AOC-S40G-i1Q

AOC-S40G-i2Q

USER’S GUIDE

Revision 1.0b

The information in this User’s Guide has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this user's guide, or to notify any person or organization of the updates. Please

Note: For the most up-to-date version of this user's guide, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this
user's guide at any time and without notice. This product, including software and documentation, is the property of
Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not
allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

WARNING: Handling of lead solder materials used in this product may expose you to lead, a
chemical known to the State of California to cause birth defects and other reproductive harm.

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.

Manual Revision 1.0b

Release Date: May 25, 2016

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

document. Information in this document is subject to change without notice. Other products and companies referred

to herein are trademarks or registered trademarks of their respective companies or mark holders.

Copyright © 2016 by Super Micro Computer, Inc.
All rights reserved.

Printed in the United States of America

Preface

Preface

About This User's Guide

This user's guide is written for system integrators, IT technicians and knowledgeable end
users. It provides information for the installation and use of the AOC-S40G-i1Q/i2Q add-on
card.

About This Add-On Card

The AOC-S40G-i1Q/i2Q 40-Gigabit Ethernet Adapter is the most exible and scalable Ethernet

adapter for today’s demanding data center environments. Based on the Intel® 40GbE network
controller XL710, the AOC-S40G-i1Q/i2Q meets the demanding needs of the next-generation

data center by providing features for virtualization, exibility for LAN and SAN networking,

and proven reliable performance.

Conventions Used in the User's Guide

Special attention should be given to the following symbols for proper installation and to prevent

damage done to the components or injury to yourself:

Warning! Indicates important information given to prevent equipment/property damage

or personal injury.

Warning! Indicates high voltage may be encountered when performing a procedure.

Important: Important information given to ensure proper system installation or to

relay safety precautions.

Note: Additional Information given to differentiate various models or provides infor­mation for correct system setup.

3

Naming Convention

Naming Convention for SIOM Network Adapters

Networking Adapter List

A O C – MH IBF – 2 Q G

1 – 2 3 – 6 7 8

Character Representation Options

1st Product Family AOC: Add On Card

2nd Form Factor S: Standard, P: Proprietary, C: MicroLP,

3rd Product Type/Speed G: GbE (1Gb/s), TG: 10GbE (10Gb/s), 25G: 25GbE (25Gb/s),

4th C

5th Chipset Manufacturer (Optional) i: Intel, m: Mellanox, b: Broadcom

6th Number of Ports 1: 1 port, 2: 2 ports, 4: 4 ports

7th Connector Type (Optional) S: SFP+/SFP28, T: 10GBase-T, Q: QSFP+, C: QSFP28

8th 2

hipset Model (Optional) N: Niantec (82599), P: Powerville (i350), S: Sageville (X550)

nd

Controller/Connector Type

(Optional)

M: Super IO Module (SIOM), MH: SIOM Hybrid

40G: 40GbE (40Gb/s), 50G: 50GbE (50Gb/s), 100G: 100GbE
(100Gb/s), IBE: EDR IB (100Gb/s), IBF: FDR IB (56Gb/s),
IBQ: QDR IB (40Gb/s), HFI: Host Fabric Interface

G: GbE RJ45, S: 10G SFP+, T: 10GBase-T

SMC Networking Add-on Cards

Model Type Form Factor Controller Connection

SGP-i2 GbE Standard LP Intel® i350 AM2 2 RJ45 (1Gb/port) 3.9” (99mm) x 2.73” (69mm) 3.5

SGP-i4 GbE Standard LP Intel® i350 AM4 4 RJ45 (1Gb/port) 3.9” (99mm) x 2.73” (69mm) 5

STG-b4S 10GbE Standard LP Broadcom® BCM57840S 4 SFP+ (10Gb/port) 5.4” (137mm) x 2.73” (69mm) 14

STG-i2T 10GbE Standard LP Intel® X540-AT2 2 RJ45 (10GBase-T) 5.9” (150mm) x

STGN-i2S 10GbE Standard LP Intel® 82599ES 2 SFP+ (10Gb/port) 4.0” (102mm) x 2.73” (69mm) 11.2

STGN-i1S 10GbE Standard LP Intel® 82598EN 1 SFP+ (10Gb/port) 4.0” (102mm) x 2.73” (69mm) 10

STG-i4S 10GbE Standard LP Intel® XL710-AM1 4 SFP+ (10Gb/port) 5.9” (150mm) x 2.73” (69mm) 8

S40G-i2Q 40GbE Standard LP Intel® XL710 AM2 2 QSFP+ (40Gb/port) 5.9” (150mm) x 2.73” (69mm) 7

PTG-i1S 10GbE Proprietary Intel® 82599EN 1 SF

UG-i4 GbE UIO FH Intel® 82571EB 4 RJ45 (1Gb/port) 6.6” (167mm) x 3.9” (98mm) 10

CGP-i2 GbE MicroLP Intel® i350 AM2 2 RJ45 (1Gb/port) 4.45” (113mm) x 1.54” (39mm) 4

CG-i2 GbE MicroLP Intel® 82580 2 RJ45 (1Gb/port) 4.45” (113mm) x 1.3” (34mm) 4

CIBF-m1 FDR IB MicroLP Mellanox® ConnectX-3 1 QSFP (56Gb/port) 4.85" (123mm) x 1.54" (39mm) 7

CIBQ-m1 QDR IB MicroLP Mellanox® ConnectX-3 1 QSFP

CTG-i1S 10GbE MicroLP Intel® 82599EN 1 SFP+ (10Gb/port) 4.85" (123mm) x 1.54" (39mm) 10

CTG-i2S 10GbE MicroLP Intel® 82599ES 2 SFP+ (10Gb/port) 4.85" (123mm) x 1.54" (39mm) 11

CTG-i2T 10GbE MicroLP Intel® X540 2 RJ45 (10GBase-T) 4.8” (123mm) x 2.75” (77mm) 13

CTGS-i2T 10GbE MicroLP Intel® X550 2 RJ45 (10GBase-T) 4.45” (113mm) x 1.54” (39mm) 12

MGP-i2 GbE SIOM Intel® i350 AM2 2 RJ45 (1Gb/p

MGP-i4 GbE SIOM Intel® i350 AM4 4 RJ45 (1Gb/port) 3.622" (92mm) x 3.428" (87.1mm) 4.4

MTGN-i2S 10GbE SIOM Intel® 82599ES 2 SFP+ (10Gb/port) 3.622" (92mm) x 3.428" (87.1mm) 7.2

MTG-i4S 10GbE SIOM Intel® XL710-AM1 4 SFP+ (10Gb/port) 3.622" (92mm) x 3.428" (87.1mm) 7

Dimension

(w/o Brackets) (L x H)

2.73” (69mm) 13

P+ (10Gb/port) 10.04” (255mm) x .78” (20mm) 7.5

(40Gb/port) 4.85" (123mm) x 1.54" (39mm) 7

ort) 3.622" (92mm) x 3.428" (87.1mm) 3.7

Power

(W)

4

AOC-S40G-i1Q/i2Q User's Guide

Contacting Supermicro

Headquarters

Address: Super Micro Computer, Inc.

980 Rock Ave.

San Jose, CA 95131 U.S.A.

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

Website: www.supermicro.com

Europe

Address: Super Micro Computer B.V.

Het Sterrenbeeld 28, 5215 ML

's-Hertogenbosch, The Netherlands

Tel: [phone]

Fax: [phone]

Email: [e-mail] (General Information)

[e-mail] (Technical Support)

[e-mail] (Customer Support)

Website: www.supermicro.nl

Asia-Pacic

Address: Super Micro Computer, Inc.

3F, No. 150, Jian 1st Rd.

Zhonghe Dist., New Taipei City 235

Taiwan (R.O.C)

Tel: [phone]

Fax: [phone]

Email: [e-mail]

Website: www.supermicro.com.tw

5

Preface

Table of Contents

Naming Convention .....................................................................................................................4

SMC Networking Add-on Cards ..................................................................................................4

Chapter 1 Overview

1.1 Introduction ............................................................................................................................8

1.2 Product Highlights .................................................................................................................8

1.3 Specications ........................................................................................................................9

General ................................................................................................................................9

I/O Features ........................................................................................................................9

Virtualization Features .........................................................................................................9

Storage Interface Features ...............................................................................................10

Manageability Features .....................................................................................................10

Advanced Software Features ............................................................................................10

OS Support .......................................................................................................................10

Cables Support .................................................................................................................11

Power Consumption .........................................................................................................11

Operation Conditions ........................................................................................................11

Physical Dimensions .........................................................................................................11

Compliance/Environmental ................................................................................................11

1.4 SMC Platform Support ........................................................................................................12

Chapter 2 Hardware Components

2.1 Add-On Card Images and Layouts ....................................................................................13

2.2 Major Components .............................................................................................................15

2.3 Connectors: LAN Port and LED Indicators ........................................................................15

Chapter 3 Installation

3.1 Static-Sensitive Devices .....................................................................................................17

Precautions .......................................................................................................................17

Unpacking .........................................................................................................................17

3.2 Before Installation ...............................................................................................................18

3.3 Installing the Add-On Card .................................................................................................18

6

AOC-S40G-i1Q/i2Q User's Guide

3.4 Installing the Add-On Card .................................................................................................19

3.5 Installing the Drivers in Linux .............................................................................................20

Build a Binary RPM Package ............................................................................................20

3.6 Building the Driver Manually ..............................................................................................20

3.7 Returning Merchandise for Service ....................................................................................22

7

AOC-S40G-i1Q/i2Q User's Guide

Chapter 1

Overview

1.1 Introduction

Congratulations on purchasing your add-on card from an acknowledged leader in the industry.
Supermicro products are designed with the utmost attention to detail to provide you with the
highest standards in quality and performance. For product support and updates, please refer
to our website at http://www.supermicro.com/products/nfo/networking.cfm#adapter.

1.2 Product Highlights

The product highlights of this add-on card include the following:

• Low-Prole Standard Short-Length Form Factor

• 1 QSFP+ Port (i1Q model) or 2 QSFP+ Ports (i2Q model)

• PCI Express 3.0 (8GT/s)

• Network Virtualization Ofoads

• Ethernet Flow Director

• Data Plane Developer Kit for Efcient Packet Processing

• Small Packet Performance

• Intelligent Ofoads

• Unied Networking Support for NAS and SAN

• Supports both Direct Attach Copper and Fiber Cables

• Asset Management

• RoHS compliant 6/6

8

1.3 Specications

General

Chapter 1: Overview

• Intel

®

XL710 40GbE controller

• Half-length low-prole standard form factor

• 1 QSFP+ port (i1Q model) or 2 QSFP+ ports (i2Q model)

• PCI-E 3.0 x8 (8 GT/s)

• Load balancing on multiple CPUs

• 40Gb/s per port

• Intel

®

PROSet Utility for Windows® Device Manager

I/O Features

• Intel

®

Flow Director

• MSI-X support

• Tx/Rx IP, SCTP, TCP and UDP checksum ofoading capabilities (IPv4, IPv6)

• Multiple queues: 1,536 Tx and Rx queues per port

Virtualization Features

• Next-generation VMDq with up to 256 VMDq VMs supported

• SR-IOV with up to 128 virtual ports

• Virtual Machine Load Balancing (VMLB)

• Advanced Packet Filtering

• VLAN support for up to 4096 VLAN tags

• VXLAN and NVGARE support

9

AOC-S40G-i1Q/i2Q User's Guide

Storage Interface Features

• Preboot eXecution Environment (PXE) support

• iSCSI remote boot

• iSCSI Acceleration

• Fibre Channel over Ethernet (FCoE)

• Simple Network Management Protocol (SNMP) and remote Network Monitoring (RMON)

static counters

Manageability Features

• Asset Management support on Supermicro

®

X10 generation platforms

• Controller asset tags such as part number, revision, serial number, and MAC address

• Controller thermal sensor

Advanced Software Features

• Teaming support

• IEEE 802.3ad (link aggregation control protocol)

• IEEE 802.1Q VLANs

• IEEE 802.3 2005 ow control support

• IEEE 802.1p

• TCP segmentation/large send ofoad

• Interrupt moderation

OS Support

• Windows

®

Server 2012 R2, 2012, 2008 R2 X86-64

• VMWare ESXi 5.1 and ESXi 5.5 X86-64

• Linux RedHat EL 6.5 nand 7.0 IA-32, X86-64, and IA-64

• Linux SuSe SLES 11 SP3 and 12 IA-32, X86-64, and IA-64

10

• FreeBSD 9 and 10 IA-32, X86-64, and IA-64

Cables Support

• QSFP+ direct attach twinax copper cables up to 7m

• Fiber-optic cables (with required optional transceivers)

Power Consumption

• Typical power consumption: 4.9W

• Maximum power consumption: 7W

Operation Conditions

Chapter 1: Overview

• Operating temperature: 0°C to 55°C (32°F to 131°F)

• Storage temperature: -40° to 70°C (-40°F to 158°F)

• Storage humidity: 90% non-condensing relative humidity at 35°C

Physical Dimensions

• Card PCB dimensions: 14.99cm (5.90in) x 6.90cm (2.72in) (LxH)

• Height of end of brackets: standard - 12cm (4.725in), low-prole - 7.94cm (3.13in)

Compliance/Environmental

• RoHS Compliant 6/6, Pb Free

11

AOC-S40G-i1Q/i2Q User's Guide

1.4 SMC Platform Support

The following platforms are supported by the AOC-S40G-i1Q/i2Q add-on card:

• Supermicro

• Supermicro

Note: This product is intended to be used with Supermicro® server systems. For the
most current product information, visit: www.supermicro.com

®

motherboards with PCI-E x8 slot

®

server systems with low-prole or full-height PCI-E x8 expansion slot

12

Chapter 2

Hardware Components

2.1 Add-On Card Images and Layouts

1

3

Chapter 2: Hardware Components

1

1

1

2

The AOC-S40G-i1Q Image

AOC-S40G-i1Q

REV: 1.00

1

1

LED1

1

2

LAN1

1

3

Intel XL710
LAN Chipset

DESIGNED IN USA

S1

LED3

JP1

JP2

The AOC-S40G-i1Q Layout

Note: All graphics shown in this manual were based upon the latest PCB revision

available at the time of publication of the manual. The motherboard you received may
or may not look exactly the same as the graphics shown in this manual.

13

AOC-S40G-i1Q/i2Q User's Guide

1

1

1

2

1

3

1

4

The AOC-S40G-i2Q Image

1

5

AOC-S40G-i2Q

REV: 1.00

LAN1

1

1

1

2

LED1

1

3

LED2

1

4

LAN2

1

5

Intel XL710
LAN Chipset

DESIGNED IN USA

S1

LED3

JP1

JP2

The AOC-S40G-i2Q Layout

14

Chapter 2: Hardware Components

2.2 Major Components

The following major components are installed on the AOC-S40G-i1Q/i2Q:

1. QSFP Port 1

2. QSFP+ Port 2 (on i2Q model only)

3. LAN LED1

4. LAN LED2 (on i2Q model only)

5. Intel XL710 Controller

2.3 Connectors: LAN Port and LED Indicators

1. LAN Ports

One network LAN port (QSFP+) is located on the add-on card. An additional LAN port is
located on the i2Q model. These LAN ports support connection speeds of 40Gbps and
10Gbps. Plug the Direct Attached Copper (DAC) cable into the QSFP+ port for network
connections.

Note: To make sure that LAN port functions properly, be sure to use the following cable

specied by the manufacturer:

• Direct-attached twin-axial copper cable, or

• Short Range or Long Range ber optic cable used in conjunction with optional optical

transceiver.

The AOC-S40G-i1Q Layout

LED3

JP1

LAN1

AOC-S40G-i1Q

REV: 1.00

LAN1

Intel XL710
LAN Chipset

LED1

LED1

S1

JP2

DESIGNED IN USA

15

AOC-S40G-i1Q/i2Q User's Guide

The AOC-S40G-i2Q Layout

AOC-S40G-i2Q

REV: 1.00

LAN1

LED3

JP1

LAN1

Intel XL710
LAN Chipset

LAN2

LED1

LED2

2. LED Indicators

Each LAN port has a corresponding LED to indicate speed and data activity. LED1 is for LAN
port 1 and LED2 is for LAN port 2 (on i2Q models only). For the location of the LEDs, see

the card layout above. For LED color and denition, see the table below.

LED1

LED2

LAN2

S1

JP2

DESIGNED IN USA

LED Color Denition

LNK

ACT

Yellow 10Gb Link Speed

Green 40Gb Link Speed

Blinking Yellow Activity at 10G speed

Blinking Green Activity at 40G speed

16

Chapter 3: Installation

Chapter 3

Installation

3.1 Static-Sensitive Devices

Electrostatic Discharge (ESD) can damage electronic com ponents. To avoid damaging your
add-on card, it is important to handle it very carefully. The following measures are generally

sufcient to protect your equipment from ESD.

Precautions

• Use a grounded wrist strap designed to prevent static discharge.

• Touch a grounded metal object before removing the add-on card from the antistatic bag.

• Handle the add-on card by its edges only; do not touch its components, or peripheral chips.

• Put the add-on card back into the antistatic bags when not in use.

• For grounding purposes, make sure that your system chassis provides excellent conduc-

tivity between the power supply, the case, the mounting fasteners and the add-on card.

Unpacking

The add-on card is shipped in antistatic packaging to avoid static damage. When unpacking
your component or system, make sure that you are static protected.

Note: To avoid damaging your components and to ensure proper installation, be sure
to always connect the power cord last, and always remove it before adding, removing
or changing any hardware components.

17

AOC-S40G-i1Q/i2Q User's Guide

3.2 Before Installation

To install the add-on card properly, be sure to follow the instructions below.

1. Power down the system.

2. Remove the power cord from the wall socket.

3. Use industry-standard anti-static equipment (such as gloves or wrist strap) and follow
the precautions listed on page 17 to avoid damage caused by ESD.

4. Familiarize yourself with the server, motherboard, and/or chassis documentation.

5. Conrm that your operating system includes the latest updates and hotxes.

3.3 Installing the Add-On Card

Follow the steps below to install the add-on card into your system.

1. Remove the server cover and, if necessary, set aside any screws for later use.

2. Remove the add-on card slot cover. If the case requires a screw, place the screw aside
for later use.

3. Position the add-on card in the slot directly over the connector, and gently push down on
both sides of the card until it slides into the PCI connector.

4. Secure the add-on card to the chassis. If required, use the screw that you previously
removed.

5. Attach any necessary external cables to the add-on card.

6. Replace the chassis cover.

7. Plug in the power cord and power up the system.

18

Chapter 3: Installation

3.4 Installing the Add-On Card

Follow the steps below to install the drivers needed for your Windows® OS support. The
controller comes with a driver on the CD-ROM CDR-NIC.

1. Run the CDR-NIC. (If you do not have a product CD-ROM, download drivers from the
Supermicro Support Website and then transfer them to your system.)

2. When the SUPERMICRO window appears, click on the computer icon next to the
product model.

Note: The graphic below is from the AOC-SG40G-i2Q card. If you are using an i1Q
card, your window may have some slight differences.

Note: If the FOUND NEW HARDWARE WIZARD screen displays on your system,
click CANCEL.

3. Click on INSTALL DRIVERS AND SOFTWARE.

4. Follow the prompts to complete the installation.

19

AOC-S40G-i1Q/i2Q User's Guide

3.5 Installing the Drivers in Linux

Follow the steps below to install the driver to a Linux system.

Build a Binary RPM Package

1. Run ‘rpmbuild -tb <lename.tar.gz>’

2. Replace <lename.tar.gz> with the specic lename of the driver.

Note: For the build to work properly, the current running kernel MUST match the ver-

sion and conguration of the installed kernel sources. If you have just recompiled the

kernel, reboot the system at this time.

3.6 Building the Driver Manually

Follow the instructions below to build the driver manually.

1. Move the base driver tar le to the directory of your choice. For example:

/home/username/ixgbe

or

/usr/local/src/ixgbe

2. Untar/unzip archive, where <x.x.x> is the version number for the driver tar le:

tar zxf ixgbe-x.x.x.tar.gz

3. Change to the driver src directory, where <x.x.x> is the version number for the driver tar:

cd ixgbe-x.x.x/src/

4. Compile the driver module:

make install

The binary will be installed as:

/lib/modules/[KERNEL_VERSION]/kernel/drivers/net/ixgbe/ixgbe.[k]o

The install locations listed above are the default locations. They might not be correct for

certain Linux distributions. For more information, see the ldistrib.txt le included in the

driver tar.

20

Chapter 3: Installation

Note: IXGBE_NO_LRO is a compile time ag. The user can enable it at compile time to
remove support for LRO from the driver. The ag is used by adding CFLAGS_EXTRA=­”DIXGBE_NO_LRO” to the make le when it’s being compiled.

make CFLAGS_EXTRA=”-DIXGBE_NO_LRO” install

5. Load the module:

For kernel 2.6.x, use the modprobe command:

modprobe ixgbe <parameter>=<value>

For 2.6 kernels, the insmod command can be used if the full path to the driver module is

specied. For example:

insmod /lib/modules/<KERNEL VERSION>/kernel/drivers/net/ixgbe/

ixgbe.ko

In addition, when using 2.6-based kernels, make sure that older ixgbe drivers are removed
from the kernel before loading the new module. To do this, use:

rmmod ixgbe; modprobe ixgbe

6. Assign an IP address to the interface by entering the following, where x is the interface
number:

ifcong ethx <IP_address> netmask <netmask>

7. Verify that the interface works. Enter the following, where <IP_address> is the IP
address for another machine on the same subnet as the interface that is being tested:

ping <IP_address>

21

AOC-S40G-i1Q/i2Q User's Guide

3.7 Returning Merchandise for Service

A receipt or copy of your invoice marked with the date of purchase is required before any
warranty service will be rendered. You can obtain service by calling your vendor for a
Returned Merchandise Authorization (RMA) number. When returning the motherboard to
the manufacturer, the RMA number should be prominently displayed on the outside of the
shipping carton, and the shipping package is mailed prepaid or hand carried. Shipping and
handling charges will be applied for all orders that must be mailed when service is complete.
For faster service, you can also request a RMA authorization online (http://www.supermicro.
com/RmaForm/).

This warranty only covers normal consumer use and does not cover damages incurred in
shipping or from failure due to the alternation, misuse, abuse or improper maintenance of
products.

During the warranty period, contact your distributor rst for any product problems.

22

(Disclaimer Continued)

The products sold by Supermicro are not intended for and will not be used in life support systems,
medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency com­munication devices or other critical systems whose failure to perform be reasonably expected to result

in signicant injury or loss of life or catastrophic property damage. Accordingly, Supermicro disclaims

any and all liability, and should buyer use or sell such products for use in such ultra-hazardous ap­plications, it does so entirely at its own risk. Furthermore, buyer agrees to fully indemnify, defend
and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
