Preface

About this User's Guide

This user's guide is written for system integrators, IT technicians, and

knowledgeable end users. It provides information for the installation and use of the

AOC-SLG3-2M2 expansion card.

About this Expansion Card

The AOC-SLG3-2M2 is an M.2 SSD carrier card that enables the user to add up

to two Non-Volatile Memory express (NVMe) M.2 Solid-State Drives (SSDs). M.2

solid-state technology is an optimized, high-performance scalable storage solution,

effectively streamlined for enterprise and client systems that leverage the cutting-

edge capabilities of PCI-Express.

An Important Note to the User

All images and layouts shown in this user's guide are based upon the latest PCB

revision available at the time of publishing. The card you have received may or may

not look exactly the same as the graphics shown in this user's guide.

Preface

Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required be-

fore any warranty service will be rendered. You can obtain service by calling your

vendor for a Returned Merchandise Authorization (RMA) number. When returning

the AOC-SLG3-2M2 card to the manufacturer, the RMA number should be promi-

nently displayed on the outside of the shipping carton, and the shipping package

is mailed prepaid or hand-carried. Shipping and handling charges will be applied

for all orders that must be mailed when service is complete. For faster service, you

can also request a RMA authorization online http://www.supermicro.com/RmaForm/.

This warranty only covers normal consumer use and does not cover damages in-

curred in shipping or from failure due to the alteration, misuse, abuse or improper

maintenance of products.

During the warranty period, contact your distributor rst for any product problems.

iii

AOC-SLG3-2M2 Expansion Card User's Guide

Conventions Used in the User's Guide

Pay special attention to the following symbols for proper system installation and for

safety instructions to prevent damage to the system or injury to yourself:

Note: Additional information given for proper system setup.

iv

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Website: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Website: www.supermicro.nl

Preface

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: [phone]

Fax: [phone]

Email: [e-mail]

Website: www.supermicro.com.tw

v

AOC-SLG3-2M2 Expansion Card User's Guide

Table of Contents

Preface

About this User's Guide ................................................................................................iii

About this Expansion Card............................................................................................iii

An Important Note to the User ...................................................................................... iii

Returning Merchandise for Service ............................................................................... iii

Conventions Used in the User's Guide .........................................................................iv

Contacting Supermicro ...................................................................................................v

Chapter 1 Overview

1-1 Overview ......................................................................................................... 1-1

1-2 Technical Specications .................................................................................. 1-1

General ............................................................................................................ 1-1

OS Support ..................................................................................................... 1-1

Physical Dimensions ....................................................................................... 1-1

Chapter 2 Hardware Components

2-1 Expansion Card Layout and Components ...................................................... 2-1

2-2 Major Components .......................................................................................... 2-1

2-3 Connectors and LEDs ..................................................................................... 2-2

M.2 Sockets ................................................................................................ 2-2

Activity LEDs .............................................................................................. 2-3

2-4 Standoffs ......................................................................................................... 2-4

2-5 Front Jumper Locations and Settings ............................................................. 2-5

Explanation of Jumpers .................................................................................. 2-5

Chapter 3 Installation

3-1 Static-Sensitive Devices .................................................................................. 3-1

Precautions ..................................................................................................... 3-1

Unpacking ....................................................................................................... 3-1

3-2 Installing Expansion Cards ............................................................................. 3-2

3-3 Additional Settings .......................................................................................... 3-5

vi

Chapter 1: Overview

Chapter 1

Overview

1-1 Overview

Congratulations on purchasing your expansion card from an acknowledged leader

in the industry. Supermicro products are designed with the utmost attention to detail

to provide you with the highest standards in quality and performance. For product

support and updates, please refer to our website at http://www.supermicro.com.

1-2 Technical Specications

General

PCIe 3.0 x8 low-prole card

Ambient operating temperature from 10°C - 55°C

Supports up to two NVMe M.2 SSDs

OS Support

The following operating systems and their later versions are supported:

Windows

Linux

VMware

Physical Dimensions

Card PCB dimensions: 2.71" x 5.24" (H x L)

Note: If the motherboard or riser card has PCI-E reverse lanes, M.2 drives installed

on this card will be displayed in reverse sequence in the OS compared to the se-

quence shown on the AOC silkscreen.

1-1

AOC-SLG3-2M2 Expansion Card User's Guide

Notes

1-2

Chapter 2: Hardware Components

Chapter 2

Hardware Components

2-1 Expansion Card Layout and Components

1

1

C

D

The AOC-SLG3-2M2 Layout

1

A

1

B

2-2 Major Components

The following major components are on the AOC-SLG3-2M2:

A. M.2 Socket 1

B. M.2 Socket 2

C. M.2 Socket 1 Activity LED

D. M.2 Socket 2 Activity LED

2-1

AOC-SLG3-2M2 Expansion Card User's Guide

2-3 Connectors and LEDs

M.2 Sockets

There are two M.2 sockets on the expansion card.

The AOC-SLG3-2M2 NVMe Connectors

A

B

A. M.2 Socket 1

B. M.2 Socket 2

2-2

Chapter 2: Hardware Components

Activity LEDs

There are two Activity LEDs on the AOC-SLG3-2M2 designated as LED1 and LED2.

See the table below for information.

A

The AOC-SLG3-2M2 LEDs

A. Activity LEDs

Activity LED Status

LED Color Status

LED1 Green Blinks whenever there is any read or write activity on M.2 Socket 1

LED2 Green Blinks whenever there is any read or write activity on M.2 Socket 2

2-3

AOC-SLG3-2M2 Expansion Card User's Guide

2-4 Standoffs

The AOC-SLG3-2M2 is designed with movable standoffs which support three dif-

ferent M.2 SSD lengths. Place the standoffs as indicated below:

M.2 Length Standoff Positions

22 mm x 110 mm 1: SRW5 and SRW6

22 mm x 80 mm 2: SRW3 and SRW4

22 mm x 60 mm 3: SRW1 and SRW2

1

1

1

2

1

3

The AOC-SLG3-2M2 Standoff Positions

2-4

Chapter 2: Hardware Components

2-5 Front Jumper Locations and Settings

JP1

JP2

JP3

The AOC-SLG3-2M2 Jumpers

Explanation of Jumpers

To modify the operation of the backplane,

Connector

Pins

3 2 1

jumpers can be used to choose between

optional settings. Jumpers create shorts

between two pins to change the function

of the connector. Pin 1 is identied with

Jumper

a square solder pad on the printed circuit

board. Note: On two pin jumpers, "Closed"

means the jumper is on and "Open" means

Setting

3 2 1

the jumper is off the pins.

These jumpers are used to congure the SMBus address where the AOC is detected

by the BIOS. The default SMBus address is set to "A0"; however, it can also be

congured to a different setting to avoid possible address conict with another device

installed on the same SMBus. Please do not change the default setting unless you

are explicitly instructed to do so by Supermicro. It should never be changed unless

explicitly instructed by Supermicro.

2-5

AOC-SLG3-2M2 Expansion Card User's Guide

Note: Unless explicitly instructed otherwise by the manufacturer, do not move the

jumpers from their default locations. Doing so may disable the jumpers. Jumpers

not documented below are unpopulated.

SMB Address

JP3
A2

0 0 0 A0

0 0 1 A2

0 1 0 A4

0 1 1 A6

1 0 0 A8

1 0 1 AA

1 1 0 AC

1 1 1 AE

JP2
A1

1-2=0, 2-3=1

JP1
A0

Hex
Address

2-6

Chapter 3: Installation

Chapter 3

Installation

3-1 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid dam-

aging your expansion card, it is important to handle it very carefully. The following

measures are generally sufcient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the expansion card from the

antistatic bag.

• Handle the expansion card by its edges only; do not touch its components or

peripheral chips.

• Put the expansion card back into the antistatic bags when not in use.

• For grounding purposes, make sure that your system chassis provides excellent

conductivity between the power supply, the case, the mounting fasteners and

the expansion card.

Unpacking

The expansion card is shipped in antistatic packaging to avoid static damage. When

unpacking your component, make sure you are static protected.

Note: To avoid damaging your components and to ensure proper installation, be

sure to always connect the power cord last, and always remove it before adding,

removing or changing any hardware components

.

3-1

AOC-SLG3-2M2 Expansion Card User's Guide

3-2 Installing Expansion Cards

The AOC-SLG3-2M2 supports two M.2 SSDs in 60 mm, 80 mm, or 110 mm length.

Visit the Supermicro website for a current list of supported M.2 SSDs.

Installing Expansion Cards

1. Power down the system and remove the power cord from the rear of the

power supply.

2. Use industry-standard anti-static equipment (such as gloves or wrist strap)

and follow the precautions on page 3-1 to avoid damage caused by ESD.

3. For each SSD, install the standoff in the appropriate hole that corresponds

with the form factor of the SSD to be installed (60 mm, 80mm, or 110 mm

length SSDs are supported). Push the plastic standoff until it snaps into the

carrier card.

4. Insert one or two M.2 SSDs into the slots on the expansion card. Then push it

at against the carrier card and the plastic standoff.

Inserting a M.2 SSD into an Expansion Card Slot

3-2

Chapter 3: Installation

Securing the M.2 SSD to the Expansion Card

5. Secure each M.2 card by pushing the standoff into place in the mounting hole

designated as 60 mm, 80 mm, or 110 mm.

3-3

AOC-SLG3-2M2 Expansion Card User's Guide

The M.2 SSD secured to the Expansion Card

6. Simultaneously slide the expansion card bracket into the PCIe slot of the

chassis, while plugging the expansion card into the appropriate slot on the

motherboard.

7. Plug the power cord into the rear of the power supply and power up the

system.

3-4

Chapter 3: Installation

3-3 Additional Settings

Depending on the system, motherboard, and BIOS version, the following BIOS

settings may be necessary for the proper operation of M.2 NVMe drives:

• Having the CPU IOU settings set to x4x4x4x4 PCIe bifurcation. This option may

be found under BIOS Setup -> Advanced -> Chipset Conguration -> North

Bridge -> IIO Conguration -> CPU Conguration -> IOU Setting -> x4x4x4x4.

• Having the NVMe Firmware Source set to AMI Native Support. This option may

be found under BIOS Setup -> Advanced -> PCIe/PCI/PnP Conguration ->

NVMe Firmware Source -> AMI Native Support.

Refer to the applicable system or motherboard user's manual.

3-5
