Sun Ultra™ 20 Workstation

Getting Started Guide

Sun Microsystems, Inc. www.sun.com

Part No. 819-2148-12 April 2006, Revision A

Submit comments about this document at: http://www.sun.com/hwdocs/feedback

Copyright 2005-2006 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, California 95054, U.S.A. All rights reserved. Sun Microsystems, Inc. has intellectual property rights relating to technology that is described in this document. In particular, and without

limitation, these intellectual property rights may include one or more of the U.S. patents listed at http://www.sun.com/patents and one or more additional patents or pending patent applications in the U.S. and in other countries.

This document and the product to which it pertains are distributed under licenses restricting their use, copying, distribution, and decompilation. No part of the product or of this document may be reproduced in any form by any means without prior written authorization of Sun and its licensors, if any.

Third-party software, including font technology, is copyrighted and licensed from Sun suppliers. FireWire and the FireWire logo are trademarks of Apple Computer, Inc., used under license.

Parts of the product may be derived from Berkeley BSD systems, licensed from the University of California. UNIX is a registered trademark in the U.S. and in other countries, exclusively licensed through X/Open Company, Ltd.

Sun, Sun Microsystems, the Sun logo, AnswerBook2, docs.sun.com, Ultra, Java, and Solaris are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and in other countries.

All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc. in the U.S. and in other countries. Products bearing SPARC trademarks are based upon an architecture developed by Sun Microsystems, Inc.

The OPEN LOOK and Sun™ Graphical User Interface was developed by Sun Microsystems, Inc. for its users and licensees. Sun acknowledges the pioneering efforts of Xerox in researching and developing the concept of visual or graphical user interfaces for the computer industry. Sun holds a non-exclusive license from Xerox to the Xerox Graphical User Interface, which license also covers Sun’s licensees who implement OPEN LOOK GUIs and otherwise comply with Sun’s written license agreements.

U.S. Government Rights—Commercial use. Government users are subject to the Sun Microsystems, Inc. standard license agreement and applicable provisions of the FAR and its supplements.

DOCUMENTATION IS PROVIDED "AS IS" AND ALL EXPRESS OR IMPLIED CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED, EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE LEGALLY INVALID.

Copyright 2005-2006 Sun Microsystems, Inc., 4150 Network Circle, Santa Clara, Californie 95054, Etats-Unis. Tous droits réservés. Sun Microsystems, Inc. a les droits de propriété intellectuels relatants à la technologie qui est décrit dans ce document. En particulier, et sans la

limitation, ces droits de propriété intellectuels peuvent inclure un ou plus des brevets américains énumérés à http://www.sun.com/patents et un ou les brevets plus supplémentaires ou les applications de brevet en attente dans les Etats-Unis et dans les autres pays.

Ce produit ou document est protégé par un copyright et distribué avec des licences qui en restreignent l’utilisation, la copie, la distribution, et la décompilation. Aucune partie de ce produit ou document ne peut être reproduite sous aucune forme, par quelque moyen que ce soit, sans l’autorisation préalable et écrite de Sun et de ses bailleurs de licence, s’il y en a.

Le logiciel détenu par des tiers, et qui comprend la technologie relative aux polices de caractères, est protégé par un copyright et licencié par des fournisseurs de Sun. FireWire et le logo de FireWire sont des marques déposées de Applex Computer, Inc., utilisé sous le permis.

Des parties de ce produit pourront être dérivées des systèmes Berkeley BSD licenciés par l’Université de Californie. UNIX est une marque déposée aux Etats-Unis et dans d’autres pays et licenciée exclusivement par X/Open Company, Ltd.

Sun, Sun Microsystems, le logo Sun, AnswerBook2, docs.sun.com, Java, Ultra, et Solaris sont des marques de fabrique ou des marques déposées de Sun Microsystems, Inc. aux Etats-Unis et dans d’autres pays.

Toutes les marques SPARC sont utilisées sous licence et sont des marques de fabrique ou des marques déposées de SPARC International, Inc. aux Etats-Unis et dans d’autres pays. Les produits portant les marques SPARC sont basés sur une architecture développée par Sun Microsystems, Inc.

L’interface d’utilisation graphique OPEN LOOK et Sun™ a été développée par Sun Microsystems, Inc. pour ses utilisateurs et licenciés. Sun reconnaît les efforts de pionniers de Xerox pour la recherche et le développement du concept des interfaces d’utilisation visuelle ou graphique pour l’industrie de l’informatique. Sun détient une license non exclusive de Xerox sur l’interface d’utilisation graphique Xerox, cette licence couvrant également les licenciées de Sun qui mettent en place l’interface d ’utilisation graphique OPEN LOOK et qui en outre se conforment aux licences écrites de Sun.

LA DOCUMENTATION EST FOURNIE "EN L’ÉTAT" ET TOUTES AUTRES CONDITIONS, DECLARATIONS ET GARANTIES EXPRESSES OU TACITES SONT FORMELLEMENT EXCLUES, DANS LA MESURE AUTORISEE PAR LA LOI APPLICABLE, Y COMPRIS NOTAMMENT TOUTE GARANTIE IMPLICITE RELATIVE A LA QUALITE MARCHANDE, A L’APTITUDE A UNE UTILISATION PARTICULIERE OU A L’ABSENCE DE CONTREFAÇON.

Preface vii

1. Setting Up the Sun Ultra 20 Workstation 1–1

1.1 Safety Information 1–1

1.2 Planning the Installation 1–2

1.3 Unpacking the Workstation 1–3

1.3.1 Front Panel Overview 1–4

1.3.2 Back Panel Overview 1–5

1.4 Cabling the Workstation 1–6

1.5 Powering On the Workstation 1–8

1.6 Powering Off the Workstation 1–9

2. Software Installation 2–1

2.1 Preparing for Installation 2–1

2.1.1 Erasing the Primary Boot Hard Disk 2–3

2.1.2 Setting up the BIOS for Operating System Installation 2–4

2.1.2.1 Setting up the BIOS for Windows XP or Solaris 10 2–4

2.1.2.2 Setting up the BIOS for a Linux Operating System 2–4

2.2 Installing the Operating System 2–5

2.3 Running the up2date Utility 2–6

iii

2.4 Installing Drivers and Mounting the Diagnostic Partition 2–6

2.4.1 Installing Linux Operating System Drivers 2–7

2.4.2 Installing Solaris Operating System Drivers 2–9

2.4.3 Installing Windows XP Operating System Drivers 2–10

2.4.3.1 Installing RAID Drivers Using XPReburn Script 2–11

2.4.3.2 Installing RAID Drivers Using a Boot Diskette 2–12

2.4.4 Installing NVIDIA Display and Chipset Drivers for Windows XP 2–14

3. Setting Up the Preinstalled Software 3–1

3.1 Configuring Solaris 10 Operating System Software 3–1

3.1.1 Licensing Information 3–2

3.1.2 Disk Configuration 3–2

3.1.3 Installation Flowchart 3–2

3.1.4 Configuring the Preinstalled Solaris 10 Operating System 3–3

3.2 Setting Up Preinstalled Development Software 3–5

3.2.1 Sun Studio Software 3–5

3.2.2 Sun Java Studio Creator 3–6

3.2.3 Sun Java Studio Enterprise 3–6

3.2.4 NetBeans IDE 3–7

3.3 Restoring and Backing Up Preinstalled Software 3–7

3.3.1 Restoring Preinstalled Software 3–7

3.3.2 Restoring Solaris Preinstalled Software 3–8

3.3.3 Reinstalling Other Software 3–8

3.3.4 Backing Up the Preinstalled Image to Another Hard Drive 3–9

3.3.5 Hard Drive Mirroring 3–9

A. Creating Windows Images on a RIS Server and Installing RIS Images A–1

A.1 Creating a 32-bit Windows XP (Service Pack 2) RIS Image A–2

A.1.1 Creating the Windows XP SP2 32-bit Image on the RIS Server A–2

iv Sun Ultra 20 Workstation Getting Started Guide • April 2006

A.1.2 Adding the NVIDA Ethernet Drivers to the Windows Image A–3

A.1.3 Adding Other Drivers and Modifying Setting Files A–4

A.2 Creating a 64-bit Windows XP RIS Image A–7

A.2.1 Installing Windows XP 64-bit onto the RIS Server A–7

A.2.2 Adding the NVIDA Ethernet Drivers to the Windows Image A–8

A.2.3 Adding Other Drivers and Modifying Setting Files A–8

A.3 Installing a RIS Image onto a Client Workstation A–12

Contents v

vi Sun Ultra 20 Workstation Getting Started Guide • April 2006

Preface

The Sun Ultra 20 Workstation Getting Started Guide provides the information that you need to set up, power on, and configure the workstation hardware and software.

How This Book Is Organized

This guide is organized into the following chapters:

Chapter 1 contains instructions on unpacking, cabling, and powering on the

workstation.

Chapter 2 describes the operating systems supported by the Sun Ultra 20

Workstation and the supplemental drivers included with the system.

Chapter 3 explains how to set up the preinstalled Solaris™ 10 Operating System and

additional development software.

Appendix A explains how to use the Remote Installation Service (RIS) to create a

Windows XP CD image containing Sun Ultra 20 Workstation drivers.

vii

Shell Prompts

Shell Prompt

C shell machine-name%

C shell superuser machine-name#

Bourne shell and Korn shell $

Bourne shell and Korn shell superuser #

Typographic Conventions

Typeface

AaBbCc123 The names of commands, files,

AaBbCc123 What you type, when contrasted

AaBbCc123 Book titles, new words or terms,

* The settings on your browser might differ from these settings.

Meaning Examples

Edit your.login file. and directories; on-screen computer output

with on-screen computer output

words to be emphasized. Replace command-line variables with real names or values.

Use ls -a to list all files.

% You have mail.

% su

Password:

Read Chapter 6 in the User’s Guide.

These are called class options.

You must be superuser to do this.

To delete a file, type rm filename.

viii Sun Ultra 20 Workstation Getting Started Guide • April 2006

Setting Up the Sun Ultra 20 Workstation

This chapter includes information about the following topics:

■ Section 1.1, “Safety Information” on page 1-1

■ Section 1.2, “Planning the Installation” on page 1-2

■ Section 1.3, “Unpacking the Workstation” on page 1-3

■ Section 1.4, “Cabling the Workstation” on page 1-6

■ Section 1.5, “Powering On the Workstation” on page 1-8

■ Section 1.6, “Powering Off the Workstation” on page 1-9

1.1 Safety Information

Refer to the following document for safety information regarding the Sun Ultra 20 Workstation:

■ Important Safety Information for Sun Hardware Systems, 816-7190-xx (a hard-copy

document is included in the Sun Ultra 20 Workstation ship kit).

■ Sun Ultra 20 Workstation Safety and Compliance Guide, 819-2149-xx (available at

http://sun.com/documentation).

1-1

1.2 Planning the Installation

Use the following flowchart as a process tool to assist you with installation of the Sun Ultra 20 Workstation.

START

Unpack the workstation and familiarize yourself with the workstation features.

Install optional components?

Connect the workstation and external device cables.

Power on the workstation.

Install the operating system or configure the preinstalled operating system.

Install the supplemental drivers from the Sun Ultra 20 Workstation Supplemental CD.

Yes

See Section 1.3, “Unpacking the Workstation” on

page 1-3. Also see Section 1.3.1, “Front Panel Overview” on page 1-4 and Section 1.3.2, “Back Panel Overview” on page 1-5.

To install DIMMs, graphic

Install optional components

See Section 1.4, “Cabling the Workstation” on

page 1-6.

See Section 1.5, “Powering On the Workstation”

on page 1-8.

See Section 2.2, “Installing the Operating

System” on page 2-5 or Chapter 3.

See Section 2.4, “Installing Drivers and

Mounting the Diagnostic Partition” on page 2-6.

accelerators, PCI cards, hard drives, tape drives, or CD or DVD drives, see the Sun

Ultra 20 Workstation User Guide or the component documentation.

READY TO WORK!

FIGURE 1-1 Flowchart for Installing the Sun Ultra 20 Workstation

1-2 Sun Ultra 20 Workstation Getting Started Guide • April 2006

1.3 Unpacking the Workstation

Carefully unpack all workstation components from the packing cartons. The following items are contained in the package.

■ Sun Ultra 20 Workstation

■ Sun Ultra 20 Workstation Documentation, which includes the following:

■ Sun Ultra 20 Workstation Setup Guide

■ Sun Ultra 20 Workstation Release Notes

■ Additional safety and license documentation

■ Sun Ultra 20 Workstation Supplemental CD (includes drivers and diagnostics

software)

■ DMS-59 cable (if the workstation is configured with an NVS280 or NVS285

graphics card)

■ Mouse (for some Sun Ultra 20 Workstation configurations)

An optional country accessory kit, which includes a power cable, keyboard, and a mouse, is packaged separately from the other items (if ordered).

FIGURE 1-2 Sun Ultra 20 Workstation Kit Contents

Chapter 1 Setting Up the Sun Ultra 20 Workstation 1-3

1.3.1 Front Panel Overview

12 3 456

FIGURE 1-3 Front Panel of the Sun Ultra 20 Workstation

TABLE 1-1 Front Panel of the Sun Ultra 20 Workstation

Label Button/LED/Port Label Button/LED/port

1 Power button 4 Two USB ports

2 Power LED 5 Microphone-in jack

3 Two 1394 (FireWire) ports 6 Headphone-out jack

1-4 Sun Ultra 20 Workstation Getting Started Guide • April 2006

1.3.2 Back Panel Overview

4 5

6 7

4 5

6 7

FIGURE 1-4 Back Panel of the Sun Ultra 20 Workstation

TABLE 1-2 Back Panel of the Sun Ultra 20 Workstation

Label Connector/Slot Label Connector/Slot

1 Power connector 7 Ethernet connector

2 Power switch 8 Four USB connectors

3 Onboard HDI15 video connector 9 PCI Express x16 graphics slot

4 Microphone jack 10 Four PCI slots

5 Line-in jack 11 Two PCI Express x1 slots

6 Line-out jack

Chapter 1 Setting Up the Sun Ultra 20 Workstation 1-5

1.4 Cabling the Workstation

FIGURE 1-5 illustrates the cable connections for the workstation.

FIGURE 1-5 Cable Connections

Connect the workstation and external devices in this order:

1. Connect the workstation power cord to a grounded electrical outlet.

2. Connect the keyboard and mouse to the USB connectors on the back panel.

3. Connect the Ethernet cable to the Ethernet connector on the Sun Ultra 20 Workstation, and connect the other end of the cable to an Ethernet RJ-45 jack.

1-6 Sun Ultra 20 Workstation Getting Started Guide • April 2006

4. Connect the monitor cable as follows:

■ If a PCI Express graphics card is not installed in the top PCI slot, connect the

monitor to the onboard video connector. See the top of

■ If a PCI Express graphics card is installed in the top PCI slot, connect the monitor

to the graphics card connector. See the bottom of

FIGURE 1-6.

Your graphics card may require a DVI cable to connect to your monitor. Systems with a NVS280 or NVS285 video card installed include a Dual DVI-I DMS-59 cable (both ends are digital); a VGA to DVI adapter is required to connect to analog monitors.

Note – The onboard video card is disabled by default when a graphics card is

installed. To enable the onboard video card, follow the instructions in the Sun Ultra 20 Workstation User Guide, Appendix B.

Connecting a monitor to the onboard video connector

Connecting a monitor to a PCI Express graphics card connector

FIGURE 1-6 Connecting the Monitor

5. Connect any additional external devices to the workstation’s other connectors.

Chapter 1 Setting Up the Sun Ultra 20 Workstation 1-7

1.5 Powering On the Workstation

Tip – If you are installing optional internal components such as additional DIMMs,

PCI cards, optical drives, or hard drives, install those components before you power on the workstation. If you are not installing optional components, you are ready to power on the workstation.

1. Turn on the power to the monitor and to all external devices.

2. Turn the power switch on the rear of the workstation to the On ( | ) position.

3. Press and release the workstation Power button on the front panel (see FIGURE 1-3).

4. After several seconds, verify that the platform power LED next to the Power button lights.

The platform power LED on the Power button lights after the workstation begins the internal booting process (see

5. If you are powering on the workstation for the first time, install the operating system or configure the preinstalled operating system after the system is finished booting.

■ See Chapter 2 for information about installing an operating system.

■ See Chapter 3 for information about configuring the preinstalled Solaris 10

operating system.

FIGURE 1-3).

1-8 Sun Ultra 20 Workstation Getting Started Guide • April 2006

+ 40 hidden pages
