INSTRUCTIONS FOR USE

ENGLISH

Article Number 10002115

Power supply 230 V ~ 50 Hz

Nominal power 300 Watt

Electrical protection class II

Net weight 1.3 kg

5 speed settings
1 turbo setting
Stainless steel whisks and dough hook
Short-time operation: 5 minutes

V03a

Hand mixer

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 1

26/07/2013 2:16 PM

2

IMPORTANT SAFETY INSTRUCTIONS

When using electric devices, basic safety precautions must be
observed. To avoid the risk of burns, electric shocks, fire, and/or
personal injury, please read the instruction manual carefully
before using the device, and observe all of the instructions during
the operation of the device.

Store this manual carefully for further use.
Please include this manual when transferring the device to a third
party.

GENERAL INFORMATION

• Electric devices are not toys! Keep children away from this device!!

• Use this device for its intended purpose only.

• This device is suitable for use in private households and not for

commercial use.

• Do not leave this device unattended during use or while it is plugged in.

• Unplug this device from the power outlet after use and before

cleaning.

• Do not carry this device by its power cord.

• Keep this device clean and dust-free.

• Check the device regularly for visible damages. Do not use the device

under any circumstances if you discover damages, if it has fallen or if it
does not function properly. Do not try to repair the device yourself.

• Repairs may only be undertaken by qualified professionals.

RISKS FROM ELECTRICITY:

• The voltage of the device specified on the rating plate must match the
voltage of your electricity network.

• Connect the device to an approved installed outlet. Do not use table
power bars or extension cords.

• Do not operate this device with a timer or remote control.

• Never touch this device, the power cord or the power plug if your

hands are wet or if you are standing on a damp or wet floor.

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS 02
OVERVIEW OF DEVICE 04
PREPARATION INFORMATION 04
BEFORE USE 04
HANDLING 05
SPEED CHART 06
CLEANING AND CARE 06
DISPOSAL 07
SERVICE / WARRANTY 07

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 2

26/07/2013 2:16 PM

3

• If the device becomes damp or wet, pull the plug immediately.

• Keep this device away from water and moisture! There is a risk of

electric shock!

• Do not immerse in water.

• There is a danger of electric shock from immersion in water or other

fluids!

• Keep the device, power cord and power plug away from hot surfaces,
open flame, direct rays of the sun and sharp edges. Make sure that the
cord does not kink during use (e.g. in doors).

• When you pull the plug, always pull by the plug and never the cord.

• If the power cord becomes damaged, it must be replaced by a

qualified professional in order to avoid hazards. The same applies for
the power plug.

HAZARDS TO PERSONS:

• This device is not meant to be used by persons with reduced physical,
sensory or mental abilities or lack of experience and / or lack of
knowledge, unless they are supervised by a person who is responsible
for their safety or have received instructions on how to use this device.

• This appliance shall not be used by children. Keep the appliance and its
cord out of reach of children.

• Children must be supervised in order to ensure that they do not play
with this device.

• Children do not recognise the dangers which could occur in dealing
with electric devices. Keep children away from this device. Be especially
careful when using this device if children are in your midst!

• Keep packaging materials such as plastic bags and polystyrene parts
out of reach of children. Danger of suffocation!

• Make sure when laying the power cord that it cannot be tripped over.

• Make sure that the device itself does not become a tripping hazard.

• Do not point this device toward people or animals!

• Make sure that your hair, loose clothing and the like do not come near

the moving parts of the device during operation.

• Do not insert any objects into the openings or bring them near any
moving parts of the device!

HAZARDS RELATED TO THIS SPECIFIC PRODUCT:

• ATTENTION! Never reach into the rotating mixer inserts.
Danger of injury!

• Keep the power cord away from the rotating mixer inserts.

• Do not lead the power cord through sinks!

• Make sure that the ventilation slits do not become clogged.

• This device is exclusively intended for mixing foods.

• Do not press the eject button for the whisk inserts during operation!

• Use this device only with the included mixer inserts!

• After use, wait until the mixer inserts stop turning and come to a

standstill before taking the device out of the mixing bowl.

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 3

26/07/2013 2:16 PM

4

• Turn the device off and pull the plug before changing, removing,
cleaning or coming into contact with mixer inserts.

• Do not use this device outdoors.

OVERVIEW OF DEVICE

1. Handle

2. Turbo button

3. Speed switch 0 – 5
EJECT mechanism

4. Housing

5. Insertion openings for the whisks
/ dough hooks

6. Power cord with power plug

7. Dough hooks

8. Whisks

PREPARATION INFORMATION

• Prepare the required ingredients. To avoid egg shells from falling in the dough,
for example, they should be put in a separate container in advance.

• The ingredients should be at room temperature or slightly cooled. Do not use
any frozen foods!

• If you would like to beat egg whites, make sure that the bowl and

whisks (8)

are clean and dry. Residues of fat or water can prevent the eggs from being
beaten fluffy.

• To reduce the risk of splashing while mixing, do not use any low mixing bowls

• Keep the necessary ingredients ready near the hand mixer.

BEFORE USE

ATTENTION!

Before inserting the

mixer inserts (7 and 8)

, turn off the device and pull the power

cord!

• Select the appropriate

mixer inserts (7 or 8)

each for the ingredients every time.

• The

dough hooks (7)

are suitable for the preparation of heavy yeast dough
and to knead tougher / heavier ingredients. Even potato dough and fillings of
different sorts can be mixed well with the dough

hooks (7)

.

• The

whisks (8)

are especially suitable for mixing / stirring light doughs, sauces,
custard powder and for making meringue, whipped cream, mayonnaise,
purees, etc.

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 4

26/07/2013 2:16 PM

5

Inserting Dough Hooks / Whisks

• For

dough hooks (7)

the hook with the sealing washer must be inserted into
the larger opening. The hook without the sealing washer must be inserted in
the smaller opening. The two

dough hooks (7)

cannot and must not be inserted

otherwise!

• The

whisks (8)

can be inserted into either

insertion opening (5)

because they

are identical.

• Both

mixing inserts (7, 8)

lock in audibly!

INFORMATION:

So that the device works properly and an unintentional loosening of the

mixer

inserts (7,8)

can be excluded, make sure that they are completely inserted into the

correct holes. The two

mixer insert types (7,8)

cannot be used together. Only the

same type of mixer insert can be used together!

HANDLING

• Insert the desired

mixer inserts (7, 8)

into the

insertion openings (5)

. Make sure

that they are correctly inserted and lock in audibly!

• Attention! Ensure that the

speed switch (3)

is on 0 and that the device is

therefore switched off!

• Insert the

plug (6)

into an approved, properly installed power outlet.

• Hold the device by the

handle (1)

over the mixing vessel so that the

mixer

inserts (7, 8)

are located in the vessel. Please note that inserting and removing

rotating

mixer inserts (7,8)

into the mixing vessel can cause splashing.

• Start the stirring / kneading cycle by putting the

speed switch (3)

on the desired

speed setting (0 – 5).

• Begin mixing at first at the lowest level and increase the speed gradually in
order to prevent the ingredients from splashing out of the bowl. The lowest
level setting should be used for dry ingredients to prevent a dust effect.

• When you press

TURBO (2)

during operation, the device runs full swing

regardless of the power setting.

• In order to prevent the device from overheating, the device should not be used
for longer than 5 minutes of continuous use. The device must be cooled off
before turning it on again.

• Set the

speed switch (3)

back to 0 when finished using and unplug it from the

power outlet.

• To remove the

mixer inserts (7, 8)

push the

speed switch (3)

all the way forward

to EJECT. Make sure that the

mixer inserts (7,8)

do not fly off unintentionally.

• Use a plastic or wooden scraper to remove any possible remaining dough which
is stuck to the

mixing inserts (7,8)

.

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 5

26/07/2013 2:16 PM

6

SPEED CHART

Speed Setting Function Application

1 Knead Kneading

1 Fold To mix dry ingredients or to fold

ingredients such as beaten egg
whites under the dough.
To stir when working at a low-speed
level.

2 Stir To stir liquid foods and the gradual

addition of dry ingredients.

2 Mix To mix prepared cake batter powder.

3 Add To add and stir in further ingredients.

3 Cake mixing To mix prepared cake batter powder

and when the dough must be
processed at a higher speed.

4 Beat To beat butter and sugar in to a

cream.

4 Ice-cream preparation To make soft ice cream and praline

mixtures.

5 Beat To make butter creams or a soft

batter.

5 Meringue To beat eggs and egg whites and for

higher speed processing.

Turbo The device runs at its highest speed.

CLEANING AND CARE

ATTENTION!

Always turn off the device before cleaning and pull the

plug (6)

from the power

outlet.

• The device, power cord and power plug must not be immersed in water or
other liquids for cleaning.

• Do not allow dirt to dry on the device. Clean the

housing (4)

and the

mixer

inserts (7,8)

after each use.

• Always turn off the device and pull the

power plug (6)

before the inserting,

removing or cleaning

mixing inserts (7,8)

or coming into contact with

mixing

inserts (7,8)

with your hands or other objects.

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 6

26/07/2013 2:16 PM

7

• Use plastic or wood scrapers to remove scraps of dough from

mixing inserts

(7,8)

and do not use metal or sharp objects such as knives or forks as these

could damage the

mixing inserts (7,8)

.

• The

mixer inserts (7, 8)

can be washed in the sink. Make sure that they are dried

off thoroughly before you insert them into the device again.

• The

housing (4)

can be wiped off carefully with a damp cloth and then dried off
carefully. Make sure that no water penetrates the device while doing so
(e.g. ventilation slits and control switch).

• Do not use any pot scourers, wire brushes, scour sand or other objects which
may damage the surface when cleaning the device.

• Do not use any solvents or gas for cleaning because they could damage the
housing.

• The

power cord and the plug (6)

may only be wiped with a dry cloth.

DISPOSAL

USED ELECTRIC HOUSEHOLD DEVICES

• If you do not want to use your electrical appliance any longer,
return it free of charge to a recycling depot for used electric
appliances.

• Used electric devices do not belong in the household garbage (see
symbol).

FURTHER DISPOSAL INSTRUCTIONS

• Return the electrical appliance in such a condition that its later
re-use or recycling is not adversely affected. Batteries must be
removed in advance and the destruction of parts which contain
fluids must be avoided.

• Electrical appliances can contain harmful substances. Improper
handling or damage to the appliance can lead to health problems
or water or ground contamination, when the appliance is recycled
later.

SERVICE / WARRANTY

The warranty period covers 3 years and begins with the purchase date. For proof of
the purchase date please retain the receipt.

The warranty covers defects and malfunctions occurring with normal use during the
warranty period.

Warranty repairs are carried out free of charge.

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 7

26/07/2013 2:16 PM

8

The warranty is void in case of damages, alterations or improper use of the device,
where these are not the responsibility of the warranty provider. This applies
especially to the following cases:

• Interference with the device by unauthorized persons.

• Alterations on or in the device, removing or effacing the serial number, removal

or alteration of the device seal.

• Damages due to impact, dropping or external influence.

• Damages due to incorrect handling or improper use.

• Damages due to external causes, e.g. voltage overload, lightning strike.

• Commercial utilization of the device.

Your legal rights in the case of a defective device (replacement, return, reduction,
compensation) are not restricted by this warranty.

Please keep the original packaging in case of a return for repair.
Repaired or exchanged components are generally covered for the remaining
warranty period of the device.

Should you have any questions relating to this product or to the manual or in case
you should find any deficiencies with this product, please contact our service hotline
directly to discuss further steps.

IMPORTANT NOTE:

Please do not send your device to our address without having been requested to.
Always contact our service hotline first.

SERVICE HOTLINE: Phone: [phone]
E-Mail: [e-mail]

ARTICLE NO.: 10002115

PRODUCED FOR:
ZENTRALE HANDELSGESELLSCHAFT - ZHG - MBH
HANNS-MARTIN-SCHLEYER-STRASSE 2
D-77656 OFFENBURG
www.zhg-online.com

MADE IN CHINA

All images serve as illustrations only and do not always show exact representations
of the device.

All rights reserved.

10002115_EB0137884_HM825S_IM_v03a_P130152_26-07-2013_GB.indd 8

26/07/2013 2:16 PM
