Models
HVB38SS
HVB56SS
HVB74SS
Encore Series - HVB Non-Refrigerated Self-Service Pull-Out
Drawer Case
Applications
• Self-service
merchandiser with
pull-out drawers for
non-refrigerated
bakery items.
EXTERIOR COLOR
INTERIOR COLOR
REAR EXTERIOR COLOR
TRIM COLOR
END PANELS
FRONT
BASKETS
REAR DOORS
LIGHTS
ELECTRICAL CONNECT
MISCELLANEOUS
□ Painted
□ Black
□ White
□ Black
□ None (Specify per line-up)
□ Stay-open pull-out drawers
□ 4''H Chrome wire baskets
□ Clear glass rear sliding doors
□ T-8 top & shelf lights
□ Leads
□ Tissue box holder
Options Features Standard
□ Laminated (confirm pattern/grain direction)
□ White
□ Black
□ Stainless steel
□ Silver
□ Full with mirror
□ 1 1/2''H Black wire baskets
□ 1 1/2''H Chrome wire baskets
□ 4''H Black wire baskets
□ Reflective glass rear sliding doors
□ Solid back panel
□ LED top & shelf lights
□ 12'' power cord
□ 1'' bumper on front & ends
□ Clear plastic basket liners
□ Tongs
Revised
20014408
4/21/2015
ONE PART PASSION, TWO PARTS SCIENCE
(Lengths do not include 1 " end panels)
Encore Series HVB Non-Refrigerated Self-Service Pull-Out
Drawer Case
HVB38SS 38"L x 41"D x 51-1/4"H
Model
HVB56SS 56"L x 41"D x 51-1/4"H
HVB74SS 74"L x 41"D x 51-1/4"H
L x D x H
STANDARD
IMPORTANT
NOTES:
1) 42'' minimum door entry
clearance required
(without shipping skid).
2) Units are supplied with
levelers which must be
adjusted during
installation to ensure the
unit is level and plumb.
3) Dimensions reflect
levelers extended 1-1/4''.
INTENDED
ENVIRONMENT
Designed to operate in
ambient conditions of 75°F
with 55% relative humidity.
INTEGRATED AVG
PRODUCT TEMP
Zone Temp (°F)
Ambient All
INTENDED USE OF
DISPLAY AREAS
Zone Intended Use
Unpackaged
All
non-refrigerated
products
INFORMATION IS SUBJECT TO CHANGE WITHOUT NOTICE. Visit www.structuralconcepts.com for the most current specs.
888 E. Porter Rd. Muskegon, MI 49441 231-798-8888
For more information on any
of our products or services
please visit us on the web at:
www.structuralconcepts.com
Revised
4/21/2015
