Models
HVOU56RSS
HVOU74RSS
HVOU96RSS
HVOU144RSS
Encore Series - HVOU Refrigerated Service Over
Self-Service Case
Applications
• Combination service
self-service
merchandiser for
refrigerated bakery
items.
EXTERIOR COLOR
INTERIOR COLOR
REAR EXTERIOR COLOR
TRIM COLOR
END PANELS
FRONT PANEL
REAR STORAGE
UPPER REAR
LOWER SHELVING
UPPER DISPLAY
LIGHTS
ELECTRICAL CONNECT
REFRIGERATION
MISCELLANEOUS
□ Painted
□ Black
□ White
□ Black
□ Full with mirror
□ ABS front panel
□ Non-refrigerated rear storage (w/o
doors)
□ Clear glass rear sliding doors
□ Clear glass shelf, lighted
□ Refrigerated
□ T-8 top & shelf lights
□ Leads
□ Remote DX refrigeration
Options Features Standard
□ Laminated (confirm pattern/grain direction)
□ Stainless steel
□ Stainless steel
□ White
□ Black
□ Stainless steel
□ Silver
□ Refrigerated rear storage (w/doors)
□ Reflective glass rear sliding doors
□ Smoked glass shelf, lighted
□ LED top & shelf lights
□ 6' locking power cord (self-cont.)
□ Breeze™ w/EnergyWise s/c refrigeration
□ 1'' bumper on front & ends
Revised
20014491
4/21/2015
ONE PART PASSION, TWO PARTS SCIENCE
(Lengths include end panels)
Encore Series HVOU Refrigerated Service Over Self-Service
Case
HVOU56RSS 58"L x 53-1/2"D x 52-5/8"H
Model
HVOU74RSS 76"L x 53-1/2"D x 52-5/8"H
HVOU96RSS 98"L x 53-1/2"D x 52-5/8"H
HVOU144RSS 146"L x 53-1/2"D x 52-5/8"H
L x D x H
STANDARD
IMPORTANT
NOTES:
1) 43'' minimum door entry
clearance required
(without shipping skid).
2) Units are supplied with
levelers which must be
adjusted during
installation to ensure the
unit is level and plumb.
3) Dimensions reflect
levelers extended 1-1/4''.
INTENDED
ENVIRONMENT
Designed to operate in
ambient conditions of 75°F
with 55% relative humidity.
INTEGRATED AVG
PRODUCT TEMP
Zone Temp (°F)
40 All
INTENDED USE OF
DISPLAY AREAS
Zone Intended Use
Packaged /
All
unpackaged
refrigerated products
INFORMATION IS SUBJECT TO CHANGE WITHOUT NOTICE. Visit www.structuralconcepts.com for the most current specs.
888 E. Porter Rd. Muskegon, MI 49441 231-798-8888
For more information on any
of our products or services
please visit us on the web at:
www.structuralconcepts.com
Revised
4/21/2015
