Sunbeam SR6856B User Manual

MASTER SERIES
Verve® Irons
User Guide
This booklet covers the use and care of the following Irons SR6856B Verve
SR6851 Verve
®
Extreme Steam Resilium® Shot & Spray Iron with Safety Auto-Off
®
Max Glide Resilium® Shot & Spray Iron with Safety Auto-Off
SR6856B
SR6851
Contents
Sunbeam’s Safety Precautions 3 Features of your Verve Iron 4 Using your Verve Iron 6 The Safety Auto-Off Feature 7 Care and Cleaning of your Verve Iron 8 Ironing Tips & Tricks 9 Ironing Chart 10
Important instructions – retain for future use.
Sunbeam’s Safety Precautions
SAFETY PRECAUTIONS FOR YOUR IRON
• Do not leave a hot iron within reach of children. If they come into contact with a hot iron it could lead to serious burns.
• Iron only on an ironing board.
• An iron takes approximately 30 minutes to cool down. Allow the iron to cool completely before storing.
• Do not wind the cord around the soleplate while the iron is still hot.
Sunbeam is very safety conscious when
designing and manufacturing consumer products, but it is essential that the product user also exercise care when using an electrical appliance. Listed below are precautions which are essential for the safe use of an electrical appliance:
• Read carefully and save all the instructions provided with an appliance.
• Always turn the power off at the power outlet before you insert or remove a plug. Remove by grasping the plug - do not pull on the cord.
• Turn the power off and remove the plug when the appliance is not in use and before cleaning.
• Do not use your appliance with an extension cord unless this cord has been checked and tested by a qualified technician or service person.
• Always use your appliance from a power outlet of the voltage (A.C. only) marked on the appliance.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• The temperature of accessible surfaces may be high when the appliance is operating.
If you have any concerns regarding the performance and use of your appliance, please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
• Do not leave the iron unattended while it is plugged into the power outlet.
• Always unplug the iron from the power outlet before filling or emptying the water tank.
• The iron must be used and rested on a stable surface.
• The iron is not to be used if it has been dropped, if there are visible signs of damage or if it is leaking.
• When placing the iron on its heel rest, ensure the surface on which it is placed is stable.
• Never leave an appliance unattended while in use.
• Do not use an appliance for any purpose other than its intended use.
• Do not place an appliance on or near a hot gas flame, electric element or on a heated oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang over the edge of a table or bench top or touch any hot surface.
• Do not operate any electrical appliance with a damaged cord or after the appliance has been damaged in any manner. If damage is suspected, return the appliance to the nearest Sunbeam Appointed Service Centre for examination, repair or adjustment.
• For additional protection, Sunbeam recommend the use of a residual current device (RCD) with a tripping current not exceeding 30mA in the electrical circuit supplying power to your appliances.
• Do not immerse the appliance in water or any other liquid unless recommended.
• Appliances are not intended to be operated by means of an external timer or separate remote control system.
• This appliance is intended to be used in household and similar applications such as: staff kitchen areas in shops, offices and other working environments; farm houses; by clients in hotels, motels and other residential type environments; bed and breakfast type environments.
Features of your Sunbeam Verve Iron
Powerful shot of steam
Pressing the shot of steam button instantly produces a powerful shot of steam to remove stubborn wrinkles.
Vertical shot of steam
Pressing the shot of steam button with the iron in an upright position produces a vertical shot of steam, which is ideal for steaming curtains and suits, and removing creases from delicate fabrics.
Fine spray mist
Pressing the spray button provides a fine mist spray to dampen hard-to-iron fabrics.
Easy-fill water inlet
Holds 300ml of water for continual high steam performance without having to refill the tank regularly.
Drip-s
top steam system
The drip-stop steam system automatically stops water flowing to the steam chamber should the temperature fall too low to generate steam. This prevents dripping, even at low temperatures.
Full length button groove
For ironing around buttons.
2400 watts for fast heat up
Provides faster initial heat up and rapid heat recovery during ironing. The 2400W element helps to maintain your selected temperature, and provides superior shot of steam output.
Resilium® non-scratch soleplate
Resilium® is a durable, scratch resistant surface that provides a superior glide and prevents rucking. Exclusive to Sunbeam, this premium soleplate features 172 steam holes to maximise steam distribution.
4
Steam Dial
Temperature Dial
Safety auto-off
The iron automatically switches itself off if left in the ironing position (horizontal) for 30 seconds, or in the heel rest position (vertical) for 15 minutes. (For more information on the
safety auto off feature see page 7).
Power light
Illuminates to indicate that the iron is connected to the power outlet and the power is turned on.
Thermostat light
Illuminates to indicate that the iron is heating and goes out when it has reached the temperature selected on the temperature dial. The thermostat light cycles on and off during ironing as the iron maintains the selected temperature.
Stable heel rest
Extra large heel rest keeps the iron stable on the ironing board.
Cord wrap
The built-in cord wrap facility allows you to wind the cord around the heel for neat and tidy storage of the cord when the iron is not in use.
Concentric steam and temperature dials
The steam and temperature dials are positioned together for easy adjustment.
Variable steam dial
Allows you to select the desired steam output for each garment. Alternatively, select the DRY setting to iron without steam.
Temperature dial
Allows you to select the desired temperature for each garment. The adjustable temperature dial also indicates the amount of steam recommended for use on each temperature setting.
5
Using your Sunbeam Verve Iron
Before first use
Remove any adhesive stickers, plastic covers or cardboard sleeves from the soleplate.
Ensure that all adhesive is removed by rubbing the soleplate with a cloth dampened with methylated spirits.
Fill the water tank and empty the water. This will rinse out any foreign particles remaining in the water tank from the manufacturing process.
NOTE: When turned on for the first time, your new iron may give off vapours for up to 10 minutes. This is due to the initial heating of the materials used. It is safe, not detrimental to the performance of the iron, and will not reoccur.
Filling the iron with water
re filling the iron with water ensure the
Befo power is turned off and the plug is removed from the power outlet. The iron can be filled with water while it is hot.
Place the iron on its heel and open the water inlet cover.
Slowly pour water into the water inlet until the maximum water level is reached. Do not exceed the maximum water level indicator.
Push the water inlet cover firmly to close. NOTE: The special soleplate design allows you
to use tap water with your Verve iron without affecting the steam performance. However in very hard water areas, Sunbeam recommends the use of distilled water, or wate been demineralised.
For best performance, we recommend the use of Sunbeam Demineralised Water, available from selected retailers. Use as a direct replacement for tap water to prolong the life of your iron.
Do not fill the iron with fabric conditioner, starches or any other solution as these will damage the steam mechanism. Do not use contaminated water.
r which has
Using your iron
1. Insert the plug into a 230/240 volt power outlet and turn the power on. The power ON light (positioned on top of the handle) will illuminate to indicate that the iron is switched on and heating.
2. Turn the temperature dial to the desired setting by aligning the set dial with the temperature indicator. The thermostat light will illuminate to indicate that the iron is heating to the selected temperature. When the thermostat light goes out the iron has reached the selected temperature and is ready to use.
NOTE: When the temperature dial is changed from a high setting to a lower temperature setting during ironing, the thermostat light will go out immediately. This indicates that the iron is cooling to the selected temperature. To ensure that the iron has reached the selected temperature and is not too hot, until the thermostat light comes on again and then goes out before ironing.
Steam ironing
Follow steps 1 and 2 above. NOTE: When steam ironing, ensure that the
temperature dial is set to any temperature within the steam band, and that the tank is at least ¼ full of water.
ting on the
wait
3. Turn the steam dial to the desired steam setting.
Steam Dial
Temperature Dial
For best results, select the steam setting that corresponds to the selected temperature, as indicated on the temperature dial.
6
Using your Sunbeam Verve Iron (continued)
Dry ironing
Follow steps 1 and 2 above.
3. Select DRY on the steam dial. This will cut off the steam flow if there is water in the tank.
Using the shot of steam
The shot of steam can be used when dry or steam ironing, when the temperature dial is set to any temperature within the steam band or above the two dot (••) setting.
1. Ensure the tank is at least
2. Select the desired temperature and wait until the thermostat light goes out.
3. Press the shot of steam button times with the iron on the soleplate to prime the pump.
¼ full of water.
several
Note: If the tank has run dry, it may be necessary to re-prime the pump after filling the iron with water.
Using the spray mist
The spray mist can be used whether dry or steam ironing to pre-dampen hard to iron fabrics.
1. Ensure the tank is at least
2. Press the spray button during ironing to release a fine mist from the spray nozzle.
The safety auto-off feature
The safety auto-off mecha turns the iron off if you forget.
The iron will automatically shut off if left on the heel rest (vertical) for 15 minutes, or in the ironing position (horizontal) for 30 seconds, without being moved.(See figure 2).
The thermostat and power lights on the handle will flash and a warning beep will sound to let you know that you have left the iron unattended.
Power to the iron's heating element will be cut.
nism automatically
Once the iron is moved the power will reconnect. Allow the iron thermostat light goes out, and continue ironing as normal.
15 minutes 30 seconds
¼ full of water.
to heat until the
Figure 2
7
Care and Cleaning
After each use
1. Turn the power off and remove the plug from the power outlet.
2. Allow the iron to cool before winding the cord around the built-in cord wrap.
Storage
Always store the iron on its heel rest. Do not store the iron with the soleplate
facing down, or in the carton.
Cleaning
To clean the exterior of your iron, wipe over with a damp soft cloth and wipe dry.
Caution: Do not use harsh abrasives, chemical cleaners or solvents to clean the exterior of your iron as these will damage the surface.
Cleaning the steam holes
To remove build up from the steam holes which may affect steam performance, use a cotton wool tip m methylated spirits.
Cleaning the Resilium
Wipe with a soft damp cloth and wipe dry.
oistened in
®
soleplate
8
Ironing Tips and Tricks
Tip # 27 - Iron shirts like a pro
Start with the collar, working from the outer edges into the middle. Iron the shoulder next, followed by the cuffs and sleeves. Place the collar at the narrow end of the board so that one front panel of the shirt is extended flat. Iron the front panel from shoulder to shirt tail. Rotate to iron the back of the shirt. Rotate and complete the remaining front panel.
Tip # 34 - Tips for T-shirts
Straighten seams on t-shirts before hanging out to dry. To avoid damage to printed graphics and logos turn the t-shirt inside out and iron the reverse side of the print. Never iron areas of your t-shirt where perspiration marks are visible as the heat of the iron will permanently fix the stain.
Tip # 54 - Hung out to dry
When washing is complete, remove shirts from the machine immediately, shake them out and hang them on coat hangers to air dry – this will keep wrinkles to a minimum.
Tip # 18 - Selecting the right temperature
If you are unsure of the correct setting for a particular garment, test a small area such as a seam or inside hem before ironing a visible area. Start with a low temperature and slowly increase the heat to find the best setting.
Tip # 33 - Don’t be afraid to iron silk
Don’t be afraid to iron silk. Although delicate in appearance, silk is the strongest and most resilient of all natural fibres. To achieve the best results, set to a low cotton setting and use regular shots of steam. Always use a pressing cloth to avoid shine marks.
Tip # 13 - Ironing the seam
Always press seams in the same direction they were made. When a garment is produced, the fibres will naturally settle in the direction they were initially pressed, so it’s best not to iron against the grain.
Tip # 26 - Sort types of fabric
Sort articles to be ironed according to the type of fabric. This will reduce the need to adjust the temperature constantly. Start with articles requiring lower temperatures and work your way through to items requiring higher settings.
Tip # 2 - Summer frocks and frills
Steam is the key when ironing delicate summer fabrics such as muslin, cotton and linen. Don’t press down with the iron, simply hover above the garment and steam it using a vertical shot of steam. Ruffling, netting, tulle or intricate hand detailing is also best ironed using this method.
Tip # 5 - Pressing your winter woollies
Steam is crucial when pressing your winter woollies. Woollen garments can be hung and steamed using the vertical shot of steam feature. After steaming, brush the garment with your hand to plump up woollen fibres. If ironing the garment flat it is best to use a pressing cloth. Don’t be afraid to apply pressure – steam and hold.
Tip # 42 - Table settings to impress
To avoid unwanted creases always iron your table cloth after taking it out of the cupboard. A dinner party is a special occasion, so treat the table cloth as you would your own outfit. For best results, lay towels across your table and iron the table cloth over the towels. This will save you time and ensure a beautifully presented table setting.
9
Ironing Chart
Fabric Temp setting Ironing Ironing recommendation
Acrylic
Acetate
Nylon
Polyester
Rayon
Viscose
Silk
Cotton Blends
Wool
Wool Blends
Corduroy
Cotton
Linen
Denim
10
MINIMUM
MINIMUM
MINIMUM
SYNTHETIC
SYNTHETIC
SYNTHETIC
• • • to Max
MAXIMUM
• • • to Max
Min to •
Min to •
Min to •
SILK
• •
WOOL
• •
WOOL
• •
WOOL
• •
COTTON
• • •
COTTON
• • •
LINEN
Dry iron on reverse side of fabric
Dry iron on reverse side of fabric
while still damp
Iron on reverse side of fabric
Iron on reverse side of fabric
Iron on reverse side of fabric
Mainly dry iron. Steam can be used under
manufacturer's instructions
Iron on reverse side of fabric. Use an ironing
cloth to prevent shine marks
and use regular shots of steam
Check label and follow manufacturer’s
instructions. Use setting for the fibre
requiring the lowest setting
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
to raise the fibres
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
to raise the fibres
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
to raise the fibres
Steam iron while still damp or use spray
to dampen. Use medium to high steam
Iron on reverse side of fabric or use an
ironing cloth to prevent shine marks,
especially with dark colours. Iron while
still damp or use spray to dampen.
Use medium to high steam
Iron while still damp or use spray
to dampen. Use maximum steam
2
Year
Replacement
Guarantee
This Sunbeam product is covered by a 2 year replacement or repair warranty, which is in addition to your rights under the Australian Consumer Law (if your product was purchased in Australia) or New Zealand Consumer Guarantees Act (if your product was purchased in New Zealand).
Should you experience any difficulties with your product during the warranty period, please contact our customer service line for advice on 1300 881 861 in Australia, or 0800 786 232 in New Zealand.
Australia
www.sunbeam.com.au 1300 881 861 Units 5 & 6, 13 Lord Street, Botany NSW 2019 Australia
New Zealand
www.sunbeam.com.nz 0800 786 232 Level 6, Building 5, Central Park, 660-670 Great South Road Greenlane, Auckland New Zealand
Upon receipt of your claim, Sunbeam will seek to resolve your difficulties or, if the product is defective, advise you on how to obtain a replacement or refund.
To assist us in managing warranty claims, we recommend you register your product as soon as practicable after purchase by creating a MySunbeam account on our website and uploading a copy of your original receipt.
In order to make a claim under our warranty, you must have the original proof of purchase documentation for the product and present it when requested (if not already uploaded to our website).
Should your product develop any defect within 2 years of purchase because of faulty materials or workmanship, we will replace or repair it, at our discretion, free of charge. A product presented for repair may be replaced by a refurbished product of the same type rather than being repaired. Refurbished parts may be used to repair the product.
Our replacement or repair warranty only applies where a defect arises as a result of faulty material or workmanship during the warranty period. Your warranty does not cover misuse or negligent handling (including damage caused by failing to use the product in accordance with this instruction booklet), accidental damage, or normal wear and tear.
Your warranty does not:
• cover freight or any other costs incurred in making a claim, consumable items, accessories that by their nature and limited lifespan require periodic renewal (such as filters and seals) or any consequential loss or damage; or
• cover damage caused by:
- power surges, power dips, voltage supply problems, or use of the product on incorrect voltage;
- servicing or modification of the product other than by Sunbeam or an authorised Sunbeam service centre;
- use of the product with other accessories, attachments, product supplies, parts or devices that do not conform to Sunbeam specifications; or
- exposure of the product to abnormally corrosive conditions; or
• extend beyond 3 months if the product is used in commercial, industrial, educational or rental applications.
The benefits given to you by our warranty are in addition to other rights and remedies under law in relation to the product.
In Australia our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
Our goods also come with guarantees that cannot be excluded under the New Zealand Consumer Guarantees Act.
If your warranty claim is not accepted, we will inform you and if requested to do so by you, repair the product provided you pay the usual charges for such repair. You will also be responsible for all freight and other costs.
Should your product require repair or service after the warranty period, contact your nearest Sunbeam service centre. For a complete list of Sunbeam’s service centres, visit our website or call our customer service line for advice on 1300 881 861 in Australia, or 0800 786 232 in New Zealand.
Need help with your appliance?
Contact our customer service team or visit our website for information and tips on getting the most from your appliance.
Australia | visit www.sunbeam.com.au phone 1300 881 861 mail Units 5 & 6, 13 Lord Street, Botany NSW 2019 Australia.
New Zealand | visit www.sunbeam.co.nz phone 0800 786 232 mail Level 6, Building 5, Central Park, 660–670 Great South Road, Greenlane, Auckland.
Sunbeam Corporation Limited | ABN 45 000 006 771 Sunbeam Corporation is a division of GUD Holdings Limited.
Sunbeam is a registered trademark.
Verve and Resilium are trademarks of Sunbeam Corporation.
Teflon is a registered trademark of DuPont
Designed and engineered in Australia. Made in China to Sunbeam’s specification. Due to minor changes in design or otherwise, the product you buy may differ slightly from the one shown here. Approved by the appropriate electrical regulatory authorities.
©Copyright Sunbeam 2014.
1/14
Loading...
