Summit SBC490BI Specification Sheet

SBC490BI 34.5" x 23.63" x 24.88" (H x W x D)

Full-sized built-in beer dispenser with black exterior and
complete tap accessory kit

Highlights:

Flexible design allows built-in or freestanding use
Accepts half, quarter, and mini kegs of your favorite brew
Includes everything you need to pour the perfect draft
Converts to a refrigerator for added convenience

Full-sized Large interior accepts half, quarter, and mini kegs
Built-in capability Make the best use of space by installing your beer dispenser under the counter and flush with other

cabinets

Fully finished black
cabinet

KIT 490 included Includes a 5lb. CO2 tank and regulator, draft arm, Sankey American tap, connection hardware, and

Convertible to a
refrigerator

Automatic defrost Reduced user maintenance with auto defrost operation
Adjustable thermostat Manage the interior temperature with ease and accuracy
Casters included Make the beer cooler portable by installing this sturdy caster set to the base
Top guard rail included If using the unit freestanding, install this silver rail on top to reduce spills and neaten service
100% CFC free Environmentally friendly design without ozone-damaging chemicals

Allows the beer dispenser to be used freestanding

cleaning kit
Transform the beer cooler into a standard refrigerator with adjustable shelves

Specifications:

Height 34.5"
Width 23.63"
Depth 24.88"
Capacity 6.4 cu.ft.
Interior Height 1 29.0"
Interior Width 1 21.25"
Interior Depth 1 18.75"
Shipping Weight 152.0 lbs.
US Electrical Safety UL
Energy Usage/Year 418.0 kWh/year
Voltage/Frequency 115 V AC/60 Hz
Canadian Electrical Safety ULC
Amps 1.7
Reversible No
Door Swing RHD
Shelf Quantity 2
Shelf Type Wire
Defrost Type Automatic
Depth with door at 90° 47.0"
Thermostat Type Dial
Fan Type Exterior
High Side PSI 280.0
Freon Oz 2.1
Freon Type R134a
Level Legs Quantity 4
Low Side PSI 88.0
Compressor Warranty 5 Years
Parts/Labor Warranty 1 Year
