SRT 40FB5203
SMART TV with DVB-T2/C/S2
SRT 32HB5203
SRT 40FB5203
User Manual
Bedienungsanleitung
Manuel ulisateur
Manuale utente
Manual do Ulizador
Инструкции за употреба
Руководство пользователя
Посібник користувача
Användar Manual
Uživatelská příručka
Navodila za uporabo
Korisnički priručnik
Uputsvo za rukovanje
Používateľská príručka
Használa útmutató
Käyöohje
Brukermanual
Manual del Usuario
Gebruiksaanwijzing
Brugervejledning
Manual de Ulizare
Instrukcja obsługi
Fig.1
Fig.2
Fig.3a
1
2 2
1
Fig.3b
S/PDIF
ETHERNET
1
SAT IN
3
ANT/CABLE IN
4
(coax)
2
HDMI 1
6
5
USB 2.0
HDMI 2 (ARC)
8
7
AV IN
CI+
10
9
3
Fig.4 Fig.5
1
123
3
789
4
8
6
9
10
11
14
16
18
20
21
22
25
26
29
30
33
34
0
VOL
SOURCE
USB
INFO
MENU
OK
BACK
G
R
SLEEP
SUBTEXT
2
654
5
CH
7
12
FAVOPTION
13
EPG
15
1.
17
19
B
Y
23
LIST
ZOOM+ZOOM-
24
ECO
27
28
31
32
AUDIO
35
36
2.
3.
Fig. 6 а Fig. 6 b
Modem
or
Router
Ethernet
port on the
back panel
Internet
Wireless router
TV Set
Fig. 7
OK
Play/Pause
5
FB
6
FF
Playlist Settings
OPTION
Fig. 8
5
FB
{
Prev.
2
Pause
}
Next
6
FF
Reverse Info.
Fig. 9
1
Pause/Stop/FB/FF
90°
90°
Rotate
Zoom In
Zoom OutRotate
Music
TV Set
www.strong.tv
Supplied by STRONG Austria
Represented by STRONG Ges.m.b.H.
Franz-Josefs-Kai 1
1010 Vienna, Austria
Email: support_at@strong.tv
19 Mar 2019 17:52
Licenses
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC
STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A
VIDEO PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED
FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM
This product contains one or more programs protected under international and U.S. copyright laws as
unpublished works. They are confidential and proprietary to Dolby Laboratories. Their reproduction
or disclosure, in whole or in part, or the production of derivative works therefrom without the express
permission of Dolby Laboratories is prohibited. Copyright 2003-2009 by Dolby Laboratories. All rights
reserved.
THIS PRODUCT IS SOLD WITH A LIMITED LICENSE AND IS AUTHORIZED TO BE USED ONLY IN
CONNECTION WITH HEVC CONTENT THAT MEETS EACH OF THE THREE FOLLOWING QUALIFICATIONS:
(1) HEVC CONTENT ONLY FOR PERSONAL USE; (2) HEVC CONTENT THAT IS NOT OFFERED FOR SALE; AND
(3) HEVC CONTENT THAT IS CREATED BY THE OWNER OF THE PRODUCT. THIS PRODUCT MAY NOT BE
USED IN CONNECTION WITH HEVC ENCODED CONTENT CREATED BY A THIRD PARTY, WHICH THE USER
HAS ORDERED OR PURCHASED FROM A THIRD PARTY, UNLESS THE USER IS SEPARATELY GRANTED
RIGHTS TO USE THE PRODUCT WITH SUCH CONTENT BY A LICENSED SELLER OF THE CONTENT. YOUR
USE OF THIS PRODUCT IN CONNECTION WITH HEVC ENCODED CONTENT IS DEEMED ACCEPTANCE OF
THE LIMITED AUTHORITY TO USE AS NOTED ABOVE.
English
SIMPLIFIED EU DECLARATION OF CONFORMITY
Hereby, STRONG declares that the radio equipment type LED TV is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: https://www.strong.tv/en/doc
Subject to alterations. In consequence of continuous research and development technical specifications, design and appearance of
products may change. Manufactured under license from Dolby Laboratories. Dolby Audio and the double-D symbol are registered
trademarks of Dolby Laboratories.The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc in the United States and other countries. Wi-Fi is a registered trademark of Wi-Fi
Alliance®. Netflix is a registered trademark of Netflix, Inc. YouTubeTM is a trademark of Google Inc. All product names are trademarks or
registered trademarks of their respective owners.
© STRONG 2019. All rights reserved.
1
To obtain the best performance and safety, please read this manual carefully. Please keep this manual for
future reference.
TABLE OF CONTENTS
1.0 INSTRUCTION 3
1.1 Safety Instructions 3
1.2 Storage 4
1.3 Accessories 4
1.4 Equipment set-up 4
2.0 INSTALLATION 5
2.1 Default PIN code: 1234 5
2.2 Front panel 5
2.3 Rear panel 5
2.4 Remote control 6
2.5 Installing the batteries 7
2.6 Using the remote control 7
3.0 FIRST TIME INSTALLATION 7
4.0 ELECTRONIC PROGRAMME GUIDE EPG 8
5.0 NETWORK CONNECTION 8
5.1 Connecting to a wired network 8
5.2 Connecting to a wireless network 9
6.0 HOME MENU 9
7.0 MENU SETTINGS 9
7.1 Menu control 9
7.2 Picture menu 9
7.3 Sound menu 10
7.4 Channel menu 10
7.5 Smart TV menu 11
7.6 System menu 12
8.0 USB 12
8.1 Reminder when using the USB player 12
8.2 USB menu 13
9.0 TROUBLESHOOTING 15
10.0 SPECIFICATIONS 17
2
1.0 INSTRUCTION
1.1 Safety Instructions
Read all of the instructions before operating the set. Keep these instructions well for later use.
Only use attachments/accessories specified or provided by the manufacturer (such as the
exclusive supply adapter, battery etc.).
Please refer to the information on the exterior back enclosure for electrical and safety
information before installing or operating the apparatus.
To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
The ventilation should not be impeded by covering the ventilation openings with items, such as
newspaper, table-cloths, curtains, etc.
The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
The mark indicates a risk of electric shock. The external wires must be installed by an
instructed person or ready-made leads or cords must be used.
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with
the installation instructions.
Danger of explosion if the battery is incorrectly replaced. Replace only with the same or
equivalent types.
The battery (battery or batteries or battery pack) shall not be exposed to excessive heat such as
sunshine, fire or the like.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Listening to music at high volume levels and for extended durations can damage one's hearing.
In order to reduce the risk of damage to hearing, one should lower the volume to a safe,
comfortable level, and reduce the amount of time listening at high levels.
The mains plug or appliance coupler is used as disconnect device, it shall remain readily
operable. When not in use and during movement, please take care of the power cord set, e.g. tie
up the power cord set with cable tie or something like that. It shall be free from sharp edges or
similar which can cause abrasion of the power cord set. When put into use again, please make
sure the power cord is not damaged. In case of damages, please get the power cord replaced
by a similar one with the same specifications. The absence of a light indication on the apparatus
does not mean that it is fully disconnected from the mains. To disconnect the apparatus
completely, the mains plug must be pulled out.
Attention should be drawn to environmental aspects of battery disposal.
No naked flame sources, such as lighted candles, should be placed on the apparatus.
To prevent the spread of fire, keep candles or other open flames away from this product
at all times.
A USB terminal can provide a maximum of 500 mA.
Equipment with this symbol is a Class II or double insulated electrical appliance. It has
been designed in such a way that it does not require a safety connection to electrical
earth.
Operating Environment
Do not install this equipment in a confined space such as a bookcase or similar unit.
Do not use the set near damp, and cold areas, protect the set from overheating.
Keep away from direct sunlight.
Do not use the set near dust place.
Do not attach candle to accessible opening area, to avoid flammable foreign material from
entering the TV.
English
3
