Sunbeam SMW1480 User Manual
Owner’s Manual
Microwave Oven
SMW1480
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door-open since open-door
operation can result in harmful exposure to microwave energy. It is important not
to defeat or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow soil or
cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the oven
door close properly and that there is no damage to the :
①
Door ( bent ),
②
Hinges and latches ( broken or loosened ),
③
Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly qualified
service personnel.
CONTENTS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY………………….………….
IMPORTANT SAFETY INSTRUCTIONS……………….……………………………...
GROUNDING INSTRUCTIONS.…………………………….……………………….…...
UTENSILS GUIDE………………………………………………………………………….
COOKING TECHNIQUES…………………………………………………………………
BEFORE YOU CALL FOR SERVICE……………………….……………………………
SPECIFICATIONS…………………………………………….……………………………
PART NAMES…… .………………………………………………………………………...
CONTROL PANEL……………………………………………………………………...…..
OPERATION INSTRUCTIONS…………….……………………………………………...
ABOUT “MENU COOKING” SETTINGS………………………………...……………….
CLEANING AND CARE…………………………………………………………………….
1
2
3
4
6
7
7
7
8
9
12
14
１
IMPORTANT SAFETY INSTRUCTIONS
When using electrical appliances, basic
safety precautions should be followed,
including the following:
WARNING - To reduce the risk of burns,
electric shock, fire, injury to persons or
exposure to excessive microwave energy:
1. Read all instructions before using the
appliance.
2. Read and follow the specific
PRECAUTIONS TO AVOID POSSIBLE
“
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
3. Select a level surface that provides
enough open space for the intake
and/or outlet vents. A minimum
clearance of 3 inches is required
” on page 1.
5.
Use this appliance only for its intended
use as described in this manual. Do not
use corrosive chemicals or vapors in
this appliance. This type of oven is
specifically designed to heat, cook or
dry food. It is not designed for industrial
or laboratory use.
6.
As with any appliance, close
supervision is necessary when used by
children.
7.
To reduce the risk of fire in the oven
cavity:
a. Do not overcook food. Carefully
attend appliance if paper, plastic or
other combustible materials are
placed inside the oven to facilitate
between the oven and any adjacent
wall. One side must be open. Leave a
minimum clearance of 3 inches above
the oven. Do not cover or block any
openings on the appliance. Do not
remove feet from the bottom of the
oven. This
grounded. Connected only to properly
grounded outlet. See “GROUNDING
INSTRUCTIONS ” on page 3.
4.
Some products such as whole eggs
and sealed containers, for example,
closed glass jars may explode and
should not be heated in this oven.
appliance must be
SAVE THESE INSTRUCTIONS
cooking.
b. Remove wire twist-ties from paper or
plastic bags before placing bag in
oven.
c. If materials inside the oven should
ignite, keep oven door closed,
turn oven off, and disconnect the
power cord or shut off power at
the fuse or circuit breaker panel.
d. Do not use the cavity for storage
purposes. Do not leave paper
products, cooking utensils or food in
the cavity when not in use.
2
8.
Microwave heating of beverage can
15.
Do not operate this appliance if it has a
result in delayed eruptive boiling,
therefore care has to be taken when
handle the container.
9.
Do not deep fry food in the microwave.
It is difficult to control the fat which
could cause a fire hazard.
10.
Pierce foods with heavy skins such as
potatoes, whole squash, apples and
chestnuts before cooking.
11.
The contents of feeding bottles and
baby jars should be stirred or shaken
and the temperature should be
checked
before serving in order to avoid burns.
12.
Cooking utensils may become hot
because of heat transferred from the
damaged cord or a plug, if it is not
working properly or if it has been
damaged or dropped.
16.
Do not immerse cord or plug in water.
Keep cord away from heated surface.
Do not let cord hang over edge of table
or counter.
17.
Use only thermometers which are
specifically designed for use in
microwave ovens.
18.
Do not operate any heating or cooking
appliance beneath this appliance.
19.
Be certain the glass tray and roller ring
are in place when you operate the
oven.
WARNING:
20.
It is hazardous for anyone
heated food. Potholders may be
needed to handle the utensil.
13.
Do not cover or block any openings on
the appliance.
14.
Do not store or use this appliance
outdoors. Do not use this product near
water, for example, near a kitchen sink,
in a wet basement, or near a swimming
pool, and the like.
other than a trained person to carry out
any service or repair operation which
involves the removal of any cover
which gives protection against
exposure to microwave energy. If
there is any damage, do not operate
the oven and contact your dealer or
Sunbeam authorized servicer.
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit, grounding
reduces risk of electric shock by providing an escape wire for the electric current.
WARNING:
Improper use of the grounding plug can result in a risk of electric shock.
SAVE THESE INSTRUCTIONS
3
Electrical R eq u irements
The electrical requirements are a 120 volt 60 Hz, AC only, 20 amp. It is recommended that
a separate circuit serving only the oven be provided. The oven is equipped with a 3-prong
grounding plug. It must be plugged into a wall receptacle that is properly installed and
grounded.
Extension Cord
If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3
blade grounding plug and a 3-slot receptacle that will accept the plug on the microwave
oven. The marked rating of the extension cord shall be equal to or greater than the
electrical rating of the appliance.
Notes:
2. Neither manufacturer nor the dealer can accept any liability for damage to the
Radio or TV Interference
Should there be any interference caused by the microwave oven to your radio or TV, check
that the microwave oven is on a different circuit, relocated the radio or TV as far away from
the oven as feasible or check position and signal of receiving antenna.
1. If you have any questions about the grounding or electrical instructions, consult
a qualified electrician or service person.
oven or personal injury resulting from failure to observe the electrical connection
procedures.
UTENSILS GUIDE
This section lists which utensils can be used in the microwave, which ones have limited
use for short periods, and which ones should not be used in the microwave.
Recommended
·Microwave browning dish —
chops, or pancakes. Follow the directions provided with your browning dish.
Use to brown the exterior of small items such as steaks,
·
Microwaveable plastic wrap
steam to escape and avoid placing it directly on the food.
·Paper towels and napkins —
excess moisture and prevent spattering. Do not use recycled paper towels, which may
contain metal and could ignite.
— Use to retain steam. Leave a small opening for some
Use for short-term heating and covering; these absorb
SAVE THESE INSTRUCTIONS
4
