Pure Juice
Juice Extractor
This book covers the use and care of the following product
Instruction Booklet
JE4700
Please read these instructions carefully
and retain for future reference.
Contents
Sunbeam’s Safety Precautions 1
Features of your Sunbeam Pure Juice 2
Assembling your Sunbeam Pure Juice 4
Operating your Sunbeam Pure Juice 5
Handy Juicing Hints 6
Care and Cleaning 7
Nutrients Found in Fruit & Vegetables 8
Recipes 9
Important instructions – retain for
future use.
Sunbeam’s Safety Precautions
SAFETY PRECAUTIONS FOR YOUR
SUNBEAM JUICER.
• Do not put fingers or other objects into the
feed chute whilst the juicer is in operation.
• Do not push fruit or vegetables into the feed
chute with your fingers, always use the food
pusher provided.
• If any fruit or vegetables become lodged in the
feed chute, use the food pusher or turn off the
juicer, remove the plug from the power outlet
and disassemble to remove the lodged fruit or
vegetables.
• Never operate without pulp container.
• Ensure the juicer is correctly and completely
assembled before turning the appliance ‘On’.
Sunbeam is very safety conscious when designing and
manufacturing consumer products, but it is essential
that the product user also exercise care when using
an electrical appliance. Listed below are precautions
which are essential for the safe use of an electrical
appliance:
• Read carefully and save all the instructions provided
with an appliance.
• Always turn the power off at the power outlet before
you insert or remove a plug. Remove
by grasping the plug - do not pull on the cord.
• Turn the power off and remove the plug when the
appliance is not in use and before cleaning.
• Do not use your appliance with an extension cord
unless this cord has been checked and tested by a
qualified technician or service person.
• Always use your appliance from a power outlet of the
voltage (A.C. only) marked on the appliance.
• This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do
not play with the appliance.
• The temperature of accessible surfaces may be high
when the appliance is operating.
• Never leave an appliance unattended while in use.
• Ensure the juicer cover is clamped securely
and pulp container is in place before juicer is
turned on. Do not unfasten the twin-locking
handles while the juicer is in operation.
• Juicing blades are very sharp, handle juicing
filter basket with care when removing,
replacing and cleaning.
• Always operate the juicer on a flat, level
surface.
• Do not operate for more than 20 seconds at
a time when juicing heavy loads. None of the
recipes in this manual are considered a heavy
load.
• Do not use the appliance if the rotating sieve
is damaged.
• Do not use an appliance for any purpose other than
its intended use.
• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.
• Do not place on top of any other appliance.
• Do not let the power cord of an appliance hang over
the edge of a table or bench top or touch any hot
surface.
• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
damaged in any manner. If damage is suspected,
return the appliance to the nearest Sunbeam
Appointed Service Centre for examination, repair
or adjustment.
• For additional protection, Sunbeam recommend
the use of a residual current device (RCD) with a
tripping current not exceeding 30mA in the electrical
circuit supplying power to your appliances.
• Do not immerse the appliance in water or any other
liquid unless recommended.
• Appliances are not intended to be operated by
means of an external timer or separate remote
control system.
• This appliance is intended to be used in household
and similar applications such as: staff kitchen areas
in shops, offices and other working environments;
farm houses; by clients in hotels, motels and other
residential type environments; bed and breakfast
type environments.
If you have any concerns regarding the performance and use of your appliance,
please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.
Ensure the above safety precautions are understood.
1
Features of your Sunbeam
Pure Juice
Food Pusher
Stainless steel grating and filtering basket
Twin safety levers
Motor base
On/Off control button
Coninuous Juicing
Allows you unlimited juicing, simply place a
glass or jug under the spout to collect juice.
Pulp collection container
Stores coarser pieces of pulp and separates
the juice. Removable for easy cleaning.
Stainless steel grating and filtering basket
Heavy duty stainless steel grating and
filtering basket designed for maximum juice
extraction and is removable for easy cleaning.
2
Lid/Feed tube
Continuous flow pulp container
Non slip feet
Feeding Tube and Food Pusher
Shaped for optimal feeding of various fruits
and vegetables making juicing a breeze.
Cold Storage
Handy cord storage keeps the benchtop tidy
by storing unwanted cord.
Non slip feet
Prevents the unit form moving across the
bench top.
3
Assembling your Sunbeam
Pure Juice
Before Use:
After unpacking your Pure Juice, we
recommend that you dissemble the unit
before using for the first time. Wash all parts
except the Motor Base in hot soapy water.
Rinse and dry immediately.
Important:
Always ensure your Pure Juice is unplugged
from the power outlet when not in use,
assembling or removing parts.
To assemble your Pure Juice
(See opposite)
1. Set up the Motor Base on a dry level
surface with the On/Off switch facing the
user.
2. Place the Juice Collector onto the Motor
Base.
3. Position the stainless steel grating and
filtering basket on to the drive shaft.
4. Place the Lid/Feed Tube on top of the
Pure Juice and secure by clipping the two
safety levers on the sides of the juicer into
position.
Note: As an added safety feature the Pure
Juice will not operate if the safety levers are
not locked in place.
5. Position the Pulp container in place.
6 Plug the Pure Juice into the 230-240V
power outlet and turn on Power. Position
a glass or jug under the Juice outlet and
commence juicing.
Food Pusher
Lid/Feed Tube
Stainless steel
grating and
filtering basket
Juice Collector /
Outlet
Drive Shaft
Motor Base
On/Off Control
Continuous
Flow Pulp
Container
4
Button
Safety Lever
Operating your Sunbeam
Pure Juice
Note: As an added safety feature the Pure
Juice will not operate if the safety levers are
not locked in place.
1. Ensure the switch on the Pure Juice is in
the ‘Off’ position and plug the cord into
a 230- 240V power outlet and turn the
power on.
2. Clean fruits and vegetables thoroughly and
remove any stems, large pits, stones and
seeds. All fruits and vegetables should be
cut into pieces to fit into Lid/Feed Tube.
3. Ensure that the Pure Juice has been
assembled correctly, making sure that
the stainless steel grating and filtering
basket revolves properly before placing
the ingredients in the Pure Juice. Refer to
page 4 for assembly instructions.
4. Switch the Pure Juice to the ‘On’ position
to start juicing. Place food into the Lid/
Feed Tube slowly and steadily, using the
Food Pusher.
Note: Do not force the food into the grating
and filtering basket as this can cause basket
to shift and result in plastic shavings getting
into the juice.
5. The Juice from the fruits or vegetables will
flow directly into the glass or jug and the
pulp will be separated and collected in the
Pulp container.
Important: If juicing large amounts of fruits
or vegetables, the pulp container will be
filled, switch Pure Juice to the ‘Off’ position,
unplug cord, and allow grating and filtering
basket to stop completely. Empty Pulp
container and reposition.
6. When juicing is complete ensure that the
Pure Juice is switched ‘Off’ and unplugged
from the power outlet.
5
Handy Juicing Hints
• Cut fruit and vegetables into suitable sizes
to fit the Feed Tube.
• Remove stones and hard seeds from fruits
such as peaches, plums and apricots.
• Remove skin from citrus fruits and other
thick skinned fruits eg. watermelon.
• Leafy vegetables should be rolled up tightly
into compact balls or rolls.
• Apricots, bananas, peaches, pears, melons
and strawberries are soft-textured fruits.
The juice extracted from these fruits is very
thick and is known as nectar. It is best to
alternate processing of these juices with
thinner juices, such as carrots, apples, etc.
Process softtextured fruits first, followed
by firmer fruits and vegetables, in order to
ensure maximum removal of thick juice.
• Allow the motor to run for approximately
1 to 2 seconds after you have finished
feeding fruit and vegetables into the Feed
Tube. This allows the maximum amount of
juice to be extracted.
• Add a few teaspoons of lemon juice to
your juice container before juicing to keep
juices from discolouring.
• Serve juices immediately for maximum
vitamin retention. Store juice in the
refrigerator, covered. Do not store for more
than 48 hours, unless canning or freezing.
• Some pulp remaining in juice is normal.
It increases the juice’s flavour and nutritive
value.
• The season, age and ripeness of the fruit
will have an effect on the amount of juice
extracted.
6
Care and Cleaning
Ensure that the Pure Juice is unplugged
before cleaning.
After use, unplug cord and disassemble the
Pure Juice. Remove the pulp from the Pulp
collecting container (the pulp may be used in
recipes, see recipe section). The Pure Juice
parts should be rinsed in cold water then
washed in warm water with a mild detergent.
Rinse well. Use a soft, damp cloth to wipe
the Motor Base.
Important: Never immerse the Motor Base in
water or any other liquid.
Caution: Cutting teeth are very sharp, handle
juicing filtering basket with care when
removing, replacing and cleaning.
Remove pulp from the grating and filtering
basket before washing. The basket can be
brushed with a nylon washing brush or clean
tooth brush to remove fine particles of pulp
that may be caught in the fine holes of the
filter. After processing highly coloured fruits
or vegetables the Pulp Collection Container
may become stained. Bicarbonate of Soda
sprinkled into the dry Container, and rubbed
with a damp cloth to help remove stains.
Caution: Never use steelwool, scouring pads,
harsh abrasive cleaners, thinners or chemical
dust cloths for cleaning.
7
Nutrients Found in Fruit
& Vegetables
Vitamin Food Source Benefits
Vitamin A Yellow fruits and vegetables e.g.
carrots dark green vegetables e.g.
spinach
Vitamin B1
(Thiamine)
Vitamin B2
(Riboflavin)
Niacin Tomatoes, peas, potatoes - Helps nervous system to function
Vitamin C
(Ascorbic
Acid)
Mineral Food Source Benefits
Calcium Broccoli, rhubarb, dried fruits,
Iron Asparagus, spinach, broccoli,
Potatoes
Dried peas and beans
Lentils
Leafy green vegetables - Keeps skin, eyes and mouth healthy
Citrus fruits, kiwi fruit,
capsicums, parsley, strawberries,
tomatoes, carrots
parsley and spinach
parsley, peas
Healthy skin, bones and teeth.
Assist vision (night)
- Aids appetite and digestion
- Release energy from carbohydrates
- Keeps nervous system healthy
- Helps cells use oxygen
Promotes normal growth and
development
- Keeps teeth, gums, skin muscles and
blood vessels healthy
- Increases resistance to infection.
- Promotes strong teeth and bones.
- Aids oxygen transportation movement
in the blood.
8
Recipes
FRUIT COCKTAILS
These fruit cocktails are an easy and
delicious treat to make in your Sunbeam
Pure Juice.
Citrus Nectar
Serves 4
2 grapefruits, peeled and quartered
3 oranges, peeled and quartered
6 apricots, seeds removed
ice cubes
Juice grapefruit, oranges and apricots, add
ice cubes and stir well.
Healthy Sunrise
Serves 4
500g ripe tomatoes
1 cup buttermilk
Juice tomatoes, add buttermilk.
Chill and serve.
Strawberry Cocktail
Serves 4
15 strawberries
4 green apples
crushed ice
Juice strawberries and apples, add ice
and stir well.
Tropical Tango
Serves 4
2 mangoes, peeled and seed removed
1 pineapple
crushed ice
Juice mango and pineapple. Add ice and
stir well.
Watermelon Fizz
Serves 4
½ medium watermelon, skin removed
¹⁄³ cup of brandy
1 cup lemonade
Juice the watermelon. Add brandy and
lemonade, stir well and chill.
Peach Divine
Serves 4
6 medium peaches, peeled and stone
removed
2 oranges, peeled and quartered
1 tablespoon honey
ice cubes
Juice peaches and oranges. Add honey and
ice cubes, stir well.
9
Recipes continued
COMBINATION OF JUICES
Below are some suggested juice
combinations. Quantities of fruit or
vegetables required depend on:
1. Quality of fruit or vegetables.
2. Number of people.
• Apple and Orange
• Apple and Grapefruit
• Apple and Plum
• Apple and Tomato
• Carrot and Celery
• Carrot, Celery and Beetroot
• Cabbage and Tomato
• Carrot and Spinach
• Pineapple and Grapefruit
• Strawberry and Apple
JUICE DRINKS
Serves 1
Vegetable Zing
2 carrots
1 stick celery
¼ cucumber
½ lemon
Island Cooler
½ pineapple
1 apple
pulp of 3 passionfruits 1
Cucumber & Pineapple Cooler
2 cucumbers
½ pineapple
1 lemon
½ cup crushed ice
Strawberry Refresher
2 oranges
1 punnet strawberries
1 tablespoon cointreau
Tomato Treat
2 carrots
2 tomatoes
2 sticks celery
½ lemon
Carrot Surprise
4 carrots
2 sticks celery
½ capsicum
Dieters Special
4 peaches
2 apricots
2 apples
10
Recipes continued
PULP RECIPES
Pulp from the Sunbeam Pure Juice can be
used in many ways. Vegetable pulp is ideal
to enrich soup, stock and casseroles. Both
fruit and vegetable pulp can be used as pie
fillings.
Apple Raisin Cake
1½ teaspoons coffee powder
2 cups water
125g butter
2 cups plain flour
¾ cup brown sugar
1 teaspoon bicarbonate of soda
1 teaspoon cinnamon
¼ teaspoons nutmeg
1 egg
½ cup apple pulp
½ cup raisins
Heat coffee, water and butter, until coffee is
dissolved and butter has melted.
Combine flour, sugar, bicarbonate of soda,
cinnamon and nutmeg in a bowl. Add egg
and coffee mixture. Mix well.
Add apple pulp and raisins.
Pour into a well greased 20cm cake pan.
Bake in a moderate oven for 1 hour or until
cooked.
Carrot Spice Cake
125g butter
¾ cup raw sugar
2 eggs
1 cup carrot pulp
200ml natural yogurt
½ cup milk
1 teaspoon bicarbonate of soda
2 cups wholemeal self raising flour
pinch salt
1 teaspoon mixed spice
½ teaspoon cinnamon
Cream butter and sugar until light and fluffy.
Add eggs one at a time, mixing after each
addition.
Add all remaining ingredients, mix well until
combined.
Pour into a well greased 20cm cake pan.
Bake 1 hour or until cooked in a moderate
oven.
Icing
70g cream cheese
15g butter
3/4 cup brown sugar
2 teaspoons lemon juice
Mix butter and cheese until well combined.
Add sugar and beat until light and fluffy.
Mix in lemon juice.
11
Recipes continued
Carrot Spice Cake
200ml strawberry pulp
50ml strawberry juice
400ml whipped cream
1 cup icing sugar
pinch salt
1 tablespoon lemon juice
1 tablespoon vanilla
Combine pulp and juice. Set aside.
Using a Sunbeam Mixmaster, whip the cream
until stiff.
Combine the pulp, juice, icing sugar, salt,
lemon juice and vanilla, stir well. Fold the
mixture through the cream.
Spoon the mousse into parfait glasses or
serving bowls and freeze until firm.
Vegetable Patties
1 cup carrot pulp
300g can kidney beans, pureed
1 onion, chopped
1/4 cup parsley, chopped
1 cup cooked brown rice
1 egg
1 teaspoon salt
1 teaspoon basil
2 tablespoons wholemeal flour
1 cup chopped nuts
4 tablespoons oil
Combine all ingredients, except nuts & oil.
Make heaped tablespoons of mixture, shape
into patties and role in chopped nuts.
Heat oil in pan and cook patties until golden
brown.
Cucumber Raita
200ml cucumber pulp
Combine ingredients well.
This is delicious when served with curries or
can be used as a dip.
12
12 Month Replacement Guarantee
In the unlikely event that this appliance develops any malfunction
within 12 months of purchase (3 months commercial use) due to
faulty materials or manufacture, we will replace it for you
free of charge.
Should you experience any difficulties with
your appliance, please phone our customer
service line for advice on 1300 881 861 in
Australia, or 0800 786 232 in New Zealand.
Alternatively, you can send a written claim
to Sunbeam at the address listed below.
On receipt of your claim, Sunbeam will
seek to resolve your difficulties or, if the
appliance is defective, advise you on how
to obtain a replacement or refund.
Your Sunbeam 12 Month Replacement
Guarantee naturally does not cover misuse
or negligent handling and normal wear and
tear.
Similarly your 12 Month Replacement
Guarantee does not cover freight or any other
costs incurred in making a claim. Please
retain your receipt as proof of purchase.
The benefits given to you by this guarantee
are in addition to your other rights and
remedies under any laws which relate to the
appliance.
Our goods come with guarantees that cannot
be excluded under the Australian Consumer
Law and under the New Zealand Consumer
Guarantees Act.
In Australia you are entitled to a
replacement or refund for a major failure and
for compensation for any other reasonably
foreseeable loss or damage. You are also
entitled to have the goods repaired or
replaced if the goods fail to be of acceptable
quality and the failure does not amount to
a major failure.
Should your appliance require repair or
service after the guarantee period, contact
your nearest Sunbeam service centre.
For a complete list of Sunbeam’s authorised
service centres visit our website or call:
Australia
www.sunbeam.com.au
1300 881 861
Units 5 & 6, 13 Lord Street
Botany NSW 2019 Australia
New Zealand
www.sunbeam.co.nz
0800 786 232
26 Vestey Drive, Mt Wellington
Auckland, New Zealand
Need help with your appliance?
Contact our customer service team or visit
our website for information and tips on
getting the most from your appliance.
In Australia
Visit www.sunbeam.com.au
Or call 1300 881 861
In New Zealand
Visit www.sunbeam.co.nz
Or call 0800 786 232
is a registered trademark.
‘Pure Juice’ is a trademark of Sunbeam Corporation.
Made in China.
Due to minor changes in design or otherwise,
the product may differ from the one shown in this leaflet.
© Copyright.
ABN 45 000 006 771
Units 5 & 6, 13 Lord Street
Botany NSW 2019 Australia
Unit 3, Building D
26 Vestey Drive
Mt Wellington Auckland
New Zealand
Sunbeam Corporation is a division of GUD Holdings Ltd.
Sunbeam Corporation Limited 2011.
9/11
Loading...
