A warm welcome

Nothing creates an inviting atmosphere quite like a

Gazco fire. The centrepiece of any home, a Gazco fire

adds warmth and character to a room or living space -

even if you don't have a chimney!

Whether you want to achieve an up-to-the-minute,

contemporary look, or have your heart set on a more

traditionally-designed fire, this brochure will help you

make the perfect choice, whatever your style or budget.

Front Cover: Studio 1 Pienza Open with White Stone fuel bed

5IF'VUVSFPG'MBNF

Page 3

Relax - it’s a

Gazco Fire

When you choose Gazco, quality and

technology are assured. From traditional

models to contemporary designs, Gazco

is committed to creating the ultimate

flame-effect gas and electric fires.

Our research and development laboratories

are amongst the most advanced in the world,

ensuring that the very latest innovations are

incorporated into our appliances. The new

high efficiency are just two examples.

Additionally, we offer a superb range of solid

fuel, gas and electric fire baskets, each one

handcrafted using traditional materials such

as brass, steel, chrome and cast iron. Many

are also offered in a choice of sizes and in a

variety of casting shapes or finishes. In fact,

there are almost 100 combinations from

which to select the perfect fire basket for

your fireplace.

Gazco is a BSI registered firm. Our rigorous

quality control system ensures that all

our appliances comply with British safety

standards as well as stringent European

regulations. We also carry the European

quality standard CE mark on all our fires.

™

E-Box

and E-Studio™ fires

Page 4

type of c

Your

Balanced Flue

(No chimney required)

Balanced flues work in conjunction with glass fronted gas

fires. The appliance is completely sealed from the room into

which it is installed (so there are no draughts and heating

efficiency is increased!) and a twin-wall pipe vents directly

to an outside wall. Air for combustion is drawn in through

the outer pipe whilst the inner pipe removes the combustion

gases to the exterior of the property. Depending on the fire

selected, the twin-walled pipe may exit horizontally through

an external wall or vertically through the roof. No electric

supply is required; therefore there is no sound with this

flue system.

An Integral Powered Flue fire is an open fronted gas

appliance with an electronically driven fan system mounted

directly behind it on an external wall. When the fire is

ignited the fan switches on automatically, expelling the

products of combustion through a short, horizontal metal

flue to the outdoors.

This works in a very similar manner to the Integral Powered

Flue. However, the main benefit is that, instead of a short,

straight-through-the-wall flue, you can have much longer flue

runs and up to three bends in the flue. This means your fire

does not have to be installed against an external wall so it

can be located in more rooms around your home.

Electric Fires

(No chimney required)

Gazco produce an excellent selection of electric Riva fires

and the electric Stilo inset fire which do not, of course,

require a chimney or flue of any kind.

Pre-cast Flue

(Class 2)

Many modern homes have been built with such flues. You

can readily identify them by either a metal flue cowl or a

raised ridge terminal on your roof. Again, the natural

circulation of heated air expels the products of combustion.

Incidentally, these flues tend to be very shallow in depth so

a slimmer fire is often required. Deep appliances, however,

may be able to be installed with the use of either a spacer

kit or deeper rebate on the fireplace.

Integral Powered Flue

(No chimney required)

Powered Flue

(No chimney required)

All fires shown with this symbol, boast the advantage of not normally requiring an air vent*. Please discuss this in full with your local retailer.

*Requirements in the Republic Of Ireland are different.

No Air Vent required (UK)

home...

The type of c himney or flue you have usually dictates your

The

choice of fire. To help you understand which fires are suitable

for your home, please use the following information and pictures

to identify your chimney. Don’t worry, if you don’t have a

chimney though, you can still find the perfect fire for your home!

Once you have identified your chimney (or confirmed you do

not have one), take note of the symbol that represents this, as

this will be used throughout the brochure to represent the fire

or fires that are suitable for installation in your home. You may

also want to utilise the fold-out key at the back of this brochure

to quick reference any symbols. Please check with your local

Gazco retailer that your flue and fireplace opening are suitable

for your fire choice.

Brick/Stone Chimney

(Class 1)

Conventional chimneys are easily recognisable. The stack

rises well above the roofline and is topped by a traditional

chimney pot or gas terminal. This type of chimney relies on

the natural circulation of heated air to expel the products of

combustion up your chimney.

Pre-fabricated Flues

You will see a metal flue cowl on your roof. Some are all

metal whilst others may terminate through a short rectangular

pot (but without a chimney stack). These flues create the

same circulation of heated air as a brick or stone chimney.

(Class 1 & 2)

Page 5

Open Studio - White Stone Fuel Bed

All Open Studio fires incorporate Gazco’s ultra contemporary flame effect, a single ribbon of modulating flames dancing over a bed of small white stones. Beautifully reflected by the stainless front plate there is also the additional option for a polished black granite interior to further increase the reflective qualities of the fire. Open Studios are one of the few gas fires on the market that allow the possibility of installing a Plasma or LCD television above them, for a great visual centrepiece, please see page 123 for full details.

There is a choice of three fire styles in the range; Open Fronted with

white stone fuel bed, Glass Fronted with white stone fuel bed and the

newly added, Glass Fronted log effect fuel bed. Our near invisible

Glass Fronted fires boast greatly increased heating efficiency whilst

maintaining all the style of the Open Studios. They are also available

in a balanced flue option making them perfect for many homes, even

those without a chimney!

According to model, there is also a choice of three sizes in perfectly

proportioned landscape form, allowing you to achieve that dramatic

look in both the smallest and the largest of interiors! Additionally, this

year we have developed the visually diverse Studio 22 fires with their

innovative portrait shape. These stunning additions are set to inspire

a whole host of ne w decorative styles and are testament to Gazco’s

continued investment into inspired product design.

Glass Fronted Studio - White Stone Fuel Bed*

Glass Fronted Studios benefit from greatly increased heat output, boasting up to 81% efficiency. The standard features of the Studio Open are also included in this fire choice, including the white stone ribbon flames. According to fire size, there are options for both conventional and balanced flue installations, making the Studio perfect for many homes, even those without a chimney!

Glass Fronted Studio - Log Effect Fuel Bed*

This latest addition to the Studio range also offers increased efficiency but with the additional benefit of a special heat-retaining lining, storing and radiating heat after the fire has been turned off. This choice is for those who want the modern styling that only comes with a Studio whilst maintaining a more traditional feel to the fire, due to a newly developed realistic log effect fuel bed, beautifully displayed behind a near invisible glass window. Highlighting the log effect is a lighter coloured interior, in contrast to the black contemporary interior of the white stone versions. This version is available in both balanced flue and conventional flue versions.

*Please note that due to the higher efficiency of the Glass Fronted Studio’s, Gazco does not recommend installing any televisions above these fires.

Remote Controls

All fires in the Studio range are supplied with a state-of-the-art Sequential remote control as standard, allowing you to operate everything from ignition to flame height and heat output from the comfort of your sofa. For the Glass Fronted Studios the Programmable Sequential remote also includes the additional benefit of programmable timer and thermostatic controls, ensuring that, if you choose to set it, whenever you return home your house will always be warm and welcoming.

Should you mislay your hand set, Studio fires also come complete with a flat Touch Control panel that can be discreetly wall mounted up to 2500mm away from the fire, allowing you to ignite, extingish and control the flame height with ease.

Studio Fires

Breathtaking! There really is no better way to describe our stunning Studio fires, with a wealth of design options complemented by a choice of sizes and fuel bed effects, these thoroughly contemporary fires will add instant style and presence to any modern interior.

Studio 2 Inca Open with White Stone fuel bed

Page 6

Studio 1

According to model, the landscape Studio 1 is available as an Open Fronted model with White Stone fuel bed or Glass Fronted version, which has the additional choices of a realistic Log fire and balanced flue option. The Studio 1 Open Fronted produces a heat output of up to 1.72kW whilst the Glass Fronted boasts greatly increased efficiency and has a heat output of up to 5.20kW.

Studio 2

The landscape Studio 2, according to model, is also available as an Open Fronted model with White Stone fuel bed or Glass Fronted version, which has the additional choices of a realistic Log fire and balanced flue option. The Studio 2 fires, being wider, produce greater heat outputs than those of the Studio 1; up to 2.30kW is offered by the Open Fronted whilst the Glass Fronted fires produce up to 6.97kW.

Studio 3

According to model, the Studio 3, the largest size in the range, is available in Open Fronted or Glass Fronted versions, both with White Stone fuel beds. The Studio 3 Glass Fronted, due to its impressive

7.30kW of heat output, is for balanced flue installations only, making it perfect for homes that do not even have a chimney! The Studio 3 Open Fronted produces a heat output of up to 3.40kW.

Studio 22

New to the Studio fires range this year are four portrait Studio 22 models which add vertical definition and instant presence. Available with a new highly realistic Log fuel bed and balanced flue installation, the Glass Fronted Studio 22 produces up to 5.85kW of heat output offering great efficiency as well as style.

Heat output and efficiency figures are based upon the maximum heat output achieved in the options available for each model, for complete technical information; please refer to the tec hnical section at the rear of this brochure.

Studio Sizes

According to model, the outstanding Studio fires range is available in up to four different sizes, offering greater installation possibilities to interiors of all proportions. With three landscape sizes and the latest portrait option, the beautifully designed Studio fires are the perfect blend of versatility and style.

Studio 22 Bauhaus in Graphite, Glass-Fronted with Log fuel bed

Page 7

Studio Edge

Studio 3 Edge, Open Fronted with White Stone fuel bed

The very latest in ﬁres design. It is hard not to warm to the outstanding

modern appeal of the Studio ﬁres. Specially designed for contemporary living,

this stunning, ‘hole in the wall’ ﬁre creates a visual delight in any living space.

It’s central feature is a modulating single ribbon of living ﬂame that dances

above a bed of white stones or, newly available for the Glass Fronted Studio

1 and 2 models, through a realistic log effect display which boasts increased

efﬁciency due to a special heat-retaining lining. Extra reﬂection is provided for

the white stone option by the sparkling stainless steel front plate, giving the

overall effect of cosy winter warmth with unbeatable ﬂair.

The Studio Edge is for those who require minimalist modern perfection. The ﬁre

has an eye-catching no-frame* design, with the option on the Open Fronted

Studio ﬁres of a polished black g ranite interior lining. The mirror-like qualities of

this lining reﬂect the continuous motion of the ﬂames still further. Glass Fronted

versions, that incorporate the white stone fuel bed, have enamelled linings as

standard, to enhance the beautiful ﬂame picture.

Studio 2 Edge, Open Fronted**

with White Stone fuel bed

Command Controls

Sequential remote

Chimney Options

†

1 2

Fuel Bed

White Stones Logs (Glass Fronted 1 & 2 only)

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 1 – Glass Fronted 70% 4.85kW   

Studio 1 – Glass Fronted 81% 5.20kW    Balanced Flue

Studio 2 – Open 25% 2.30kW   

Studio 2 – Glass Fronted 78% 6.85kW   

Studio 2 – Glass Fronted 81% 6.97kW    Balanced Flue

Studio 3 – Open 25% 3.40kW   

Studio 3 – Glass Fronted 81% 7.30kW    Balanced Flue

Studio 22 Edge available, please see pages 20-21.

* No-frame refers to added exterior fr ames, Glass Fronted Studios have an additional 27mm inner frame that secures the glass window in place. ** For detailed information on installing televisions above Open Studio Fires, please see page

123. For Glass Fronted Studio Edge installation requirements, please see page 127. † Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, inc luding flue gather requirements, please see pages 123-127.

X X X

Page 8

aus

)

tudio 1 Bauhaus, Open Fronted

ces

  

30kW

  

ced Flue



  

Studio 2 Bauhaus Conventional Flue, Glass Fronted in Polished Stainless with Log fuel bed

n Anthracite finish with White Stone fuel bed

io Bauh

as the other Studio ﬁres, whilst individually boasting a classic 3

the Bauhaus to whatever the size and style of your room perfectly.

Furthermore, every Studio ﬁre comes complete with Gazco’s very

rom ignition to heat output without moving from your seat.

Anthraci

uel Be

White Stone

ogs (Glass Fronted 1 & 2 only

ommand Controls

equential remot

Fire Choi

Studio 1 – Open 25%72

Balanced Flu

tudio 2 – Ope

tudio 2 – Glass Fronted

tudio 3 – Open 25%.40k

alanced Flu

ncluding flue gather requirements, please see pages 123-126

81%5.20kW

5%2.

78%.85k

1%.97k

1%7.30kW

.85kW

Chimney Options

1 2

Page 9

Studio Profil

The Studio Proﬁl features ultra contemporary styling that ﬁts in

perfectly with all modern interiors. Furthermore, the Studio Proﬁl

offers you two stunning frame choices and is available on all sizes

and fuel types of Studio ﬁres. For the Glass Fronted Studio 1 and

2 ﬁres there is the added option to have the new realistic log fuel

bed, boasting increased heating efﬁciency due to it’s heat-retaining

lining*. All this, and the Studio standard features such as

Sequential remote control.

Colour Choices

Anthracite Polished Stainless

Fuel Bed

White Stones Logs (Glass Fronted 1 & 2 only)

Command Controls

Sequential remote

* Heat-retaining lining for log fuel bed only. ** For detailed information on installing televisions above Open Studio Fires, please see page 123. † Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, inc luding flue gather requirements, please see pages 123-126.

Studio 1 Profil, Open Fronted** in Polished Stainless with White Stone fuel bed

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 1 – Glass Fronted 70% 4.85kW   

Studio 1 – Glass Fronted 81% 5.20kW    Balanced Flue

Studio 2 – Open 25% 2.30kW   

Studio 2 – Glass Fronted 78% 6.85kW   

Studio 2 – Glass Fronted 81% 6.97kW    Balanced Flue

Studio 3 – Open 25% 3.40kW   

Studio 3 – Glass Fronted 81% 7.30kW    Balanced Flue

Studio 22 Profil available, please see pages 20-21.

Chimney Options

1 2

X X X

†

Studio 2 Profil, Glass Fronted in Anthracite with White Stone fuel bed

Page 10

Studio 2 Steel, Glass Fronted

Studio 2 Steel, Glass Fronted in Graphite with Log fuel bed

in Bronze with Log fuel bed

Studio Steel

The Studio Steel is for those with large spaces who

wish to create a greater presence with their choice of

ﬁreplace. The Studio Steel’s wide frame instantly creates

a distinctive and individual focal point that can be further

heightened by your choice of frame size and colour.

Operation is simplicity itself too, as Gazco’s Sequential

remote control takes care of everything from ignition to

ﬂame height adjustment.

Studio 1 Steel, Open Fronted

in Iridium with White Stone fuel bed

Colour Choice

Bronze Graphite Iridium

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 1 – Glass Fronted 70% 4.85kW   

Studio 1 – Glass Fronted 81% 5.20kW    Balanced Flue

Studio 2 – Open 25% 2.30kW   

Studio 2 – Glass Fronted 78% 6.85kW   

Studio 2 – Glass Fronted 81% 6.97kW    Balanced Flue

Studio 3 – Open 25% 3.40kW   

Studio 3 – Glass Fronted 81% 7.30kW    Balanced Flue

Studio 22 Steel available, please see pages 20-21.

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, including flue gather requir ements, please see pages 123-126.

Fuel Bed

White Stones Logs (Glass Fronted 1 & 2 only)

Command Controls

Sequential remote

Chimney Options

†

X X X

1 2

Page 11

Studio 22 Steel in Graphite

Studio 22 Bauhaus in Polished Stainless

Studio 22

The stunning Glass Fronted Studio 22 is the latest addition to

the successful Studio ﬁres range, offering yet another approach

to ultra contemporary styling. Speciﬁcally designed to add

vertical deﬁnition, this portrait ﬁre will instantly become a focal

point in any modern interior.

All Studio 22 ﬁres feature our new log effect fuel bed which

incorporates a special heat-retaining lining, adding to the ﬁres

performance and energy efﬁciency. It incorporates Studio

features such as Sequential remote control, allowing you to

operate everything from ignition to heat output at just the

push of a button, and ﬂat Touch Control panel which can be

discreetly located up to 2500mm away from the ﬁre.

With four model choices available from the ‘hole in the wall’

Edge, with it’s no-frame design*, to the visually impacting Steel,

Bauhaus and Proﬁl options, the Studio 22 offers many style

choices to greatly expand your interior possibilities.

Studio 22 Profil in Anthracite

Colour Choice

Anthracite (Studio 22 Bauhaus & Profil) Polished Stainless (Studio 22 Bauhaus & Profil) Bronze (Studio 22 Steel) Graphite (Studio 22 Steel) Iridium (Studio 22 Steel)

Fire Choices

Studio 22 – Glass Fronted 78% 5.85kW    Balanced Flue

* No-frame refers to added exterior fr ames. All Studio 22 fires have a visible 27mm inner frame that secures the glass window in place. † Efficiency figures given are based upon the maximum heat output achieved in the options available for this model, for complete technical information, please see pages 123-126.

Fuel Bed

Log

Command Controls

Sequential remote

Chimney Options

†

Page 12

Studio 1 Kepler, Open

Studio 2 Andes, Open with White Stone fuel bed

with White Stone fuel bed

Studio Andes, Inca, Geilo & Kepler

The Studio Andes, Inca, Geilo and Kepler offer a beautiful

natural design statement. Available only with the Open

Fronted 1 and 2 Studios, these eye-catching solid timber

wooden frames cannot help but impress as they surround

a real gas ﬁre with a choice of Walnut and Oak*. Perfectly

crafted to ﬁt in with the latest wood designs these

innovative ﬁres perfectly complement many of the current

popular interior design concepts. This years latest addition,

the new Geilo in natural Oak, now brings a lighter wood

choice to this family of natural frames.

Studio 2 Inca, Open with White Stone fuel bed

Studio 2 Geilo, Open

with White Stone fuel bed

Wood Choice

Andes - Walnut centre with stained Oak edges* Inca - Walnut quarters* Geilo - Solid Oak* Kepler - Solid Walnut*

* Wood is a natural material. There will be variations in shading and,

occasionally, knots in the timbers used.

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 2 – Open 25% 2.30kW   

For detailed information on installing televisions above Open Studio Fires, please see page 123. † Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, including flue gather requir ements, please see pages 123-126.

Fuel Bed

White Stones

Command Controls

Sequential remote

Chimney Options

†

1 2

Page 13

Studio Sienna

The very latest in the Studio family, the Studio Sienna

offers another natural option when choosing your perfect

ﬁre. Precision cut from solid Travertine*, this beautiful

stone frame brings a timeless elegance to the Studio

ﬁre, that will be equally at home in both contemporary or

traditional interiors.

Available in a choice of two sizes of Open Fronted

Studio with a modulating ribbon of living ﬂame, reﬂective

stainless front plate and optional polished black granite

interior. Simply operated by the innovative Sequential

remote, you can now sit back, relax and control everything

at just the touch of a button.

Style has never been so effortless!

Stone Choice

Travertine*

Fuel Bed

White Stones

Command Controls

Sequential remote

* Stone is a natural material and therefore each fir e will have unique

variations in the shading and patterning that occur in the stone used.

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 2 – Open 25% 2.30kW   

Chimney Options

1 2

†

Studio 1 Sienna, Open with White Stone fuel bed

Studio 2 Sienna, Open detail

Studio 2 Sienna, Open with White Stone fuel bed

Page 14

Studio 1 Firenza, Open with

Studio 2 Firenza, Open with White Stone fuel bed

White Stone fuel bed

Studio Firenza

Also new to the Studio range, and available on two sizes

of Open Fronted Studio, the Studio Firenza is designed

for maximum visual impact in your living space. The dark

natural Granite* adds a solid quality whilst beautifully

contrasting with the ﬂuid motion of the ﬂickering ribbon

ﬂames.

Within the ﬁre, the white stone fuel bed entices the eye

whilst the stainless front plate and optional polished

black granite interior reﬂects and intensiﬁes the perpetual

motion of the ﬂames.

For a ﬁre that leaves a lasting impression, look no further

than the Studio Firenza!

Studio 2 Firenza, Open detail

Stone Choice

Granite*

* Stone is a natural material and therefore each fir e will have unique

variations in the shading and patterning that occur in the stone used.

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 2 – Open 25% 2.30kW   

For detailed information on installing televisions above Open Studio Fires, please see page 123 † Efficiency figures given are based upon the maximum heat output achieved in the options available for this model, for complete technical information, including flue gather r equirements, please see pages 123-126.

Fuel Bed

White Stones

Command Controls

Sequential remote

Chimney Options

†

1 2

Page 15

Studio 2 Pienza, Open with White Stone fuel bed

Studio 1 Pienza, Open detail

Studio Pienza

The beautiful Studio Pienza, new to the Studio collection,

blends the subtle textures and delicate tones of natural

stone* with the very latest in ﬁreplace design. Precision

cut from a single piece of Limestone*, the reﬁned Pienza

takes no shortcuts in the pursuit for design perfection.

From the visually stunning ribbon of living ﬂames to

the Sequential remote control, the Studio Pienza comes

with all the features of the Open Fronted Studio's, being

available in two sizes enabling you to bring a sense of

opulence to interiors of all proportions.

Stone Choice

Limestone*

Fuel Bed

White Stones

Command Controls

Sequential remote

* Stone is a natural material and therefore each fir e will have unique

variations in the shading and patterning that occur in the stone used.

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 2 – Open 25% 2.30kW   

Chimney Options

1 2

†

For detailed information on installing televisions above Open Studio Fires, please see page 123. † Efficiency figures given are based upon the maximum heat output achieved in the options available for this model, for complete technical information, including flue gather r equirements, please see pages 123-126.

Studio 1 Pienza, Open with White Stone fuel bed

Page 16

Studio Link

Studio 1 Link, Open with White Stone fuel bed

The Studio Link is for those prepared to make a bold

statement. Showing the same excellent features as the rest

of the Studio family, from Sequential remote control to the

stunning ribbon of living ﬂame, the Link stands apart with

its distinctive frame. This bold new design made of polished

stainless steel/opaque black, cannot help but become a

talking point.

Studio 1 Link, Open detail

Colour Choice

Black with Stainless inserts

Fuel Bed

White Stones

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 2 – Open 25% 2.30kW   

For detailed information on installing televisions above Open Studio Fires, please see page 123. † Efficiency figures given are based upon the maximum heat output achieved in the options available for this model, for complete technical information, including flue gather r equirements, please see pages 123-126.

Community Design Registration No.000568043

Command Controls

Sequential remote

†

Chimney Options

1 2

Page 17

Studio Icon

Studio 1 Icon, Glass Fronted Balanced Flue with Log fuel bed

The Studio Icon is a dramatic ﬁre for a dramatic effect!

Cleverly designed to not only create a strong focal point for a

room, but to also offer easier installation possibilities.

The Icon is available in two distinctive versions: the Studio

Open with ultra slim proﬁle and White Stone base or a balanced

ﬂue, Glass Fronted version which has the added option of the

new realistic log display, the latter boasts greatly increased

efﬁciency due to design-integrated heat convection technology

and a special heat-retaining lining.

Strikingly crafted from 3mm steel and ﬁnished in Graphite, the

Studio Icon is the contemporary classic of the future.

Studio 1 Icon, Open Fronted with

White Stone fuel bed

Studio 1 Icon, Open Fronted with

White Stone fuel bed

Colour Choice

Graphite

Fuel Bed

White Stones Log (Glass Fronted)

Fire Choices

Studio 1 – Open 25% 1.72kW   

Studio 1 – Glass Fronted 81% 5.20kW  Balanced Flue

X X

Command Controls

Sequential remote

†

Chimney Options

1 2

Page 18

Complete Fires

E-Studio

Very high efficiency 16” wide fires that are set behind a virtually invisible glass window. E-Studio™ fires successfully combine the latest in fire technology with the distinctive white stone ribbon flame effect of the Studio range at the front of this brochure. E-Studio™ fires are also available as a fire choice for many of our designs in the later Mix-and-Matc h section of this brochure.

E-Box

This top-of-the-range 16” wide fire is very similar to the E-Studio™ above, with high efficiency and much improved fuel economy. Set behind a virtually invisible glass window, it offers a choice of coal or pebble effect fuel beds. E-Box™ fires are also available as a fire choice for many of our designs in the later Mix-and-Matc h section of this brochure.

Linea

For a truly unique visual effect, look no further than the inspirational Glass Fronted Linea fire. This thoroughly modern approach to fire design offers a dramatic chorus of vertical flames, strikingly offset against a pure black background. With a selection of style choices and stunning finishes, the contemporary Linea will become an instant focal point in your room and because all Linea fires have balanced flue operation, you don’t even require a chimney!

Riva

The stylish Riva is one of the most versatile fires across the Gazco range with its benefits also expanding into a range of stoves available from our Gazco Stoves brochure. According to model, there is a selection of three landscape and portrait sizes, two stunning fuel bed options and a wealth of frame styles. Additional versatility is afforded by the options for both hearth mounting or ‘hole in the wall’ installations for selected models as well as six outstanding electric fire designs (please see pages 62-63). The Riva’s extremely efficient convection system produces up to 5.3kW of controllable heat, making it a welcoming and functional visual centrepiece in your home.

E-Studio™

(Also available in the Mix-and-Match section)

E-Box™

(Also available in the Mix-and-Match section)

Linea

Riva

Remote Controls

All gas Riva, E-Box™ and E-Studio™ fires come with manual operation and the option to upgrade to a Standard remote control (allowing you to control both the flame height and heat output) or the Programmable remote, (with additional thermostatic and timer controls). Linea fires come complete with a state-of-the-art programmable Sequential remote as standard (allowing remote operation of ever ything from ignition to extinguish, also with the benefits of programmable timer and thermostatic controls).

Standard

(Upgradable)

Programmable

(Upgradable)

Sequential

(supplied with Linea)

Electric Riva Remote

(supplied with fire)

In addition to the extensive Studio range, we have many other fires that are also a ‘complete package’, as the fire and frame choices are perfectly designed to complement each other.

Riva Spectrum 67

Page 19

Fusion

This latest addition to the Gazco fires range, is an

outstanding combination of smooth, sparkling glass

with striking Graphite or Iridium finished steel. The ultra

contemporary styling comes with a choice of Gazco’s

most energy efficient fires, the E-Studio™ with it’s

mesmerising white stones and ribbon flames, or for a

more traditional look, the E-Box™ with a choice of coal

or pebble effect fuel beds

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 132-133. ** Please refer to television manufacturer s guide for recommendations on installing a television near heating appliances.

Fusion E-Box™ in Iridium with Coal fuel bed

Fusion E-Box™ in Graphite with Pebble fuel bed

Colour Choice

Graphite Iridium

Fuel Bed

E-Studio™ white stones Coals Pebbles

Command Controls

Manual Standard upgradable Programmable remote

Fire Choices

E-Box™ 76% 3.80kW    

E-Box™ Balanced Flue 86% 3.52kW 

E-Studio™ 72% 3.10kW    

E-Studio™ Balanced Flue 82% 3.52kW 

Chimney Options

1 2 3

E%kW

†

X X X X

Fusion E-Studio™** in Graphite

Page 20

Futura E-Box™ with Pebble fuel bed

Futura E-Studio™

Futura

At the cutting edge of modern design, the strong lines,

slim profile and smooth surface of the new Futura mark

out its innovative styling. The highly reflective 5mm

black glass finish is immediately impressive yet not

overpowering in smaller spaces and by incorporating

your choice of the E-Studio™ or E-box™ fire, the Futura

offers the perfect combination of ‘design statement’ and

functional efficiency.

Sharp, sleek and sophisticated!

Futura E-Box™ with Coal fuel bed

Colour Choice

Black Glass

Fuel Bed

E-Studio™ white stones Coals Pebbles

Fire Choices

E-Box™ 76% 3.80kW    

E-Box™ Balanced Flue 86% 3.52kW 

E-Studio™ 72% 3.10kW    

E-Studio™ Balanced Flue 82% 3.52kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 132-133.

X X X X

E%kW

Command Controls

Manual Standard upgradable Programmable remote

Chimney Options

†

1 2 3

Page 21

E-Studio™ Steel

E-Studio™ Steel in Graphite

The E-studio™ Steel with its visually impressive Graphite or

Iridium ﬁnished frame and ultra efﬁcient ﬁre is the perfect

blend of style and functionality. Gazco’s advanced technology

E-Studio™ ﬁre produces up to 3.52kW of heat output,

features a white stone fuel bed and beautiful enamelled lining

which reﬂects the continuous motion of the ﬂames.

E-Studio™ Steel in Graphite detail

E-Studio™ Steel in Iridium

Colour Choice

Graphite Iridium

Fuel Bed

E-Studio™ white stones

Fire Choices

E-Studio™ 72% 3.10kW    

E-Studio™ Balanced Flue 82% 3.52kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 132-133.

X X

Command Controls

Manual Standard upgradable Programmable remote

E%kW

†

Chimney Options

1 2 3

Page 22

Stockton Inset E-Box™

Stockton Inset

Combining the looks of a traditional stove with the latest high

efficiency heating, the new Stockton Inset fires have it all.

Featuring the latest E-Box™ technology you can now enjoy up

to 86% efficiency and a superb coal effect fire with the option

of standard or programmable remote controls.

Stockton Inset E-Box™

Colour Choice

Black Cast Iron

Fuel Bed

Coals

Fire Choices

E-Box™ 76% 3.80kW 

E-Box™ Balanced Flue 86% 3.52kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 132-133.

Command Controls

Manual Standard upgradable Programmable remote

X X

†

Chimney Options

1 2 3

Page 23

Linea Steel

Inspirational! What other description can there be for

Gazco’s impressive Linea Steel?

With it’s thoroughly modern lines and exceptionally slim

profile, this steel and glass-fronted fire complements the

most contemporary of interiors, plus there’s up-to-the-

minute technology to match. Furthermore, not only is the

Linea Steel a highly efficient fire but also complete

operation of all functions is via Gazco’s programmable

Sequential remote control.

Colour Choice

Graphite Iridium

Command Controls

Sequential remote

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see page 128.

Linea Steel in Iridium

Fire Choices

Linea Steel Balanced Flue 82% 4.30kW 

Chimney Options

1 2

E%kW

†

Linea Steel in Graphite

Page 24

Linea Designio

Linea Designio in Iridium

There are some things in life with an allure that is

immediate and obvious. With its incredibly slimline frame

and unique visual effect the Linea Designio is one such

object. In fact, it's just like having a 'live action' work of

modern art on your wall, with a choreography of blue,

yellow and orange flames against a background of

pure black.

Operation is simplicity itself too. Gazco's Sequential remote

control takes care of everything from ignition to the

thermostatic regulation of heat output.

Linea Designio in Graphite

Colour Choice

Graphite Iridium

Fire Choices

Linea Designio Balanced Flue 82% 4.30kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see page 128.

Command Controls

Sequential remote

E%kW

Chimney Options

†

1 2

Page 25

Linea Vetro

The ultra-contemporary Linea Vetro is one of the sleekest

fires in the world and one that is at the leading edge of

heating efficiency. The flame effect is unique too, offering an

almost graphic display of moving colour that both fascinates

and delights, while the very latest Sequential remote control

operates everything from ignition to heat output.

Make your design statement with the outstanding Linea and

let the smooth simplicity of sparkling glass create a stylish

effect in your contemporary living room.

Colour Choice

Black glass White glass

Command Controls

Sequential remote

Linea Vetro with White glass

Fire Choices

Linea Vetro Balanced Flue 82% 4.30kW 

Chimney Options

1 2

E%kW

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see page 128.

Linea Vetro with Black glass

Page 26

Riva Avanti

Riva 67 Avanti Horizontal Curve

First in the glass-fronted Riva range is the stylish Avanti,

a superbly efficient convector that is available in three

distinctive formats - 53, 67 and 70. The portrait-shaped

53 features a driftwood log effect fire whilst the 67 and 70

are landscape and complete with authentic log effect fires.

All have the built-in comfort of adjustable heat and flames

to exactly suit your mood.

Riva 53 Avanti Vertical Curve

Riva 70 Avanti Horizontal Curve

Each model comes complete with a brushed stainless

steel front. Whichever your preference, you can be sure the

Avanti will provide a striking focal point at the very heart of

your home.

Colour Choice

Stainless/Black

Frame Styles

Vertical Curve (53) Horizontal Curve (67) Horizontal Curve (70)

Fire Choices

Riva 53 72% 4.90kW 

Riva 53 Balanced Flue 78% 5.30kW 

Riva 67 72% 4.90kW 

Riva 67 Balanced Flue 75% 4.60kW 

Riva 70 Balanced Flue 84% 6.50kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 128-129.

X X X X X

Fuel Bed

Driftwood Logs (53) Logs (67 & 70)

Command Controls

Manual Standard upgradable Programmable remote

Chimney Options

†

1 2

Page 27

Riva Designio

Riva 67 Designio in Iridium

A design statement in its own right, the glass-fronted

Designio has the style to appeal across the widest range

of contemporar y interiors - and a performance to match.

The magnificent gas fires (driftwood logs for the 53

and logs for the 67) are teamed with an exceptionally

efficient convection system that produces up to 5.3kW of

controllable heat.

Choose one of Gazco's optional Command remote controls

and adjustment is easier still!

Riva 53 Designio in Graphite

Colour Choice

Graphite Iridium

Fuel Bed

Driftwood Logs (53) Logs (67)

Fire Choices

Riva 53 72% 4.90kW 

Riva 53 Balanced Flue 78% 5.30kW 

Riva 67 72% 4.90kW 

Riva 67 Balanced Flue 75% 4.60kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages128-129.

Command Controls

Manual Standard upgradable Programmable remote

X X X X

†

Chimney Options

1 2

Page 28

Riva 53 Profil 2 in Iridium

Riva Profil 2

Whether part of a standard fireplace or as a hole-in-the-

wall installation, the three stylish Riva Profil 2 models all

feature the glow and flames of a highly realistic gas log

fire. This provides not only a remarkable focal point for

your room but an effective heating appliance as well. To

maximise your décor options, the Profil 2 frame is available

in two outstanding finishes, Graphite or Iridium.

Colour Choice

Graphite Iridium

Fuel Bed

Driftwood Logs (53) Logs (67 & 70)

Command Controls

Manual Standard upgradable Programmable remote

Fire Choices

Riva 53 72% 4.90kW 

Riva 53 Balanced Flue 78% 5.30kW 

Riva 67 72% 4.90kW 

Riva 67 Balanced Flue 75% 4.60kW 

Riva 70 Balanced Flue 84% 6.50kW 

Chimney Options

1 2

X X X X X

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 128-129.

†

Riva 67 Profil 2 in Graphite

Page 29

Riva Spectrum

Riva 67 Spectrum

The all new Riva Spectrum combines a bold new frame

design with the superb heating efficiency that the glass

fronted Riva range can offer.

Available in landscape 67 and 70 sizes, complete with

realistic log effect fires, or in the portrait 53 size that

features an authentic driftwood log fire. Whatever your

choice, the Spectrum's stylish black frame with polished

steel highlights will be sure to impress.

Riva 53 Spectrum

Riva 70 Spectrum

Colour Choice

Black with Stainless inserts

Fuel Bed

Driftwood Logs (53) Logs (67 & 70)

Fire Choices

Riva 53 72% 4.90kW  

Riva 53 Balanced Flue 78% 5.30kW 

Riva 67 72% 4.90kW  

Riva 67 Balanced Flue 75% 4.60kW 

Riva 70 Balanced Flue 84% 6.50kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 128-129.

Command Controls

Manual Standard upgradable Programmable remote

X X X X X

†

Chimney Options

1 2

Page 30

Riva Esprit

Designed to blend perfectly into today's modern interiors,

the new version of the Riva 67 Esprit creates not only an

impressive focal point at the heart of any contemporar y

space but also power to heat it.

Colour Choice

Graphite Iridium

Fuel Bed

Logs

Command Controls

Manual Standard upgradable Programmable remote

Fire Choices

Riva 67 72% 4.90kW  

Riva 67 Balanced Flue 75% 4.60kW  

Chimney Options

Riva 67 Esprit in Graphite

Riva 67 Esprit in Iridium

1 2

X X

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 128-129.

†

Riva 67 Esprit in Iridium

Page 31

Riva Vetro

Style abounds in the shape of the new Riva Vetro. Its

'widescreen' appearance and realistic log effect fire provide

the ultimate centrepiece for your living space. Furthermore,

with the Riva Vetro you have the option of upgrading to

one of Gazco's very latest Command remote controls,

allowing easy operation of ever ything including heat and

flame adjustment and even timer and thermostatic functions

with the Programmable option.

Colour Choice

Black glass

Fuel Bed

Logs

Fire Choices

Riva 67 72% 4.90kW 

Riva 67 Balanced Flue 75% 4.60kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 128-129.

Command Controls

Manual Standard upgradable Programmable remote

X X

†

Chimney Options

1 2

Page 32

Electric Riva

Electric Riva Avanti

Electric Riva Designio

Electric Riva Esprit

Electric Riva View

The Riva 67 is also available as an electric fire. You simply slot

it into a pre-constructed opening (in a wall, fireplace or wooden

surround), plug in and switch on for that 'real fire' look and

authentic atmosphere. Alternatively, you can mount the Electric

Riva on the wall with an optional wall mounting fixing kit.

The Arlington model is for hearth mounting only.

The impressive electric log-effect fire provides flickering flames

and a warming glow at the touch of a button on the remote

control. There's instant heat too, as the heater can be operated

with either 1kW or 2kW of output. Or, if you wish, you can just

enjoy the flames without any heat.

Choose from Arlington, Avanti, Designio, Esprit and Vetro

versions, or the slimline View version which is only 142mm deep

when mounted onto the wall or just 35mm when recessed .

Fuel Bed

Logs

Fire Choices

Electric Riva 67 99% 2.00kW 

Command Controls

Remote

Chimney

E%kW

Option

Electric Riva Arlington

For complete model choices, dimensions and additional information please see pages 128-129.

Page 33

Gas F67 Riva Stoves

Gas F67 Riva

For those who like to combine all the benefits of a Riva

with the look of a stove, Gazco’s F67 Riva range is the

answer for you. Available hearth-mounted or mounted on a

“Bench” or “Pedestal”, the F67 offers an incredibly stylish

solution. For more details please see our Gazco Stoves

brochure or go on-line to www.gazco.com and visit the

Stoves section.

Gas F67 Riva Bench

Gas F67 Riva Pedestal

Colour Choice

Black with stainless inserts

Fuel Bed

Logs

Fire Choices

Riva 67 72% 4.90kW 

Riva 67 Balanced Flue 75% 4.60kW 

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please refer to the Gazco Stoves brochur e.

Command Controls

Manual Standard upgradable Programmable remote

X X

†

Chimney Options

1 2

Page 34

Mix & Match Fires

We therefore suggest that you view the features for each of our fire choices below and choose an option that is most suited to your home, then browse through and decide on a design that suits the style of your interior. There is a handy table at the bottom of each page that clearly shows the fire choices and chimney options available for that particular frame.

VFC

Available in 16”, 18” and 22” widths and standard or low lintel heights, the VFC Convector is our most versatile fire. It is suitable for brick chimneys only but offers the additional benefits of a slightly deeper fuel bed and unique VFC (variable flame control) system, which allows you to select the exact balance of flame, glow and heat to suit your mood.

Radiant

These fires are for those who want all the visuals of a Gazco fire, but do not require the additional heat of a convector or do not wish to refurbish an existing open fireplace, whether conventional ‘chairbrick’ opening for a VFC Tapered fire or traditional cast iron fireplace. Tapered fires are available in 16", 18" and 22' widths and can generally be fitted into existing openings without further building work.

Please use the fold out key attached to the back cover of this broc hure to help remind you of each fire’s features whilst browsing. If you need further information on any fire, this can be found in the technical section on pages 122-138.

Remote Controls

Gazco was the first UK company to introduce remote controls for gas

fires. Today, our Command remote control systems allow most fires to be

upgraded to remote control. Simply use the fold out key at the back of this

brochure to choose which remote control is most suitable for your needs.

Standard

(Upgradable)

Programmable

(Upgradable)

Logic IPF

Logic

Logic Fires are available in 16” widths and are the easiest of all our fires to install, giving you excellent value for money through reduced installation costs. The Logic fires are available in Hotbox, Convector and IPF Convector versions and are all “Reduced Draught" fires, meaning that in all cases a wall or floor vent is not required. For a more detailed description of Hotbox, Convector and IPF fires please see pages 120-121.

E-Box

This top-of-the-range 16” wide fire provides exceptional heating efficiency and much improved fuel economy. Set behind a virtually invisible glass window, Gazco’s technology has created a fire that offers considerably lower running costs through increased efficiency (ie. gas consumption is lower so saving you money). Available in conventional and Balanced flue options.

E-Studio

Very high efficiency 16” wide fires that are set behind a virtually invisible glass window. E-Studio™ fires successfully combine the technology of E-Box™ fires with the distinctive White Stone ribbon flame effect of the Studio fires at the start of this broc hure.

Available in conventional and

Balanced flue options.

To further expand your possibilities, this next section of the brochure features a host of frame designs which can be matched with a number of technically different fire choices, allowing you to get not only the perfect look but the most suitable fire for your home.

Page 35

22" Designio VFC Convector in Iridium,

16" Designio E-Studio™ in Graphite

shown in Stovax made-to-measure Malmo mantel

Designio

With its smart finish and crisp clean lines, the Designio

not only exudes contemporary style but is also available in

versions to suit most homes - even those without

a chimney.

All you have to do is decide on the size, colour, whether

you would like a coal, pebble or white stone fire effect and

if the option of a remote control appeals.

16" Designio Logic Convector in Iridium,

shown in Stovax Copenhagen mantel

Colour Choice

Graphite Iridium

Fuel Bed

E-Studio™ white stones Coals

Pebbles

Fire Choices

Logic Hotbox 48% 3.20kW     

Logic Convector 61% 4.10kW 

E-Box™ 76% 3.80kW 

E-Box™ Balanced Flue 86% 3.52kW 

E-Studio™ 72% 3.10kW 

E-Studio™ Balanced Flue 82% 3.52kW 

VFC Convector* 50% 4.75kW** 

Logic IPF 62% 3.80kW 

VFC + powered flue kit 50% 4.75kW* 

* 16" RD model also available, requires no air vent ** Heat output for 16” models, for 22” model see pages 134-135

Not IPF or VFC

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Command Controls

Manual Standard upgradable Programmable remote (E-Box™ & E-Studio™) Logic IPF remote

X X X X X X

†

Chimney Options

1 2PF3

BF PF

Page 36

Dimension

Dimension Logic Hotbox with Coal fuel bed, shown in Stovax Copenhagen mantel with cherry insert

Classically stylish with a modern edge, the Dimension

could just as easily blend into traditional or contemporary

interiors. Key to its appeal is the broad, matt black profile

which frames the fire, continually drawing your eye to

the dancing flames above glowing coals, pebbles or

white stones.

There are versions of the Dimension to suit all types of

chimney, including the latest high efficiency E-Box™ and

E-Studio™. Your Gazco retailer will be happy to advise

which is precisely right for you.

Dimension E-Box™ with Pebble fuel bed

Colour Choice

Matt Black

Fuel Bed

E-Studio™ white stones Coals

Pebbles

Fire Choices

Logic Hotbox 48% 3.20kW     

Logic Convector 61% 4.10kW     

E-Box™ 76% 3.80kW     

E-Box™ Balanced Flue 86% 3.52kW     

E-Studio™ 72% 3.10kW     

E-Studio™ Balanced Flue 82% 3.52kW     

Logic IPF 62% 3.80kW     

Not IPF

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Command Controls

Manual Standard upgradable Programmable remote (E-Box™ & E-Studio™) Logic IPF remote

X X X X X X X

Chimney Options

†

1 2 3

BF PF

Page 37

Evolution

Evolution is a living flame gas fire that is in perfect harmony

with the 21st Century - right down to the remote control. In

a Brushed Stainless Steel finish you can select either coal,

pebble or white stone fuel bed.

There are also versions to suit all types of chimne y or,

indeed, no chimney at all. If you are looking for a 16” wide

fire, your choice even includes the latest, high efficiency

E-Box™ & E-Studio™ variants. So please ask your Gazco

retailer to help you decide which Evolution model is exactly

right for your home.

Evolution E-Studio™, shown in Stovax Small Art Deco mantel

Colour Choice

Brushed Stainless Steel

Fuel Bed

E-Studio™ white stones Coals Pebbles

Command Controls

Manual Standard upgradable Programmable remote (E-Box™ & E-Studio™) Logic IPF remote

Fire Choices

Logic Hotbox 48% 3.20kW     

Logic Convector 61% 4.10kW  

E-Box™ 76% 3.80kW   

E-Box™ Balanced Flue 86% 3.52kW  

E-Studio™ 72% 3.10kW  

E-Studio™ Balanced Flue 82% 3.52kW 

VFC Convector* 50% 4.75kW**  

Logic IPF 61% 3.80kW 

VFC + powered flue kit 50% 4.75kW*  

* 16" RD model also available, requires no air vent ** Heat output for 16” models, for 22” model see pages 134-135

Not IPF or VFC

Chimney Options

1 2PF3

BF PF

X X X X

X X

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Evolution Logic Hotbox with Pebble fuel bed

Page 38

Infiniti

Distinctively designed for the most modern of interiors, the

Infiniti's unique style provides an almost 'wide screen' look.

If your home has a c himney then, according to type, the

Infiniti is available in VFC (variable flame control) Convector,

Logic Hotbox, Logic Convector and E-Box™ versions. For

non-chimney homes, you can select from VFC Convector

with powered flue, Logic IPF (integral powered flue) and

balanced flue E-Box™ versions. Whichever you choose, you'll

be able to create the effect you want.

Colour Choice

Brushed Stainless Steel & Black

Fuel Bed

Coals Pebbles

Command Controls

Manual Standard upgradable Programmable remote (E-Box™) Logic IPF remote

Infiniti VFC Convector

Fire Choices

Logic Hotbox 48% 3.20kW  

Logic Convector 61% 4.10kW  

E-Box™ 76% 3.80kW  

E-Box™ Balanced Flue 86% 3.52kW  

VFC Convector* 50% 4.75kW  

Logic IPF 61% 3.80kW 

VFC + powered flue kit 50% 4.75kW 

* 16" RD model also available, requires no air vent

Not IPF or VFC

Chimney Options

1 2 3

BF PF

X X

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

†

Infiniti Logic Hotbox with Pebble fuel bed

Page 39

22" Progress VFC Convector, shown

16" Progress Logic Hotbox with Coal fuel bed, shown in Stovax Art Deco mantel

in Stovax Malmo mantel

16" Progress Logic Convector with Pebble fuel

bed, shown in Stovax Brompton mantel

Progress

Smooth curves and an exquisite Iridium metallic finish

are the hallmarks of the Progress. Available in 16” and

22” widths, there are versions to suit virtually all homes -

even if your room does not have a c himney. Available in

Pebble, Coal or White Stone fuel beds and with a choice of

optional remote controls.

Your Gazco retailer will be pleased to help you achieve

exactly the look that's right for you.

Colour Choice

Iridium

Fuel Bed

E-Studio™ white stones Coals

Pebbles

Fire Choices

Logic Hotbox 48% 3.20kW   

Logic Convector 61% 4.10kW   

E-Box™ 76% 3.80kW   

E-Box™ Balanced Flue 86% 3.52kW  

E-Studio™ 72% 3.10kW   

E-Studio™ Balanced Flue 82% 3.52kW 

VFC Convector* 50% 4.75kW**    

Logic IPF 61% 3.80kW  

VFC + powered flue kit 50% 4.75kW*   

* 16" RD model also available, requires no air vent ** Heat output for 16” models, for 22” model see pages 134-135

Not IPF or VFC

Command Controls

Manual Standard upgradable Programmable remote (E-Box™ & E-Studio™) Logic IPF remote

X X X X X X

†

Chimney Options

1 2 3

BF PF

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Page 40

Electric Stilo, shown in

Stilo Slimline Convector, shown in Stovax Helsinki mantel

Stovax Small Art Deco surround

Stilo

The smooth curves of the Stilo ﬁre appeal to the eye

even when the stunning gas ﬁre is not alive. When

alight the effect is even more appealing, as the Iridium

ﬁnish of the Stilo reﬂects the ﬂames beautifully.

Available in 16” width versions to suit practically all

homes, even those without chimneys; also available in

an electric version that can be ﬁtted in any home, to

easily add ambience.

Colour Choice

Iridium

Fuel Bed

Coals

Fire Choices

Premier Slimline Convector 48% 3.10kW   

Premier Slimline Power 46% 3.10kW  Flue Convector

Premier Electric Inset 99% 2.00kW 

Command Controls

Manual

X X

1 2

Chimney Options

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see page 136.

Page 41

Arts E-Box™ in Matt Black with Coal fuel bed, shown in Stovax made-to-measure Alborg mantel

Arts

At its peak in the 1920s and 1930s, the Arts movement

combined art and technology to bring aesthetic appeal to

virtually any object in daily use. Today, this evocative style is

still influencing contemporary design.

Adhering to the movement's original concept, Gazco's Arts,

with its beautifully curved front, echoes the style of the

era whilst incorporating the very latest gas fire innovations,

including the opportunity to specify the high efficiency

E-Box™ and E-Studio™ options.

Colour Choice

Matt Black Highlight Polished Polished Chrome Polished Brass

Fuel Bed

E-Studio™ white stones Coals Pebbles

Command Controls

Manual Standard upgradable Programmable remote (E-Box™ & E-Studio™) Logic IPF remote

Arts Logic Hotbox in Highlight Polished with Pebble fuel bed, shown in Stovax Small Kensington mantel

Arts Logic Hotbox in Polished Brass with Pebble fuel bed

Fire Choices

Logic Hotbox 48% 3.20kW  

Logic Convector 61% 4.10kW  

E-Box™ 76% 3.80kW  

E-Box™ Balanced Flue 86% 3.52kW  

E-Studio™ 72% 3.10kW  

E-Studio™ Balanced Flue 82% 3.52kW 

VFC Convector* 50% 4.75kW   

Logic IPF 61% 3.80kW 

VFC + powered flue kit 50% 4.75kW 

* 16" RD model also available, requires no air vent

Not IPF or VFC

Chimney Options

1 2 3

BF PF

X X X X

X X

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Arts E-Box™ in Polished Chrome with Coal fuel bed, shown in Stovax Pembroke 36 mantel

Page 42

Arts E-Studio™ in Polished Chrome

Arts VFC Convector in Highlight Polished, shown in Stovax Chelsea cast front and Stovax Malmo mantel

Arts (contd.)

Gazco’s Arts ﬁres perfectly combine the elegance and

style of the 1920s with the tec hnology and innovations

of the 21st Centur y. You can choose to specify the gas

ﬁre that best suits your individual needs, including the high

efﬁciency E-Box™ or E-Studio™. It is also available in the

most popular 16” width, as well as being offered with a

wide choice of fronts and frames.

Arts Logic Hotbox in Highlight Polished

with Pebble fuel bed

Arts Logic Convector in Matt Black

with Pebble fuel bed

Page 43

Richmond

With its elegant design and finely detailed castings, the 16”

Richmond will add period refinement to any fireplace, whilst

still enjoying all the 21st Century benefits, including E-Box™

high efficiency heating and a Command remote control.

Colour Choice

Black Cast Iron

Fuel Bed

Coals Pebbles

Command Controls

Manual Standard upgradable Programmable remote (E-Box™) Logic IPF remote

Richmond VFC Convector

Fire Choices

Logic Convector 61% 4.10kW   

E-Box™ 76% 3.80kW   

E-Box™ Balanced Flue 86% 3.52kW  

VFC Convector* 50% 4.75kW   

Logic IPF 61% 3.80kW  

VFC + powered flue kit 50% 4.75kW  

* 16" RD model also available, requires no air vent

Not IPF or VFC

Chimney Options

1 2 3

BF PF

X X X

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Richmond E-Box™ with Coal fuel bed

Page 44

Holyrood

A masterpiece of traditional design, Gazco's Holyrood allows

you to personalise your new fire to your exact needs. It is

available in three widths, each with four different fronts (polished

brass, polished chrome, matt black or highlight polished) and

with a choice of up to fifteen frame styles/finishes (see pages

102-103), as well as manual or remote controls.

Colour Choice

Matt Black Polished Brass Highlight Polished Polished Chrome

Fuel Bed

Coals Pebbles

Command Controls

Manual Standard upgradable Programable remote (E-Box™) Logic IPF remote

16" Holyrood VFC Convector

with Highlight Polished front and frame

Holyrood Chrome detail

Fire Choices

Logic Hotbox 48% 3.20kW  

Logic Convector 61% 4.10kW  

E-Box™ 76% 3.80kW 

E-Box™ Balanced Flue 86% 3.52kW 

VFC Convector* 50% 4.75kW**   

Logic IPF 61% 3.80kW 

VFC + powered flue kit 50% 4.75kW* 

* 16" RD model also available, requires no air vent ** Heat output for 16” models, for 18" and 22” models see pages 134-135

Not IPF or VFC

Chimney Options

BF PF

X X X X

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

22" Holyrood VFC Convector with Polished Brass front and frame, shown in Stovax Georgian mantel

Page 45

16" Holyrood VFC Convector

16" Holyrood E-Box™ with Matt Black front and frame with Coal fuel bed

with Highlight Polished front and frame

Holyrood (contd.)

Gazco’s Holyrood not only offers you a vast choice of

ﬁnishes and sizes, but also six different ﬁre choices

dependent upon your requirements. Fire versions available

with the Holyrood include: E-Box™, VFC Convector,

Logic Hotbox, Logic Convector, VFC + powered ﬂue and

Logic IPF. So you can now have total control over the

ﬁnish and ﬁre for you!

Page 46

Spanish

Spanish Logic Hotbox with Highlight Polished front and frame with Coal fuel bed, shown in Stovax Small Kensington mantel

Based on a traditional design, the Spanish has remained a firm

favourite with homeowners for almost two decades. Part of

this appeal is Gazco's mix and match system, whereby the four

different fronts and fifteen different frames (see pages 102-103)

can be combined to give the precise look you require.

Spanish Logic Hotbox with Polished Brass front

and frame with Coal fuel bed, shown in Stovax

Small Kensington mantel

Colour Choice

Matt Black Polished Brass Highlight Polished Polished Chrome

Fuel Bed

Coals

Pebbles

Fire Choices

Logic Hotbox 48% 3.20kW  

Logic Convector 61% 4.10kW  

E-Box™ 76% 3.80kW  

E-Box™ Balanced Flue 86% 3.52kW 

VFC Convector* 50% 4.75kW** 

Logic IPF 61% 3.80kW 

VFC + powered flue kit 50% 4.75kW* 

* 16" RD model also available, requires no air vent ** Heat output for 16” models, for 18" and 22” models see pages 134-135

Not IPF or VFC

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

X X X X

Command Controls

Manual Standard upgradable Programable remote (E-Box™) Logic IPF remote

†

Chimney Options

1 2 3

BF PF

Page 47

Spanish Highlight Polished detail

Spanish E-Box™ with Matt Black front and frame with Coal fuel bed

Spanish (contd.)

Gazco's Spanish is available in three different widths and, if

you select the most popular 16" width, there are also Logic

Hotbox, Logic Convector, VFC Convector, VFC + powered ﬂue

and Logic IPF variants as well as the high-efﬁciency E-Box™.

With so much choice, please ask your Gazco retailer to help

you decide on the perfect version for your home.

Spanish Chrome detail

Page 48

Winchester

A masterpiece of casting detail, the Winc hester’s hob grate

styling is equally well suited to both traditional and more

contemporary interiors.

Furthermore, there are versions of the Winchester for all types

of home even if you don’t have a chimney! With a choice of

finishes and fire options including the Logic Hotbox, Logic

Convector and Logic IPF as well as the latest high efficiency

E-Box™ and E-Studio™, there is an elegant and versatile

Winchester that will be perfect for you and your home.

Winchester Logic Hotbox with Coal fuel bed, shown in Stovax Georgian mantel with Polished Belgravia front

Winchester E-Box™ with Coal fuel bed

Colour Choice

Matt black

Fuel Bed

E-Studio™ white stones Coals Pebbles

Command Controls

Manual Standard upgradable Programmable remote (E-Box™ & E-Studio™) Logic IPF remote

Fire Choices

Logic Hotbox 48% 3.20kW     

Logic Convector 61% 4.10kW     

E-Box™ 76% 3.80kW     

E-Box™ Balanced Flue 86% 3.52kW     

E-Studio™ 72% 3.10kW     

E-Studio™ Balanced Flue 86% 3.52kW     

Logic IPF 62% 3.80kW     

Not IPF

Chimney Options

1 2 3

BF PF

X X X X X

X X

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130-135.

Winchester Logic Hotbox with Coal fuel bed, shown in Stovax Pembroke 36 mantel with Belgravia Cast Iron front

Page 49

Cast Iron Convectors

Combination Convector with Urn Design Polished panels

Here is the ultimate marriage between traditional style and

modern technology. By making discreet alterations to three

classic, cast iron Victorian fireplaces (manufactured by our

sister company Stovax), you can now enjoy quintessential

period charm yet also benefit from the added efficiency and

convenience of a Gazco convector gas fire. Complete with

Command remote control if you wish.

Finished in a choice of either black or highlight polished,

each model can be teamed with your selection from a

wide range of tiles and cast panel designs. Please ask your

retailer for full details or visit our website.

Art Nouveau Convector, shown

in Stovax Chatsworth mantel

Victorian Convector, shown

in Stovax Georgian mantel

Fuel Bed

Coals

Fire Choices

Logic Convector 61% 4.10kW 

VFC Convector* 50% 4.75kW    

Logic IPF 61% 3.80kW 

VFC + powered flue kit 50% 4.75kW 

* 16" RD model also available, requires no air vent

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 130, 131 and 135.

Command Controls

Manual Standard upgradable Logic IPF remote

†

Chimney Options

1 2 3

BF PF

Page 50

Poppy & Wheatsheaf Cast Iron Fireplace,

Decorative Arched Insert, shown in Stovax Georgian mantel

shown in Stovax Brompton mantel

Classic Fireplace

If you already own a Classic Fireplace manufactured by Gazco's

sister company Stovax, or are thinking of installing one, then

why not opt for the convenience of a highly realistic gas fire

with optional remote control or electric fire with a warming

flickering glow and a fan heater that is discreetly hidden behind

the ashpan cover when not in use.

Fuel Bed

Coals

Command Controls

Gas: Manual or Standard upgradable Electric: Manual

Art Nouveau Tiled Insert, Highlight Polished

shown in Stovax Chatsworth mantel

Please see Stovax Classic Fireplaces brochure for full details on our extensive range of Cast Iron Fireplaces.

Page 51

101

VFC Tapered Fires

A Gazco VFC Tapered fire simply replaces an open fire in a

standard ‘chairbrick’ fireplace to offer comforting radiant heat and

provide an exceptional ‘real fire’ look but with all the convenience

of gas and, if you wish, even a remote control.

Another benefit is our superb VFC (variable flame control)

technology. This allows you to select the exact balance of flame,

glow and heat to suit your mood. Set to 'Blue' and the coals

glow brightly with a lower, translucent flame with a hint of blue.

Set to 'Yellow' and you will enjoy the yellow, flickering flames and

authentic atmosphere of a genuine fire.

Available in three width sizes and with a choice of Arts, Holyrood

or Spanish fronts in a variety of brass and cast iron finishes.

16" VFC Tapered Fire with Highlight Polished Spanish front

Fuel Bed

Coals

Command Controls

Manual Standard upgradable

Fire Choices

VFC Tapered 16”* 25% 2.35kW 

VFC Tapered 18” 25% 2.65kW 

VFC Tapered 22” 25% 3.05kW 

* 16" RD model also available, requires no air vent

Chimney Options

1 2

E%kW

†

† Efficiency figures given are based upon the maximum heat output ac hieved in the options available for this model, for complete technical information, please see pages 134-135.

100

16" VFC Tapered Fire with Matt Black Holyrood front

Page 52

Personalise your Gazco fire

ass is also

att

ass also available fo

kolished B

att

ackPolished

ass

Sta

ess

Sta

ess

att

Sta

ess

Sta

ess

att

ack

att

ack

lle

att

You can personalise your Gazco Logic Hotbox, Logic Convector, Logic IPF and VFC Convector fires by choosing from the traditional fronts and frames illustrated on this page. All of the fronts are also suitable for E-Box™ and VFC Tapered fires whilst E-Studio™ fires are only compatible with the Arts fronts. E-Box™ and E-Studio™ fires can also be styled with the Arts frames.

ire Frames

Fire Fronts

Holyrood

Spanish

Matt Black Cast Polished Brass with black Highlight Polished Polished Chrome*

Iron with brass finials* columns & brass finials*

Matt Black Polished Brass Highlight Polished Polished Chrome

* E-Box™ versions have no finials.

rofil Fram

rative Fram

rts Frame

att Blac

Black

Polished Br

ras

rushed Stainless

Brushed Stee

rushed tee

inl

Polished Stainless

Steel

tee

lished

inl

Arts

102

Matt Black Polished Brass Highlight Polished Polished Chrome

otes

1. All frames have 50mm profile Profil Frame in Br

available with 67mm profile Profil Frame in M Br

Black and

r low lintel

att Black NB: E-Box™ & E-Studio™ versions

ave a gri

olished Brass

rushed Stainless

l & M

Polished Stainless

l & M

Black

Page 53

Fire Baskets

105

Fuels

Wood, coal and smokeless fuels

Most Gazco traditional fire baskets in this brochure are suitable for burning solid fuels such as logs and coal as well as approved smokeless fuels.

Gas

All Gazco fire baskets can be specified for use with either Natural Gas or LPG. Natural Gas is provided through mains pipelines, whilst LPG is usually supplied to homes in rural areas from a tank in the garden or from gas bottles.

Electric

Many fire baskets are available with Gazco’s “electric coal effect” fan heater. These will require a 13amp socket located within 1 metre of your fireplace.

Gas & Electric options

Gas fires

Fires with gas logs (1), driftwood (2), coals (3) or glass (4) are available for both natural gas and LPG. The glass effect is only offered as an option with the Aspen, Chamonix and Tahoe models. Please see page 137 for a full list of options.

Operation of your gas fire basket can be upgraded to Gazco’s Standard Command remote control system. Available on all models except the Swan’s Nest, once manually ignited, the handset allows you to alter flame height and heat output all from the comfort of your armc hair!

Electric fires

Electric fires (5) provide you with the comforts of a warming, flickering coal effect glow and a thermostatically controlled fan heater. They can be operated in three modes – glow only, glow + 1kW of heat and glow + 2kW of heat – and, in most cases, the fan heater can be discreetly hidden behind an optional ashpan cover when not in use.

Custom-built gas fire baskets

If you have an existing g rate or basket, and would like the extra convenience of a gas fire, then Gazco can provide you with a made-to-measure fire in a choice of log, driftwood or coal effects. Please see pages 118-119 for details.

1 Gas logs

2 Gas driftwood

3 Gas coals

4 Gas glass

5 Electric fire with coal-effect

We offer a superb range of fire baskets, each one handcrafted using traditional materials such as brass, steel, chrome and cast iron. Many are also offered in a choice of sizes and in a variety of casting shapes or finishes. In fact, there are almost 100 combinations from which to select the perfect fire basket for your fireplace.

According to model, there is a choice of solid fuel, gas and electric fire baskets so before you make your selection, speak to your local Gazco retailer about which option is right for you and your chimney.

104

Page 54

Contemporary

107

Aspen

Available in two sizes. Stainless steel/black steel construction. Complete with your choice of glass, log, driftwood or coal effect gas fire.

Chamonix with Smoked Glass top

One size. Features a top in grey glass and is complete with your choice of glass, log, driftwood or coal effect gas fire.

Chamonix with Stainless Steel top

This Chamonix features a Stainless Steel top and is available in small and medium (smaller depth) sizes. Complete with your choice of glass, log, driftwood or coal effect gas fire.

Tahoe

One size. Stainless steel/black steel construction. Complete with your choice of glass, log, driftwood or coal effect gas fire.

Davos

One size. Stainless steel/black steel construction. Complete with your choice of log, driftwood or coal effect gas fire (above).

Davos

One size. Stainless steel/black steel construction. Complete with your choice of log (above), driftwood or coal effect gas fire.

(Medium shown)

fire baskets

106

Large Aspen with Log effect gas fire

Page 55

Traditional fire baskets

Milan

Available in two sizes (15" or 18" grate size). Straight front in polished cast iron. Choice of all gas and electric fire options, except glass.

Stratford

Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Amhurst

Available in two sizes. Straight front in choice of black cast iron or polished cast iron. Choice of all gas and electric fire options, except glass.

Art Deco

Available in two sizes. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

109

Small Art Deco in Polished Cast Iron with Log effect gas fire, shown in Stovax London front

108

Medium Milan shown in Stovax Belgravia front and Grafton Stone Mantel

Page 56

Large Art Deco in Polished Cast Iron with Coal effect gas fire, shown in Stovax Art Deco Mantel

111

Small Amhurst in Black Cast Iron with Log effect gas fire, shown in Stovax Belgravia front

Rochester

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Harlech

One size. Straight front in choice of brass or polished iron/ steel. Choice of all gas and electric fire options, except glass.

110

Ascot

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Page 57

Portland

113

Stratford in Brass

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Portland Extended

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Audley

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Earlswood

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Dorchester

One size. Straight front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Montrose

One size. Straight or bowed front in brass. Choice of all gas and electric fire options, except glass.

Page 58

115

Kennet

One size. Bowed front in brass. Choice of all gas and electric fire options, except glass.

Cheltenham

One size. Straight front in brass only. Choice of all gas and electric fire options, except glass.

Inverness

One size. Bowed front in choice of brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

Ludlow

One size. Bowed front in brass only. Choice of all gas and electric fire options, except glass.

Kendal

Kendal coal-effect gas fire. One size. Choice of straight or bowed front in brass. Choice of all gas and electric fire options, except glass.

Halifax

One size. Straight front in brass or polished iron/steel. Choice of all gas and electric fire options, except glass.

114

Melbury One size. Choice of straight or bowed front in brass or polished

iron/steel. Choice of all gas and electric fire options, except glass.

Page 59

117

Adam

One size. Straight front in choice of black or highlight polished cast iron. Choice of all gas and electric fire options, except glass.

Plymouth

One size. Straight front in choice of black or highlight polished cast iron. Choice of all gas and electric fire options, except glass.

Pub Scene

One size. Straight front in choice of black or highlight polished cast iron. Choice of all gas and electric fire options, except glass.

Spanish

Available in two sizes. Straight front in black or highlight polished cast iron and with a choice of four cast iron legs, two brass + two cast iron legs or four brass legs. Choice of all gas and electric fire options, except glass.

Swan's Nest

Available in three sizes in black cast iron only, with log gas fire. Choice of Georgian (left) or Queen Anne (above) brass fire dogs.

Cromwell

Available in two sizes. Straight front in black cast iron only. Choice of all gas fire options, except glass.

(Queen Anne)

116

Large Swan’s Nest with Georgian ﬁre dogs.

Page 60

Radiant gas fires custom-built

Features of our superb custom-built radiant Gas Fires include:

s 3IMPLEmulti-purpose manual control knob - for

fingertip control of ignition, pilot light and gas supply.

sUpgradable to Command remote control system.

sAdjustable flame setting - infinitely variable

between high and low to suit your mood.

sPiezo ignition - automatic sparking without batteries

or mains electricity.

sFlame failure device - automatically shuts off the

gas supply if the pilot light goes out.

sOxygen sensitive safety pilot - automatically shuts

off the gas supply if the oxygen level in your room falls below a safe level.

sReduced Draught versions - no additional

ventilation required.

sNatural gas or LPG - versions available for both

types of gas.

sHeat outputs - around 2.5kW depending on model.

Gazco made-to-measure log-effect fire at Langs Hotel, Glasgow

This log-effect fire is in a Devon restaurant. Gazco made-to-measure fires are suitable for domestic and commercial use. Please ask your retailer for further information about sizes, shapes and installation regulations.

Log fuel effect Driftwood fuel effect Coal fuel effect

The minimum and maximum sizes for made-to-measure gas fires are as follows:

Note: The sizes above are given as a guide only and ar e subject to the actual shape required. Ther e are strict regulations r egarding the installation of all gas fires including custom-built models. In particular, some openings will requir e some form of canopy to be fitted in order to comply with BS5871 (Part 3). Your Gazco dealer will be able to advise you about sizes, shapes, regulations etc. and to ans wer any other questions you may have.

Dimensions - with Manual Control upgradable to Command remote

Coals Logs Driftwood

Minimum* Maximum Minimum* Maximum Minimum* Maximum

Width (mm) 230 556 230 556 230 556

Depth (mm) 160 319 160 375 160 375

*Trays with these very minimum dimensions will be supplied without le gs.

119

Dimensions - with Manual Control

Coals Logs Driftwood

Minimum Maximum Minimum Maximum Minimum Maximum

Width (mm) 165 610 230 840 230 840

Depth (mm) 130 319 155 375 155 375

for your fireplace

Gazco offers a comprehensive made-to-measure service for living flame gas fires. A wide range of sizes are available, there is virtually no limit on shape and all are supplied with Gazco's class-leading fuel effects. This makes them ideal for everything from a small Victorian cast iron fireplace in a bedroom to a large centrepiece in a pub or restaurant.

118

Gazco made-to-measure coal-effect fire in an original antique grate and fireplace

Page 61

Additional Information

VFC Fires (See pages 68-69, 72-77, 80-93 and 96-97)

VFC Convector

Available in 16”, 18” and 22” widths and standard or low lintel heights, the VFC Convector is suitable for brick chimneys only but offers the additional benefits of a slightly deeper fuel bed and unique VFC (variable flame control) system. The latter feature allows you to select the exact balance of flame, glow and heat to suit your mood. Set to ‘Blue’ and the fuel bed glows brightly with a lower, translucent flame with a hint of blue. Set to ‘Yellow’ and you will enjoy the yellow, flickering flames and authentic atmosphere of a genuine fire. VFC Convectors are available with

coal fuel beds and the option of a Standard remote control.

VFC Powered Flue

Convector

A Powered Flue Kit can be added

to the VFC Convector to allow

it to be installed in homes with

no chimney. This kit gives you

the flexibility of locating the fan

unit on an outside wall up to six

metres away from the fire, and to

incorporate bends in the flue (as

illustrated right).

Radiant Fires

These fires are for those who do not require the additional heat of a

convector or do not wish to refurbish an existing open fireplace, whether

conventional ‘chairbrick’ opening or traditional cast iron fireplace.

VFC Tapered Fires (See pages 100-101)

Providing the same unique variable flame control feature as the

VFC Convector, VFC Tapered Fires are designed for installation into

conventional 'chairbrick' fireplaces. They are available in 16”, 18” and

22” widths and, according to width, with a choice of Arts, Holyrood or

Spanish fronts in a variety of brass, chrome and cast iron finishes, as

shown on pages 102-103.

Radiant Fires for Classic Fireplaces (See pages 98-99)

These are non-VFC fires with shapes specially adapted to suit the cast

iron Classic Fireplaces manufactured by our sister company Stovax Ltd.

Alternatively, should you have an original period fireplace of this type, or

a reproduction, then we can generally produce a custom-built fire to meet

your needs. Your retailer will be pleased to give you further information.

Command remote controls:

Gazco was the first UK company to introduce remote controls for

gas fires. Today, our Command remote control systems allow most

fires to be upgraded, either at the time of purc hase or at a later

date, with either:

a) Standard upgradable remote control

Once the pilot light has been ignited manually you

can vary the flame height and heat output from

the comfort of your armc hair.

b) Programmable remote control

This deluxe version has two additional features.

The first allows you to thermostatically control the

room temperature whilst the second allows you

to programme your fire to switch itself on and

off twice a day. Use both and you can even come

home to a glowing fire that has heated the room

to the temperature you select!

Some fires in the Gazco range come with the remote included

with the product, these are:

c) Open Studio sequential remote control

With this infra red remote control, you do not need

to light the pilot manually as the whole operating

sequence (on/off and flame height heat output) is

activated from the handset itself.

d) Glass Fronted Studio and Linea

sequential remote

This programmable, radio frequency remote control

offers all of the features of the Open Studio

sequential remote but with the additional benefits

of programmable thermostatic and timer functions.

e) Logic IPF remote control

This sequential remote differs in design to those

illustrated above, although offering similar features.

Please ask your Gazco dealer for further details.

f) Electric Riva

This remote operates the electric Riva, allowing

you at the touch of a button to choose between

four different flame effects, with or without heat.

121

Gazco's impressive choice of fires with a selection of fire fronts. The types of fire available with each frame and front are listed in the main brochure.

Logic Fires (See pages 68-77 and 80-97)

Logic Hotbox

The 16” Logic Hotbox is suitable for all chimney types and has been designed to meet the requirements of today’s modern homes where central heating is the norm and only a precast flue has been supplied by the builder. It provides a superb focal point and ambience but without the additional heat emitted by a convector. You may choose coal or pebble fuel beds and there is the option of a Standard remote control.

Logic Convectors

The Logic 16” Convector is a highly efficient, all-new engine that is suitable for all chimney types. It differs from the Hotbox, however, by incorporating a convection system that provides virtually twice the heating efficiency, so there is even more heat going into your room. The Logic Convector is available with coal or pebble fuel beds, both offering an excellent look and realistic flames, and the option of a Standard remote control.

Logic IPF Convector

There is also an IPF (Integral Powered Flue) version of the Logic Convector for homes without a chimney. All you need is to be able to position the fire on an outside wall so that the flue can go straight through (as pictured right). It is available with coal fuel bed and supplied complete with Sequential remote control.

The Logic IPF has also been specially developed for cavity wall properties and has been cleverly designed to use the gap in the wall to save space. You can either recess the fire into the inner skin of the wall or recess the fan unit into the outer skin. Alternatively, with non-cavity walls you can construct a false chimney breast in your room.

Just as importantly, the Logic IPF incorporates the very latest integrated electronics that allow all functions to be operated from its own, unique remote control. There is no need to turn a fan on before igniting the fire and no need for a permanent pilot light.

120

E-Box™ Fires (See pages 36-39, 42-43, 68-77 and 80-95)

This top-of-the-range, 16” wide engine provides exceptional heating

efficiency and much improved fuel economy. Set behind a virtually invisible

glass window, Gazco’s technology has created a design that offers

considerably lower running costs (gas consumption is lower so saving you

money). Furthermore, installation is not only simpler than larger glass-

fronted fires but also no hearth is required where the E-Box™ is fitted

50mm (2”) above floor level – ideal for hole-in-the-wall settings.

Conventional Flue

The E-Box™ can be installed into all chimney types and has high

efficiency levels of up to 76%. The conventional flue E-Box™ is

available with coal or pebble fuel beds and the option of Standard or

Programmable remote controls.

Balanced Flue version

If you do not have a c himney there is the option of a balanced flue

E-Box™. Not only can this be easily fitted to homes with no chimney,

but the balanced flue version additionally allows for greater combustion

control and even higher efficiency levels of up to 86%. This version is

also available with coal or pebble fuel beds and the option of Standard

or Programmable remote controls.

E-Studio™ Fires

(See pages 36-41, 68-73, 76-77, 80-83 and 94-95)

This premium 16” wide engine provides high heating efficiency with a

contemporary fresh look. Set behind a virtually invisible glass window,

the E-Studio™ boasts a stunning ribbon flame effect combined with

Gazco’s latest technology, to create a stylish design and lower running

costs (gas consumption is lower so saving you money).

Conventional Flue

The E-Studio™ can be installed into all chimney types and has high

efficiency levels of up to 72%. The conventional flue E-Studio™ is

available with the option of Standard or Programmable remote controls.

Balanced Flue version

If you do not have a c himney there is the option of a balanced flue

E-Studio™. Not only can this be easily fitted to homes with no chimney,

but the balanced flue version additionally allows for greater combustion

control and even higher efficiency levels of up to 82%. This version is also

available with the option of Standard or Programmable remote controls.

Page 62

Open Fronted Fires

Product Code

Description Flue

Type

Gas

Type

Fuel

Effect

Heat Input

(kW)

Heat

Output

(kW) Efﬁciency

Remote Control

Appliance Size

(mm)

8700CHEC

Studio 1 Conventional Nat. Gas White Stones 6.90 1.72 25% Sequential See table overleaf

P8700CHEC

Studio 1 Conventional LPG White Stones 6.90 1.72 25% Sequential See table overleaf

8701CHEC

Studio 2 Conventional Nat. Gas White Stones 8.80 2.20 25% Sequential See table overleaf

P8701CHEC

Studio 2 Conventional LPG White Stones 9.30 2.30 25% Sequential See table overleaf

8702CHEC

Studio 3 Conventional Nat. Gas White Stones 13.20 3.30 25% Sequential See table overleaf

P8702CHEC

Studio 3 Conventional LPG White Stones 13.70 3.40 25% Sequential See table overleaf

Glass Fronted Fires

Product Code

Description Flue

Type

Gas

Type

Fuel

Effect

Heat

Input

(kW)

Heat

Output

(kW) Efﬁcienc y

Remote Control

Appliance Size

(mm)

8700CFCHEC

Studio 1 Conventional Nat. Gas White Stones 6.90 4.85 70% Sequential See tables overleaf

P8700CFCHEC

Studio 1 Conventional LPG White Stones 6.90 4.85 70% Sequential See tables overleaf

8700BFCHEC

Studio 1 Balanced ﬂue Nat. Gas White Stones 6.30 5.10 81% Sequential See tables overleaf

P8700BFCHEC

Studio 1 Balanced ﬂue LPG White Stones 6.10 4.95 81% Sequential See tables overleaf

8700CFLEC

Studio 1 Conventional Nat. Gas Logs 6.70 4.70 70% Sequential See tables overleaf

P8700CFLEC

Studio 1 Conventional LPG Logs 6.90 4.83 70% Sequential See tables overleaf

8700BFLEC

Studio 1 Balanced ﬂue Nat. Gas Logs 6.40 5.20 81% Sequential See tables overleaf

P8700BFLEC

Studio 1 Balanced ﬂue LPG Logs 6.30 5.10 81% Sequential See tables overleaf

8701CFCHEC

Studio 2 Conventional Nat. Gas White Stones 8.30 6.50 78% Sequential See tables overleaf

P8701CFCHEC

Studio 2 Conventional LPG White Stones 8.30 6.50 78% Sequential See tables overleaf

8701BFCHEC

Studio 2 Balanced ﬂue Nat. Gas White Stones 8.40 6.80 81% Sequential See tables overleaf

P8701BFCHEC

Studio 2 Balanced ﬂue LPG White Stones 7.30 5.92 81% Sequential See tables overleaf

8701CFLEC

Studio 2 Conventional Nat. Gas Logs 8.50 6.65 78% Sequential See tables overleaf

P8701CFLEC

Studio 2 Conventional LPG Logs 8.80 6.85 78% Sequential See tables overleaf

8701BFLEC

Studio 2 Balanced ﬂue Nat. Gas Logs 8.60 7.00 81% Sequential See tables overleaf

P8701BFLEC

Studio 2 Balanced ﬂue LPG Logs 8.00 6.50 81% Sequential See tables overleaf

8702BFCHEC

Studio 3 Balanced Flue Nat. Gas White Stones 9.00 7.30 81% Sequential See tables overleaf

P8702BFCHEC

Studio 3 Balanced Flue LPG White Stones 9.00 7.30 81% Sequential See tables overleaf

8704BFLEC

Studio 22 Balanced Flue Nat. Gas Logs 7.50 5.85 78% Sequential Please see page 126

P8704BFLEC

Studio 22 Balanced Flue LPG Logs 7.00 5.46 78% Sequential Please see page 126

Studio

FIRE INFORMATION

123

X X

The above information is to assist you in your choice of a suitable Gazco ﬁre. This is not intended to be all the information required to install your ﬁre. This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

Installing Televisions above Open Fronted Studio Fires On a normal flue which is functioning correctly, Open Fronted Studio's do not create a particularly hot environment on the wall above where they are installed. Accordingly, it may be possible to install Plasma or LCD TV's above them, as long as the distance to the TV is a minimum of 450mm from the top of the fire and as long as it has been checked with the TV manufacturers installation instructions with regard to installation and heat proximity. If in doubt please contact and check with your TV manufacturer.

Glass Fronted Studio Fires Gazco does not recommend installation of televisions above Glass Fronted Studio fires.

Technical Information

The following pages provide much of the

dimensional, heat input/output, efficiency and

product code information you will need to

choose your new Gazco fire. For more detailed

specifications, please consult your Gazco retailer.

Alternatively, complete installation instructions may

be downloaded from www.gazco.com.

Contents

Studio Fires 123

Linea Wall Mounted Fires 128

Gas and Electric Riva Cassette Fires 128

Logic Hotbox, Convector and IPF Fires 130

E-Box™ and E-Studio™ Fires 132

VFC Fires 134

Stilo Fires 136

Gas Fires for Stovax Classic Fireplaces 136

Fire Baskets 137

122

Page 63

ADDITIONAL INFORMATION FOR OPEN FRONTED STUDIO FIRES (mm)

125

Open Fronted Frame Size (mm) Glass Fronted CF Frame Size (mm) Glass Fronted BF Frame Size (mm) Description Frame Finish Product Code w h d Product Code w h d Product Code w h d STUDIO 1

Bauhaus Anthracite

8711AN

764 439 28

8711CFAN01

860 534 28

8711BFAN01

850 524 28

Bauhaus Polished Stainless Steel

8711P

764 439 28

8711CFSS01

860 534 28

8711BFSS01

850 524 28

Proﬁl Anthracite

8710AN

750 426 13

8710CFAN01

846 520 13

8710BFAN01

836 510 13

Proﬁl Polished Stainless Steel

8710P

750 426 13

8710CFSS01

846 520 13

8710BFSS01

836 510 13

Steel Bronze

8712BZ

1120 675 13

8712CFBFBZ01

1120 675 25

8712CFBFBZ01

1120 675 25

Steel Graphite

8712GP

1120 675 13

8712CFBFGP01

1120 675 25

8712CFBFGP01

1120 675 25

Steel Iridium

8712IR

1120 675 13

8712CFBFIR01

1120 675 25

8712CFBFIR01

1120 675 25

Link Polished Stainless/Black

8723PBK

1332 491 23 N/A N/A N/A N/A N/A N/A

Andes Oak/Walnut

8723KW

1332 497 21 N/A N/A N/A N/A N/A N/A

Inca Walnut Quarters

8723WQ

1200 559 27 N/A N/A N/A N/A N/A N/A

Geilo Solid Oak

8723SK

1332 497 27 N/A N/A N/A N/A N/A N/A

Kepler Solid Walnut

8723SW

1332 497 27 N/A N/A N/A N/A N/A N/A

Icon Graphite

8725GP01

880 2098 13 N/A N/A N/A

8725BFGP01

880 2143 44

Firenza Black Granite

8723GBK

1200 600 20 N/A N/A N/A N/A N/A N/A

Pienza White Limestone

8723LMS

1200 600 20 N/A N/A N/A N/A N/A N/A

Sienna Beige Travertine

8723TRV

1200 600 20 N/A N/A N/A N/A N/A N/A

STUDIO 2

Bauhaus Anthracite

8718AN

964 439 28

8718CFAN02

1060 534 28

8718BFAN02

1050 524 28

Bauhaus Polished Stainless Steel

8718P

964 439 28

8718CFSS02

1060 534 28

8718BFSS02

1050 524 28

Proﬁl Anthracite

8717AN

950 426 13

8717CFAN02

1046 520 13

8717BFAN02

1036 510 13

Proﬁl Polished Stainless Steel

8717P

950 426 13

8717CFSS02

1046 520 13

8717BFSS02

1036 510 13

Steel Bronze

8719BZ

1320 675 13

8719CFBFBZ02

1320 675 25

8719CFBFBZ02

1320 675 25

Steel Graphite

8719GP

1320 675 13

8719CFBFGP02

1320 675 25

8719CFBFGP02

1320 675 25

Steel Iridium

8719IR

1320 675 13

8719CFBFIR02

1320 675 25

8719CFBFIR02

1320 675 25

Link Polished Stainless/Black

8724PBK

1532 491 23 N/A N/A N/A N/A N/A N/A

Andes Oak/Walnut

8724KW

1532 497 21 N/A N/A N/A N/A N/A N/A

Inca Walnut Quarters

8724WQ

1400 559 27 N/A N/A N/A N/A N/A N/A

Geilo Solid Oak

8724SK

1532 497 27 N/A N/A N/A N/A N/A N/A

Kepler Solid Walnut

8724SW

1532 497 27 N/A N/A N/A N/A N/A N/A

Firenza Black Granite

8724GBK

1500 600 20 N/A N/A N/A N/A N/A N/A

Pienza

White Limestone

8724LMS

1500 600 20 N/A N/A N/A N/A N/A N/A

Sienna Beige Travertine

8724TRV

1500 600 20 N/A N/A N/A N/A N/A N/A

STUDIO 3

Bauhaus Anthracite

8721AN

1354 439 28 N/A N/A N/A

8721BFAN03

1440 524 28

Bauhaus Polished Stainless Steel

8721P

1354 439 28 N/A N/A N/A

8721BFSS03

1440 524 28

Proﬁl Anthracite

8720AN

1340 426 13 N/A N/A N/A

8720BFAN03

1426 510 13

Proﬁl Polished Stainless Steel

8720P

1340 426 13 N/A N/A N/A

8720BFSS03

1426 510 13

Steel Bronze

8722BZ

1710 675 13 N/A N/A N/A

8722BFBZ03

1740 675 25

Steel Graphite

8722GP

1710 675 13 N/A N/A N/A

8722BFGP03

1740 675 25

Steel Iridium

8722IR

1710 675 13 N/A N/A N/A

8722BFIR03

1740 675 25

STUDIO 22

Bauhaus Anthracite N/A N/A N/A N/A N/A N/A

8728BFAN22

439 964 28

Bauhaus Polished Stainless N/A N/A N/A N/A N/A N/A

8728BFSS22

439 964 28

Proﬁl Anthracite N/A N/A N/A N/A N/A N/A

8726BFAN22

426 950 13

Proﬁl Polished Stainless N/A N/A N/A N/A N/A N/A

8726BFSS22

426 950 13

Steel Bronze N/A N/A N/A N/A N/A N/A

8729BFBZ22

675 1320 13

Steel Graphite N/A N/A N/A N/A N/A N/A

8729BFGP22

675 1320 13

Steel Iridium N/A N/A N/A N/A N/A N/A

8729BFIR22

675 1320 13

FRAME INFORMATION

Appliance dimensions (mm)

Dimension Studio 1 Studio 2 Studio 3

A Gather width 664 864 1254 B Gather top 250 250 325 C Gather taper 207 307 465 D Base width 635 835 1225 E** Box width 660 860 1250 F Max. lintel width 130 130 130 G Gather depth 187 187 187 H** Box height 334 334 334 I* Base height 133 133 133 J Base depth 130 130 130 K Base 182 182 182 L Spigot height 50 50 50 M Gather height 300 300 700 N Total height 817 817 1217

* adjustable feet can increase base height by up to 235 mm ** If installed with one of the Studio frames, a 5mm space must be left around the front edge of the appliance.

CHIMNEY TYPES

Studio 1

sClass 1 brick built ﬂue

a) Can be ﬁtted without the optional ﬂue gather if the chimne y is sound. b) If the optional gather is used, then it must be connected to a 7" ﬂexible ﬂue liner suitable for gas.

sPre-fabricated 7" twin wall ﬂue system suitable for gas

a) Must be ﬁtted with the optional ﬂue gather.

Conventional Flue Installation

The conventionally ﬂued Glass Fronted Studio has been designed with ease of installation in mind and can be installed two ways:

1) Direct connection to a

5" ﬂue liner

5" twin wall gas vent system

2) No additional ﬂuing is

needed when it is installed into an existing builders opening below a masonry chimney and sealed to the ﬁreplace opening (assuming that the chimney is of sound construction).

The above information is to assist you in your choice of a suitable Gazco ﬁre. This is not intended to be all the information required to install your ﬁre.

124

This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

315

501

272

ADDITIONAL INFORMATION FOR GLASS FRONTED STUDIO FIRES (mm)

CONVENTIONAL FLUE

752 - Studio 1 CF

952 - Studio 2 CF

- Studio 1 CF

829

- Studio 2 CF

1029

124

Studio 2 and 3

sClass 1 brick built ﬂue

sPre-fabricated 7" twin wall ﬂue system suitable for gas

Note: it is possible to install the Studio 2 and 3 into a Class 1 brick ﬂue. However, this type of installation should only be undertaken by chimne y specialists. This is because it will require the front wall and structure of the chimney breast to be extensively cut away to allow enough width to ﬁt the ﬁre and also provide access to the top of the gather to allow either a) Connection of a 7" ﬂexible ﬂue liner suitable for gas b) Creation of a smooth transition between the top of the gather and the ﬂue

156

428

229

Dotted lines indicate

total dimensions for

Flue Gather

D BASE

a) Must be ﬁtted with the ﬂue gather.

BALANCED FLUE

745 - Studio 1 BF

945 - Studio 2 BF

1335 - Studio 3 BF

345

820 - Studio 1 BF

738

571

310

1020 - Studio 2 BF

1410 - Studio 3 BF

158

491

F G

BASE MAIN BOX

BASE

127

416

119

291

543

624

Page 64

STUDIO ICON FRAME SIZES

127

GLASS FRONTED STUDIO EDGE INSTALLATION OPTIONS

Edge Kit – this kit is screw-mounted to the front ﬂange of the outer ﬁrebox. The L-shaped attachments can either provide a 20mm return against which high temperature plasterboard/screed can be butted up for the ‘clean edge’ look or, if the ﬁrebox ﬂange is on the outside of a brick or stud work wall, allow ceramic or stone tiles to be ﬁxed with a similar look. The Edge Kit is ﬁnished in black to complement the Studio.

Cool Wall Kit – again, screw-mounted to the front ﬂange of the outer ﬁrebox, the 60mm deep U-shaped attachments of the Cool Wall kit are designed primarily for studwork false chimney breasts. The additional depth allows some of the heat to be vented up into the void above the ﬁrebox and then re-enter the room at a higher level. The effect is to produce a cooler wall immediately above the appliance than would otherwise be the case. The Cool Wall Kit is left unﬁnished so that it can be painted to match the front face of your ﬁreplace.

Installation method for studwork/false

chimney breast application

Edge Kit

Installation method for brick/masonary

chimney breast application

Convected heat ﬂows directly out into room

Cool Wall Kit

Installation method for studwork/false

chimney breast application

Installation method for brick/masonary

chimney breast application

Convected heat ﬂows up through an open channel and can be vented back into room

at a higher point

Convected heat ﬂows up

through an open channel

and can be vented back

into room at a higher point

NB: When using the Edge Kit, heat resistant board and high temperature ﬁnishing plaster must be used. Please refer to installation instructions for full details.

NB: Full installation information, including the requirement for the use of noncombustible materials, can be downloaded from www.gazco.com

When using the Edge Kit the ﬁre is recessed by 20mm from the ﬁnished wall surface and the kit is ﬁnished in black to complement the Studio.

When using the Cool Wall Kit the ﬁre is recessed by 60mm from the ﬁnished wall surface and the kit is left unﬁnished so that it can be painted to match your decor.

STUDIO ICON OPEN FRONTED (mm)

2098

335

110

660

628

880

STUDIO ICON GLASS FRONTED (mm)

STUDIO OPTIONS AND ACCESSORIES

Open Fronted Studio Fires

Product Code Description

Studio 1

8714GBK Blac k Granite linings

8713 Flue gather*

Studio 2

8715GBK Blac k Granite linings

Studio 3

8716GBK Blac k Granite linings

*Flue gather automatically included with Open Fronted Studio 2 and Studio 3 Fires.

Glass Fronted Studio Fires

8572 Warm air ducting kit (2 outlets)

8524 Balanced ﬂue kit - vertical

Studio 1

8727CFEK01 Edge ﬁtting kit for conventional ﬂue

8727BFEK01 Edge ﬁtting kit for balanced ﬂue

8727CFCW01 Cool Wall ﬁtting kit for conventional ﬂue

8727BFCW01 Cool Wall ﬁtting kit for balanced ﬂue

8534 Balanced ﬂue kit - up and out

Studio 2

8727CFEK02 Edge ﬁtting kit for conventional ﬂue

8727BFEK02 Edge ﬁtting kit for balanced ﬂue

8727CFCW02 Cool Wall ﬁtting kit for conventional ﬂue

8727BFCW02 Cool Wall ﬁtting kit for balanced ﬂue

8509 Balanced ﬂue kit - up and out

Studio 3

8727BFEK03 Edge ﬁtting kit for balanced ﬂue

8727BFCW03 Cool Wall ﬁtting kit for balanced ﬂue

8567 Balanced ﬂue kit - up and out

Studio 22

8727BFEK22 Edge ﬁtting kit for balanced ﬂue

8727BFCW22 Cool Wall ﬁtting kit for balanced ﬂue

8708 Balanced ﬂue kit - rear

8534 Balanced ﬂue kit - up and out

STUDIO 22 APPLIANCE

2143

335

110

660

126

880 O/A

628

DIMENSIONS (mm)

504mm

O/A FLANGE

1029mm

O/A FLANGE

146mm

283mm

1175mm

423mm

158mm

186mm

1029mm

162mm

81mm

1163mm

84mm

O/A

264mm

21mm

Page 65

Linea Wall Mounted Fires

129

ADDITIONAL INFORMATION

NOTE: New 53 and 67 conventional ﬂue connection system means easier installation. No access to ﬂue connector required during installation.

†A marble slip with a minimum width of 150mm is recommended around ALL installations. No combustible material, including wallpaper, should be less than 150mm from the appliance.

*When installing below 150mm from the ﬂoor it is recommended that a 12mm thick non-combustible hearth is provided, extending 300mm in front and 150mm each side of the ﬁre.

NOTE: Access to ﬂue will be required during installation.

Gas entry 8mm

*Please see opposite

Marble slip

†

Studwork

Optional warm air ducting kit 8572

5" Gas vent ﬂue

Gas entry 8mm

*Please see opposite

Marble slip

†

Studwork

Optional warm air ducting kit 8572

6" Flue kit up out 8534

6" Flue kit vertical 8524

390mm

min

Balanced FlueConventional Flue

Diagrammatic representation only. Not accurate for installation purposes

Product Code Description

All Riva Gas Cassettes

8455 Standard Remote Control Kit

8456 Programmable Thermostatic Remote Control Kit

8572 Warm air ducting kit (2 outlets)

8524

Balanced ﬂue kit - vertical (2x1000mm straight,

1x1000 terminal length)*

8534

Balanced ﬂue kit - up and out (1x198mm straight,

1x462mm terminal length, 1x90º bend)*

8454 Terminal guard (required for below 2m)

*Additional ﬂue pipe lengths and bends are available to extend the above kits

Riva 67 Electric

8688SL

Wall mounting box for Slimline Electric

Cassette 8590SLELR*

*Arlington, Esprit and Vetro ﬁres cannot be used in conjunction with wall mounting box.

OPTIONS AND ACCESSORIES

Product Code Description

Riva 53

8571

Fan-assisted convection circulation kit (240v) for Riva 53 conventional ﬂue

8576

Fan-assisted convection circulation kit (240v) for Riva 53 balanced ﬂue

Riva 67

8571

Fan-assisted convection circulation kit (240v) for Riva 67 conventional ﬂue

8566

Fan-assisted convection circulation kit (240v) for Riva 67 balanced ﬂue

8600BB Beig e brick effect ceramic lining

8736 Linerless kit

Riva 70

8571

Fan-assisted convection circulation kit (240v) for Riva 70 balanced ﬂue

8601BB Beig e brick effect ceramic lining

Riva 67 Electric

8661BEL Arlington frame for electric ﬁre Blac k Cast Iron 940 627 75 8641BS Avanti horizontal curve frame for electric ﬁre Stainless Steel/Black 825 699 140 8634GP Designio frame for electric ﬁre Graphite 775 603 68 8634IR Designio frame for electric ﬁre Iridium 775 603 68 8684GP Esprit frame for electric ﬁre Graphite 925 684 70 8684IR Esprit frame for electric ﬁre Iridium 925 684 70 8662BKEL Vetro frame for electric ﬁre Black Glass 1052 650 92 8735GP View frame for electric ﬁre Graphite 950 590 35 8735IR View frame for electric ﬁre Iridium 950 590 35

Riva 70

8643BS Avanti horizontal curve frame for balanced ﬂue Stainless Steel/Blac k 870 880 134 8495GP70 Proﬁl 2 frame for balanced ﬂue Graphite 740 752 38 8495IR70 Proﬁl 2 frame for balanced ﬂue Iridium 740 752 38 8739BK70 Spectrum frame for balanced ﬂue Black with Stainless inserts 910 765 50

Product Code Description Frame Finish

Frame Size (mm)

whd

FRAME INFORMATION cont'd.

FRONT INFORMATION

Product Code

Complete Front

8652GP Designio Front Graphite 775 620 170 8652IR Designio Front Iridium 775 620 170 8657GP Steel Front Graphite 1050 650 167 8657IR Steel Front Iridium 1050 650 167 8653BK Vetro Front Black Glass 1050 650 167 8653WH Vetro Front White Glass 1050 650 167

FIRE INFORMATION

Gas and Electric Riva Cassette Fires

FIRE INFORMATION

X X

FRAME INFORMATION

Description

Product Code

8651EC Linea Balanced ﬂue Nat. Gas N/A 5.25 4.30 82% Sequential 775 620 170 P8651EC Linea Balanced ﬂue LPG N/A 5.25 4.30 82% Sequential 775 620 170

Product Code Description Flue Type Gas Type

8596 Riva 53 Conventional Nat. Gas Driftwood Logs 6.80 4.90 72% Upgradable 540 665 350 P8596 Riva 53 Conventional LPG Driftwood Logs 6.60 4.80 73% Upgradable 540 665 350 8592 Riva 53 Balanced ﬂue Nat. Gas Driftwood Logs 6.80 5.30 78% Upgradable 540 665 350 P8592 Riva 53 Balanced ﬂue LPG Driftwood Logs 6.30 4.90 78% Upgradable 540 665 350 8590LUC Ri va 67 Conventional Nat. Gas Logs 6.80 4.90 72% Upgradable 670 530 350 P8590LUC Riva 67 Conventional LPG Logs 6.70 4.80 72% Upgradable 670 530 350 8595LUC Ri va 67 Balanced ﬂue Nat. Gas Logs 6.10 4.60 75% Upgradable 670 530 350 P8595LUC Riva 67 Balanced ﬂue LPG Logs 5.80 4.40 75% Upgradable 670 530 350 8597 Riva 70 Balanced ﬂue Nat. Gas Logs 7.80 6.50 84% Upgradable 700 705 350 P8597 Riva 70 Balanced ﬂue LPG Logs 7.40 6.20 84% Upgradable 700 705 350 8590SLELR Riva 67 N/A Electric Logs 2.00 2.00 99% Remote 665 535 105

Description

Frame Finish

Flue Type

Product Code Description Frame Finish

Riva 53

8632BS Avanti vertical cur ve frame for conventional ﬂue and balanced ﬂue Stainless Steel/Black 650 819 120 8644GP Designio frame for conventional ﬂue and balanced ﬂue Graphite 650 735 68 8644IR Designio frame for conventional ﬂue and balanced ﬂue Iridium 650 735 68 8495GP53 Proﬁl 2 frame for conventional ﬂue and balanced ﬂue Graphite 590 729 38 8495IR53 Proﬁl 2 frame for conventional ﬂue and balanced ﬂue Iridium 590 729 38 8739BK53 Spectrum frame for conventional ﬂue and balanced ﬂue Black with Stainless inserts 760 729 50

Riva 67 Gas

8641BS Avanti horizontal curve frame for conventional ﬂue and balanced ﬂue Stainless Steel/Black 825 699 140 8634GP Designio frame for conventional ﬂue and balanced ﬂue Graphite 775 603 68 8634IR Designio frame for conventional ﬂue and balanced ﬂue Iridium 775 603 68 8684GP Esprit frame for conventional ﬂue and balanced ﬂue Graphite 925 684 70 8684IR Esprit frame for conventional ﬂue and balanced ﬂue Iridium 925 684 70 8495GP67 Proﬁl 2 frame for conventional ﬂue and balanced ﬂue Graphite 710 590 38 8495IR67 Proﬁl 2 frame for conventional ﬂue and balanced ﬂue Iridium 710 590 38 8739BK67 Spectrum frame for conventional ﬂue and balanced ﬂue Black with Stainless inserts 880 590 50 8662BK Vetro frame for conventional ﬂue and balanced ﬂue Black Glass 1052 650 92

The above information is to assist you in your choice of a suitable Gazco ﬁre. This is not intended to be all the information required to install your ﬁre.

128

This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

Frame Size (mm)

whd

Gas

Type

Heat Input (kW)

Heat

Output

(kW)

Efﬁciency

Remote Control

Fuel

Effect

Heat

Input

(kW)

Heat

Output

(kW) Efﬁciency

Remote Control

Fuel

Effect

whd

Fire Size (mm)

whd

Opening Size (mm)

whd

Frame Size (mm)

Page 66

Logic Hotbox, Convector and IPF Fires

ADDITIONAL INFORMATION

Logic Hotbox, Convector and IPF Fires

If your chimne y has a shallow ‘starter block’ then use spacer kit 8315 and a 3" (75mm) deep rebate surround to achieve the C1 dimension. Pre cast flues with a deep 'starter block' may be installed in exactly the same way as a conventional masonry opening providing there is a depth of 8

" (215mm) at C1.

If you are ﬁtting a Decorative or Proﬁl frame with an Arts Front, an additional ﬁtting kit will be provided to ease installation. You can install a Logic Convector Fire with a Stovax Cast Iron Victorian, Art Nouveau or Combination Fireplace. Conventional Logic Hotbox and Logic Convector ﬁres require 5" minimum ﬂue sizes. Please consult your local Gazco and Stovax dealer for further information.

Installation of Logic Hotbox or Logic Convector into Pre Cast Flues (minimum 16,500mm2)

Installation of Logic Integral Powered Flue

FRAME AND FRONT INFORMATION cont'd.

Product Code

Description Frame

Finish

Frame Size (mm)

Marble or similar

Sealed gap

Spacer

$

Hearth

592

192

370

550

183 596 155

596

499

Fan unit recessed in outer wall.

Outer wall Inner wall

Guard

External fan unit

335mm min overall 855mm max overall

Convector unit

Front

75mm (3")

Rebated surround

Convector unit recessed in inner wall.

Front

40mm (1

/4")

Rebated surround

Convector unit

Outer wall

Inner wall

Guard

300mm min overall 780mm max overall

External fan unit

Diagrammatic representation only. Not accurate for installation purposes.

Fire Frame Choice

8284MB Arts frame Matt Black 510 605 8284PBR Arts frame Polished Brass 510 605 8284P Arts frame Polished Stainless Steel 510 605 8284BS Arts frame Brushed Stainless Steel 510 605 8284BPBR Arts frame Polished Brass & Matt Black 510 605 8284BP Arts frame Polished Stainless Steel & Matt Black 510 605 8284BBS Arts frame Brushed Stainless Steel & Matt Black 510 605 8285 Decorative frame Matt Black 505 610 8266 Decorative frame Polished Brass 505 610 8232 Decorative frame Polished Stainless Steel 505 610 8235 Decorative frame Brushed Stainless Steel 505 610 8345 Proﬁl (Standard) frame Matt Black 490 600 8340 Proﬁl (Standard) frame Polished Brass 490 600 8342 Proﬁl (Standard) frame Polished Stainless Steel 490 600 8229 Proﬁl (Standard) frame Brushed Stainless Steel 490 600

131

LOGIC HOTBOX FIRE INFORMATION

Heat

Product Code

8306MCUC Logic Hotbox Class 1 & 2 Nat. Gas Coals 6.70 3.20 48% Upgradable 410 560 250

P8306MCUC Logic Hotbox Class 1 & 2 LPG Coals 6.70 3.20 48% Upgradable 410 560 250

8306PBUC Logic Hotbox Class 1 & 2 Nat. Gas Pebbles 6.70 3.20 48% Upgradable 410 560 250

P8306PBUC Logic Hotbox Class 1 & 2 LPG Pebbles 6.70 3.20 48% Upgradable 410 560 250

LOGIC CONVECTOR FIRE INFORMATION

Product Code

8308MCUC Logic Convector Class 1 & 2 Nat. Gas Coals 6.70 4.10 61% Upgradable 410 560 250

P8308MCUC Logic Convector Class 1 & 2 LPG Coals 6.70 4.10 61% Upgradable 410 560 250

8308PBUC Logic Convector Class 1 & 2 Nat. Gas Pebbles 6.70 4.10 61% Upg radable 410 560 250

P8308PBUC Logic Convector Class 1 & 2 LPG Pebbles 6.70 4.10 61% Upgradable 410 560 250

LOGIC INTEGRAL POWERED FLUE FIRE INFORMATION

Product Code

8316MC Logic IPF Powered ﬂue Nat. Gas Coals 6.70 4.20 62% Sequential 410 560

P8316MC Logic IPF Powered ﬂue LPG Coals 6.70 4.20 62% Sequential 410 560

Description

Flue

Type

Flue

Type

Flue Type

Gas

Type

Gas

Type

Gas

Type

Fuel

Effect

Fuel

Effect

Fuel

Effect

Input (kW)

Heat Input (kW)

Heat

Input

(kW)

Heat

Output

(kW)

Heat

Output

(kW)

Heat

Output

(kW)

Efﬁciency

Remote

Remote Control

Control

Opening Size (mm)

whd

Opening Size (mm)

whd

Opening Size (mm)

whd

additional

info. on

FRAME AND FRONT INFORMATION

Product Code

Complete Front Choice

8251GP Designio front Graphite 595 615 68 8251IR Designio front Iridium 595 615 68 8681MB Dimension front Matt Black 540 635 68 8255BS Evolution front for Logic Hotbox Stainless Steel 489 597 45 8257BS Evolution front for Logic Convector and IPF Stainless Steel 489 597 45 8249BS Inﬁniti front Stainless Steel 620 710 75 8253IR Progress front Iridium 520 598 60 8678 Richmond front for Logic Convector and IPF Black Cast Iron 540 635 50

8698MB Winchester Matt Black 508 619 55

Fire Front Choice

8288MB Arts ﬁre front for Logic Hotbox and Logic Convector Matt Black 390 230 8284PBR Ar ts ﬁre front for Logic Hotbox and Logic Convector Polished Brass 390 230 8288P Arts ﬁre front for Logic Hotbox and Logic Convector Polished Chrome 390 230 8288HP Arts ﬁre front for Logic Hotbox and Logic Convector Highlight Polished 390 230 8282MB Arts ﬁre front for Logic IPF Matt Black 390 230 8282PBR Arts ﬁre front for Logic IPF Polished Brass 390 230 8282P Arts ﬁre front for Logic IPF Polished Chrome 390 230 8282HP Arts ﬁre front for Logic IPF Highlight Polished 390 230 8391 Hol yrood ﬁre front Matt Blac k with Brass ﬁnials 385 265 8397 Hol yrood ﬁre front Polished Brass with black columns 385 265 8150 Hol yrood ﬁre front Highlight Polished 385 210 8397P Holyrood ﬁre front Polished Chrome 385 210 8382 Spanish ﬁre front Matt Blac k 385 210 8388 Spanish ﬁre front Polished Brass 385 210 8153 Spanish ﬁre front Highlight Polished 385 210 8388P Spanish ﬁre front Polished Chrome 385 210

The above information is to assist you in your choice of a suitable Gazco ﬁre. This is not intended to be all the information required to install your ﬁre.

130

This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

Description Frame

Finish

Frame Size (mm)

whd

OPTIONS AND ACCESSORIES

Product

Description

Code

8455 Standard remote control kit

for Logic Hotbox and Logic Convector

8315 Spacer kit (75mm) for

Logic Hotbox and Logic Convector

Page 67

E-Box™

133

The information on these pages is to assist you in your choice of a suitable Gazco ﬁre. This is not intended to be all the information required to install your ﬁre. This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

Installation of E-Box™ & E-Studio™ Conventional Flue into Pre-cast Flue installations. (minimum 16,500mm2)

Additional Note: Conventional E-BoxTM and E-Studio

ﬁres require a minimum ﬂue size of 5".

E-Box™ & E-Studio™ Fires

Installation of E-Box™ & E-Studio™ Balanced Flue

" (215mm) at C1.

Overall external dimensions (mm)

E-Box™ Balanced Flue Minimum Flue Length = 88mm Maximum Flue Length = 506mm Recessed in to a cavity or a false chimney brest

Marble or similar

Sealed gap

Spacer

$

Hearth

232

408

Ø 146.5

472

278

303

592

232

549

435

Min and max ﬂue size length (mm)

232

506 max.

Diagrammatic representation only. Not accurate for installation purposes.

ADDITIONAL INFORMATION

E-BOX™ OPTIONS AND ACCESSORIES

Product Code Description

8455 Standard remote control kit 8456 Programmable Thermostatic Remote Control Kit 8315 Spacer kit (75mm) for conventional ﬂue E-Box™

E-STUDIO™ OPTIONS AND ACCESSORIES

Product Code Description

8455 Standard remote control kit 8456 Programmable Thermostatic Remote Control Kit

E-BOX™ FIRE INFORMATION

Product Code

8691MCUC E-Box™ Conventional Nat. Gas Coals 5.10 3.80 76% Upgradable 410 560 250

P8691MCUC E-Box™ Conventional LPG Coals 4.80 3.70 76% Upgradable 410 560 250

8691PBUC E-Box™ Conventional Nat. Gas Pebbles 5.10 3.80 76% Upgradable 410 560 250

P8691PBUC E-Box™ Conventional LPG Pebbles 4.80 3.70 76% Upgradable 410 560 250

8692MCUC E-Box™ Balanced ﬂue Nat. Gas Coals 4.10 3.52 86% Upgradable 410 560 235

P8692MCUC E-Box™ Balanced ﬂue LPG Coals 4.10 3.52 86% Upgradable 410 560 235

8692PBUC E-Box™ Balanced ﬂue Nat. Gas Pebbles 4.10 3.52 86% Upgradable 410 560 235

P8692PBUC E-Box™ Balanced ﬂue LPG Pebbles 4.10 3.52 86% Upgradable 410 560 235

FRAME AND FRONT INFORMATION

Product Code

Complete Front Choice

8699GP Fusion Graphite 520 1127 38 8699IR Fusion Iridium 520 1127 38 8687BK Futura Black 520 1127 48 8272GP Designio front Graphite 595 615 68 8272IR Designio front Iridium 595 615 68 8680MB Dimension front Matt Black 540 635 68 8258BS Evolution front Stainless Steel 489 597 45 8256BS Inﬁniti front Stainless Steel 620 710 75 8253IR Progress front Iridium 520 598 60 8679 Richmond front Black Cast Iron 540 665 50 8696 Stockton Inset front Black Cast Iron 529 601 128 8697MB Winchester Matt Black 508 619 55

Fire Frame Choice

8283MB Arts frame Matt Black 510 605 8283PBR Arts frame Polished Brass 510 605 8283P Ar ts frame Polished Stainless Steel 510 605 8283BS Arts frame Brushed Stainless Steel 510 605

Description

Description Frame

E-Studio™

E-STUDIO™ FIRE INFORMATION

Product Code

8691CFCHUC E-Studio™ Conventional Nat. Gas White Stones 4.30 3.10 72% Upgradable 410 560 250

P8691CFCHUC E-Studio™ Conventional LPG White Stones 4.30 3.10 72% Upgradable 410 560 250

8692BFCHUC E-Studio™ Balanced ﬂue Nat. Gas White Stones 4.30 3.50 82% Upgradable 410 560 235

P8692BFCHUC E-Studio™ Balanced ﬂue LPG White Stones 3.75 3.00 79% Upgradable 410 560 235

FRAME AND FRONT INFORMATION

Product Code

Complete Front Choice

8699GP Fusion Graphite 520 1127 38 8699IR Fusion Iridium 520 1127 38 8687BK Futura Black 520 1127 48 8272GP* Designio front Graphite 595 615 68 8272IR* Designio front Iridium 595 615 68 8680MB Dimension front Matt Black 540 635 68 8258BS* Evolution front Stainless Steel 489 597 45 8253IR* Progress front Iridium 520 598 60 8695GP Steel front Graphite 850 670 32 8695IR Steel front Iridium 850 670 32 8697MB Winchester Matt Black 508 619 55

Fire Frame Choice

8283MB* Arts frame Matt Black 510 605 8283PBR* Arts frame Polished Brass 510 605 8283P* Arts frame Polished Stainless Steel 510 605 8283BS* Arts frame Brushed Stainless Steel 510 605 8283BPBR* Arts frame Polished Brass & Matt Black 510 605 8283BP* Arts frame 8283BBS* Arts frame

Description

Description Frame

Polished Stainless Steel & Matt Black Brushed Stainless Steel & Matt Black

Flue Type

Finish

Gas

Type

Frame Size (mm)

whd

Finish

Flue Type

Gas

Type

Effect

Frame Size (mm)

whd

510 605 510 605

Heat

Fuel

Effect

Fire Frame Choice cont'd.

8283BPBR Arts frame Polished Brass & Matt Black 510 605 8283BP Arts frame Polished Stainless Steel & Matt Black 510 605 8283BBS Arts frame Brushed Stainless Steel & Matt Black 510 605

Fire Front Choice

8282MB Arts ﬁre front Matt Black 390 230 8282PBR Ar ts ﬁre front Polished Brass 390 230 8282P Arts ﬁre front Polished Chrome 390 230 8282HP Arts ﬁre front Highlight Polished 390 230 8693MB Holyrood ﬁre front Matt Black 385 210 8693PBB Holyrood ﬁre front Polished Brass with black columns 385 210 8693HP Holyrood ﬁre front Highlight Polished 385 210 8693P Holyrood ﬁre front Polished Chrome 385 210 8694MB Spanish ﬁre front Matt Black 385 210 8694HP Spanish ﬁre front Highlight Polished 385 210 8694PBR Spanish ﬁre front Polished Brass 385 210 8694P Spanish ﬁre front Polished Chrome 385 210

Fuel

8282MB Arts ﬁre front Matt Black 390 230 8282PBR Arts ﬁre front Polished Brass 390 230 8282P Ar ts ﬁre front Polished Chrome 390 230 8282HP Arts ﬁre front Highlight Polished 390 230

*For E-Studio™ Balanced Flue ﬁres, please specify the codes below:

Heat

Input

Output

(kW)

Heat Input

(kW)

Product Code

Fire Front Choice

8272BFGP Designio front Graphite 8272BFIR Designio front Iridium 8258BFBS Evolution front Stainless Steel 8253BFIR Progress front Iridium 8283BFMB Arts frame Matt Black 8283BFPBR Arts frame Polished Brass 8283BFP Arts frame Polished Stainless Steel 8283BFBS Arts frame Brushed Stainless Steel 8283BFBPBR Arts frame Polished Brass & Matt Black 8283BFBP Arts frame Polished Stainless Steel & Matt Black 8283BFBBS Arts frame Brushed Stainless Steel & Matt Black

Efﬁciency

(kW)

Heat

Output

(kW)

Description Frame

Efﬁciency

Remote Control

Finish

Opening Size (mm)

whd

Opening Size (mm)

whd

Front Size (mm)

Frame Size (mm)

whd

Page 68

VFC Fires

135

VFC Convector Frame Choice

Description Frame Finish

16” Convector Fires 18” Convector Fires 22” Convector Fires

Product

Code

Dimensions (mm)

Product

Code

Dimensions (mm)

Product

Code

Dimensions (mm)

wh w h w h

Arts frame Matt Black

8284MB

510 605 N/A N/A N/A N/A N/A N/A

Arts frame Polished Brass

8284PBR

510 605 N/A N/A N/A N/A N/A N/A

Arts frame Polished Stainless Steel

8284P

510 605 N/A N/A N/A N/A N/A N/A

Arts frame Brushed Stainless Steel

8284BS

510 605 N/A N/A N/A N/A N/A N/A

Arts frame Polished Brass & Matt Black

8284BPBR

510 605 N/A N/A N/A N/A N/A N/A

Arts frame Polished Stainless Steel & Matt Black

8284BP

510 605 N/A N/A N/A N/A N/A N/A

Arts frame Brushed Stainless Steel & Matt Blac k

8284BBS

510 605 N/A N/A N/A N/A N/A N/A

Decorative frame # Matt Black

8285

505 610

8286

560 605

8287

655 605

Decorative frame # Polished Brass

8266

505 610

8267

560 605

8268

655 605

Decorative frame # Polished Stainless Steel

8232

505 610

8233

560 605

8234

655 605

Decorative frame # Brushed Stainless Steel

8235

505 610

8236

560 605

8237

655 605

Proﬁl (Standard) frame # Matt Black

8345

490 600

8355

540 600

8365

640 600

Proﬁl (Standard) frame # Polished Brass

8340

490 600

8350

540 600

8360

640 600

Proﬁl (Standard) frame # Polished Stainless Steel

8342

490 600

8352

540 600

8362

640 600

Proﬁl (Standard) frame # Brushed Stainless Steel

8229

490 600

8230

540 600

8231

640 600

Proﬁl (Standard) frame - LL # Matt Blac k

8346

490 545

8356

540 545

8366

640 545

Proﬁl (Standard) frame - LL # Polished Brass

8341

490 545

8351

540 545

8361

640 545

Proﬁl (Standard) wide frame # Polished Brass

8280

530 615

8281

580 618 N/A N/A N/A

FRAME AND FRONT INFORMATION cont'd.

VFC Convector and VFC Tapered Fire Front Choice

Description Frame Finish

16” Convector Fires 18” Convector Fires 22” Convector Fires

Product

Code

Dimensions (mm)

Product

Code

Dimensions (mm)

Product

Code

Dimensions (mm)

wh w h w h

Arts ﬁre front Matt Black

8282MB

390 230 N/A N/A N/A N/A N/A N/A

Arts ﬁre front Polished Brass

8282PBR

390 230 N/A N/A N/A N/A N/A N/A

Arts ﬁre front Polished Chrome

8282P

390 230 N/A N/A N/A N/A N/A N/A

Arts ﬁre front Highlight Polished

8282HP

390 230 N/A N/A N/A N/A N/A N/A

Holyrood ﬁre front Matt Black with brass ﬁnials

8391

385 265

8392

440 265

8393

540 265

Holyrood ﬁre front Polished Brass with black columns

8397

385 265

8398

440 265

8399

540 265

Holyrood ﬁre front Highlight Polished

8150

385 210

8151

440 210

8152

540 210

Holyrood ﬁre front Polished Chrome

8397P

385 210

8398P

440 210

8399P

540 210

Spanish ﬁre front Matt Black

8382

385 210

8383

440 210

8384

540 210

Spanish ﬁre front Polished Brass

8388

385 210

8389

440 210

8390

540 210

Spanish ﬁre front Highlight Polished

8153

385 210

8154

440 210

8155

540 210

Spanish ﬁre front Polished Chrome

8388P

385 210

8389P

440 210

8390P

540 210

VFC Fires

OPTIONS AND ACCESSORIES

Product Code

Description

8455 Standard remote control kit for VFC Convector

8435

Power Flue kit for VFC coal convector ﬁres, with brass wall switch. **

8435BS

Power Flue kit for VFC coal convector ﬁres, with

brushed steel wall switch ** 8448 Rear exit ﬂue adaptor for power ﬂue kit 8449 Top exit ﬂue adaptor for power ﬂue kit

8454

Safety terminal guard (required if power ﬂue outlet

is below 2 metres)

ADDITIONAL INFORMATION

You can install a VFC Convector Fire with a Stovax Cast Iron Victorian, Art Nouveau or Combination Fireplace. Please consult your local Gazco and Stovax dealer for further information.

# If you are ﬁtting a Decorative or Proﬁl frame with an Arts Front, an additional ﬁtting kit will be provided to ease installation.

** The power ﬂue kit includes 500mm ﬂue pipe. Any extra ﬂue pipe needs to be purchased separately, and needs to be of 125mm twin wall construction (not supplied by Gazco).

Additional Note: VFC ﬁres require 7" minimum ﬂue size.

16" 18" 22"

A 15"

380mm

17"

432mm

/4"

527mm

/2"

190mm

71/2"

190mm

71/2"

190mm

C7"

180mm7"180mm7"180mm

D10

/4"

260mm

121/4

310mm

414mm

FIRE INFORMATION

Product Code

16” VFC Convector Fires

8420UC VFC Convector 16” Class1/PF Nat. Gas Coals 9.45 4.75 50% Upgradable 410 560 310 P8420UC VFC Convector 16” Class1/PF LPG Coals 9.50 4.75 50% Upgradable 410 560 310

8421UC VFC Convector 16” (RD) Class1/PF Nat. Gas Coals 6.85 3.43 50% Upgradable 410 560 310

P8421UC VFC Convector 16” (RD) Class1/PF LPG Coals 6.65 3.30 50% Upg radable 410 560 310 8461UC VFC Convector 16” (LL) Class1/PF Nat. Gas Coals 9.45 4.75 50% Upgradable 410 510 310

8463UC VFC Convector 16” (LL / RD) Class1/PF Nat. Gas Coals 6.85 3.43 50% Upgradable 410 510 310

18” VFC Convector Fires

8425UC VFC Convector 18” Class1/PF Nat. Gas Coals 10.60 5.30 50% Upgradable 460 560 310 P8425UC VFC Convector 18” Class1/PF LPG Coals 10.60 5.30 50% Upgradable 460 560 310 8466UC VFC Convector 18” (LL) Class1/PF Nat. Gas Coals 10.60 5.30 50% Upgradable 460 510 310

22” VFC Convector Fires

8430UC VFC Convector 22” Class1/PF Nat. Gas Coals 12.30 6.15 50% Upgradable 560 560 310 P8430UC VFC Convector 22” Class1/PF LPG Coals 12.70 6.35 50% Upgradable 560 560 310 8471UC VFC Convector 22” (LL) Class1/PF Nat. Gas Coals 12.30 6.15 50% Upgradable 560 510 310

16” VFC Tapered Fires

8300UC VFC Tapered 16” Class 1 Nat. Gas Coals 9.45 2.35 25% Upgradable See table opposite P8300UC VFC Tapered 16” Class 1 LPG Coals 9.50 2.40 25% Upgradable See table opposite

8301UC VFC Tapered 16” (RD) Class 1 Nat. Gas Coals 6.85 1.70 25% Upgradable See table opposite

P8301UC VFC Tapered 16” (RD) Class 1 LPG Coals 6.65 1.65 25% Upgradable See table opposite

18” VFC Tapered Fires

8305UC VFC Tapered 18” Class 1 Nat. Gas Coals 10.60 2.65 25% Upgradable See table opposite P8305UC VFC Tapered 18” Class 1 LPG Coals 10.60 2.65 25% Upgradable See table opposite

22” VFC Tapered Fires

8310UC VFC Tapered 22” Class 1 Nat. Gas Coals 12.30 3.05 25% Upgradable See table opposite P8310UC VFC Tapered 22” Class 1 LPG Coals 12.70 3.05 24% Upgradable See table opposite

LL = Low Lintel RD = Reduced Draught Fire (input below 7kW so no additional ventilation required) Class1/PF = Suitable for Class 1 chimneys or a powered ﬂue installation

FRAME AND FRONT INFORMATION

Product Code

16” VFC Convector Complete Front Choice

8251GP Designio front Graphite 595 615 68 8251IR Designio front Iridium 595 615 68 8257BS Evolution front Stainless Steel 489 597 45 8249BS Inﬁniti front Brushed Stainless Steel 620 710 75 8253IR Progress front Iridium 520 598 60 8678 Richmond front Blac k Cast Iron 540 635 50

22” VFC Convector Complete Front Choice

8252GP Designio front Graphite 730 615 68 8252IR Designio front Iridium 730 615 68 8259BS Evolution front Stainless Steel 639 597 45 8254IR Progress front Iridium 670 598 60

The above information is to assist you in your choice of a suitable Gazco ﬁre. This is not intended to be all the information required to install your ﬁre.

134

This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

Description Flue

Description Frame

Finish

Gas

Fuel

Heat

Type

Effect

Input

(kW)

ADDITIONAL INFORMATION

Frame Size (mm)

whd

Efﬁciency Remote

Output

(kW)

Control

Opening Size (mm)

whd

Page 69

Stilo Fires

FIRE INFORMATION

Product Code Fireplace Flue Type Gas

Type

Fuel

Effect

Heat Input (kW)

Heat

Output

(kW)

9000 Victorian Tiled Insert N/A Electric Coals N/A 2.00

9062 Combination Fireplace N/A Electric Coals N/A 2.00

9064 Arched Insert N/A Electric Coals N/A 2.00

9102 Art Nouveau Tiled Insert N/A Electric Coals N/A 2.00

Electric Fires for Stovax Classic Fireplaces

137

The above information is to assist you in your choice of a suitable Gazco Fire Basket. This is not intended to be all the information required to install your ﬁre. This can be obtained from your local Gazco retailer or you can download the full installation instructions from the Gazco website at www.gazco.com

* Allow 150mm between basket and ﬁreplace opening to reach right hand side controls. ** All electric ﬁre basket controls are located at the front of the basket.

†

Please note the Small Amhurst, Small Art Deco and Small Milan can be supplied as reduced draft versions where the input is under 7kW. This means that no air vent will be required.

††

Swan's Nest has 'extended' controls only.

Fire Baskets

Adam  – 420x440x285 – – – 13.0 2.65 ––––

Amhurst*

†

 395x330x275 520x330x280 – – 12.0 2.4 15.0 3.0 – –

Art Deco*

†

 395x305x280 520x305x280 – – 12.0 2.4 15.0 3.0 – –

Ascot* –  735x355x405 – – – 15.0 3.0 ––––

Aspen*  – 600x160x400 – 760x160x510 – –  13.0 2.6 – – 15.0 3.0

Audley* –  520x300x280 – – – 15.0 3.0 ––––

Chamonix (Steel)  – 600x160x400 650x160x350 – – –  13.0 2.6 15.0 3.0 – –

Chamonix (Glass)  – 535x485x305 – – – –  13.0 2.6 ––––

Cheltenham* –  535x485x305 – – – 15.0 3.0 ––––

Cromwell  – 395x150x250 – 490x150x275  – – 12.0 2.4 – – 15.0 3.0

Davos  – 560x230x310 – – – – – 11.0 2.2 ––––

Dorchester* –  520x330x280 – – – 15.0 3.0 ––––

Earlswood* –  520x330x280 – – – 15.0 3.0 ––––

Halifax* –  520x455x280 – – – 15.0 3.0 ––––

Harlech* –  520x485x280 – – – 15.0 3.0 ––––

Inverness* –  535x685x280 – – – 15.0 3.0 ––––

Kendal* –  900x660x430 – – – 15.0 3.0 ––––

Kennet* –  520x645x280 – – – 15.0 3.0 ––––

Ludlow* –  560x645x280 – – – 15.0 3.0 ––––

Melbury* – 

740x645x405 – – – 15.0 3.0 – – – –

Milan

†

 601x305x378 727x305x378 – – 12.0 2.4 15.0 3.0 – –

Montrose* –  740x580x405 – – – 15.0 3.0 ––––

Plymouth

 – 430x440x285 – – – 15.0 2.6 ––––

Portland* –  520x305x280 – – – 15.0 3.0 ––––

Portland Extended* –  735x305x308 – – – 15.0 3.0 ––––

Pub Scene  – 430x455x285 – – – 13.0 2.6 ––––

Rochester*  520x415x280 – – – 15.0 3.0 ––––

Stratford*  520x330x280 – – – 15.0 3.0 ––––

Spanish  – 447x235x318 – 525x235x369 – 13.0 2.6 – – 15.0 3.0

Swan's Nest

††

– – 800x435x490 950x435x490

1250x435x525

 –– – – 16.0 3.2 21.9 4.4 32.0 6.4

Tahoe  – 630x165x300 – – – –  12.0 2.4 ––––

Model

Gas

Controls

Front

Small

Small Medium Large

Medium Large

Solid fuels

Electric coals

Gas coals

Gas logs

Gas driftwood

Gas glass

In Out In Out In Out

Right side

Overall Dimensions

WxHxD in mm Gas Heat Outputs (kW)Fuel Options

600

FRAME & FRONT INFORMATION

Description Frame Finish

Stilo front for Premier Slimline & Power Flue Convector Iridium 470 615

FIRE INFORMATION

Product Code Description

K8216 Premier Slimline Convector Class 1 & 2 Nat. Gas Coal 6.80 3.30 48% 350 560 123

K8191 Premier Slimline Power Flue Convector Power ﬂue Nat. Gas Coal 6.70 3.10 46% 350 560 See info above

K1525 Premier Electric Inset N/A Electric Coal N/A 2.00 99% 406 559 110

Gas Fires for Stovax Classic Fireplaces

FIRE INFORMATION

Product Code Fireplace Flue Type Gas

8000MCUC Victorian Tiled Insert Class 1 Nat. Gas Coals 10.00 2.00

P8000MCUC Victorian Tiled Inser t Class 1 LPG Coals 10.00 2.00

8210MCUC Victorian Tiled Front Class 1 Nat. Gas Coals 12.00 2.40

P8210MCUC Victorian Tiled Front Class 1 LPG Coals 12.00 2.40

8002MCUC Horseshoe Insert Class 1 Nat. Gas Coals 10.00 2.00

P8002MCUC Horseshoe Insert Class 1 LPG Coals 10.00 2.00

8004MCUC Adelaide Insert Class 1 Nat. Gas Coals 10.00 2.00

P8004MCUC Adelaide Insert Class 1 LPG Coals 10.00 2.00

8041MCUC Regency Hob Insert Class 1 Nat. Gas Coals 9.00 1.80

P8041MCUC Regency Hob Inser t Class 1 LPG Coals 9.00 1.80

8062MCUC Combination Insert Class 1 Nat. Gas Coals 10.00 2.00

P8062MCUC Combination Insert Class 1 LPG Coals 10.00 2.00

8064MCUC Arched Insert Class 1 Nat. Gas Coals 10.00 2.00

P8064MCUC Arched Insert Class 1 LPG Coals 10.00 2.00

8102MCUC Art Nouveau Tiled Insert Class 1 Nat. Gas Coals 10.00 2.00

P8102MCUC Art Nouveau Tiled Insert Class 1 LPG Coals 10.00 2.00

8202MCUC Art Nouveau Tiled Front Class 1 Nat. Gas Coals 12.00 2.40

P8202MCUC Art Nouveau Tiled Front Class 1 LPG Coals 12.00 2.40

8300UC Poppy & Wheatsheaf Tiled Front Class 1 Nat. Gas Coals 9.45 2.35

P8300UC Poppy & Wheatsheaf Tiled Front Class 1 LPG Coals 9.50 2.40

8301UC Poppy & Wheatsheaf Tiled Front (RD) Class 1 Nat. Gas Coals 6.85 1.70

P8301UC Poppy & Wheatsheaf Tiled Front (RD) Class 1 LPG Coals 6.65 1.65

8023MCUC Knightsbridge & Kensington Insert Class 1 Nat. Gas Coals 16.0 3.20

P8023MCUC Knightsbridge & Kensington Insert Class 1 LPG Coals 16.0 3.20

8023LUC Knightsbridge & Kensington Insert Class 1 Nat. Gas Logs 16.0 3.20

P8023LUC Knightsbridge & Kensington Insert Class 1 LPG Logs 16.0 3.20

RD = Reduced Draught Fire (input below 7kW so no additional ventilation required) n

OPTIONS AND ACCESSORIES

Product Code Description

8455 Standard remote control kit

136

Flue Type

Frame Size (mm)

Heat

Gas

Fuel

Type

Effect

Input

(kW)

Heat

Output

(kW) Efﬁciency

Type

ADDITIONAL INFORMATION

Installation of Premier Power Flue Convector

Opening Size (mm)

wh d

Fuel

Effect

Heat

Input

(kW)

104

Heat

Output

(kW)

557

Page 70

Technical Specifications

Gazco gratefully acknowledges the assistance of the following companies with photographic settings:

Furnishings and Ornaments:- www.furniturevillage.co.uk; www.lauraashley.com; www.faginsantiques.com; www.theorangetree.co.uk; www.habitat.co.uk; www.houseoffraser.co.uk; www.ashorejeweller y.co.uk; www.eclectique.co.uk; www.debenhams.com; www.next.co.uk; Pilgrim 01404 41219

Wood Mantels:- www.stovax.com Stone Mantels:- www.farmington.co.uk; www.bnsp.co.uk; www.grandisson.com Wood flooring:- www.beechbros.co.uk Tiles & Stone floors:- www.originalstyle.com Televisions:- www.heavitreeradio.co.uk Plants:- www.stbridgetnurseries.co.uk Paintings:- www.easyart.com

Other products offered by the Gazco family that may be of interest to you include:

Gazco Stoves www.gazco.com

Featuring one of the widest selections of contemporary and traditional Stoves, there is a Gazco stove for every style of home. Offering you the wonderful ambience of a real fire-effect with superb efficiency, these beautiful stoves give you a choice of gas or electric to heat your home.

Redfyre Range Cookers www.redfyrecookers.co.uk

Handcrafted by skilled artisans, Redfyre’s leading collection of range cookers build upon their heritage dating back to 1931. A multitude of versions and options are available including the Traditional, Central Heating or Universal – combining the heat store efficiencies with the utmost of modern usability. All versions are available in a choice of 6 beautifully enamelled colours and options including a choice of gas, oil or electric; 2 or 4 ovens; round or square hobplate covers; gas, electric or induction hobs; the ability to run up to 24 radiators and provide domestic hot water.

Godin Cookers www.godincookers.co.uk

Godin cookers and stoves have been manufactured in France since 1840. Now available in the UK and Republic of Ireland through Redfyre range cookers is the Godin cookers family of the Souveraine, Chatelaine and Exclusive cookers. Godin cookers have a reputation as leader in the development of heating and cooking products and artfully blend tradition with innovation to provide the ultimate kitchen accoutrements. Individually handmade to the highest standards, these professional quality appliances are the cookers of choice for many Michelin c hefs.

Wamsler Cookers and Stoves www.wamslercookers.co.uk

Wamsler products, synonymous with the manufacture of solid fuel cookers and heating products, are now available in the UK and Republic of Ireland through Redfyre range cookers. Featuring a wide choice of solid fuel cookers, central heating cookers and multi-fuel stoves that are particularly suited to British & Irish homes, Wamsler offer a viable ecological way to heat your home and cook.

To receive a copy of the Gas Stoves brochure, please call 01392 474061. For a copy of Redfyre, Godin or Wamsler brochures please call 01392 474079. Alternatively, details on the full range of products and Brochure PDF’s, along with your nearest dealers contact details, can be found at all the websites as detailed above.

Gazco is a member of the Stovax Group which manufactures and distributes many other high quality fireplace products:

All specifications given in this brochure are approximate. Actual specifications for each individual product will vary according to model. Your Gazco retailer will be pleased to provide any further information you require or you may view/download specification sheets from www.gazco.com

Installation

Gazco gas fires must be fitted by a qualified gas installer (CORGI registered in the UK) who should also verify the proposed site conditions are fully suitable for the product selected. Complete installation instructions for many models can be obtained prior to purchase by downloading them from www.gazco.com

Colours

Owing to variations in studio lighting and printing inks, the finishes/colours of fires illustrated in this brochure may differ slightly from actual models. Before purchasing, please ask your retailer to show you finish/colour samples.

Care and maintenance

Traditional materials, such as polished steel and brass, tarnish on contact with air, especially when also exposed to heat. To help minimise this effect, we recommend fires receive regular treatment with Stovax Steel Cleaner and Stovax Brass & Copper Polish. Other surfaces can be maintained from time to time with Stovax Stainless Steel Cleaner and Stovax Traditional Black Grate Polish. Additionally, please remember that gas fires will require servicing annually by a CORGI registered engineer.

Product improvement

Gazco's policy is one of constant product improvement. Appliances may therefore sometimes differ from the descriptions or illustrations in this brochure.

Please note: The operation and appearance of gas appliances depends on variable factors such as gas pressure supplied and exact fire conditions.

138

Air ventilation for gas fires

To comply with gas appliance installation regulations, all Studio 2 and 3 Open Fronted fires, all Glass Fronted Conventionally flued Studio 2 fires, all Standard VFC Convector and tapered fires, all fires for Stovax Classic Fireplaces and most Fire Baskets require additional ventilation into your room. Please consult either your Gazco retailer or the Gazco Technical Information on our website www.gazco.com to confirm the ventilation required. Gazco offer suitable wall and floor vents which are available from your local retailer. All other fires featured in this brochure do not require additional ventilation.

Wall Vent -

One size, choice of brass or stainless steel

Floor Vent -

Two sizes, brass only

Cast iron performance

Stovax Gas and Electric Fires User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
