Sundance Spas Camden, Certa, Chelsee, Hamilton, Metro Owner's Manual

CamdenTM • CertaTM • ChelseeTM • HamiltonTM • Metro

TM

6530-436, Rev. B

Attention New Spa Owner!

Congratulations on the purchase of your new Sundance® 780 series spa! The
following is a list of automated functions and maintenance recommendations
for your new spa. Automated functions have been listed below in an attempt to

suppress any operational concerns you may have during startup and the rst

24-hours of ownership! Maintenance recommendations are listed in an attempt
to stress their importance in protecting your new spa.

Automated Operations

Approximately two minutes after power is applied to the spa, the rst ltration/

heating cycle turns on pump 1 (see sec. 9.0, page 23). In Certa/Chelsee/
Hamilton models, an automatic ve minute “blow-out” function also activates

pump 2 for a period of ve minutes to ush all lines. Then, after ve minutes,

pump 2 turns off and pump 1 continues to operate for the duration of the cycle.

Note: this function only occurs during the rst ltration/heating cycle each day.

Maintain Healthy Spa Water

Always maintain your hot tub’s water chemistry within the following

parameters as dened by the Association of Pool And Spa Professionals/USA:

pH 7.4 - 7.6

Free Chlorine 3.0 - 4.0 ppm

Free Bromine 2.0 - 4.0 ppm

Total Alkalinity 100 - 120 ppm

Calcium Hardness 150 - 250 ppm

Always maintain your spa lter as outlined below to ensure healthy spa water.

Refer to page 29-30 for additional information.

Required Filter Maintenance

Your new hot tub is equipped with an advanced 2-stage MicroClean™ water

ltration system that provides unsurpassed water quality! To ensure maximum
water quality at all times, you should clean and reuse the larger pleated lter
cartridge every month and replace (throw away) the smaller MicroClean lter
cartridge every 3 months, or earlier as necessary. The smaller MicroClean lter
cartridge is designed to be thrown away! Attempts to reuse this lter cartridge

may result in the re-release of unwanted particles back into the spa. See page

29-30 for detailed lter cartridge replacement instructions.

Required Water Maintenance

You should replace the spa’s water every 3 months. The frequency depends on
a number of variables including frequency of use, number of users, and attention
paid to water quality maintenance. You will know it is time for a change when

you cannot control sudsing and/or you can no longer get the normal feel or

sparkle to the water, even though the key water balance measurements are all
within the proper parameters. See page 36 for additional information.

Table of Contents

1.0 Important Spa Owner Information ............................................... 1

2.0 FCC Notice .....................................................................................1

3.0 Important Safety Instructions ...................................................... 2

3.1 Important CSA Safety Instructions (CANADA Only) ....................... 4

3.2 Hyperthermia .................................................................................. 5

3.3 Cautions .......................................................................................... 6

3.4 General Electrical Safety Instructions ............................................. 6

4.0 Choosing A Location .................................................................... 7

4.1 Outdoor Location ............................................................................ 8

4.2 Indoor Location ................................................................................... 8

5.0 Power Requirements ....................................................................9

5.1 US/Canada 60Hz Power Options ................................................. 10

5.2 Export 50Hz Power Options ......................................................... 11

6.0 Electrical Wiring Instructions ....................................................12

7.0 Spa Fill Up Procedure ................................................................. 15

8.0 Control Functions ....................................................................... 20

8.1 Control Panel (All Models Except Metro) ...................................... 20

8.2 Control Panel (Metro Models Only) .............................................. 21

8.3 General Spa Features And Controls ............................................. 22

9.0 Operating Instructions ................................................................ 23

9.1 Setting Water Temperature .......................................................... 23

9.2 Activate Jets Pumps ..................................................................... 23

9.3 Selecting Desired Massage Action ............................................... 24

9.4 Air Controls ................................................................................... 24

9.5 SunGlow™ Light Operation (Metro Models Only) ........................ 24

9.6 Multi-Colored LED Light Operation (All Models Except Metro) ..... 25

9.7 SMT Jets ....................................................................................... 26

9.8 Non-Rotating Jets ......................................................................... 26

9.9 Waterfall Operation (All Models Except Metro) ............................. 26

9.10 Optional Audio System (Certa/Chelsee/Hamilton Only) ............... 26

10.0 Automatic Filtration Cycles ........................................................ 27

10.1 Standard Filtration/Heating Modes (F0 - F3) ................................ 27

10.2 Economy Filtration/Heating Modes (F4 - F6) ................................ 27

10.3 Lock Modes (L1 - L2) .................................................................... 27

10.4 Selecting The Filtration/Heating Mode .......................................... 28

11.0 Spa Maintenance ......................................................................... 29

11.1 Cleaning The Filter ....................................................................... 29

11.2 DrainingAndRelling ................................................................... 31

11.3 Pillow Care .................................................................................... 32

11.4 Cleaning The Spa Interior ............................................................. 33

11.5 Rotating Jet Cleaning Procedure .................................................. 33

11.6 Maintaining the Cover ................................................................... 34

11.7 Maintaining The Synthetic Cabinet ............................................... 34

11.8 Winterizing .................................................................................... 34

11.9 Restarting Your Spa in Cold Weather ........................................... 35

12.0 Water Quality Maintenance ........................................................ 36

12.1 pH Control ..................................................................................... 36

12.2 Sanitizing ...................................................................................... 36

12.3 Optional CD Ozone Water Maintenance System.......................... 37

13.0 Error Conditions / Error Messages ............................................ 37

13.1 Summer Logic ............................................................................... 37

13.2 Overheat Condition ....................................................................... 38

13.3 Panel displays SN1 ....................................................................... 38

13.4 Panel displays SN2 ....................................................................... 38

13.5 Panel displays FL1 or FL2 ............................................................ 38

13.6 Panel displays COL ...................................................................... 39

13.7 Panel displays ICE ........................................................................ 39

13.8 Panel displays - - - ....................................................................... 39

14.0 Troubleshooting Procedures ..................................................... 40

14.1 None of the Components Operate (e.g. Pump, Light) ................. 40

14.2 Pump Does Not Operate but Light Does ...................................... 40

14.3 Poor Jet Action ..............................................................................40

14.4 Water is Too Hot ...........................................................................40

14.5 No Heat ......................................................................................... 41

15.0 Convertible Metro Circuit Diagram (60Hz) ................................ 42

16.0 Camden Circuit Diagram (60Hz) ................................................ 43

17.0 Certa/Chelsee/Hamilton Circuit Diagram (60Hz) ...................... 44

19.0 Camden Circuit Diagram (50Hz) ................................................ 46

20.0 Certa/Chelsee/Hamilton Circuit Diagram (50Hz) ...................... 47

21.0 Optional SunSound™ Stereo Receiver Functions ................... 48

21.1 SunSound™AudioReceiverSpecications ................................. 54

21.2 Audio System Remote Control ..................................................... 56

21.3 Optional MP3 Player Connection .................................................. 57

1.0 Important Spa Owner Information

Your new Sundance® 780 Series Spa is constructed to the highest
standards and is capable of providing many years of trouble-free use.

However, because heat retentive materials are utilized to insulate the

spa for efficient operation, an uncovered acrylic spa surface and wall fit­tings directly exposed to sunlight and high temperatures for an extended
period is subject to permanent damage or discoloration. Damage
caused by exposing the spa to this abuse is not covered under war­ranty. We recommend that you always keep the spa full of water when
it is exposed to direct sunlight and that you keep the insulating cover in
place at all times when the spa is not in use. Read and carefully follow
the requirements for your spa’s support base found in section 4.0 titled,

“Choosing a Location” (Page 7).

We constantly strive to offer the finest spas available, therefore
modifications and enhancements may be made which affect the
specifications, illustrations and/or instructions contained herein.

2.0 FCC Notice

This equipment has been tested and found to comply with the limits for

a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be deter­mined by turning the equipment off and on, the user is encouraged to try

to correct the interference by one or more of the following measures:

1. Rearrange or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver

3. Connect the equipment into an outlet on a circuit different from the
circuit connected.

4. Consult the dealer or an experienced radio/TV technician for help.
Changes or modications not expressly approved by the party

responsible for FCC compliance could void the user’s authority to
operate this equipment.

Page 1

3.0 Important Safety Instructions

READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!

When installing and using this electrical equipment, basic safety precau-

tions should always be followed, including:

1. WARNING: To reduce the risk of injury, do not permit children to use
this product unless they are closely supervised at all times.

2. WARNING: A grounding wire connector is provided on this unit to
connect a minimum No. 8 AWG (8.4mm2) solid copper conductor
between this unit and any metal equipment, metal enclosures of
electrical equipment, metal water pipe, or conduit within 5 feet (1.5m)
of the unit.

3. DANGER: Risk of Accidental Drowning. Extreme caution must be

exercised to prevent unauthorized access by children. To avoid

accidents, ensure that children cannot use this spa unless they are
supervised at all times.

4. DANGER: Risk of Injury. The suction ttings in this spa are sized to

match the specic water ow created by the pump. Should the need
arise to replace the suction ttings or the pump, be sure that the ow
rates are compatible. Never operate the spa if the suction ttings are
broken or missing. Never replace a suction tting with one rated less
than the ow rate marked on the original suction tting.

5. DANGER: Risk of Electric Shock. Install at least 5 feet (1.5m) from
all metal surfaces. As an alternative, a spa may be installed within
5 feet (1.5m) of metal surfaces if each metal surface is permanently
connected (bonded) by a minimum No. 8 AWG (8.4mm2) solid cop­per conductor attached to the wire connector on the grounding lug,
inside the equipment compartment on the equipment box.

6. DANGER: Risk of Electric Shock. Do not permit any electrical
appliance, such as a light, telephone, radio, television, etc. within
5 feet (1.5m) of a spa, unless such appliances are built-in by the
manufacturer.

7. ELECTRICAL SUPPLY: The electrical supply for this product
must include a suitably rated switch or circuit breaker to open all
ungrounded supply conductors to comply with section 422-20 of the

National Electrical Code, ANSI/NFPA 70. The disconnect must be

Page 2

readily accessible and visible to the spa occupant but installed at
least 5 feet (1.5m) from the spa water.

8. WARNING: To Reduce the Risk of Injury:

9. The water in a spa should never exceed 104°F (40°C). Water
temperatures between 100°F (38°C) and 104°F (40°C) are consid­ered safe for a healthy adult. Lower water temperatures are recom­mended for young children and when spa use exceeds 10 minutes.

10. Since excessive water temperatures have a high potential for caus­ing fetal damage during the early months of pregnancy, pregnant
or possibly pregnant women should limit spa water temperatures
to 100°F (38°C). If pregnant, please consult your physician before
using a spa.

11. Before entering the spa, the user should measure the water tem­perature with an accurate thermometer since the tolerance of water

temperature-regulating devices may vary as much as +/- 5°F (2°C).

12. The use of alcohol, drugs, or medication before or during spa use
may lead to unconsciousness with the possibility of drowning.

13. Persons suffering from obesity or a medical history of heart disease,

low or high blood pressure, circulatory system problems, diabetes,

infectious diseases or immune deciency syndromes should consult
a physician before using a spa. If you experience breathing difcul-

ties in association with using or operating your spa, discontinue use
and consult your physician.

14. Persons using medication should consult a physician before using

a spa since some medication may induce drowsiness, while other
medication may affect heart rate, blood pressure, and circulation.

15. Always shower before and after using your spa. To reduce the pos­sibility of contracting a waterborne illness, always maintain water
chemistry within the parameters listed on the inside cover of this
manual. If you or other bathers experience such a condition, discon-

tinue use and seek medical attention.

Page 3

3.1 Important CSA Safety Instructions (CANADA Only)

When using this electrical equipment, basic safety precautions should

always be followed, including the following:

1. READ AND FOLLOW ALL INSTRUCTIONS.

2. A green colored terminal or a terminal marked G, Gr, Ground,
Grounding or the symbol* is located inside the supply terminal box
or compartment. To reduce the risk of electric shock, this terminal
must be connected to the grounding means provided in the elec­tric supply service panel with a continuous copper wire equivalent

in size to the circuit conductors that supply this equipment (*IEC
Publication 417, Symbol 5019).

3. At least two lugs marked “Bonding Lugs” are provided on the
external surface or on the inside of the supply terminal box/

compartment. To reduce the risk of electric shock, connect the local
common bonding grid in the area of the spa to these terminals with
an insulated or bare copper conductor not smaller than No. 6 AWG
(10mm2).

4. All eld-installed metal components such as rails, ladders, drains

or other similar hardware within 10 feet (3m) of the spa shall be

bonded to the equipment grounding buss with copper conductors not
smaller than No. 6 AWG (10mm2).

5. SAVE THESE INSTRUCTIONS.

WARNING: Children should not use spas without adult supervision.

WARNING: Do not use spas unless all suction guards are installed to

prevent body and hair entrapment.

WARNING: People with infectious diseases should not use a spa.

WARNING: To avoid injury, exercise care when entering or exiting the

spa.

WARNING: Do not use drugs or alcohol before or during the use of a
spa to avoid unconsciousness and possible drowning.

WARNING: Pregnant or possibly pregnant women should consult a

physician before using a spa.

Page 4

WARNING: Water temperature in excess of 38 °C (104 °F) may be
injurious to your health.

WARNING: Before entering the spa, measure the water temperature
with an accurate thermometer.

WARNING: Do not use a spa immediately following strenuous exercise.

WARNING: Prolonged immersion in a spa may be injurious to your

health.

WARNING: Do not permit electric appliances (such as light, telephone,
radio, television, etc.) within 5 feet (1.5m) of this spa unless factory
installed.

CAUTION: Maintain water chemistry in accordance with manufacturer’s
instructions.

WARNING: The use of alcohol or drugs can greatly increase the risk of
fatal hyperthermia in spas.

3.2 Hyperthermia

Prolonged immersion in hot water may induce hyperthermia. A descrip­tion of the causes, symptoms, and effects of hyperthermia are as

follows:

Hyperthermia occurs when the internal temperature of the body reaches
a level several degrees above the normal body temperature of 98.6°F
(37°C). The symptoms of hyperthermia include drowsiness, lethargy,
and an increase in the internal temperature of the body. The effects of

hyperthermia include:

A Unawareness of impending hazard;
B. Failure to perceive heat;
C. Failure to recognize the need to exit spa;
D. Physical inability to exit spa;
E. Fetal damage in pregnant women; and
F. Unconsciousness and danger of drowning.

Page 5

3.3 Cautions

1. Persons suffering from heart disease, diabetes, high or low blood

pressure, and any condition requiring medical treatment, pregnant
women, the elderly, or infants should consult with a physician before
using a spa.

2. The Consumer Products Safety Commission/USA has stated that

the water temperature in a spa should not exceed 104°F (40°C).

Immersion in water in excess of 104°F (40°C) can be hazardous to

your health.

3. Observe a reasonable time limit when using the spa. Long expo­sures at higher temperatures can cause high body temperature.

Symptoms may include dizziness, nausea, fainting, drowsiness, and

reduced awareness. These effects could possibly result in drowning.

4. Do not use the spa under the inuence of alcohol, narcotics, or other
drugs. Use of the spa under these conditions may lead to serious

consequences.

5. Always test the spa water temperature before entering the spa.
Enter and exit the spa slowly. Wet surfaces can be very slippery.

6. Never bring any electrical appliances into or near the spa. Never
operate any electrical appliances from inside the spa or when you
are wet unless such appliances are built-in by the manufacturer.

7. Proper chemical maintenance of spa water is necessary to maintain

safe water and prevent possible damage to spa components.

8. Use the straps and clip tie downs to secure the cover when not in

use. This will help to discourage unsupervised children from enter­ing the spa and keep the spa cover secure in high-wind conditions.
There is no representation that the cover, clip tie-downs, or actual
locks will prevent access to the spa.

3.4 General Electrical Safety Instructions

Your new Sundance® 780 Series Spa is equipped with a "state-of­the-art" equipment system. It contains the most advanced safety and
self-protective equipment in the industry. Nonetheless, this spa must

be installed properly to ensure dependable usage. Please contact your

local Sundance dealer or local building department should you have any
questions regarding your installation.

Proper grounding is extremely important. Sundance spas are equipped

with a current collector system. A pressure wire connector is provided
on the surface of the control box, located outside the equipment door

(Figure-B, page 14) to permit connection of a bonding wire between
this point and any ground metal equipment, metal water pipe or conduit

Page 6

within 5 feet (1.5m) of the spa, or copper clad grounding rod buried
within 5 feet (1.5m) of the spa. Bonding wire must be at least No. 8 AWG
(8.4mm2) solid copper wire. This is a most important safety assurance
feature.

Before installing your spa, check with your local building department to
ensure installation conforms to local building codes.

120/240 Volt Metro Convertible Model

A spa connected to a 120VAC electrical service must be located close

enough to a grounded, grounding-type electrical outlet so that the
included power cord can be plugged directly into it. DO NOT USE AN
EXTENSION CORD as this could cause damage to the spa’s equipment

due to insufcient voltage. The power supplied to this spa must

be a dedicated circuit with no other appliances or lights sharing the
power provided by the circuit.

4.0 Choosing A Location

IMPORTANT: Because of the combined weight of the spa, water and

users, it is extremely important that the base upon which the spa rests

be smooth, at, level and capable of uniformly supporting this weight,

without shifting or settling, for the entire time the spa is in place. If the
spa is placed on a surface which does not meet these requirements,

damage to the skirt and/or the spa shell may result. Damage caused

by improper support is not covered under warranty. It is the responsibil­ity of the spa owner to assure the integrity of the support over time. We
recommend a poured, reinforced concrete slab with a minimum thick­ness of 4 inches (10cm). Wood decking is also acceptable provided it is
constructed so that it meets the requirements outlined above.

The spa must be installed in such a manner as to provide drainage away

from it. Placing the spa in a depression without provisions for proper
drainage could allow rain, overow and other casual water to ood the

equipment and create a wet condition in which it would sit in. For

spas which will be recessed into a oor or deck, install so as to permit

access to the equipment, either from above or below, for servicing. Make
certain that there are no obstructions which would prevent removal of all
side cabinet panels and access to the jets components, especially on
the side with the equipment bay doors.

Page 7

4.1 Outdoor Location

In selecting the ideal outdoor location for your spa, we suggest that you

take into consideration the following:

• The proximity to changing area and shelter (especially in regions
subject to cold weather).

• The pathway to and from your spa (this should be free of debris so
that dirt and leaves are not easily tracked into the spa).

• The closeness to trees and shrubbery (remember that leaves and
birds could create extra work in keeping the spa clean).

• A sheltered environment (less wind and weather exposure can result
in lowered operation and maintenance costs).

• The overall enhancement of your environment. It is preferable not to
place the spa under an unguttered roof overhang since run-off water
will shorten the life expectancy of the spa cover.

4.2 Indoor Location

For indoor installations many factors need to be considered before

installing a spa indoors:

• PROPER FOUNDATION: Consult a Structural Engineer when con­sidering a foundation that will adequately support the spa the entire

time it is in place. Proper support is critical especially if the spa is to

rest on a second story or higher. For spas that are to rest on balco­nies, roofs or other platforms not specifically tied into the main struc­tural support, you should consult a professional Structural Engineer
with experience in this type of application.

• PROPER DRAINAGE: It is extremely important to have in place
measures to sufficiently handle excessive water spillage. Be sure
the flooring in which the spa rests on has adequate drainage and can
handle draining of the entire contents of the spa. Be sure to make
provisions for ceilings or any other structures that may be below the
spas installation. Areas around your spa can become wet or moist
so all flooring and subsequent furniture, walls and adjacent struc­tures should be able to withstand or resist water and moisture.

• PROPER VENTILATION: Proper ventilation should be discussed

with an Engineer or authority competent enough to understand the
necessary provisions needed to vent moist or heated air and air
associated with chemical odors outdoors. When the spa is in use
considerable amounts of moisture will escape potentially causing

Page 8

mold and mildew, over time this can damage certain surfaces and or
surroundings.

• SUFFICIENT ACCESS: In the unlikely event that you should ever
need to access or gain entry to any portion of the spa for servicing,
it is highly recommended that you plan your indoor installation to
provide full access to the entire spa.

• WARRANTY: Damage caused by not following these guidelines
or any improper installation not in accordance with local codes or

authorities is not covered under the spas warranty. Please consult

your local state or city building ordinances.

WARNING: In addition to maintenance of lters and water

chemistry, proper ventilation is recommended to reduce the
risk of exposure to viruses and bacteria that could be present
in the air or water. Consult a licensed architect or building

contractor to determine your specic needs if installing your

spa indoors.

5.0 Power Requirements

Sundance® spas are designed to provide optimum performance and

exibility of use when connected to the maximum electrical service listed

in the tables listed on page 10-11. If you prefer, your qualified techni-

cian can perform a minor circuit board modication to allow your spa to

accept an electrical service other than the factory setting. Turn page for
details.

Page 9

5.1 US/Canada 60Hz Power Options

US/Canada Metro Convertible Models (60Hz)

120V/15A* 240V/30A* 240V/40A**

Voltage: 120 VAC 240 VAC 240 VAC
# of Wires: 3 (15A GFCI Cord, 4 (Hard 4 (Hard
US Models Only*) Wired Only) Wired Only)
Frequency: 60Hz 60Hz 60Hz
Current Draw: 12A 21A 30A
Circuit Breaker: 15A, 1-Pole 30A, 2-Pole 40A, 2-Pole

For 240 VAC Heater Operation: Move the red wire on the main terminal
strip (TB1) from position #1 to position #3. Make certain wires are connected
exactly as shown in Figure-D (page 14) before applying power. Failure to

do so will result in damage to the circuit board and/or related components

and void the manufacturer’s warranty.

*

In the 15A and 30A conguration, the heater will not operate at the same
time as the high-speed jets pump. The factory setting is 120V/15A.

Note: all Canadian spas must be hard wired (120 VAC or 240 VAC)
per CSA Canadian standards.

**

If the spa is to be operated on 40A service, remove the jumper JP1 #1-2

on the circuit board to allow the heater to operate at the same time as the
high-speed jets pump (page 42).

240V/40A* 240V/50A**

Voltage: 240 VAC 240 VAC
# of Wires: 3 3
Frequency: 60Hz 60Hz
Current Draw: 26A 36A
Circuit Breaker: 40A, 2-Pole 50A, 2-Pole

* In the 40A configuration, the heater will not operate at the same time as

the high-speed jets pump.

** In the 50A configuration, the heater will operate at the same time as the

high-speed jets pump. This is the factory setting.

US/Canada 1-Pump Camden Model (60Hz)

Page 10

tUS/Canada Certa/Chelsee/Hamilton 2-Pump Models (60Hz)

240V/40A* 240V/50A** 240V/60A***

Voltage: 240 VAC 240 VAC 240 VAC
# of Wires: 3 3 3
Frequency: 60Hz 60Hz 60Hz
Current Draw: 26A 36A 45A
Circuit Breaker: 40A, 2-Pole 50A, 2-Pole 60A, 2-Pole

*

In 40A conguration, the heater will not operate while either jets pump

is running in high speed.

**

In 50A conguration, the heater will not operate while both jets pumps

are running in high speed.

is the factory setting.
*** in 60A conguration, the heater will operate while both jets pumps are

running in high speed.

Note: pump 2 runs only in high speed.

Note: pump 2 runs only in high speed. This

Note: pump 2 runs only in high speed.

5.2 Export 50Hz Power Options

230V/20A* 230V/30A**

Voltage: 230 VAC 230 VAC
# of Wires: 3 3
Frequency: 50Hz 50Hz
Current Draw: 15A 21A
Circuit Breaker: 20A 30A

* In the 20A conguration, the heater will not operate at the same time as

the high speed jets pump. This is the factory setting.

** In the 30A conguration, the heater will operate at the same time as the

high speed jets pump.

Export 1-Pump Camden/Metro Models (50Hz)

Export 2-Pump Certa/Chelsee/Hamilton Models (50Hz)

230V/20A* 230V/30A** 230V/40A***

Voltage: 230 VAC 230 VAC 230 VAC
# of Wires: 3 3 3
Frequency: 50Hz 50Hz 50Hz
Current Draw: 15A 23A 29A
Circuit Breaker: 20A 30A 40A

*

In 20A conguration, the heater will not operate while either jets pump is
running in high speed. This is the factory setting. Note: pump 2 runs

only in high speed.

** In 30A conguration, the heater will not operate while both jets pumps

are running in high speed. Note: pump 2 runs only in high speed.

*** In 40A conguration, the heater will operate while both jets pump are run-

ning in high speed. Note: pump 2 runs only in high speed.

Page 11

6.0 Electrical Wiring Instructions

IMPORTANT NOTICE: The electrical wiring of this spa must meet the

requirements of the National Electrical Code (NEC) and any applicable
state or local codes. The electrical circuit must be installed by a quali-

ed electrician and approved by a local building/electrical inspection

authority.

1. Convertible 120/240V Powered Metro Models Only:

• 120V “Plug-in” Operation: This spa must operate on the supplied
120V GFCI cord at its original length or must be hard-wired for
longer runs. Never use an extension cord for any reason!

• Convertible 120/240V Heater Operation: the included 120V GFCI
cord must be discarded for 240V heater operation. This spa must
be hard-wired. Supplying power to either conguration above which

is not in accordance with these instructions will void both the inde­pendent testing agency listing and the manufacturer’s warranty.

2. Dedicated 230-240V Power Camden/Certa/Chelsee/Hamilton
Models: These spas must be permanently connected (hard-wired)
to the power supply. No plug-in connections or extension cords
are to be used in conjunction with the operation of these spas.
Supplying power to these spas which is not in accordance with these
instructions will void both the independent testing agency listing and
the manufacturer’s warranty.

3. The power supplied to this spa must be a dedicated circuit with no
other appliances or lights sharing the power provided by the circuit.

4. To determine the current, voltage and wire size required, refer to
section 5.0 “Power Requirements” (page 10-11).

• Wire size must be appropriate per NEC and/or local codes.

• We recommend type THHN wire.

• All wiring must be copper to ensure proper connections. Do not use

aluminum wire.

• When using wire larger than #6 (10mm2), add a junction box near
the spa and reduce to short lengths of #8 (8.4mm2) wire to connect
to the spa.

5. The electrical supply for this product must include a suitably rated
switch or circuit breaker to open all ungrounded supply conductors

to comply with Section 422-20 of the National Electrical Code, ANSI/

Page 12

NFPA 70. The disconnecting means must be readily accessible to

9

10

4

37

1

2 2

Figure-A

Equipment Area

1. Control Box

2. Power Supply Entrance(s)

3. 2-Speed Pump #1

4. Heater

5. Spa Drain Valve

6. Pump Drain Plug(s)

7. 1-Speed Pump #2

8. Circulation Pump

9. Optional CD Ozonator (Purchased Separately)

10. Ozone Injector

11. Control Panel

Flow

Note: Pump Locations Vary by Model

Circulation Pump
Behind Load Box

8

6 6

5

11

9

10

4

37

1

2 2

Figure-A

Equipment Area

1. Control Box

2. Power Supply Entrance(s)

3. 2-Speed Pump #1

4. Heater

5. Spa Drain Valve

6. Pump Drain Plug(s)

7. 1-Speed Pump #2

8. Circulation Pump

9. Optional CD Ozonator (Purchased Separately)

10. Ozone Injector

11. Control Panel

Flow

Note: Pump Locations Vary by Model

Circulation Pump
Behind Load Box

8

6 6

5

11

the spa’s occupant but installed at least 5 feet (1.5m) from spa water.

6. The electrical circuit supplied for the spa must include a suitable
ground fault circuit interrupter (GFCI) as required by NEC Article
680-42.

7. To gain access to the spa’s power terminal block, remove the screws
securing the cabinet panel on the side of the spa under the controls.
Then remove the four control box door screws and door (Figure-B,
page 14).

8. Select the power supply inlet you want to use (Figure-A, below).
Feed power cable to control box, then install it through the large
opening provided in the bottom side of the box.

9. Connect wires, color to color, on terminal blocks TB1 and TB3

(Figures C-F, page 14). TIGHTEN SECURELY! All wires must be

hooked up securely or damage could result.

10. Install control box door and screws and reinstall the cabinet side
panels.

Page 13

BLUE

BLUE

BROWN

BROWN

1

2

US/Canada Camden/Certa/Chelsee/Hamilton

Models: 240 VAC, 3-Wire Connection (60Hz)

Figure-F

TB1

All Export Models:

230 VAC, 3-Wire Connection (50Hz)

to Circuit
Board

BLK

RED

Power In

RED

RED

BLK

BLK

1

2

Figure-E

TB1

to Circuit
Board

Power In

Green

TB3

Green

TB3

GRN

WHT

WHT

BLK

BLK

BLK

RED

1

2

3

Figure-C

TB1

to Circuit
Board

Power In

GRN

WHT WHT

BLK

BLK

BLK

RED

RED

1

2

3

US/Canada Metro Convertible Models:

120/240 VAC, 4-Wire Connection (60Hz)

Figure-D

TB1

to Circuit
Board

Power In

US/Canada Metro Convertible Models:

120 VAC, 3-Wire Connection (60Hz)

BLUE

BLUE

BROWN

BROWN

1

2

US/Canada Camden/Certa/Chelsee/Hamilton

Models: 240 VAC, 3-Wire Connection (60Hz)

Figure-F

TB1

All Export Models:

230 VAC, 3-Wire Connection (50Hz)

to Circuit
Board

BLK

RED

Power In

RED

RED

BLK

BLK

1

2

Figure-E

TB1

to Circuit
Board

Power In

Green

TB3

Green

TB3

GRN

WHT

WHT

BLK

BLK

BLK

RED

1

2

3

Figure-C

TB1

to Circuit
Board

Power In

GRN

WHT WHT

BLK

BLK

BLK

RED

RED

1

2

3

US/Canada Metro Convertible Models:

120/240 VAC, 4-Wire Connection (60Hz)

Figure-D

TB1

to Circuit
Board

Power In

US/Canada Metro Convertible Models:

120 VAC, 3-Wire Connection (60Hz)

Figure-B - Control Box

1. Terminal Block

2. Bonding Lug

3. Grounding Terminal

TB1

3

2

1

Page 14

7.0 Spa Fill Up Procedure

FOR BEST RESULTS, READ EACH STEP IN ITS ENTIRETY BEFORE
PROCEEDING WITH THAT STEP.

1. Prepare The Spa For Filling

• Clear all debris from the spa. (Although the spa shell has been
polished at the factory, you may want to treat it with a specially
formulated spa cleaner. Consult your dealer for additional infor-

mation prior to lling spa.

• Remove lter lid (page 22), then remove lter cartridge from lter

bucket as illustrated in section 11.1 (page 29).

2. Fill Spa

• Place the end of your garden hose into the empty lter bucket.

CAUTION: Never ll with water from a water softener. If
your water is extremely “hard”, it is preferable to ll half-

way with hard water and the rest of the way with soft-

ened water. Or, you may ll entirely with hard water if

you use a special water additive available from your
Sundance dealer.

• Fill spa with clean tap water from garden hose until water covers all
jets but does not touch the bottom of the lowest headrest (DO NOT

OVERFILL!)

IMPORTANT: Always ll your spa through the lter

bucket after draining. Failure to do so may cause air
to be trapped in either pump, preventing the pump
from circulating water. Remove the hose and replace
the lter cartridge as illustrated in section 11.1 (page

29).

Page 15

3. Turn On Power

121

2

Turn on power to spa at the home’s circuit breaker to start boot up

sequence (sec. 9.0, page 23). The heater and lter/circulation pump

will automatically activate after several seconds. If the control panel

LED ashes water temperature and “COOL” or “ICE” this is normal.

Refer to page 39 for additional information.

4. Activate Jets Pumps
Turn on all jet(s) pumps to ensure proper mixing when

adding start-up chemical in step 5.

5. Add Start-Up Chemicals
Add the spa water chemicals as recommended by your Sundance

dealer. See section titled “WATER QUALITY MAINTENANCE” (page

36) for general guidance.

6. Establish A Stable Sanitizer Reading

Establish a stable sanitizer reading between 3.0-4.0 ppm Chlorine or

2.0-4.0 ppm Bromine. To ensure healthy water conditions, always

maintain a constant sanitizer reading within the levels recommended
by the Association of Pool And Spa Professionals/USA printed on the

inside cover of this manual. If sanitizer levels cannot be stabilized,
perform the decontamination procedure steps 9-15 on the following
page. Note: the “decontamination procedure” steps 9-15 should also

be used after the spa has been “Winterized” (sec. 11.8, page 34) or
has been sitting without power for an extended period.

7. Set Spa To Heat
To warm spa water to a comfortable temperature, follow

these steps:

• The LED display on the control panel displays the actual
temperature of the spa water. Press either the COOLER
(Down) or WARMER (Up) button once to display the “set” tempera­ture for 5 seconds. If you want the water to heat to a different tem­perature, simply press COOLER or WARMER within 5 seconds. The
set temperature increases or decreases by one degree each time
one of these buttons is pressed.

• The heater will turn off when the temperature corresponding to the
thermostat setting is achieved.

Page 16

Important Heater Details:

• The maximum temperature for which the spa can be set is 104°F
(40°C) and the minimum is 65°F (18°C).

• For 2-pump Certa/Chelsee/Hamilton models powered by a 40
amp service, jets pump #1 must be set to low speed and jets
pump #2 must be turned off to operate the heater.

• Setting the thermostat at maximum will not accelerate the
heating process. This will only result in a higher ultimate
temperature.

• The heater operates until the water reaches the programmed

“set temperature”, then turns off. The heater will reactivate
after the water cools to approximately 1.5° below the “set
temperature.”

8. Place Cover On Spa

• Keeping the insulating cover in place anytime the spa is not in use
will reduce the time required for heating, thereby minimizing operat­ing costs.

• The time required for initial heat-up will vary depending on the start­ing water temperature.

DANGER:

carefully before entering spa!

Decontamination Procedure (Steps 9-15)

Steps 9-15 below are only required when sanitizer levels are unstable

after performing steps 1-6 above. Disregard steps 9-15 below if sanitizer
levels remain stable at 3.0-4.0 ppm Chlorine or 2.0-4.0 ppm Bromine
after performing steps 1-6 above.

9. Add 2.5 ounces of Sodium Dichlor for every 100 gallons of water.
Refer to the table (page 18) for approximate water ll volume by
model.

Risk of injury! Always check water temperature

Page 17

CAUTION: Never add Chlorine tablets (Trichlor) to your
spa for any reason! This chemical may damage components
within your spa and void the manufacturer warranty.

Water Fill Volume by Model
Spa Model Approximate Fill Volume

Camden ..................................... 250 US Gallons (946 Liters)

Certa .......................................... 385 US Gallons (1,457 Liters)

Chelsee ..................................... 365 US Gallons (1,382 Liters)

Hamilton .................................... 400 US Gallons (1,514 Liters)

Metro ......................................... 190 US Gallons (719 Liters)

10. Leave spa cover open during this step to allow

excessive chemical vapors to exit spa, protecting
pillows and plastic knobs from chemical attack. If spa
is indoors, open doors and windows for proper ventila­tion. Turn on all spa jets pumps for one hour, open all
air controls, and place all massage selector knob(s) in their center

“combo” position as shown (right). Note: You will need to press the
jets pump button(s) every 20 minutes since these functions have an
automatic 20 minute time-out function that turns them off.

CAUTION: Never leave your spa unattended for any reason
while the cover is open and accessible to small children and
animals!

11. Turn off power to the spa at the circuit breaker, then drain spa as

outlined in section 11.2 (page 31).

12. Rell spa with clean tap water from garden hose until water covers

all jets but does not touch the bottom of the lowest headrest (DO

NOT OVERFILL!)

Page 18

CAUTION: Never ll with water from a water softener. If your
water is extremely “hard”, it is preferable to ll half-way with

hard water and the rest of the way with softened water. Or,

you may ll entirely with hard water if you use a special water

additive available from your Sundance dealer.

13. Consult your authorized Sundance dealer for chemical recommenda-

tions, then add chemicals to spa water to achieve a constant sani-

tizer reading within the levels recommended by the Association of
Pool And Spa Professionals/USA printed on the inside cover of this

manual.

14. Turn on all jet pumps when adding chemicals to ensure proper mix-

ing and leave your spa cover open until the sanitizer level falls below

4.0 ppm to protect pillows and plastic knobs from chemical attack.

CAUTION: Never leave your spa unattended for any reason
while the cover is open and accessible to small children and
animals!

CAUTION: To prevent the unlikely possibility of contracting a
waterborne
parameters. If you or other bathers experience such a
condition, discontinue use and seek medical attention

illness, maintain water chemistry within step 6

.

15. Establish a sanitizer reading between 3.0-4.0 ppm Chlorine or 2.0-

4.0 ppm Bromine, then allow the spa to set undisturbed for 8 hours.

Retest water after 8 hours to determine if sanitizer levels are stable.
If sanitizer levels are stable, your spa is ready for use. To ensure
healthy water conditions, always maintain a constant sanitizer read­ing within the levels recommended by the Association of Pool And
Spa Professionals/USA printed on the inside cover of this manual.
If sanitizer levels are not stable at this time, it will be necessary to
repeat this procedure in its entirety (steps 1-15) until stable sanitizer

readings are achieved.

Page 19

8.0 Control Functions

1 2

A

B

C D E F

G

H

1 2

A

B

C D E F

G

H

8.1 Control Panel (All Models Except Metro)

A. LED Display: can display

current water temperature
(default display), water
temperature set point,

selected ltration/heating

mode, and error messages.

B. Heat Indicator: lit when heater is on.

C. Warmer ( ∆ ) Button: increases water temperature set point.

D. Cooler ( ) Button: decreases water temperature set point.

∆∆

E. Jets 1 Button: turns jets pump #1 on and off. Press once for low

speed; press a second time for high speed; press a third time to turn

pump #1 off.

F. Jets 2 Button (Certa/Chelsee/Hamilton Models): turns high-speed

jets pump #2 on and off. Press once to turn on; press a second time

to turn pump #2 off.

G. Light On/Off Button: Turns waterfall, footwell and control lights on

in unison. Press once for high intensity; press a second time for
medium intensity; press a third time for low intensity; press a fourth

time to turn off. The displayed color is changed using the light mode
button (H) below.

H. Light Mode Button: Selects one of 7 color modes for waterfall, foot-

well and control lights. See page 25 for additional information.

Operation Details

• Temperature Adjustment: 65-104 °F (18-40 °C). Factory default set­ting is 100 °F (38 °C).

• Underwater Light Operation: light runs for approximately 1 hour then

shuts off.

• Jets 1/Jets 2 Button Operation: jets run for 20 minutes after acti­vated, then turn off automatically to conserve energy. Simply press
either jets button to continue operation for an additional 20 minutes.

Page 20

8.2 Control Panel (Metro Models Only)

B C D

E

F

A B C D

E

F

A

A. LED Display: can display current

water temperature (default display),
water temperature set point, selected

ltering/heating mode, and error

messages.

B. Heat Indicator: lit when heater is on.

C. Warmer ( + ) Button: increases water

temperature set point.

D. Cooler ( - ) Button: decreases water temperature set point.

E. Jets 1 Button: turns jets pump #1 on and off. Press once for low

speed; press a second time for high speed; press a third time to turn

pump #1 off.

F. Light Button: turns underwater light on in random color mode or in

one of six solid colors. Refer to section 9.5 (page 24) for details.

Operation Details

• Temperature Adjustment: 65-104 °F (18-40 °C). Factory default set­ting is 100 °F (38 °C).

• Underwater Light Operation: light runs for approximately 1 hour then

shuts off.

• Jets 1/Jets 2 Button Operation: jets run for 20 minutes after acti­vated, then turn off automatically to conserve energy. Simply press
either jets button to continue operation for an additional 20 minutes.

Page 21

1

2

278

12

2

4c

12

4d

4a

4b

12

5

3c

3b

3a

1

12

10

9

8

6

7

13

11

13

Hamilton model illustrated - Jet locations and features will vary by model

Spa features subject to change without notice.

1. Control Panel

2. Filter Lid & Filter Cartridge

3. Air Controls w/LED Light* (3a-3c)

4. Pillows (4a-4d)

5. Massage Selector w/LED Light*

6. Gravity Drain/Ozone Return/Heater
Return Fitting

7. Spa Light

8. Suction Fittings & Filters

(Filters protect massage
selector from debris entrap­ ment/damage. Filters require
periodic cleaning).

9. Integrated Cupholder

10. Waterfall w/LED Light**

11. Waterfall Control (On/Off)**

12. Optional Audio System
(Certa/Chelsee/Hamilton
Models only).

13. Optional Audio System Remote
Control (Certa/Chelsee/Hamilton

Models only).

* Light feature not offered on Metro Models
** Waterfall function not offered on the Metro

Models

1

2

278

12

2

4c

12

4d

4a

4b

12

5

3c

3b

3a

1

12

10

9

8

6

7

13

11

13

Hamilton model illustrated - Jet locations and features will vary by model

Spa features subject to change without notice.

1. Control Panel

2. Filter Lid & Filter Cartridge

3. Air Controls w/LED Light* (3a-3c)

4. Pillows (4a-4d)

5. Massage Selector w/LED Light*

6. Gravity Drain/Ozone Return/Heater
Return Fitting

7. Spa Light

8. Suction Fittings & Filters

(Filters protect massage
selector from debris entrap­ ment/damage. Filters require
periodic cleaning).

9. Integrated Cupholder

10. Waterfall w/LED Light**

11. Waterfall Control (On/Off)**

12. Optional Audio System
(Certa/Chelsee/Hamilton
Models only).

13. Optional Audio System Remote
Control (Certa/Chelsee/Hamilton

Models only).

* Light feature not offered on Metro Models
** Waterfall function not offered on the Metro

Models

8.3 General Spa Features And Controls

Page 22

9.0 Operating Instructions

1.

2.

3.

1.

2.

3.

121

2

The spa control system has automatic functions that
operate upon startup and normal operation to protect

the system. Upon power up, the readout displays the
following information:

1. Control panel displays current software release

(e.g. 3.56), then;

2. Control panel displays “888” and all indicator LEDs are

lit, permitting visual inspection of all display segments
and indicator lights for proper operation.

3. After the initial start-up sequence ends, the actual water temperature
is displayed. If water temperature at this time is less then the factory
default temperature setting of 100 °F (38 °C) and the spa is set to
ltration/heating mode “F0”, “F1”, “F2” or “F3” (page 28), the heater
will turn on and run until the water temperature rises to the factory

setting, then turn off. Note: it is common for the heater to turn on
after the spa is rst lled because tap water is often very cold.

4. Approximately two minutes after power is applied to the spa, the rst
ltration/heating cycle turns on pump 1. In Certa/Chelsee/Hamilton
models, an automatic ve minute “blow-out” function also activates
pump 2 for a period of ve minutes to ush all lines. Then, after ve

minutes, pump 2 turns off and pump 1 continues to operate for the
duration of the cycle. Note: this function only occurs during the rst

ltration/heating cycle each day.

9.1 Setting Water Temperature

The spa’s thermostat provides optimum control of water
temperature. The temperature setpoint (set temperature)
can be adjusted from 65-104 °F (18-40 °C). To raise the set
temperature, press the WARMER ( ) button. To lower the
set temperature, press the COOLER ( ) button. Note: The rst press

of either WARMER ( ) for COOLER ( ) button displays the set
temperature.

9.2 Activate

Jets Pumps

The JETS 1 button activates the functions of the main

2-speed jets pump. The rst press activates pump 1 in

low speed, the second press activates high speed, and the
third press shuts the pump off. For 2-pump models, the
JETS 2 button controls jets pump 2 which only operates in
high speed. Both pumps have a twenty minute default when manually

activated.

Page 23

9.3 Selecting Desired Massage Action

CB

ACBA

Spa Light Sequence

OFF RED OFF

OFF

GREEN

TEAL

OFF BLUE

OFF VIOLET

OFF ORANGE

OFF

RANDOM

Spa Light Sequence

OFF RED OFF

OFF

GREEN

TEAL

OFF BLUE

OFF VIOLET

OFF ORANGE

OFF

RANDOM

Your Sundance spa is equipped to allow you to customize
the massage action you desire. Each model incorporates a

massage selector that allows you to customize the massage

and performance by diverting water between various jet
systems. Simply turn massage selector to position A

(Combo), B, or C to divert water pressure to various jet groups. Note:

The massage selector is designed to operate in positions A (Combo), B,
and C for optimum performance. It is considered normal for sound levels
within the valve to vary between positions due to the large amounts of

water owing through it! For optimum ltration benets, leave the valve

in position A when spa is covered. Select position B or C for maximum
jet performance during spa use.

9.4 Air Controls

Certain jet systems have their own air control. Each

control introduces air into the water lines that supply specic

jet groups. Simply rotate any air control knob clockwise to
open, or counterclockwise to close. Note: To minimize heat loss, close

all air controls when spa is not in use. Certain jets may not draw air
while the jets pump is running in low speed; this is considered normal.

™

9.5 SunGlow

Light Operation (Metro Models Only)

The spa light offers 6 constant color variations and a unique random

mode for enhanced spa enjoyment. Press the LIGHT button once to turn
the spa light on in “Random” mode, then repeatedly press the button to

turn the light off or to select one of 6 constant colors as illustrated below.

You must press the LIGHT button within 5 seconds between each “off” or
“color” step in the light sequence to prevent it from resetting. Pressing
the button after 5 seconds restarts the sequence at “Random” mode.

This mode automatically changes the light color every 8 to 20 seconds.

Note: Any time the spa light is manually turned on, it will automatically

turn off after approximately 1 hour. If you desire more light at this time,
simply turn the light back on.

Page 24

9.6 Multi-Colored LED Light Operation (All Models Except Metro)

Freeze Color Blend Mode:

Selects or “freezes” your low speed blending color of choice.

Solid Color Mode:

Selects one of 7 solid (high-intensity) colors of choice.

Press

Once

Press

Again

Press

Again

Hold For

3 Seconds

then

Release

Press
Again

High-Speed Color Blend Mode:

Displays hunderds of colors in 5 second intervals.

Low-Speed Color Blend Mode:

Displays hundreds of colors in 20 seconds intervals.

OR

Special Effects Mode (Overrides All Modes):

Displays colors that automatically blend, flash and alter

directions randomly. Four random modes offered.

BLUE (X4) VIOLET (X5) RED (X6) AMBER (X7) GREEN (X8) AQUA (X9)

WHITE (X10)

NEAR

Freeze Color Blend Mode:

Selects or “freezes” your low speed blending color of choice.

Solid Color Mode:

Selects one of 7 solid (high-intensity) colors of choice.

Press

Once

Press

Again

Press

Again

Hold For

3 Seconds

then

Release

Press
Again

High-Speed Color Blend Mode:

Displays hunderds of colors in 5 second intervals.

Low-Speed Color Blend Mode:

Displays hundreds of colors in 20 seconds intervals.

OR

Special Effects Mode (Overrides All Modes):

Displays colors that automatically blend, flash and alter

directions randomly. Four random modes offered.

BLUE (X4) VIOLET (X5) RED (X6) AMBER (X7) GREEN (X8) AQUA (X9)

WHITE (X10)

NEAR

A. Pressing the LIGHT button activates the Footwell, Waterfall,

Massage and Air Control LED Lights in sequence as follows:

High - Medium - Low - Off.

Anytime the light system has been manually activated, it will automati­cally turn off after approximately 1 hour. If at this time you desire more
light operation, simply turn the light back on.

B. This button offers five light modes for your enjoyment.

Press the LIGHT MODE button to select your favorite lighting
effect as follows:

Page 25

9.7 SMT Jets

A

B

C

A

B

C

A

B C

A

B C

Full
On

Full
OFF

180°

180°

Full
On

Full
OFF

180°

180°

Each SMT Jet offers an adjustable ow stream and ow
volume. To adjust (A), gently press each jet nozzle to the
side to initiate a rotating massage, or center the nozzle for a
non-rotating jet stream. Adjust ow volume (A,B,C) by
turning outer jet ring clockwise to increase ow or counter­clockwise to decrease ow. Note: Always keep at least 6

adjustable jets open at all times on each jet system.

9.8 Non-Rotating Jets

All SMT Turbo jets (A) offers an adjustable ow stream
angle. To adjust each jets ow stream angle, simply push the
nozzle to the left or right. The Accu-Pressure jet (B) is non-

adjustable. The SMT Fluidix jet (C) is non-adjustable.

9.9 Waterfall Operation (All Models Except Metro)

Turn waterfall control valve counterclockwise to increase
waterfall(s) output. Turn control valve clockwise to decrease
or turn off waterfall(s) output. Note: it takes half of a revolution

to change the waterfall from a full off to a full on flow rate.

Note: jet appear-

Note: jet appear-

ance may vary.

ance may vary.

Note: jet appear-

Note: jet appear-

ance may vary.

ance may vary.

9.10 Optional Audio System (Certa/Chelsee/Hamilton Only)

Spas equipped with the optional audio system offer
enhanced spa enjoyment. These models include a
high-quality AM/FM/CD stereo receiver with four
high-quality marine speakers for unsurpassed
sound quality and long-life, a hard wired remote

control and an MP3 adapter cable. Refer to section

21.0 (page 48) for complete stereo operation details.

Page 26

10.0 Automatic Filtration Cycles

Your new spa includes a 24-hour circulation pump which lters the water

continuously while using less energy than a common 100 watt light bulb!
The circulation pump draws water through the short side of the double-

ended lter cartridge and effectively removes small debris in your spa.

Note: the 24-hour circulation pump system also supplies heated water
to the spa when the heater turns on. This features cannot be altered or
disabled.

The control system activates a programmable “standard” or “economy”
ltration/heating cycle to remove larger debris missed by the 24-hour
circulation pump ltration system. These cycles utilize pump #1 and the
larger lter cartridge end to quickly clear “skim” the water of large debris
and minimize their “bath-tub ring” effect. Apart from their ltration ben­et, each mode also effects the operation of your spa’s heater. Refer to

sections 10.1 and 10.2 below for additional information.

10.1 Standard Filtration/Heating Modes (F0 - F3)

Standard ltration/heating modes are typically selected by customers in

cold climates where heat up times are extended due to lower ambient
temperatures. In these modes, the water temperature is regulated by
the set temperature, 24-hour circulation pump, and heater which turns
on as needed. After the programmed set temperature is reached, the
heater turns off and the circulation pump continues to operate 24-hours

to lter and clean your spa.

10.2 Economy Filtration/Heating Modes (F4 - F6)

Economy ltration/heating modes are typically selected by customers in
warm climates where heat up times are minimized due to higher ambi-

ent temperatures. In these modes, the water temperature is regulated
by the set temperature, 24-hour circulation pump, and heater only

while a programmed lter cycle is running (unless in summer logic; see

section 13.1, page 37). Note: these modes consume less energy than
standard modes F0-F3 outlined in section 10.1.

10.3 Lock Modes (L1 - L2)

These modes are designed for use during spa service or to prevent

unauthorized use.

Page 27

10.4 Selecting The Filtration/Heating Mode

Press and hold both control panel WARMER ( ) and COOLER ( )
buttons at the same time, then release. Then press either WARMER
( ) or COOLER ( ) button to select ltration/heating mode F0-F6 or
lock modes L1-L2 outlined below.

Standard Filtration/Heating Modes
F0 5 minutes of ltration per day (one 5 minute “Blow-Out”

cycle every 24 hours to purge all plumbing lines)

F1 1 hour of ltration per day (one 30-minute cycle every 12

hours); this is the factory default setting.

F2 1.5 hours of ltration per day (one 30-minute cycle every

8 hours)

F3 2 hours of ltration per day (one 30-minute cycle every 6

hours)

Economy Filtration/Heating Modes
F4 1 hour of ltration/heating per day (one 30-minute cycle

every twelve hours)

F5 1.5 hours of ltration/heating per day (one 30-minute

cycle every eight hours)

F6 2 hours of ltration/heating per day (one 30-minute cycle

every six hours)

Lock Modes
L1 Lock Out (disables all spa functions to permit lter

cleaning)

L2 Lock Mode (disables the jets and light buttons to prevent

unauthorized use of spa.) Filtration/heating cycle will con­tinue to operate as programmed in this mode. The tem-

perature display ashes when this function is enabled. Example:
the “F3” ltration/heating cycle was enabled prior to choosing lock
mode. The spa continues to perform the “F3” cycle until lock mode

is canceled, allowing another cycle to be selected.

To set a time for the rst ltration/heating cycle, simply turn power on to
the spa two minutes prior to the desired time. EXAMPLE: If you desire
your rst ltration/heating cycle to begin at 10:00 AM turn off power to
the spa and turn it back on again at 9:58 AM. Note: start time is approx-

imate and may vary slightly from day to day.

Page 28

11.0 Spa Maintenance

B

A

C

TURN POWER TO HOT TUB OFF!

1. Rotate stage 2 retainer counterclockwise
to release, then separate filter assembly.

2. Replace (throw-away) stage 2 filter after 3
months use or as needed. DO NOT REUSE!

Stage 1

filter

(Reuseable)

Stage 2

filter

Loosen filter nut to provide clearance, then
remove filter assembly.

Filter
Nut

1.

2.

Replace!

DO NOT

Reuse!

B

A

C

TURN POWER TO HOT TUB OFF!

1. Rotate stage 2 retainer counterclockwise
to release, then separate filter assembly.

2. Replace (throw-away) stage 2 filter after 3
months use or as needed. DO NOT REUSE!

Stage 1

filter

(Reuseable)

Stage 2

filter

Loosen filter nut to provide clearance, then
remove filter assembly.

Filter
Nut

1.

2.

Replace!

DO NOT

Reuse!

Proper and regular maintenance of your spa will help it retain its beauty
and performance. Your authorized Sundance dealer can supply you with

all the information, supplies and accessory products you will need to
accomplish this.

11.1 Cleaning The Filter

Your new spa is equipped with an exclusive MicroClean™ 2-stage lter

cartridge located under the lter lid. Fine debris are ltered 24-hours
by the circulation pump drawing water through the ultra-ne (stage 2)
cartridge. Larger debris are ltered by the main 2-speed pump drawing

water through the (stage 1) polyester mesh (pleated) cartridge during

normal operation and during each ltration/heating cycle. Combined,
both lter halves work together to give you unsurpassed water quality

by trapping suspended particles on their outer surface. Note: To ensure

optimum performance, clean and reuse the stage 1 cartridge once a
month and replace the stage 2 cartridge every 3 months, or as needed.

All models include lters on their footwell suction covers (shown
right) that prevent debris from entering pump 2 and the massage

selector(s), when operating. These lters must remain in place
to protect these components from debris entrapment/damage.

They should be cleaned every 2 months, or when weak pump 2
performance is observed.

ALWAYS TURN POWER TO SPA OFF BEFORE CLEANING THE
FILTER CARTRIDGE! Refer to the lter cleaning/replacement

procedure below:

Page 29

B

A

C

F

TURN POWER TO HOT TUB OFF!

D

Rinse debris from all filter pleats using a
garden hose and high-pressure nozzle. Start
at top and work downward to face. Repeat
process until all filter pleats are clean.

Submerge assembled filter in spa and tilt each
end upward to remove trapped air bubbles
from inside each filter cavity.

Stage 1

filter

New

Stage 2

filter

E

1. Install new stage 2 filter onto clean stage 1 filter.

2. Insert retainer into stage 2 filter and rotate
clockwise to assembly. DO NOT OVERTIGHTEN

RETAINER (FINGER TIGHT ONLY)!

G

1. Install filter assembly, then tighten filter nut so it
just touches filter face. DO NOT OVERTIGHTEN!

2. Turn power to hot tub back on.

Filter

Nut

1.2.

Trapped

Air

Bubbles

Top

Reusable
Stage 1
Filter

1. Rotate stage 2 retainer counterclockwise
to release, then separate filter assembly.

2. Replace (throw-away) stage 2 filter after 3
months use or as needed. DO NOT REUSE!

Stage 1

filter

(Reuseable)

Stage 2

filter

Loosen filter nut to provide clearance, then
remove filter assembly.

Filter
Nut

1.

2.

Replace!

DO NOT

Reuse!

Note: The Stage 2 filter cartridge cannot be
cleaned and must be (thrown out) replaced
every 3 months, or as needed.

Note: Remove and clean the Stage 1
filter cartridge once a month.

Periodically, the polyester mesh (pleated) lter will need a more thor­ough cleaning to remove imbedded oils and minerals. For this, we
suggest cleaning as illustrated above (step D), followed by soaking the

lter overnight in a plastic container lled with a solution of water and a
specially formulated lter cleanser available from your Sundance dealer.

CAUTION! Never scrub the polyester mesh lter cartridge

with a brush as this will cause the polyester mesh to wear
out and come apart. Never let the spa pump run or have

a lter cycle come on without a lter cartridge in the skim­mer compartment. Running the spa without a lter cartridge

may permit debris to enter the spa plumbing and void the
warranty!

Page 30

The average life expectancy of the polyester mesh lter cartridge is

3/8"

Figure G

Figure H

Figure I

3/8"

Figure G

Figure H

Figure I

approximately two years with proper care and water quality main­tenance. The smaller stage 2 lter cannot be cleaned and must be
replaced (thrown-out) every 3-months, or as needed. DO NOT reuse
this cartridge! Attempts to reuse this cartridge will reintroduce debris
back into your spa! Replacement cartridges may be purchased from
your Sundance dealer.

11.2 Draining And Refilling

About every 3 months, you will want to replace the spa’s water. The
frequency depends on a number of variables including the amount of
use and attention paid to water quality maintenance. You will know it is

time for a change when you cannot control sudsing and/or you can no

longer get the normal feel or sparkle to the water even though the key
water balance measurements are all within the proper parameters.

CAUTION! READ THIS BEFORE DRAINING:

CAUTION! READ THIS BEFORE DRAINING: To prevent

damage to the spa’s components, turn off power to the spa

damage to the spa’s components, turn off power to the spa
at the circuit breaker before draining it. Do not turn the power

at the circuit breaker before draining it. Do not turn the power

back on until your spa has been relled. There are certain

back on until your spa has been relled. There are certain

precautions to keep in mind when draining your spa. If it is

precautions to keep in mind when draining your spa. If it is

extremely cold, and the spa is outdoors, freezing could occur

extremely cold, and the spa is outdoors, freezing could occur
in the lines or the equipment (see “WINTERIZING”, sec. 11.8

in the lines or the equipment (see “WINTERIZING”, sec. 11.8

page 34). On the other hand, if it is hot outdoors, do not

page 34). On the other hand, if it is hot outdoors, do not
leave the spa’s surface exposed to direct sunlight for long

leave the spa’s surface exposed to direct sunlight for long
periods.

periods.

Draining Procedures:

1. Turn off power to spa at breaker.

2. Locate the 3” gray drain valve cap on side of the
spa cabinet. Unscrew drain valve cap to expose the
underlying male garden hose tting (g. G-I).

3. Attach female garden hose end to drain tting and

route opposite end of garden hose away from spa

(g. H).

4. Pull outward on garden hose end at drain connection
(approx. 3/8”) to open drain valve and release water
from spa (g. I). Water drains at approximately 3

gallons per minute.

To prevent

Page 31

5. After spa has drained, close drain valve by pushing inward on garden

1 2

Place both hands on
pillow with thumbs as
shown.

Press inward with
thumbs to curl pillow
lip in ward so you can
grab i t with fingertips.

3 4

5

Flex p illow lip inward
2-3" t o get a good
grip o n the ends.

Gently pull outward on
pillow to release mounting
stud f rom receptacle on
spa sh ell.

Wash pillow(s) in a mild deterg ent so ap and warm water solution. Never machine wash your pillo ws
or att empt to clean them with a non -appro ved vinyl cleaning agent!

6

To reinstall pillows: Simply align pillow over mounting s tud re ceptacle, then gently push in ward to snap in place.

1 2

Place both hands on
pillow with thumbs as
shown.

Press inward with
thumbs to curl pillow
lip in ward so you can
grab i t with fingertips.

3 4

5

Flex p illow lip inward
2-3" t o get a good
grip o n the ends.

Gently pull outward on
pillow to release mounting
stud f rom receptacle on
spa sh ell.

Wash pillow(s) in a mild deterg ent so ap and warm water solution. Never machine wash your pillo ws
or att empt to clean them with a non -appro ved vinyl cleaning agent!

6

To reinstall pillows: Simply align pillow over mounting s tud re ceptacle, then gently push in ward to snap in place.

hose end at drain connection until you feel it bottom out. Remove

garden hose and install gray drain cap before relling spa. Note:

the gray drain cap cannot be installed until the drain valve is closed.
Refer to “Spa Fill Up Procedure” (page 15) for recommended lling
instructions.

11.3 Pillow Care

Remove and clean the headrest pillows as needed
with soapy water using a cloth or soft-bristle brush. To
maintain water resistance and luster, apply a quality
vinyl conditioner once a month. Always remove the
pillows when adding chemical shock treatment to the

spa water. The pillows can be returned to the spa when the sanitizer

reading drops below 4.0 ppm. Note: Metro pillows vary in appearance,
not shown.

Pillow Removal/Cleaning Procedure

Page 32

11.4 Cleaning The Spa Interior

Release Position C
"Click" Position B
Stop Position A

Outer Jet
Adjustment
Ring (X)

fig. 1

Release Position C
"Click" Position B
Stop Position A

Outer Jet
Adjustment
Ring (X)

fig. 1

To preserve the sheen of your spa's surface, it is crucial that you avoid
using abrasive cleaners or cleaners which have adverse chemical effect
on the surface. If you are not certain as to the suitability of a particular

cleanser, consult your authorized Sundance dealer. Regardless of the

cleanser used, use extreme care to assure that no soap residue is left

on the surface. This could cause severe sudsing when the spa is relled.

11.5 Rotating Jet Cleaning Procedure

If you experience a sticky rota­tional jet, perform the following
cleaning procedure. In most of
these cases debris is present in
the jet bearings and must be
cleared to achieve proper opera­tion. Note: This procedure is

considered normal maintenance
for this type of jet.

Procedure

1. Remove jet internal from spa

wall tting by placing your hand around the outer jet adjustment ring

and rotating it counterclockwise (g. 1). Rotate jet adjustment ring
until it stops at position (A). Use additional force at position (A) to
continue rotation until you feel a “click” at position (B); then feel the

internal release at position (C). It may seem like your are over torqu­ing the jet internal between positions (A-B), however, additional force
is necessary at position (A) to unlatch its retaining mechanism from

the wall tting.

2. Fill a clean bucket with tap water and immerse jet internal. Rotate

submersed jet internal’s nozzle in a circular motion while moving it

back and forth allowing water to ow through both ends of the jet.

This motion allows slow moving water to wash back through the jet
bearing and dislodge any debris that might be lodged in the bearing.
Clean each jet internal for approximately 1 to 2 minutes twice a year,
or when a particular jets rotation appears sluggish, jerky, or

obstructed.

3. Reinstall jet internal by inserting it in any jet opening of the same jet
type. Rotate the jet internal clockwise with light pressure until your

feel the retaining mechanism “snap” in place. The jet’s nozzle should

Page 33

rotate freely to the left or right using only ngertip pressure. If jet

rotation appears sluggish or obstructed at this time, repeat steps 2-3
until condition clears. If condition persists, contact dealer for technical
support.

11.6 Maintaining the Cover

Using the Sundance insulating spa cover anytime the spa is not in use
will signicantly reduce your operating costs, heat-up time and mainte-

nance requirements. To prolong the life of the cover, handle it with care

and clean it regularly using mild soap and water. Periodic treatments with

a special conditioner developed for Sundance spa covers will help pro-

tect against deterioration caused by UV rays from the sun. Never allow

anyone to stand or sit on the cover, and avoid dragging it across rough
surfaces.

11.7 Maintaining The Synthetic Cabinet

Your new spa’s synthetic cabinet requires little or no maintenance of any
kind. To clean, simply wipe cabinet with a clean towel and mild soap
solution.

CAUTION: Never spray cabinet with a garden hose for any
reason since this action may induce an electrical short in the
spa’s electrical equipment.

11.8 Winterizing

Your Sundance spa is designed to automatically protect itself against
freezing when operating properly. During periods of severe freez­ing temperatures, you should check periodically to be certain that the
electrical supply to the spa has not been interrupted. In extreme, bitter

cold weather less than -20 °F (-29 °C), choose the F3 “Standard” ltra­tion/heating mode to prevent freezing (page 28). If you do not intend to

use your spa, or if there is a prolonged power outage during periods of

severe freezing temperatures, it is important that all water be removed
from the spa and equipment to protect against damage from freez-

ing. For expert winterization of your spa, contact your authorized
Sundance dealer. In emergency situations, damage can be minimized

by taking the following steps:

Page 34

1. Follow the directions on page 31-32 for draining the spa.

2. As the water level drops below the seats, use whatever means
necessary to get the water out of the recessed seating areas and

into the footwell.

3. When the water level ceases to drop, use whatever means available
to remove any remaining water from the footwell.

4. Turn off power to the spa.

5. Remove the equipment-side cabinet panels and locate the drain
plugs in the front of the pump(s) (Figure-A, page 13). Remove
these plugs to allow the water to drain out of the pumps and heater.

Note: Approximately one to two gallons will be released during this
procedure. Use a wet/dry vacuum or other means to keep this from
ooding the equipment compartment. Replace the drain plugs.

6. Loosen the hose clamp on the circulation pump intake behind the

control box (Figure-A, page 13) and pull the hose off (twist hose

back and forth while pulling outward). Tip hose down and allow to
drain, then reinstall hose and clamp.

7. Re-install cabinet side panels and cover spa so that no casual mois-

ture can enter into it.

Consult your authorized Sundance dealer if you have any questions
regarding winter use or winterizing.

11.9 Restarting Your Spa in Cold Weather

If you want to start up your spa after it has sat empty for a time in

freezing temperatures, be aware that the water remaining in certain sec­tions of the piping may still be frozen. This situation will block water ow

preventing the spa from operating properly and possibly damaging the
equipment. We recommend you consult your dealer for guidance before
attempting to re-start your spa under these conditions.

Page 35

12.0 Water Quality Maintenance

Maintaining the quality of the water within specied limits will serve to

enhance your enjoyment and prolong the life of the spa's equipment. It
is a fairly simple task, but it requires regular attention because the water
chemistry involved is a balance of several factors. There is no simple
formula, and there is no avoiding it. A careless attitude in regard to water
maintenance will result in poor and potentially unhealthful conditions for

soaking and even damage to your spa. For specic guidance on main­taining water quality, consult your authorized Sundance dealer who can
recommend appropriate chemical products for sanitizing and maintain-

ing your spa.

CAUTION: Never store spa chemicals inside the spa's
equiment bay.

12.1 pH Control

pH is a measure of relative acidity or alkalinity of water and is
measured on a scale of 0 to 14. The midpoint of 7 is said to be neutral,
above which is alkaline and below which is acidic. In spa water, IT IS
VERY IMPORTANT TO MAINTAIN A SLIGHTLY ALKALINE CONDITION
OF 7.4 to 7.6. Problems become proportionately severe the further
outside of this range the water gets. A low pH will be corrosive to metals
in the spa equipment. A high pH will cause minerals to deposit on the
interior surface (scaling). In addition, the ability of the sanitation agents
to keep the spa clean is severely affected as the pH moves beyond the
ideal range. That is why almost all spa water test kits contain a measure

for pH as well as sanitizer.

12.2 Sanitizing

To destroy bacteria and organic compounds in the spa water, a sanitizer

must be used regularly. Chlorine and Bromine are the two most popular

sanitizers used to date. Many other additives are available for your spa.

Some are necessary to compensate for out-of-balance water, some aid
in cosmetic water treatment and others simply alter the feel or smell of

the water. Your authorized Sundance dealer can advise you on the use

of these additives.

Page 36

12.3 Optional CD Ozone Water Maintenance System

If you have elected to have your spa equipped with the optional CD

Ozone water purication system you will nd that your water stays fresh
and clear with signicantly less chemical sanitizer usage. You will also

probably be able to go longer between complete spa drainings. The CD

ozone unit operates in conjunction with the circulation pump.

CAUTION: Do not use Chlorine tablets (Trichlor) in your spa.
This chemical can have an extremely corrosive effect on
certain materials in the spa. Damage caused by use of this
chemical, or improper use of any chemicals, is not covered
under the spa's warranty.

13.0 Error Conditions / Error Messages

13.1 Summer Logic

When the actual spa water temperature reaches up to 2°F

(1 °C) above the set temperature, the spa goes into “sum­mer logic.” The circulation pump will turn off automati-

cally to avoid adding additional heat to the water, even­tually creating an overheat condition. This setting is not
user-programmable.

Note: The summer logic does not take effect until the spa water temper­ature reaches 95 °F (35 °C). This condition is more likely in excessively
hot weather. Remember, the spa’s ability to cool is directly affected by
the ambient temperature. An excessively hot ambient temperature may
prevent the spa from cooling down because it’s fully insulated construc­tion is designed to retain heat and to minimize operating costs.

Page 37

13.2 Overheat Condition WARNING! DO NOT ENTER SPA WATER! Water is too hot.

Overheat protection. Heater is deactivated. Spa water tem­perature is above acceptable limits. When the actual water

temperature is approximately 2 °F (1 °C) above the set tem­perature, the circulation pump will stop operating to reduce (frictional)
heating. To correct condition, remove spa cover to speed cooling
(CAUTION! Never leave spa uncovered when children are present!)

If condition persists, contact your authorized Sundance dealer.

There are a number of unique functions designed into yo ur spa to

protect it from damage and/or aid in troubleshooting. Refer to sections

13.3-13.8 below for a listing of all possible error messages and their
meanings.

13.3 Panel displays SN1

Open sensor (heater is disabled) or shorted sensor (spa is
deactivated). The high-limit temperature sensor is not function-

ing. Your authorized dealer must repair this.

13.4 Panel displays SN2

Open or shorted sensor (heater disabled). The temperature

sensor is not functioning. Your authorized dealer must repair

this.

13.5 Panel displays FL1 or FL2

A ashing “FL1” display means the ow switch is

malfunctioning open, the circulation pump’s lter cartridge
is excessively dirty, or an “air lock” condition has occurred
at the circulation pump intake. A ashing “FL2” display
means the ow switch is malfunctioning closed.

• This error will cause the heater to deactivate. The main
pump #1 may also deactivate.

• This problem is caused by an interruption in water ow from an
excessively dirty lter cartridge, an “air lock” condition at the pump
intake, or by a malfunctioning ow switch.

Page 38

To Correct Condition:

1. Verify water level is 1” below lowest pillow. Add water if

necessary.

2. Check for clogged/excessively dirty lter cartridge. See

section 11.1 (page 29-30).

3. Purge “air lock” from circulation pump intake by removing the lter
cartridge. Hold your garden hose over the lter wall tting (with

grate) using a rag as a seal around hose end, then ask a helper to

turn on water for 30 seconds, then turn off. Reinstall lter cartridge

and check spa. See section 11.1 (page 29-30).

4. If problem persists, contact your authorized dealer.

13.6 Panel displays COL

Cool Condition - Temperature has dropped 20 °F (11 °C) below
the current set temperature. The pump and heater have been
activated to bring the temperature to within 15 °F (8 °C) of the

set temperature. No corrective action is required. Note: during
cold periods, you may consider increasing the number of ltration cycles.

13.7 Panel displays ICE

Freeze Protection - A potential freeze condition has been
detected. No action is required. Main pump will operate to
circulate warm water through the plumbing until the spa is out
of danger.

13.8 Panel displays - - -

The safety “Watchdog” software has been triggered and the
spa is deactivated. A problem has been detected which could
cause damage to the spa or its components. Contact your

authorized dealer.

Page 39

14.0 Troubleshooting Procedures

In the event your Sundance spa is not working the way it should, please

rst review all the installation and operating instructions in this manual

and check the message on the panel display. If you are still not satis-

ed it is working properly, please follow the appropriate troubleshooting

instructions. Note: If any of the supply cords to the accessories are
damaged, they must be replaced by authorized service personnel.

14.1 None of the Components Operate (e.g. Pump, Light)

Check the following:

1. Is there power to the spa?

2. Is the household circuit breaker tripped?

3. Call your authorized dealer.

14.2 Pump Does Not Operate but Light Does

Press the JETS Button:

1. If no water movement is detected, make sure power is going to the
spa and check the water level. If it does not solve the problem, con-

tact your authorized Sundance dealer.

2. The main pump operates but no water ows to jets. Pump may not

be properly primed. This can happen after the spa is drained and

relled. Press the JETS 1 button several times, never leaving the

motor on for more than 5 to 10 seconds at a time. Turn power off
and let the air out by loosening the cap on the massage selector

and/or removing the lter. Refer to section 8.3 (page 22). Make cer-
tain you tighten the massage selector cap and/or reinstall the lter

before turning on spa power and restarting the pump.

14.3 Poor Jet Action

1. Press the JETS 1 button to make certain the pump #1 is on.

2. Rotate the air control clockwise to the “on” position.

3. Check for dirty lter. Clean, if necessary.

4. Make sure jets are all the way open.

14.4 Water is Too Hot

Reduce thermostat setting so the heater turns off.

Page 40

14.5 No Heat

1. Check thermostat setting.

2. Keep the spa cover in place while heating.

3. Check the settings to see if your spa is in economy ltration/heating

mode (page 27-28).

Should checking the above steps fail to correct the problem, please call
your dealer so that they may arrange service. We build the best spas in
the industry. Nonetheless, we are always striving to improve the quality
and features of our products. Your input as a Sundance spa owner is
a cherished part of this process. If you have any comments or sugges­tions, or if you wish to be informed on any new products for your spa,
please write to us.

CONGRATULATIONS on your good taste and welcome to the happiest
and most relaxed family in the world!

Page 41

15.0 Convertible Metro Circuit Diagram (60Hz)

Ozonator

O

3

GRN

TB1

Standard 120 VAC 3-Wire Connection

(60 Hz, 1 Phase, 15 A Service)

Use copper conductors ONLY. Wire size must be

appropriate per NEC and/or local codes.

WHT

WHT

WHT

WHT

WHT

BLK

BLK

RED

BLK

BLK

BLK

BLK

BLK

RED

RED

RED

BLK

321

Heater

1.0 kW @ 120 VAC

4.0 kW @ 240 VAC

Flow Switch

Hi-limit/Freeze

Sensor

Temperature Sensor

J2

J3

F1

20A

250V

SC-20

Circ.

Pump

Main

Pump

Spa Light

Transformer

120 VAC

J4

BLK

RED

*

GRN

TB1

WHT

BLK RED

321

Optional 120/240 VAC

4-Wire Convertible

Heater Connection

1. Remove and discard the

factory installed GFCI Cord.

2. Move RED

*

wire from TB1

position #1 to TB1 position #3

as shown below.

3. Permanently connect to

the power supply. Use

copper conductors ONLY.

Wire size must be

appropriate per NEC and/or

local codes.

4. If hot tub is to be operated

on 30A service, make sure

the jumper provided at

location JP1 #1&2 on the

circuit board is installed. If

hot tub is to be operated on

40A service, remove the

jumper JP1 #1&2 on the

circuit board.

HILO

JP1

4

2

3

1

6 5

8 7

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful

interference.

2. This device must accept any inteference

received including interference that may

cause undesired operation.

J20

J21

J12

J14

J16

J11

J15

J13

J17 J7 J8 J9 J10

J5

J6

Heater IN Heater OUT

F1*

K1

K2

K3

K4

K5 K7 K8

J1

Control

Panel

Ozonator

O

3

GRN

TB1

Standard 120 VAC 3-Wire Connection

(60 Hz, 1 Phase, 15 A Service)

Use copper conductors ONLY. Wire size must be

appropriate per NEC and/or local codes.

WHT

WHT

WHT

WHT

WHT

BLK

BLK

RED

BLK

BLK

BLK

BLK

BLK

RED

RED

RED

BLK

321

Heater

1.0 kW @ 120 VAC

4.0 kW @ 240 VAC

Flow Switch

Hi-limit/Freeze

Sensor

Temperature Sensor

J2

J3

F1

20A

250V

SC-20

Circ.

Pump

Main

Pump

Spa Light

Transformer

120 VAC

J4

BLK

RED

*

GRN

TB1

WHT

BLK RED

321

Optional 120/240 VAC

4-Wire Convertible

Heater Connection

1. Remove and discard the

factory installed GFCI Cord.

2. Move RED

*

wire from TB1

position #1 to TB1 position #3

as shown below.

3. Permanently connect to

the power supply. Use

copper conductors ONLY.

Wire size must be

appropriate per NEC and/or

local codes.

4. If hot tub is to be operated

on 30A service, make sure

the jumper provided at

location JP1 #1&2 on the

circuit board is installed. If

hot tub is to be operated on

40A service, remove the

jumper JP1 #1&2 on the

circuit board.

HILO

JP1

4

2

3

1

6 5

8 7

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful

interference.

2. This device must accept any inteference

received including interference that may

cause undesired operation.

J20

J21

J12

J14

J16

J11

J15

J13

J17 J7 J8 J9 J10

J5

J6

Heater IN Heater OUT

F1*

K1

K2

K3

K4

K5 K7 K8

J1

Control

Panel

This wiring diagram is used for all US/Canada Metro 120/240 VAC
(60Hz) convertible power models.

Page 42

16.0 Camden Circuit Diagram (60Hz)

STEREO

(Optional)

Power Supply

OZONATOR (OPTIONAL)

O

3

GRN

TB1

Standard 240 VAC, 3-Wire Connection (60Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST

BE APPROPRIATE PER NEC AND/OR LOCAL CODES

RED

RED

J6

BLK

J5

WHT

WHT

WHT

WHT

RED

BLK

BLK

BLK

BLK

RED RED

BLK BLK

BLK

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

30A, 250V

SC-30

PUMP 1

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

Logic Jumper Settings (Factory Defaults Shown)

JP1 1-2 ON = 40A Logic

JP1 1-2 OFF = 50A Logic (Factory Default Setting

JP1 3-4 ON = 2 Pump Operation

JP1 3-4 OFF = 1 Pump Operation

JP1 5-6 ON = Not Used

JP1 5-6 OFF = Not Used

JP1 7-8 ON = ºC Temperature Display

JP1 7-8 OFF = ºF Temperature Display

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful

interference.

2. This device must accept any inteference

received including interference that may

cause undesired operation.

Heater

5.5 kW

240 VAC

STEREO

(Optional)

Power Supply

OZONATOR (OPTIONAL)

O

3

GRN

TB1

Standard 240 VAC, 3-Wire Connection (60Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST

BE APPROPRIATE PER NEC AND/OR LOCAL CODES

RED

RED

J6

BLK

J5

WHT

WHT

WHT

WHT

RED

BLK

BLK

BLK

BLK

RED RED

BLK BLK

BLK

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

30A, 250V

SC-30

PUMP 1

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

Logic Jumper Settings (Factory Defaults Shown)

JP1 1-2 ON = 40A Logic

JP1 1-2 OFF = 50A Logic (Factory Default Setting

JP1 3-4 ON = 2 Pump Operation

JP1 3-4 OFF = 1 Pump Operation

JP1 5-6 ON = Not Used

JP1 5-6 OFF = Not Used

JP1 7-8 ON = ºC Temperature Display

JP1 7-8 OFF = ºF Temperature Display

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful

interference.

2. This device must accept any inteference

received including interference that may

cause undesired operation.

Heater

5.5 kW

240 VAC

This wiring diagram is used for all US/Canada Camden 240VAC (60Hz)

dedicated power models.

Page 43

17.0 Certa/Chelsee/Hamilton Circuit Diagram (60Hz)

STEREO

(Optional)

Power Supply

OZONATOR (OPTIONAL)

O

3

GRN

TB1

Standard 240 VAC, 3-Wire Connection (60Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST

BE APPROPRIATE PER NEC AND/OR LOCAL CODES

RED

RED

J6

BLK

J5

WHT

WHT

WHT

WHT

RED

BLK

BLK

BLK

BLK

RED RED

BLK BLK

BLK

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

30A, 250V

SC-30

PUMP 1

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful

interference.

2. This device must accept any inteference

received including interference that may

cause undesired operation.

Heater

5.5 kW

240 VAC

40A Logic

40A

PUMP 2

HI

RED

BLK

STEREO

(Optional)

Power Supply

OZONATOR (OPTIONAL)

O

3

GRN

TB1

Standard 240 VAC, 3-Wire Connection (60Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST

BE APPROPRIATE PER NEC AND/OR LOCAL CODES

RED

RED

J6

BLK

J5

WHT

WHT

WHT

WHT

RED

BLK

BLK

BLK

BLK

RED RED

BLK BLK

BLK

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

30A, 250V

SC-30

PUMP 1

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

This device complies with Part 15 of the

FCC rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful

interference.

2. This device must accept any inteference

received including interference that may

cause undesired operation.

Heater

5.5 kW

240 VAC

40A Logic

40A

PUMP 2

HI

RED

BLK

This wiring diagram is used for all US/Canada Certa/Chelsee/ Hamilton
240VAC (60Hz) dedicated power models.

Page 44

18.0 Metro Circuit Diagram (50Hz)

Ozonator

O

3

TB1

230 VAC, 3-Wire Connection (50Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST

BE APPROPRIATE PER NEC AND/OR LOCAL CODES

21

Flow Switch

Hi-limit/Freeze Sensor

Temperature Sensor

J2

J3

F1

20A

250V

SC-20

Circ.

Pump

Main

Pump

Spa

Light

Transformer

230 VAC

J4

HILO

GRN

Export 230 VAC 50 Hz

Power Connections

BLU

BRN

JP1

4

2

3

1

6 5

8 7

Heater Specifications

Export 50 Hz Model:

2.7 kW @ 230 VAC

J20

J21

J12

J14

J16

J11

J15

J13

J17 J7 J8 J9 J10

J5

J6

Heater IN Heater OUT

F1

K1

K2

K3

K4

K5 K7 K8

BLK

WHT

BRN

BRN

BLU

BLU

BLU

BRN

BRN

BLK BLU BRN BLU BRN

J1

Control Panel

Ozonator

O

3

TB1

230 VAC, 3-Wire Connection (50Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST

BE APPROPRIATE PER NEC AND/OR LOCAL CODES

21

Flow Switch

Hi-limit/Freeze Sensor

Temperature Sensor

J2

J3

F1

20A

250V

SC-20

Circ.

Pump

Main

Pump

Spa

Light

Transformer

230 VAC

J4

HILO

GRN

Export 230 VAC 50 Hz

Power Connections

BLU

BRN

JP1

4

2

3

1

6 5

8 7

Heater Specifications

Export 50 Hz Model:

2.7 kW @ 230 VAC

J20

J21

J12

J14

J16

J11

J15

J13

J17 J7 J8 J9 J10

J5

J6

Heater IN Heater OUT

F1

K1

K2

K3

K4

K5 K7 K8

BLK

WHT

BRN

BRN

BLU

BLU

BLU

BRN

BRN

BLK BLU BRN BLU BRN

J1

Control Panel

This wiring diagram is used for Export Metro 230V (50Hz) dedicated
power models.

Page 45

19.0 Camden Circuit Diagram (50Hz)

OZONATOR (OPTIONAL)

O

3

GRN

TB1

230 VAC 3-Wire Connection (50Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST BE

APPROPRIATE PER NEC AND/OR LOCAL CODES

BLU

BLU

J6

BRN

J5

BRN

WHT

BRN

BLU

BLK

BLU

BLK

BLU

BRN

BLU BLU

BRN BRN

BRN

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

20A, 250V

SC-20

PUMP 1

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

Heater

2.7 kW @

230 VAC

OZONATOR (OPTIONAL)

O

3

GRN

TB1

230 VAC 3-Wire Connection (50Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST BE

APPROPRIATE PER NEC AND/OR LOCAL CODES

BLU

BLU

J6

BRN

J5

BRN

WHT

BRN

BLU

BLK

BLU

BLK

BLU

BRN

BLU BLU

BRN BRN

BRN

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

20A, 250V

SC-20

PUMP 1

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

Heater

2.7 kW @

230 VAC

This wiring diagram is used for Export Camden 230V (50Hz)
dedicated power models.

Page 46

20.0 Certa/Chelsee/Hamilton Circuit Diagram (50Hz)

STEREO

(Optional)

Power Supply

OZONATOR (OPTIONAL)

O

3

GRN

TB1

230 VAC 3-Wire Connection (50Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST BE

APPROPRIATE PER NEC AND/OR LOCAL CODES

BLU

BLU

J6

BRN

J5

BRN

WHT

BRN

BLU

BLK

BLU

BLK

BLU

BRN

BLU

BRN

BLU BLU

BRN BRN

BRN

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

20A, 250V

SC-20

PUMP 1

PUMP 2

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

Heater

2.7 kW @

230 VAC

STEREO

(Optional)

Power Supply

OZONATOR (OPTIONAL)

O

3

GRN

TB1

230 VAC 3-Wire Connection (50Hz, 1-Phase Service)

USE COPPER CONDUCTORS ONLY. WIRE SIZE MUST BE

APPROPRIATE PER NEC AND/OR LOCAL CODES

BLU

BLU

J6

BRN

J5

BRN

WHT

BRN

BLU

BLK

BLU

BLK

BLU

BRN

BLU

BRN

BLU BLU

BRN BRN

BRN

2

1

FLOW SWITCH

HI - LIMIT / FREEZE SENSOR

TEMPERATURE SENSOR

J1

J2

J3

F1

20A, 250V

SC-20

PUMP 1

PUMP 2

TRANSFORMER

240 VAC

J4

F1

JP1

4

2

3

1

6 5

8 7

7 6 2 4

HI

HI

LO

C

Control Panel

CIRC.

PUMP

SPA LIGHT

J20

K1

K2

K3

K4

K5

K6 K7 K8

J21

J11

J12

J13

J14

J15

J16

J17

J18

J19

J7

J8

J9

J10

Heater

2.7 kW @

230 VAC

This wiring diagram is used for Export Certa/Chelsee/Hamilton 230V

(50Hz) dedicated power models.

Page 47

21.0 Optional SunSound™ Stereo Receiver Functions

1

8 9 10 11 12 13 14 15 16 17

2 3 4 5 6 71

8 9 10 11 12 13 14 15 16 17

2 3 4 5 6 7

To start enjoying your new Sundance SunSound Stereo Receiver,

please read the following operation instructions in their entirety.

1. Power Button: Press PWR (Power) to turn deck on or off.

2. Equalization Button: Repeatedly press EQ/LD to choose from DSP

Off, Jazz, Pop, Classic, Rock or Vocal equalization options. Press
and hold EQ/LD for 2 seconds to enable or disable the “LOUD”

function.

Special Recommendation: After you have powered up your

Aquatic AV Audio System, we suggest you try one of the preset
DSP (digital sound presets) settings to customize the sound in
your spas audio system. It's easy, simply press the EQ/LD but­ton (2) to activate the DSP. Then repeatly press the button again
and you will be able to choose from Jazz, Pop, Classical, Rock
and Vocal DSP settings. This will enhance your listening experi-

ence and make it more enjoyable.

3. Mute Button: Press Mute to mute audio output. Press again to
return to previous volume level.

4. Open Button: Press Open to ip down the front access panel for
CD access. Gently insert CD into slot (DO NOT FORCE!) Make
sure to close the front panel to prevent damage to the unit. Note:

never insert a wet or moist CD since it may damage the mechanism
and void the manufacturer warranty.

Page 48

5. A/PS Button: Press A/PS to scan station presets. The tuner will
scan up, wait for a few seconds, then continue. Once a desired sta-

tion is found, press A/PS a second time to cancel scan. To automati­cally scan and store station presets, simply press and hold A/PS for

several seconds, then release.

6. DISP Button: Press DISP to switch between clock and station
frequency. When selected, the clock will display for 5 seconds then
automatically revert back to station frequency.

7. Source Button: Press Source to change input from audio, CD or

AUX mode (Auxiliary MP3 mode). Press a second time to switch

back. Note: Auxiliary Mode (AUX) enables external MP3 playback
mode. See section 21.3 page 57 for details.

8. Volume Buttons: Press + (Volume Up) or - (Volume Down) to

increase or decrease volume level.

9. SEL Button: Press SEL to choose control function:

1) Bass 4) Fader

2) Treble 5) Volume

3) Balance

To adjust selection, press + (Volume Up) or - (Volume Down). Bass

control: Adjusts the amount of low frequency. Treble control:

Adjusts the amount of high frequency. Balance control adjusts the

amount of sound output to the left and right speakers. Fader control
adjusts the amount of sound output. You can decrease the sound

level of the rear speakers by pressing + (Volume Up). To decrease
the sound level of the front speakers press - (Volume Down). Note:

Bass and Treble settings are available only if EQ is set to DSP Off.

10. Preset 1/Pause Play Button: In tuner mode, any station can
be stored as preset 1 by pressing and holding this button for 2
seconds. To recall the station preset, simply press and release this
button. In CD mode pressing this button will pause or play the CD.

11. Preset 2/INT Button: In tuner mode, any station can be stored as
preset 2 by simply pressing and holding this button for 2 seconds.
To recall the station preset, simply press and release this button. In
CD mode pressing this button will preview each song on the disc for
about 10 seconds. Simply press again to turn off this feature.

Page 49

12. Preset 3/RPT Button: In tuner mode, any station can be stored

1

8 9 10 11 12 13 14 15 16 17

2 3 4 5 6 7

as preset 3 by simply pressing and holding this button for several
seconds. To recall the station preset, simply press and release this
button. In CD mode pressing this button will play a song repeatedly.

Press again to turn off this feature.

13. Preset 4/RDM Button: In tuner mode, any station can be stored
as preset 4 by simply pressing and holding this button for several
seconds. To recall the station preset, simply press and release this
button. In CD mode press this button to randomly play song tracks.

Press again to turn off this feature.

14. Preset 5/DN Button: In tuner mode, any station can be stored
as preset 5 by simply pressing and holding this button for several
seconds. To recall the station preset, simply press and release this
button. In CD mode this button will browse the folders on CD-R and
CD-RW disks.

15. Preset 6/UP Button: In tuner mode, any station can be stored

16. BND Button: Press BND to select one of the following frequency

as preset 6 by simply pressing and holding this button for several
seconds. To recall the station preset, simply press and release this
button. In CD mode this button will browse the folders on CD-R and
CD-RW disks.

bands: FM1, FM2, FM3, AM1, AM2 and WB (weather band).

Page 50

17. Tuning UP/DOWN Buttons: Press Track Up to manually adjust sta-
tion frequency up. Press and hold Track Up to scan for next higher
station. Scan mode stops as soon as a strong station is found. Press
Track Down to manually adjust frequency down. Press and hold

Track Down to scan for next lower station. Scan mode stops as soon
as a strong station is found. In CD mode pressing these buttons will
advance the CD up or down to the next or previous track. To fast
forward or rewind through a track, simply press and hold either but­ton as desired during CD playback.

18. Reset Button (Not Illustrated): If keys do not function at all and the
unit appears to be "locked up", use a ballpoint pen to press the Reset

Button under the front panel (press OPEN to flip down front panel for

access). The Reset button is located directly below the Eject Button.

Press to clear all memory (except station presets) and reset deck.

Note: this action will reset the display and clock to default settings.

19. Eject Button (Not Illustrated): To eject CD, press OPEN and flip-
down the front access panel, then press the Eject button located to
the left of CD slot.

20. USA/Europe Switch (Not Illustrated): You can switch between

American (USA) and European radio frequency bands by flipping a
switch located on the bottom of the deck. To change bands:

1) Power down unit

2) Lift up sticker under the CD player.

3) Choose desired frequency band as indicated on the sticker. .

4) Put sticker back in place and power up the unit.

21. Setting The Clock (Unit Must be Off): To set the current time, press
and hold Display (6) for 3 seconds until the clock display starts to

blink, then set hours using the Track Up and/or Track Down button
(17). Press Display a second time to set minutes, using the Track Up
and/or Track Down buttons. Press and hold Display a third time to

exit clock setup (or simply wait for 5 seconds).

22. Selecting Weather Band Mode: Press BND (16) while in tuner
mode until WB displays (deck automatically skips to the strongest
weather channel) or press BND a second time to return to previous

mode. When WB weather band mode is active:

1) Press Track Up (17) to scan to higher weather channel.

2) Press Track Down (17) to scan to lower weather channel.

3) To save a weather channel preset, press and hold one of six

Page 51

numeric keys 1-6. Note: weather channel 7 is not accessible

1

8 9 10 11 12 13 14 15 16 17

2 3 4 5 6 7

through preset key.

23. Display information DISP: When a retail music CD is

inserted, press DISP (6) to change modes as follows:

1) Clock (displays for 5 seconds only).

2) CD track no. / Playtime

When a CD containing MP3 les is inserted, press DISP (6)
change modes as follows:

1) Clock (displays for 5 seconds only).

2) Track no. / Playtime

3) Folder name

4) File name

5) Song name

6) Artist’s name

7) Album name

The system can only display the rst 8 letters of ID3 tags. If the

recorded information is longer than 8 letters, text will scroll to the left

once, then the 8 rst letters will be displayed. If specic info has not
been recorded on an MP3 disc, NO FOLD, NO TRK, NO TLT, NO

ALBM, NO ART will display.

24. Playback Order of CD with MP3 Files:

1) A directory that does not include an MP3 le is skipped.

2) We recommend that you make no more than two levels for each

disc.

Page 52

3) Maximum number of folders: 256

4) Maximum number of folder levels: 8

5) Maximum number of characters for MP3 le name and

folder name: 32

6) Sampling frequency: 16 kHz, 22.05 kHz, 24 kHz, 32 kHz, 44.1

kHz, 48kHz

7) Bit rates: 8-320 Kbps

8) MP3 decoding format: MPEG 1 & 2 Audio Layer 3

9) Folder names and le names can be displayed with up to 8 char-

acters (see Display key).

10) The characters A-Z, 0-9 can be displayed on this unit, other

characters may not be displayed correctly.

11) ID3 tag is supported (see Display key).

25. Reading MP3 les from a disc: When a disc containing MP3 data
is loaded, the unit checks all the data on the disc. If the disc contains
numerous folders with many levels, it takes a longer time to start
playback. In addition, it may take time for the unit to move to the

next MP3 le and the fast forward function may not be performed
smoothly. When selected to play, les and folders are accessed in

order in which they were written by the CD writer. Therefore, the
playing order may not be the same as the order in which they are
expected. For example, a disc with the following folder/le hierarchy

is subject to folder select, le select and play back order as illustrated
on page 55.

Page 53

21.1 SunSound™ Audio Receiver Specifications

• Marine Grade AM/FM/CD/CD-R/CD-RW/MP3

• 7 Bands of Weather Band

• Stainless Steel Sealed Chassis and Mounting Hardware

• IPX5 Water Intrusion & CFR-46 Rated

• Conformal Coated Printed Circuit Boards

• ASTMB117 Salt Fog Tested 400 Hours

• ASTM D4329 UV Stable Tested 400 Hours

• Double Sealed Water Protection Transport Gaskets

• White Low Current / Low Heat LCD

• White Backlit Control Surfaces

• 5 Band Digital Sound Stage Settings

• 200 Watt, 50 x 4

• MP3 with ID-3 Tag, Video

• Switchable Tuner Frequency U.S. or Euro Band/CE Approved

Page 54

Press and hold to go 10 les forward.

Example of a disc's folder/le hierarchy

Folder

File

Level 1 Level 2 Level 3 Level 4 Level 5

Operation of the keys

Press and hold to return 10 les behind.

Press (Track Down) to select folder down

Press (Track UP) to select folder up

5

6

Page 55

21.2 Audio System Remote Control

SOURCE

VOL

PWRPWR

D

C

E

F

G

H

A

B

A remote control is supplied on all spas with the
optional audio system. This remote provides control
over all radio and CD playback functions.

External MP3 Playback

The supplied remote control provides no control over

external MP3 player operation of any kind with the

exception of volume control and source selection.

All external MP3 playback operations are performed solely by the MP3
player. Refer to section 21.3 for external MP3 player connection and

operation details.

A. LED Display: displays the current radio or CD operation functions

and presets.

B. Feature not available.

C. Station Preset Button: Press to choose next AM/FM radio

preset station

D. Tuning UP/Down Button: Press to search for next radio sta-

tion. In CD mode, press either side of the button to advance to next
CD track or to recall previous CD track

E. Band Button: Press to select FM1, FM2, FM3, AM1, AM2 or WB

(weather band, page 52)

F. Source Button: Press

to select AM/FM radio mode, CD mode

or AUX mode for external MP3 player use (sec. 21.3 page 57).

G.

Volume Button: Press

to adjust volume level higher or lower.

H. Power Button: Press to turn audio system on or off

Page 56

21.3 Optional MP3 Player Connection

A. Connecting Your MP3 Player

1. Plug in the MP3 Player (purchased separately) with supplied mini

RCA cable into the auxiliary port (Figure A).

2. Plug the other end of the supplied cable into the phone jack connec­tion on the MP3 Player (Figure B).

(iPod shown for demonstration purposes only)

Figure A

Figure B

B. Enabling MP3 Player for Use

1. Select preferred song/album/play list and start playback prior to
plugging in MP3 Player.

2. Press “Source Button” on stereo receiver or remote until the display
reads “AUX” as shown.

C. Operating MP3 Player

All playback operations are conducted via the MP3 Player. The

Stereo Deck and/or Stereo Remote functions do not work on the
external MP3 Player.

WARNING: Electrical Shock Hazard Exists!

Never install, remove or operate iPod or MP3 Player while

hands are wet or while sitting partially or fully immersed in
spa!

Page 57

The following UL requirements must be observed for all
spas with optional stereo components installed.

A. “CAUTION - Risk of Electric Shock. Do not leave compartment door open”;

B. “CAUTION - Risk of Electric Shock. Replace components only with identical

components”; and

C. Do not operate the audio/video controls while inside the spa.”

D. “WARNING - Prevent Electrocution. Do not connect any auxiliary components
(for example: cable, additional speakers, headphones, additional audio/video

components etc.) to the system.”

E. These units are not provided with an outdoor antennae; when provided, it should be

installed in accordance with Article 810 of the National Electric Code, ANSI/NFPA 70.

F. Do not service this product yourself as opening or removing covers may expose you

to dangerous voltage or other risk of injury. Refer all servicing to qualified service
personnel.

G. When the power supply connections or power supply cord(s) are damage; if water is

entering the audio/video compartment or any electrical equipment compartment area;
if the protective shields or barriers are showing signs of deterioration; or if there are
signs of other potential damage to the unit, turn off the unit and refer to a qualified
service personnel.

H. This unit should be subjected to periodic routing maintenance (for example, once

every 3 months) to make sure that the unit is operating properly.

P/N: 6530-509, Rev. A

Page 58

Notes:

Notes:
