Strong SRT 4661X User's Manual

1. Introduction 2

1.1 Overview

1.2 Main Features

2. Safety/Precautions 3

2.1 Safety

2.2 Precautions

3. Points to Check before Use 5

3.1 Accessories

4. Controls/Functions 6

4.1 Front Panel

4.2 Rear Panel

4.3 Remote Controller

5. How to Connect 10

6. Operation 11

6.1 Getting Started

6.2 System Setting

6.3 Channels

6.4 Electronic Program Guide

6.5 Games

6.6 USB Menu

6.7 System Information

6.8 PVR

7. Troubleshooting 44

8. Specifications 45

Contents

2 3

This satellite receiver is designed for the reception of free-to-air. Depending on your location, enjoy the rich choice of up to 10,000 different channels broadcasting a large range of programs: culture, sports, cinema, news, events, etc. This receiver is assembled with highly qualified electronic parts.

Introduction

1.1 Overview

MPEG-II digital & fully DVB compliant

On-Screen Display (OSD) with a 256-colors color resolution

DiSEqC control version 1.0, 1.1, 1.2 and USALS compatible

16 renameable favorite channel groups

Powerful channel control by Favorites, Lock, Skip, Move and Delete

Channel sorting by Alphabet, Transponder and Conditional Access System (CAS)

Multilingual language OSD & menu : English, Italian, Turkish, Arabic, Parsi, German, French, Russian, Spanish, Portuguese

Extended Electronic Program Guide (EPG) and program reservation through EPG

Teletext by OSD/VBI (Vertical Blanking Interval)

Last channel memory function

Total of 10,000 programmable channels

Advanced ‘Channel List’ menu

Multi-satellite search

Games with stereo sound

Software & channels database upgrades via RS-232C: PC to STB/STB to STB

Parental Lock/ Installation Lock / Receiver Lock / Channel Lock / Lock Channel Confirm.

Digital audio output [S/PDIF

]

Multi-picture display

Zoom capabilities

Advanced Blind Search Function

Color Adjustment Function

USB Interface

Component output(Y/Pb/Pr)

USB2.0 PVR Ready via external HDD with Timeshift, Record & Playback functions

High speed software upgrade via USB 2.0

MP3 player and JPEG viewer

1.2 Main Features



Be sure to read this user's manual before starting the operation of the unit.



Do not touch the power cord with wet hands as it may cause electric shock.



Never open the cover. It is very dangerous to touch the inside of the unit due to possible electric shock.



Place the unit in a well ventilated and no-heat environment.



When you do not use this unit for a long time, make sure that the power cord is pulled out from the outlet. Also do not use a damaged power cord as it may cause fire or electric shock.



A professional installation is required. If reception is interrupted, contact your local service centre.

Safety/Precautions

2.1 Safety

DiSEqC is a trademark of EUTELSAT

4 5

When installing the unit

2.2 Precautions



Install the unit horizontally. An uneven installation may cause the unit to be damaged.



Do not put heavy items such as a TV set on the unit. That may damage the unit.

Do not leave the unit where the water drops or splashes.

Do not put water holding items such as vases on the unit.



Do not install the unit:

ҮWhere it is subject to vibrations ҮWhere it is exposed to direct sunlight ҮWhere there is humidity ҮWhere the temperature is too high or too low. ҮWhere there is no ventilation



Moving the unit to a hot area from a cold one will cause condensation. Do not operate the unit for one or two hours or until it has dried completely.

User's manual : 1

User's manual

Remote control : 1

Batteries (AAA type) : 2

Component Cable : 1

The accessories below are included with this receiver:

Points to Check before Use

3.1 Accessories

Your dish should be properly installed and azimuth and elevation must be precisely set up.

This unit supports DiSEqC 1.2 and can work with a compatible antenna positioner.

Ask your dealer for information.

3.2 The Satellite dish

RCA Cable : 1

The mains plug is used as the disconnect device.

The disconnect device shall remain readily operable.

Ȟ If any of the above-listed

accessories is missing, contact your sales representative.

6 7

Controls/Functions

4.1 Front Panel

4.2 Rear Panel

7 1181 3 5

9 10 122 4 6

No. Name Connector Function

1LNB INPUT IEC 169-24 FEMALE IF input from LNB to digital tuner

2 LOOP OUT IEC 169-24 FEMALE IF loop-through output from digital tuner

3 AUDIO L RCA cinch Left audio output

4 AUDIO R RCA cinch Right audio output

5VIDEO RCA cinch Composite video output

6 S/PDIF RCA cinch Digital audio output

7Y RCA cinch Component video output (Y)

8Pb RCA cinch Component video output (Pb)

9Pr RCA cinch Component video output (Pr)

10 RS-232C DB-9 Low speed serial port

11 RF OUT UHF 21-69 IEC 169-2 MALE Output to TV

12 TV ANT IN IEC 169-2 FEMALE Input from terrestrial antenna

Standby/Power on Indications Lamp : Flashes red light in ‘Standby’ mode and

shows no light in ‘Power ON’ mode.

Indication Light : Flashes when a key on the Remote Control Unit (RCU) is

pressed.

Power : Switches the receiver between ‘Standby’ and ‘Power ON’ modes.

- CH.

ƊƊ/ƌƌ

: To switch channels or change the cursor position on the

application screen.

USB : To connect USB devices such as Memory stick or external Hard Disk Drive.

3 6

51 2 4

8 9

4.3 Remote controller 4.3 Remote controller

POWER :To turn the receiver On/Off.

MUTE: To turn the sound On/Off.

Numeric Keys (0-9) : To enter numerical

settings (such as channel numbers) directly.

INFO : To show information about the current program. Press twice to show detail.

PAUSE : To pause the video. Press again to resume the video.

EPG : To show the TV/Radio program guide.

GROUP:To change the channel

groups(Satellites or favorite groups).

MENU : To enter or exit the main menu.

EXIT :To exit from the present menu and

move to the previous menu.

- Double arrow UP/DOWN : To move to the next or previous page when many pages are available.

- Up & Down : To switch channels in non-menu mode and move the cursor up/down in menu mode.

- Left & Right : To change the volume level in non-menu mode and modify a setting in menu mode.

OK: To show the Channel List in non-

menu mode and select an item or confirm in menu mode.

TV/RADIO :To switch between TV and

Radio.

TV/SAT :To switch the TV output source

between the satellite input and the UHF/VHF antenna input.

1514

1312

1110

RECALL(RED

)

To move to the previous channel. Used for special functions in menu mode.

AUDIO(GREEN

)

To show the Multilanguage audio track, the stereo-mono mode. Used for special functions in menu mode.

TEXT(YELLOW

)

To show the teletext contents if teletext is transmitted. Used for special functions in menu mode.

BLUE : To display multiple pictures.

COLOR : To control the brightness,

contrast and color of a picture.

ZOOM : To zoom in the screen picture.

Press the ZOOM button and select a screen section, then press the OK button. (You can zoom in by 3 times)

RWD : Playback in rewind mode.

ADVANCE : Go to live channel.

FWD : Playback in forward mode.

REC : Start recording.

PLAY : Play Content.

STOP : Stop Playback.

FILELIST : To display the filelist.

BOOKMARK : To mark a specific place

in a file for later retrieval.

SLEEP : To set the STB off after minutes.

10 11

Operation

6.1 Getting Started



Turn on your TV and receiver.



The pop-up menu for language selection will appear.<Figure 6.1.1>

Select one language and press to proceed.

After your receiver is powered on, proceed with installation as follows :

1) Menu Language Setting

How to Connect

Connect the TV antenna to TV ANT IN

Connect the RF-IN of the TV to RF-OUT

When available, you may instead connect the video and audio of the TV to video and audio: Connect the red and white connectors to Audio R and Audio L, and the yellow connector to video

When available, you may instead connect the Component Video of your TV to Component Video for best quality: connect the Y, Pb and Pr of your TV to Y,Pb and Pr respectively

Connect your satellite dish

1312

6.1 Getting Started 6.1 Getting Started



Select the item that you want to edit, and set its parameters as desired. <Dish Setting>

- LNB Power : Select among ON/OFF/13V/18V.

- LNB Type : Select among Single/Universal/OCS.

- LNB Freq : Set the frequency of the LNB oscillator.

- 22KHz : When not AUTO, set the signal path from LNB or switch by selecting a control

signal among 0/22KHz.

- DiSEqC switch : Select DiSEqC protocol among OFF/1.0/1.1 as appropriate for your configuration.

- Committed/Uncommitted : Select the DiSEqC port.



Select the item that you want to edit and set its parameters as desired. <Motorized Setting>

- Frequency : If the default TP frequency is not appropriate, you can select another TP

frequency at which to check for signal.

- DiSEqC Motor : Select DiSEqC protocol among OFF/1.2/USALS as appropriate for your

Motor.

(

When the DiSEqC Motor parameter is set as 1.2

)

- Hemisphere : Select between the Northern/Southern.

- Move : You can move the dish to the West/East.

- Limit : If you want to set limits, press .

- Disable Limit : You can disable the East and West limits.

- Goto Center : Move the dish to the initial 0 position.

- Set East / West Limit : Move the dish East or West using / .

Press to set East or West limit.

(

When the DiSEqC Motor parameter is set as USALS

)

- Sat Degree : Satellite location.

- Antenna Position : Press .

- Goto Reference : Move the dish to the reference 0 position.

- Antenna Longitude : Your longitude at present.

- Antenna Latitude : Your latitude at present.

Note : You need to know what LNB you are using to correctly set the L.O. (local

oscillator) frequency.

Note : You need to understand how your receiver is connected to properly set the

22KHz and DiSEqC.



When you are done, press the EXIT button.

VOL



Press the MENU button to display the main menu.



Use / and / to move in the menu.



Press on ‘Dish Setting’. The following window will appear. <Figure 6.1.2> If you have a motorized dish, press on ‘Motorized Setting’. <Figure 6.1.3>

Note : Enter a 4-Digit password if need arise. The default password is ‘0000’.

VOL

2) Antenna Setup

1514

Manual Scan <Figure 6.1.7>



Select a transponder.



To change a transponder’s information (Frequency, Symbol Rate), use the NUMERIC buttons.



To change a transponder's polarization, use the or keys.

 To add a new transponder, press the GREEN button.

 To delete a transponder, press the YELLOW button with the cursor next to the Frequency

parameter.

 To search a transponder, set its different parameters and press .

VOL

6.1 Getting Started 6.1 Getting Started

Package Identifier (PID) Scan <Figure 6.1.8>



Select a transponder.



To change a transponder’s information (Frequency, Symbol Rate), use the NUMERIC buttons.



To change a transponder's polarization, use the or keys.

 To add a new transponder, press the GREEN button.

 To delete a transponder, press the YELLOW button with the cursor next to the Frequency

parameter.

 To search a transponder, set its different parameters and press / . You can search

a specific channel of the transponder by setting its PID data (Video, Audio and PCR).

Note : If you cannot access programs after correctly completing a scan procedure,

please contact your seller or your installer.

VOL

Through this function, the receiver searches for all the available channels and saves them in memory. Chose Auto Scan to search using transponders (frequencies) in memory, or chose Blind Scan to look for new satellite/transponders.

Auto Scan <Figure 6.1.4>



Press on the names of the satellites that you want to scan under ‘Satellite List’. You can select more than one satellite.



Press and set the ‘Search Type’ and ‘Network Search’ parameters.

- Search Type : Decide for which channels to search (All channels/ Free channels only/

TV channels only).

- Network Search : Set ON to find more transponders (frequencies) through a Network Information Table (NIT) scan. That is, when the broadcaster is sending a NIT through a given transponder, the receiver will also scan for transponders listed in the NIT and not otherwise recognized.

(this can happen when a transponder is new)



Press under ‘SCAN’ to scan the selected satellites. <Figure 6.1.5>

VOL

3) Satellite Scan

Blind Scan <Figure 6.1.6>



Select the satellites you want to search by pressing the button on the remote.



Press



/ to set the “Polarization” and “Scan Mode” options.

- Polarization : Select Vertical / Horizontal / All.

- Scan Mode : Select Fast / Detail.

- SCAN : Begin channel search of the selected satellites.



Press the RED button on the remote to begin a blind scan of all ‘selected’ satellites.

VOL
