Sunbeam 1626 User Manual

Instruction Manual

WALL MOUNT 1500-WATT HAIR DRYER

Mode d'Emploi

SÉCHOIR À CHEVEUX-1500 WATTS À MONTAGE MURAL

Manual de Instrucciones

SECADOR DE CABELLO DE 1500 WATTS MONTAJE EN LA PARED

Manual de Instruções

SECADOR DE CABELO DE 1500 WATTS FIXAÇÃO À PAREDE

Sunbeam®is a trademark of Sunbeam Corporation or its affiliated companies.

Distributed by Sunbeam Products Inc., Delray Beach, Florida 33445.

Sunbeam®est une marque de Sunbeam Corporation ou de ses sociétés apparentées.

Distribué par Sunbeam Products Inc., Delray Beach, Florida 33445.

Sunbeam®es una marca de Sunbeam Corporation o de sus corporaciones afiliadas.

Distribuido por Sunbeam Products Inc., Delray Beach, Florida 33445.

Sunbeam® é uma marca da Sunbeam Corporation ou de suas empresas afiliadas.

Distribuído pela Sunbeam Products Inc., Delray Beach, Florida 33445.

P.N. 85084

MODEL/MODELO MODÈLE/MODELO

1626

MODEL/MODELO MODÈLE/MODELO

1626

When using electrical appliances, especially when children are present, basic safety precautions should always be followed, including the following:

READ AND SAVE ALL INSTRUCTIONS BEFORE USING

KEEP AWAY FROM WATER

DANGER – As with most electrical appliances, electrical parts are electrically

live even when the switch is off. To reduce the risk of death by electric shock:

1. Do not install or store appliance where it can fall or be pulled into a tub or sink.

2. Always unplug this appliance from the electrical outlet immediately after using and before cleaning.

3. Do not use while bathing.

4. Do not place in or drop into water or other liquid.

5. If hand unit falls into water, turn unit off immediately. Do not reach into water.

ARNING – To reduce risk of burns, electrocution, fire or injury to persons:

1. Close supervision is necessary when this appliance is used by, on, or near invalids or disabled persons. This appliance should not be used by or on children.

2. Use this appliance only for its intended use as described in this manual. Do not use attachments not recommended by Sunbeam.

3. Never operate this appliance if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged or dropped into water. Return the appliance to Sunbeam Appliance

Service Station, 95 W.L. Runnels Industrial Drive, Hattiesburg, MS 39401 for examination or repair.

4. Keep the cord away from heated surfaces.

5. Never block the air openings of the appliance or place it on a soft surface, such as a bed or couch, where the air openings may be blocked. Keep the air openings free of lint, hair, etc.

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS

6. Never use while sleeping.

7. Never drop or insert any object into any opening.

8. Do not use outdoors, or operate where aerosol (spray) products are being used, or where oxygen is being administered.

9. Periodically inspect wall unit for secure mounting.

10. Do not direct hot air toward eyes or other heat-sensitive areas.

11. The unit and attachments may be hot during use. Allow to cool before handling. To avoid burn hazard, do not let bare skin touch heated surfaces.

12. Do not place appliance on any surface while it is operating.

13. While using the appliance, keep your hair away from the air inlets.

14. Do not wrap cord around dryer. Continuous stress on the cord can damage cord insulation and result in a shock, fire, or burn hazard.

15. Do not operate this appliance with a voltage converter.

FOR HOUSEHOLD USE ONLY

OPERATE ON 110V 50-60Hz ONLY

Any service other than specifically mentioned should be performed only

by an authorized service facility. Please see warranty service information.

FOR PRODUCTS PURCHASED IN THE U.S. AND CANADA ONLY:

To reduce the risk of electrical shock, this appliance has a polarized plug (one blade is wider than the other). This plug fits a polarized outlet only one way; if the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. DO NOT ATTEMPT TO DEFEAT THIS SAFETY FEATURE.

CAUTION – Never allow the power supply cord to be pulled, twisted, or severely bent. Never wrap the cord tightly around the dryer. Damage will occur at the high flex point of entry into the dryer, causing it to rupture, arc, and short. Inspect the cord frequently for damage. Stop use immediately if damage is visible or unit stops or operates intermittently.

PERATING

INSTRUCTIONS

This dryer is equipped with an appliance leakage circuit interrupter (ALCI) for your safety. This device is designed to make the appliance inoperable under some abnormal conditions (such as accidental immersion in water).

After the appliance is plugged in, you must check your protective device as follows:

1. Press the “Reset” button on the ALCI device.

2. Press the “Test” button. The “Reset” button will pop out. This verifies that the protective device is working properly.

3. Press the “Reset” button once more to reactivate the safety device and use your appliance.

REPEAT THE ABOVE PROCEDURE BEFORE EACH USE TO CONFIRM

THAT THE PROTECTIVE DEVICE IS OPERATING.

If your protective device does not operate as described above, the entire appliance should be returned to Sunbeam Appliance Service Station, 95 W.L. Runnels Industrial Drive, Hattiesburg, MS 39401 for examination or repair.

TO USE

1. Press the release buttons to remove the dryer.

2. To start the dryer, press the ON button on the wall mount unit.

3. Slide the control switch to: LOW position for styling hair, MED position for drying hair, HIGH position for fastest drying.

4. Stop the dryer by pushing the OFF button or by replacing the unit to the mounting base, which will automatically engage the OFF switch.

HAIR DRYER

RELEASE

BUTTON

OFF

UTTON

BUTTON

HIGH

MED LOW

SWITCH

ALL MOUNT

For your protection, this unit contains a thermostat that prevents the dryer from overheating. Should the air intake and/or air outlet become blocked or obstructed, the hair dryer will automatically shut off. If this occurs, slide the switch to OFF, unplug and allow dryer to cool. If dryer continues to turn off automatically, discontinue use and return to Sunbeam Appliance Service Station, 95 W.L. Runnels Industrial Drive, Hattiesburg, MS 39401 for examination or repair.

CAUTION

Use your Sunbeam hair dryer with care. Directing a high volume of heat continuously to one area can overheat hair and scalp. When using a “High” heat setting, hold the blower opening a few inches away from the hair, drying one section at a time. Work layers of hair in quick strokes. Keep the dryer in motion until drying and styling are complete.

MOUNTING INSTRUCTIONS

For use on sheetrock or wood walls only. The Sunbeam Wall Mount hair dryer is designed for installation on sheetrock or wood

walls only. To mount onto wall, be sure there are no hidden electrical circuits or pipes in the mounting location.

Follow these instructions:

1. Remove wall bracket from the unit.

2. Use the bracket as template to mark position of holes for drilling close to electrical outlet, away from tub or sink.

3. Drill three 3/16 inch holes.

4. Insert the three anchor bushings by tapping lightly with a hammer until the shoulder of the bushing rests against the wall.

5. Position wall bracket and tighten the two bottom screws first, then tighten the top screw. (Anchor bushings and screws are provided for you).

6. Match the slots on the back of the mounting base with the hooks on the bracket.

7. Press bracket onto the hooks and slide down to insure secure mounting.

8. Plug the unit into the nearby electrical outlet (110 volt, 50 – 60 cycle AC only).

ANGER

To reduce risk of electrocution, do not install where unit can fall into tub or sink.

STORAGE

1. Always store dryer inside the base.

2. Do not mount or store dryer in an area with excessive heat or moisture.

3. Do not wrap cord around dryer. Allow to hang loosely from dryer.

4. Do not hang dryer by cord or use cord as a handle.

5. Store in a cool, dry place and out of reach of children.

6. Store where dryer will not be accidentally damaged from bumping or falling. Do not put anything on top of dryer.

AINTENANCE, CARE AND CLEANING

1. Always unplug dryer from outlet before cleaning.

2. Clean dryer by wiping with a soft, lightly moistened cloth.

3. NEVER PUT HAIR DRYER IN WATER.

4. The motor never needs oil or grease.

5. Check the removable lint screen. It is important that you clean the removable lint screen when hair, lint or dust begin to build up on it. To remove the screen, rotate counter-clockwise and loosen. To clean, brush the outside of the screen with a toothbrush to loosen lint, etc. Then turn the screen over and rinse under a running faucet. Towel dry the screen thoroughly. If inside of screen is dirty, brush gently with a toothbrush to clean. To replace screen, line up pegs on inside of the screen with slots on side of unit and rotate clockwise to lock in place.

1. To remove lens:

Insert tool (screw driver, knife point, etc.) in crevice to flex tabs.

2.Replace bulb and lamp holder as an

assembly by pulling straight out. Each bulb can be replaced separately.

WALL MOUNT

NIGHT LIGHT

110V-120V

POWER SUPPLY

3-FT. P

OWER CORD

RELEASE BUTTON

OFF

BUTTON

REMOVABLE

INT SCREEN

HAIR DRYER

HIGH

MED

LOW

SWITCH

6-FT. POWER CORD

RACKET

SCREW

IGHT LIGHT F

EATURE

To change bulbs,

follow instructions below.

TOP HOUSING OF

WALL M

OUNT

3-FT. P

OWER CORD

BRACKET

SCREW

LOCKING P

LATE

STANDARD ON MODEL 001626-040-000

OPTIONAL ON MODEL

001626-020-000

NOTES

2 YEAR LIMITED WARRANTY

Sunbeam Products Inc. warrants to the original purchaser, subject to the limitations and exclusions set forth below, that this product shall be free, in all material respects, of mechanical and electrical defects in material and workmanship from the date of purchase for two years. This warranty does

not cover normal wear of parts or damage resulting from any of the following: negligent use or misuse of the product, use on improper voltage or current, use contrary to operating instructions or disassembly, repair or alteration by any person other than an authorized service center.

Our obligation hereunder is limited to repair or replacement, at manufacturer's option, of the product during the warranty period, provided that the product, along with the model number and original dated proof of purchase, is sent postage prepaid, directly to the following address:

For products purchased in the United States:

SUNBEAM APPLIANCE SERVICE STATION

95 W.L. Runnels Industrial Drive

Hattiesburg, MS 39401

For products purchased in Canada:

SUNBEAM APPLIANCE SERVICE STATION (KND)

100 Alfred Kuehne Boulevard

Brampton, ON L6T 4K4

Do not return this product to the place of purchase or to the manufacturer; doing so may delay the processing of your warranty claim.

Answers to questions regarding this warranty or for your nearest authorized service location may be obtained by calling toll-free 1-800-597-5978 or by writing to Sunbeam – Consumer Affairs, at P.O. Box 948389, Maitland, FL 32794-8389. Answers to questions regarding this warranty or for your nearest Canadian authorized service location may be obtained by calling toll-free in Canada 1-800-667-8623. For warranty information or for an authorized service location outside of the United States and Canada, please see the warranty service card inserted in the product packaging.

DISCLAIMER

Product repair or replacement as provided under this warranty is your exclusive remedy.

SUNBEAM PRODUCTS, INC. SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT OR ANY PART THEREOF, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW. SUNBEAM PRODUCTS, INC., DISCLAIMS ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF THIS PRODUCT OR ANY PART THEREOF. Some states and provinces

do not allow the exclusion or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights, which vary from State to State or Province to Province.

Made in China

8. Ne l’utilisez pas à l’extérieur ni dans un endroit ou des produits en aérosol sont utilisés où dans un endroit où de l’oxygène est administré.

9. Inspecter périodiquement l’unité murale pour garantir la sécurité du montage.

10. Ne dirigez pas l’air chaud vers vos yeux ou autres endroits sensibles à la chaleur.

11. L’unité et son équipement peuvent chauffer durant l’utilisation. Leur permettre de se refroidir avant manipulation. Pour éviter tout risque de brûlure, ne pas laisser la peau nue toucher les surfaces chaudes.

12. Ne placez pas l’appareil sur une surface quelconque pendant qu’il fonctionne.

13. Prenez soin que vos cheveux n’entrent pas dans les admissions d’air pendant que vous l’utilisez.

14. Ne pas enrouler la corde autour du séchoir. Une tension continue sur la corde peut abîmer l’isolation de la corde et aboutir à un choc, un incendie ou risque de brûlure.

15. Ne pas utiliser cet appareil avec un transformateur de voltage.

USAGE DOMESTIQUE SEULEMENT

FONCTIONNE UNIQUEMENT SOUS 110V 50-60Hz

Tout autre utilisation que celle mentionnée devra être prise en charge

par un service extérieur compétent. Veuillez consulter

les données d’information sur la garantie de service.

POUR PRODUITS ACHETÉS AUX ÉTAS-UNIS ET AU CANADA UNIQUEMENT:

Cet appareil est muni d’une fiche polarisée (une lame est plus large que l’autre). Comme mesure de sécurité, cette fiche peut etrê insérée dans une prise de courant polarisée dans un sens seulement. Si elle n’entre pas dans la prise de courant, inversez la fiche et essayez de nouveau. Si elle refuse toujours d’entrer, communiquez avec un électricien compétent.

N’ESSAYEZ PAS D’OUTREPASSER CETTE MESURE DE SÉCURITÉ. ATTENTION - Ne jamais permettre à la corde d’être tirée, tordue ou exagérément pliée. Ne

jamais serrer la corde autour du séchoir. Des dégats se produiront au niveau du point de flexion élevé d’entrée du séchoir, le faisant se rompre, se courber et raccourcir. Inspecter fréquemment la corde pour contrôle des dégats. Stopper immédiatement l’utilisation si les dégats sont visibles ou si l’appareil s’arrête ou opère par intermittence.

CONSERVEZ CES INSTRUCTIONS

Lors de l’utilisation d’appareils électriques, surtout à proximité d’enfants, des mesures de sécurité de base doivent toujours être suivies, incluant celles qui suivent:

LISEZ TOUTES LES INSTRUCTIONS AVANT L’UTILISATION

GARDEZ L’APPAREIL LOIN DE L’EAU

ANGER – Comme avec la plupart des appareils électriques, les pièces

électriques sont sous tension même lorsque l’interrupteur est dans la position d’arrêt. Pour réduire le danger de choc électrique:

1. Ne mettez pas ou ne rangez pas l’appareil dans un endroit d’ou il peut tomber ou etrê tiré dans une baignoire ou un évier.

2. Toujours retirer cet appareil de la prise de courant après usage et avant nettoyage.

3. Ne l’utilisez pas en prenant un bain.

4. Ne le placez pas ou ne l’échappez pas dans l’eau ou autre liquide.

5. Si l’appareil portatif tombe dans l’eau, le mettre immédiatement en position arrêt. Ne pas le toucher dans l’eau.

ADVERTISSEMENT – Pour réduire le risque de brûlures, électrocution, incendie

ou blessures personnelles:

1. Une surveillance attentive est nécessaire lorsque cet appareil est utilisé par, sur ou proche de personnes invalides ou malades. Cet appareil ne doit pas être utilisé par ou sur des enfants.

2. Utilisez-le tel que décrit dans ce livret d’instructions. N’utilisez pas d’accessoires non recommandés par Sunbeam.

3. N’utilisez pas cet appareil si le cordon ou la fiche est endommagé ou s’il ne fonctionne pas proprement, s’il a été échappé ou endommagé d’une façon quelconque ou échappé dans l’eau. Apportez-le au Sunbeam Appliance Service Station, 95 W.L. Runnels Industrial Drive, Hattiesburg, MS 39401, pour inspection et réparation.

4. Gardez le cordon loin des surfaces chaudes.

5. Ne bloquez jamais les admissions d’air de cet appareil et ne le placez pas sur une surface molle, telle qu’un lit ou un sofa, où les admissions d’air peuvent être bloquées. Gardez les admissions d’air exemptes de charpie, cheveux, etc.

6. Ne l’utilisez jamais lorsque vous vous endormez.

7. N’échappez jamais ou n’insérez jamais d’objet dans les ouvertures.

MESURES DE SÉCURITÉ IMPORTANTES
