LUXURY WARMING PILLOW TOP MATTRESS PAD

P.N. 112866

IMPORTANT INSTRUCTIONSDO NOT DESTROY

As with all electrical products, misuse of product or failure to properly follow the instructions may cause overheating, fire, or personal injury. Please read the product label and all of the instructions before using your warming product.

1. Do not use this warming pillow top mattress pad with an infant, a child, an incapacitated person, a paraplegic, a quadriplegic, a diabetic, one insensitive to heat such as a person with poor blood circulation, or anyone who cannot clearly understand the instructions and/or operate the controls.

2. Do not use with damaged cords. Damaged cords can lead to fire. Do not trap, fold, cross, or pinch cords between bed slats, mattress, or springs, or against walls, footboards, or bed frame.

3. Do not dry clean this warming product. Cleaning liquid may damage the insulation of the heating element. Improper laundering may cause problems with the heating wire which can lead to fire.

4. Do not pinch, flex, or expose the heating wire to rubbing. A damaged heating wire may result in possible overheating or fire.

5. Turn off the control for the warming product when not using.

6. Keep control away from an open window.

7. Do not use pins; they may damage the electric wiring.

8. Be sure this warming pillow top mattress pad is used only on an AC supply current circuit of 110-120 volts. Do not use with an extension cord.

9. May experience increased heat in areas where warming product is bunched or folded while in use.

10. Keep all dogs, cats, and other pets away from this warming product. This is an electrical appliance that they can damage or be injured by.

11. Do not use warming pillow top mattress pad on a waterbed, sofa, bunk bed, or mechanically adjustable bed.

12. Do not use another electronic heating device in conjunction with your warming product.

13. Use the proper size warming pillow top mattress pad for your bed. For example, use a Twin Size mattress pad on a Twin Size bed.

14. If the following Important Instructions are not followed the warming product will not operate properly.

15. If you see the warming product operating improperly, unplug it immediately and call Sunbeam Consumer Service at the 800 number listed under “How to Obtain Warranty Service”.

Warnings and Safeguards

Welcome

Thank you for choosing a Sunbeam

warming product. With your purchase

you’ve made a real investment in your

comfort and can look forward to

staying warm and cozy for many cool

days to come.

With over 50 years of experience and

over 25 million households using a

Sunbeam®warming product, you can

rest comfortably knowing that

Sunbeam®is the brand to trust…

for quality and performance.

So get ready for a more restful sleep.

Controller Matrix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Auto-Off & Pre-Heat features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Fold Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-7

Installing the batteries . . . . . . . . . . . . . . . . . . . . . . . .4

Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Using your control(s) . . . . . . . . . . . . . . . . . . . . . . . . . .5

Dual operation settings . . . . . . . . . . . . . . . . . . . . . . . 5

Step-by-Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Multiple Remote Control Warming Products . . . . . . . . . . . 6-7

Changing the remote settings . . . . . . . . . . . . . . . . . . . 6

Changing the base unit settings . . . . . . . . . . . . . . . . . . 7

DD 2 Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-9

Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Using your control(s) . . . . . . . . . . . . . . . . . . . . . . . . . .9

Dual operation settings . . . . . . . . . . . . . . . . . . . . . . . 9

Step-by-Step . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Care and cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-12

War ranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

How to obtain warranty service . . . . . . . . . . . . . . . . . . 14

Ta ble of contents

Controller feature matrix

Part Number Cordless Backlit Auto-Off Warming Silent Pre-Heat Easy Easy Grip

Operation Display Settings Operation Operation

Remote ❂❂10 hour 10 ❂❂❂ ❂

DD2 ❂ 10 hour 20 ❂❂❂ ❂

Auto-Off & Pre-Heat features

Auto-Off Feature for warming pillow top mattress pad control:

The “Auto-Off” feature is designed for safety and conservation of energy by automatically turning your warming product off after 10 hours of continuous use.

The Auto-Off function engages 10 hours after the control is turned “ON”.

For Dual Control: Each control operates independently and will turn off

10 hours after the control is turned “ON”.

Pre-heat:

1 To use the preheat feature, simply press the round “On/Off” button and then

press the “Preheat” button. The preheat function will heat the bed for a period of 30 minutes.

2 To reset the preheat feature, simply press the “On/Off” button OFF. 3 To turn back ON repeat step 1.

To restart all warming products after a power failure:

Press the “On/Off” button, the warming product will begin to warm. Note: After a power outage, the “Auto-Off” feature automatically resets the timer.

I85R (Single Control) I85RKQ (Dual Control)

85P (Single Control) 85KQP (Dual Control)

Fold test

Before initial use:

1 Remove product from vinyl storage bag /box. 2 Pull controls from center fold of the warming product. 3 Make sure the control cord (base unit cord – remote

only) is connected to the mattress pad module then plug the power cord into an outlet.

4 Press “On/Off” button, then turn the control to the

highest setting and wait five to seven minutes.

5 Put your hand between the folds and you should feel the

mattress pad warming. Note: Remember, the warming product is not a heating pad. It will not feel hot to the touch when laid out flat in a normal manner.

CAUTION: Do not continue the fold test for more than seven minutes. DO NOT attempt to make any internal adjustments to this appliance. If you have followed each step of the fold test and the warming product does not heat, stop using it immediately, disconnect the power cord and contact Consumer Services at the 800 number listed under How to Obtain Warranty Service (page 14).

DUAL CONTROL SET UP

run cord

under the bed

Base Unit

(under the bed)

Cord Connector

Module

Label

Power Cord

Flag Tag

Head of the bed

Foot of the bed

run cord

under the bed

Base Unit

(under the bed)

Cord Connector

Module

Label

Power Cord

Flag Tag

Head of the bed

Foot of the bed

SINGLE CONTROL SET UP

Features:

• REMOTE CONTROL – cordless operation

• AUTO-OFF – 10 hour independent auto-off (see page 2)

• ELECTRONIC DIGITAL CONTROL – for easy setting with backlit LCD

• PRE-HEAT – for cozy warmth before bedtime (see page 2)

• 10 TEMPERATURE SETTINGS – select your personal comfort level

• SOLID STATE – for accurate and consistent heat control

• EASY GRIP – ergonomic control for easy operation

• AUDIBLE BEEP – indicates setting change

I85R (Single Control) I85RKQ (Dual Control)

Remote

Installing the Batteries:

1 Remove the battery compartment door from the back

of the remote control.

2 Insert three AAA batteries, matching the + and -

markings in the battery compartment to the markings on the batteries.

3 Replace the battery compartment door. 4 If your pillow top mattress pad has two remote

controls, repeat steps 1 – 3 to install batteries in the second remote control. (Three AAA batteries per control not included)

1 Lay the warming pillow top mattress pad on the bed with the label at the foot of the bed (pillow top

surface facing up, module facing down).

2 Make sure the base unit cord is connected into the module until

the plastic hinges click into place. CAUTION: Cord must be COMPLETELY CONNECTED. A risk of fire could result from a loose connection.

3 Run the base unit cord on the floor under the bed. Do not

sandwich cord between the mattress and box spring. Avoid any tangling or pinching.

4 Place the base unit on the floor under the bed. 5 Control placement:

• Dual Control – from the lying position, place the right control on the right side of the bed.

Place the left control on left side of bed.

• Single Control – Place the remote control where it is convenient for you.

6 Plug power cord into a 110-120 volt wall outlet.

*Please see page 6 if you have more than one Sunbeam Remote Control Warming Product.

Step-by-step

CAUTION: Do not plug main power cord into the wall outlet until you have completely set up your warming product per the instructions.

• Disconnect power cord from wall before detaching control from warming product.

• Always make sure cords are NOT trapped or pinched between bed slats, mattress, springs, against wall, foot board or bed frame, or between furniture, walls or chairs.

CAUTION: Do not attempt to force the plug. This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electrical shock, this plug is intended to fit only one way into an outlet. If the plug does not fit in the outlet, reverse the plug. If it still does not fit, contact a qualified electrician.

IMPORTANT

Using your Remote Control(s):

1 To turn the warming pillow top mattress pad ON, simply press the

“On/Off” button. The backlit display light will illuminate and begin to warm at the comfort setting last used.

CAUTION: ALWAYS turn the warming pillow top mattress pad OFF when not in use.

2 To turn the warming pillow top mattress pad OFF simply press the

“On/Off”.

Dual operation settings:

While lying in bed, each person can have complete control over his/her comfort level for ultimate personalized warmth.

From the lying position:

Either “right” or “left” control can be set to operate the entire pillow top mattress pad.

• Locate the dual control setting switch (on back of each control, above battery panel).

• Set switch to preferred operating setting – both sides or one side only.

The “left” control operates the left side.

The “right” control operates the right side.

Dual Control Setting Switch

If you own two or more Sunbeam remote controlled warming products (in your home), interference is likely to occur. To avoid interference between multiple remote controlled warming products, you must change the address of both the remote control and the base unit of the second warming product.

To change the address of your SECOND warming product:

Remote Control:

1 Open the battery door on the remote control(s). You will see a small square silver colored switch under the battery door latch. 2 You will see two small switches labeled “1” and “2”. To change the address of the remote, carefully move one of the switches to the up

position with a small screwdriver.

Once the address has changed on the controller, you must set the base unit switch to match.

WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate equipment.

Multiple Remote Control Warming Products

3 alternate address options

standard address

Remote controller

Base Unit:

1 Unplug the base unit and turn it over. Carefully insert a small screwdriver blade in the slot of the small 1/2 in. square cover over the

switches and lift the cover off the base.

2 To change the address of the base unit, carefully move one of the switches to the up position replicating the position on the remotes.

3 Snap the cover back into place, plug in the base unit and check that the base unit can receive instructions from the remote (the base

unit should beep when the on/off button is pushed or the comfort level is set on the remote).

The remote control and base unit address settings must be identical.

Note: Repeat steps above using suggested settings for any additional remote controlled warming products.

3 alternate address options

standard address

Base unit

DD2

Features:

• DIGITAL CONTROL – with backlit LCD for night time viewing

• AUTO-OFF – 10 hour independent auto-off (see page 2)

• 20 TEMPERATURE SETTINGS – select your personal comfort level

• SILENT OPERATION – no clicking

• PRE-HEAT – for cozy warmth before bedtime (see page 2)

• SOLID STATE – for accurate and consistent heat control

• EASY OPERATION – electronic digital controller for easy operation

• EASY GRIP – ergonomic control for easy operation

run cord

under the bed

Cord Connector

Flag Tag

Head of the bed

Foot of the bed

run cord

under the bed

Cord

Connector

Secondary

Control

Primary Control

Head of the bed

Foot of the bed

Flag Tag

DUAL CONTROL SET UPSINGLE CONTROL SET UP

85P (Single Control) 85KQP (Dual Control)

Using your Control(s):

1 To turn the control ON, simply press the “On/Off” button. The backlit

display light will reset itself by flashing “88” and then will return to the previous setting and will begin to warm.

CAUTION: ALWAYS turn the warming pillow top mattress pad control OFF when not in use.

2 To turn the warming mattress pad control OFF simply press the

“On/Off” button.

1 Lay the warming pillow top mattress pad on the bed with the label at the foot of the bed (pillow top

surface facing up, module facing down).

2 Make sure the control cord is connected into the module at the

bottom of the warming pillow top mattress pad until the plastic hinges click into place. CAUTION: Control cord must be COMPLETELY CONNECTED. A risk of fire could result from a loose connection.

3 Run the control cord on the floor under the bed. Do not sandwich

cord between the mattress and box spring. Avoid any tangling or pinching.

4 Control Placement:

• Dual Control pillow top warming mattress pad – from the lying position, place primary control

(label on back of control) on the right side of the bed. Place the secondary control on left side of bed.

• Single Control pillow top warming mattress pad – the control can be placed on either

side of the bed.

5 Plug power cord into a 110-120 volt wall outlet.

Step-by-step

CAUTION: Do not plug main power cord into the wall outlet until you have completely set up your warming product per the instructions.

• Disconnect power cord from wall before detaching control from warming product.

• Always make sure cords are NOT trapped or pinched between bed slats, mattress, springs, against wall, foot board or bed frame, or between furniture, walls or chairs.

IMPORTANT

Dual control placement:

While lying in bed, each person can have complete control over his/her comfort level for ultimate personalized warmth. From the lying position – place primary control (label on back of control) on the right side of the bed.

The “primary” control operates the right side.

The “secondary” control operates the left side.
