Summit SCFF237 User Manual

Write Model & Serial Nos. (on back of unit) here:

Écrire les numéros de modèle et de série

(à l'arrière de l'appareil) ici:

_______________________________ _______________________________

FELIX STORCH, INC. Summit Appliance Division An ISO 9001:2015 registered company 770 Garrison Avenue Bronx, New York 10474 www.summitappliance.com

Commercial Reach-In Refrigerators and Freezers

Grands réfrigérateurs et congélateurs commerciaux

Refrigerators/Refrigérateurs: SCRR231, SCRR491

Freezers/Congélateurs: SCFF236, SCFF496

User's Manual

Mode d'emploi

Please read this manual thoroughly prior to equipment set-up,

operation and maintenance.

Veuillez s'il vous plaît lire ce manuel attentivement avant la mise en place,

le branchement et la maintenance de l'équipement.

TABLE OF CONTENTS

Appliance Safety ........................................................................................ 2

Important Safeguards ........................................................................... 3 - 5

Technical Information ................................................................................ 6

Installation .................................................................................................. 7

Cabinet Location Guidelines Electrical Connection

Operation .................................................................................................... 8

Temperature Controller ..................................................................... 8

To silence an audible alarm ............................................................... 8

Defrosting .......................................................................................... 8

Interior lighting ................................................................................... 8

Cleaning and Maintenance ................................................................. 9 - 10

Cleaning the Exterior of the Unit ........................................................ 9

Cleaning the Interior of the Unit ......................................................... 9

Cleaning the Condenser Coil ............................................................. 9

Cleaning the Fan Blades and Motor ................................................ 10

Additional Safety Warnings ..................................................................... 10

Troubleshooting ....................................................................................... 11

Limited Warranty ...................................................................................... 12

French Translation ............................................................................ 13 - 27

APPLIANCE SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. Safety messages will follow the Safety Alert Symbol and either the word "DANGER" or "WARNING".

DANGER means that failure to heed this safety statement may result in severe personal injury or death.

WARNING means that failure to heed this safety statement may result in extensive product damage, serious personal injury, or death.

All safety messages will alert you about the potential hazard, tell you how to reduce the chance of injury, and let you know what can happen if the instructions are not followed.

IMPORTANT SAFEGUARDS

Before the appliance is used, it must be properly positioned and installed as described in this manual, so read the manual carefully. To reduce the risk of fire, electrical shock or injury when using the appliance, follow basic precautions, including the following:

 Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter,

and do not use an extension cord.

 Do not connect grounding wire to a gas or water pipe.  Replace all panels before operating.  It is recommended that a separate circuit serving only your appliance be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

 Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or

explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.

 Before proceeding with cleaning and maintenance operations, make sure the power line of the

unit is disconnected.

 Do not connect or disconnect the electric plug when your hands are wet.  Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can

result in electrical shock or death.

 Do not attempt to repair or replace any part of your appliance unless it is specifically

recommended in this manual. All other servicing should be referred to a qualified technician.

 This appliance is CFC- and HFC-free and contains a small quantity of liquid propane (R290a)

which is environmentally friendly, but flammable. It does not damage the ozone layer, nor does it increase the greenhouse effect. Care must be taken during transportation and setting up of the appliance that no parts of the cooling system are damaged. Leaking coolant can ignite and may damage the eyes.

In the event of any damage:

- Avoid open flames and anything that creates a spark,

- Disconnect from the electrical power line,

- Air the room in which the appliance is located for several minutes and

- Contact the Service Department for advice.

 The more coolant there is in an appliance, the larger the room it should be installed in. In the

event of a leakage, if the appliance is in a small room, there is the danger of combustible gases building up. The amount of coolant in the appliance is stated on the data plate on the appliance.

It is hazardous for anyone other than an Authorized Service Person to carry out servicing or

DANGER - Risk of fire or explosion. Flammable refrigerant used.

• Do not use mechanical devices to defrost refrigerator. Do not puncture refrigerant tubing.

• To be repaired only by trained service personnel. Do not puncture refrigerant tubing.

CAUTION - Risk of fire or explosion

• Flammable refrigerant used. Consult repair manual/owner’s guide

before attempting to service this product. All safety precautions must be followed.

• Dispose of properly in accordance with federal or local regulations. Flammable refrigerant used.

• Risk of fire or explosion due to puncture of refrigerant tubing. Follow handling instructions carefully. Flammable refrigerant used.

CAUTION - Avoid obstructing any ventilation openings in the appliance or

in the enclosure when building-in.

repairs to this appliance.

 Take serious care when handling, moving, and using the appliance to avoid either damaging

the refrigerant tubing or increasing the risk of a leak.

 Replacing component parts and servicing shall be done by factory authorized service

personnel so as to minimize the risk of possible ignition due to incorrect parts or improper service.

FOLLOW WARNING CALLOUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL

or other injury.

 To prevent overheating and fire hazard, remove all packaging before use, including the tray at

the bottom of the appliance.

 When installing, leave at least 8" at the back of the unit.  To ensure proper ventilation for your appliance, the front of the unit must be completely

unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below 90°F (32°C). This unit must be installed in an area protected from the elements, such as wind, rain, water spray or drips.

 The appliance should not be located next to ovens, grills or other sources of high heat.  The appliance must be installed with all electrical, water and drain connections in accordance

 Use two or more people to move and install the appliance. Failure to do so can result in back

with state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in accordance with the National Electrical Code and local codes and ordinances, is required.

 Do not kink or pinch the power supply cord of the appliance.  The size of the fuse (or circuit breaker) should be 15 amperes.  It is important that the appliance be leveled in order to work properly. You may need to make

several adjustments to level it.

 All installations must be in accordance with local plumbing code requirements.  Make certain that the pipes are not pinched, kinked or damaged during installation.  Check for leaks after connection.  Never allow children to operate, play with or crawl inside the appliance.  Do not use solvent-based cleaning agents or abrasives on the interior. These cleaners may

damage or discolor the interior.

 Use this appliance only for its intended purpose as described in this User's Manual.  Keep fingers out of the “pinch point” areas. Clearances between the doors and between the

doors and cabinet are necessarily small. Be careful closing doors when children are in the area.

Risk of child entrapment!

Child entrapment and suffocation are not problems of the past. Junked or abandoned appliances are still dangerous, even if they will “just sit in the garage a few days”.

Before discarding your old refrigerator:

 Take off the doors.  Leave the shelves in place so that children may not easily climb inside.

- SAVE THESE INSTRUCTIONS -

TECHNICAL INFORMATION

Model

SCRR231

SCRR491

SCFF236

SCFF496

Description

1-door

refrigerator

2-door

refrigerator

1-door freezer

2-door freezer

Temperature Range

32 to 50°F

(0 to 10°C)

32 to 50°F

(0 to 10°C)

-8 to 0°F

(-22 to -18°C)

-8 to 0°F

(-22 to -18°C)

Unit Dimensions

29"W x 32.2"D

x 82.5"H

54"W x 32.2"D x

82.5"H

29"W x 32.2"D x

82.5"H

54"W x 32.2"D

x 82.5"H

Capacity

23 ft3

46.6 ft3

23 ft3

46.6 ft3

Unit Weight

282 lbs

447 lbs

282 lbs

447 lbs

Door/Housing/ Liner Material

304 stainless

steel

304 stainless

steel

304 stainless

steel

304 stainless

steel

Self-Closing Door(s)

Yes

No. of shelves

3 6 3

Shelf Material

Plastic-coated

steel

Plastic-coated

steel

Plastic-coated

steel

Plastic-coated

steel

Shelf Loading

176 lbs/shelf

Temperature Display

Yes

Type of Controller

Digital

Electrical Rating

115V AC, 60Hz

Connection Rating

3.76A / 720W

3.36A / 643W

6.45A / 1234W

10.25A /

1962W

Compressor Power

590W

495W

590W

854W

Defrost

Automatic

Refrigerant

R290a

Casters

Yes

ETL Compliance

Yes

INSTALLATION

IMPORTANT! PLEASE READ BEFORE INSTALLATION

 If the unit has recently been transported, let it stand upright for a minimum of

24 hours before plugging it in.

 Be sure there is proper ventilation around the unit in the area where it will

operate. Leave at least 8” at the back.

 Make sure all accessories are installed (i.e. shelves, shelf clips, casters)

before plugging the unit in.

 Be sure the unit has dropped down to desired temperature before loading it

with product.

 Please read through the manual in its entirety.

Cabinet Location Guidelines:

 Install the unit on a strong and level surface.

– Unit may make unpleasant noises if surface is uneven. – Unit may malfunction if surface is uneven.

 Install the unit in a well-ventilated indoor area.

– Unit performs more efficiently in a well-ventilated area. – For best performance, maintain a clearance of 8" at the back of the unit. – Outdoor use may cause decreased efficiency and damage to the unit.

 Avoid installation in a high humidity and/or dusty area.

– Humidity could cause unit to rust and experience decreased efficiency. – Dust collected on the condenser coil will cause the unit to malfunction.

Clean the condenser at least once a month with a brush or clean cloth.

 Select a location away from heat and moisture-generating equipment.

– High ambient temperatures will cause the compressor to overwork, leading

to higher energy bills and gradual breakdown of the unit.

Electrical Connection:

 Be sure the required compressor voltage is being supplied at all times. Low or

high voltage can detrimentally affect the refrigeration unit.

 All units should be plugged into a grounded and properly-sized electrical outlet

with appropriate overcurrent protection. Refer to the electrical requirements on the nameplate.

 Be sure the unit has its own dedicated outlet.



Do not use an extension cord.

OPERATION

For freezers SC FF236 For refrigerators SCRR231 and SCFF496 and SCRR491

refrigerator

 When loading the unit, be careful not to block the air duct located at the back

and the fan on the ceiling of the unit. Blocking the air flow may reduce the performance of the unit. For the best performance, maintain at least 4 inches of clearance between the contents and the air duct.

 Set the shelves that come with the unit to fit your needs.  Do not leave the unit door open for long periods of time. For the most efficient

operation, close the door immediately after use.

Temperature Controller:

The digital temperature controller is located on the front of the unit, above the door. It displays the temperature measured by the probe inside the unit and allows you to set the desired temperature; it also controls the defrost function.

To set the desired temperature:

1. Press the SET button. The set temperature will be displayed.

2. Press the ▲ or ▼ button to modify the displayed value.

3. Press SET to confirm the new set temperature and exit the adjustment. If no button is pressed within 10 seconds, the cabinet temperature will be displayed.

To silence an audible alarm:

Press the mute button.

Defrosting:

Defrosting is automatic, but the process can be induced manually by pressing the ▼

button for more than 3 seconds for refrigerator models (5 seconds

for freezers).

Repeat this process to stop defrosting.

Interior Lighting:

The cabinet interior lights up when the door is opened and shuts off when the door is closed.
