R
ELECTRIC BLOWER
OPERATOR’S MANUAL
A Division of Snow Joe®, LLC Model SBJ601E-RM Form No. SJ-SBJ601E-RM-880E-V1
10-AMP | 2-SPEED | ALL-PURPOSE
THANKS FOR YOUR PURCHASE
OF A REMANUFACTURED PRODUCT.
To make sure you get the most out of
your
product, be sure to register online at
snowjoe.com
to enjoy full product support.
PASTE UPC LABEL HERE
R
ELECTRIC BLOWER
OPERATOR’S MANUAL
A Division of Snow Joe®, LLC Model SBJ601E-RM Form No. SJ-SBJ601E-RM-880E-V1
10-AMP | 2-SPEED | ALL-PURPOSE
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Any electrical appliance can be dangerous if used incorrectly.
Some of the safety precautions given in this manual apply
generally to many appliances. Other warnings are specic to
the use of this electric blower.
Always follow these safety guidelines. Failure to do so may
result in serious bodily injury or death.
mDANGER! This indicates a hazardous situation, which,
if not followed, will result in serious injury or death.
mWARNING! This indicates a hazardous situation, which,
if not avoided, could result in serious injury or death.
mCAUTION! This indicates a hazardous situation, which,
if not avoided, could result in minor or moderate injury.
General Safety
FOR HOUSEHOLD USE ONLY
Before using, be sure that everyone using this tool reads
and understands all safety instructions and other information
contained in this manual. Save this manual and review it
frequently prior to using this tool and when instructing
others on the proper operating procedures.
mCAUTION! Wear appropriate hearing protection during
use. After long periods of extended use, the noise generated
from this appliance may cause hearing loss if your ears are
not properly protected.
mWARNING! When using electric yard tools, basic safety
precautions should always be followed to reduce the risk of
re, electric shock, and personal injury, including the following:
1. Keep work area clean and well-lit – Cluttered, dark
areas invite accidents.
2. Replacement parts – When servicing this unit, use only
identical replacement parts. Replace or repair damaged
cords immediately.
3. Keep children, bystanders, and pets away – All
spectators, including pets, should be kept a safe distance
away from the work area.
4. Dress properly – Do not wear loose clothing or jewelry
as such articles can get caught in moving parts. Wear a
protective covering to contain long hair. Wearing rubber
gloves and substantial non-slip footwear is recommended
when working outdoors.
5. Extension cords – To prevent electric shock, use only
with an extension cord suitable for outdoor use.
6. Avoid accidental starting – Do not carry the blower with
your nger on the switch. Make sure the switch is o
before plugging in the unit.
7. Do not abuse the cord – Never carry the blower by the
cord or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
8. Moving parts – Keep hands and feet away from moving
parts. Keep guards in place and in proper working order.
9. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at
the rate for which it is designed.
10. Wear personal protective equipment – When using this
tool, wear safety glasses with side shields or goggles to
provide necessary eye protection. Wear ear defenders to
prevent hearing damage. Use a face or dust mask if the
work environment is dusty.
11. Disconnect the tool – Disconnect the blower from the
power supply when it is not in use, before servicing it,
when changing accessories, and when performing any
other maintenance task.
12. Store idle tool indoors – When not in use, the blower
should be stored indoors in a dry and high or locked-up
place out of the reach of children.
13. Maintain the blower with care – Keep the blower tube
and the fan area clear and clean for optimal performance
and to reduce the risk of injury. Inspect the extension
cord periodically and immediately replace it if damaged.
Keep the handle dry, clean, and free from oil and grease.
Follow the additional recommendations described in the
maintenance section of this manual.
14. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) that are to be used
for the blower. Receptacles are available having built-in
GFCI protection and may be used for this measure of
safety.
15. Use the right tool – Do not use the tool for any job except
that for which it is intended.
© 2017 by Snow Joe®, LLC
All rights reserved. Original instructions.
SAVE THESE INSTRUCTIONS
1
16. Avoid dangerous environments – Do not use the blower
in rain, damp, or wet locations.
17. Stay alert – Watch what you are doing. Use common
sense. Do not operate the blower when you are tired or
under the inuence of drugs, alcohol, or other medication.
Additional Safety Instructions
• Do not use the blower in the rain or in a damp area.
• Use extra care when cleaning on stairs.
• Keep rm footing and maintain good balance at all times.
Do not overreach. Overreaching can result in loss of
balance.
• Turn o all controls before unplugging the tool.
• Do not use the tool if the power switch does not turn it ON
or OFF. Any tool that cannot be controlled with the switch is
dangerous and must be repaired.
• Do not use the tool with a damaged plug. If the tool is not
working as it should or has been dropped, damaged, left
outdoors, or dropped into water, return it to an authorized
Snow Joe
Sun Joe
(1-866-766-9563).
• Carefully inspect your appliance prior to use and follow all
label and marking instructions.
• Keep all parts of your body away from any moving parts
and all hot surfaces of the unit.
• Do not put any object into the tool's openings. Do not use
the tool with any opening blocked; keep openings free of
dust, lint, hair, or any other object that may reduce air ow.
• Check the work area before each use. Remove all objects
such as rocks, broken glass, nails, wire, or string, which can
be thrown or become entangled in the machine.
• Service on the product must be performed by qualied
repair personnel only. Service or maintenance performed
by unqualied personnel could result in injury to the user or
damage to the product.
• This blower is intended for residential use only. Commercial
use of this product is prohibited and will void the
manufacturer's warranty.
• Never run the unit without the proper equipment attached.
Always ensure the blower tube is properly installed.
• Always grasp the handle when operating the unit, only
operate the machine in its intended orientation.
®
+ Sun Joe® dealer or contact the Snow Joe® +
®
customer service department at 1-866-SNOWJOE
• Never douse or squirt the unit with water or any other liquid.
Clean the unit after each use as described in the cleaning
and storage section.
Electrical Safety
1. Ground fault circuit interrupter (GFCI) protection should
be provided on the circuit(s) or outlet(s) to be used for
this electric blower. Receptacles are available having builtin GFCI protection and may be used for this measure of
safety.
2. Make sure that the mains voltage matches that listed on
the unit's rating label. Using the improper voltage can
damage the motor and injure the user.
3. To prevent electric shock, use only with an extension cord
suitable for outdoor use, such as SW-A, SOW-A, STW-A,
STOW-A, SJW-A, SJOW-A, SJTW-A, or SJTOW-A.
Before use, check that the extension cord is in good
condition. When using an extension cord, make sure to
use one heavy enough to carry the current your product
will draw. For lengths less than 50 ft (15 m), a No.16 AWG
(or greater) extension cord should be used. An undersized
cord will cause a drop in line voltage resulting in loss of
power and overheating.
m WARNING m
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the electric blower to make
contact with water while it is in operation. If the
appliance becomes wet while turned o, wipe dry
before starting.
• Use only a UL-, CSA-, or ETL-rated extension cord
for outdoor, all-weather use.
• Do not use an extension cord over 100 ft (30 m).
• Do not touch the appliance or its plug with wet hands
or while standing in water. Wearing rubber boots
oers some protection.
EXTENSION CORD CHART
Extension Cord
Length
Wire Gauge (A.W.G.):
Up to 50 ft
(15 m)
16 14
+50 ft - 100 ft
(+15 m - 30 m)
Specic Safety Rules For Blower
• The blower has been designed to clear light debris and
leaves from hard surfaces – not for clearing grassed areas.
• When operating the unit, never point the blower nozzle
in the direction of people or pets or in the direction of
windows. Use extra caution when blowing debris near solid
objects, such as trees, automobiles, and walls.
• Be sure to secure the unit when transporting it.
4. To reduce the risk of electric shock, this appliance has a
polarized plug (i.e. one blade is wider than the other). Use
this appliance only with a polarized UL-, CSA-, or ETLlisted extension cord recommended for outdoor,
all-weather use.
The appliance plug will t into a polarized extension
cord only one way. If the appliance plug does not t
fully into the extension cord, reverse the plug. If the plug
still does not t, obtain a correct polarized extension
cord. A polarized extension cord will require the use of a
2
polarized wall outlet. The extension cord plug will t into
the polarized wall outlet only one way. If the plug does
not t fully into the wall outlet, reverse the plug. If the plug
still does not t, contact a qualied electrician to install
the proper wall outlet. Do not modify the appliance plug,
extension cord receptacle, or extension cord plug in any
way.
5. To prevent the extension cord from disconnecting from
the unit during operation, always use the on-board cord
retainer.
Fig. 3
Cord retainer
6. Do not abuse the cord. Never pull the blower by the cord
or yank the cord to disconnect it from the receptacle.
Keep the cord away from heat, oil, and sharp edges.
This electric blower is double-insulated, eliminating the
need for a separate grounding system. Use only identical
replacement parts. Read the instructions before servicing
double-insulated appliances. Use this blower only as
described in this manual.
Double-Insulated Appliances
In a double-insulated appliance, two systems of insulation
are provided instead of grounding. No grounding means is
provided on a double-insulated appliance, nor should a means
for grounding be added to the appliance. Servicing a doubleinsulated appliance requires extreme care and knowledge
of the system, and should be performed only by qualied
service personnel at an authorized Snow Joe
dealer. Replacement parts for a double-insulated appliance
must be identical to the parts they replace. A double-insulated
appliance is marked with the words “Double Insulation” or
“Double Insulated.” The symbol
may also be marked on the appliance.
DOUBLE-INSULATED: GROUNDING NOT
REQUIRED. WHEN SERVICING, USE ONLY
IDENTICAL REPLACEMENT PARTS.
(square within a square)
®
+ Sun Joe®
3
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand and follow all
instructions on the machine before attempting to assemble and operate.
Symbols SymbolsDescriptions Descriptions
READ THE OPERATOR'S
MANUAL(S) – Read,
understand and follow all
instructions in the user
manual(s) before attempting to
assemble and operate.
Keep bystanders and children
a safe distance away.
SAFETY ALERT – Indicates
a precaution, a warning or
a danger.
Beware of ying objects
and debris.
DANGER! Rotating blades
pose a serious risk of injury.
Keep hands and feet away
from openings while the
machine is running.
Immediately remove the plug
from the mains if the power
cable is damaged, frayed or
entangled. Always keep the
power cable away from heat,
oil and sharp edges.
WARNING! Do not expose the
unit to rain or wet conditions.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
The rotating part will continuously
run for several seconds after you
turn o the machine.
WARNING! Turn the machine
OFF and disconnect it from the
power supply before inspecting,
cleaning, changing accessories
or conducting any other
maintenance task.
DOUBLE INSULATION – When servicing, use only identical replacement parts.
4
Know Your Electric Blower
Read the owner’s manual and safety instructions carefully before operating the electric blower. Compare the illustration below to
the electric blower in order to familiarize yourself with the location of the various controls and adjustments. Save this manual for
future reference.
1. ON/OFF switch (speed settings 1 to 2)
2. Handle
3. Appliance cord
4. Cord retainer
5. Air inlet
6. Tube release button
7. Nozzle release tab
8. Blower tube
9. Blower concentrator nozzle
1 2
3
6
4
7
8
9
Technical Data
Rated Voltage 120 V ~ 60 Hz
Power 10 A
No Load Speed 12000 –15000 rpm
5
Variable Speed Settings 2
Air Speed (max) 215 MPH
Blower Air Volume (max) 240 CFM
Weight 4.4 lbs (2 kg)
5
Unpacking
Carton Contents
• Electric blower
• Blower tube
• Blower concentrator nozzle
• Manual with registration card
1. Carefully remove the electric blower and check to see that
all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you nd damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use the electric blower.
The packaging is made of recyclable materials. Properly
dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are not
toys. Do not let children play with plastic bags, foils or small
parts. These items can be swallowed and pose a suocation
risk!
®
+ Sun Joe® customer service center at
Attaching the Blower Tube
1. Slide the blower tube forward until the notched area on
the blower housing clicks into the slot on the blower tube
(Fig. 1).
2. Insert the concentrator nozzle onto the end of the blower
tube until it locks into position (Fig. 1).
NOTE: The concentrator nozzle is used to increase
air ow in tight areas (i.e around ower beds, under
decks, etc.).
Fig. 1
Notched
area
Slot
Blower tube
Concentrator
Air outlet
nozzle
Assembly
WARNING! To avoid serious personal injury, read and
m
understand all safety instructions provided.
mWARNING! Do not connect to power supply until
assembly is complete. Failure to comply could result in
accidental starting and possible serious personal injury.
mWARNING! Before performing any maintenance, make
sure the tool is unplugged from the power supply. Failure to
heed this warning could result in serious personal injury.
mWARNING! To prevent serious personal injury, make
sure the switch is in the OFF (0) position, the unit is unplugged
and the impeller has come to a complete stop before attaching
or removing tubes.
3. To remove the blower tube, turn the ON/OFF power switch
to the OFF (0) position and disconnect the tool from the
power supply (Fig. 2).
4. Press the tube release button and remove the blower tube
(Fig. 2).
Fig. 2
ON/OFF switch
(2 blower speed control)
Tube release button
Blower tube
6
Operation
2. To reach maximal speed, move the switch to the "2"
position (Fig. 6).
Connecting to a Power Source
1. Secure the extension cord to the motor housing using the
cord retainer located at the rear of the blower. Securing
the extension cord in this manner prevents accidental
removal of the electrical cord during operation (Fig. 3).
2. Plug the female end of the electrical cord into the cord
receptacle at the back of the unit.
Fig. 3
Appliance cord
Cord retainer
Extension cord
Starting + Stopping
1. To start the electric blower, slide the ON/OFF switch to the
"1" position (Fig. 4 & 5).
Fig. 4
Fig. 5
ON (1)
OFF (0)
"1" – Normal speed
Fig. 6
3. To stop the unit, slide the ON/OFF switch to position (0)
(Fig. 4).
"2" – Higher speed
Operating Tips
mWARNING! Use the electric blower only in daylight or
good articial light.
• When using the electric blower, plant your feet rmly on
the ground and place your dominant hand on the unit
handle to control the unit. Use your other hand to steady
the unit as needed.
• Wear personal protective equipment during your work
session. This includes boots, safety glasses/goggles, ear
defenders, long pants and a long-sleeve shirt.
• Make sure the blower tube nozzle is not directed at
anybody or any loose debris before starting the unit.
• Verify that the unit is in good working condition. Make sure
the tubes and guards are in place and secure.
• Keep a rm grip on the unit handle while in use.
• To reduce the risk of hearing loss associated with
increased sound levels, hearing protection is required.
• Operate power equipment only at reasonable hours—not
early in the morning or late at night when people might be
disturbed. Comply with times listed in local ordinances.
Usual recommendations are 9:00 am to 5:00 pm, Monday
through Saturday.
• To reduce noise levels, limit the number of pieces of
power equipment used at any one time and operate
power blowers at the lowest possible speed setting
necessary to do the job.
• Use rakes and brooms to loosen debris before blowing.
• In dusty conditions, slightly dampen surfaces.
• Conserve water by using power blowers instead of hoses
for many lawn and garden applications, including areas
such as gutters, screens, patios, grills, porches and
gardens.
7
• Blow debris into a safe, open area away from children,
pets, open windows or freshly washed cars.
• Clean up after using leaf blowers and other lawn
equipment. Dispose of debris appropriately.
mWARNING! To avoid serious personal injury, wear
ear defenders, goggles or safety glasses at all times when
operating this unit. Wear a face mask or dust mask in dusty
locations.
mWARNING! To prevent serious personal injury or
damage to the unit, make sure the blower tube is in place
before operating the unit.
Maintenance
mWARNING! Always wear protective gloves during
maintenance operations. Do not carry out maintenance when
the engine is running or hot.
mWARNING! Use only original manufacturer’s
replacement parts, accessories and attachments. Failure to do
so can cause possible injury and poor performance.
To order genuine replacement parts or accessories for the
Sun Joe
com or contact the Snow Joe
center at 1-866-SNOWJOE (1-866-766-9563).
®
SBJ601E-RM electric blower, please visit snowjoe.
®
+ Sun Joe® customer service
Air Vents
Never cover air vents. Keep them free from obstructions
and debris. They must always remain clear for proper motor
cooling.
mWARNING! To avoid serious personal injury, do not
wear loose tting clothing or articles such as scarves, strings,
chains, ties, etc., that could get drawn into the air vents. To
make sure long hair does not get drawn into the air vents, tie
back long hair.
Blowing Operation
• Hold the blower rmly with your dominant hand on the unit
handle. Sweep from side to side with the nozzle several
inches above the ground or oor (Fig. 7).
Fig. 7
• Slowly advance the unit, keeping the accumulated pile
of debris in front of you. Most dry blowing operations are
better suited to low speeds rather than high speeds. High
speed blowing is best for moving heavier items like large
debris or gravel.
mWARNING! Disconnect the extension cord before
performing any maintenance task.
If the extension cord is plugged into the appliance, someone
could accidentally turn on the unit while you are inspecting it,
which could result in serious personal injury.
1. Store the tool, instruction manual and accessories in a
secure, dry place. In this way, you will always have the
information ready at hand.
2. Keep the tool’s air vents unclogged and clean at all times.
3. Remove dust and dirt regularly. Cleaning is best done with
a rag or brush.
4. Never use caustic agents to clean plastic parts.
mWARNING! Do not use cleaning agents to clean the
plastic parts of the tool. A mild detergent on a damp cloth is
recommended. Water must never come into contact with the
tool.
Storage
1. Examine the electric blower thoroughly for worn, loose,
or damaged parts. Should you need to repair or replace a
part, contact an authorized Snow Joe
or call the Snow Joe
at 1-866-SNOWJOE (1-866-766-9563) for assistance.
2. Examine the extension cord thoroughly for signs of excess
wear or damage. If it is worn or damaged, replace it
immediately.
3. Disconnect the extension cord from the electric blower
before storing.
4. Clean the blower tube thoroughly before storing. Store the
blower in a dry, well-ventilated place that is inaccessible to
children. Keep away from corrosive agents.
®
+ Sun Joe® customer service center
®
+ Sun Joe® dealer
8
Service + Support
If your Sun Joe® SBJ601E-RM electric blower requires service
or maintenance, please call the Snow Joe
customer service center at 1-866-SNOWJOE (1-866-766-
9563).
®
+ Sun Joe®
Model + Serial Numbers
When contacting the company, reordering parts, or arranging
service from an authorized dealer, you will need to provide the
model and serial numbers, which can be found on the decal
located on the housing of the unit. Copy these numbers into
the space provided below.
Record the following numbers from the housing or handle of your
new product:
S B J 6 0 1 E - R M
Model #:
Serial #:
9
Troubleshooting
m
WARNING! Always unplug the power cord before performing any adjustments, maintenance, or repairs to your
electric blower.
Problem
Motor fails to start
when switch is
turned on.
Possible Cause
1. Power cord is not plugged in or
connection is loose.
2. Household circuit breaker is tripped.
1. Plug in the power cord.
2. Check circuit breaker.
Solution
Optional Accessories
WARNING! ALWAYS use only authorized Snow Joe
m
replacement parts or accessories that are not intended for use with this electric blower. Contact Snow Joe
are unsure whether it is safe to use a particular replacement part or accessory with your electric blower. The use of any other
attachment or accessory can be dangerous and could cause injury or mechanical damage.
1
Universal wall bracket with
mounting hardware
®
+ Sun Joe® replacement parts and accessories. NEVER use
®
+ Sun Joe® if you
ModelAccessories Item
SJWB
(Fits most Snow Joe
Sun Joe
blower vac models SBJ601E+
SBJ603E + SBJ605E)
®
tools, including
®
+
2
NOTE: Accessories are subject to change without any obligation on the part of Snow Joe
changes. Accessories can be ordered online at snowjoe.com or via phone by contacting the Snow Joe
service center at 1-866-SNOWJOE (1-866-766-9563).
Gutter cleaning blower attachment
10
SBJ6-GA
(For use with blower vac
models SBJ601E + SBJ603E
+ SBJ605E + iONBV)
®
+ Sun Joe® to provide notice of such
®
+ Sun Joe® customer
SNOW JOE® + SUN JOE® REFURBISHED GOODS WARRANTY
GENERAL CONDITIONS:
®
Snow Joe
+ Sun Joe® operating under Snow Joe®, LLC warrants
this refurbished product to the original purchaser for 90 days
against defects in material or workmanship when used for normal
residential purposes. If a replacement part or product is needed,
it will be sent free of charge to the original purchaser except as
noted below.
The duration of this warranty applies only if the product is put to
personal use around the household. It is the owner’s responsibility
to correctly perform all maintenance and minor adjustments
explained in the owner’s manual.
HOW TO OBTAIN YOUR REPLACEMENT PART OR PRODUCT:
To obtain a replacement part or product, please visit
snowjoe.com/help or email us at help@snowjoe.com for
instructions. Please be sure to register your unit beforehand to
speed up this process. Certain products may require a serial
number, typically found on the decal axed to the housing
or guard of your product. All products require a valid proof
of purchase.
EXCLUSIONS:
• Wearing parts like belts, augers, chains and tines are
not covered under this warranty. Wearing parts can be
purchased at snowjoe.com or by calling 1-866-SNOWJOE
(1-866-766-9563).
• Batteries are covered in full for 90-days from the date of
purchase.
Snow Joe® + Sun Joe® may from time to time change the design
of its products. Nothing contained in this warranty shall be
®
construed as obligating Snow Joe
+ Sun Joe® to incorporate
such design changes into previously manufactured products, nor
shall such changes be construed as an admission that previous
designs were defective.
This warranty is intended to cover product defects only.
®
Snow Joe
, LLC is not liable for indirect, incidental or
consequential damages in connection with the use or misuse of
®
the Snow Joe
+ Sun Joe® products covered by this warranty.
This warranty does not cover any cost or expense incurred
by the purchaser in providing substitute equipment or service
during reasonable periods of malfunction or non-use of this
product while waiting for a replacement part or unit under this
warranty. Some states do not allow exclusions of incidental or
consequential damages so the above exclusions may not apply
in all states. This warranty may give you specic legal rights in
your state.
HOW TO REACH US:
We’re here to help Monday through Friday from 9AM to 6PM EST.
You can reach us at 1-866-SNOWJOE (1-866-766-9563), online
at snowjoe.com, via email at help@snowjoe.com or tweet us
@snowjoe.
EXPORTS:
®
Customers who have purchased Snow Joe
+ Sun Joe®
products exported from the United States and Canada should
®
contact their Snow Joe
+ Sun Joe® distributor (dealer) to obtain
information applicable to your country, province or state. If for
any reason, you are not satised with the distributor’s service,
or if you have diculty obtaining warranty information, contact
®
your Snow Joe
+ Sun Joe® seller. If in the event your eorts are
unsatisfactory, please reach out to us directly.
11
snowjoe.com
mWARNING! This product or its power cord contains chemicals, including lead, known to the State
of California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
For more information go to www.P65Warnings.ca.gov.
mWARNING! Some dust created by power sanding, sawing, grinding, drilling, and other construction
activities contains chemicals known [to the State of California] to cause cancer, birth defects, or other
reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To reduce
your exposure to these chemicals: work in a well ventilated area, and work with approved safety
equipment, such as those dust masks that are specically designed to lter out microscopic particles.
For more information go to www.P65Warnings.ca.gov.
Loading...
