Sunbeam BT5350 User Guide

Pizza Bake & Grill™

19L Family Size Oven

User Guide

BT5350

Contents

Sunbeam’s Safety Precautions 1

Features of your Pizza Bake & Grill 2

Using your Pizza Bake & Grill 6

Cooking Pizza guide 8

Roasting guide 8

Grilling guide 9

Roasting tips for vegetables 10

Care and cleaning 11

Recipes 12

Important instructions – retain for
future use.

Sunbeam’s Safety Precautions

SAFETY PRECAUTIONS FOR YOUR

SUNBEAM BAKE & GRILL OVENS.

• Always operate on a flat surface.

• Avoid contact with oven surfaces, including
oven door, during and after use, as they will
be hot.

• Use well away from walls and curtains.

Sunbeam is very safety conscious when

designing and manufacturing consumer products,
but it is essential that the product user also
exercise care when using an electrical appliance.
Listed below are precautions which are essential
for the safe use of an electrical appliance:

• Read carefully and save all the instructions
provided with an appliance.

• Always turn the power off at the power outlet
before you insert or remove a plug. Remove
by grasping the plug - do not pull on the cord.

• Turn the power off and remove the plug when
the appliance is not in use and before cleaning.

• Do not use your appliance with an extension
cord unless this cord has been checked and
tested by a qualified technician or service
person.

• Always use your appliance from a power outlet of
the voltage (A.C. only) marked on the appliance.

• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or lack
of experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety.

• Children should be supervised to ensure that
they do not play with the appliance.

• The temperature of accessible surfaces may be
high when the appliance is operating.

• Never leave an appliance unattended while
in use.

• Do not place items on top of the oven whilst in
use.

• Do not block or cover the air vents on the top,
back or side of the oven.

• Do not use in confined spaces.

• Do not immerse the unit in water.

• Do not use an appliance for any purpose
other than its intended use.

• Do not place an appliance on or near a hot gas
flame, electric element or on a heated oven.

• Do not place on top of any other appliance.

• Do not let the power cord of an appliance hang
over the edge of a table or bench top or touch
any hot surface.

• Do not operate any electrical appliance with a
damaged cord or after the appliance has been
damaged in any manner. If damage is suspected,
return the appliance to the nearest Sunbeam
Appointed Service Centre for examination, repair
or adjustment.

• For additional protection, Sunbeam recommend
the use of a residual current device (RCD)
with a tripping current not exceeding 30mA in
the electrical circuit supplying power to your
appliances.

• Do not immerse the appliance in water or any
other liquid unless recommended.

• Appliances are not intended to be operated
by means of an external timer or separate remote
control system.

• This appliance is intended to be used in
household and similar applications such as: staff
kitchen areas in shops, offices and other working
environments; farm houses; by clients in hotels,
motels and other residential type environments;
bed and breakfast type environments.

If you have any concerns regarding the performance and use of your appliance,

please visit www.sunbeam.com.au or contact the Sunbeam Consumer Service Line.

Ensure the above safety precautions are understood.

1

Features of your Pizza Bake & Grill

Rack support guides

With three rack support
guides: upper, middle and
lower, each cooking function
is maximised.

™

Removable crumb tray

Crumb tray slides out for
emptying without the need
to open the door and has a
cool touch handle for added
safety.

2

Extra deep back

Extra depth in the back allows you to
cook pizzas up to 30cm in size

Heating light

Light on indicates that the oven is
heating. When the set temperature is
reached, the light will switch off. During
the cooking process this light will turn
on and off occasionally to ensure that
the desired temperature is maintained
constantly throughout the oven.

1600 watt element

Powerful 1600 watt oven for a fast
heat-up.

Power light

Indicates when the oven is turned on.
Lights up when the timer or 'ON' setting
has been selected.

Non-slip rubber feet

Keeps the oven secure on the bench top
during use and prevents scratching of
bench top surfaces.

3

Features of your Sunbeam Bake & Grill continued

Temperature Control

Variable temperature control allows you
to select the perfect temperature for each
cooking task. Temperature range is from
60ºC to 240ºC.

Oven Settings

Select from Pizza/Toast, Grill, Reheat
or Bake.

Pizza/Toast: Using the PIZZA/TOAST setting
allows maximum heat for fast, quick
cooking of pizzas and toast. For toast, use
this setting in combination with the timer.

Grill: Use the GRILL setting for grilling
open sandwiches, sausages and vegetables.

Reheat: Heats food from beneath and is
ideal for perfectly reheating leftovers.

Bake: Suitable for roasting baked dinners
as well as baking homemade biscuits,
cakes and muffins.

60 minute timer and on/off control

The timer can be set up to 60 minutes
and will automatically turn the oven off
and sound a bell at the end of the cooking
time. Alternatively, the dial can be set to
the ON position for continuous operation,
until it is turned off manually. Variable
browning control allows you to toast your
bread to a desired colour. LIGHT TOAST on
the timer represents the lightest toasting
shade and DARK TOAST represents the
darkest toasting shade.

4

Features of your Sunbeam Bake & Grill continued

Aluminium pizza tray

Cooks up to a 30cm pizza to perfection

Enamel baking pan

Enamel baking pan can be used on its own
or with the drip tray insert.

Enamel drip tray insert

The drip tray insert sits inside the baking
pan and allows fats to drain away for fat-free
cooking. The drip tray also helps to prevent
splattering.

Chrome plated wire rack

The removable wire rack is reversible and
may be used in the raised or sunken position,
giving you greater versatility when cooking.

Crumb tray

Insert the tray into bottom of the oven.
Removable for easy cleaning.

Sunken

Raised

5

Using your Bake & Grill

™

Position the oven on a dry, level surface,
ensuring that the ventilation slots on the side
and top of the appliance are not obstructed.
Plug the power cord into a 230-240 volt
power outlet and turn the power on.

Note: When turned on for the first time,
your Bake & Grill may give off vapours for
up to 10 minutes. This is due to the initial
heating of the materials used. It is safe, not
detrimental to the performance of the oven
and will not re occur.

Important: Do not force open the oven door
beyond its limit or let the door drop open
as this will distort the door and hinder the
oven's ability to maintain a proper seal.

For pizza

The top two and bottom two elements will
heat when the 'pizza' setting has been
selected.

1. Place the wire rack in the middle shelf in
the sunken position.

2. Place the pizza tray on the shelf.

3. Turn the oven setting to ‘PIZZA/TOAST’.

4. Set the temperature to 210ºC and allow
tray to preheat for 5-10 minutes before
using.

To toast

The top two and bottom two elements will
heat when the ‘TOAST’ setting has been
selected.

1. Place the wire rack into the middle rack
support guide, in the sunken position.

2. Arrange bread on the wire rack.

3. Turn the oven setting to ‘TOAST’.

4. Set the temperature control to the
maximum 240ºC.

5. To set the time first turn the dial fully
clockwise to 60 minutes, then turn it
ant-clockwise to the toast icons to start the
timer. This ensures accurate timing. Light
Toast represents the lightest toast shade
and Black Toast represents the darkest
shade.

6. A bell will sound when the selected toast
cycle has ended.

Note: Toasting times will vary depending
on the type of bread used. Sweet and fruit
breads generally take less time than white or
wholemeal breads.

To grill

The top two elements will heat when the
‘GRILL’ setting has been selected.

1. Place the wire rack, in the sunken position,
into the highest rack support guide.

2. Place the drip tray inside the baking pan
and position the food on the drip tray.
Place the baking pan on the wire rack.

3. Turn the oven setting to ‘GRILL’.

4. Set the temperature control to maximum
240ºC.

Note: For best results, allow the oven to
preheat for 5 -10 minutes or as per recipe
instructions.

5. To turn the grill on, turn the timer control
clockwise to the desired time. Alternatively,
for continuous operation, turn the timer
control to the ON position.

6. When finished grilling, the oven will switch
off automatically and a bell will sound if
the timer was selected. Alternatively, turn
the timer control to OFF position if the
continuous mode was selected.

6
