Preface

About This Manual

This manual is written for professional system integrators and PC techni­cians. It provides information for the installation and use of the SuperServer
6014P-8/6014P-8R/6014P-82R/6014P-82. Installation and maintainance
should be performed by experienced technicians only.

The SuperServer 6014P-8/6014P-8R/6014P-82R/6014P-82 is a high-end
server based on the SC814+S-560/SC814+S-R560 1U rackmount chassis
and the Super X6DHP-8G/X6DHP-8G2 a dual processor serverboard that
supports Intel® XeonTM processors at a Front Side (System) Bus speed of
800 MHz.

Manual Organization

Chapter 1: Introduction

The first chapter provides a checklist of the main components included with
the server system and describes the main features of the X6DHP-8G/
X6DHP-8G2 serverboard and the SC814+S-560/SC814+S-R560 chassis,
which comprise the SuperServer 6014P-8/6014P-8R/6014P-82R/6014P-82.

Preface

Chapter 2: Server Installation

This chapter describes the steps necessary to install the SuperServer
6014P-8/6014P-8R/6014P-82R/6014P-82 into a rack and check out the
server configuration prior to powering up the system. If your server was
ordered without processor and memory components, this chapter will refer
you to the appropriate sections of the manual for their installation.

Chapter 3: System Interface

Refer here for details on the system interface, which includes the functions
and information provided by the control panel on the chassis as well as
other LEDs located throughout the system.

iii

SUPERSERVER 6014P-8/6014P-8R/6014P-82R/6014P-82 User's Manual

Chapter 4: System Safety

You should thoroughly familiarize yourself with this chapter for a general
overview of safety precautions that should be followed when installing and
servicing the SuperServer 6014P-8/6014P-8R/6014P-82R/6014P-82.

Chapter 5: Advanced Serverboard Setup

Chapter 5 provides detailed information on the X6DHP-8G/X6DHP-8G2
serverboard, including the locations and functions of connections, headers
and jumpers. Refer to this chapter when adding or removing processors or
main memory and when reconfiguring the serverboard.

Chapter 6: Advanced Chassis Setup

Refer to Chapter 6 for detailed information on the SC814+S-560/SC814+S­R560 server chassis. You should follow the procedures given in this chap­ter when installing, removing or reconfiguring SCSI or peripheral drives and
when replacing system power supply modules and cooling fans.

Chapter 7: BIOS

The BIOS chapter includes an introduction to BIOS and provides detailed
information on running the CMOS Setup Utility.

Appendix A: BIOS POST Codes

Appendix B: Software Installation

Appendix C: System Specifications

iv

Notes

Preface

v

SUPERSERVER 6014P-8/6014P-8R/6014P-82R/6014P-82 User's Manual

Table of Contents
