Important Safety Instructions
• Connection can only be to a 240V AC mains supply.
• All safety and operating instructions should be read before the product is operated.
• All warnings on the product and in this user’s manual should be adhered to.
• Earthing: The antenna cable must be earthed.
• Do not use attachments not recommended by the product manufacturer as they may cause
hazards or damage to the equipment.
•Do not overload adaptors, wall sockets or extension cables as this can result in unit failure or
electrical shock.
•For cleaning, use only a dry or lightly dampened cloth. Do not use liquid cleaners or aerosol
cleaning products.
• Servicing can only be performed by qualified service personnel.
• Do not place this product in an unstable position.
2
Overview
Thank you for purchasing this Strong Digital Terrestrial Television Receiver.
This product has been manufactured in accordance with strict quality control procedures and is
fully compliant with Australian specifications.
Your new receiver will enable you to experience superior picture and sound quality, widescreen
images, extra channels plus a variety of new features.
•For a complete list of all of our digital terrestrial television receivers and satellite receivers, please
go to our website: www.strong-technologies.com
• For general enquiries, please email us at tech2@strong-technologies.com
• For technical assistance, please call our Technical Support Help Line on 1800 820 030
Main Features
• Component: Y / Pb / Pr
• Super Video Output: 4-Pin Mini Din
• RCA/Cinch: CVBS + L/R Audio
• RF Modulator
• Dolby Digital: S/PDIF Coaxial
• 16:9 Full screen, 4:3 Letterbox & Full screen
• Auto & Manual Search Modes
• Favourite Channel List Editing
• Fully Adjustable Menu Interface
• Picture In Menu
• EPG: Electronic Program Guide
• Picture Zoom Function
• Signal Level and Quality Indicators
• Captions and Teletext
• Time Clock Settings
• 8 Timer Event Settings
• Parental Lock
• Full Function Infra Red Remote Control
• RS-232C Port for Software Upgrade
• Games Function
• DVB/T Compliant
• COFDM Demodulation
• Dimensions: W250mm x D175mm x H38mm
3
Contents
Important Safety Instructions.............................................................................................................................................2
Main Features ......................................................................................................................................................................3
Checklist of Accessories ....................................................................................................................................................5
Controls and Indicators ......................................................................................................................................................6
Front panel ................................................................................................................................................... 6
Installing the batteries in the remote control ............................................................................................. 9
How to Connect .................................................................................................................................................................10
A: Y / Pb / Pr (Component) using the supplied RCA blue–red–green lead ............................................. 10
B. Separate S-Video (Y/C) connector ..................................................................................................... 10
C: CVBS (Composite) using the supplied RCA red–white–yellow lead .................................................. 11
D: Connection by RF Modulator (where no AV inputs are available on your TV) ................................... 11
E. Connecting the antenna...................................................................................................................... 12
Looping Out ............................................................................................................................................ 12
Scanning for channels and stations............................................................................................................ 13
Setting the time........................................................................................................................................... 15
Video settings ............................................................................................................................................. 19
Selecting a channel................................................................................................................................. 21
Adjusting the volume............................................................................................................................... 22
Getting channel Information .................................................................................................................... 22
Zooming in .............................................................................................................................................. 24
Re-scanning for channels and stations ................................................................................................... 25
Electronic Program Guide (EPG)................................................................................................................ 31
Opening the EPG.................................................................................................................................... 32
Using the timer............................................................................................................................................ 32
Setting or cancelling a timer from the EPG ............................................................................................. 32
Setting or cancelling a timer from the Preferences menu ....................................................................... 34
System Maintenance .........................................................................................................................................................36
System information ................................................................................................................................. 36
7 RF OUT IEC 169-24 femaleConnect to TV when using the RF
modulator
8 LOOP IN IEC 169-24 female Input from connector 2 when using the RF
modulator
9 POWER – To turn unit on or off
7
Remote Control
1. STANDBY: To switch between power-on and
stand-by modes
2. Numeric Buttons (0–9): To choose a channel
directly, or to enter numeric information in a
menu
3. TV/RAD: To switch between TV and radio
(and vice versa)
4. EPG (Electronic Program Guide): To show
the TV and radio program guide
5. MENU: To display the main menu, or return
to a previous menu
6. CH (▲/▼): To change channels in viewing
mode, or to move the cursor up or down in a
menu
7. VOL (
8. OK: To show the channel list in viewing mode,
9. FAV: To display the favourites list in viewing
8
e/f): To change the volume in
viewing mode, or to change an option or
setting in a menu
and to select an item (or confirm a choice) in
a menu
mode, and to select a favourite
10. RECALL: To return to the previous channel
11. SUB: To display closed captions
12. AUDIO: To choose a audio format (PCM
stereo or Dolby Digital), audio language
and display subtitles.
13. MUTE: To turn the sound on or off
17. PAGE UP: To move to the next page if there
is more than one page
18. PAUSE: To freeze the screen
19. ZOOM: To zoom in or out
20. PAGE DOWN: To move to the previous page
if there is more than one page
14. FORMAT: To change the aspect ratio
15 INFO: To show information about the
current program
16. EXIT: To close the current menu and return
to normal viewing
21. TXT: To show Teletext
22. UPGRADE: To upgrade the software
Installing the batteries in the remote control
1. Press down on the retaining catch on the lid of the battery recess on the remote control and
remove the lid.
2. Insert two AAA batteries into the recess.
Be careful to insert the batteries as shown in the diagram inside the recess.
3. Replace the lid over the recess and gently push down on the lid until it snaps firmly into place.
9
How to Connect
There are a number of alternative methods for connecting the SRT 5020, depending on your
preference and the connection types on your TV. These methods are labelled A, B, C and D below.
(Connection E, connecting to an antenna, is mandatory for connection methods A, B and C.)
IMPORTANT: Refer to the diagram on page 7 for the location of the sockets identified by numbers in
the methods listed below.
A: Y / Pb / Pr (Component) using the supplied RCA blue–red–green lead
For Component video, connect to your TV with the supplied Y / Pb / Pr Component cable (with
blue, red and green leads). Connect the leads between the Y, Pb and Pr sockets on the SRT 5020
(top row of socket group 6, taking care to match the colour of a lead with the colour of the socket),
and the corresponding Component sockets on your TV. (The Component sockets on the TV have
the same colour-coding.)
You will need to make separate connections for left and right audio via the audio sockets on the
bottom row of socket group 6. This can be done using the supplied RCA cable.
For right audio, connect the red RCA lead between the red audio socket on the SRT 5020 and the
corresponding socket on your TV.
For left audio, connect the white RCA lead between the white socket on the SRT 5020 and the
corresponding socket on your TV. These RCA audio connections will provide MPEG-2 stereo.
NOTE: Dolby digital bitstream audio S/PDIF can be achieved using a coaxial cable. (This
cable is not supplied.) The cable should be connected between socket 5 on the SRT
5020 and the S/PDIF socket on your Dolby Digital decoder amplifier. See “Audio
settings” on page 19 for instructions on how to receive Dolby Digital audio.
B. Separate S-Video (Y/C) connector
If your TV has a 4 Pin Mini Din S-Video socket, you can connect an S-Video cable between socket 4
on the SRT 5020 and the corresponding S-Video socket on your TV. (An S-Video cable is not
supplied.)
You will need to make separate connections for left and right audio via the audio sockets on the
bottom row of socket group 6. This can be done using the supplied RCA cable.
For right audio, connect the red RCA lead between the red audio socket on the SRT 5020 and the
corresponding socket on your TV.
For left audio, connect the white RCA lead between the white socket on the SRT 5020 and the
corresponding socket on your TV. These RCA audio connections will provide MPEG-2 stereo.
NOTE: Dolby digital bitstream audio S/PDIF can be achieved using a coaxial cable. (This
cable is not supplied.) The cable should be connected between socket 5 on the SRT
5020 and the S/PDIF socket on your Dolby Digital decoder amplifier. See “Audio
settings” on page 19 for instructions on how to receive Dolby Digital audio.
10
C: CVBS (Composite) using the supplied RCA red–white–yellow lead
Using the appropriate socket colour-coding on socket group 6, you can connect to your TV with
the supplied RCA cable. This gives you CVBS (Composite Video) and MPEG-2 stereo audio.
For video, connect the yellow RCA lead between the yellow video socket in socket group 6 on the
SRT 5020 and the corresponding socket on your TV.
For right audio, connect the red RCA lead between the red audio socket on the SRT 5020 and the
corresponding socket on your TV.
For left audio, connect the white RCA lead between the white socket on the SRT 5020 and the
corresponding socket on your TV.
NOTE: Dolby digital bitstream audio S/PDIF can be achieved using a coaxial cable. (This
cable is not supplied.) The cable should be connected between socket 5 on the SRT
5020 and the S/PDIF socket on your Dolby Digital decoder amplifier. See “Audio
settings” on page 19 for instructions on how to receive Dolby Digital audio.
D: Connection by RF Modulator (where no AV inputs are available on your TV)
If your TV does not have any audio-visual (AV) Inputs for connection, you can receive digital
broadcasts by using the in-built RF modulator of the SRT 5020.
1. Connect an RF cable from your antenna wall plate to the TV ANT IN socket on the rear of the
SRT 5002 (socket 1).
2. Connect another RF cable (not supplied) between the LOOP OUT socket on the SRT 5020
(socket 2) and the LOOP IN socket on the SRT 5020 (socket 8).
3. Connect another RF cable (not supplied) between the RF OUT socket on the SRT 5020 (socket 7)
and the ANT In socket on your TV.
4. Turn on the SRT 5020 with the power switch on the back panel. The red stand-by light appears
on the display along with 4 horizontal lines.
5. Press the Power button on the SRT 5020 remote control.
6. Turn on your TV and conduct an auto scan to find the RF channel. (The RF channel is 38 by
default, but you may need to refer to the instruction manual that came with your TV).
Once the RF channel has been found, a Strong Technologies Welcome screen appears listing
various set-up options. These options are explained in “Getting Started” on page13.
How to select a different RF channel
If the RF channel is not channel 38:
1. Press the MENU key on the remote control followed by the blue button (labelled TXT).
2. Press OK on the remote control. You will see a menu with a number of options.
3. Press CH ▼ on the remote control until the Settings option is highlighted, and then press OK.
4. Press CH ▼ on the remote control until the RF Modulator option is highlighted, and then press OK.
5. Use the number keys on the remote control to enter the correct RF channel (as described in
your TV manual), and then press OK.
11
E. Connecting the antenna
Connect the antenna lead coming from your antenna wall plate to the ANT IN socket on the SRT
5020 (socket 1).
Looping Out
If you connect a recording device (such as a VCR) either between the SRT 5020 and the TV (or from
the TV), you will not be able to watch one channel while manually recording another. To overcome
this, you can connect an RF cable (not supplied) between the LOOP OUT socket on the SRT 5020
(socket 2) and the ANT IN connector on your TV (or VCR).
12
Loading...
+ 28 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
