Stuart CP300 Instruction Manual

Instruction Manual

Version 2.2B

Hotplate, acid resistant

CP300

2

Hotplate

CP300
Instructions for use

Introduction

Thank you for purchasing this piece of Stuart
equipment. To get the best performance
from the equipment and for your own safety,
please read these instructions carefully
before use. Before discarding the packaging
check that all parts are present and correct.

This equipment is designed to operate under
the following conditions:

 For indoor use only
 Use in a well ventilated area
 Ambient temperature range +5ºC to

+40ºC

 Altitude to 2000m
 Relative humidity not exceeding 80%
 Mains supply fluctuation not exceeding

10%

 Over-voltage category II IEC60364-4-443
 Pollution degree 2
 Use with a minimum distance all around

of 200mm from walls or other items

If the equipment is not used in the manner
described in this manual and with
accessories other than those recommended
by Stuart, the protection provided may be
impaired.

Electrical Installation

THIS EQUIPMENT MUST BE
EARTHED

Before connection please ensure that the
line supply corresponds to that shown on
the rating plate.

Model

Supply requirements

CP300 230V, 50 or 60Hz,~, single phase

The unit is supplied with two mains leads
fitted with IEC plugs for connection to the
control box. One has a U.K. 3 pin plug and
the other has a 2 pin “Shuko” plug for
connection to the mains. Choose the lead
appropriate for your electrical installation and
discard the other. Should neither lead be
suitable, take the lead with the U.K. plug and
replace the plug with a suitable alternative.
This involves cutting off the moulded plug,

preparing the cable and connecting to the re­wireable plug in accordance with its
instructions.

THIS OPERATION SHOULD ONLY BE
UNDERTAKEN BY A QUALIFIED
ELECTRICIAN

The wires in the mains cable are coloured as
follows:

BROWN - LIVE
BLUE - NEUTRAL
GREEN/YELLOW - EARTH

The control unit is fitted with an IEC socket at
the rear for connection of the mains lead.
The appropriate mains lead should be
connected BEFORE connection to the mains
supply.

Should the mains lead need replacement, a
cable of 1mm

2

of harmonised code H05W-F
connected to an IEC320 plug should be
used.

NOTE: Refer to the equipment’s rating plate
to ensure that the plug and fusing are
suitable for the voltage and wattage stated.
The UK mains lead is protected by a 10A
fuse mounted in the plug top.

Model

Power

Fuse

CP300 900W T5A

Fuse fitted in both live and neutral lines.

IF IN DOUBT CONSULT A QUALIFIED
ELECTRICIAN

Safety Advice Before Use

 Do not use to heat flammable materials.
 Position the instrument on a firm level

surface away from any heat sensitive or
flammable material.

 Never move or carry the unit while it is in

use or connected to the mains supply.
Switch off and allow to cool for at least 30
minutes.

 The unit should be carried using both

hands with fingers under each side frame.

 In the case of mains interruption, a fault

or failure, the unit WILL continue to
operate on removal of the fault.

 NEVER immerse the hotplate unit in acid

or any other liquid. The unit has breather
holes in the base which will allow liquid
access that will destroy sensitive
components.

3

General Description

The acid resistant hotplate consists of a
ceramic tile and heater assembly mounted in
a block of high grade PTFE. The hotplate is
controlled via a separate control unit which is
connected by a 2 metre lead (partly covered
with a PTFE sleeve). This allows the hotplate
to be located in a fume hood and the
controller outside, away from the corrosive
environment.

Controls

Front of control unit

Rear of control unit

Rear of control unit

Operation

1. Position the hotplate unit on a firm level

surface away from any heat sensitive or

flammable material.

2. Plug the hotplate lead into the hotplate
inlet socket of the control unit.

3. Connect the control unit to the mains
supply (the green mains indicator light will
illuminate).

4. Position the control unit in the area it is to
be used (e.g. outside the fume hood).

5. Turn the control unit ON using the
temperature control knob and select the
temperature of the hotplate by using the
printed scale around the knob. The heater
on light will illuminate.

Maintenance

WARNING: Before attempting to
clean the unit, ensure that the

hotplate is cool and that the
control unit is disconnected from the
mains electricity supply.

The control unit should be cleaned using a
damp cloth and mild detergent solution. Do
not use harsh or abrasive cleaning agents.

The hotplate body can be cleaned with
almost any cleaning agent compatible with
PTFE. A damp cloth will remove most types

of contamination. For more difficult stains a

domestic cleaner is recommended.

Cleaning is made easier if spillages are
attended to promptly. In any case, spillages

of alkali, phosphoric acid and hydrofluoric

acid MUST be removed immediately as
these chemicals can attack and damage the
glass ceramic. Ensure the appropriate safety
precautions are observed.

NEVER immerse the hotplate unit in acid
or any other liquid. The unit has breather
holes in the base which will allow liquid
access that will destroy sensitive
components.

WARNING: A ceramic top which is

scratched, chipped, chemically etched or
damaged must not be used.

Temperature
control knob

Hot warning light Heater on light

Mains

indicator light

Temperature
control knob

Hot warning light Heater on light

Mains

indicator light

Main IEC inlet

socket

Hotplate inlet

socket

Main IEC inlet

socket

Hotplate inlet

socket

WARNING: When the hotplate surface
is hot (>50ºC) the hot warning light will

begin to flash red. This will continue to
flash while the plate temperature is above 50ºC

even after the hotplate has been switched off
(the control unit must remain connected to the
mains supply).

4

Warranty

Cole-Parmer Ltd. warrants this equipment to
be free from defects in material and workmanship,
when used under normal laboratory conditions,
for a period of three (3) years. In the event of a
justified claim, Cole-Parmer will replace any
defective component or replace the unit free
of charge.

This warranty does NOT apply if damage is
caused by fire, accident, misuse, neglect,
incorrect adjustment or repair, damage
caused by installation, adaptation,
modification, fitting of non-approved parts or
repair by unauthorised personnel.

This warranty does NOT apply if the ceramic
top has broken due to mechanical impact,
scratching, chipping or chemical etching.

Cole-Parmer Ltd.
Beacon Road,
Stone, Staffordshire,
ST15 0SA, United Kingdom
Tel: [phone]
Email: [e-mail]
Web: www.stuart-equipment.com

Technical Specification

CP300

Plate material (hotplate) Glass ceramic

EFTP )etalptoh( lairetam ydoB

mm003 x 003 snoisnemid etalP
mm002 x 002 aera detaeH

W00

9 rewop retaeH

Maximum plate temperature

400ºC
Hotplate dimensions (w x d x h) 320 x 360 x 60mm
Control unit dimensions (w x d x h) 150 x 160 x 65mm
Lead length 2m
Net weight 11kg

zH06-05 ,V032 ylppus lacirtcelE

Tel: [phone]

Only spare parts supplied or specified by
Cole-Parmer or its agents should be used.
Fitting of non-approved parts may affect
the performance of the safety features

designed into the instrument. If in any
doubt, please contact the Service
Department of Cole-Parmer or the point
of sale.

For any other technical enquiries, please
contact the Technical Support Department:
Email: [e-mail],
Tel: [phone].

Servicing

This product does not require any routine
servicing.

NOTE: There are no internal user­replaceable parts.

In the event of a product failure any
repairs or replacement o

f parts MUST
only be undertaken by suitably qualified
personnel.

For advice, please contact the Service
Department, quoting both the model number
and serial number:
Email: [e-mail]

and so we cannot guarantee that interference will not
occur in practice. Where there is a possibility that injury,
damage or loss might occur if equipment malfunctions
due to radio frequency interference, or for general
advice before use, contact the manufacturer.

This product meets the applicable
harmonised standards for radio frequency
interference and may be expected not to

interfere with, or be affected by, other equipment with

similar qualifications. We cannot be sure that other

equipment used in its vicinity will meet these standards

Product Laboratory Equipment

Manufacturer Cole-Parmer Ltd

Beacon Road
Stone, Staffordshire
ST15 0SA
United Kingdom

File Number P225

Authorised Cole-Parmer
Representative Beacon Road

Stone, Staffordshire
ST15 0SA
United Kingdom

Object of Declaration

CP300 PTFE Hotplate

(reference the attached list of catalogue numbers)

The object of the declaration described above is in conformity with the relevant Union Harmonisation Legislation:

References to the relevant harmonised standards used or referen
to which conformity is declared:

Additional Information

Place of Issue

Date of Issue

Authorised Representative

Title

Signature

IEC/EN 61010-1:2010

Safety requirements for electrical equipment for
measurement, control and laboratory use.
Part 1: General requirements.

Particular requirements for laboratory equipment for the
heating of materials.

Electrical equipment for measurement, control and
laboratory use. EMC requirements.
Part 1: General requirements (Class A).

IEC/EN 61010-2-010:2003

IEC/EN 61326-1:2006

Low Voltage Directive

EMC Directive
RoHS Directive

2004/108/EC
2011/65/EC

Year of CE Marking: 2003

Stone, Staffordshire, UK

June 2009. Revised 18 April 2017

Carl Warren

Technical Manager

2006/95/EC

(until 19 April 2016)

2014/35/EU

(from 20 April 2016)

5

EU Declaration of Conformity

This declaration of conformity is issued under the sole responsibility of the manufacturer

Signed for and on behalf of the above manufacturer

Declaration of Conformity is also available to view online at www.stuart-equipment.com

6

INSPECTION REPORT

MODEL CP300

ELECTRICAL SAFETY

1. Earth continuity

2. Insulation

3. Flash test

FUNCTIONAL

1. Indicators

2. Heating function

3. Visual acceptance

QUALITY CONTROL INSPECTOR

7
