Number of Instances of an Application 10
What If I Get an Error Message When Starting an Application? 11
Suspending and Resuming Applications 11
iii
Session Toolbars for Controlling an Application 11
Resumability Settings for Applications 12
Do I Lose My Work If I Close My Browser? 13
Changing the Way an Application is Displayed 13
Copying Information Between Applications 14
Running Applications Using a Different User Name and Password 14
Using a Single-Button Apple Macintosh Mouse 15
Printing 15
Managing Your Print Jobs 15
Printing From UNIX Platform Applications 16
Printing from UNIX Platform Applications to UNIX, Linux, or Mac OS X
Platform Computers 16
Printing from UNIX Platform Applications to a Windows Computer 17
Printing From Windows Applications 17
Printing from Windows Applications to UNIX, Linux, or Mac OS X
Platform Computers 18
Printing from Windows Applications to a Windows Computer 18
PDF Printing 19
Using PDF Printing 19
Printing Troubleshooting 20
Changing Your Settings 20
Client Settings 21
Editing Profiles 21
Application Groups 21
▼ How To Create a Group 22
Using SGD From Your Desktop Start or Launch Menu 23
▼ How to Add SGD to Your Desktop Start or Launch Menu 24
Working With the Start or Launch Menu 24
Logging In 25
iv Sun Secure Global Desktop 4.5 User Guide • April 2009
Displaying a Webtop 25
Running Applications 26
Printing 26
Using Application Groups 26
Using My Desktop 26
Logging Out 27
Logging Out of the SGD Webtop 27
Logging Out Using the Start or Launch Menu 27
A. Installing the SGD Client Manually 29
Installing the SGD Client 29
▼ How to Install the SGD Client Manually on Microsoft Windows
Platforms 30
▼ How to Install the SGD Client Manually on Solaris OS and Linux
Platforms 31
Logging In Using the SGD Client 32
▼ How to Configure the SGD Client 32
B. Advanced Configuration 35
Client Settings 35
Changing the Login Page URL 36
Changing the Language 36
Changing Proxy Settings 36
Specifying an Alternative PDF Viewer 36
Printing 37
Configuring Your Client Printers 37
Accessing the Drives on Your Computer 38
C. Profile Settings 39
Description of Profile Settings 39
Configuring Integrated Mode Operation 41
Contents v
Glossary 43
Index 47
vi Sun Secure Global Desktop 4.5 User Guide • April 2009
Preface
The Sun Secure Global Desktop 4.5 User Guide provides an introduction to using Sun
Secure Global Desktop software (SGD). The manual provides information on how
you can use SGD to run applications. This document is intended for both new and
existing users of SGD.
How This Book Is Organized
Chapter 1 describes how to use SGD to run applications from your computer.
Appendix A describes how to install the SGD Client manually on your computer.
Appendix B discusses configuration settings for advanced users of SGD.
Appendix C describes the available profile settings.
A Glossary of words and phrases and their definitions is also included.
Related Documentation
The following table lists the documentation for this product. The online
documentation is available at:
vii
http://docs.sun.com/app/docs/coll/1706.4
Application Title Part Number Format Location
Release Notes Sun Secure Global Desktop 4.5
Release Notes
Installation Sun Secure Global Desktop 4.5
Installation Guide
Administration Sun Secure Global Desktop 4.5
Administration Guide
User Sun Secure Global Desktop 4.5 User
Guide
Proxy Server Sun Secure Global Desktop 4.5
Gateway Administration Guide
Third-Party Web Sites
Sun is not responsible for the availability of third-party web sites mentioned in this
document. Sun does not endorse and is not responsible or liable for any content,
advertising, products, or other materials that are available on or through such sites
or resources. Sun will not be responsible or liable for any actual or alleged damage
or loss caused by or in connection width the use of or reliance on any such content,
goods, or services that are available on or through such sites or resources.
820-6687-10 HTML
PDF
820-6688-10 HTML
PDF
820-6689-10 HTML
PDF
820-6690-10 HTML
PDF
820-6691-10 HTML
PDF
Online
Software CD and online
Online
Software CD and online
Online
Online
Online
Sun Welcomes Your Comments
Sun is interested in improving its documentation and welcomes your comments and
suggestions. You can email your comments to Sun at:
docfeedback@sun.com
Please include the following document title and part number in the subject line of
your email:
Sun Secure Global Desktop 4.5 User Guide, part number 820-6690-10.
viii Sun Secure Global Desktop 4.5 User Guide • April 2009
CHAPTER
1
Using Sun Secure Global Desktop
Sun Secure Global Desktop software (SGD) provides you with secure, remote access
to desktop applications running on application servers.
You can be writing a report on a computer in the office, administering UNIX
platform servers on your PC at home, or checking stock databases with a laptop on
the train, SGD enables you do all this.
SGD also enables you to run applications over a secure network connection to
safeguard corporate and private data.
With SGD, you access all the applications that you can run from a single place, the
webtop.
To access a webtop, all you need is a browser with Java™ technology enabled.
®
This manual guides you through the basics of using SGD. It describes how to log in
and log out of the software, as well as how you can use SGD to run applications.
Logging In
This section describes how to log in to SGD and display the SGD webtop.
User Names and Passwords
When you use SGD, you need to know your user name and password for the
following servers:
■ The SGD server
■ The application servers that run your applications
1
The following table describes the user names and passwords you might require
when using SGD.
User Name and Password Description
SGD server When you log in to SGD, you need to type a user name and
password so that the SGD server knows who you are and can
display your webtop. You do not need to type this password again
until the next time you log in to SGD.
You might also be able to log in to SGD anonymously, that is,
without typing a user name and password.
Application servers When you start an application, you might need to supply a
password for the application server that runs it. The SGD server
can remember these passwords, so you do not need to type them
every time. Use the Save This Password option, if available, when
you type your user name and password.
If you want to use a different user name and password to run an
application, you can force SGD to prompt you.
▼ How to Log In to SGD
Before you log in to SGD, ensure that the following requirements are met:
■ JavaScript™ software is enabled in your browser
■ Java technology is enabled in your browser
Note – If Java technology is not enabled in your browser, you can download the
SGD Client program to your computer. See “Installing the SGD Client” on page 29
for more details.
■ You have a user name and password for the SGD server. Contact your SGD
Administrator if you do not know your user name and password.
■ You know the login Uniform Resource Locator (URL) for the SGD server. Contact
your SGD Administrator if you do not know the URL for the SGD login page.
1. Using your browser, go to the SGD login URL.
The SGD login URL is usually http://server.example.com/sgd, where
server.example.com is the name of the SGD server.
Note – If Java technology is not enabled in your browser, a warning message is
shown. You must enable Java technology in your browser before proceeding.
The SGD Login dialog box is shown. See
2 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-1.
FIGURE 1-1 SGD Login Dialog Box
Note – If JavaScript is not enabled in your browser, a warning message is displayed
beneath the login dialog box.
2. Type in your SGD user name and password.
3. Click the Login button.
While SGD is starting up, the splash screen is shown. See
Chapter 1 Using Sun Secure Global Desktop 3
FIGURE 1-2.
FIGURE 1-2 SGD Splash Screen
The Initial Connection dialog box is shown. This is a security message that is
shown the first time you connect to an SGD server. See
FIGURE 1-3 Initial Connection Dialog Box
FIGURE 1-3.
4. (Optional) Click the View Certificate button.
The Certificate Details dialog box is shown. This screen enables you to view
security certificate details, to ensure that the server you are connecting to can be
trusted. See
4 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-4.
FIGURE 1-4 Certificate Details Dialog Box
a. Check that the Validity and Subject fields are correct.
b. Click Close.
The Initial Connection dialog box is redisplayed.
5. If the certificate details are correct, click Yes to agree to the connection.
Once you have clicked Yes, you do not see the security message again unless
there is a problem with the connection.
The SGD Client icon is displayed in the task bar, as shown in
FIGURE 1-5.
FIGURE 1-5 SGD Client Task Bar Icon
The SGD webtop is displayed. See FIGURE 1-7.
Potentially Unsafe Connection Message
If there is a security problem with the connection to the SGD server, a Potentially
Unsafe Connection message is displayed, as shown in
Chapter 1 Using Sun Secure Global Desktop 5
FIGURE 1-6.
FIGURE 1-6 Potentially Unsafe Connection Message
If you see a Potentially Unsafe Connection message, do the following.
▼ How To Deal With a Potentially Unsafe Connection
Message
1. Click the View Certificate button and make a note of the certificate details.
2. Click the Reject button to cancel the connection and contact your SGD
Administrator.
The SGD Webtop
Your webtop is a special web page that lists the applications you can run through
SGD and enables you to run them.
FIGURE 1-7 shows the different areas of the webtop.
6 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-7 SGD Webtop
# Name Description
1 Menu bar Includes Logout, Help, and Info buttons
2 Applications area Lists the applications that you can run
3 Printing area Enables you to manage your print jobs
4 Information area Displays error messages and system information
The different areas of the webtop are described in the following sections.
Menu Bar
This area of the webtop includes buttons for logging out and for displaying help and
diagnostics information.
See “Logging Out” on page 27 for more information about logging out of SGD.
Chapter 1 Using Sun Secure Global Desktop 7
From the webtop, you can display a page containing diagnostics information. This is
useful if you need to contact Support.
Click the Info button on your webtop and then click the Detailed
Diagnostics link in the Information area.
Applications Area
The Applications area of the webtop is used to display the list of applications that
you can run through SGD.
See “Using Applications” on page 9 for more information about running
applications.
Only an SGD Administrator can add an application to, or remove an application
from, the list of applications that you can run. If you want more applications, contact
an SGD Administrator. However, you can choose how and when your applications
display on your webtop. You do this by creating webtop groups. See “Application
Groups” on page 21.
Printing Area
The Printing area of the webtop includes links that enable you to list and control
your print jobs.
See “Printing” on page 15 for more information about printing.
Information Area
The Information area is used to display error messages and system information. The
information displayed includes the following:
■ User name
■ Secure connection status
User Name
Your SGD user name is displayed on the webtop toolbar, next to the padlock symbol,
as shown in
8 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-8.
FIGURE 1-8 User Name Displayed on the Webtop Toolbar
If the toolbar says you are logged in as “Guest user” then you either logged in
without typing a user name and password, known as an anonymous login, or you
are using a webtop that is shared with other users.
These details also display on the webtop when you first log in.
Secure Connection Status
If you have a secure connection, the locked padlock symbol is displayed below
the webtop menu bar. Also, when you first log in, the page that is displayed on the
webtop tells you whether you have a secure or a standard connection.
Secure connections to SGD are available only if an SGD Administrator has enabled
them.
You might not automatically receive a secure connection, or you might only get a
secure connection under certain circumstances. Contact your SGD Administrator if
you do not get a secure connection when you need one.
Using Applications
Use the Applications area of the webtop to start, stop, and manage your
applications.
Running Applications
To start an application, you click its link on your webtop, as shown in FIGURE 1-9.In
a few moments the application is shown, ready for you to use.
FIGURE 1-9 Webtop Link for Running an Application
When you start an application, you might be asked for a user name and password.
This is your user name and password for the application server that runs the
application.
Chapter 1 Using Sun Secure Global Desktop 9
You do not have to exit an application before starting another. Just click another link.
SGD Administrators configure how the applications display.
Note – You cannot start a Windows application using a different Windows domain
name. Ask an SGD Administrator to do this for you.
If you have difficulties, contact your SGD Administrator.
You can also run your applications using links in the desktop Start or Launch Menu.
See “Using SGD From Your Desktop Start or Launch Menu” on page 23 for more
details.
Number of Instances of an Application
When an application is running, a triangle appears in front of the application’s name
on the webtop and a number appears in brackets after it. The session toolbar also
appears below the application name. The session toolbar is used to suspend, resume,
or end an application.
application are running.
FIGURE 1-10 Webtop Link When the Application is Running
FIGURE 1-10 shows the webtop link when two instances of an
The number in brackets is the number of separate instances of the application that
you have started. SGD Administrators configure how many instances of an
application you can start. To find out how many instances of an application you are
allowed, point to its link on the webtop. The popup that is displayed states the
number of sessions allowed.
See “Suspending and Resuming Applications” on page 11 for more details.
What If I Get an Error Message When Starting an Application?
If an error message is shown when you click a link to start an application, try one of
the following:
10 Sun Secure Global Desktop 4.5 User Guide • April 2009
■ Make sure you supplied the correct user name and password for the application
server. If SGD does not prompt you for this information, hold down the Shift key
and click the link to force the prompt to appear.
■ Log out of SGD and exit your browser, then restart it and log in to SGD again.
Click the application’s link.
■ Contact an SGD Administrator, supplying all the information shown in the error
message.
Suspending and Resuming Applications
Some applications can be configured to keep running, even when they are not
displayed. These are “resumable” applications.
To close an application’s window without ending the application, you suspend the
application. To display the window again and start using the application, you resume
the application.
As an application is still running even though it is not displayed, you can start
writing an urgent report in the office and then log out of SGD at the end of the day.
The application is suspended. When you get home, you can log in to SGD again,
resume the application and carry on writing the report.
Suspending and resuming applications is done using the session toolbars on the
webtop.
Session Toolbars for Controlling an Application
There is a separate session toolbar for each running instance of the application:
■ Click to suspend an application
■ Click to resume an application
■ Click to end an application
Click the triangle to hide and show the session toolbars for the application sessions,
as shown in
FIGURE 1-11 Session Toolbar when Hidden
You can manage all your application sessions at once, using the following links at
the top of the Applications area:
■ Click the Suspend All link to suspend all running applications
FIGURE 1-11.
Chapter 1 Using Sun Secure Global Desktop 11
■ Click the Resume All link to resume all suspended applications
■ Click the Cancel All link to end all running or suspended applications
FIGURE 1-12 Links for Managing All Application Sessions
Resumability Settings for Applications
To see if an application is resumable or not, point to its link on your webtop and
look at the popup window that is displayed.
The available resumability settings for an application are described in the following
table.
Resumability Settings Description
Not Resumable This application exits when you log out of SGD. You cannot
suspend or resume non-resumable applications.
Note - Non-resumable applications only have a Cancel button in
the session toolbar.
Resumable Until Log
Out
Always Resumable This application continues running even after you have logged
This application continues running until you log out of SGD.
While you are logged in, you can suspend and resume these
applications.
out of SGD. When you log in again, click the Resume button to
display the running application again.
Note – If you log in to SGD without typing a user name and password, resumable
applications are only resumable until you log out.
Do I Lose My Work If I Close My Browser?
No, you do not lose any work if you accidentally close your browser without
logging out, or if your browser crashes. You can restart your browser and log in to
SGD to display your webtop.
12 Sun Secure Global Desktop 4.5 User Guide • April 2009
However, if the SGD Client exits unexpectedly, or if you close down the SGD Client,
your ability to resume an application depends upon how your SGD Administrator
configured the application and how you logged in to SGD.
■ If an application is configured to be “Not Resumable”, then it exits when the SGD
Client exits or is closed down. Typically, applications are configured to be Not
Resumable if they are used only for short periods at a time, and are not
business-critical functions.
■ Applications configured to be “Always Resumable”, or “Resumable Until Log
Out”, continue to run for a period of time after an SGD Client exits or is closed
down. Simply restart your browser, log in to SGD again and resume the
applications that are still running.
■ If you logged in to SGD anonymously, in other words you did not supply a user
name and password, or you are using a shared webtop, where more than one
person logs in using the same user name and password, then your applications
exit if the SGD Client exits or is closed down. In both cases, the reason for this is
that SGD cannot tell when you log in to SGD again that you are the same user as
before, because you are not using a unique user name and password. See also
“User Name” on page 8.
Changing the Way an Application is Displayed
Your SGD Administrator defines how an application is displayed on your desktop.
For example, if the application is displayed full-screen or in a desktop window.
A graphical application that is displayed in a desktop window can be scaled to fit
the size of the window. If you resize the window, SGD rescales the application to fit
the new window size, without displaying any scroll bars.
You can switch the application between being scaled and not being scaled by
pressing the Scroll Lock key.
To see if an application is displayed in a scalable window, point to its link on your
webtop and look at the popup that is shown. Alternatively, look in the status bar at
the bottom of the window.
Copying Information Between Applications
For Windows applications and X applications, use the normal method for the
application you are copying from, and then the usual method for the application you
are pasting to. You might not be allowed to copy and paste information from
particular applications. This is configured by your SGD Administrator. If you are not
allowed to copy and paste between an application, the following message is pasted
instead of the information you copied:
Chapter 1 Using Sun Secure Global Desktop 13
Sun Secure Global Desktop Software: Copied data not available
to this application
For character applications, click with the right mouse button, and then click Copy or
Paste as appropriate. To select a column of text, hold down the Shift key while
selecting the text.
You can copy information between different types of application, for example from
an xterm running on an application server to a text editor running on your
computer.
You can only copy and paste graphics to or from Windows applications.
Running Applications Using a Different User Name and Password
To force SGD to prompt you for a user name and password when you start an
application, hold down the Shift key when you click the application’s link on your
webtop.
Forcing SGD to prompt you for a user name and password in this way means that
SGD does not use any user name and password that has already been saved for the
application server. This is useful if you want to run an application as another user.
If the Save This Password check box is selected, the new user name and password
are saved, replacing any previously saved user name and password for you on this
application server. This user name and password is used for any other applications
you run on this application server.
Holding down the Shift key has no effect in the following cases:
■ When you are logged in to SGD anonymously, or as a shared user.
■ When the link for starting an application is in your desktop Start or Launch
Menu. The Shift key prompt only works for links on a webtop.
Using a Single-Button Apple Macintosh Mouse
Many Microsoft Windows applications and X applications make use of a middle
mouse button or a right mouse button. To use these applications from an Apple
Macintosh mouse with one button, click the button while holding down one of the
following keys on the keyboard:
■ To simulate a middle mouse button click, press Alt while clicking the mouse
button
14 Sun Secure Global Desktop 4.5 User Guide • April 2009
■ To simulate a right mouse button click, press Command while clicking the mouse
button
Printing
SGD enables you to print from your applications to a printer attached to your
computer.
Usually, you can choose the printer you want to print to. However, for some
applications you might only be able to print to your default printer.
Managing Your Print Jobs
You use the Printing area of the webtop to manage your print jobs. The Printing area
shows the number of jobs currently in the print queue and includes controls for
managing your print jobs, as shown in
FIGURE 1-13 Printing Area of the SGD Webtop
FIGURE 1-13.
When documents are printing, the webtop tells you how many print jobs are in the
queue.
Click the Pause link to temporarily stop printing. The printer icon changes to show
you when printing is paused, as shown in
FIGURE 1-14 Printing Paused Icon
If you pause printing, any print jobs that are pending are held in a queue until you
either cancel them or resume printing.
Click the Resume link to start printing again after you have paused printing.
Click the Cancel All link to delete all your print jobs.
FIGURE 1-14.
Chapter 1 Using Sun Secure Global Desktop 15
To manage print jobs individually, click the List All Jobs button. The webtop
displays a list of all the print jobs in the queue, along with information about the job.
For example, the number of copies and the printer to use.
If you have paused printing, click to print just that one print job.
To cancel a print job, click .
Printing From UNIX Platform Applications
SGD enables you to print from UNIX platform applications to a printer attached to
your computer.
Printing from UNIX Platform Applications to UNIX, Linux, or Mac OS X Platform Computers
From a terminal window on the application server, you can print a file to your
default printer by typing the following command:
$ lp file
Alternatively, you can specify any client printer that your SGD Administrator has
configured.
For example, if a client printer named salesprinter has been configured by your
SGD administrator, you can use the following command:
$ lp -d salesprinter file
Printing from UNIX Platform Applications to a Windows Computer
The following command prints file to your default printer on the Windows
computer:
$ lp file
You can also print to a port on the computer. For example:
$ lp -d LPT1: file
16 Sun Secure Global Desktop 4.5 User Guide • April 2009
You can also print by specifying the universal naming convention (UNC) name of a
network printer that is accessible from the computer. To use a UNC name, you must
enclose the printer name in quotes and escape backslashes as appropriate for the
shell. For example:
$ lp -d ’\\\\PRTSERVER\\HPLJ5’ file
To avoid problems with UNC names, you can print using a “friendly” name such as:
$ lp -d label-printer file
In this case, the friendly name must be configured by your SGD Administrator.
Printing From Windows Applications
SGD enables you to print from Windows applications to a printer attached to your
computer.
Printing from Windows Applications to UNIX, Linux, or Mac OS X Platform Computers
If you print from a Microsoft Windows application to a UNIX, Linux, or Max OS X
platform computer, you see the client printers that have been configured by your
SGD Administrator.
In the application server’s Print dialog box, the printers on your computer are
designated by “Sun SGD” in the printer name, as shown in
Chapter 1 Using Sun Secure Global Desktop 17
FIGURE 1-15.
FIGURE 1-15 Microsoft Windows Print Dialog Box, With an SGD Client Printer Selected
See “Configuring Your Client Printers” on page 37 for more information on how you
can configure your own client printers.
Printing from Windows Applications to a Windows Computer
If you print from a Microsoft Windows application to a Microsoft Windows
computer, you see some, all, or none of the printers that are attached to the client
and also the printers that are attached directly to the application server. The SGD
Administrator configures the client printers you can see.
In the application server’s Print dialog box, the printers on your client are
designated by “Sun SGD” in the printer name, as shown in
PDF Printing
With SGD you can also use Portable Document Format (PDF) printing. This avoids
many problems with print drivers by using the Adobe PDF format.
SGD has two PDF printers: Universal PDF Printer and Universal PDF Viewer.
18 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-15.
On Microsoft Windows computers, the Universal PDF Printer printer displays the
print job as a PDF file in Adobe Reader, which then prints the PDF file to your
default printer. The Universal PDF Viewer printer displays the print job as a PDF file
in Adobe Reader. You can then decide whether to print or save the PDF file.
On UNIX, Linux, and Mac OS X platform computers, there is no difference between
the Universal PDF Printer and Universal PDF Viewer printers, as the print job is
always displayed as a PDF file in a PDF viewer. You can then decide whether to
print or save the PDF file.
Using PDF Printing
From a Windows application, you print in the normal way and select either the
Universal PDF Printer or the Universal PDF Viewer printer in the application’s Print
dialog box.
From an application running on a UNIX or Linux platform application server, you
print in the normal way, specifying a PDF printer as part of the print command. For
example:
$ lp -d "Universal PDF Printer" file
$ lpr -P "Universal PDF Viewer" file
The file must be a PostScript file, so the application must be able to output
PostScript.
On Windows computers, the PDF file is displayed in the Adobe Reader. Depending
on the printer you select, either of the following applies:
■ If the Universal PDF Printer printer is selected, the PDF file is printed
automatically to your default printer. The Adobe Reader runs minimized and
does not exit when the print job has finished.
■ If the Universal PDF Viewer printer is selected, the PDF file is displayed in the
Adobe Reader window. You can then decide whether to print or save the file.
On UNIX, Linux, and Mac OS X platform computers, the PDF file is displayed in a
PDF viewer. You can then decide whether to print or save the PDF file. There is no
difference between the Universal PDF Printer and the Universal PDF Viewer
printers, as the print job is always displayed in a PDF viewer.
Chapter 1 Using Sun Secure Global Desktop 19
Printing Troubleshooting
If you print from an application and the output does not appear, check the
following.
Possible Cause More Information
Have You Paused Printing? Make sure that your webtop indicates that printing is
not paused. See “Printing Paused Icon” on page 16.
Is Your Printer Set Up Correctly? Make sure your printer is set up correctly. For
example, by printing a web page to the printer from a
browser.
Have You Printed To the Correct
Printer?
Is the Message “No Client Printer
Available” Displayed?
You can choose a printer to print to. If you do not
select a printer, output is sent to your default printer.
To see which printer is your default printer, point to
the printer icon on your webtop. A popup shows the
name of your default printer.
If you want to change your default printer, you must
log out of SGD, change the default printer, then log in
to SGD again.
Make sure that your webtop does not display a “No
Client Printer Available” message and that the printer
icon does not contains a red X. This means that SGD
does not support printing for your computer or for
your printer.
Your SGD Administrator might be able to help enable
printing.
If none of the above solves your printing problem, contact your SGD Administrator.
Changing Your Settings
You can configure the following settings by clicking on the Edit button in the
Applications area:
■ Client settings
■ Application Groups
20 Sun Secure Global Desktop 4.5 User Guide • April 2009
Client Settings
Each time the SGD Client starts it uses a profile. A profile is a group of configuration
settings that control the SGD Client. The settings in a profile define the following:
■ How the SGD Client connects to an SGD server. For example, the URL to connect
to and the proxy server to use.
■ The operating mode of the SGD Client. For example, whether to display a
webtop or whether the list of applications that you can run is displayed in the
desktop Start or Launch Menu, known as Integrated mode.
■ How the SGD Client behaves. For example, if it loses a connection to an SGD
server.
You have one profile for each SGD server you connect to.
The available client settings are described in Appendix C.
Editing Profiles
You can only edit profiles if your SGD Administrator has configured SGD to let you
do this.
You can only edit profiles from a webtop. On your webtop, click the Edit button in
the Applications area of the webtop, and then click the Client Settings tab.
You can only edit your own profiles, and you can only edit the profile for the SGD
server you are currently connected to.
When you first edit a profile, the settings are the ones that your SGD Administrator
has configured for you.
To restore a profile to the system default settings, click the Reset button.
Note – You must log out of SGD and log in again for changes to your profile to take
effect.
Application Groups
Only an SGD Administrator can add an application to, or remove an application
from, the list of applications that you can run. However, you can choose how and
when those applications display on your webtop. You do this by creating groups.
Groups are useful for grouping similar applications together or for hiding
applications you do not use very often. How you use groups is up to you.
Chapter 1 Using Sun Secure Global Desktop 21
▼ How To Create a Group
1. On the webtop, click the Edit button.
2. Click the Edit Groups tab.
3. Click the Add New Group button.
Type a name for the group.
In Choose Your Content, select the check boxes for the applications and
documents you want to include in the group.
4. Set the display options for the group.
To hide the applications and the group so that they do not display on your
webtop, you deselect the check box next to I Want to See This Group on My
Webtop When I Log In.
To hide the contents of the group so that only the group name is displayed when
you first log in, you deselect the check box next to I Want to See the Contents of
This Group When I Log in.
FIGURE 1-16 Creating a New Group Using the Edit Groups tab
5. Click the Save Group button.
6. Click the Update button.
The names of the webtop groups you create are displayed on the webtop.
22 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-17 Group Displayed on a Webtop, Showing Group Contents
A separator line to show you which applications are in the group is also
displayed.
7. Click the triangle to hide and show the applications in the group.
FIGURE 1-18 Group Displayed on a Webtop, Hiding Group Contents
You can add as many groups as you like. You can change or delete a group
whenever you like. After making a change you must click Update.
Using SGD From Your Desktop Start or Launch Menu
You can use SGD from your desktop Start or Launch Menu. This is called Integrated
mode. When you use SGD in Integrated mode, the links for starting applications
display in your desktop Start or Launch Menu, instead of on your webtop. This
means you can run applications through SGD in the same way as applications
installed on your computer.
▼ How to Add SGD to Your Desktop Start or
Launch Menu
To add SGD to your desktop Start or Launch Menu, you usually have to perform an
initial login to display a webtop, and then edit your profile.
Chapter 1 Using Sun Secure Global Desktop 23
1. Start a browser and go to the SGD login URL.
The SGD login URL is at http://server.example.com/sgd, where
server.example.com is the name of the SGD server.
2. Log in and display a webtop.
3. Edit your profile as follows.
a. Click the Edit button in the Applications area of the webtop, and then click
the Client Settings tab.
b. Select the Add Applications to Start Menu check box.
c. To start the SGD Client when you log in to your desktop, select the Connect
on System Login check box.
d. (Optional) If you want the SGD Client to log you in automatically to SGD
when it starts, select the Automatic Client Login check box.
Your SGD Administrator can tell you whether you can use automatic logins.
e. (Optional) Configure the proxy server settings.
Your SGD Administrator can tell you what proxy server settings to use.
f. Click Save.
4. Log out of SGD.
Working With the Start or Launch Menu
This section describes the how you do the following tasks using the desktop Start or
Launch Menu.
■ Logging in
■ Running applications
■ Printing
■ Displaying a webtop
■ Using application groups
Logging In
You log in to SGD by clicking the Login link on your desktop Start or Launch Menu.
See
FIGURE 1-19.
24 Sun Secure Global Desktop 4.5 User Guide • April 2009
FIGURE 1-19 Logging In Using the Desktop Start or Launch Menu
Note – If you log in to more than one SGD server, there is a Login link for each
server in the Start or Launch Menu.
Once you have logged in to SGD, the Start or Launch Menu is updated with the
links for the applications you can run through SGD, as shown in
To use SGD in Integrated mode, you always log in using the Start or Launch Menu.
If you start a browser and log in, your applications are not displayed in the Start or
Launch Menu.
FIGURE 1-20 Webtop Content Links in the Desktop Start or Launch Menu
FIGURE 1-20.
Displaying a Webtop
If you need to display a webtop, for example to be able to edit your profile, resume
a suspended application or manage printing, you click the Webtop link in the Start
or Launch Menu. The webtop is displayed in your default browser.
Running Applications
To start an application, you click its link on the Start or Launch Menu. To start
another instance of the application, you click the link again.
Chapter 1 Using Sun Secure Global Desktop 25
Unlike the webtop, you cannot suspend and resume individual applications.
Instead, when you log out of SGD, your running applications are either suspended
or ended, depending on their resumability settings. See “Suspending and Resuming
Applications” on page 11. When you log in again, any suspended applications you
have are resumed automatically.
See “Using Applications” on page 9 for more information about running
applications using SGD.
Printing
You cannot manage individual print jobs from the Start or Launch Menu and so
print jobs go straight to the selected printer.
See “Printing” on page 15 for more information about printing using SGD.
Using Application Groups
If you have arranged any of your webtop content to display in groups, those groups
are also used in the Start or Launch Menu. If the group is configured to hide webtop
content, the content does not display in the Start or Launch Menu.
Using My Desktop
My Desktop is a feature that enables you to log in and display a full-screen desktop
application, without displaying your webtop.
My Desktop displays the desktop application configured for you by an SGD
Administrator, for example, a Microsoft Windows desktop.
You start My Desktop by clicking the My Desktop link on the SGD web server
Welcome page, at http://server.example.com. This link displays the SGD Login
page. Once you have logged in, the My Desktop full-screen desktop application is
displayed.
An alternative way to start My Desktop is by going to
http://server.example.com/sgd/mydesktop.
After starting My Desktop, you can close the browser window.
26 Sun Secure Global Desktop 4.5 User Guide • April 2009
Note – You cannot suspend or resume your My Desktop application. You must log
out of the desktop application as normal.
Logging Out
The log out procedure varies, depending on whether you are using the SGD webtop
or you are using SGD from the desktop Start or Launch Menu.
Logging Out of the SGD Webtop
Always log out of SGD before closing your browser.
Click the Logout button on your webtop and click OK when prompted for
confirmation. See
FIGURE 1-21 Log Out Button on the Webtop
FIGURE 1-21.
Logging Out Using the Start or Launch Menu
To log out of SGD in Integrated mode, you click the Logout link on the Start or
Launch Menu.
Chapter 1 Using Sun Secure Global Desktop 27
28 Sun Secure Global Desktop 4.5 User Guide • April 2009
APPENDIX
A
Installing the SGD Client Manually
To use Sun Secure Global Desktop (SGD) with a browser that does not have Java
technology enabled, you must download the SGD Client manually and install it on
your computer.
Installing the SGD Client
The SGD Client is usually installed automatically when you connect to an SGD
server using a browser with Java technology enabled. Follow these instructions only
if you want to install the SGD Client manually.
You do not need superuser (root) or administrator privileges to install the SGD
Client.
On Microsoft Windows platforms, the SGD Client is installed in the C:\Program
Files\Sun\Secure Global Desktop Client directory by default, but you can
choose a different installation directory when you install the software. A shortcut for
the SGD Client is added to the Windows Start Menu.
On UNIX and Linux platforms, the SGD Client is installed in the $HOME/bin
directory by default, but you can choose a different installation directory when you
install the software.
29
▼ How to Install the SGD Client Manually on
Microsoft Windows Platforms
1. In a browser, go to an SGD web server.
For example, http://server.example.com.
The SGD web server Welcome page is displayed, as shown in
FIGURE A-1 SGD Welcome Page
FIGURE A-1.
2. (Optional) Select your preferred language.
Click one of the flags at the top of the Welcome page.
The Welcome page is displayed in the selected language.
3. Click Install the Sun Secure Global Desktop Client.
The Sun Secure Global Desktop Client page is displayed.
30 Sun Secure Global Desktop 4.5 User Guide • April 2009
4. Download the SGD Client installation program.
Click Download the Secure Global Desktop Client for Microsoft Windows.
Save the installation program to a temporary directory on the PC.
The SGD Client installation program is sgdcwin-lang.exe, where lang is the
selected language.
5. Change to the temporary directory and install the SGD Client.
Double-click sgdcwin-lang.exe and follow the instructions on the screen.
▼ How to Install the SGD Client Manually on
Solaris OS and Linux Platforms
1. In a browser, go to an SGD web server.
For example, http://server.example.com
The SGD web server Welcome page is displayed, as shown in
FIGURE A-2.
Appendix A Installing the SGD Client Manually 31
FIGURE A-2 SGD Welcome Page
2. (Optional) Select your preferred language.
Click one of the flags at the top of the Welcome page.
The Welcome page is displayed in the selected language.
3. Click Install the Sun Secure Global Desktop Client.
The Sun Secure Global Desktop Client page is displayed.
4. Download the SGD Client tar file.
Click Download the Secure Global Desktop Client for platform, where platform is
the operating system for your computer platform.
Save the tar file to a temporary directory on your computer.
Tar file names indicate a platform, as follows:
■ sgdci3so.tar for Solaris™ Operating System (Solaris OS) on x86 platforms
■ sgdcspso.tar for Solaris OS on SPARC
■ sgdci3li.tar for Linux platforms
32 Sun Secure Global Desktop 4.5 User Guide • April 2009
®
technology platforms
5. Change to the temporary directory and extract the tar file.
$ cd /tempdir
$ tar xvf tarfile
6. Install the SGD Client.
$ sh sgdc/install
Follow the instructions on the screen.
Logging In Using the SGD Client
On UNIX and Linux platforms, you start the SGD Client with the ttatcc command.
On Microsoft Windows platforms, you can either start the SGD Client as part of the
installation or click Start → Programs → Sun Secure Global Desktop → Login.
▼ How to Configure the SGD Client
The first time you start the SGD Client, it asks for the following information:
■ The Uniform Resource Locator (URL) of the SGD server to which it connects. This
is usually http://server.example.com/sgd, where server.example.com is the name
of an SGD server.
■ The proxy settings to use. The settings can be determined from your default
browser, requiring Java technology, or you can type them in.
1. Start the SGD Client for the first time.
■ On UNIX and Linux platforms:
$ cd $HOME/bin
$ sh ttatcc
■ On Windows platforms:
Click Start → Programs → Sun Secure Global Desktop → Login.
The Client Connection Settings dialog box is shown. See
Appendix A Installing the SGD Client Manually 33
FIGURE A-3.
FIGURE A-3 Client Connection Settings Dialog Box
2. Type in the Server URL for the SGD server.
3. Select a Proxy Settings option.
If you select the Use HTTP Proxy Server option, type the proxy server host name
and port in the fields provided.
4. Click the Connect button to connect to the SGD server.
Your default browser is loaded and the SGD Login dialog is displayed.
5. Log in to SGD.
Type in your SGD user name and password at the SGD Login dialog. Click the
Login button to log in to SGD.
6. Log out of SGD.
Click the Logout button on the SGD webtop menu bar.
The Client Connection settings you have entered are used by the SGD Client for
any subsequent connections to this SGD server.
34 Sun Secure Global Desktop 4.5 User Guide • April 2009
APPENDIX
B
Advanced Configuration
This appendix includes configuration information for advanced users of Sun Secure
Global Desktop (SGD).
The following advanced configuration topics are described:
■ “Client Settings” on page 35
■ “Printing” on page 37
■ “Accessing the Drives on Your Computer” on page 38
Client Settings
You can change some of the following settings for your SGD Client:
■ Login page Uniform Resource Locator (URL)
■ Language
■ Proxy settings
■ Portable Document Format (PDF) viewer
To display the Client Settings tab, you click the Edit button in the Applications area
of the webtop. You can only edit client settings for the SGD server you are currently
connected to.
Note – Your SGD Administrator determines if you are allowed to change your own
client settings.
35
Changing the Login Page URL
You use the Login URL setting to specify the location of the login page on the SGD
server.
This client setting applies when you are logging in to SGD from the desktop Start or
Launch Menu.
The Login URL is usually http://server.example.com/sgd/index.jsp, where
server.example.com is the name of an SGD server.
Changing the Language
You use the Preferred Language setting to specify the language used for the login
page and on-screen messages.
This client setting applies when you are using SGD from the desktop Start or Launch
Menu.
Changing Proxy Settings
You use the settings in the Proxy section of the Client Settings tab to specify the
proxy servers used by the SGD client.
The default setting is to use the same proxy server settings as your browser. But you
can enter manual settings for an HTTP proxy server.
Specifying an Alternative PDF Viewer
When printing PDF files on UNIX, Linux, and Mac OS X platform computers, the
PDF file is normally displayed using the default PDF viewer for the computer.
You can override this by specifying another PDF viewer for the Alternative PDF
Viewer setting. Type in the application command for the alternative PDF viewer. If
the application is not on your PATH, type the full path name for the application.
36 Sun Secure Global Desktop 4.5 User Guide • April 2009
Printing
If you are using a UNIX, Linux, or Mac OS X computer, you can override the settings
made by the SGD Administrator and configure printers on the computer.
Configuring Your Client Printers
Typically, your SGD Administrator configures the available client printers for you to
use. However, if you are printing from a UNIX, Linux, or Mac OS X platform
computer, you can override these settings and configure your own client printers.
You do this by defining them in a client printer configuration file in your home
directory at $HOME/.tarantella/printerinfo.txt. This file is not installed by
default. You must create this file, or ask your SGD Administrator for a template file
that you can install and edit.
The format of the printer configuration file is as follows:
[UNIX]
"printer_name" = "windows_driver" printer_type
"printer_name" = "windows_driver" printer_type...
printer_name is the name of the printer as it is known to the lp or lpr system on
the computer.
windows_driver is the name of the printer driver to use when printing from a
Microsoft Windows application server.
printer_type is the format to be used for the print job. The values can be
PostScript, PCL, or Text.
An example of a client printer configuration file is as follows:
[UNIX]
"drafts" = "HP DeskJet 970Cxi" PCL
"salesprinter" = "HP LaserJet 5/5M" PostScript
This defines two client printers: drafts and salesprinter. You can then use the
following command to print from a UNIX platform application to salesprinter:
$ lp -d salesprinter file
Appendix B Advanced Configuration 37
Accessing the Drives on Your Computer
Your SGD Administrator configures whether you can access the drives on your
computer from applications running through SGD.
If you are using a UNIX, Linux, or Mac OS X platform computer, by default your
home directory is mapped to a drive called “My Home.” But you can configure the
drives you want to use with applications. This is done by editing your client
configuration file, $HOME/.tarantella/native-cdm-config. This file is
automatically created when the SGD Client is installed. The file contains detailed
instructions on how to create mapped drives.
The configuration file contains entries of the form <path> <type> <label>, where:
■ <path> is the absolute path name of the client file system
■ <type> is either unknown, fixed, floppy, cdrom, or remote
■ <label> is the name used in the application session
Use a separate line for each drive and separate each of the fields with a space or a
tab. If either the <path> or the <label> fields contains spaces or tabs, enclose the
field in quotes.
You can use environment variables in the <path> or <label> fields. You delimit
these with a dollar sign ($). To use a literal $, escape it with another $.
The following is an example configuration file.
[CDM]
$HOME$ fixed "My Home"
/tmp/$USER$ fixed Temp
"/mnt/win/My Documents" fixed "My Local Documents"
[/CDM]
Note – Changes to the configuration file only take effect when you log out and then
log in to SGD.
The access rights for a mapped client drive are shown in brackets after the drive
name: (rw)means read-write access, (ro) means read only access.
38 Sun Secure Global Desktop 4.5 User Guide • April 2009
APPENDIX
C
Profile Settings
This appendix describes the settings you can configure in a profile.
Description of Profile Settings
Each time the SGD Client starts it uses a profile. A profile is a group of configuration
settings that control the SGD Client.
The following table lists the settings available in a profile, with a description of what
they do.
39
If you are unsure about a setting, ask your SGD Administrator for help.
Setting Description
Login URL The SGD Uniform Resource Locator (URL) to use for the profile. This is
usually http://server.example.com/sgd, where server.example.com is the name
of an SGD server.
If you use a browser to display the SGD webtop, the URL is loaded
automatically in your default browser so that you can log in and access your
webtop.
In Integrated mode, the URL is only loaded in your default browser if you
need to log in to SGD.
The default Login URL is http://server.example.com/sgd/index.jsp.
Connect on System Login If enabled, the SGD Client is started automatically with this profile whenever
you log in to your computer.
If enabled, the SGD Client creates an application shortcut or symbolic link for
itself in the startup folder of your desktop system.
This is disabled by default.
Add Applications to Start Menu Controls how you use SGD.
If enabled, the applications you can run are displayed in the desktop Start or
Launch Menu on your computer. This is called Integrated mode.
If disabled, the applications you can run are displayed on a webtop in a
browser.
With Integrated mode, you cannot suspend and resume individual
applications or pause and resume individual print jobs.
This is disabled by default.
Automatic Client Login If enabled, as soon as the SGD Client starts, it attempts to log you in
automatically to SGD. Your Administrator can tell you whether automatic
logins are being used.
You can only enable this option if the Add Applications to Start Menu setting
is enabled.
This is disabled by default.
Alternative PDF Viewer The application command for an alternative Portable Document Format (PDF)
viewer to use with PDF printing.
If the application is not on your PATH, type the full path to the application.
This setting only applies to UNIX, Linux, and Mac OS X platform computers.
Logging Controls the amount of information that is output to the SGD Client log file.
The output is logged to a text file in the same directory as the SGD Client.
The default is Errors only.
Preferred Language The default language to use when the SGD Client is started from the
command line. For example, when the SGD Client is in Integrated mode.
The language selected is used for messages displayed by the SGD Client, the
login dialog, and the webtop.
The default is English.
40 Sun Secure Global Desktop 4.5 User Guide • April 2009
Setting Description
Check for Local X Server If enabled, the SGD Client checks whether there is an X server running on the
computer.
Enabling this option can improve performance when launching X applications
that are configured to display using an X server on the computer.
This setting only applies to Windows computers.
This setting is disabled by default.
Proxy Settings Settings that control how the SGD Client determines what proxy servers to
use.
Use Default Web Browser Settings means use the proxy server settings
configured in your default browser.
Manual Proxy Settings enable you to define the proxy server settings in the
profile. You can specify an Hypertext Transfer Protocol (HTTP) proxy server.
If the proxy settings are determined from a browser, the settings are stored
and used the next time the SGD Client starts.
If Establish Proxy Settings on Session Start is enabled, the SGD Client obtains
the proxy settings from the browser every time it starts. The stored proxy
settings are not used. If Automatic Client Login is selected, the Establish
Proxy Settings on Session Start setting is not available.
By default, the Use Default Web Browser Settings check box is selected and
the Establish Proxy Settings on Session Start check box is not selected.
Connection Failure Settings that control what the SGD Client does if the connection to an SGD
server is lost: Whether to always reconnect, to never reconnect or to ask you
what to do.
If the SGD Client reconnects, these settings control how many attempts are
made to reconnect and the time in seconds between each attempt.
If the SGD Client is unable to reconnect, the webtop session ends and any
running applications are ended or suspended, depending on how they have
been configured for you.
The default settings are: Always Attempt to Reconnect, Number of Attempts:
6, and Interval: 10.
Configuring Integrated Mode Operation
The following settings on the Client Settings tab are used for configuring Integrated
mode operation of SGD:
■ Connect on System Login
■ Automatic Client Login
■ Add Applications to Start Menu
See “Using SGD From Your Desktop Start or Launch Menu” on page 23 for more
information.
Appendix C Profile Settings 41
42 Sun Secure Global Desktop 4.5 User Guide • April 2009
Glossary
This chapter defines terms used with the Sun Secure Global Desktop (SGD) software.
A
application A program running on a server. SGD lets you access your applications using a
browser on any computer.
B
browser Software you run on your computer to access SGD. For example, Microsoft
Internet Explorer or Mozilla Firefox.
I
Integrated mode The mode of operation when you run SGD from the desktop Start or Launch
Menu. Applications are started by clicking links in the Start or Launch Menu.
43
L
link Provides access to documents and applications on your webtop. Usually an
icon with a label.
P
password A secret set of characters that, together with your user name, proves your
identity to a server. You can have different passwords, and user names, on
different servers.
profile A group of configuration settings that control the SGD Client.
S
server A computer, or software, that provides services to other computers. The SGD
server enables you to see your webtop. Other servers might run the
applications that are listed on your webtop.
SGD Administrators The people who can configure SGD, put links on user’s webtops and set up
applications.
SGD server The SGD software you log in to using your browser to see your webtop.
U
user name The unique name by which servers identify you. You can have different user
names on different servers.
44 Sun Secure Global Desktop 4.5 User Guide • April 2009
W
webtop The special web page you see when you log in to SGD. The webtop provides
access to your applications.
Glossary 45
46 Sun Secure Global Desktop 4.5 User Guide • April 2009
Index
A
Alternative PDF Viewer, specifying, 36
anonymous users
closing the browser, 13
webtop username, 9
Apple Macintosh mouse, single-button, 15
applications
adding to the webtop, 8
authentication, 14
cancelling, 11
copying and pasting between, 14
error messages, 11
groups, 21
number of instances, 10
printing, 16, 17
resuming, 11
running, 9
running from the Start Menu, 10, 26
scaling the display, 13
starting, 9
suspending, 11
Applications area, 8
authentication
applications, 14
B
browser
closing, 13
Java technology-enabled, 2
JavaScript-enabled, 2
C
cancelling applications, 10
client drives, accessing, 38
client install, 29
client printers, configuration, 37
clipboard, 14
copying, 14
D
desktop Start Menu
application links, 10
using SGD from, 10, 23, 24, 41
desktops, full screen, 26
diagnostics information, 8
E
error messages
when starting an application, 11
G
glossary of terms, 43
groups
creating, 21
Guest user, 9
I
Info button, 8
Information area, 8
Initial Connection dialog, 4
Integrated mode, 23
47
J
Java technology-enabled web browser, 2
JavaScript, 2
L
language, changing, 36
logging out of SGD, 27
login URL, 2
changing, 36
M
Menu bar, 7
My Desktop, 26
P
pasting, 14
PDF printing, 19
changing the default viewer, 36
Potentially Unsafe Connection, 5
printing
managing print jobs, 15
PDF files, 19
troubleshooting problems with, 20
UNIX platform applications, 16
user configuration, 37
Windows applications, 17
Printing area, 8
proxy settings, changing, 36
splash screen, 3
SSL connections, 9
standard connections, 9
Start Menu, 10
suspending applications, 10, 11
U
Universal PDF Printer printer, 19
Universal PDF Viewer printer, 19
user names, 1, 9
W
webtop
adding applications, 8
application start links, 9
Applications area, 8
Information area, 8
introduction, 6
Menu bar, 7
Printing area, 8
user name, 9
Windows applications, 17
NT domains, 10
Windows domains, 10
R
resuming applications, 10, 11
S
scalable windows, 13
secure connections, 9
SGD
adding links to the desktop Start Menu, 23
glossary of terms, 43
introduction, 1
logging out, 27
splash screen, 3
SGD Client
manual install, 29
shared accounts
closing the browser, 13
webtop username, 9
48 Sun Secure Global Desktop 4.5 User Guide • April 2009
Loading...
