FCC ID: 2AI5B-SO58
SO58
1080P
GETTING STARTED
Welcome
Congratulations on your new camera!This user manual will help you to learn the basics of
capturing life’s most incredible moments!
TO Power ON
Press the Power/Mode Button
To Power OFF
Press and hold the Power/Mode Button
OVERVIEW
Turn camera ON and repeatedly press the Power/Mode button to cycle through video
modes,photo modes, playback and settings.The modes will appear in following order
SETTING MENU
Press the Power/Mode button to enter the settings menu,Repeatedly press the down/on
button to cycle through options and press the OK button to select desired option.
*As below are the details of the setting menu,including all types of camera’s setting
menu.
PAGE1
: 1080FHD (1920X1080)/1080P (1440X1080)/720 (1280x720)/ WVGA
Exposure:+2.0,+5/3,+4/3,+1.0,+2/3,+1/3,+0.0,-1/3,-2/3,-1.0,-4/3,-5/3,-2.0
: off/on
: off/1min/2min/3min/5min/10min
: off/1s/2s/5s/10s/30s/1min
: off/on
: off/on
: off/on
Image size: 16M/12M/10M/8M/5M/3M/2MHD/1.3M/VGA
: Fine/Normal/Economy
: Off/3s/5s/10s/20s Timer
: strong/normal/soft
: Auto/100/200
: off/on
: Auto/daylight/cloudy/tungsten/fluorescent
Frequency: 50HZ/60HZ
: off/on
: off/1min/2min/3min
: off/on
: off/3min/5min/10min
: English/Chinese/Japanese/French/Deutsch/Korean/Italian/Portuguese
Beep Sound: off/on
: MM/DD/YY,YY/MM/DD,DD/MM/YY
: off/on
:
Resolution
(848x480) / VGA (640x480)
Motion Detection
Cyclic Record
Video Lapse
WDR
PAGE 2
Record Audio
Date Stamp
Quality
Capture Mode
Sharpness
PAGE 3
ISO
Anti-Shaking
White Balance
OSD Mode
Screen Saver
PAGE 4
Rotate
Auto Power Off
Language
Date/Time
Polish/Spanish/Turkey
PAGE 5
Car Mode
WIFI SSID
SPORT DV
WIFI Password: 12345
Delete: Current/All
Format: Cancel/OK
Default Setting: Cancel/OK
Version: firmware
PAGE 6
VIDEO MODE
To record video, verify the camera is in Video mode. If the video icon on your camera’s
LCD screen is not showing, press the Power/Mode button repeatedly until it appears.
To start recording:
Press the OK button, the camera status Lights will flash while recording.
To stop recording:
Press the OK button, The camera Status Lights stop flashing and the camera emits one
beep to indicate recording has stopped.
This camera automatically stops recording when the battery is out of power. Your Video
will be saved before the camera powers OFF.
PHOTO MODE
To capture a Photo,v erify the camera is in Photo mode. If the Photo icon on your camera’s
LCD screen is not showing, press the Power/Mode button repeatedly until it appears
To take a photo:
Press the OK button.the camera will e m i t the camera shutter sound
PLAYBACK
Playing Back Videos and Photos
To enter the Playback Menu:
1:Press the Mod e button to enter the playback Mode
2:Use the UP and DOWN button to cycle through the various options,press the OK button
to select desired opti
on
STORAGE/MICROSD CARDS
This camera is compatible with 4GB,16GB and 32GB capacity micro SD, microSDHC, and
microSDXC memory cards, you must use a microSD card with a Class 10 speed rating. We
recommend using brand name memory cards for maximum reliability in high-vibration
activities
BATTERY
Charging The Battery
To charge the battery
1. Connect the camera to a computer or USB power supply
2. The Charging Status Light remains ON while the battery is charging.
3. The Charging Status Light will turn OFF when the battery is fully charged.
4. Charging Time:3.5 hours (5v,500mah)
CAMERA APP
Connecting to the App(Wi-Fi Edition Only)
The App lets you control your camera remotely using a smart phone or tablet. Features
include full camera control,live preview,photo playback and sharing of select content and
more.
1. Download the App(GoPlus Cam) to your smart phone or tablet at the Apple App Store
or Google Play.
2. Press the Power/Mode button to power camera ON
3. Make sure the camera is in video or photo modes
4. Press the UP button turn on the Wi-Fi, and there will show the wifi name and password
on your camera’s LCD screen.
5. In your smart phone or tablet’s Wi-Fi settings, connect to the network called”
XtremePro ” followed by a series of numbers.
6. Enter the password “1234567890”,which shows on your camera’s LCD screen.
7. Open the App on your smart phone or tablet, press connect into
*Press the UP button to turn OFF Wi-Fi.
The App is compatible with smart phones and tablets listed below.
For Apple ios:
*iphone6,6s,6&6Plus(ios9)
*ipad Air & Mini(ios9)
For Android:
*Android 4x Quad-core devices
COMPATIBILITY
*Compatibility varies by device. Content playback, sharing and access to the camera’s
memory card might be not available on some devices
FCC STATEMENT :
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including
interference that may cause undesired operation.
Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF warning statement:
The device has been evaluated to meet general RF exposure
requirement. The device can be used in portable exposure condition
without restriction.
- English: "
This device complies with Industry Canada licence-exempt RSS standard(
s). Operation is subject to the following two conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that
may cause undesired operation of the device."
- French:"
Le présent appareil est conforme aux CNR d'Industrie Canada applicables
aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le
fonctionnement."
