TS1871-TS1872-TS1874
1.8V Input/Output Rail-to-Rail
Low Power Operational Amplifiers
■Operating at VCC = 1.8V to 6V
■Rail-to-rail input & output
■Extended Vicm (VDD - 0.2V to VCC + 0.2V)
■Low supply current (400 A)
■Gain bandwidth product (1.6MHz)
■High stability
■ESD tolerance (2kV)
■Latch-up immunity
■Available in SOT23-5 micropackage
Description
The TS187x (single, dual & quad) is an operational amplifier family able to operate with voltage as low as 1.8V and features both I/O rail- to-rail.
The common mode input voltage extends 200mV at 25°C beyond the supply voltages while the output voltage swing is within 100mV of each rail with 600 Ohm load resistor. This device consumes typically 400µA per channel while offering 1.6Mhz of gain-bandwidth product. The amplifier provides high output drive capability typically at 65mA-load.
These performances make the TS187X family ideal for sensor interface, battery-supplied and portable applications.
Pin Connections (top view)
TS1871ILT |
|
|
|
Output |
1 |
5 |
VCC |
VDD |
2 |
|
|
Non Inverting Input |
3 |
4 |
Inverting Input |
TS1871ID-TS1871IDT
N.C. |
1 |
|
8 |
N.C. |
Inverting Input |
2 |
_ |
7 |
VCC |
Non Inverting Input |
3 |
+ |
6 |
Output |
VDD |
4 |
|
5 |
N.C. |
TS1872IST-TS1872IN-TS1872ID-TS1872IPT
Output 1 |
1 |
|
|
8 |
VCC |
Inverting Input 1 |
2 |
_ |
|
7 |
Output 2 |
Non Inverting Input 1 |
3 |
+ |
_ |
6 |
Inverting Input 2 |
VDD |
4 |
|
+ |
5 |
Non Inverting Input 2 |
TS1874IN-TS1874ID-TS1874IDT-TS1874IPT |
|||||
Output 1 |
1 |
|
|
14 |
Output 4 |
Inverting Input 1 |
2 |
_ |
_ |
13 |
Inverting Input 4 |
Non Inverting Input 1 |
3 |
+ |
+ |
12 |
Non Inverting Input 4 |
|
|
||||
VCC |
4 |
|
|
11 |
VDD |
Non Inverting Input 2 |
5 |
+ |
+ |
10 |
Non Inverting Input 3 |
Inverting Input 2 |
6 |
_ |
_ |
9 |
Inverting Input 3 |
|
|
||||
Output 2 |
7 |
|
|
8 |
Output 3 |
Applications
■ |
Battery-powered applications (toys) |
■ |
Audio driver (headphone driver) |
■ |
Portable communication devices (cell |
■ |
Laptop/notebook computers |
|
phone) |
|
|
Order Codes
Part Number |
Temperature |
Package |
Packaging |
Marking |
||
Range |
||||||
|
|
|
|
|||
|
|
|
|
|
|
|
TS1871ID/IDT/AID/AIDT |
|
|
SO |
Tube or Tape & Reel |
|
|
TS1871ILT/AILT |
|
|
SOT23-5L |
Tape & Reel |
K171/K172 |
|
TS1872IN/AIN |
|
|
DIP |
Tube |
|
|
TS1872ID/IDT/AID/AIDT |
|
|
SO |
Tube or Tape & Reel |
|
|
TS1872IPT/AIPT |
|
|
TSSOP |
Tape & Reel |
|
|
|
-40°C, +125°C |
(Thin Shrink Outline Package) |
|
|||
|
|
|
||||
TS1872IST/AIST |
|
|
mini SO |
Tape & Reel |
K171/K172 |
|
TS1874IN/AIN |
|
|
DIP |
Tube |
|
|
TS1874ID/IDT/AID/AIDT |
|
|
SO |
Tube or Tape & Reel |
|
|
TS1874IPT/AIPT |
|
|
TSSOP |
Tape & Reel |
|
|
|
|
|
(Thin Shrink Outline Package) |
|
||
|
|
|
|
|
||
May 2005 |
|
|
Revision 2 |
|
1/22 |
|
|
|
|
|
|
|
TS1871-TS1872-TS1874 |
Absolute Maximum Ratings |
||
1 Absolute Maximum Ratings |
|
|
|
Table 1: Key parametes and their absolute maximum ratings |
|
|
|
|
|
|
|
Symbol |
Parameter |
Value |
Unit |
|
|
|
|
VCC |
Supply voltage 1 |
7 |
V |
Vid |
Differential Input Voltage 2 |
±1 |
V |
Vi |
Input Voltage |
VDD-0.3 to VCC +0.3 |
V |
Tstg |
Storage Temperature |
-65 to +150 |
°C |
Tj |
Maximum Junction Temperature |
150 |
°C |
Rthja |
Thermal Resistance Junction to Ambient3 |
250 |
°C/W |
|
SOT23-5 |
||
|
|
||
|
SO8 |
125 |
|
|
SO14 |
103 |
|
|
TSSOP8 |
120 |
|
|
TSSOP14 |
100 |
|
|
miniSO8 |
190 |
|
|
|
|
|
|
HBM: Human Body Model4 |
2 |
kV |
ESD |
MM: Machine Model5 |
200 |
V |
|
CDM: Charged Device Model |
1.5 |
kV |
|
|
|
|
|
Latch-up Immunity |
200 |
mA |
|
|
|
|
|
Lead Temperature (soldering, 10sec) |
250 |
°C |
|
|
|
|
|
Output Short Circuit Duration |
see note6 |
|
1)All voltages values, except differential voltage are with respect to network terminal.
2)Differential voltages are the non-inverting input terminal with respect to the inverting input terminal. If Vid > ±1V, the maximum input current must not exceed ±1mA. In this case (Vid > ±1V) an input serie resistor must be added to limit input current.
3)Short-circuits can cause excessive heating. Destructive dissipation can result from simultaneous short-circuit on all amplifiers
4)Human body model, 100pF discharged through a 1.5kΩ resistor into pin of device.
5)Machine model ESD, a 200pF cap is charged to the specified voltage, then discharged directly into the IC with no external series resistor (internal resistor < 5Ω), into pin to pin of device.
6)Short-circuits from the output to Vcc can cause excessive heating. The maximum output current is approximately 80mA, independent of the magnitude of Vcc. Destructive dissipation can result from simultaneous short-circuits on all amplifiers.
Table 2: Operating conditions
Symbol |
Parameter |
Value |
Unit |
|
|
|
|
VCC |
Supply Voltage |
1.8 to 6 |
V |
|
|
|
|
Vicm |
Common Mode Input Voltage Range 1 |
VDD - 0.2 to VCC + 0.2 |
V |
Vicm |
Common Mode Input Voltage Range 2 |
VDD to VCC |
V |
Toper |
Operating Free Air Temperature Range |
-40 to + 125 |
°C |
1)At 25°C, for 1.8 ≤ VCC ≤ 6V, Vicm is extended to VDD - 0.2V, VCC + 0.2V.
2)In full temperature range, both Rails can be reached when VCC does not exceed 5.5V.
2/22
Electrical Characteristics |
TS1871-TS1872-TS1874 |
Table 3: VCC = +1.8V, VDD = 0V, RL, CL connected to VCC/2, Tamb = 25°C (unless otherwise specified)
Symbol |
Parameter |
Min. |
Typ. |
Max. |
Unit |
|
|
|
|
|
|
|
Input Offset Voltage |
|
|
|
|
Vio |
Vicm = Vout = VCC /2 |
|
0.1 |
3 |
mV |
TS1871/2/4 |
|
||||
|
|
|
|||
|
TS1871A/2A/4A |
|
|
1 |
|
|
|
|
|
|
|
∆Vio |
Input Offset Voltage Drift |
|
2 |
|
µV/°C |
|
|
|
|
|
|
Iio |
Input Offset Current 1 |
|
3 |
30 |
nA |
Vicm = Vout = VCC /2 |
|
||||
|
|
|
|
|
|
Iib |
Input Bias Current 1) |
|
40 |
125 |
nA |
Vicm = Vout = VCC /2 |
|
||||
|
|
|
|
|
|
CMR |
Common Mode Rejection Ratio |
|
|
|
dB |
0 ≤ Vicm ≤ VCC, Vout = VCC /2 |
55 |
77 |
|
||
|
|
|
|||
|
|
|
|
|
|
SVR |
Supply Voltage Rejection Ratio |
70 |
80 |
|
dB |
|
|
|
|
|
|
|
Large Signal Voltage Gain |
|
|
|
|
Avd |
Vout = 0.5V to 1.3V |
|
|
|
dB |
RL = 2kΩ |
77 |
92 |
|
||
|
RL = 600Ω |
70 |
85 |
|
|
|
|
|
|
|
|
|
High Level Output Voltage |
|
|
|
|
VOH |
Vid = 100mV |
|
|
|
V |
RL = 2kΩ |
1.65 |
1.77 |
|
||
|
RL = 600Ω |
1.62 |
1.74 |
|
|
|
|
|
|
|
|
|
Low Level Output Voltage |
|
|
|
|
VOL |
Vid = -100mV |
|
|
|
mV |
RL = 2kΩ |
|
88 |
100 |
||
|
RL = 600Ω |
|
115 |
150 |
|
|
|
|
|
|
|
|
Output Source Current |
|
|
|
|
Io |
VID = 100mV, VO = VDD |
20 |
65 |
|
mA |
Output Sink Current |
|
|
|
||
|
|
|
|
|
|
|
VID = -100mV, VO = VCC |
20 |
65 |
|
|
|
|
|
|
|
|
ICC |
Supply Current (per amplifier), Vout = Vcc/2 |
|
|
|
µA |
AVCL = 1, no load |
|
400 |
560 |
||
|
|
|
|||
|
|
|
|
|
|
GBP |
Gain Bandwidth Product |
0.9 |
1.6 |
|
MHz |
RL = 10kΩ, CL = 100pF, f = 100kHz |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
SR |
Slew Rate |
0.38 |
0.54 |
|
V/µs |
RL = 10kΩ, CL = 100pF, AV = 1 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
φm |
Phase Margin |
|
53 |
|
Degrees |
CL = 100pF |
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
en |
Input Voltage Noise |
|
27 |
|
nV/√Hz |
|
|
|
|
|
|
THD |
Total Harmonic Distortion |
|
0.01 |
|
% |
|
|
|
|
|
|
1) Maximum values including unavoidable inaccuracies of the industrial test.
3/22
TS1871-TS1872-TS1874 Electrical Characteristics
Table 4: VCC = +3V, VDD = 0V, RL, CL connected to VCC/2, Tamb = 25°C (unless otherwise specified)
Symbol |
Parameter |
Min. |
Typ. |
Max. |
Unit |
|
|
|
|
|
|
|
Input Offset Voltage |
|
|
|
|
Vio |
Vicm = Vout = VCC /2 |
|
0.1 |
3 |
mV |
TS1871/2/4 |
|
||||
|
|
|
|||
|
TS1871A/2A/4A |
|
|
1 |
|
|
|
|
|
|
|
∆Vio |
Input Offset Voltage Drift |
|
2 |
|
µV/°C |
|
|
|
|
|
|
Iio |
Input Offset Current 1 |
|
3 |
30 |
nA |
Vicm = Vout = VCC /2 |
|
||||
|
|
|
|
|
|
Iib |
Input Bias Current 1) |
|
4 |
125 |
nA |
Vicm = Vout = VCC /2 |
|
||||
|
|
|
|
|
|
CMR |
Common Mode Rejection Ratio |
|
|
|
dB |
0 ≤ Vicm ≤ VCC, Vout = VCC /2 |
60 |
80 |
|
||
|
|
|
|||
|
|
|
|
|
|
SVR |
Supply Voltage Rejection Ratio |
70 |
85 |
|
dB |
|
|
|
|
|
|
|
Large Signal Voltage Gain |
|
|
|
|
Avd |
Vout = 0.5V to 2.5V |
|
|
|
dB |
RL = 2kΩ |
80 |
92 |
|
||
|
RL = 600Ω |
|
|
||
|
|
74 |
95 |
|
|
|
|
|
|
|
|
|
High Level Output Voltage |
|
|
|
|
VOH |
Vid = 100mV |
|
|
|
V |
RL = 2kΩ |
2.82 |
2.95 |
|
||
|
RL = 600Ω |
2.80 |
2.95 |
|
|
|
|
|
|
|
|
|
Low Level Output Voltage |
|
|
|
|
VOL |
Vid = -100mV |
|
|
|
mV |
RL = 2kΩ |
|
88 |
L120 |
||
|
RL = 600Ω |
|
115 |
160 |
|
|
|
|
|
|
|
|
Output Source Current |
|
|
|
|
Io |
VID = 100mV, VO = VDD |
20 |
80 |
|
mA |
Output Sink Current |
|
|
|
||
|
|
|
|
|
|
|
VID = -100mV, VO = VCC |
20 |
80 |
|
|
|
|
|
|
|
|
ICC |
Supply Current (per amplifier), Vout = Vcc/2 |
|
|
|
µA |
AVCL = 1, no load |
|
450 |
650 |
||
|
|
|
|||
|
|
|
|
|
|
GBP |
Gain Bandwidth Product |
1 |
1.7 |
|
MHz |
RL = 10kΩ, CL = 100pF, f = 100kHz |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
SR |
Slew Rate |
0.42 |
0.6 |
|
V/µs |
RL = 10kΩ, CL = 100pF, AV = 1 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
φm |
Phase Margin |
|
53 |
|
Degrees |
CL = 100pF |
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
en |
Input Voltage Noise |
|
27 |
|
nV/√Hz |
|
|
|
|
|
|
THD |
Total Harmonic Distortion |
|
0.01 |
|
% |
|
|
|
|
|
|
1) Maximum values including unavoidable inaccuracies of the industrial test.
4/22
Electrical Characteristics |
TS1871-TS1872-TS1874 |
|||||
Table 5: VCC = +5V, VDD = 0V, CL & RL connected to VCC/2, Tamb = 25°C (unless otherwise |
|
|||||
specified) |
|
|
|
|
|
|
|
|
|
|
|
|
|
Symbol |
Parameter |
Min. |
Typ. |
Max. |
|
Unit |
|
|
|
|
|
|
|
|
Input Offset Voltage |
|
|
|
|
|
Vio |
Vicm = Vout = VCC /2 |
|
0.1 |
3 |
|
mV |
TS1871/2/4 |
|
|
||||
|
|
|
|
|||
|
TS1871A/2A/4A |
|
|
1 |
|
|
|
|
|
|
|
|
|
∆Vio |
Input Offset Voltage Drift |
|
2 |
|
|
µV/°C |
|
|
|
|
|
|
|
Iio |
Input Offset Current 1 |
|
3 |
30 |
|
nA |
Vicm = Vout = VCC /2 |
|
|
||||
|
|
|
|
|
|
|
Iib |
Input Bias Current 1) |
|
70 |
130 |
|
nA |
Vicm = Vout = VCC /2 |
|
|
||||
|
|
|
|
|
|
|
CMR |
Common Mode Rejection Ratio |
65 |
85 |
|
|
dB |
0 ≤ Vicm ≤ VCC, Vout different of VCC /2 |
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SVR |
Supply Voltage Rejection Ratio |
70 |
90 |
|
|
dB |
|
|
|
|
|
|
|
|
Large Signal Voltage Gain |
|
|
|
|
|
Avd |
Vout = 1V to 4V |
|
|
|
|
dB |
RL = 2kΩ |
83 |
92 |
|
|
||
|
RL = 600Ω |
77 |
85 |
|
|
|
|
|
|
|
|
|
|
|
High Level Output Voltage |
|
|
|
|
|
VOH |
Vid = 100mV |
|
|
|
|
V |
RL = 2kΩ |
4.80 |
4.95 |
|
|
||
|
RL = 600Ω |
4.75 |
4.90 |
|
|
|
|
|
|
|
|
|
|
|
Low Level Output Voltage |
|
|
|
|
|
VOL |
Vid = -100mV |
|
|
|
|
mV |
RL = 2kΩ |
|
88 |
130 |
|
||
|
RL = 600Ω |
|
115 |
188 |
|
|
|
|
|
|
|
|
|
|
Output Source Current |
|
|
|
|
|
Io |
VID = 100mV, VO = VDD |
20 |
80 |
|
|
mA |
Output Sink Current |
|
|
|
|
||
|
|
|
|
|
|
|
|
VID = -100mV, VO = VCC |
20 |
80 |
|
|
|
|
|
|
|
|
|
|
ICC |
Supply Current (per amplifier), Vout = Vcc/2 |
|
|
|
|
µA |
AVCL = 1, no load |
|
500 |
835 |
|
||
|
|
|
|
|||
|
|
|
|
|
|
|
GBP |
Gain Bandwidth Product |
1 |
1.8 |
|
|
MHz |
RL = 10kΩ, CL = 100pF, f = 100kHz |
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SR |
Slew Rate |
0.42 |
0.6 |
|
|
V/µs |
RL = 10kΩ, CL = 100pF, AV = 1 |
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
φm |
Phase Margin |
|
55 |
|
|
Degrees |
CL = 100pF |
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
en |
Input Voltage Noise |
|
27 |
|
|
nV/√Hz |
|
|
|
|
|
|
|
THD |
Total Harmonic Distortion |
|
0.01 |
|
|
% |
|
|
|
|
|
|
|
1) Maximum values including unavoidable inaccuracies of the industrial test.
5/22
TS1871-TS1872-TS1874 |
Electrical Characteristics |
Figure 1 : |
|
|
|
|
|
|
|
|
|
|
|
|
|
Input Offset Voltage Distribution |
|
|
|||||||
|
160 |
|
|
|
|
|
|
|
|
|
|
|
140 |
|
|
|
|
|
|
492 pieces tested |
|
||
|
|
|
|
|
|
|
Vcc = 5V |
|
|
||
|
|
|
|
|
|
|
|
|
|
||
pieces |
120 |
|
|
|
|
|
|
Temp = +25°C |
|
||
|
|
|
|
|
|
|
|
|
|
||
100 |
|
|
|
|
|
|
|
|
|
|
|
of |
|
|
|
|
|
|
|
|
|
|
|
Quantity |
80 |
|
|
|
|
|
|
|
|
|
|
|
60 |
|
|
|
|
|
|
|
|
|
|
|
40 |
|
|
|
|
|
|
|
|
|
|
|
20 |
|
|
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
|
|
|
|
|
|
|
-2. |
-1.6 |
-1.2 |
-.8 |
-.4 |
0 |
.4 |
.8 |
1.2 |
1.6 |
2 |
|
|
|
Input Offset Voltage (mV) |
|
|
|
Figure 2 :
Input Bias Current vs. Temperature
|
10.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Vcc = 1.8V |
|
|
|
0.0 |
|
|
|
|
|
|
Vicm = 0.9V |
|
|
(nA) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
current |
-10.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input bias |
-20.0 |
|
|
|
|
|
|
|
|
|
-30.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
-40.0 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
Figure 3 :
Supply Current / Amplifier vs. Supply Voltage
|
600 |
|
|
|
|
(µA) |
500 |
|
|
|
|
|
|
|
|
|
|
Current |
400 |
|
|
|
|
300 |
|
|
Tamb = 25°C |
|
|
Supply |
|
|
|
|
|
200 |
|
|
|
|
|
|
100 |
|
|
|
|
|
0 |
|
|
|
|
|
0 |
2 |
4 |
6 |
8 |
Supply Voltage (V)
Figure 4 :
Input Offset Voltage Drift vs. Temperature
|
200 |
|
|
|
|
|
|
Vcc = 1.8V |
|
|
|
|
|
|
|
|
|
|
|
||
|
150 |
|
|
|
|
|
|
|
|
|
(µV) |
100 |
|
|
|
|
|
|
Vcc = 3V |
|
|
Drift |
50 |
|
|
|
|
|
|
|
|
|
Voltage |
|
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
|
|
Vcc = 5V |
|
||
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
Input |
-50 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
-100 |
|
|
|
|
|
|
|
|
|
|
-150 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
|
|
|
|
Temperature (°C) |
|
|
|
Figure 5 :
Input Bias Current vs. Temperature
|
10.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Vcc = 3V |
|
|
|
|
|
|
|
|
|
|
Vicm = 1.5V |
||
(nA) |
0.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
bias current |
-10.0 |
|
|
|
|
|
|
|
|
|
-20.0 |
|
|
|
|
|
|
|
|
|
|
Input |
-30.0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
-40.0 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
Figure 6 :
Supply Current / Amplifier vs. Temperature
|
550 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Vcc = 5V |
|
|
|
500 |
|
|
|
|
|
|
|
|
|
(µA) |
|
|
|
|
|
|
|
Vcc = 3V |
|
|
450 |
|
|
|
|
|
|
|
|
|
|
Current |
400 |
|
|
|
|
|
|
Vcc = 1.8V |
|
|
|
|
|
|
|
|
|
|
|
|
|
Supply |
350 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
300 |
|
|
|
|
|
|
|
|
|
|
250 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
|
|
|
|
|
Temperature (°C) |
|
|
|
6/22
Electrical Characteristics |
TS1871-TS1872-TS1874 |
Figure 7 :
Common Mode Rejection vs. Temperature
|
120 |
|
|
|
|
|
Vcc = 1.8V |
|
|
|
|
|
|
|
|
|
|
|
|
||
(dB) |
115 |
|
|
|
|
|
Vicm = 0V |
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
Rejection |
110 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Vcc = 3V |
|
|
|
|
105 |
|
|
|
|
|
Vicm = 0V |
|
|
||
Mode |
100 |
|
|
|
|
|
|
|
|
|
Common |
95 |
|
|
|
|
|
Vcc = 5V |
|
|
|
|
|
|
|
|
Vicm = 0V |
|
|
|||
|
|
|
|
|
|
|
|
|||
90 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
85 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
Figure 8 :
Supply Voltage Rejection vs. Temperature
|
110 |
|
|
|
|
|
|
|
|
|
|
|
Vcc = 3V |
|
|
|
|
|
|
|
|
(dB) |
100 |
Vicm = 0V |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Rejection |
90 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Voltage |
80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Supply |
70 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
Figure 9 :
Power Supply Voltage Rejection vs. Frequency
|
-20 |
|
|
|
(dB) |
|
Vcc = 1.8V |
|
|
-30 |
Vicm = 0.7V |
|
|
|
Rejection |
|
Gain = 10 |
|
|
-40 |
|
|
|
|
|
|
|
|
|
Voltage |
-50 |
|
|
|
-60 |
|
|
|
|
Supply |
|
|
|
|
-70 |
|
|
|
|
|
|
|
|
|
|
-80 |
|
|
|
|
100 |
1000 |
10000 |
100000 |
|
|
Frequency (Hz) |
|
Figure 10 :
Supply Voltage Rejection vs. Temperature
|
110 |
|
|
|
|
|
|
|
|
|
|
|
Vcc = 1.8V |
|
|
|
|
|
|
|
|
(dB) |
100 |
Vicm = 0V |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Rejection |
90 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Voltage |
80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Supply |
70 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
Figure 11 :
Supply Voltage Rejection vs. Temperature
|
110 |
|
|
|
|
|
|
|
|
|
|
|
Vcc = 5V |
|
|
|
|
|
|
|
|
(dB) |
100 |
Vicm = 0V |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
Rejection |
90 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Voltage |
80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Supply |
70 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
60 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
Figure 12 :
Open Loop Gain vs. Temperature
|
110 |
|
|
|
|
|
|
|
|
|
|
|
Vcc = 1.8V |
|
|
|
|
|
|
|
|
|
|
Vicm = 0.9V |
|
|
|
|
|
|
|
|
Gain (dB) |
100 |
|
|
|
|
|
|
RL = 2 kOhms |
|
|
|
|
|
|
|
|
|
|
|||
90 |
|
|
|
|
|
|
|
|
|
|
Loop |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
RL = 600 Ohms |
|
|||
Open |
80 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
70 |
|
|
|
|
|
|
|
|
|
|
-40 |
-20 |
0 |
20 |
40 |
60 |
80 |
100 |
120 |
140 |
Temperature (°C)
7/22
