PRO STEAM
IRONS
SR4110
SR4210
SR4310
User Guide
This book covers the use and care of the following Sunbeam Irons:
SR4110 Pro Steam
SR4210 Pro Steam® Teflon® Iron
SR4310 Pro Steam® Teflon® Pro Iron
®
Glide Iron
Contents
Sunbeam’s Safety Precautions 3
Features of your Pro Steam Iron 4
Using your Pro Steam Iron 6
Care and Cleaning 8
Ironing Tips and Tricks 9
Ironing Chart 10
Sunbeam’s Safety Precautions
Australia
www.sunbeam.com.au
1300 881 861
Units 5 & 6,
13 Lord Street,
Botany NSW 2019
Australia
New Zealand
www.sunbeam.co.nz
0800 786 232
Level 6, Building 5,
Central Park,
660-670 Great South Road,
Greenlane, Auckland
New Zealand
SAFETY PRECAUTIONS FOR YOUR IRON
• Do not leave a hot iron within reach of children.
If they come into contact with a hot iron it could
lead to serious burns.
• Iron only on an ironing board.
• An iron takes approximately 30 minutes to cool
down. Allow the iron to cool completely before
storing.
• Do not wind the cord around the soleplate while
the iron is still hot.
Sunbeam is very safety conscious when designing
and manufacturing consumer products, but it is
essential that the product user also exercise care
when using an electrical appliance. Listed below are
precautions which are essential for the safe use of
an electrical appliance:
• Read carefully and save all the instructions
provided with an appliance.
• Always turn the power off at the power outlet
before you insert or remove a plug. Remove by
grasping the plug - do not pull on the cord.
• Turn the power off and remove the plug when the
appliance is not in use and before cleaning.
• Do not use your appliance with an extension cord
unless this cord has been checked and tested by
a qualified technician or service person.
• Always use your appliance from a power outlet of
the voltage (A.C. only) marked on the appliance.
• This appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning use
of the appliance by a person responsible for their
safety.
• Children should be supervised to ensure that they
do no play with the appliance.
• The temperature of accessible surfaces may be
high when the appliance is operating.
• Never leave an appliance unattended while
in use.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
• Do not leave the iron unattended while it is
plugged into the power outlet.
• Always unplug the iron from the power outlet
before filling or emptying the water tank.
• The iron must be used and rested on a stable
surface.
• When placing the iron on its heel, ensure that the
surface on which the stand is placed is stable.
• The iron is not to be used if it has been dropped,
if there are any visible signs of damage or if it is
leaking.
• Do not use an appliance for any purpose other
than its intended use.
• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch any
hot surface.
• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
damaged in any manner. If damage is suspected,
return the appliance to the nearest Sunbeam
Appointed Service Centre for examination, repair
or adjustment.
• For additional protection, Sunbeam recommend
the use of a residual current device (RCD)
with a tripping current not exceeding 30mA in
the electrical circuit supplying power to your
appliances.
• Do not immerse the appliance in water or any
other liquid unless recommended.
• Appliances are not intended to be operated
by means of an external timer or separate remote
control system.
• This appliance is intended to be used in
household and similar applications such as: staff
kitchen areas in shops, offices and other working
environments; farm houses; by clients in hotels,
motels and other residential type environments;
bed and breakfast type environments.
3
Features of your Sunbeam
Pro Steam Iron
Powerful shot of steam
Pressing the shot of steam button instantly
produces a powerful 120g/min shot of steam
to remove stubborn wrinkles.
Vertical shot of steam
Pressing the shot of steam button with the iron
in an upright position produces a vertical shot
of steam, which is ideal for steaming curtains
and suits, and removing creases from delicate
fabrics.
Fine spray mist
Pressing the spray button provides a fine mist
spray to dampen hard-to-iron fabrics.
Easy-fill water inlet
The water inlet cover opens fully to allow easy
filling of the water tank, without bubbling or
spilling.
Large water tank
Holds 280ml of water for continual high
steam performance without having to refill
the tank regularly.
Full length button groove
For ironing around buttons.
DuPont Teflon
(SR4210, SR4310)
Glides easily across all types of fabric and
prevents sticking.
®
3 Coat Non-stick soleplate
Glide Polished Aluminium soleplate (SR4110)
Durable polished aluminium soleplate
is hard -wearing and easy to clean.
4
Long cord with 360º cord outlet
The cord outlet is ideal for left or right
hand use, and provides greater versatility
and ease of movement when ironing. The
flexible grommet protects the cord from
fraying.
Safety auto-off (Model SR4310 only)
The iron automatically switches itself off
if left in the ironing position (horizontal)
for 30 seconds, or in the heel rest
position (vertical) for 15 minutes. (For
more information on the safety auto off
feature see page 7).
Thermostat light
Illuminates to indicate that the iron
is heating and goes out when it has
reached the selected temperature. The
thermostat light cycles on and off during
ironing as the iron maintains the selected
temperature.
Variable Constant Steam
The steam dial allows you to select the
desired constant steam output for each
garment. Alternatively, select the DRY
setting to iron without steam.
Temperature dial
Allows you to select the desired
temperature for each garment. The
adjustable temperature dial also indicates
the amount of steam recommended for
use on each temperature setting.
Stable heel rest
Large heel rest keeps the iron stable on
the ironing board.
Cord wrap facility
The built-in cord wrap facility allows you
to wind the cord around the heel for neat
and tidy storage of the cord when the iron
is not in use.
2400 watts
For fast heat up, a higher pressure steam
shot, a quicker heat recovery, and an even
temperature.
5
Using your Sunbeam Pro Steam Iron
Before first use
Remove any adhesive stickers, plastic
covers or cardboard sleeves from the
soleplate. Ensure that all adhesive is
removed by rubbing the soleplate with a
cloth dampened with methylated spirits.
Fill the water tank and empty the water.
This will rinse out any foreign particles
remaining in the water tank from the
manufacturing process.
NOTE: When turned on for the first time,
your new iron may give off vapours for up
to 10 minutes. This is due to the initial
heating of the materials used. It is safe,
not detrimental to the performance of the
iron, and will not reoccur.
Filling the iron with water
Before filling the iron with water ensure
the power is turned off and the plug is
removed from the power outlet. The iron
can be filled with water while it is hot.
Place the iron on its heel and open the
water inlet cover.
Slowly pour water into the water inlet
until the maximum water level is reached.
Do not exceed the maximum water level
indicator. Push the water inlet cover firmly
to close.
NOTE: The special soleplate design
allows you to use tap water with your Pro
Steam iron without affecting the steam
performance. However in very hard water
areas, Sunbeam recommends the use of
distilled water, or water which has been
demineralised.
Do not fill the iron with fabric conditioner,
starches or any other solution as these will
damage the steam mechanism. Do not use
contaminated water.
Using your iron
1. Insert the plug into a 230/240 volt
power outlet and turn the power on.
2. Turn the temperature dial to the desired
setting by aligning the setting on the
dial with the temperature indicator. The
thermostat light (positioned on the top
of the handle) will illuminate to indicate
that the iron is heating to the selected
temperature. When the thermostat
light goes out the iron has reached the
selected temperature and is ready to
iron.
NOTE: When the temperature dial is
changed from a high setting to a lower
temperature setting during ironing, the
thermostat light will go out immediately.
This indicates that the iron is cooling
to the selected temperature. To ensure
that the iron has reached the selected
temperature and is not too hot, wait until
the thermostat light comes on again and
then goes out before ironing.
Dry ironing
Follow steps 1 and 2 above.
3. Select DRY on the steam dial. This will
cut off the steam flow if there is water
in the tank.
Steam ironing
Follow steps 1 and 2 above.
NOTE: When steam ironing, ensure that the
temperature dial is set to any temperature
within the steam band and that the tank is
at least ¼ full of water.
3. Turn the steam dial to the desired steam
setting.
6
Using your Sunbeam Pro Steam Iron (continued)
Using the shot of steam
The shot of steam can be used whether dry
or steam ironing when the temperature dial
is set to any temperature above the two
dot (••) setting.
1. Ensure the tank is at least ¼ full of
water.
2. Select the desired temperature and
wait until the thermostat light goes
out.
3. Press the shot of steam button
several times with the iron on the
soleplate to prime the pump.
NOTE: If the tank has run dry, it may be
necessary to re-prime the pump after
filling the iron with water.
Using the spray mist
The spray mist can be used whether dry
or steam ironing to pre-dampen hard to
iron fabrics.
1. Ensure the tank is at least ¼ full of
water.
2. Press the spray button during ironing
to release a fine mist from the spray
nozzle.
The safety auto-off feature
(Model SR4310 only)
The safety auto-off mechanism
automatically turns the iron off if you
forget.
The iron will automatically shut off if left
on the heel rest (vertical) for 15 minutes,
or in the ironing position (horizontal) for
30 seconds, without being moved.
The thermostat light on the handle will
flash and a warning beep will sound to
let you know that you have left the iron
unattended.
Power to the iron's heating element will
be cut.
Once the iron is moved the power will
reconnect. Allow the iron to heat until the
thermostat light goes out, and continue
ironing as normal.
15 minutes 30 seconds
7
Care and Cleaning
After each use
1. Turn the power off and remove the
plug from the power outlet.
2. Allow the iron to cool before winding
the cord around the built-in cord wrap.
Storage
Always store the iron on its heel rest.
NOTE: Do not store the iron with the
soleplate facing down, or in the carton.
Cleaning
To clean the exterior of your iron, wipe over
with a damp soft cloth and wipe dry.
Caution: Do not use harsh abrasives,
chemical cleaners or solvents to clean the
exterior of your iron as these will damage
the surface.
To clean the steam holes
To remove build up from the steam holes
which may affect steam performance, use
a cotton wool tip moistened in methylated
spirits.
Cleaning the Teflon® Select non-stick
soleplate (SR4210 & SR4310)
The non-stick coating reduces sticking
of fabrics and starches to the soleplate.
Do not iron over sharp objects such as
buttons, studs and zippers, as these will
scratch the surface.
Wipe the soleplate with a damp soft cloth
after each use. If polyester has burnt to
the soleplate, iron a damp cotton cloth
while hot.
Caution: Do not use scouring pads,
abrasives or harsh cleaners to clean
your Teflon
as these may scratch and damage the
surface.
Cleaning the Glide Polished Aluminium
(SR4110)
Rub gently with a stainless steel soap pad
moistened in warm water. Wipe dry.
®
Select non-stick soleplate,
8
Ironing Tips and Tricks
Tip # 27 - Iron shirts like a pro
Start with the collar, working from the
outer edges into the middle. Iron the
shoulder next, followed by the cuffs and
sleeves. Place the collar at the narrow end
of the board so that one front panel of the
shirt is extended flat. Iron the front panel
from shoulder to shirt tail. Rotate to iron
the back of the shirt. Rotate and complete
the remaining front panel.
Tip # 34 - Tips for T-shirts
Straighten seams on t-shirts before
hanging out to dry. To avoid damage to
printed graphics and logos turn the t-shirt
inside out and iron the reverse side of
the print. Never iron areas of your t-shirt
where perspiration marks are visible as the
heat of the iron will permanently fix the
stain.
Tip # 54 - Hung out to dry
When washing is complete, remove shirts
from the machine immediately, shake
them out and hang them on coat hangers
to air dry – this will keep wrinkles to a
minimum.
Tip # 18 - Selecting the right temperature
If you are unsure of the correct setting
for a particular garment, test a small area
such as a seam or inside hem before
ironing a visible area. Start with a low
temperature and slowly increase the heat
to find the best setting.
Tip # 33 - Don’t be afraid to iron silk
Don’t be afraid to iron silk. Although
delicate in appearance, silk is the
strongest and most resilient of all natural
fibres. To achieve the best results, set to
a low cotton setting and use regular shots
of steam. Always use a pressing cloth to
avoid shine marks.
Tip # 13 - Ironing the seam
Always press seams in the same direction
they were made. When a garment is
produced, the fibres will naturally settle
in the direction they were initially pressed,
so it’s best not to iron against the grain.
Tip # 26 - Sort types of fabric
Sort articles to be ironed according to the
type of fabric. This will reduce the need
to adjust the temperature constantly. Start
with articles requiring lower temperatures
and work your way through to items
requiring higher settings.
Tip # 2 - Summer frocks and frills
Steam is the key when ironing delicate
summer fabrics such as muslin, cotton
and linen. Don’t press down with the iron,
simply hover above the garment and steam
it using a vertical shot of steam. Ruffling,
netting, tulle or intricate hand detailing is
also best ironed using this method.
Tip # 5 - Pressing your winter woollies
Steam is crucial when pressing your
winter woollies. Woollen garments can be
hung and steamed using the vertical shot
of steam feature. After steaming, brush
the garment with your hand to plump up
woollen fibres. If ironing the garment flat
it is best to use a pressing cloth. Don’t be
afraid to apply pressure – steam and hold.
Tip # 42 - Table settings to impress
To avoid unwanted creases always iron
your table cloth after taking it out of the
cupboard. A dinner party is a special
occasion, so treat the table cloth as you
would your own outfit. For best results, lay
towels across your table and iron the table
cloth over the towels. This will save you
time and ensure a beautifully presented
table setting.
9
Ironing Chart
Fabric Temp setting Ironing Ironing recommendation
Acrylic
Acetate
Nylon
Polyester
Rayon
Viscose
Silk
Cotton Blends
Wool
Wool Blends
Corduroy
Cotton
Linen
Denim
MINIMUM
Min to •
MINIMUM
Min to •
MINIMUM
Min to •
SYNTHETIC
•
SYNTHETIC
•
SYNTHETIC
•
SILK
• •
WOOL
• •
WOOL
• •
WOOL
• •
COTTON
• • •
COTTON
• • •
LINEN
• • • to Max
MAXIMUM
• • • to Max
Dry iron on reverse side of fabric
Dry iron on reverse side of fabric
Mainly dry iron. Steam can be used under
Iron on reverse side of fabric. Use an ironing
Check label and follow manufacturer’s
instructions. Use setting for the fibre
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
Steam iron on reverse side of fabric
or use an ironing cloth. Brush gently
Steam iron while still damp or use spray
to dampen. Use medium to high steam
Iron on reverse side of fabric or use an
ironing cloth to prevent shine marks,
especially with dark colours. Iron while
still damp or use spray to dampen.
Iron while still damp or use spray
to dampen. Use maximum steam
while still damp
Iron on reverse side of fabric
Iron on reverse side of fabric
Iron on reverse side of fabric
manufacturer's instructions
cloth to prevent shine marks
and use regular shots of steam
requiring the lowest setting
to raise the fibres
to raise the fibres
to raise the fibres
Use medium to high steam
10
Year
Australia
www.sunbeam.com.au
1300 881 861
Units 5 & 6,
13 Lord Street,
Botany NSW 2019
Australia
New Zealand
www.sunbeam.co.nz
0800 786 232
Level 6, Building 5,
Central Park,
660-670 Great South Road,
Greenlane, Auckland
New Zealand
2 year
2 years
Need help with your appliance?
Contact our customer service team
or visit our website for information
and tips on getting the most from
your appliance.
Australia | visit www.sunbeam.com.au
phone 1300 881 861
mail Units 5 & 6, 13 Lord Street,
Botany NSW 2019 Australia.
New Zealand | visit www.sunbeam.co.nz
phone 0800 786 232
mail Level 6, Building 5,
Central Park,
660–670 Great South Road,
Greenlane, Auckland.
Sunbeam Corporation Limited | ABN 45 000 006 771
Sunbeam Corporation is a division of GUD Holdings Limited.
Sunbeam is a registered trademark.
‘Pro Steam’ is a registered trademark of Sunbeam Corporation.
‘Teflon’ is a registered trademark of DuPont.
Made in China to Sunbeam’s specification.
Due to minor changes in design or otherwise,
the product you buy may differ slightly from the one shown here.
Approved by the appropriate electrical regulatory authorities.
©Copyright Sunbeam 2015.
08/15
Loading...
