Digital Satellite Receiver
SRT 6200/SRT 6202/SRT 6205
Picture similar
User Manual
1.00
SRT 6202/6205 |
SRT 6205 |
2
3
Table of Contents
1.0 Introduction |
2 |
|
1.1 |
Safety Instructions |
2 |
1.2 |
Storage |
2 |
1.3 |
Equipment Set-up |
3 |
1.4 |
Accessories |
3 |
1.5 |
Usage of external USB devices |
3 |
2.0 Your Receiver |
3 |
|
2.1 |
Rear Panel |
3 |
2.2 |
Remote Control Unit |
4 |
2.3 |
Default PIN code: 0000 |
5 |
3.0 Connections |
5 |
|
3.1 |
Basic connection with SCART cable |
5 |
3.2 |
Connecting to Satellite Dish |
5 |
3.3 |
Connecting USB storage device |
5 |
4.0 Starting up |
5 |
|
4.1 |
Language Selection |
5 |
4.2 |
Select Satellite |
5 |
4.3 Antenna mode |
6 |
|
5.0 Main Menu |
6 |
|
5.1 |
Channel Organiser |
6 |
5.2 |
Installation |
7 |
5.3 |
System setting |
8 |
5.4 |
Timer |
10 |
5.5 |
Multimedia |
11 |
6.0 Watching TV and listening to the radio |
12 |
|
A.1 Trouble Shooting |
13 |
|
A.2 Specifications |
14 |
|
STRONG declares that this item complies with the basic requirements and other relevant regulations of directives CE 2004/108/EEC and 73/23EEC; RoHS 2002/95EEC
Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of products may change. All product names are trademarks or registered trademarks of their respective owners.
© STRONG 2011. All rights reserved. 03/2011
*€0,14/Min. from German wired line
*€0.42/Min. max. from mobile network
*€0,12/Min. from Austrian wired line
*€0,14/Min. from French wired line
per March 2010
4
1.0Introduction
1.1Safety Instructions
DO NOT INSTALL YOUR RECEIVER:
nIn a closed or poorly ventilated cabinet; directly on top of or under any other equipment; on a surface which might obstruct the ventilation slots.
DO NOT EXPOSE THE RECEIVER OR ITS ACCESSORIES:
nTo direct sunlight or near any other equipment that generates heat; to rain or intense moisture; to intense vibration and to any shock which may cause permanent damage to your receiver or to any magnetic objects, such as loudspeakers, transformers, etc.
nDo not use a damaged power cord. It may cause a fire or an electrical shock. Do not touch a power cord with wet hands. It may cause an electric shock.
nWhen the receiver is not used for a long period of time, you should unplug the power cord from the wall socket.
nDo not use alcohol or ammonia based liquids to clean the receiver. If you wish, you may clean your receiver with a soft lint-free cloth slightly made damp with a mild soap solution, only after disconnecting from the mains voltage supply. Make sure no foreign
objects fall through the ventilation slots because this could cause fire or an electric shock.
nDo not place any objects on top of the receiver because this might prevent proper cooling of the components inside.
Safety Precautions
nNever open the receiver cover. It is dangerous to touch the inside of the receiver due to high voltage currents and possible electrical hazards and your warranty will be void. Refer all maintenance or servicing to suitably qualified personnel.
nWhen you are connecting cables, be sure that the receiver is disconnected from the mains supply voltage. Wait a few seconds after switching off the receiver before you move the receiver or disconnect any equipment.
nIt is a necessity that you only use an approved extension and compatible wiring that is suitable for the electrical power consumption of the installed equipment. Please ensure that the electrical power supply corresponds with the voltage on the electrical identification plate at the back of the receiver.
If the receiver does not operate normally even after strictly following the instructions in this user
manual, it is recommended to consult your dealer or the desired service / support.
1.2 Storage
Your receiver and its accessories are stored and delivered in a packaging designed to protect against electric shocks and moisture. When unpacking it, make sure that all the parts are included and keep the packaging away from children. For transporting the receiver from one place to another or if you are returning it under warranty conditions, make sure to repack the receiver in its original packaging with its accessories. Failing to comply with such packaging procedures could void your warranty.
5
1.3 Equipment Set-up
We recommend you consult a professional installer to set up your equipment. Otherwise, please follow the instructions below:
nRefer to the user manual of your TV and your antenna.
nMake sure that the SCART cable and outdoor components are in a good condition and the SCART connections are well shielded
This manual provides complete instructions for installing and using this receiver. The following symbols will serve as follow.
Warning: |
Indicates a warning message for your necessary attention. |
Tips: |
Indicates any other additional important or helpful information. |
MENU |
Represents a button on the remote control or the receiver (Bold Character) |
Move to |
Represents a menu item within the On Screen Display. (Italic Character) |
1.4 Accessories
nUser’s Manual
n1 Remote control unit
n2x Batteries (AAA type)
Note: The batteries should not be recharged, disassembled, electrically short-circuited, be mixed or used with other types of batteries. If rechargeable accumulators instead of batteries are going to be used, we recommend using (e.g. NiMH) types
with low self-discharge to ensure long time operation of remote control.
1.5 Usage of external USB devices
nIt is recommended to use USB 2.0 storage devices. If your device is not compatible to USB 2.0 specifications, recording, playback and other multimedia functions of the receiver would not work properly.
nIf you are going to use external USB HDD (Hard Disk Drive) please consider that it might be the case that the power specifications exceed the supported output of your receiver (5V/500mA). If so, please connect your USB HDD to an according external power adapter.
nTo ensure best performance of your USB storage device please format it by this receiver (menu “Recording Device”) to FAT32 system. Other file systems are not supported by the receiver.
nSTRONG cannot guarantee compatibility to all types of USB storage devices.
2.0Your Receiver
2.1Rear Panel
|
Fig. 2 |
1. TO TV |
To connect to your TV using a coaxial cable or if you have a cable |
|
connected to the ANT input from your TV* |
2. ANT IN |
To connect to your terrestrial antenna or cable TV using coaxial cable* |
