Sunbeam 2377 User Manual

User

Manual

STAND

MIXER

Model 2377

safety

When using electrical appliances, basic safety precautions
should always be followed, including the following:

• READ ALL INSTRUCTIONS BEFORE USING THE
MIXER.

• To protect against risk of electrical shock, do not put
Mixer in water or other liquid. This may cause personal
injury or damage to the product.

• Close supervision is necessary when Mixer is used by or
near children or incapacitated persons.

• Unplug from outlet while not in use, before putting on or
taking off parts and before cleaning.

• Avoid contacting moving parts. Keep hands, hair,
clothing, as well as spatulas and other utensils away from
beaters during operation to reduce the risk of injury to
persons and/or damage to the Mixer.

• Do not operate Mixer with a damaged cord or plug or
after the appliance malfunctions, or is dropped or
damaged in any manner. Return appliance to the nearest
Authorized Sunbeam Appliance Service Center for
examination, repair or electrical or mechanical
adjustment.

• The use of attachments not recommended or sold by
Sunbeam may cause fire, electrical shock or injury.

• Do not use outdoors or for commercial purposes.

• Do not let cord hang over edge of table or countertop or
touch hot surfaces, including the stove.

• Remove beaters from Mixer before washing.

• Do not place Mixer or bowls on or near a hot gas or
electric burner, or in a heated oven.

• Do not use Mixer for other than intended use.

• Do not leave Mixer unattended while it is operating.

IMPORTANT SAFEGUARDS

ii

Safety

safety

SPECIAL INSTRUCTIONS

iii

This Unit Is for Household Use Only

When your MIXMASTER® Mixer is first used, you
may experience an odor and possibly a slight wisp of
smoke from your mixer’s motor. This is caused by the
heat curing of the insulation which protects the motor
and is normal. After the first few uses, this effect will
disappear.

FOR PRODUCTS PURCHASED IN THE U.S. AND
CANADA ONLY

To reduce the risk of electrical shock, this appliance has
a polarized plug (one blade is wider than the other).
This plug fits a polarized outlet only one way; if the
plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician.
Do not attempt to defeat this safety feature.

SAVE THESE

INSTRUCTIONS

contents

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Learning About Your Stand Mixer . . . . . . . . . . . . . . . . .2

Assembling the Stand Mixer . . . . . . . . . . . . . . . . . . . . .3

Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . .6

Mixing Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Helpful Hints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Breads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Using Dough Hooks . . . . . . . . . . . . . . . . . . . . . . .11

Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

One-Year Limited Warranty . . . . . . . . . . . . . . . . . . . . .14

How to Obtain Warranty Service . . . . . . . . . . . .14

Table of Contents

iv

welcome

Congratulations! You are the owner of a SUNBEAM

®

Stand Mixer.

Before you use this product for the first time, please take
a few moments to read these instructions and keep it for
reference. Pay particular attention to the Safety
Instructions provided. Please review the product service
and warranty statements. For your future reference,
please note:

Date product received:
Service number:

(Located on the bottom of the stand mixer)

FEATURES

Thank you for choosing the SUNBEAM®Mixer. For
generations we have been helping cooks prepare moist
cakes, light and fluffy meringue and chewy cookies.
You can even make bread dough with your SUNBEAM

®

Mixmaster®Mixer.
The SUNBEAM®Mixmaster®Mixer offers you a choice

of 12 different mixing speeds.
The Bowl-Fit Beaters and Bowls have been designed

to mix ingredients thoroughly and evenly.
No problem ejecting the beaters either – just push the

Ejector Button located on the side of the handle.
You’ll love being able to make so many things with

your Mixer!

Welcome

1

your mixer

Learning About Your Stand Mixer

2

A. Beater Ejector
B. BURST OF

POWER®
Feature

C. Speed Control

Dial

D. Mixer-Release

Trigger

E. Headlock
F. Stand
G. Dough Hooks
H. Turntable

Locator Switch

I. Turntable

J. Bowl-Fit Beaters
Ka. Large Mixing

Bowl

Kb. Small Mixing

Bowl

A

B

C

D

E

F

G

H

I

J

Ka

Kb

stand mixer

Before assembling the mixer, be sure the speed
control dial is in the OFF position and the electric
cord is unplugged.

Attaching the Turntable

Place the revolving turntable into the base of the
stand by pressing the turntable into the center hole
of the adjustment slot until it snaps into place.

Adjusting the Turntable

The turntable must be adjusted depending upon
which bowl size is being used (see “Adding the
Mixing Bowl”). To adjust, press down on the
turntable locator switch and slide switch to the
proper icon.

Attaching and Removing Mixer Head

To attach the mixing head, press in on the mixer­release trigger, located at the rear of the stand.

Place the mixer head on the stand so that the metal
pivot on the bottom of the mixer head goes into the
latched opening on the top of the stand.

As you release pressure from the mixer-release
trigger, the top of the latch should clamp around the
metal pivot. Once the mixing head is lowered into
position, it will lock into place.

To raise the mixing head, press the head lock button
downward while pulling up on the handle of the
mixing head. Once unlocked, the mixing head can be
removed by pressing the mixer release trigger. Be sure
the mixer head is securely in position before using.

NOTE: This mixer is NOT intended for use away
from the stand.

Assembling the Stand Mixer

3

assembling

Adding the Mixing Bowl

Move the turntable locator switch to the proper
setting – the large bowl icon if you are using the
large bowl; the small bowl icon if you are using a
small bowl. Place the desired mixing bowl onto the
turntable.

Mixing bowls should NEVER be used in a
conventional oven, microwave oven, on top of the
range or on any other heated surface. If mixing
bowls are scratched or chipped, do not use mixer.
Mixer bowl should not be used to blend in hot
liquids.

Attaching the Beaters

Be sure the speed control dial is in the OFF position
and unplug electric cord from the electrical outlet.
Lift mixer head up and back to pull it out of the
way of the bowl.

NOTE: It is important that the beaters go into the
correct sockets. Otherwise the mixer will not give
you the proper mixing action. Do not risk ruining a
recipe or damaging your mixer. Read the following
instructions carefully.

One of the beaters is shaped like a cone and has a
nylon button on the bottom. It goes into the socket
on the side of the mixer nearest the side of the
bowl. The other beater is square-shaped and goes
into the socket nearest the center of the bowl. See
beater symbols located on the bottom of the mixer
head.

Insert the beaters, one at a time, using a
combination pressing and twisting motion, until the
beaters snap into position.

If a beater should not properly snap into place, pull
it out of the socket and rotate it one quarter turn.
Reinsert the beater into the socket until it snaps
into position.

4

Assembling

CONE SHAPED

BEATER

SQUARE

BEATER

NYLON

BUTTON

SIDE OF BOWL

CONE
BEATER

SQUARE
BEATER

assembling

Assembling

ATTACHING THE DOUGH HOOKS

Set the speed dial in the OFF position and unplug
the electric cord from the electrical outlet. Lift mixer
head up and back to tilt it out of the way of the
bowl, while holding it in an upright position.

NOTE: The dough hooks must go into the correct
sockets. The mixer will operate with the dough
hooks in the wrong position. However, you will not
get proper kneading action and you could risk
ruining a recipe or damaging your mixer. Read the
following instructions carefully.

The dough hook with the small washer and foot
goes into the socket on the side of the mixer nearest
the side of the bowl. The other dough hook with the
large washer goes into the socket nearest the center
of the bowl. See the dough hook symbols located on
the bottom of the mixer head.

5

operating

ABOUT THE SPEED CONTROL DIAL

The speed control dial is used for turning the mixer
ON and OFF and for selecting its 12 mixing speeds.

Rotate the speed control dial in a clockwise
direction to increase mixing speed; and in a counter­clockwise direction to decrease mixing speed.

As you rotate the speed control dial, notice that a
numbered speed is aligned with the indicator on top
of the mixer head. This numbered speed indicates
the speed at which the mixer is operating.

Rotate the speed control dial until the indicator is
opposite the numbered speed you wish to use.

BURST OF POWER®FEATURE

Press down on button or top handle to
automatically increase the beater speed by 150
RPM for an immediate boost of power.

HEAD LOCK

The head lock feature locks the mixing head in the
down position for added control while mixing and
locks it in the up position for added convenience
while cleaning.

To unlock, press down the button on the side of the
stand.

To lock, lower mixing head until it automatically
locks in place.

Operating Instructions

6

SPEED

INDICATOR

MIXING GUIDE

SPEED

CONTROL

DIAL

guide

Mixing Guide

SPEED MIXING

SETTING GUIDE EXAMPLE

1 Fold-Kneaded Use when mixing dry ingredients or when

folding two portions of a recipe together,
such as a beaten egg white into a batter
or when directions call for LOW speed.
Use for kneading bread.

2 Stir Use when stirring liquid ingredients or

when gentle action is needed to moisten
dry ingredients.

3 Blend Use when quick breads require a brisk

action, just enough to blend ingredients
but not enough to develop a smooth
batter.

4 Mix Use when mixing dry ingredients and

liquid ingredients together alternately in
a recipe.

5 Combine Use when recipe calls for combining

ingredients together.

6 Cake Mixes Use when preparing packaged cake

mixes or when directions call for
MEDIUM speed.

7 Cream Use when creaming sugar and butter

together.

8 Whip Use to whip potatoes or to develop a

smooth batter.

9 Whip/Cream Use to whip whipping cream or to

develop a light, fluffy texture.
10 Desserts Use to beat air into whipped desserts.
11 Frostings Use when preparing light, fluffy frostings

and candies.
12 Egg Whites Use when aerating eggs and egg whites.

Use when directions call for HIGH speed.

NOTE: Due to variations in ingredient temperatures and quantities, the Mixing
Guide speeds are only suggested. If necessary, adjust speeds as needed to
achieve desired results.

7

EJECTING THE BEATERS OR DOUGH HOOKS

After you’ve finished mixing, turn the speed control
dial to OFF and unplug the electric cord from the
electrical outlet. Push the ejector button located near
the handle to remove beaters or dough hooks.

Scrape excess batter off the beaters using a rubber or
plastic spatula. Do not strike beaters on the rim of
the bowl.

CLEANING YOUR MIXER

To clean the mixer, wipe the mixer head, stand and
turntable with a damp cloth, then dry. DO NOT

IMMERSE THE MIXER HEAD OR STAND IN
WATER. Avoid the use of abrasive cleaners, as they

may mar the finish of the mixer.
Wash the beaters and bowls in hot, soapy water after

each use. Rinse thoroughly and dry. Beaters and
bowls may also be washed in an automatic
dishwasher.

STORING YOUR MIXER

Store the mixer in a dry location, such as on a
countertop or table top, or in a closet or cupboard.
Insert the beaters into the proper sockets. Place the
dough hooks in the mixing bowl.

Store the bowl(s) on the turntable. The beaters will
help hold the bowl in position. Wind the electric cord
into a coil, secure it with a twist fastener.

MAINTENANCE

The motor of your stand mixer has been carefully
lubricated at the factory and does not require any
additional lubricant. Other than the recommended
cleaning, no further user maintenance should be
necessary.

Return the mixer to the nearest Authorized Sunbeam
Service Center for servicing or repairs.

cleaning

Caring For Your Mixer

8
