

A. Backpanel USB 0/1

B. Front Panel USB 2/3

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGP IO2

C

USB4/5

J7

USB2/3

JP1

BIOS

I-SATA3

I-SATA2

J8

B

JBT

USB6

FLOPPY

I-SATA1

I-SATA0

JL1

FAN4

C. Front Panel USB 4/5

D. Front Panel USB 6

E. Chassis Intrusion

IDE#1

2-15

X7DWE User's Manual

G

F

E

D

Fan Headers

The X7DWE has six chassis/system/CPU fan

headers (Fan1 to Fan6). All these 4-pin fans

headers are backward compatible with the

traditional 3-pin fans. The onboard fan speeds

are controlled by Thermal Management via

Hardware Monitoring in the Advanced Setting

in BIOS. (The Default setting is Disabled.) See

the table on the right for pin defi nitions.

VGA Connector

A VGA connector is located at JVGA1 on the

I/O backplane. Refer to the board layout below

for the location.

Fan Header

Pin Defi nitions

Pin# Defi nition

1 Ground

2 +12V

3 Tachometer

4 PWR Modulation

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1

JI2C2

PWR

SMB

A

FAN1

LED5

A. Fan 1

B. Fan 2

BANK2

CPU1

BANK1

C. Fan 3

D. Fan 4

E. Fan 5

F. Fan 6

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

BIOS

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

I-SATA1

I-SATA3

I-SATA0

I-SATA2

J8

USB6

IDE#1

FLOPPY

JL1

FAN4

G. VGA

B

C

2-16

Chapter 2: Installation

ATX PS/2 Keyboard and PS/2
Mouse Ports

The ATX PS/2 keyboard and the PS/2

mouse are located at JKM1. See the

table on the right for pin defi nitions.

(The mouse port is above the key-

board port. See the table on the right

for pin defi nitions.)

Serial Ports

COM1 is a connector located on the

I/O Backpanel, and COM2 is a header

located at JCOM2. See the table on

the right for pin defi nitions.

PS/2 Keyboard and

Mouse Port Pin

Defi nitions

Pin# Defi nition

1 Data

2NC

3 Ground

4 VCC

5 Clock

6NC

Serial Port Pin Defi nitions

(COM1/COM2)

Pin # Defi nition Pin # Defi nition

1 CDC 6 DSR

2 RXD 7 RTS

3TXD 8CTS

4DTR 9 RI

5 Ground 10 NC

COM1

VGA

LAN1

LAN2

USB0/1

B

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

A

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

C

JI2C3

Slot1 PCI-X 133MHz

JI2C1
JI2C2

(Pin 10 is available on COM2
only. NC: No Connection.)

SMB

PWR

FAN1

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

JP1

BIOS

J8

LED5

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JBT

USB6

FLOPPY

I-SATA1

I-SATA3

I-SATA0

I-SATA2

JL1

FAN4

A. Keyboard/Mouse

B. COM1

C. COM2

IDE#1

2-17

X7DWE User's Manual

Wake-On-LAN

The Wake-On-LAN header is located

at JWOL1 on the motherboard. You

must also have a LAN card with a

Wake-On-LAN connector and a cable

to use this feature. See the table on

the right for pin defi nitions.

Power LED/Speaker

On the JD1 header, pins 1-3 are used

for power LED indication, and pins

4-7 are for the speaker. See the table

on the right for speaker pin defi ni-

tions. Please note that the speaker

connector pins (4-7) are for use with

an external speaker. If you wish to

use the onboard speaker, you should

close pins 6-7 with a jumper.

Wake-On-LAN

Pin Defi nitions

Pin# Defi nition

1 +5V Standby

2 Ground

3 Wake-up

Speaker Connector

Pin Setting Defi nition

Pins 6-7 Internal Speaker

Pins 4-7 External Speaker

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1

JI2C2

SMB

PWR

FAN1

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

A

SPKR

JPT1

JWOL1

I-SATA5

I-SATA4

B

LE1

J18

JD1

BIOS

LED5

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

USB6

FLOPPY

I-SATA1

I-SATA3

I-SATA0

I-SATA2

J8

JL1

FAN4

A. WOR

B. PWR LED/Speaker

IDE#1

2-18

GLAN 1/2 (Giga-bit Ethernet

D

Ports)

Chapter 2: Installation

Two G-bit Ethernet ports are located

at JLAN1 and JLAN2 on the I/O

backplane. These ports accept RJ45

type cables.

T-SGPIO Headers

Two SGPIO (Serial-Link General

Purpose Input/Output) headers (T-

SGPIO-1/T-SGPIO-2) are located

next to the IDE connector on the

motherboard. These headers support

serial link interfaces for the onboard

SATA and SAS connectors. See the

table on the right for pin defi nitions.

Refer to the board layout below for

the location.

GLAN1 GLAN2

T-SGPIO

Pin Defi nitions

Pin# Defi nition Pin Defi nition

1NC 2 NC

3 Ground 4 Data

5 Load 6 Ground

7NC 8 NC

Note: NC= No Connections

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

A

JP2

B

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1
JI2C2

PWR

SMB

FAN1

LED5

A. GLAN1

B. GLAN2

C. T-SGPIO-1

C. T-SGPIO-2

C

JP1

BIOS

J8

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

I-SATA3

I-SATA2

JBT

I-SATA1

I-SATA0

USB6

IDE#1

FLOPPY

JL1

FAN4

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

2-19

X7DWE User's Manual

SMB

A System Management Bus header is

located at J18. Connect the appropri-

ate cable here to utilize SMB on your

system.

Power SMB (I2C) Connector

Power SMB (I2C) Connector (J17)

monitors power supply, fan and sys-

tem temperatures. See the table on

the right for pin defi nitions.

SMB Header

Pin Defi nitions

Pin# Defi nition

1 Data

2 Ground

3 Clock

4 No Connection

PWR SMB

Pin Defi nitions

Pin# Defi nition

1 Clock

2 Data

3 PWR Fail

4 Ground

5+3.3V

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1

JI2C2

B

PWR

SMB

FAN1

LED5

A. SMB

B. PWR SMB

BIOS

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

I-SATA1

I-SATA3

I-SATA0

I-SATA2

J8

USB6

IDE#1

FLOPPY

JL1

FAN4

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

A

LE1

J18

JD1

SPKR

JPT1

JWOL1

I-SATA5

I-SATA4

2-20

2-6 Jumper Settings

Connector

Pins

Jumper

Cap

Setting

Chapter 2: Installation

Explanation of
Jumpers

To modify the operation of the mother-

board, jumpers can be used to choose

between optional settings. Jumpers cre-

ate shorts between two pins to change

the function of the connector. Pin 1

is identifi ed with a square solder pad

on the printed circuit board. See the

motherboard layout pages for jumper

locations.

Note: On two pin jumpers,

"Closed" means the jumper

is on and "Open" means the

jumper is off the pins.

GLAN Enable/Disable

JPL1/JPL2 enable or disable the GLAN

Port1/GLAN Port2 on the mother-

board. See the table on the right for

jumper settings. The default setting is

Enabled.

SMB

PWR

Intel 5400

North Bridge

South Bridge

LE1

JD1

Intel ESB2

SPKR

JPT1

FAN1

JWOL1

BANK2

BANK1

I-SATA5

I-SATA4

JP1

BIOS

J8

J7

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

A

JPL1

JPL2

B

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1
JI2C2

J18

I-SATA3

I-SATA2

CPU1

CPU2

USB4/5

USB2/3

JBT

LED5

USB6

I-SATA1

I-SATA0

FAN2

FAN3

T-SGPIO1

T-SGPIO2

JL1

JOH1

LED6

FLOPPY

FAN4

3 2 1

3 2 1

Pin 1-2 short

GLAN Enable

Jumper Settings

Pin# Defi nition

1-2 Enabled (default)

2-3 Disabled

A. GLAN Port 1 Enable

B. GLAN Port 2 Enable

FP CTRL

IDE#1

2-21

X7DWE User's Manual

CMOS Clear

JBT1 is used to clear CMOS. Instead of pins, this "jumper" consists of contact

pads to prevent the accidental clearing of CMOS. To clear CMOS, use a metal

object such as a small screwdriver to touch both pads at the same time to short

the connection. Always remove the AC power cord from the system before clear-

ing CMOS.

Note: For an ATX power supply, you must completely shut down the sys-

tem, remove the AC power cord and then short JBT1 to clear CMOS.

Watch Dog Enable/Disable

Watch Dog (JWD) is a system monitor that

can reboot the system when a software ap-

plication hangs. Close Pins 1-2 to reset the

system if an application hangs. Close Pins

2-3 to generate a non-maskable interrupt

signal for the application that hangs. See the

table on the right for jumper settings. Watch

Dog must also be enabled in the BIOS.

SMB

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

B

JI2C3

Slot1 PCI-X 133MHz

JI2C1

JI2C2

PWR

FAN1

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

I-SATA5

SPKR

LE1

J18

JWOL1

I-SATA4

JPT1

JD1

BIOS

LED5

CPU1

CPU2

USB4/5

A

J7

USB2/3

JP1

JBT

USB6

I-SATA1

I-SATA3

I-SATA0

I-SATA2

J8

FAN2

FAN3

T-SGPIO1

T-SGPIO2

JL1

LED6

FLOPPY

FAN4

JOH1

Watch Dog

Jumper Settings (JWD)

Jumper Setting Defi nition

Pins 1-2 Reset

(default)

Pins 2-3 NMI

Open Disabled

A. Clear CMOS

B. Watch Dog Enable

FP CTRL

IDE#1

2-22

I2C Bus to PCI-X/PCI-Exp. Slots

D

E

Chapter 2: Installation

Jumpers JI2C1, JI2C2, JI2C3, and JI2C4

allow you to connect the System Man-

agement Bus (I

2

C) to PCI-X and PCI-E

slots. The default setting is Open to dis-

able the connection. See the table on the

right for jumper settings.

VGA Enable/Disable

JPG1 allows you to enable or disable the

VGA Controller. The default position is on

pins 1 and 2 to use this feature. See the

table on the right for jumper settings.

I2C to PCI-X/PCI/Exp

Jumper Settings

Jumper Setting Defi nition

Closed Enabled

Open Disabled (Default)

VGA Enable/Disable

Jumper Settings (JPG1)

Jumper Setting Defi nition

Pins 1-2 Enabled

Pins 2-3 Disabled

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

C

JI2C3

Slot1 PCI-X 133MHz

2

A. JI

SMB

PWR

FAN1

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

A

JI2C1
JI2C2

B

LE1

J18

JD1

SPKR

JPT1

JWOL1

I-SATA5

I-SATA4

JP1

BIOS

J8

LED5

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

I-SATA3

I-SATA2

JBT

I-SATA1

I-SATA0

USB6

IDE#1

FLOPPY

JL1

FAN4

C1

2

B. JI

C2

C. JI2C3

2

D. JI

C4

E. VGA Enabled

2-23

X7DWE User's Manual

2-7 Onboard Indicators

GLAN LEDs

There are two GLAN ports on the moth-

erboard. Each Gigabit Ethernet LAN port

has two LEDs. The yellow LED indicates

activity, while the Link LED may be green,

amber or off to indicate the speed of the

connection. See the tables at right for

more information.

Onboard Power LED

An Onboard Power LED is located at LE1

on the motherboard. When this LED is lit,

the system is on. Be sure to turn off the

system and unplug the power cord before

removing or installing components. See

the tables at right for more information.

Link

LED

Activity

LED

Rear View (when facing the
rear side of the chassis)

GLAN Activity Indicator

LED Settings

Color Status Defi nition

Yellow Flashing Active

GLAN Link Indicator

LED Color Defi nition

Off No Connection or 10 Mbps

Green 100 Mbps

Amber 1 Gbps

Onboard PWR LED Indicator (LE1)

LED Color Defi nition

Off System Off (PWR cable

Green System On

Green:
Flashing
Quickly

Green:
Flashing
Slowly

not connected)

ACPI S1 State

ACPI S3 (STR) State

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

A

B

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1

JI2C2

PWR

SMB

FAN1

LED5

A. GLAN Port1 LEDs

B. GLAN Port2 LEDs

C. Onboard Power LED

BIOS

CPU1

CPU2

FAN2

FAN3

JOH1

FP CTRL

LED6

T-SGPIO1

T-SGPIO2

USB4/5

J7

USB2/3

JP1

JBT

I-SATA1

I-SATA3

I-SATA0

I-SATA2

J8

USB6

IDE#1

FLOPPY

JL1

FAN4

BANK2

BANK1

Intel 5400

North Bridge

Intel ESB2

South Bridge

C

LE1

J18

JD1

SPKR

JPT1

JWOL1

I-SATA5

I-SATA4

2-24

Chapter 2: Installation

CPU VRM Overheat LED
Indicators

Two CPU VRM Overheat LED Indicators

are located on the motherboard. When

LED5 is on, it indicates a possible CPU1

VRM Overheat. When LED6 is on, a

CPU2 VRM Overheat might have oc-

curred. See the tables at right for more

information.

CPU1 VRM Overheat (LED5)/

CPU2 VRM Overheat (LED6)

LED Status Defi nition

LED5: Off CPU1 VRM Temperature

Normal

LED5: On CPU1 VRM Overheat

LED6: Off CPU2 VRM Temperature

Normal

LED6: On CPU2 VRM Overheat

COM1

VGA

LAN1

LAN2

USB0/1

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

JI2C4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3

Slot1 PCI-X 133MHz

JI2C1
JI2C2

PWR

SMB

FAN1

LED5

A

A. LED5: CPU1VRM OH

B. LED6: CPU2VRM OH

BANK2

BANK1

Intel 5400

North Bridge

CPU1

CPU2

FAN2

FAN3

B

JOH1

FP CTRL

LED6

T-SGPIO1

I-SATA3

I-SATA2

USB4/5

USB2/3

JBT

USB6

I-SATA1

I-SATA0

T-SGPIO2

JL1

FLOPPY

FAN4

IDE#1

Intel ESB2

South Bridge

SPKR

LE1

J18

JPT1

JD1

JWOL1

I-SATA5

I-SATA4

JP1

BIOS

J8

J7

2-25

X7DWE User's Manual

2-8 Floppy Drive, SIMLP, Serial ATA and Hard Disk
Drive Connections

Note the following when connecting the fl oppy and hard disk drive cables:

•

The fl oppy disk drive cable has seven twisted wires.

A red mark on a wire typically designates the location of pin 1.

•

A single fl oppy disk drive ribbon cable has 34 wires and two connectors to

•

provide for two fl oppy disk drives. The connector with twisted wires always

connects to drive A, and the connector that does not have twisted wires always

connects to drive B.

Floppy Connector

The fl oppy connector is located at J22

on the motherboard. See the table on

the right for pin defi nitions.

SMB

PWR

Intel 5400

North Bridge

South Bridge

LE1

Intel ESB2

SPKR

JD1

FAN1

BANK2

BANK1

J7

JP1

BIOS

I-SATA5

I-SATA4

I-SATA3

I-SATA2

J8

JWOL1

JPT1

COM1

VGA

LAN1

LAN2

FAN5

FAN6

VGA

CTRL

X7DWE

LAN

CTRL

JPL1

JPL2

KB/MS

USB0/1

JP2

Super I/O

8-Pin PWR

JPG1

DIMM2B

DIMM2A

DIMM1B

DIMM1A

Slot7 SIMLP

Slot6 PCI-E x8

Slot5 PCI-E x8

Slot4 PCI-E x8

JWD

Slot3 PCI-E x8

COM2

Slot 2 PCI-E x4

Slot 0 PCI-U

24-Pin ATX PWR

JI2C3
JI2C4

Slot1 PCI-X 133MHz

JI2C1
JI2C2

J18

CPU1

CPU2

USB4/5

USB2/3

JBT

I-SATA1

I-SATA0

LED5

USB6

T-SGP IO1

T-SGP IO2

Pin# Defi nition Pin # Defi nition

1 Ground 2 FDHDIN

3 Ground 4 Reserved

5 Key 6 FDEDIN

7 Ground 8 Index

9 Ground 10 Motor Enable

11 Ground 12 Drive Select B

13 Ground 14 Drive Select B

15 Ground 16 Motor Enable

17 Ground 18 DIR

19 Ground 20 STEP

21 Ground 22 Write Data

23 Ground 24 Write Gate

25 Ground 26 Track 00

27 Ground 28 Write Protect

29 Ground 30 Read Data

31 Ground 32 Side 1 Select

33 Ground 34 Diskette

A. Floppy

FAN2

FAN3

JOH1

FP CTRL

LED6

A

IDE#1

FLOPPY

JL1

FAN4

Floppy Drive Connector

Pin Defi nitions

2-26

Chapter 2: Installation

G

F

E

D

Serial ATA Ports

Six Serial ATA Ports (I-SATA0~I-

SATA 5) are located at JS1~JS6

on the motherboard. These ports

provide serial-link signal transmis-

sion, which is faster than that of the

traditional Parallel ATA. See the table

on the right for pin defi nitions.

SIMLP IPMI Slot

The SIMLP IPMI (Supermicro Intel-

ligent Management) Slot is located at

Slot 7 on the motherboard. Refer to

the layout below for the SIMLP IPMI

Slot location.

Serial ATA

Pin Defi nitions

Pin# Defi nition

1 Ground

2 TX_P

3 TX_N

4 Ground

5 RX_N

6 RX_P

7 Ground

A. I-SATA0

B. I-SATA1

C. I-SATA2

D. I-SATA3

E. I-SATA4

F. I-SATA5

G. SIMLP

X7DWE

B

C

A

2-27

X7DWE User's Manual

IDE Connector

An IDE Connector is located at JIDE1

on the motherboard. This connector

provides HDD IO connection. See the

table on the right for pin defi nitions.

IDE Drive Connector

Pin Defi nitions

Pin# Defi nition Pin # Defi nition

1 Reset IDE 2 Ground

3 Host Data 7 4 Host Data 8

5 Host Data 6 6 Host Data 9

7 Host Data 5 8 Host Data 10

9 Host Data 4 10 Host Data 11

11 Host Data 3 12 Host Data 12

13 Host Data 2 14 Host Data 13

15 Host Data 1 16 Host Data 14

17 Host Data 0 18 Host Data 15

19 Ground 20 Key

21 DRQ3 22 Ground

23 I/O Write 24 Ground

25 I/O Read 26 Ground

27 IOCHRDY 28 BALE

29 DACK3 30 Ground

31 IRQ14 32 IOCS16

33 Addr1 34 Ground

35 Addr0 36 Addr2

37 Chip Select 0 38 Chip Select 1

39 Activity 40 Ground

X7DWE

A. IDE#1

A

2-28

Chapter 3: Troubleshooting

Chapter 3

Troubleshooting

3-1 Troubleshooting Procedures

Use the following procedures to troubleshoot your system. If you have followed all

of the procedures below and still need assistance, refer to the ‘Technical Support

Procedures’ and/or ‘Returning Merchandise for Service’ section(s) in this chapter.

Note: Always disconnect the power cord before adding, changing or installing any

hardware components.

Before Power On

Make sure that there are no short circuits between the motherboard and

1.

chassis.

Disconnect all ribbon/wire cables from the motherboard, including those for

2.

the keyboard and mouse.

Remove all add-on cards.

3.

Install CPU 1 fi rst (making sure it is fully seated) and connect the chassis

4.

speaker and the power LED to the motherboard. (Check all jumper settings

as well.)

No Power

Make sure that no short circuits between the motherboard and the chassis.

1.

Make sure that all jumpers are set to their default positions.

2.

Check that the 115V/230V switch on the power supply is properly set.

3.

Turn the power switch on and off to test the system.

4.

The battery on your motherboard may be old. Check to verify that it still sup-

5.

plies ~3VDC. If it does not, replace it with a new one.

3-1

X7DWE User's Manual

No Video

If the power is on but you have no video, remove all the add-on cards and

1.

cables.

Use the speaker to determine if any beep codes exist. Refer to the Appendix

2.

for details on beep codes.

Losing the System’s Setup Confi guration

Make sure that you are using a high quality power supply. A poor quality

1.

power supply may cause the system to lose the CMOS setup information.

Refer to Section 1-6 for details on recommended power supplies.

The battery on your motherboard may be old. Check to verify that it still sup-

2.

plies ~3VDC. If it does not, replace it with a new one.

If the above steps do not fi x the Setup Confi guration problem, contact your

3.

vendor for repairs.

NOTE

If you are a system integrator, VAR or OEM, a POST diagnostics

card is recommended. For I/O port 80h codes, refer to App. B.

Memory Errors

Make sure that the DIMM modules are properly and fully installed.

1.

Check if different speeds of DIMMs have been installed and check if the BIOS

2.

setup is confi gured for the fastest speed of RAM used. (It is recommended to

use the same RAM speed for all DIMMs in the system.)

Make sure you are using the correct type of DDR2 FBD (Fully Buffered) ECC

3.

800/667/533 SDRAM (recommended by the manufacturer.)

Check for bad DIMM modules or slots by swapping a single module between

4.

all memory slots and check the results.

Make sure that all memory modules are fully seated in their slots. As an in-

5.

terleaved memory scheme is used, you must install pair(s) modules at a time,

beginning with Bank 1, then Bank 2, and so on (see Page 2-6).

Check the position of the 115V/230V switch on the power supply.

6.

3-2

Chapter 3: Troubleshooting

3-2 Technical Support Procedures

Before contacting Technical Support, please take the following steps. Also, please

note that as a motherboard manufacturer, Supermicro does not sell directly to end-

users, so it is best to fi rst check with your distributor or reseller for troubleshooting

services. They should know of any possible problem(s) with the specifi c system

confi guration that was sold to you.

Please go through the ‘Troubleshooting Procedures’ and 'Frequently Asked

1.

Question' (FAQ) sections in this chapter or see the FAQs on our website

(

http://www.supermicro.com/support/faqs/) before contacting Technical Sup-

port.

BIOS upgrades can be downloaded from our website at

2.

supermicro.com/support/bios/

If you still cannot resolve the problem, include the following information when

3.

contacting Supermicro for technical support:

Motherboard model and PCB revision number

•

BIOS release date/version (this can be seen on the initial display when your

•

system fi rst boots up)

System confi guration

•

An example of a Technical Support form is on our website at

•

supermicro.com/support/contact.cfm).

Distributors: For immediate assistance, please have your account number ready

•

when placing a call to our technical support department. We can be reached by

e-mail at [e-mail] or by fax at: [phone], option 2.

).

(http://www.

(http://www.

3-3 Frequently Asked Questions

Question: What are the various types of memory that my motherboard can

support?

Answer: The X7DWE has 4 240-pin DIMM slots that support DDR2 FBD ECC

800/667/533 SDRAM modules. It is strongly recommended that you do not mix

memory modules of different speeds and sizes.

Question: How do I update my BIOS?

Answer: It is recommended that you do not upgrade your BIOS if you are not

experiencing any problems with your system. Updated BIOS fi les are located on

3-3

X7DWE User's Manual

our website at (http://www.supermicro.com/support/bios/). Please check our BIOS

warning message and the information on how to update your BIOS on our website.

Also, check the current BIOS revision and make sure it is newer than your BIOS

before downloading. Select your motherboard model and download the BIOS fi le

to your computer. Unzip the BIOS fi les onto a bootable fl oppy and reboot your

system. Follow the Readme.txt to continue fl ashing the BIOS.

Warning: Do not shut down or reset the system while updating the BIOS

to prevent possible system boot failure!)

Question: What's on the CD that came with my motherboard?

Answer: The supplied compact disc has quite a few drivers and programs that

will greatly enhance your system. We recommend that you review the CD and

install the applications you need. Applications on the CD include chipset drivers

for the Windows OS, security and audio drivers.

3-4 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be-

fore any warranty service will be rendered. You can obtain service by calling your

vendor for a Returned Merchandise Authorization (RMA) number. When returning

to the manufacturer, the RMA number should be prominently displayed on the

outside of the shipping carton, and mailed prepaid or hand-carried. Shipping and

handling charges will be applied for all orders that must be mailed when service

is complete.

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alternation, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor fi rst for any product problems.

3-4

Chapter 4

Chapter 4: BIOS

BIOS

4-1 Introduction

This chapter describes the Phoenix BIOS™ Setup utility for the X7DWE. The

Phoenix ROM BIOS is stored in a fl ash chip and can be easily upgraded using a

fl oppy disk-based program.

Note: Due to periodic changes to the BIOS, some settings may have been

added or deleted and might not yet be recorded in this manual. Please

refer to the Manual Download area of the Supermicro website <http://www.

supermicro.com> for any changes to the BIOS that may not be refl ected

in this manual.

System BIOS

The BIOS is the Basic Input Output System used in all IBM® PC, XT™, AT®, and

®

PS/2

compatible computers. The Phoenix BIOS stores the system parameters,

types of disk drives, video displays, etc. in the CMOS. The CMOS memory requires

very little electrical power. When the computer is turned off, a backup battery pro-

vides power to the CMOS Logic, enabling it to retain system parameters. When the

computer is powered on, the computer is confi gured with the values stored in the

CMOS Logic by the system BIOS, which gains control at boot up.

How To Change the Confi guration Data

The CMOS information that determines the system parameters may be changed

by entering the BIOS Setup utility. This Setup utility can be accessed by pressing

the <Delete> key at the appropriate time during system boot. From the main menu,

you can access the other setup screens, such as the Security and Power menus.

Beginning with Section 4-3, detailed descriptions are given for each parameter

setting in the Setup utility.

Warning: Do not shut down or reset the system while updating BIOS to

prevent possible boot failure.

4-1

X7DWE User's Manual

4-2 Running Setup

Default settings are in bold text unless otherwise noted.

The BIOS setup options described in this section are selected by choosing the ap-

propriate text from the main BIOS Setup screen. All displayed text is described in

this section, although the screen display is often all you need to understand how

to set the options as shown on the following page.

When you fi rst power on the computer, the Phoenix BIOS™ is immediately acti-

vated.

While the BIOS is in control, the Setup program can be activated in one of two

ways:

By pressing <Delete> immediately after turning the system on, or

1.

When the message shown below appears briefl y at the bottom of the screen

2.

during the POST (Power On Self-Test), press the <Delete> key to activate the

main Setup menu:

Press the <Delete> key to enter Setup

4-3 Main BIOS Setup

All main Setup options are described in this section. The main BIOS Setup screen

is displayed below.

Use the Up/Down arrow keys to move among the different settings in each menu.

Use the Left/Right arrow keys to change the options for each setting.

Press the <Esc> key to exit the CMOS Setup Menu. The next section describes in

detail how to navigate through the menus.

Items that use submenus are indicated with the

press the <Enter> key to access the submenu.

icon. With the item highlighted,

4-2

Main BIOS Setup Menu

Chapter 4: BIOS

Main Setup Features

System Time

To set the system date and time, key in the correct information in the appropriate

fi elds. Then press the <Enter> key to save the data.

System Date

Using the arrow keys, highlight the month, day and year fi elds, and enter the correct

data. Press the <Enter> key to save the data.

BIOS Date

This fi eld displays the date when this version of BIOS was built.

Legacy Diskette A

This setting allows the user to set the type of fl oppy disk drive installed as dis-

kette A. The options are Disabled, 360Kb 5.25 in, 1.2MB 5.25 in, 720Kb 3.5 in,

1.44/1.25MB, 3.5 in and 2.88MB 3.5 in.

IDE Channel 0 Master/Slave, SATA Port 1, SATA Port ,
SATA Port 3 and SATA Port 4

These settings allow the user to set the parameters of IDE Channel 0 Master/Slave,

SATA Port 1, SATA Port 2,SATA Port 3, and SATA Port 4 slots. Hit <Enter> to activate

the following sub-menu screen for detailed options of these items. Set the correct

confi gurations accordingly. The items included in the sub-menu are:

4-3

X7DWE User's Manual

Type

This option allows the user to select the type of IDE hard drive. Select Auto to

allow the BIOS to automatically confi gure the parameters of the HDD installed

at the connection. Enter a number between 1 to 39 to select a predetermined

HDD type. Select User to allow the user to enter the parameters of the HDD

installed. Select CDROM if a CDROM drive is installed. Select ATAPI if a remov-

able disk drive is installed.

CHS Format

The following items will be displayed by the BIOS:

Cylinders: This item indicates the status of cylinders.

Headers: This item indicates the number of headers.

Sectors: This item displays the number of sectors.

Maximum Capacity: This item displays the maximum storage capacity of the

system.

LBA Format

The following items will be displayed by the BIOS:

Total Sectors: This item displays the number of total sectors available in the
LBA Format.

4-4

Chapter 4: BIOS

Maximum Capacity: This item displays the maximum capacity in the LBA
Format.

Multi-Sector Transfers

This item allows the user to specify the number of sectors per block to be

used in multi-sector transfer. The options are Disabled, 4 Sectors, 8 Sectors,

and 16 Sectors.

LBA Mode Control

This item determines whether the Phoenix BIOS will access the IDE Channel 0

Master Device via the LBA mode. The options are Enabled and Disabled.

32 Bit I/O

This option allows the user to enable or disable the function of 32-bit data transfer.

The options are Enabled and Disabled.

Transfer Mode

This option allows the use r to set the transfer mo de. The options are Standard, Fast

PIO1, Fast PIO2, Fast PIO3, Fast PIO4, FPIO3/DMA1 and FPIO4/DMA2.

Ultra DMA Mode

This option allows the user to select Ultra DMA Mode. The options are Disabled,

Mode 0, Mode 1, Mode 2, Mode 3, Mode 4, and Mode 5.

Parallel ATA

This setting allows the user to enable or disable the function of Parallel ATA. The

options are Disabled and Enabled.

Serial ATA

This setting allows the user to enable or disable the function of Serial ATA. The

options are Disabled and Enabled.

Native Mode Operation

Select the native mode for ATA. The options are: Parallel ATA, Serial ATA, Both,

and Auto.

4-5

X7DWE User's Manual

SATA Controller Mode Option

Select Compatible to allow the SATA and PATA drives to be automatically-detected

and be placed in the Legacy Mode by the BIOS. Select Enhanced to allow the

SATA and PATA drives to be to be automatically-detected and be placed in the

Native IDE Mode. (Note: The Enhanced mode is supported by the Windows 2000

OS or a later version.)

When the SATA Controller Mode is set to "Enhanced", the following items will

display:

Serial ATA (SATA) RAID Enable

Select Enable to enable Serial ATA RAID Functions. (For the Windows OS envi-

ronment, use the RAID driver if this feature is set to Enabled. When this item is

set to Enabled, the item: "ICH RAID Code Base" will be available for you to select

either Intel or Adaptec Host RAID fi rmware to be activated. If this item is set to

Disabled, the item-SATA AHCI Enable will be available.) The options are Enabled

and Disabled.

ICH RAID Code Base

Select Intel to enable Intel's SATA RAID fi rmware. Select Adaptec to use Adaptec's

HostRAID fi rmware. The options are Intel and Adaptec.

SATA AHCI Enable

Select Enable to enable the function of Serial ATA Advanced Host Interface. (Take

caution when using this function. This feature is for advanced programmers only.

The options are Enabled and Disabled.)

System Memory

This display informs you how much system memory is recognized as being present

in the system.

Extended Memory

This display informs you how much extended memory is recognized as being pres-

ent in the system.

4-6

Chapter 4: BIOS

4-4 Advanced Setup

Choose Advanced from the Phoenix BIOS Setup Utility main menu with the ar-

row keys. You should see the following display. The items with a triangle beside

them have sub menus that can be accessed by highlighting the item and pressing

<Enter>.

Boot Features

Access the submenu to make changes to the following settings.

QuickBoot Mode

If enabled, this feature will speed up the POST (Power On Self Test) routine by

skipping certain tests after the computer is turned on. The settings are Enabled

and Disabled. If Disabled, the POST routine will run at normal speed.

QuietBoot Mode

This setting allows you to Enable or Disable the graphic logo screen during boot-

up.

POST Errors

Select Enable to stop the POST routine and allow the system to display error

messages when an error occurs during bootup. The options are Enabled and

Disabled.

ACPI Mode

Use the setting to determine if you want to employ ACPI (Advanced Confi guration

and Power Interface) power management on your system. The options are Yes

and No.

4-7

X7DWE User's Manual

Power Button Behavior

If set to Instant-Off, the system will power off immediately as soon as the user hits

the power button. If set to 4-sec., the system will power off when the user presses

the power button for 4 seconds or longer. The options are instant-off and 4-sec

override.

Resume On Modem Ring

Select On to “wake your system up” when an incoming call is received by your

modem. The options are On and Off.

EFI OS Boot

If enabled, this feature provides support for EFI OS booting. The options are En-

abled and Disabled.

Keyboard On Now Function

This feature allows the user to determine how to use the keyboard to power on the

system from S3~S5 States. Select Space to allow the user to power on the system

by pressing the space bar. Select Password to allow the user to enter the password

to power on the system. Select Disabled to disable this function.

Power Loss Control

This setting allows you to choose how the system will react when power returns

after an unexpected loss of power. The options are Stay Off, Power On, and Last

State.

Watch Dog

If enabled, this option will automatically reset the system if the system is not active

for more than a predefi ned time period. The options are Enabled and Disabled.

Summary Screen

This setting allows you to Enable or Disable the summary screen which displays

the system confi guration during bootup.

4-8

Chapter 4: BIOS

Memory Cache

Cache System BIOS Area

This setting allows you to designate a reserve area in the system memory to be

used as a System BIOS buffer to allow the BIOS to write (cache) its data into this

reserved memory area. Select Write Protect to enable the function and reserve

this area for the Video BIOS ROM access only. Select Uncached to disable this

function and make this area available for other devices.

Cache Video BIOS Area

This setting allows you to designate a reserve area in the system memory to be

used as a Video BIOS buffer to allow the BIOS to write (cache) its data into this

reserved memory area. Select Write Protect to enable the function and reserve

this area for the Video BIOS ROM access only. Select Uncached to disable this

function and make this area available for other devices.

Cache Base 0-512K

If enabled, this feature allows the data stored in the base memory area: block

0-512K to be cached (written) into a buffer, a storage area in the Static DROM

(SDROM) or to be written into L1, L2 cache inside the CPU to speed up CPU

operations. Select Uncached to disable this function. Select Write Through to al-

low data to be cached into the buffer and written into the system memory at the

same time. Select Write Protect to prevent data from being written into the base

memory area of Block 0-512K. Select Write Back to allow the CPU to write data

back directly from the buffer without writing data to the System Memory for fast

CPU data processing and operation. The options are Uncached, Write Through,

Write Protect, and Write Back.

Cache Base 512K-640K

If enabled, this feature allows the data stored in the memory area: 512K-640K to

be cached (written) into a buffer, a storage area in the Static DROM (SDROM) or

written into L1, L2 or L3 cache inside the CPU to speed up CPU operations. Select

Uncached to disable this function. Select Write Through to allow data to be cached

into the buffer and written into the system memory at the same time. Select Write

Protect to prevent data from being written into the base memory area of Block

512-640K. Select Write Back to allow the CPU to write data back directly from the

buffer without writing data to the system memory to speed up CPU's operation.

The options are Uncached, Write Through, Write Protect, and Write Back.

Cache Extended Memory

If enabled, this feature allows the data stored in the extended memory area to

be cached (written) into a buffer, a storage area in the Static DROM (SDROM) or

written into L1, L2, L3 cache inside the CPU to speed up CPU operations. Select

4-9

X7DWE User's Manual

Uncached to disable this function. Select Write Through to allow data to be cached

into the buffer and written into the system memory at the same time. Select Write

Protect to prevent data from being written into the extended memory area above 1

MB. Select Write Back to allow the CPU to write data back directly from the buffer

without writing data to the System Memory for fast CPU data processing and opera-

tion. The options are Uncached, Write Through, Write Protect, and Write Back.

Discrete MTRR Allocation

If enabled, MTRRs (-Memory Type Range Registers) are confi gured as distinct,

separate units and cannot be overlapped. If enabled, the user can achieve better

graphic effects when using a Linux graphic driver that requires the write-combining

confi guration with 4GB or more memory. The options are Enabled and Disabled.

PCI Confi guration

Access the submenu to make changes to the following settings for PCI devices.

Onboard GLAN1/Onboard GLAN2 (Gigabit- LAN) OPROM Confi gure

Select Enabled to allow the system to boot from the GLAN1 connection or the GLAN

2 connection. The options are Enabled and Disabled.

Option ROM Replacement

If set to enabled, the user is allowed to select the bootable peripheral device. If a

system hangs during bootup, please change the setting of this item. The options

are Enabled and Disabled.

PCI Parity Error Forwarding

Enable this item to forward the PCI errors that occurs behind the P2P bridges to the

South Bridge, so NMI can be asserted. The options are Enabled and Disabled.

PCI Fast Delayed Transaction

Enable this function to improve the DMA data transfer rate for a PCI 32-bit multi-

media card. The options are Enable and Disabled.

Reset Confi guration Data

If set to Yes, this item clears the Extended System Confi guration Data- (ESCD)

area. The options are Yes and No.

Frequency for PCI-X

This option allows the user to change the bus frequency for the devices installed

in the slot(s) indicated. The options are Auto, PCI 33 MHz, PCI 66 MHz, PCI-X 66

MHz, PCI-X 100 MHz, and PCI-X 133 MHz.

4-10

Chapter 4: BIOS

UIO PCI-Exp. x8, Slot1 PCI-X 133 MHz, Slot2 PCI-Exp.
x4, Slot3 PCI-Exp x8, Slot4 PCI-Exp x8, Slot5 PCI-Exp x8,
and Slot6 PCI-Exp x8

Access the submenu for each of the settings above to make changes to the

following:

Option ROM Scan

When enabled, this setting will initialize the device expansion ROM. The options

are Enabled and Disabled.

Enable Master

This setting allows you to enable the selected device as the PCI bus master.

The options are Enabled and Disabled.

Latency Timer

This setting allows you to set the clock rate for the Bus Master. A high-priority,

high-throughout device may benefi t from a greater clock rate. The options are

Default, 0020h, 0040h, 0060h, 0080h, 00A0h, 00C0h, and 00E0h. For Unix,

Novell and other Operating Systems, please select the option: other. If a drive

fails after the installation of a new software, you might want to change this setting

and try again. A different OS requires a different Bus Master clock rate.

Large Disk Access Mode

This setting determines how large hard drives are to be accessed. The options are

DOS or Other (for Unix, Novelle NetWare and other operating systems).

Advanced Chipset Control

Access the submenu to make changes to the following settings.

Warning: Take caution when changing the Advanced settings. An Incor-

rect value, a very high DRAM frequency or an incorrect DRAM timing may

cause system to become unstable. When this occurs, reset the setting to

the default setting.

SERR Signal Condition

This setting specifi es the ECC Error conditions that an SERR# is to be asserted.

The options are None, Single Bit, Multiple Bit, and Both.

Clock Spectrum Feature

If Enabled, the BIOS will monitor the level of Electromagnetic Interference caused

by the components and will attempt to decrease the interference whenever needed.

The options are Enabled and Disabled.

4-11

X7DWE User's Manual

Intel VT for Direct I/O (VT-d)

Select Enable to enable the functionality of the Intel Virtualization Technology for

Direct I/O VT-d

the DMAR ACPI Tables. This feature offers fully-protected I/O resource-sharing

across the Intel platforms, providing the user with greater reliability, security

and availability in networking and data-sharing. The settings are Enabled and

Disabled. Press the <Enter> key to enter the submenu.

4GB PCI Hole Granularity

This feature allows you to select the granularity of PCI hole for PCI slots. If MTRRs

are not enough, this option may be used to reduce MTRR occupation. The options

are: 256 MB, 512 MB, 1GB and 2GB.

Memory Voltage Auto-Detect

Set to Enabled to allow the BIOS automatically detect the memory voltage accord-

ing to its SPD table. Select 1.5V-Forced to use low-power fully-buffered DIMMs

(FBDIMM). Select 1.8V-Forced to use 1.8V memory for testing. (Using the 1.8V-

Forced setting may be harmful to some 1.5V FBDIMM.) The options are: Auto-

Detect, 1.5V-Forced and 1.8V-Forced.

support by reporting the I/O device assignment to VMM through

Memory Branch Mode

This option determines how the two memory branches operate. System address

space can either be interleaved between the two branches or Sequential from one

branch to another. Mirror mode allows data correction by maintaining two copies

of data in two branches. Single Channel 0 allows a single DIMM population dur-

ing system manufacturing. The options are Interleave, Sequential, Mirroring, and

Single Channel 0.

Branch 0 Rank Sparing/Branch 1 Rank Sparing

Select Enable to enable the function of memory sparing for Memory Bus Branch 0

or Branch 1. The options are Enabled and Disabled.

Branch 0 Rank Interleaving/Branch 1 Rank Interleaving

Select enable to enable Interleaved Memory for Memory Bus Branch 0 Rank or

Branch 1 Rank. The options for Memory Interleaving are 1:1, 2:1 and 4:1.

Enhanced x8 Detection

Select Enabled to enable Enhanced x8 DRAM UC Error Detection. The options

are Disabled and Enabled.

4-12

Chapter 4: BIOS

Demand Scrub

Scrubbing is a process that allows the North Bridge to correct correctable memory

errors found on a memory module. When the CPU or I/O issues a demand- read

command, and the read data from memory turns out to be a correctable ECC, it

is corrected and sent to the original source. Memory is updated as well. Select

Enabled to use Demand Scrubbing for ECC memory correction. The options are

Enabled and Disabled.

High Temperature DRAM Operation

When set to Enabled, the BIOS will refer to the SPD table to set the maximum DRAM

temperature. If disabled, the BIOS will set the maximum DRAM temperature based

on a predefi ned value. The options are Enabled and Disabled.

AMB Thermal Sensor

Select Enabled to enable the thermal sensor embedded in the Advanced Memory

Buffer on a fully buffered memory module for thermal monitoring. The options are

Disabled and Enabled.

Thermal Throttle

Select Enabled to enable closed-loop thermal throttling on a fully buffered (FBD)

memory module. In the closed-loop thermal environment, thermal throttling will be

activated when the temperature of the FBD DIMM module exceeds a predefi ned

threshold. The options are Enabled and Disabled.

Global Activation Throttle

Select Enabled to enable the function of open-loop global thermal throttling on the

fully buffered (FBD) memory modules and allow global thermal throttling to become

active when the number of activate control exceeds a predefi ned number. The op-

tions are Enabled and Disabled.

Force ITK Confi guration Clocking

Select Enabled to confi gure FBD clock settings to support ITK testing. The options

are Disabled and Enabled.

Reserved Branch for ITK Test

This feature allows the user to specify the memory branch number to be reserved

for ITK testing. The default setting is Branch 1.

Snoop Filter

Select Enabled to eliminate snoop traffi c to the graphics port to greatly improve

system performance when running graphics intensive applications. The options are

Enabled and Disabled.

4-13

X7DWE User's Manual

Crystal Beach Features

Select Enabled to use the Intel I/O AT (Acceleration Technology) to accelerate the

performance of TOE devices. (Note: A TOE device is a specialized, dedicated pro-

cessor that is installed on an add-on card or a network card to handle some or all

packet processing of this add-on card. For this motherboard, the TOE device is built

inside the ESB 2 South Bridge chip.) The options are Enabled and Disabled.

Route Port 80h Cycles to

This feature allows the user to decide which bus to send debug information to. The

options are Disabled, PCI and LPC.

High Precision Event Time

Select Yes to activate the High Precision Event Timer (HPET), which is capable of

producing periodic interrupts at a much higher frequency than a Real-time Clock

(RTC) can in synchronizing multimedia streams, providing smooth playback and

reducing the dependency on other timestamp calculation devices, such as an x86

RDTSC Instruction embedded in a CPU. The High Precision Event Timer is used

to replace the 8254 Programmable Interval Timer. The options for this feature are

Yes and No.

USB Function

Select Enabled to enable the function of USB devices specifi ed. The settings are

Enabled and Disabled.

Legacy USB Support

This setting allows you to enable support for Legacy USB devices. The settings

are Enabled and Disabled.

4-14

Chapter 4: BIOS

Advanced Processor Options

Access the submenu to make changes to the following settings.

CPU Speed

This is a display that indicates the speed of the installed processor.

Frequency Ratio (Available when supported by the CPU.)

The feature allows the user to set the internal frequency multiplier for the CPU. The

options are: Default, x12, x13, x14, x15, x16, x17 and x18.

Core-Multi-Processing (Available when supported by the CPU.)

Set to Enabled to use a processor's Second Core and beyond. (Please refer to Intel's

website for more information.) The options are Disabled and Enabled.

Machine Checking (Available when supported by the CPU.)

Set to Enabled to activate the function of Machine Checking and allow the CPU to

detect and report hardware (machine) errors via a set of model-specifi c registers

(MSRs). The options are Disabled and Enabled.

Thermal Management 2 (Available when supported by the CPU.)

Set to Enabled to use Thermal Management 2 (TM2) which will lower CPU voltage

and frequency when the CPU temperature reaches a predefi ned overheat threshold.

Set to Disabled to use Thermal Manager 1 (TM1), allowing CPU clocking to be

regulated via CPU Internal Clock modulation when the CPU temperature reaches

the overheat threshold.

C1/C2 Enhanced Mode (Available when supported by the CPU.)

Set to Enabled to enable Enhanced Halt State to lower CPU voltage/frequency to

prevent overheat. The options are Enabled and Disabled. (Note: please refer to

Intel’s website for detailed information.)

Execute Disable Bit (Available when supported by the CPU and the OS.)

Set to Enabled to enable Execute Disable Bit and allow the processor to classify

areas in memory where an application code can execute and where it cannot, and

thus preventing a worm or a virus from inserting and creating a fl ood of codes to

overwhelm the processor or damage the system during an attack. Note: this feature

is available when your OS and your CPU support the function of Execute Disable

Bit. The options are Disabled and Enabled. For more information, please refer to

Intel's and Microsoft's websites.

Adjacent Cache Line Prefetch (Available when supported by the CPU.)

The CPU fetches the cache line for 64 bytes if this option is set to Disabled. The

4-15

X7DWE User's Manual

CPU fetches both cache lines for 128 bytes as comprised if Enabled. The options

are Disabled and Enabled.

Hardware Prefetch (Available when supported by the CPU.)

Set this option to Enabled to enable the hardware components that are used in

conjunction with software programs to prefetch data in order to shorten execution

cycles and maximize data processing effi ciency. The options are Disabled and

Enabled.

Set Maximum Ext. CPUID=3

When set to Enabled, the Maximum Extended CPUID will be set to 3. The options

are Disabled and Enabled.

Direct Cache Access (Available when supported by the CPU.)

Set to Enable to route inbound network IO traffi c directly into processor caches

to reduce memory latency and improve network performance. The options are

Disabled and Enabled.

DCA Delay Clocks (Available when supported by the CPU.)

This feature allows the user to set the clock delay setting from snoop to prefetch

for Direct Cache Access. Select a setting from 8 (bus cycles) to 120 (bus cycles)

(in 8-cycle increment). The default setting is 32 (bus cycles).

Intel <R> Virtualization Technology (Available when supported by the CPU.)

Select Enabled to use the feature of Virtualization Technology to allow one platform

to run multiple operating systems and applications in independent partitions, creat-

ing multiple "virtual" systems in one physical computer. The options are Enabled

and Disabled. Note: If there is any change to this setting, you will need to power off

and restart the system for the change to take effect. Please refer to Intel’s website

for detailed information.

Intel EIST Support (Available when supported by the CPU.)

Select Enabled to use the Enhanced Intel SpeedStep Technology and allows the

system to automatically adjust processor voltage and core frequency in an effort

to reduce power consumption and heat dissipation. The options are Enabled and

Disabled. Please refer to Intel’s website for detailed information.

C1 State Mode (Available when supported by the CPU.)

Select Disable to disable the Standard C1 Halt State which will partially turn off

the CPU internal clocks to conserve energy and prevent system overheating when

the OS is idle. Select Enable to use the Enhanced C1 Halt State to lower the CPU

clock frequency and the supply voltage before turning off the clocks.

4-16

Chapter 4: BIOS

I/O Device Confi guration

Access the submenu to make changes to the following settings.

KBC Clock Input

This setting allows you to select clock frequency for KBC. The options are 6MHz,

8MHz, 12MHz, and 16MHz.

Serial Port A

This setting allows you to assign control of serial port A. The options are Enabled

(user defi ned), Disabled, and Auto (BIOS- or OS- controlled).

Base I/O Address

This setting allows you to select the base I/O address for serial port A. The options

are 3F8, 2F8, 3E8, and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for serial port A. The

options are IRQ3 and IRQ4.

Serial Port B

This setting allows you to assign control of serial port B. The options are Enabled

(user defi ned), Disabled, Auto (BIOS controlled) and OS Controlled.

Mode

This setting allows you to set the type of device that will be connected to serial port

B. The options are Normal and IR (for an infrared device).

Base I/O Address

This setting allows you to select the base I/O address for serial port B. The options

are 3F8, 2F8, 3E8 and 2E8.

Interrupt

This setting allows you to select the IRQ (interrupt request) for serial port B. The

options are IRQ3 and IRQ4.

Floppy Disk Controller

This setting allows you to assign control of the fl oppy disk controller. The options

are Enabled (user defi ned), Disabled, and Auto (BIOS and OS controlled).

Base I/O Address

This setting allows you to select the base I/O address for the Floppy port. The op-

tions are Primary and Secondary.

4-17

X7DWE User's Manual

DMI Event Logging

Access the submenu to make changes to the following settings.

Event Log Validity

This is a display to inform you of the event log validity. It is not a setting.

Event Log Capacity

This is a display to inform you of the event log capacity. It is not a setting.

View DMI Event Log

Highlight this item and press <Enter> to view the contents of the event log.

Event Logging

This setting allows you to Enable or Disable event logging.

ECC Event Logging

This setting allows you to Enable or Disable ECC event logging.

Mark DMI Events as Read

Highlight this item and press <Enter> to mark the DMI events as read.

Clear All DMI Event Logs

Select Yes and press <Enter> to clear all DMI event logs. The options are Yes

and No.

4-18

Chapter 4: BIOS

Console Redirection

Access the submenu to make changes to the following settings.

COM Port Address

This item allows you to specify which COM port to direct the remote console to:

Onboard COM A or Onboard COM B. This setting can also be Disabled.

BAUD Rate

This item allows you to set the BAUD rate for console redirection. The options are

300, 1200, 2400, 9600, 19.2K, 38.4K, 57.6K, and 115.2K.

Console Type

This item allows you to set console redirection type. The options are VT100,

VT100/8bit, PC-ANSI/7bit, PC ANSI, VT100+, VT-UTF8 and ASCII.

Flow Control

This item allows you to select the fl ow control option for the console. The options

are: None, XON/XOFF, and CTS/RTS.

Console Connection

This item allows you to decide how console redirection is to be connected: either

Direct or Via Modem.

Continue CR after POST

Select on to continue with console redirection after the POST routine. The options

are On and Off.

4-19

X7DWE User's Manual

Hardware Monitor Logic

Highlight this and hit <Enter> to see monitor data for the following items:

CPU1 Temperature/CPU2 Temperature/System Temperature

Fan1-Fan6 Speeds:

If the feature of Auto Fan Control is enabled, the BIOS will automatically display

the status of the fans indicated in this item.

Fan Speed Control Modes

This feature allows the user to decide how the system controls the speeds of the

onboard fans. The CPU temperature and the fan speed are correlative. When the

CPU on-die temperature increases, the fan speed will also increase, and vice versa.

Select Workstation if your system is used as a Workstation. Select Server if your

system is used as a Server. Select 3-pin if your chassis uses 3-pin fans. Select

4-pin if your chassis uses 4-pin fans. Select “Disable” to disable the fan speed

control function and allow the onboard fans to constantly run at the full speed (12V).

The Options are: 1. Full Speed @12V, 2. Optimized Server w/3-pin, 3. Optimized

Workstation w/3-pin, 4. Optimized Server w/4-pin, 5. Optimized Workstation w/4-pin,

6. Quiet w/4-pins, and 7. Super-Quiet w/4-pins.

Voltage Monitoring

The following items will be monitored and displayed:

VcoreA/VcoreB, +12V/-12V, +5Vsb/+5VDD, +3.3V, P1V5/P_VTT/Vbat

Note: In the Windows OS environment, the Supero Doctor III settings take

precedence over the BIOS settings. When fi rst installed, Supero Doctor III

adopts the temperature threshold settings previously set in the BIOS. Any

subsequent changes to these thresholds must be made within Supero Doc-

tor, since the SD III settings override the BIOS settings. For the Windows

OS to adopt the BIOS temperature threshold settings, please change the

SDIII settings to be the same as those set in the BIOS.

4-20

Chapter 4: BIOS

IPMI (The option is available only when an IPMI card is
installed in the system.)

IPMI Specifi cation Version:

This item displays the current IPMI Version.

Firmware Version: This item displays the current Firmware Version.

System Event Logging

Select Enabled to enable IPMI Event Logging. When this function is set to Disabled,

the system will continue to log events received via system interface. The options

are Enabled and Disabled.

Clear System Event Logging

Enabling this function to force the BIOS to clear the system event logs during the

next cold boot. The options are Enabled and Disabled.

Existing Event Log Number

This item displays the number of the existing event log.

Event Log Control

System Firmware Progress

Enabling this function to log POST progress. The options are Enabled and Dis-

abled.

BIOS POST Errors

Enabling this function to log POST errors. The options are Enabled and Dis-

abled.

4-21

X7DWE User's Manual

BIOS POST Watch Dog

Set to Enabled to enable POST Watch Dog. The options are Enabled and Dis-

abled

OS Boot Watch Dog

Set to Enabled to enable OS Boot Watch Dog. The options are Enabled and Dis-

abled.

Timer for Loading OS (Minutes)

This feature allows the user to set the time value (in minutes) for the previous

item: OS Boot Watch Dog by keying-in a desired number in the blank. The default

setting is 10 (minutes.) (Please ignore this option when OS Boot Watch Dog is set

to "Disabled".)

Time Out Option

This item allows the user to decide what action to take in an event of a system boot

failure. The options are No Action, Reset, Power Off and Power Cycles

System Event Log/System Event Log (List Mode)

These options display the System Event (SEL) Log and System Event (SEL) Log

in List Mode. Items include: SEL (System Event Log) Entry Number, SEL Record

ID, SEL Record Type, Time Stamp, Generator ID, SEL Message Revision, Sensor

Type, Sensor Number, SEL Event Type, Event Description, and SEL Event Data.

4-22

Chapter 4: BIOS

Realtime Sensor Data

This feature display information from motherboard sensors, such as temperatures,

fan speeds and voltages of various components.

4-5 Security

Choose Security from the Phoenix BIOS Setup Utility main menu with the arrow

keys. You should see the following display. Security setting options are displayed

by highlighting the setting using the arrow keys and pressing <Enter>. All Security

BIOS settings are described in this section.

4-23

X7DWE User's Manual

Supervisor Password Is:

This feature indicates if a supervisor password has been entered to the system.

Clear means such a password has not been used, and Set means a supervisor

password has been entered.

User Password Is:

This feature indicates if a user password has been entered to the system. Clear

means such a password has not been used, and Set means a user password has

been entered.

Set Supervisor Password

When the item Set "Supervisor Password" is highlighted, hit the <Enter> key. When

prompted, type the Supervisor's password in the dialogue box to set or to change

supervisor's password, which allows access to the BIOS.

Set User Password

When the item "Set User Password" is highlighted, hit the <Enter> key. When

prompted, type the user's password in the dialogue box to set or to change the

user's password, which allows access to the system at boot-up.

Password on Boot

This setting allows you to determine if a password is required for a user to enter the

system at system boot. The options are Enabled (password required) and Disabled

(password not required).

4-24

Chapter 4: BIOS

4-6 Boot

Choose Boot from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. See details on how to change the order and

specs of boot devices in the Item Specifi c Help window. All Boot BIOS settings

are described in this section.

Boot List

Candidate
List

Boot Priority Order/Excluded from Boot Orders

The devices included in the boot list section (above) are bootable devices listed in

the sequence of boot order as specifi ed. The boot functions for the devices included

in the candidate list (above) are currently disabled. Use a <+> key or a <-> key to

move the device up or down. Use the <f> key or the <r> key to specify the type of

an USB device, either fi xed or removable. You can select one item from the boot

list and hit the <x> key to remove it from the list of bootable devices (to make its

resource available for other bootable devices). Subsequently, you can select an

item from the candidate list and hit the <x> key to remove it from the candidate

list and put it in the boot list. This item will then become a bootable device. See

details on how to change the priority of boot order of devices in the "Item Specifi c

Help" window.

4-25

X7DWE User's Manual

4-7 Exit

Choose Exit from the Phoenix BIOS Setup Utility main menu with the arrow keys.

You should see the following display. All Exit BIOS settings are described in this

section.

Exit Saving Changes

Highlight this item and hit <Enter> to save any changes you made and to exit the

BIOS Setup utility.

Exit Discarding Changes

Highlight this item and hit <Enter> to exit the BIOS Setup utility without saving any

changes you may have made.

Load Setup Defaults

Highlight this item and hit <Enter> to load the default settings for all items in the

BIOS Setup. These are the safest settings to use.

Discard Changes

Highlight this item and hit <Enter> to discard (cancel) any changes you've made.

You will remain in the Setup utility.

Save Changes

Highlight this item and hit <Enter> to save any changes you made. You will remain

in the Setup utility.

4-26

Appendix A: POST Error Beep Codes

Appendix A

POST Error Beep Codes

This section lists POST (Power On Self Test) error beep codes for the Phoenix BIOS.

POST error beep codes are divided into two categories: recoverable and terminal.

This section lists Beep Codes for recoverable POST errors.

Recoverable POST Error Beep Codes

When a recoverable type of error occurs during POST, BIOS will display a POST

code that describes the problem. BIOS may also issue one of the following beep

codes:

1 long and two short beeps - video confi guration error

1 repetitive long beep - no memory detected

A-1

X7DWE User's Manual

Notes

A-2

Appendix B: Installing the Windows OS

Appendix B

Installing the Windows OS

After all hardware components have been installed, you must fi rst confi gure Intel

South Bridge RAID Settings before you install the Windows OS and other software

drivers. To confi gure RAID settings, please refer to RAID Confi guration User Guides

posted on our website at www.supermicro.com/support/manuals.

B-1 Installing the Windows XP/2000/2003 OS for
Systems with RAID Functions

Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the

1.

system will start booting up from CD.

Press the <F6> key when the message-" Press F6 if you need to install a

2.

third party SCSI or RAID driver" displays.

When the Windows XP/2000/2003 Setup screen appears, press "S" to specify

3.

additional device(s).

Insert the driver diskette-"Intel AA RAID XP/2000/2003 Driver for ESB2" into

4.

Drive A: and press the <Enter> key.

Choose the Intel(R) ESB2 SATA RAID Controller from the list indicated in the

5.

XP/2000/2003 Setup Screen, and press the <Enter> key.

Press the <Enter> key to continue the installation process. (If you need to

6.

specify any additional devices to be installed, do it at this time.) Once all

devices are specifi ed, press the <Enter> key to continue with the installation.

From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The

7.

XP/2000/2003 Setup will automatically load all device fi les and then, continue

the Windows XP/2000/2003 installation.

After the Windows XP/2000/2003 OS Installation is completed, the system will

8.

automatically reboot.

B-1

X7DWE User's Manual

B-2 Installing the Windows XP/2000/2003 OS for
Systems without RAID Functions

Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the

1.

system will start booting up from CD.

Continue with the OS installation. The Windows OS Setup screen will display.

2.

From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The

3.

XP/2000/2003 Setup will automatically load all device fi les and then continue

with the Windows XP/2000/2003 installation.

After the Windows XP/2000/2003 OS Installation is completed, the system will

4.

automatically reboot.

Insert the Supermicro Setup CD that came with your motherboard into the CD

5.

Drive during system boot, and the main screen will display.

B-2

Appendix C: Installing Other Software Programs and Drivers

Appendix C

Installing Other Software Programs and Drivers

C-1 Installing Drivers other than the Adaptec Embedded
Serial ATA RAID Controller Driver

After you've installed the Windows Operating System, a screen as shown below

will appear. You are ready to install software programs and drivers that have not

yet been installed. To install these software programs and drivers, click the icons

to the right of these items.

Driver/Tool Installation Display Screen

Note: Click the icons showing a hand writing on the paper to view the

readme fi les for each item. Click on a computer icon to the right of an item

to install an item (from top to the bottom) one at a time. After installing

each item, you must re-boot the system before proceeding with the

next item on the list. The bottom icon with a CD on it allows you to view

the entire contents of the CD.

C-1

X7DWE User's Manual

C-2 Confi guring Supero Doctor III

The Supero Doctor III program is a Web-base management tool that supports

remote management capability. It includes Remote and Local Management tools.

The local management is called the SD III Client. The Supero Doctor III program

included on the CDROM that came with your motherboard allows you to monitor

the environment and operations of your system. Supero Doctor III displays crucial

system information such as CPU temperature, system voltages and fan status.

See the Figure below for a display of the Supero Doctor III interface.

Note: 1 The default user name and password are ADMIN.

Note 2: In the Windows OS environment, the Supero Doctor III settings

take precedence over the BIOS settings. When fi rst installed, Supero Doc-

tor III adopts the temperature threshold settings previously set in BIOS. Any

subsequent changes to these thresholds must be made within Supero Doc-

tor, since the SD III settings override the BIOS settings. For the Windows

OS to adopt the BIOS temperature threshold settings, please change the

SDIII settings to be the same as those set in BIOS.

Supero Doctor III Interface Display Screen-I (Health Information)

C-2

Appendix C: Installing Other Software Programs and Drivers

Supero Doctor III Interface Display Screen-II (Remote Control)

Note: SD III Software Revision 1.0 can be downloaded from our website

at: ftp://ftp.supermicro.com/utility/Supero_Doctor_III/. You can also

download SDIII User's Guide at: http://www.supermicro.com/PRODUCT/

Manuals/SDIII/UserGuide.pdf. For Linux, we will still recommend that you

use Supero Doctor II.

C-3

X7DWE User's Manual

Notes

C-4
