Part I:

Getting into the details

Page 11

About this manual

Page 12

Welcome!

This is the Operation Manual for Steinberg’s Cubase. Here you will find detailed information about all the features and functions in the program.

About the program versions

The documentation covers two program versions; Cubase and Cubase Studio, for two different operating systems or “platforms”; Windows and Mac OS X.

Some features described in the documentation are only applicable to the Cubase version. Whenever this is the case this will be clearly indicated in the heading of the related subject.

Similarly, some features and settings are specific to one of the platforms, Windows or Mac OS X. This is clearly stated in the applicable cases. In other words:

Ö If nothing else is said, all descriptions and procedures in the documentation are valid for both Cubase and Cubase Studio, under Windows and Mac OS X.

The screenshots are taken from the Windows version of Cubase.

Key command conventions

Many of the default key commands in Cubase use modifier keys, some of which are different depending on the operating system. For example, the default key command for Undo is [Ctrl]-[Z] under Windows and [Command]-[Z] under Mac OS X.

When key commands with modifier keys are described in this manual, they are shown with the Windows modifier key first, in the following way:

[Win modifier key]/[Mac modifier key]-[key] For example, [Ctrl]/[Command]-[Z] means “press [Ctrl]

under Windows or [Command] under Mac OS X, then press [Z]”.

Similarly, [Alt]/[Option]-[X] means “press [Alt] under Windows or [Option] under Mac OS X, then press [X]”.

Ö Please note that this manual often refers to right-clicking, e.g. to open context menus. If you are using a Mac with a single-button mouse, hold down [Ctrl] and click.

About this manual

Page 13

VST Connections: Setting up input and

output busses

Page 14

About this chapter

Cubase uses a system of input and output busses to transfer audio between the program and the audio hardware.

• Input busses let you route audio from the inputs on your audio

hardware into the program. This means that when you record audio, you will always do this through one or several input busses.

• Output busses let you route audio from the program to the

outputs on your audio hardware. When you play back audio, you will always do this through one or several output busses.

As you can see, the input and output busses are vital when you work with Cubase. This is why you find this chapter at the beginning of the Operation Manual – once you understand the bus system and know how to set up the busses properly, it will be easy to go on with recording, playing back, mixing and doing surround work (Cubase only).

Setting up busses

Strategies

In Cubase, you can create any number of busses. A number of surround formats are supported (Cubase only). In Cubase Studio, busses are in mono or stereo.

Ö The bus configuration is saved with the project – therefore it is a good idea to add and set up the busses you need and save these in a template project (see “Save

as Template” on page 457).

When you start working on new projects, you start from this template. That way you get your standard bus configuration without having to make new bus settings for each new project. If you need to work with different bus configurations in different projects, you can either create several different templates or store your configurations as presets (see “Other bus

operations” on page 17). The templates can of course also contain other

settings that you regularly use – sample rate, record format, a basic track layout, etc.

So, which type of busses do you need? This depends on your audio hardware, your general audio setup (e.g. surround speaker setup) and what kind of projects you work with.

Here’s an example: Let’s say you are using audio hardware with eight analog

inputs and outputs and digital stereo connections (10 inputs and outputs all in all). Furthermore, you work with a surround setup in 5.1 format (Cubase only). Here’s a list of busses you may wish to add:

Input busses

• Most likely you need at least one stereo input bus assigned to an analog input pair. This would let you record stereo material. If you want to be able to record in stereo from other analog input pairs as well, you add stereo input busses for these, too.

• Although you can record mono tracks from one side of a stereo input, it may be a good idea to add a dedicated mono input bus. This could be assigned to an analog input to which you have connected a dedicated microphone pre-amp for example. Again, you can have several different mono busses.

• You probably want a dedicated stereo input bus assigned to the digital stereo input, for digital transfers.

• Cubase only: If you want to transfer surround material directly to a surround track, e.g. from surround-configured location recording equipment, you need an input bus in that surround format – in this example, this would be a 5.1 input bus.

Output busses

• You probably want one or several stereo output busses for monitoring and listening to stereo mixes.

• For digital transfers, you need a stereo bus assigned to the digital stereo output as well.

• Cubase only: You need a surround bus in the format of your speaker configuration (in this example, 5.1) assigned to the correct outputs (which in turn are connected to the correct speakers). You may want additional surround busses if you tend to work in different surround formats.

Different busses can use the same inputs/outputs on the audio hardware! For example, you may want a stereo output bus assigned to the same outputs as the front stereo channels in your surround bus – this makes it easy to listen to stereo mixes without having to reconnect your speakers.

VST Connections: Setting up input and output busses

Page 15

Preparations

Before you set up busses, you should name the inputs and outputs on your audio hardware. For example, if you are using a 5.1 surround speaker setup, you should name the outputs according to which speaker they are connected to (Left, Right, Center and so on).

The reason for this is compatibility – it makes it easier to transfer projects between different computers and setups. For example, if you move your project to another studio, the audio hardware may be of a different model. But if both you and the other studio owner have given your inputs and outputs names according to the surround setup (rather than names based on the audio hardware model), Cubase will automatically find the correct inputs and outputs for your busses and you will be able to play and record without having to change the settings.

Use the Device Setup dialog to assign names to the inputs and outputs of your audio hardware:

1. Open the Device Setup dialog from the Devices menu.

2. Make sure that the correct driver for your audio hard-

ware is selected on the VST Audio System page, so that the audio card is listed in the Devices list.

3. Select your audio card in the list.

The available input and output ports on your audio hardware are listed on the right.

4. To rename a port, click its name in the “Show as” column and enter a new name.

• If needed, you can also disable ports by deactivating them in the “Visible” column.

Disabled ports will not show up in the VST Connections window when you are making bus settings. If you attempt to disable a port that is used by a bus, you will be asked whether this is really what you want – note that this will remove the port from the bus!

5. Click OK to close the Device Setup dialog.

Mac OS X only: Retrieving channel names

For some audio cards, you can automatically retrieve the ASIO channel names for the ports of your audio hardware:

1. Open the Device Setup dialog via the Devices menu.

2. On the VST Audio System page, select your audio

card on the “ASIO driver” pop up menu.

3. In the Devices list to the left, select your audio card.

The available settings are displayed.

4. In the settings section to the right, click the Control

Panel button.

This opens the control panel for your audio hardware.

5. Activate the “Use CoreAudio Channel Names” option.

6. When you now open the VST Connections window to

set up the busses in your system, you will find that the port names in the Device Port column correspond to the names that are used by the CoreAudio driver.

Ö If you want to use the project later on with an earlier version of Cubase, you will have to re-assign the port connections in the VST Connections window (see below).

Mac OS X only: Port selection and activation

On the settings page for your audio card (opened via the Device Setup dialog, see above), you can specify which input and which output port should be active. This allows you, for example, to use the Microphone input instead of the Line input or even to deactivate the audio card input or output completely, if required.

Ö This function is only available for Built-In Audio, standard USB audio devices and a certain number of other audio cards (e.g. Pinnacle CineWave).

Ö If you open a project created on another computer and the port names do not match (or the port configuration is not the same – e.g. the project is created on a system with multi-channel i/o and you open it on a stereo in/out system), the Pending Connections dialog will appear.

This allows you to manually re-route ports used in the project to ports available in your system.

VST Connections: Setting up input and output busses

Page 16

The VST Connections window

You add and set up busses in the VST Connections window, opened from the Devices menu.

This window contains the following tabs:

• The Inputs and Outputs tabs are for viewing input busses or output busses, respectively.

• The Group/FX tab allows you to create Group and FX channels/tracks and to make output assignments for these. See

“Setting up Group and FX channels” on page 20.

• The External FX tab (Cubase only) allows you to create effect send/return busses for connecting external effects which can then be selected via the effect pop-up menus from inside the program. See “External instruments/effects (Cubase only)” on

page 20 and “Using external effects (Cubase only)” on page 163 for further information.

• The External Instruments tab (Cubase only) allows you to create input/output busses for connecting external instruments. See “External instruments/effects (Cubase only)” on page 20 and the chapter “VST Instruments and Instrument tracks” on

page 169 for further information.

• The Studio tab (Cubase only) is where you enable and configure the Control Room. See the chapter “Control Room (Cu-

base only)” on page 135.

For the time being, we shall focus on how to set up input and output busses.

Depending on which tab you have selected, Inputs or Outputs, the window lists the current input or output busses, with the following columns:

Column Description

Bus Name Lists the busses. You can select busses and rename

Speakers Indicates the speaker configuration (mono, stereo, sur-

Audio Device This shows the currently selected ASIO driver.

them by clicking on them in this column.

round formats) of each bus.

Column Description

Device Port When you have “opened” a bus (by clicking its + button

Click You can route the click to a specific output bus, regard-

in the Bus Name column) this column shows which physical inputs/outputs on your audio hardware are used by the bus.

less of the actual Control Room output, or indeed when the Control Room is disabled.

Adding a bus

1. Click the Inputs or Outputs tab depending on which you want to add.

2. Click the Add Bus button.

A dialog appears.

3. Select the desired (channel) configuration.

The pop-up menu contains Mono and Stereo options as well as several surround formats (Cubase only). To select another surround format, use the “More…” submenu.

• Alternatively you can right-click in the VST Connections window and add a bus in the desired format directly from the context menu.

The new bus appears with the ports visible.

4. Click in the Device Port column to select an input/output port for a channel in the bus.

The pop-up menu that appears lists the ports with the names you have assigned in the Device Setup dialog. Repeat this for all channels in the bus.

Adding a child bus (Cubase only)

A surround bus is essentially a set of mono channels – 6 channels in the case of the 5.1 format. If you have a mono track in the project, you can route it to a separate speaker channel in the bus (or route it to the parent surround bus and use the SurroundPanner to position it in the surround image). But what if you have a stereo track that you simply want to route to a stereo channel pair within the bus (Left and Right or Left Surround and Right Surround for example)? For this you need to create a child bus.

VST Connections: Setting up input and output busses

Page 17

1. Select the surround bus in the list and right-click on it.

A pop-up menu appears.

2. Select a channel configuration from the “Add Child

Bus” submenu.

As you can see, you can create stereo child busses (routed to various speaker channel pairs in the surround bus) or other surround bus formats (with fewer channels than the “parent bus”).

The child bus you created will be available for direct routing in the mixer. It is a part of the parent surround bus, which means there will be no separate channel strip for it.

Although child busses are probably most useful in output busses, you can also create child busses within a surround input bus – for example if you want to record a stereo channel pair (e.g. front left-right) in the surround bus to a separate stereo track.

Setting the Main Mix bus (the default output bus)

The Main Mix is the output bus that each new channel in the mixer will be assigned to when it is created.

Any of the output busses in the VST Connections window can be the default output bus. By right-clicking on the name of an output bus, you can set this bus as the Main Mix bus.

When creating new audio, group or FX channels in the mixer, they will automatically be routed to the default bus.

The default bus is indicated by an orange colored speaker icon next to its name in the VST Connections window.

Presets

On the Inputs and Outputs tabs, you will find a Presets menu. Here you can find three different types of presets:

• A number of standard bus configurations.

• Automatically created presets tailored to your specific

hardware configuration.

On each startup, Cubase will analyze the physical inputs and outputs provided by your audio hardware and create a number of hardwaredependent presets with the following possible configurations:

• one stereo bus

• various combinations of stereo and mono busses

• a number of mono busses

• Cubase only: one 5.1 bus (if you have 6 or more inputs)

• Cubase only: various combinations of 5.1 and stereo busses (if you have 6 or more inputs)

• Cubase only: various combinations of 5.1 and mono busses (if you have 6 or more inputs)

• You can also save your own setups as presets.

To store the current configuration as a preset, click the Store “+” button and enter a name for the preset. You can then select the stored configuration directly from the Presets pop-up menu at any time. To remove a stored preset, select it and click the “-” button.

Other bus operations

• To change the port assignment for a bus, you proceed

as when you added it: Make sure the channels are visible (by clicking the “+” button next to the bus, or by clicking the “+ All” button at the top of the window) and click in the Device Port column to select ports.

• To remove a bus you do not need, select it in the list,

right-click and select “Remove Bus” from the pop-up menu, or press [Backspace].

Setting the default output bus in the VST Connections window.

VST Connections: Setting up input and output busses

Page 18

Using the busses

This section describes briefly how to use the input and output busses you have created. For details refer to the chapters “Recording” on page 66 and “The mixer” on page 109.

Routing

When you play back an audio track (or any other audio-related channel in the mixer – VST Instrument channels, ReWire channels, etc.), you route it to an output bus. In the same way, when you record on an audio track you select from which input bus the audio should be sent.

• You can select input and output busses in the Inspector, using the Input and Output Routing pop-up menus.

• You can also select busses in the Routing panel at the top of each channel strip in the mixer.

Ö If the Routing panel is not shown, click the Show Routing button in the extended common panel or open the Mixer context menu and select “Show Routing View” from the Window submenu (see “Normal vs. Extended channel

strips” on page 112).

Ö For audio-related channel types other than audio track channels (i.e. VST Instrument channels, ReWire channels, Group channels and FX channels), only the Output Routing pop-up menu is available.

• If you press [Shift]-[Alt]/[Option] and select an input or

output bus in the Track list or the Mixer Routing View (Cubase only), it will be chosen for all selected channels.

This makes it easy to quickly set several channels to use the same input or output. Similarly, if you press [Shift] and select a bus, the following selected channels will be set to use incrementing busses – the second selected channel will use the second bus, the third will use the third bus and so on.

When selecting an input bus for a track you can only select busses that correspond to the track’s channel configuration. Here are the details for input busses:

• Mono tracks can be routed to mono input busses or individual channels within a stereo or surround input bus (Cubase only).

• Mono tracks can be routed to External Inputs configured on the Studio tab of the VST Connections window. These can be mono or individual channels within a stereo or surround bus (Cubase only). They can also be routed to the Talkback input.

• Mono tracks can also be routed to mono output busses, mono group output busses or mono FX channel output busses, provided that these will not lead to feedback.

• Stereo tracks can be routed to mono input busses, stereo input busses or stereo child busses within a surround bus (Cubase only).

• Stereo tracks can be routed to External Inputs that are configured in the Studio tab of the VST Connections window. These can be mono input busses or stereo input busses. They can also be routed to the Talkback input.

• Stereo tracks can also be routed to mono or stereo output busses, mono or stereo group output busses and mono or stereo FX channel output busses, provided that these will not lead to feedback.

• Surround tracks can be routed to surround input busses (Cubase only).

• Surround tracks can be routed to External Inputs that are configured in the Studio tab of the VST Connections window, provided that these have the same input configuration.

• Surround tracks can also be routed to output busses, provided that these have the same input configuration or will not lead to feedback.

For output busses any assignment is possible.

Assignments that will lead to feedback are not available in the pop-up menu. This is also indicated by a one-way symbol.

To disconnect input or output bus assignments, select “No Bus” from the corresponding pop-up menu.

VST Connections: Setting up input and output busses

Page 19

Viewing the busses in the mixer

Hide Input Channels (Cubase only)

Hide Output Channels

In the mixer, busses are represented by input and output channels (shown in separate panes to the left and right in the window). You can show or hide these independently by clicking the Hide Input Channels and Hide Output Channels buttons in the common panel:

Ö In Cubase Studio, only the output busses are visible in the mixer!

The input busses you have created in the VST Connections window are available for selection on the Input Routing pop-up menus, but you will not be able to make any specific mixer settings for the input busses.

Input channels (Cubase only)

Here you can do the following:

• Check and adjust the recording level using the Input

Gain knobs and/or the level fader.

See “Setting input levels” on page 71.

• Change the phase of the input signal.

This is done by clicking the Input Phase button next to the Input Gain control.

• Add effects or EQ to the input bus.

See “Recording with effects (Cubase only)” on page 78 for an example of how to add effects to your recording at the input bus stage.

The settings you make in the input channel strip will be a permanent part of the recorded audio file!

Output channels

The output channels are shown to the right in the mixer. Here you can do the following:

• Adjust the output level for the busses with the faders.

• Open the Channel Settings window to add effects or EQ.

These will affect the whole bus. Examples of effects you may want to add here include compressors, limiters and dithering. See the chapter “Audio

effects” on page 150.

The input channels are shown to the left in the mixer. As you can see, each input channel resembles a regular mixer channel strip.

VST Connections: Setting up input and output busses

Page 20

Setting up Group and FX channels

The Group/FX tab in the VST Connections window shows all Group channels and FX channels in your project. You can create new Group or FX channels by clicking the corresponding Add button. This is the same as creating Group channel tracks or FX channel tracks in the Project window (see “Using group channels” on page 127 and the chapter

“Audio effects” on page 150).

However, the VST Connections window also allows you to create child busses for Group and FX channels (Cubase only). This is useful e.g. if you have Group or FX channels in surround format and want to route stereo channels to specific channel pairs in these.

To create a child bus for a Group channel or FX channel in surround format, proceed as follows:

1. Open the VST Connection window and select the Groups/FX tab.

2. Select the Group or FX channel in the list and rightclick it.

3. Select a channel configuration from the “Add Child Bus” submenu.

The child bus you created will be available for direct routing in the mixer. It is a part of the parent Group or FX channel, which means there will be no separate channel strip for it.

About monitoring

By default, monitoring is done via the Control Room (see the chapter “Control Room (Cubase only)” on page 135). When the Control Room is disabled on the Studio tab of the VST Connections window, the Main Mix bus (see “Set-

ting the Main Mix bus (the default output bus)” on page 17)

will be used for monitoring.

Ö In Cubase Studio, the Main Mix bus is always used for monitoring.

Setting the monitoring level

When you are using the Control Room for monitoring, this is set in the Control Room Mixer, see “The Control Room

Mixer” on page 141. When you are monitoring via the Main

Mix bus, you can adjust the monitoring level in the regular Project Mixer.

External instruments/effects (Cubase only)

Cubase supports the integration of external effect devices and external instruments, e.g. hardware synthesizers, into the sequencer signal flow.

You can use the External Instruments tab and the External FX tab in the VST Connections window to define the necessary send and return ports and access the instruments/effects through the VST Instruments window.

External instruments and effects are indicated by an “x” icon in the list next to their names in the respective pop-up menus.

Requirements

• To use external effects, you need audio hardware with

multiple inputs and outputs. To use external instruments, a MIDI interface must be connected to your computer.

An external effect will require at least one input and one output (or input/ output pairs for stereo effects) in addition to the input/output ports you use for recording and monitoring.

• As always, audio hardware with low-latency drivers is a

good thing to have.

Cubase will compensate for the input/output latency and ensure that the audio processed through external effects is not shifted in time.

Connecting the external effect/instrument

To set up an external effect or instrument, proceed as follows:

1. Connect an unused output pair on your audio hard-

ware to the input pair on your external hardware device.

In this example, we assume that the hardware device has stereo inputs and outputs.

VST Connections: Setting up input and output busses

Page 21

2. Connect an unused input pair on your audio hardware

to the output pair on your hardware device.

Please note that it is possible to select input/output ports for external effects/instruments that are already used (i.e. that have been selected as inputs/outputs in the VST Connections window). If you select a used port for an external effect/instrument, the existing port assignment will be broken. Note that you will not get a warning message!

Once the external device is connected to the audio hardware of your computer, you have to set up the input/output busses in Cubase.

Setting up external effects

1. Open the VST Connections window from the Devices menu.

2. Open the External FX tab and click “Add External FX”.

3. In the dialog that appears, enter a name for the exter-

nal effect and specify the Send and Return configurations.

Depending on the type of effect, you can specify mono, stereo or surround configurations.

• You also need a MIDI device that corresponds with the external effect. You can then click the Associate MIDI Device button to connect the two.

You can use the MIDI Device Manager to create a new MIDI device for the effect. Note that delay compensation will only be applied for the effect when you use MIDI devices. For information about the MIDI Device Manager and user device panels see the chapter “Using MIDI devices” on page 314.

4. Click OK. This adds a new External FX bus.

5. Click in the Device Port column for the Send Bus

“Left” and “Right” ports and select the outputs on your audio hardware.

6. Click in the Device Port column for the Return Bus

“Left” and “Right” ports and select the inputs on your audio hardware.

7. If you like, make additional settings for the bus.

These are found in the columns to the right. Note that you can adjust these while actually using the external effect – which may be easier as you can hear the result. The following options are available:

Setting Description

Delay If your hardware effect device has an inherent delay (la-

Send Gain Allows you to adjust the level of the signal being sent to

Return Gain Allows you to adjust the level of the signal coming in from

MIDI Device When you click in this column, a pop-up menu opens

Used Whenever you insert an external effect into an audio

tency), you should enter this value here, as it allows Cubase to compensate for that delay during playback. You can also let the delay value be determined by the program: Right-click in the Delay column for the effect and select “Check User Delay”. Note that you do not have to take the latency of the audio hardware into account – this is handled automatically by the program.

the external effect.

the external effect. Note however that excessive output levels from an external effect device may cause clipping in the audio hardware. The Return Gain setting cannot be used to compensate for this – you have to lower the output level on the effect device instead.

where you can disconnect the effect from the associated MIDI device, select a MIDI device, create a new device or open the MIDI Device Manager to edit the MIDI device. When Studio Manager 2 is installed, you may also select an OPT editor to access your external effect.

track, this column shows a checkmark (“x”) to indicate that the effect is being used.

8. When you are done, close the VST Connections win-

dow.

Ö Note that external device ports are exclusive, see

“Connecting the external effect/instrument” on page 20.

How to use the external effect

If you now click an insert effect slot for any channel, you will find the new external FX bus listed on the “External Plug-ins” submenu.

When you select it, the following happens:

• The external FX bus is loaded into the effect slot just like a regular effect plug-in.

• The audio signal from the channel is sent to the outputs on the audio hardware, through your external effect device and back to the program via the inputs on the audio hardware.

VST Connections: Setting up input and output busses

Page 22

• A parameter window appears, showing the Delay, Send Gain

Measure Effect’s Loop Delay button

and Return Gain settings for the external FX bus. You can adjust these as necessary while playing back. The parameter window also provides the “Measure Effect’s Loop Delay for Delay Compensation” button. This is the same function as the “Check User Delay” option in the VST Connections window. It provides Cubase with a Delay value to be used for delay compensation. When you have defined a MIDI device for the effect, the corresponding Device window will be opened. When Studio Manager 2 is installed, and you have set up a corresponding OPT editor, this OPT editor will be displayed.

The default parameter window for an external effect

Like any effect, you can use the external FX bus as an insert effect or as a send effect (an insert effect on an FX channel track). You can deactivate or bypass the external effect with the usual controls.

Setting up external instruments

1. Open the VST Connections window from the Devices menu.

2. Open the External Instrument tab and click “Add External Instrument”.

• You also need a MIDI device that corresponds with the

external instrument. You can then click the Associate MIDI Device button to connect the two.

You can use the MIDI Device Manager to create a new MIDI device. For information about the MIDI Device Manager and user device panels, see the chapter “Using MIDI devices” on page 314.

4. Click OK.

This adds a new external instrument bus.

5. Click in the Device Port column for the “Left” and

“Right” ports of the Return Bus and select the inputs on your audio hardware to which you connected the external instrument.

6. If you like, make additional settings for the bus.

These are found in the columns to the right. Note that you can adjust these while actually using the external instrument – which may be easier as you can hear the result. The following options are available:

Setting Description

Delay If your hardware device has an inherent delay (latency),

Return Gain Allows you to adjust the level of the signal coming in from

MIDI Device When you click in this column, a pop-up menu opens

Used Whenever you insert the external instrument into a VST

you should enter this value here. This allows Cubase to compensate for that delay during playback. Note that you do not have to take the latency of the audio hardware into account – this is handled automatically by the program.

the external instrument. Note however that excessive output levels from an external device may cause clipping in the audio hardware. The Return Gain setting cannot be used to compensate for this – you have to lower the output level on the device instead.

where you can disconnect the instrument from the associated MIDI device, select a MIDI device, create a new device or open the MIDI Device Manager to edit the MIDI device. When Studio Manager 2 is installed, you may also select an OPT editor to access your external instrument.

Instrument slot, this column shows a checkmark (“x”) to indicate that the instrument is being used.

3. In the dialog that appears, enter a name for the external instrument and specify the number of required mono and/or stereo returns.

Depending on the type of instrument, a specific number of mono and/or stereo return channels is required.

VST Connections: Setting up input and output busses

7. When you are done, close the VST Connections win-

dow.

Ö Note that external device ports are exclusive, see

“Connecting the external effect/instrument” on page 20.

Page 23

How to use the external instrument

Once you have set up the external instrument in the VST Connections window, you can use it as a VST Instrument. Open the VST Instruments window and click on an empty instrument slot. On the Instrument pop-up menu, your external instrument is listed on the External Plug-ins submenu:

When you select the external instrument in the VST Instruments window, the following happens:

• A parameter window for the external device is opened automatically. This may either be the Device window, allowing you to create a generic device panel, an OPT editor window or a default editor. For information about the Device window, the MIDI Device Manager and User device panels, see the chapter “Using MIDI devices” on page 314.

To send MIDI notes to the external instrument, open the Output Routing pop-up menu in the Inspector for the corresponding MIDI track and select the MIDI device to which the external instrument is connected. This ensures use of delay compensation. The instrument will now play any MIDI notes it receives from this track and return them to Cubase through the return channel(s) you have set up.

The external instrument will behave like any other VST Instrument in Cubase.

About the Favorites buttons

In the VST Connections window, both the External FX tab and the External Instruments tab feature a Favorites button.

Favorites are device configurations that you can recall at any time, like a library of external devices that are not constantly connected to your computer. They also allow you to save different configurations for the same device, e.g. a multi-effect board or an effect that provides both a mono and a stereo mode.

To save a device configuration as a favorite, proceed as follows:

• When you have added a new device in the VST Connections window, select it in the Bus Name column and click the Favorites button.

A context menu is displayed showing an option to add the selected effect or instrument to the Favorites.

• You can recall the stored configuration at any time by clicking the Favorites button and selecting the device name from the context menu.

About the “plug-in could not be found” message

When you open a project that uses an external effect/instrument, you may get a “plug-in could not be found” message. This will happen when you remove an external device from the VST Connections window although it is used in a saved project, or when transferring a project to another computer on which the external device is not defined. You may also see this message when opening a project created with an earlier version of Cubase.

In the VST Connections window, the broken connection to the external device is indicated by an icon in the Bus Name column.

To reestablish the broken connection to the external device, simply right-click the entry for the device in the Bus Name column and select “Connect External Effect”. The icon is removed, and you can use the external device within your project as before.

Note that busses set up for external effects or external instruments are saved “globally”, i.e. for your particular computer setup.

The Favorites button on the External FX tab

VST Connections: Setting up input and output busses

Page 24

Freezing external effects/instruments

Just as when working with regular VST instruments and effects, you can also choose to freeze external effects and instruments. The general procedure is described in detail in the chapters “Audio effects” on page 150 and “VST In-

struments and Instrument tracks” on page 169.

Note that you have to perform Freeze in realtime. Otherwise external effects will not be taken into account.

When freezing external instruments or effects, you can adjust the corresponding tail value in the Freeze Channel Options dialog:

• Use the arrow buttons next to the Tail Size value field to

set the desired Tail length, i.e. the range after the part boundary that should also be included for the freeze. You can also click directly in the value field and enter the desired value manually (the maximum value being 60s).

• When the Tail Size is set to 0s (default), the freezing will

only take into account the data within the Part boundaries.

VST Connections: Setting up input and output busses

Page 25

The Project window

Page 26

Background

The Project window is the main window in Cubase. This provides you with an overview of the project, allowing you to navigate and perform large scale editing. Each project has one Project window.

About tracks

The Project window is divided vertically into tracks, with a timeline running horizontally from left to right. The following track types are available:

Track type Description

Audio For recording and playing back audio events and audio

Folder Folder tracks function as containers for other tracks,

FX Channel FX channel tracks are used for adding send effects. Each

Group Channel

Instrument This allows you to create a track for a dedicated instru-

parts. Each audio track has a corresponding audio channel in the mixer. An audio track can have any number of automation tracks for automating mixer channel parameters, effect settings, etc.

making it easier to organize and manage the track structure. They also allow you to edit several tracks at the same time. See “Folder tracks” on page 53.

FX channel can contain up to eight effect processors – by routing effect sends from an audio channel to an FX channel, you send audio from the audio channel to the effect(s) on the FX channel. Each FX channel has a corresponding channel strip in the mixer – in essence an effect return channel. See the chapter “Audio effects” on page 150. All FX channel tracks are automatically placed in a special FX channel folder in the Track list, for easy management. An FX channel can also have any number of automation tracks for automating mixer channel parameters, effect settings, etc.

By routing several audio channels to a Group channel, you can submix them, apply the same effects to them, etc. (see “Using group channels” on page 127). A Group channel track contains no events as such, but displays settings and automation curves for the corresponding Group channel. Each Group channel track has a corresponding channel strip in the mixer. In the Project window, Group channels are organized as tracks in a special Group Tracks folder.

ment, making e.g. VST instrument handling easier and more intuitive. Instrument tracks have a corresponding channel strip in the mixer. Each instrument track can have any number of automation tracks in the Project window. However, Volume and Pan are automated from within the mixer. It is possible to edit Instrument tracks directly in the Project window, using the Edit In-Place function (see

“The In-Place Editor” on page 356). For more information

on instrument tracks, see the chapter “VST Instruments

and Instrument tracks” on page 169.

Track type Description

MIDI For recording and playing back MIDI parts. Each MIDI

Marker The Marker track displays markers which can be moved

Arranger The Arranger track is used for arranging your project, by

Ruler (Cubase only)

Signature Time signature events can be added and edited on the

Tempo You can create tempo changes within a project using the

Transpose The Transpose track allows you to set global key

Video For playing back video events. A project can have only

track has a corresponding MIDI channel strip in the mixer. It is possible to edit MIDI tracks directly in the Project window, using the Edit In-Place function (see “The In-

Place Editor” on page 356).

A MIDI track can have any number of automation tracks for automating mixer channel parameters, insert and send effect settings etc.

and renamed directly in the Project window (see “Mark-

ers” on page 54). A project can have only one marker

track.

marking out sections in the project and determining in which order they should be played back. See the chapter

“The Arranger track” on page 96.

Ruler tracks contain additional rulers, displaying the timeline from left to right. You can use any number of ruler tracks, each with a different display format if you wish. See “The ruler” on page 33 for more information about the ruler and the display formats.

signature track, or in the Tempo Track Editor window. A project can have only one signature track. See the chapter “Editing tempo and signature” on page 401 for details.

tempo track. A project can have only one tempo track. See the chapter “Editing tempo and signature” on page

401 for details.

changes. A project can have only one transpose track. See the chapter “The Transpose functions” on page 103.

one video track.

About parts and events

The tracks in the Project window contain parts and/or events. Events are the basic building blocks in Cubase. Different event types are handled differently in the Project window:

• Video events and automation events (curve points) are always viewed and rearranged directly in the Project window.

• MIDI events can always be found in MIDI parts, which are containers for one or more MIDI events. MIDI parts are rearranged and manipulated in the Project window. To edit the individual MIDI events in a part, you have to open the part in a MIDI editor (see “The MIDI editors” on page 337).

The Project window

Page 27

• Audio events can be displayed and edited directly in the Project window, but you can also work with audio parts containing several events. This is useful if you have a number of events which you want to treat as one unit in the project. Audio parts also contain information about the time position in the project.

An audio event and an audio part

Audio handling

When you work with audio files, it is crucial to understand how audio is handled in Cubase:

When you edit or process audio in the Project window, you always work with an audio clip that is automatically created on import or during recording. This audio clip refers to an audio file on the hard disk that itself remains untouched. This means, that audio editing and processing is “non-destructive”, in the sense that you can always undo changes or revert to the original versions.

An audio clip does not necessarily refer to just one original audio file! If you apply e.g. some processing to a specific section of an audio clip, this will create a new audio file containing only this section. The processing will then be applied to the new audio file only, leaving the original audio file unchanged. Finally, the audio clip is automatically adjusted, so that it refers both to the original file and to the new, processed file. During playback, the program will switch between the original file and the processed file at the correct positions. You will hear this as a single recording, with processing applied to one section only. This feature makes it possible to undo processing at a later stage, and to apply different processing to different audio clips that refer to the same original file.

An audio event is the object that you place on a time position in Cubase. If you make copies of an audio event and move them to different positions in the project, they will still all refer to the same audio clip. Furthermore, each audio event has an Offset value and a Length value. These determine at which positions in the clip the event will start

and end, i.e. which section of the audio clip will be played back by the audio event. For example, if you resize the audio event, you will just change its start and/or end position in the audio clip – the clip itself will not be affected.

An audio region is a section within a clip with a length value, a start time, and a snap point. Audio regions are shown in the pool and are best created and edited in the Sample Editor.

Ö If you want to use one audio file in different contexts, or if you want to create several loops from one audio file, you should convert the corresponding regions of the audio clip to events and bounce them into separate audio files. This is necessary since different events that refer to the same clip access the same clip information.

The Project window

Page 28

Window Overview

Project overview

The event display, showing audio parts and events, MIDI parts, automation, markers, etc.

Inspector

Ruler

Info line

Toolbar

The Track list with various track types

Mute & Solo

Record Enable & Monitor

Track name

Lane Display Type

Show/hide automation

Indicates whether effect sends, EQ or insert effects are activated for the track. Click to bypass.

Musical/Linear Time Base

Lock track

Automation Read/Write Edit channel settings

Track activity indicator

Freeze Audio Track

Automation Read/Write

Automation parameter (click to select parameter)

Append automation track

Mute

Lock track

Record Enable & Monitor

Track name

MIDI Output

Bank Patch MIDI channel

Drum map, Lock track and Lane display type

Automation Read/Write

Edit channel settings

Mute & Solo

Effect sends/insert effects indicators and bypass

Edit In-Place

Track activity indicator

The Track list

The Track list displays all the tracks used in a project. It contains name fields and settings for the tracks. Different track types have different controls in the Track list. To see all the controls you may have to resize the track in the Track list (see “Resizing tracks in the Track list” on page 35).

• The Track list area for an audio track:

• The Track list area for an automation track (opened by

clicking the Show/Hide Automation button on a track):

• The Track list area for a MIDI track:

The Project window

Page 29

The Inspector

The area to the left of the Track list is called the Inspector. This shows additional controls and parameters for the track you have selected in the Track list. If several tracks are selected (see “Handling tracks” on page 38), the Inspector shows the setting for the first (topmost) selected track.

To hide or show the Inspector, click the Inspector icon in the toolbar.

The Inspector icon

• For most track classes, the Inspector is divided into a

number of sections, each containing different controls for the track. You can hide or show sections by clicking on their names.

Clicking the name for a hidden section brings it into view and hides the other sections. [Ctrl]/[Command]-clicking the section name allows you to hide or show a section without affecting the other sections. [Alt]/[Option]-clicking a section name shows or hides all sections in the Inspector.

• You can also use key commands to show different In-

spector sections.

These are set up in the Key Commands dialog, see “Setting up key com-

mands” on page 480.

Ö Hiding a section does not affect its functionality.

For example, if you have set up a track parameter or activated an effect, your settings will still be active even if you hide the respective Inspector section.

Which sections are available in the Inspector depends on the selected track.

Ö Please note that not all Inspector tabs are shown by default. You can show/hide Inspector sections by rightclicking on an Inspector tab and activating/deactivating the desired option(s).

Make sure you right-click on an inspector tab and not on the empty area below the Inspector, as this will open the Quick context menu instead.

The Inspector Setup context menu

Inspector sections

The Inspector contains the controls that can be found on the Track list, plus some additional buttons and parameters. In the table below, these additional settings and the different sections are listed. Which sections are available for which track type is described in the following sections.

Parameter Description

Auto Fades Settings button

Edit Channel settings

Volume Use this to adjust the level for the track. Changing this

Pan Use this to adjust the panning of the track. As with the

Delay This adjusts the playback timing of the audio track. Posi-

Input Routing This lets you specify which Input bus or MIDI input the

Opens a dialog in which you can make separate Auto Fade settings for the audio track. See “Making Auto Fade

settings for a separate track” on page 95.

Opens the Channel Settings window for the track, allowing you to view and adjust effect and EQ settings, etc. See “Using Channel Settings” on page 122.

setting will move the track’s fader in the mixer window, and vice versa. See “Setting volume in the mixer” on page

117 to learn more about setting levels.

Volume setting, this corresponds to the Pan setting in the mixer.

tive values delay the playback while negative values cause the track to play earlier. The values are set in milliseconds.

track should use (see “Setting up busses” on page 14 for information about Input busses).

The Project window

Page 30

Parameter Description

Output Routing

Inserts section Allows you to add insert effects to the track, see the

Equalizers section

Equalizer Curve section

Sends section Allows you to route an audio track to one or several FX

Studio Sends (Cubase only)

Surround Pan (Cubase only)

Channel section

Notepad section

User Panel (Cubase only)

Quick Controls Here you can configure quick controls, e.g. to use remote

Here you decide to which output the track should be routed. For audio tracks you select an output bus (see

“Setting up busses” on page 14) or Group channel, for

MIDI tracks you select a MIDI output and for Instrument tracks, you select the Instrument to which it is routed.

chapters “Audio effects” on page 150 and “MIDI realtime

parameters and effects” on page 305. The Edit button at

the top of the section opens the control panels for the added insert effects.

Lets you adjust the EQs for the track. You can have up to four bands of EQ for each track, see “Making EQ set-

tings” on page 123. The Edit button at the top of the sec-

tion opens the Channel Settings window for the track. Lets you adjust the EQs for the track graphically, by click-

ing and dragging points in a curve display.

channels (up to eight), see the chapter “Audio effects” on

page 150. For MIDI tracks, this is where you assign MIDI

send effects. The Edit button at the top of the section opens the control panel for the first effect in each FX channel.

The Studio Sends are used to route cue mixes to Control Room Studios. For a detailed description of Studios and Studio Sends, see the chapter “Control Room (Cubase

only)” on page 135.

When the SurroundPanner is used for a track, this is also available in the Inspector. For further information, see

“Using the SurroundPanner” on page 184.

Shows a duplicate of the corresponding mixer channel strip. The channel overview strip to the left lets you activate and deactivate insert effects, EQs and sends.

This is a standard text notepad, allowing you to jot down notes about the track. If you have entered any notes about a track, the icon next to the “Notepad” heading will light up to indicate this. Moving the pointer over the icon will display the Notepad text in a tooltip.

Here you can display device panels, e.g. for external MIDI devices, audio track panels or VST insert effect panels. For information on how to create or import MIDI device and user panels, see the separate PDF document “MIDI Devices”.

devices. See the chapter “Track Quick Controls” on

page 295.

Audio tracks

For audio tracks, all settings and sections listed above are available.

Instrument tracks

As explained in the chapter “VST Instruments and Instru-

ment tracks” on page 169, the Inspector for an Instrument

track shows some of the sections you would find for VST Instrument channels and MIDI tracks.

MIDI tracks

When a MIDI track is selected, the Inspector contains a number of additional sections and parameters, affecting the MIDI events in realtime (e.g. on playback). Which sections are available for MIDI tracks is described in the chapter

“MIDI realtime parameters and effects” on page 305.

Arranger track

For the Arranger track, the Inspector displays the lists of available Arranger chains and Arranger events. See “The

Arranger track” on page 96 for details.

Folder tracks

When a folder track is selected, the Inspector shows the folder and its underlying tracks, much like a folder structure in the Windows Explorer or Mac OS X Finder.

Ö You can click one of the tracks shown under the folder in the Inspector to have the Inspector show the settings for that track. This way, you don’t have to “open” a folder track to make settings for tracks within it.

FX channel tracks

When an FX channel track is selected, the following controls and sections are available:

• Edit button

• Volume control

•Pan control

• Output Routing pop-up menu

• Inserts section

• Equalizers section

• Equalizer Curve section

• Sends section

• Studio Sends section (Cubase only)

• Surround Pan section (Cubase only)

• Channel section

• Notepad section

The Project window

Page 31

FX channel tracks are automatically placed in a special

Active project indicator

Show/hide Inspector

Show/hide Info line

Show/hide Overview

Open Mixer

Open Pool

Automation mode

Constrain delay compensation

Project window tools

Transport controls (Previous/Next Marker, Cycle, Stop, Play, and Record)

folder, for easier management. When this folder track is selected, the Inspector shows the folder and the FX channels it contains. You can click one of the FX channels shown in the folder to have the Inspector show the settings for that FX channel – this way you don’t have to “open” a folder track to access the settings for the FX channels in it.

Group channel tracks

When a Group channel track is selected, the following controls and sections are available:

• Edit button

• Volume control

• Pan control

• Output Routing pop-up menu

• Inserts section

• Equalizers section

• Equalizer Curve section

• Sends section

• Studio Sends section (Cubase only)

• Surround Pan section (Cubase only)

• Channel section

•Notepad section

Just like FX channel tracks, all Group channel tracks are placed in a separate folder – when this is selected, the Inspector shows the folder and the Group channels it contains. You can click one of the Group channels shown in the folder to have the Inspector show the settings for that Group channel – this way, you don’t have to “open” a folder track to access the settings for the Group channels in it.

Transpose track

When the transpose track is selected, the following controls and sections are available:

• Mute button

• Keep Transpose in Octave range

• Toggle Timebase button

• Lock button

• Notepad section The Transpose track controls are described in detail in the

chapter “The Transpose functions” on page 103.

Signature track and tempo track

For the signature track and the tempo track, the Inspector displays a list of all time signature events or tempo events. See the chapter “Editing tempo and signature” on page

401 for details.

Video tracks

When a video track is selected, the Inspector contains a lock button for locking the track (see “Locking events” on

page 48), a Mute button for interrupting video playback

and two settings for how the video thumbnails are shown: Show Frame Numbers and Snap Thumbnails (see “Play-

ing back a video file” on page 447).

Video tracks make use of the Notepad Inspector tab.

The toolbar

The toolbar contains tools and shortcuts for opening other windows and various project settings and functions:

Marker tracks

When the marker track is selected, the Inspector shows the marker list. For more information, see the section

“Markers” on page 54.

Ruler tracks (Cubase only)

For ruler tracks, the Inspector isn’t used.

The Project window

Page 32

Ö In addition to these, the toolbar can contain a number

Snap on/off

Snap mode

Grid pop-up menu

Quantize value

Color pop-up menu

Autoscroll and Suspend Autoscroll when Editing

Snap to Zero Crossing

Project Root Key

of other tools and shortcuts, not visible by default. How to set up the toolbar and specify which tools should be displayed or hidden is described in the section “Using the

Setup options” on page 471.

The info line

The info line shows information about the currently selected event or part in the Project window. You can edit almost all values on the info line using regular value editing. Length and position values are displayed in the format currently selected for the ruler (see “The ruler” on page 33).

• To hide or show the info line, click the Show Event Info

Line button on the toolbar. The following elements can be selected for display and

editing on the info line:

• Audio events

•Audio parts

•MIDI parts

• Video events

•Markers

• Automation curve points

• Transpose events

• Arranger events

When several elements are selected

• If you have several elements selected, the info line will

show information about the first item in the selection. The values will be shown in yellow to indicate that several elements are selected.

• If you edit a value on the info line, the value change is applied to all selected elements, relatively to the current values.

If you have two audio events selected and the first is one bar long and the other two bars long, the info line shows the length of the first event (one bar). If you now edit this value to 3 bars in the info line, the other event will be resized by the same amount – and will thus be 4 bars long.

• If you press [Ctrl]/[Command] and edit on the info line, the values will be absolute instead. In our example above, both events would be resized to 3 bars. Note that [Ctrl]/ [Command] is the default modifier key for this – you can change this in the Preferences (Editing–Tool Modifiers page, under the Info Line category).

Editing Transpose and Velocity for MIDI parts

When one or several MIDI parts are selected, the info line contains Transpose and Velocity fields.

• Adjusting the Transpose field transposes the selected parts in semitone steps.

Note that this transposition doesn’t change the actual notes in the part – it’s just a “play parameter”, affecting the notes on playback. The transposition you specify for a part on the info line is added to the transposition set for the whole track. For more information on transposing, see the chapter “The Transpose functions” on page 103.

• Adjusting the Velocity field shifts the velocity for the selected parts – the value you specify is added to the velocities of the notes in the parts.

Again, this velocity shift only affects the notes on playback, and again, the value you specify is added to the Vel.Shift. value set for the whole MIDI track in the Inspector.

Getting on-the-fly info with the Arrow tool

If the option “Select Tool: Show Extra Info” is activated in the Preferences (Editing–Tools page), a tooltip will be shown for the Arrow tool, displaying information depending on where you point it. For example, in the Project window event display, the tool will show the current pointer position and the name of the track and event you’re pointing at.

The Project window

Page 33

The ruler

The ruler at the top of the event display shows the timeline. Initially, the Project window ruler uses the display format specified in the Project Setup dialog (see “The

Project Setup dialog” on page 34), as do all other rulers

and position displays in the project. However, you can select an independent display format for the ruler by clicking the arrow button to the right of it and selecting an option from the pop-up menu (you can also bring up this pop-up menu by right-clicking anywhere in the ruler).

Option Positions and lengths displayed as

Bars+Beats Bars, beats, sixteenth notes and ticks. By default there

Seconds Hours, minutes, seconds and milliseconds. Timecode This format displays hours, minutes, seconds and frames.

Samples Samples. User Hours, minutes, seconds and frames, with a user defin-

Time Linear When this is selected, the ruler will be linear relative to

Bars+Beats Linear

• The selection you make here affects the ruler, the info

line and tooltip position values (which appear when you drag an event in the Project window).

You can also select independent formats for other rulers and position displays.

• To set the display format globally (for all windows), use

the primary display format pop-up on the Transport panel, or hold down [Ctrl]/[Command] and select a display format in any ruler.

are 120 ticks per sixteenth note but you can adjust this with the “MIDI Display Resolution” setting in the Preferences (MIDI page).

The number of frames per second (fps) is set in the Project Setup dialog (see “The Project Setup dialog” on page 34). You can choose between 24, 25, 29.97 and 30fps or

29.97 and 30dfps (“drop frame”).

able number of frames per second. You set the desired number of fps in the Preferences (Transport page).

time. This means that if there are tempo changes on the tempo track, the distance between the bars will vary in Bars+Beats mode.

When this is selected, the ruler will be linear relative to the meter position – bars and beats. This means that if there are tempo changes on the tempo track, there still will be the same distance between bars in Bars+Beats mode. If the ruler is set to a time-based mode, the distance between seconds will vary depending on the tempo changes.

• If you use the “Timecode” or “User” options and the option “Show Timecode Subframes” is activated in the Preferences (Transport page), the frames will also display subframes.

There are 80 subframes per frame.

Using multiple rulers – ruler tracks (Cubase only)

As described above, the Cubase Project window contains a main ruler at the top of the event display, displaying the timeline from left to right.

If needed, you can have several rulers in the Project window, by adding ruler tracks to the project. Each ruler track contains an additional ruler.

• To add a ruler track, select “Add Track” from the Project menu and from the submenu that appears, select “Ruler”.

A ruler track showing an additional ruler is added to the Track list.

A ruler track set to the display format “Seconds”

You can add any number of ruler tracks to a project, and position them as needed by dragging them up or down in the Track list. Each of the rulers can show a separate display format:

• To select a display format for a ruler track, click on its name in the Track list and select an option from the popup menu.

Note that ruler tracks are completely independent from the main event display ruler, as well as rulers and position displays in other windows. This means that:

• Each ruler track in a project can have its own display format.

• Ruler tracks are not affected by the display format setting in the Project Setup dialog (see “The Project Setup dialog” on

page 34).

• Ruler tracks are not affected if you set the display format globally with the primary time display in the Transport panel.

Ö Ruler tracks are affected by the option “Show Timecode Subframes” in the Preferences (Transport page, see above).

The Project window

Page 34

Operations

Creating a new project

You create a new project in the following way:

1. Select “New Project” from the File menu.

A dialog appears, listing a number of project templates, including any custom templates you may have created (see “Save as Template” on

page 457).

2. Select a template (or “Empty”) and click OK.

A file dialog appears, allowing you to specify a location for the project folder. This will contain all files related to the project.

3. Select an existing folder or create a new one. Then click OK.

A Project window opens. If you selected a template, the new project will be based on this template, and include the corresponding tracks, events and settings.

The Project Setup dialog

General settings for the project are made in the Project Setup dialog. This is opened by selecting “Project Setup…” from the Project menu.

Ö If the “Run Setup on Create New Project” option is activated in the Preferences dialog (General page), the Project Setup dialog will open automatically when you create a new project.

The following settings are available in the Project Setup dialog:

Setting Description

Start The start time of the project. Allows you to have the

Length The length of the project. Frame Rate Used when synchronizing Cubase with external equip-

Display Format This is the global display format used for all rulers and

Display Offset Offsets the time positions displayed in the ruler etc., al-

Bar Offset This works just like “Display Offset” described above, in

Sample Rate The sample rate at which Cubase records and plays audio. Record

Format/ File Type

Stereo Pan Law

project start at another time than zero. Also used for setting the sync start position when synchronizing Cubase to external devices (see “Setting up Cubase for external

sync to timecode” on page 433). When you change this

setting you will be asked whether you want to keep the project content at its timecode positions. “Yes” means that all events will stay at their original timecode positions – i.e. they will be moved in relation to the start of the project. “No” means that all events keep their position relative to the project start.

ment. If Cubase is slave, this value is automatically set to the frame rate of the incoming sync signal. If Cubase is the master, this determines the frame rate of the sent sync signal. See “Setting the Frame Rate” on page 430.

position displays in the program, except ruler tracks (Cubase only, see “Ruler tracks (Cubase only)” on page 31). However, you can make independent display format selections for the individual rulers and displays if you like. For descriptions of the different display format options, see “The ruler” on page 33.

lowing you to compensate for the Start position setting. Typically, if you synchronize Cubase to an external source starting at a frame other than zero, you set the Start position to this value. However, if you still want the display in Cubase to start at zero, set the Display Offset to the same value.

that it offsets the time positions in the ruler by a number of bars, allowing you to compensate for the Start position setting. The difference is that Bar Offset is only used when the “Bars+Beats” display format is selected (see

“The ruler” on page 33).

When you record audio in Cubase, the files that are created will be of this resolution and file type. See “Selecting

a recording file format” on page 69.

Decides whether panning should use power compensation or not (see “About the “Stereo Pan Law” setting (au-

dio channels only)” on page 121).

While most Project Setup settings can be changed at any time, you must select a sample rate once and for all when starting with a new project! All audio files must be of this sample rate to play back correctly.

The Project window

Page 35

Zoom and view options

Zooming in the Project window is done according to the standard zoom techniques, with the following special notes:

• When you are using the Zoom tool (magnifying glass), the result depends on the option “Zoom Tool Standard Mode: Horizontal Zooming Only” in the Preferences (Editing–Tools page).

If this is activated and you drag a selection rectangle with the Zoom tool, the window will only be zoomed horizontally (track height will not change). If the option is off, the window will be zoomed both horizontally and vertically.

• When using the vertical zoom sliders, the tracks are scaled relatively.

In other words, if you have made any individual track height adjustments (see below), the relative height differences are maintained.

You find the following options are available on the Zoom submenu on the Edit menu:

Option Description

Zoom In Zooms in one step, centering on the project cursor. Zoom Out Zooms out one step, centering on the project cursor. Zoom Full Zooms out so that the whole project is visible. “The

Zoom to Selection

Zoom to Selection (Horiz)

Zoom to Event This option is available only in the Sample Editor (see

Zoom In Vertically Zooms in one step vertically. Zoom Out

Vertically Zoom In Tracks Zooms in on the selected track(s) one step vertically. Zoom Out Tracks Zooms out the selected track(s) one step vertically. Zoom Selected

Tracks Undo/Redo

Zoom

• If the option “Zoom while Locating in Time Scale” is activated in the Preferences (Transport page), you can also zoom by clicking in the main ruler and dragging up or down with the mouse button pressed.

Drag up to zoom out; drag down to zoom in.

whole project” means the timeline from the project start to the length set in the Project Setup dialog (see above).

Zooms in horizontally and vertically so that the current selection fills the screen.

Zooms in horizontally so that the current selection fills the screen.

“Zooming” on page 224).

Zooms out one step vertically.

This zooms in vertically on the selected track(s) and minimizes the height of all other tracks.

These options allow you to undo/redo the last zoom operation.

• You can zoom the contents of parts and events verti-

cally, using the waveform zoom slider in the top right corner of the event display.

This is useful when viewing quiet audio passages.

To get an approximate reading on the level of the audio events by viewing the waveforms, make sure this slider is all the way down. Otherwise, zoomed waveforms may be mistaken for clipped audio.

• If you activate the option Quick Zoom in the Preferences

(Editing page), the contents of parts and events will not be continuously redrawn when you zoom manually.

Instead, the contents are redrawn once you have stopped changing the zoom – activate this if screen redraws are slow on your system.

Resizing tracks in the Track list

• You can change the height of an individual track by click-

ing on its lower border in the Track list and dragging up or down.

To change the height of all tracks simultaneously, hold down [Ctrl]/ [Command] and resize one of the tracks in this way. If “Snap Track Heights” is activated on the Track scale pop-up (see below), the track height will change in fixed increments when you resize it.

This behavior is different when “Enlarge Selected Track” is activated on the Edit menu (see below).

• You can also change the width of the Track list area, by

dragging the border between the Track list and the event display.

• By default, the controls shown for tracks in the Track list

will adapt to the track size. This means that when resizing a track’s height or width the controls will be placed where they best “fit in”.

If you prefer to have the controls in fixed positions, you can deactivate the option “Wrap Controls” in the Track Controls settings dialog (see “Cus-

tomizing track controls” on page 472).

• You can decide for each track type which controls

should be shown in the Track list – see “Customizing

track controls” on page 472.

The Project window

Page 36

• You can use the Track scale pop-up (opened by clicking

Click here…

…to open the context menu.

the arrow button above the vertical zoom control) to set the number of tracks to view in the current Project window.

The track height will be adjusted to show only the number of tracks specified on the pop-up menu. By selecting “Zoom N Tracks” from the popup you can manually set the number of tracks to fit in the current Project window.

• Tracks can also be divided vertically in lanes – see “Ed-

iting in Lane Display mode” on page 50.

The Enlarge Selected Track option

When this option is activated on the Edit menu (or in the Preferences, Editing–Project & Mixer page), the selected track is enlarged automatically. This is useful if you are stepping through the tracks in the Track list, to check or edit the settings. The tracks will revert to the size they had before when they are deselected. You can adjust the size directly in the Track list if the default enlargement factor does not suit you.

While this is the program behavior you will want in most cases, it may be a disadvantage when changing the track height you started out with for one or more tracks (i.e. their “original” height, before “Enlarge Selected Track” was activated). As soon as you try to resize a track, it is selected and automatically enlarged. Instead of turning off “Enlarge Selected Track”, resizing the desired track(s) and the activating “Enlarge Selected Track” again, you can resize a track in the Track list without selecting it.

Proceed as follows:

1. Move the mouse pointer over the lower border of the (unselected) track you want to resize.

The mouse pointer turns into a divider symbol.

2. Hold down [Alt]/[Option] and drag the lower border of

the track until it reaches the desired height.

Now, when you select this track, (and “Enlarge Selected Track” is activated), it will be enlarged. It will revert to the changed size, when you select a different track.

Zoom presets and Cycle markers

The pop-up menu to the left of the horizontal zoom control allows you to select, create and organize zoom presets. These are useful if you want to toggle between different zoom settings (e.g. one where the whole project is displayed in the project window and another with a high zoom factor for detailed editing). With this pop-up menu, you can also zoom in on the area between cycle markers in the project.

The upper part of the menu lists the zoom presets:

• To store the current zoom setting as a preset, select

Add from the pop-up menu.

A dialog appears, allowing you to type in a name for the preset.

• To select and apply a preset, select it from the pop-up

menu.

• The “Zoom Full” preset is always available. Selecting

this option zooms out so that the whole project is visible. “The whole project” means the timeline from the project start to the length set in the Project Setup dialog (see

“The Project Setup dialog” on page 34).

• If you want to delete a preset, select “Organize…” from

the pop-up menu.

In the dialog that appears, select the preset in the list and click the Delete button. The preset is removed from the list.

The Project window

Page 37

• If you want to rename a preset, select “Organize…”

from the pop-up menu.

In the dialog that appears, select the desired preset in the list and click the Rename button. A second dialog opens, allowing you to type in a new name for the preset. Click OK to close the dialogs.

Zoom presets are global for all projects, i.e. they are available in all projects you open or create.

The middle part of the pop-up lists any cycle markers you have added in the project:

• If you select a cycle marker from this menu, the event display is zoomed in to encompass the marker area (see

“Markers” on page 54).

• You cannot edit the cycle markers in this pop-up menu. For information on editing markers, see “Editing markers in

the Marker window” on page 54.

Only the cycle markers you create in the current project are available on the menu.

The Zoom history

Cubase maintains a history of recent zoom stages, allowing you to undo and redo zoom operations. This way you can zoom in several steps and then easily go back to the zoom stage at which you started.

There are two ways to invoke Undo Zoom and Redo Zoom:

• Use the items on the Zoom submenu on the Edit menu.

You can also assign key commands for these.

• Double-click with the Zoom tool (magnifying glass) to Undo Zoom.

Press [Alt]/[Option] and double-click to Redo Zoom.

Adjusting how parts and events are shown

The Preferences on the File menu (the Cubase menu, under Mac OS X) contains several settings for customizing the display in the Project window.

The Event Display page contains common settings for all track types:

Option Description

Colorize Event Background

Show Event Names

Determines whether the backgrounds or “contents” (waveforms, etc.) of parts and events will be colorized. See “Handling tracks” on page 38.

Determines whether the names of parts and events should be shown in the Project window.

Option Description

Transparent Events

Show Data on Small Track Heights

When this is activated, events and parts will be transparent, showing the waveforms and MIDI events only.

If this is activated, the contents of events and parts will be shown, even if the height of a track is very small.

The Event Display–Audio page contains settings for audio events:

Option Description

Interpolate Audio Images

Wave Image Style

Show Event Volume Curves Always

Fade Handles always on top

Thick Fade Lines

Show Waveforms

Background Color Modulation

If the option is deactivated, single sample values are drawn as “steps”. If the option is activated they are interpolated to form “curves”.

Determines whether audio waveforms should be displayed as solid images, frames or “inverted” images (solid+frame). This selection affects all waveform images in the Project window, Sample Editor and Audio Part Editor. Note that the “Framed” and “Solid and Framed” styles are more demanding for the computer. If the system feels slower in these modes, please switch back to “Solid” wave image style.

If this is activated the “volume curves” created with the volume and fade handles are always shown – if not, the curves are only shown for selected events.

When this option is activated, the fade handles stay at the top of the event, and vertical help lines indicate the exact end or start points of fades.

If this option is activated, the fade lines and volume curves are thicker, increasing their visibility.

Determines whether audio waveforms should be shown at all.

When this is activated, the backgrounds of audio waveforms are displayed in a different way, reflecting the waveform dynamics. This is especially useful to get an overview when working with small track heights.

The Event Display–MIDI page contains settings for MIDI parts:

Option Description

Default Edit Action

Part Data Mode Determines if and how events in MIDI parts should be

Determines which editor should be opened when you double-click a MIDI part or select it and press [Ctrl]/ [Command]-[E]: the Key, List, In-Place, Drum or Score Editor. Note that this setting is overridden for tracks with drum maps if the option “Edit as Drums when Drum Map is assigned” (see below) is activated.

shown in the Project window: as score notes, as drum notes or as lines. If “No Data” is selected, events will not be shown at all. Note that this setting is overridden for tracks with drum maps if the option “Edit as Drums when Drum Map is assigned” (see below) is activated.

The Project window

Page 38

Option Description

Show Controllers

Edit as Drums when Drum Map is assigned

Note Name Style

Governs whether non-note events (controllers, etc.) should be shown in MIDI parts in the Project window.

If this is activated, parts on MIDI tracks with drum maps assigned will be shown with drum note symbols in the Project window. Also, the parts will automatically open in the Drum Editor when double-clicked (overriding the Default Edit Action setting above).

Determines how MIDI note names (pitches) should be displayed in editors, etc.

The Event Display–Video page contains settings for video events:

Option Description

Show Video Thumbnails

Video Cache Size

When this is activated, thumbnail frames of the video contents are shown on the Video track.

This determines how much memory is available for video thumbnails. If you have long video clips and/or work with a large zoom factor (so that a lot of frames are shown in the thumbnails), you may have to raise this value.

Zooming and navigating in the overview line

By clicking the Show Overview button on the toolbar, an extra pane appears under the toolbar; the project overview line.

• You can drag the track view rectangle to view other

sections of the project.

This can also be done by clicking anywhere in the upper part of the overview – the track view rectangle will be moved to where you clicked. The number of tracks shown will not change.

Handling tracks

To add a track to the project, select “Add Track” from the Project menu and select a track type from the submenu that appears. The new track is added below the currently selected track in the Track list.

• The items on the “Add Track” submenu are also avail-

able on the context menu.

This is accessed by right-clicking in the Track list.

Show Overview button

In the overview line, events and parts on all tracks are displayed as boxes. You can use the overview line to zoom in or out, and for navigating to other sections of the project. This is done by moving and resizing the track view rectangle in the overview line:

The track view rectangle

• The track view rectangle indicates the section of the project currently displayed in the event display.

• You zoom in or out horizontally by resizing the rectangle.

Resize it by dragging the edges of the rectangle.

The Project window

• If you select Audio, MIDI, Group Channel or Instrument

from the Add Track submenu, a dialog opens, allowing you to insert several tracks in one go.

Just enter the desired number of tracks in the value field.

• For audio and group channel tracks, the channel config-

uration – mono, stereo or a surround configuration (Cubase only) – can be set in the Configuration pop-up.

• The Browse Sounds option in the Add Track dialog is

described in the chapter “Working with Track Presets” on

page 288.

• In the Preferences (Editing–Project & Mixer page), you

can find the option “Auto Track Color Mode”.

This offers you several options for automatically assigning colors to tracks that are added to the project.

Page 39

Once you have created tracks, you can manipulate and re-

This track is selected.

arrange them in various ways:

• To rename a track, double-click in the name field and type in a new name.

If you hold down any modifier key when pressing [Return] to close the name field, all events on the track will get the name you entered.

• To select a track, click on it in the Track list.

A selected track is indicated by a light gray color in the Track list.

It is possible to select several tracks by pressing [Ctrl]/[Command] and clicking on them. [Shift]-click to select a continuous range of tracks.

• To move a track, click and drag it up or down in the list.

• To duplicate a track, complete with all contents and

channel settings, right-click in the Track list and select “Duplicate tracks” from the context menu, or select “Duplicate tracks” from the Project menu.

The duplicated track will appear below the original track.

• You can select a default color for a track by activating “Show Track Colors” above the Track list and selecting a color from the Color pop-up menu on the toolbar. This color will be used for all events on the track and will also be shown in the Mixer. You can override the default track color for individual events and parts by using the Color tool or the Color Selector pop-up menu. For more information, see “Applying track and event colors” on page 475.

The option “Colorize Event Background” in the Preferences dialog (Event Display page) determines whether the backgrounds or waveforms of events will be colorized.

• To remove a track, right-click on it in the Track list and select “Remove Selected Tracks” from the context menu.

You can also remove multiple selected tracks, by selecting “Remove Selected Tracks” either from the context menu or from the Project menu. Furthermore, you can remove all tracks not containing any events by selecting “Remove Empty Tracks” from the Project menu.

• To change the track height of an individual track, click on its lower border in the Track list and drag up or down, see “Resizing tracks in the Track list” on page 35.

Ö Note that you can also automatically enlarge the selected track, see “The Enlarge Selected Track option” on

page 36.

Disabling audio tracks

Audio tracks can be disabled by selecting “Disable Track” from the Track list context menu. Disabling a track is similar to muting it (see “Muting events” on page 49), since a disabled track will not be played back. However, disabling a track not only “zeroes” the output volume from the track, but actually shuts down all disk activity for it. See “About

track disable/enable” on page 63 for more information.

Track folding

On the Project menu you will find the Track Folding submenu, allowing you to quickly show, hide or invert what is displayed in the Project window event display. This enables you for example to divide the project into several parts (by creating several folder tracks for the different project elements) and showing/hiding their contents by selecting a menu function (or using a key command). You can also fold in automation tracks this way. The following options are available:

• Toggle Selected Track

When you select this menu option, the fold state of the selected track is reversed, i.e. if the track was folded in (its elements (subtracks) were hidden), it is now unfolded (all subtracks displayed) and vice versa.

• Fold Tracks

Select this menu option to fold in all open folder tracks in the Project window. Please note that the exact behavior of this function depends on the “Deep Track Folding” setting in the Preferences, see below.

• Unfold Tracks

Select this menu option to unfold all folder tracks in the Project window. Please note that the exact behavior of this function depends on the “Deep Track Folding” setting in the Preferences, see below.

• Flip Fold States

Select this menu option to flip the fold states of the tracks in the Project window. This means that all tracks that were folded in will be unfolded and all unfolded tracks will be folded in, respectively.

Ö You can assign key commands for these menu options in the Key Commands dialog (Project category).

The Project window

Page 40

In the Preferences (Editing–Project & Mixer page), you can find the following option affecting the track folding behavior:

• Deep Track Folding

When this is activated, any folding settings you make in the Track Folding submenu of the Project menu also affect the sub-elements of the tracks, i.e. if you fold in a folder track which contains 10 audio tracks 5 of which have several automation tracks open, all these audio tracks within the folder track will be folded in as well.

• You can resize the upper part by clicking and dragging

the divider between the Track list sections.

Dividing the Track list (Cubase only)

It is possible to divide the Track list into two parts. Both sections will have independent zoom and scroll controls (if needed), but resizing the window vertically will affect the lower section only (if possible). This is useful if you’re working with a video track along with multi-track audio for example. This way, you can place the video track in the upper Track list, letting you scroll the audio tracks separately in the lower Track list, referencing them against the video track.

• To divide the Track list, click the “Divide Track List” button in the top right corner of the Track list.

• To revert to a single Track list, click the button again. When the Track list is divided into two parts, the following

applies:

• If you add tracks from the Add Track submenu of the Project menu, Video tracks, Marker tracks and Arranger tracks will automatically be placed in the upper part of the Track list.

If the Track list already contains tracks of the type Video, Marker or Arranger, these will automatically be moved to the upper part when you divide the Track list. All other types of tracks will be placed in the lower part.

• If you add tracks from the context menu invoked by right-clicking in the Track list, tracks will be added to the part of the Track list in which you click.

• You can move any type of track from the lower Track list to the upper and vice versa by right-clicking it in the Track list and selecting “Toggle Track List” from the context menu.

Switching between musical and linear time base

Tracks can be either musical (tempo) or linear (time) based.

• On a track using linear time base, the events will be po-

sitioned on specific time positions – changing the playback tempo will not affect the time position of events.

• On a track using musical time base, the positions of

events are represented as meter values (bars, beats, 1/16th notes and ticks, with 120 ticks per 1/16th note). If you change the playback tempo, the events will play back at an earlier or later time.

• In the Preferences (Editing page), you can find the op-

tion “Default Track Time Type” (Cubase only).

This allows you to specify the default track time type for new tracks (Audio, Group/FX, MIDI and Marker tracks). When you change this setting, all new tracks will use the selected time type. You can choose between “Musical”, “Time Linear” and “Follow Transport Main Display”. Selecting “Musical” will cause all added tracks to be set to musical time type. When you select “Time Linear”, all new tracks will use linear time base. The third option uses the primary time format setting on the Transport panel. When this is set to “Bars+Beats”, tracks with musical time base will be added. When this is set to any of the other options (Seconds, Timecode, Samples, etc.), all new tracks will use linear time base.

Whether to use musical or linear time base depends on the type of project and recording situation. You can always change this setting individually for each track, by clicking the musical/linear time base button in the Inspector or Track list. Musical time base is indicated by a note symbol, while linear time base is indicated by a clock symbol.

The Project window

Page 41

Internally, events on musical time based tracks use the

Musical time base selected

Linear time base selected

same high precision for positioning (64 bit floating point values) as linear time based events. However, switching between linear and musical time base results in a very small loss of precision (introduced by the mathematical operations used for scaling values in the two different formats). Therefore you should avoid switching repeatedly between the two modes.

For more information about tempo changes, see the chapter “Editing tempo and signature” on page 401.

Adding events to a track

There are a number of ways to add events to a track:

• By recording (see “Basic recording methods” on page

67).

• By dragging files and dropping them on the track at the desired position.

You can create events by dragging and dropping from the following locations:

•The desktop

• The MediaBay and its related windows (see the chapter “The

MediaBay” on page 273)

•The Pool

• A library (a Pool file that is not attached to a project)

• The “Find media” dialog

• The Project window of another open project

• The Audio Part Editor of any open project

• The Sample Editor – press [Ctrl]/[Command] and drag to create an event of the current selection, or click in the left column of the region list and drag to create an event from a region.

• By selecting “Audio File…” or “Video File…” from the Import submenu on the File menu.

This opens a file dialog, allowing you to locate the file you wish to import. When you import a file this way, a clip is created for the file and an event that plays the whole clip is inserted on the selected track, at the position of the project cursor. You can also import MIDI files by using the Import submenu, but this works in a slightly different way (see “Exporting and importing standard

MIDI files” on page 464).

• By grabbing audio CD tracks and converting them to audio files (see “Importing audio CD tracks” on page 459).

• By importing only the audio portion of a video file and converting it to an audio file (see “Extracting audio from a

video file” on page 450).

• By using Copy and Paste on the Edit menu.

This allows you to copy all kinds of events between projects. You can also copy events within the project, e.g. from the Sample Editor.

• By drawing.

Some types of events (markers and automation events) can be drawn directly into the Project window. For audio and MIDI tracks, you can draw parts (see “Creating parts” on page 42).

Audio file import options

When you are importing audio files there are a number of options concerning how the files should be treated by Cubase:

• You can choose to copy the file into the audio folder of the project and have the project make reference to the copied file rather than the original file. This helps you keep your project “self-contained”.

• You can choose to split stereo and multi-channel files into a number of mono files.

• Furthermore, you may want all files in the project to have the same sample rate and sample size (resolution).

The Preferences dialog (Editing–Audio page) contains a setting that lets you decide which options to use. Select one of the following options on the “On Import Audio Files” pop-up menu:

While you drag the clip in the Project window, its position will be indicated by a marker line and a numerical position box. See also “Using

drag and drop” on page 264.

The Project window

Page 42

• Open Options Dialog

An Options dialog appears when you import, allowing you to select whether you want to copy the files to the Audio folder and/or convert them to the project settings. Please note the following: – When importing a single file of a format other than the project settings, you can specify which properties (sample rate and/or resolution) should be changed. – When importing multiple files at the same time, you can select to convert the imported files automatically if necessary, i.e. if the sample rate is different than the project’s or the resolution is lower than the project setting.

• Use Settings

No Options dialog will appear when you import. Instead, you can choose to make any of the options below the pop-up the standard action(s). Activate any number of the following options to have them performed automatically each time you import audio files:

Option Description

Copy Files to Working Directory

Convert and Copy to Project If Needed

Split multichannel files

If files are not already in the project’s audio folder they are copied there before being imported.

If files are not already in the project’s audio folder they are copied there before being imported. Furthermore, if the files have a different sample rate or a lower resolution than the project settings, they are automatically converted.

If you import a multi-channel audio file (including twochannel stereo files), it will be split into a number of mono files – one for each channel – which are placed on separate, automatically created mono tracks.

Creating parts

Parts are containers for MIDI or audio events. If you record MIDI, a MIDI part is automatically created, containing the recorded events. You can also create empty audio or MIDI parts and later add events to them.

There are two ways to do this:

• Draw a part on a MIDI or audio track with the Pencil tool.

You can also draw parts by pressing [Alt]/[Option] and using the Arrow tool.

• Double-click with the Arrow tool on a MIDI or audio track, between the left and right locator.

To add events to a MIDI part, you use the tools and functions in a MIDI editor (see “The Key Editor – Overview” on

page 340). Adding events to audio parts is done in the

Audio Part Editor (see “Window overview” on page 255) by pasting or by using drag and drop.

• You can also gather existing audio events into a part, by

using the “Events to Part” function on the Audio menu.

This creates an audio part containing all selected audio events on the same track. To remove the part and make the events appear as independent objects on the track again, select the part and use the “Dissolve Part” function on the Audio menu.

Auditioning audio parts and events

Audio parts and events can be auditioned in the Project window with the Play tool:

When auditioning, audio will be routed directly to the Control Room (Cubase only), if the Control Room is activated. When the Control Room is deactivated, the audio will be routed to the default output bus, bypassing the audio channel’s settings, effects and EQs. In Cubase Studio, the Main Mix bus is always used for monitoring.

1. Select the Play tool.

Note that the Play tool and the Scrub tool share the same tool button. If the tool icon on the toolbar doesn’t show a speaker symbol, first click on the icon to select it, then click again and select “Play” from the pop-up menu.

2. Click where you want playback to start, and keep the

mouse button pressed.

Only the track on which you click is played back, starting at the click position.

3. Release the mouse button to stop playback.

The Project window

Page 43

Scrubbing

The Scrub tool allows you to locate positions in the audio by playing back, forwards or backwards, at any speed:

1. Select the Scrub tool.

Note that the Play tool and the Scrub tool share the same tool button. If the tool icon on the toolbar doesn’t show a “scrub symbol”, first click on the icon to select it, then click again and select “Scrub” from the pop-up menu.

2. Click at the desired position and keep the mouse button pressed.

The project cursor is moved to the position at which you click.

3. Drag to the left or right.

The project cursor follows the mouse pointer and the audio is played back. The speed and pitch of the playback depend on how fast you move the pointer.

You can adjust the responsiveness of the Scrub function in the Preferences (Transport–Scrub page).

Ö It is also possible to “scrub” the whole project with the Jog wheel on the Transport panel (Cubase only).

See “Project scrubbing – the Jog Wheel (Cubase only)” on page 63.

• Note that scrubbing can be quite a burden on your system. To avoid playback problems, you will find the “CPU Saving Scrub Mode” option in the Preferences (Transport–Scrub page).

When you activate this option, scrubbing will be less demanding on the processor. This can be very useful when scrubbing in a large project, where the “normal” scrub behavior leads to processing overloads. When “CPU Saving Scrub Mode” is activated, the effects are disabled for scrubbing and the resampling quality is lower.

Selecting events

Selecting events is done using any of the following methods:

• Use the Arrow tool.

The standard selection techniques apply.

• Use the Select submenu on the Edit menu.

The options are:

Option Description

All Selects all events in the Project window. None Deselects all events. Invert Inverts the selection – all selected events are dese-

In Loop Selects all events that are partly or wholly between

From Start to Cursor Selects all events that begin to the left of the project

From Cursor to End Selects all events that end to the right of the project

Equal Pitch These are available in the MIDI Editors (see “Select-

Select Controllers in Note Range

All on Selected Tracks

Select Event This is available in the Sample Editor (see “Window

Left/Right Selection Side to Cursor

lected and all events that were not selected are selected instead.

the left and right locator.

cursor.

ing notes” on page 346) and the Sample Editor (see “Using the Select menu” on page 227).

This is available in the MIDI Editors (see “Selecting

controllers within the note range” on page 346).

Selects all events on the selected track.

overview” on page 221).

These two functions are only used for range selection editing (see “Creating a selection range” on page 51).

Editing parts and events

This section describes techniques for editing in the Project window. If not explicitly stated, all descriptions apply to both events and parts, even though we use the term “event” for convenience.

Ö When you are using the tools for editing, you can in many cases get additional functions by pressing modifier keys (e.g. pressing [Alt]/[Option] and dragging with the Arrow tool creates a copy of the dragged event).

On the following pages, the default modifier keys are described – you can customize these in the Preferences (Editing–Tool Modifiers page), see “Setting up tool modifier keys” on page 483.

The Project window

Note that these functions work differently when the Range Selection tool is selected (see “Creating a

selection range” on page 51).

• Select all events on a track by right-clicking on it in the

Track list and selecting “Select All Events” from the context menu.

• You can also use the arrow keys on the computer key-

board to select the closest event to the left, right, above or below.

If you press [Shift] and use the arrow keys, the current selection will be kept, allowing you to select several events.

Page 44

• If the option “Auto Select Events under Cursor” is acti-

vated in the Preferences (Editing page), all events on the selected track(s) that are “touched” by the project cursor are automatically selected.

This can be helpful when rearranging your project, since it allows you to select whole sections (on all tracks) by selecting all tracks and moving the project cursor.

• It is also possible to select ranges, regardless of the event and track boundaries.

This is done using the Range Selection tool (see “Range editing” on

page 51).

• Note that in the Preferences (Editing page), you can find the option “Use Up/Down Navigation Commands for selecting Tracks only”.

By default, tracks are selected with the up/down arrow keys on the computer keyboard. However, these are also used for selecting events (see above) which can lead to confusing results in some cases. Since track selection is a most vital operation in both editing and mixing, you have the option to use the navigation controls for track selection only. The following applies:

• When this option is deactivated and no event/part is selected in the Project window, the up/down arrow keys on the computer keyboard are used to step through the tracks in the Track list – just as you would expect this to work.

• When this option is deactivated and an event/part is selected in the Project window, the up/down arrow keys still step through the tracks in the Track list – but on the currently selected track, the first event/part will automatically be selected as well. If this is not the desired behavior, you have to activate “Use Up/Down Navigation Commands for selecting Tracks only”.

• When this option is activated, the up/down arrow keys are only used to change the track selection – the current event/ part selection in the Project window will not be altered.

• Also in the Preferences (Editing–Tools page), you can

find the Cross Hair Cursor options section.

This allows you to display a cross hair cursor when working in the Project window and editors, facilitating navigation and editing, especially when arranging in large projects. You can set up the colors for the line and the mask of the cross hair cursor, and define its width. The cross hair cursor works as follows:

• When the Selection tool (or one of its subtools) is selected, the cross hair cursor appears when you start moving/copying a part/event, or when using the event trim handles.

• When the Pencil tool, the Scissors tool or any other tool that makes use of this function is selected, the cross hair cursor appears as soon as you move the mouse over the event display.

• The cross hair cursor is only available for tools where such a function is of any use. The Mute tool for example does not use a cross hair cursor, as you have to click directly on an event to mute it.

Moving events

To move events in the Project window, use the following methods:

• Click and drag to a new position.

All selected events will be moved, maintaining their relative positions. You can only drag events to tracks of the same type. If Snap is activated, this determines to which positions you can move the events (see “The Snap

function” on page 56).

Note also that you can restrict movement to be either horizontal or vertical only, by holding down [Ctrl]/[Command] while dragging.

You will note that there is a slightly delayed response when you move an event by dragging. This helps you avoid accidentally moving events when you click on them in the Project window. You can adjust this delay with the Drag Delay setting in the Preferences (Editing page).

• Select the event and edit the Start position in the info line.

• Use the “Move to” options on the Edit menu.

The following options are available:

Option Description

Cursor Moves the selected event to the project cursor position. If

Origin Moves the selected events to their original positions, i.e.

Front/Back This function doesn’t actually change the position of the

there are several selected events on the same track, the first event will start at the cursor, and the following will be lined up end-to-start after the first one.

the positions at which they were originally recorded.

events, but moves the selected events to the front or back, respectively. This is useful if you have overlapping events, and want to see one that is partially obscured. For audio events, this is an extra important feature, since only the visible sections of events will be played back. Moving an obscured audio event to front (or moving the obscuring event to back) will allow you to hear the whole event on playback (see also “Overlapping events” on

page 256).

Note that it is also possible to use the “To Front” function on the event context menu for this (although this works in a different way, see “Create Events mode (Preferences)” on page 76).

The Project window

Page 45

• Use the Nudge buttons in the toolbar.

These move the selected events to the left or right. The amount of movement depends on the selected display format (see “The Project Setup di-

alog” on page 34) and the value set on the Grid pop-up menu.

When the Range Selection tool is used, the Nudge buttons move the selection range (see “Moving and

duplicating” on page 52).

Ö The Nudge buttons are not visible in the toolbar by default.

You can decide which items should be visible by right-clicking in the toolbar and activating the corresponding option on the context menu. See “The setup context menus” on page 471 for more information.

Duplicating events

Events can be duplicated in the following ways:

• Hold down [Alt]/[Option] and drag the event to a new position.

If Snap is activated, this determines to which positions you can copy the events (see “The Snap function” on page 56).

If you hold down [Ctrl]/[Command] as well, movement direction is restricted to either horizontal or vertical. That means if you drag an event vertically it cannot be moved horizontally at the same time.

• Audio and MIDI parts can also be duplicated by pressing [Alt]/[Option]-[Shift] and dragging.

This creates a shared copy of the part. If you edit the contents of a shared copy, all other shared copies of the same part are automatically edited in the same way.

Note:

• When you duplicate audio events, the copies are al-

ways shared. This means that shared copies of audio events always refer to the same audio clip (see “Audio

processing” on page 205).

• You can convert a shared copy to a real copy by select-

ing “Convert to Real Copy” from the Edit menu. This creates a new version of the clip (that can be edited independently) and adds this to the Pool. Note that no new files are created by this operation – for that you need to use the “Bounce Selection” function from the Audio menu (see “Ex-

porting regions as audio files” on page 269).

• Selecting “Duplicate” from the Edit menu creates a

copy of the selected event and places it directly after the original.

If several events are selected, all of these are copied “as one unit”, maintaining the relative distance between the events.

• Selecting “Repeat…” from the Edit menu opens a dia-

log, allowing you to create a number of copies (regular or shared) of the selected event(s).

This works just like the Duplicate function, but you can specify the number of copies.

• You can also perform the Repeat function by dragging:

Select the event(s) to repeat, press [Alt]/[Option], click the handle in the lower right corner of the last selected event and drag to the right.

The longer to the right you drag, the more copies are created (as shown by the tooltip).

• Selecting “Fill Loop” from the Edit menu creates a num-

ber of copies starting at the left locator and ending at the right locator.

The last copy is automatically shortened to end at the right locator position.

Shared copies are indicated by showing the name in italic text and an icon in the right corner of the part.

The Project window

Page 46

Using Cut, Copy and Paste

You can cut or copy selected events, and paste them in again, using the functions on the Edit menu.

• When you paste an audio event, it is inserted on the selected track, positioned so that its snap point is aligned with the cursor position.

If the selected track is of the wrong type, the event will be inserted on its original track. See “The Snap function” on page 56 for information about the snap point.

• If you use the “Paste at Origin” function, the event is pasted at its original position (the position from which you cut or copied it).

Renaming events

By default, audio events show the name of their clip, but you can enter a separate descriptive name for separate events if you like. This is done by selecting the event and typing in a new name in the “Description” field in the info line.

• You can also give all events on a track the same name as the track by changing the track name, holding down a modifier key and pressing [Return].

See “Handling tracks” on page 38.

Splitting events

You can split events in the Project window in the following ways:

• Click with the Scissors tool on the event you want to split.

If Snap is activated, this determines the exact split position (see “The

Snap function” on page 56). You can also split events by pressing [Alt]/

[Option] and clicking with the Arrow tool.

• Select “Split at Cursor” from the Edit menu.

This splits the selected events at the position of the project cursor. If no events are selected, all events (on all tracks) that are intersected by the project cursor will be split.

• Select “Split Loop” from the Edit menu.

This splits events on all tracks at the left and right locator positions.

Ö If you split a MIDI part so that the split position intersects one or several MIDI notes, the result depends on the option “Split MIDI Events” in the Preferences (Editing– MIDI page).

If the option is activated, the intersected notes will be split (creating new notes at the beginning of the second part). If it is deactivated, the notes will remain in the first part, but “stick out” after the end of the part.

Gluing events together

You can glue events together using the Glue Tube tool. There are three possibilities:

• Clicking on an event with the Glue Tube tool glues it to-

gether with the next event on the track. The events do not have to touch one another.

The result is a part containing the two events, with one exception: If you first split an event and then glue the two sections together again (without moving or editing them first), they become a single event again.

• You can select several events on the same track and

click on one of them with the Glue Tube tool.

A single part is created.

• When you hold down [Alt]/[Option] while clicking on an

event with the Glue Tube tool, this event will be glued together with all following events on this track.

You can change the default key command for this in the Preferences (Editing–Tool Modifiers page).

Resizing events

Resizing events means to move their start or end positions individually. In Cubase, there are three types of resizing:

Resizing type Description

Normal Sizing The contents of the event stay fixed, and the start or end

Sizing Moves Contents

Sizing Applies Time Stretch

point of the event is moved to “reveal” more or less of the contents.

The contents follow the moved start or end of the event (see the figure below).

The contents will be time stretched to fit the new event length (see the separate description on “Resizing events

using time stretch” on page 47).

The Project window

Page 47

To select one of the resizing modes, select the Arrow tool and then click again on the Arrow tool icon on the toolbar. This opens a pop-up menu from which you can select one of the resizing mode options.

The icon on the toolbar will change, indicating the selected resizing mode.

The actual resizing is done by clicking and dragging the lower left or right corner of the event. If Snap is activated, the Snap value determines the resulting length (see “The

Snap function” on page 56).

Normal sizing

• It is also possible to resize events by using the Trim but-

tons (located in the Nudge palette) on the toolbar.

This will move the start or end position of the selected Event(s) by the amount set on the Grid pop-up menu. The sizing type currently selected applies to this method too, with the exception of “Sizing Applies Time Stretch” which is not possible with this method. You can also use key commands for this (by default, press [Ctrl]/[Command] and use the left and right arrow key).

Ö Note that the Nudge palette is not visible in the toolbar by default. See “The setup context menus” on page 471 for instructions on how to show and hide items in the toolbar.

Ö When resizing events, any automation data will not be taken into account.

Sizing moves contents.

• If several events are selected, all will be resized in the same way.

• You can also resize events with the Scrub tool.

This works just the same as when resizing with the Arrow tool, but the audio under the pointer is played back (scrubbed) while you drag.

The Project window

Resizing events using time stretch

If you want to resize a part and make its contents “fit” the new size, you should use this option. Proceed as follows:

1. Click the Arrow icon on the toolbar and select the “Siz-

ing Applies Time Stretch” option from the pop-up menu.

2. Point close to the end point of the part you want to

stretch.

3. Click and drag left or right.

When you move the mouse, a tooltip shows the current mouse position and length of the part. Note that the snap value applies, as with any part operation.

Page 48

4. Release the mouse button.

The padlock symbol indicates that one or more of the lock options are activated for the event.

The part is “stretched” or “compressed” to fit the new length.

• For MIDI parts, this means that the note events are stretched (moved and resized).

Controller data will be moved.

• For audio parts, this means that the events are moved, and that the referenced audio files are time stretched to fit the new length.

A dialog shows the progress of the time stretch operation.

Ö You can adjust which algorithm should be used for the time stretch algorithm in the Preferences (Editing–Audio page).

For more information about time stretch, see “Time Stretch” on page 212.

Sliding the contents of an event or part

You can move the contents of an event or part without changing its position in the Project window. By default, this is done by pressing [Alt]/[Option]-[Shift], clicking in the event or part and dragging to the left or right.

When sliding the contents of an audio event, you cannot slide past the start or end of the actual audio clip. If the event plays the whole clip, you cannot slide the audio at all.

Group editing operations include:

• Selecting events.

• Moving and duplicating events.

• Resizing events.

• Adjusting fade-in and fade-out (audio events only, see “Creat-

ing fades” on page 89).

• Splitting events (splitting one event will automatically split any other grouped events that are intersected by the split position).

• Locking events.

• Muting events (see below).

• Deleting events.

Locking events

If you want to make sure you don’t edit or move an event by accident, you can lock it. Locking can affect one (or any combination) of the following properties:

Lock Options Description

Position If this is locked, the event cannot be moved. Size If this is locked, the event cannot be resized. Other If this is locked, all other editing of the event is disabled.

This includes adjusting the fades and event volume, processing, etc.

• To specify which of these properties should be affected

by the Lock function, use the “Lock Event Attributes” popup menu in the Preferences (Editing page).

Grouping Events

Sometimes it is useful to treat several events as one unit. This can be done by grouping them: Select the events (on the same or different Tracks) and select “Group” from the Edit menu.

• To lock events, select them and select “Lock…” from

the Edit menu.

The events will be locked according to the options specified in the Preferences.

Grouped events are indicated by a group icon in the right corner.

If you edit one of the grouped events in the Project window, all other events in the same group are affected too (if applicable).

The Project window

• You can adjust the lock options for a locked event by se-

lecting it and selecting “Lock…” from the Edit menu again.

This opens a dialog in which you can activate or deactivate the desired lock options.

Page 49

• To unlock an event (turn off all lock options), select it and select “Unlock” from the Edit menu.

• It is also possible to lock a whole track, by clicking the padlock symbol in the Track list or in the Inspector.

This disables all editing of all events on the track.

Muting events

To mute individual events in the Project window, proceed as follows:

• To mute or unmute a single event, click on it with the Mute tool.

another track in the Track list will automatically solo that track instead – the solo state “moves” with the track selection. If the option isn’t activated, the track you solo stays soloed, regardless of the selection.

Removing events

To remove an event from the Project window, use any of the following methods:

• Click on the event with the Eraser tool.

Note that if you press [Alt]/[Option] while you click, all following events on the same track will be deleted, but not the event you clicked and all events before it.

• Select the event(s) and press [Backspace], or select

“Delete” from the Edit menu.

• To mute or unmute several events, select them – either by using the standard selection techniques, or by using one of the options on the Select submenu on the Edit menu – and click on one of the selected events with the Mute tool.

All selected events will be muted.

• You can also click in an empty area with the Mute tool and drag a selection rectangle around several events you want to mute or unmute, and then click on one of them with the Mute tool.

• You can mute events by selecting them and selecting “Mute” from the Edit menu.

Similarly, you can unmute the selected events by selecting “Unmute” from the Edit menu.

• You can also change the mute status of selected events on the info line.

Muted events can be edited as usual (with the exception of adjusting fades), but are not played back.

Muted events are “grayed out”.

• You can also mute whole tracks by clicking the Mute (“M”) button in the Track list, the Inspector or the mixer.

Clicking the Solo (“S”) button for a track mutes all other tracks. Note that there are two modes for the track solo function: If the option “Enable Solo on Selected Track” is activated in the Preferences (Editing–Project & Mixer page) and you have soloed a track, selecting

Creating new files from events

An audio event plays a section of an audio clip, which in turn refers to one or more audio files on the hard disk. However, in some situations you may want to create a new file that consists only of the section played by the event. This is done with the function “Bounce Selection” on the Audio menu:

1. Select one or several audio events.

2. Set up fade in, fade out and event volume (on the info

line or using the volume handle) as desired.

These settings will be applied to the new file. For details on fades and event volume, see “Creating fades” on page 89.

3. Select “Bounce Selection” from the Audio menu.

You are asked whether you want to replace the selected event or not.

• If you click “Replace”, a new file is created, containing

only the audio in the original event. A clip for the new file is added to the Pool, and the original event is replaced by a new event playing the new clip.

• If you click “No”, a new file is created and a clip for the

new file is added to the Pool.

The original event is not replaced.

You can also apply the Bounce Selection function to an audio part. In that case, the audio from all events in the part will be combined into a single audio file. If you choose “Replace” when asked, the part will be replaced with a single audio event playing a clip of the new file.

The Project window

Page 50

Editing in Lane Display mode

When you are recording in Stacked cycle recording mode, each take ends up on a separate lane on the track, see

“Recording audio in Stacked mode” on page 77 and “Cycle Record mode: Stacked/Stacked 2 (No Mute)” on page

82. However, you can also select this lane mode manually

for individual tracks, and use it when editing in the Project window. This makes it easier to view and handle overlapping events and parts.

Audio tracks

1. In the Track list or in the Inspector for the selected track, click the Lane Display Type button and select “Lanes Fixed” from the pop-up menu.

The audio track is divided vertically into two lanes. By default, all audio events end up in the first (top) lane.

2. Now you can move events or parts between lanes, either by dragging or by using the “To Front” commands on the Edit menu or the context menu (this will move the event on the lane that has playback priority).

Note that if there are overlapping audio events, the audio on the lowest lane has playback priority – moving events between lanes affects what will be heard!

If the vertical zoom factor is sufficiently high, the sections that will be heard on playback are indicated in green.

• Note that there will always be an extra, empty lane at the bottom of the track – moving an event there always will add another lane.

Depending on the number of lanes used, you may want to adjust the vertical zoom for the track – simply drag the track edges in the Track list.

3. After rearranging the overlapping events so that you hear what you want, you can select all events and select “Delete Overlaps” from the Advanced submenu on the Audio menu.

This puts all events in the top lane and resizes events so that overlapping sections are removed.

4. To turn off Lanes mode, select “Lanes Off” from the

Lane Display Type pop-up menu.

If you do this without using the “Delete Overlaps” function, all overlapping sections will be kept. However, the sections that were green will now be the sections visible (“on top”) and thus the sections that will be heard.

MIDI tracks

1. In the Track list or in the Inspector for the selected

track, click the Lane Display Type button and select “Lanes Auto” or “Lanes Fixed”.

• In Lanes Auto mode, extra lanes will automatically be

added where necessary – if two MIDI parts overlap, they will automatically be put on separate lanes.

• In Lanes Fixed mode, you have to move MIDI parts be-

tween lanes manually (by dragging them or by using the “Move to Front/Back” commands on the Edit menu or context menu).

In this mode, there will always be an extra, empty lane at the bottom of the track – if you move a part there, another lane will be added and so on.

2. You can edit the overlapping parts as usual – by cut-

ting, deleting or muting sections in the Project window or by opening them in a MIDI editor.

In an editor, parts on different lanes will be treated just like parts on different tracks – you can use the part list pop-up menu to select an active part for editing, etc. Note that there is no playback priority between lanes on a MIDI track – all unmuted parts will be heard during playback.

3. To merge all overlapping parts into one, make sure the

MIDI track is selected, position the left and right locator around the parts and select “Merge MIDI in Loop” from the MIDI menu.

In the dialog that appears, activate the Erase Destination option and click OK. This merges all unmuted MIDI between the locators to a single part.

4. To turn off Lanes mode, select “Lanes Off” from the

Lane Display Type pop-up menu.

The Project window

Page 51

Range editing

Editing in the Project window isn’t necessarily restricted to handling whole events and parts. You can also work with selection ranges, which are independent from the event/part and track boundaries.

Creating a selection range

To make a selection range, drag with the Range Selection tool.

When the Range Selection tool is selected, the Select submenu on the Edit menu has the following items for making selection ranges:

Option Description

All Makes a selection that covers all tracks, from the start of

None Removes the current selection range. Invert Only used for event selection (see “Selecting events” on

In Loop Makes a selection between the left and right locator, on

From Start to Cursor

From Cursor to End

All on Selected Tracks

Select Event This is available in the Sample Editor (see “Using the Se-

Left Selection Side to Cursor

Right Selection Side to Cursor

• Double-clicking on an event with the Range Selection tool creates a selection range encompassing the event.

If you hold down [Shift] you can double-click several events in a row, and the selection range will expand to encompass them all. Double-clicking a second time on an event opens it for editing in the Sample Editor.

the project to the end (as defined by the Length setting in the Project Setup dialog).

page 43).

all tracks. Makes a selection on all tracks, from the start of the

project to the project cursor. Makes a selection on all tracks, from the project cursor to

the end of the project. Only used for event selection (see “Selecting events” on

page 43).

lect menu” on page 227).

Moves the left side of the current selection range to the project cursor position.

Moves the right side of the current selection range to the project cursor position.

Adjusting the size of the selection range

You can adjust the size of a selection range in the following ways:

• By dragging its edges.

The pointer takes the shape of a double arrow when you move it over an edge of the selection range.

• By holding down [Shift] and clicking.

The closest selection range edge will be moved to the position at which you clicked.

• By adjusting the selection range start or end position on

the info line.

• By using the Trim buttons on the toolbar.

The left Trim buttons will move the start of the selection range and the right buttons will move the end. The edges will be moved by the amount specified on the Grid pop-up.

Clicking this Trim button…

…will move the start of the selection range to the right by 1beat.

• By using the Nudge buttons on the toolbar.

These will move the whole selection range to the left or the right. The amount of movement depends on the selected display format (see “The

Project Setup dialog” on page 34) and the value specified on the Grid

pop-up menu.

Note that the contents of the selection are not moved – using the Nudge buttons is the same as adjusting the start and end of the selection range at the same time, by the same amount.

Ö The Trim buttons and the Nudge buttons are located in the Nudge palette, which is not visible in the toolbar by default.

See “The setup context menus” on page 471 for instructions on how to show and hide items in the toolbar.

The Project window

Page 52

Making selection ranges for several non-contiguous tracks

You can create selection ranges that cover several tracks by pressing [Alt]/[Option]-[Shift]. However, it is also possible to exclude tracks from a selection range:

1. Create a selection range from the first to the last desired track.

2. Press [Alt]/[Option] and click in the selection range on the tracks you want to exclude from the selection.

3. In the same manner, you can add a track to the selection range by [Alt]/[Option]-clicking in the selection range area on the track.

Moving and duplicating

• To move a selection range, click and drag it to a new position.

This will move the contents of the selection range to the new position. If the range intersected events or parts, these will be split before moving, so that only the sections within the selection range are affected.

• To duplicate a selection range, hold down [Alt]/[Option] and drag.

You can also use the Duplicate, Repeat and Fill Loop functions, just as when duplicating events (see “Duplicating events” on page 45).

Using Cut, Copy and Paste

When working with selection ranges, you can either use Cut, Copy and Paste on the Edit menu, or use the functions “Cut Time” and “Paste Time” on the Range submenu on the Edit menu. These work differently to their related functions on the Edit menu:

Function Description

Cut Cuts out the data in the selection range and moves it to

Copy Copies the data in the selection range to the clipboard.

the clipboard. The selection range is replaced by empty track space in the Project window, meaning that events to the right of the range keep their positions.

Function Description

Paste Pastes the clipboard data at the start position and track

Paste at Origin Pastes the clipboard data back at its original position. Ex-

Cut Time Cuts out the selection range and moves it to the clip-

Paste Time Pastes the clipboard data at the start position and track

Paste Time at Origin

of the current selection. Existing events are not moved to make room for the pasted data.

isting events are not moved to make room for the pasted data.

board. Events to the right of the removed range are moved to the left to fill out the gap.

of the current selection. Existing events are moved to make room for the pasted data.

Pastes the clipboard data back at its original position. Existing events are moved to make room for the pasted data.

Deleting selection ranges

Again, you can either use “regular” Delete or “Delete Time”:

• If you use the Delete function on the Edit menu (or press

[Backspace]), the data within the selection range is replaced by empty track space.

Events to the right of the range keep their position.

• If you use “Delete Time” on the Edit menu’s Range sub-

menu, the selection range is removed and events to the right are moved to the left to close up the gap.

Other functions

On the Range submenu on the Edit menu, you will find three more range editing functions:

Function Description

Split Splits any events or parts that are intersected by the selec-

Crop All events or parts that are partially within the selection

Insert Silence Inserts empty track space from the start of the selection

tion range, at the positions of the selection range edges.

range are cropped, that is, sections outside the selection range are removed. Events that are fully inside or outside the selection range are not affected.

range. The length of the silence equals the length of the selection range. Events to the right of the selection range start are moved to the right to “make room”. Events that are intersected by the selection range start are split, and the right section is moved to the right.

The Project window

Page 53

Region operations

A folder track

Tracks in the folder

Regions are sections within a clip, with various uses. While regions are perhaps best created and edited in the Sample Editor (see “Working with regions” on page 228), the following region functions are available in the Advanced submenu of the Audio menu:

Function Description

Event or Range as Region

Events from Regions

Folder tracks

Moving tracks into a folder is a way to structure and organize tracks in the Project window. By grouping tracks in folder tracks, you can solo and mute them in a quicker and easier way and perform editing on several tracks as one entity. Folder tracks can contain any type of track including other folder tracks.

Handling folder tracks

• Creating a folder track

Select “Add Track” from the Project menu and select “Folder” from the submenu that appears, or right-click in the Track list and select “Add Folder Track” from the context menu to create a folder track.

• Moving tracks into a folder

In the Track list, click on a track that you want to move into a folder and drag it onto a folder track. A green arrow pointing to a folder appears when you drag the track onto the folder track in the list. The track is placed in the folder track, and all parts and events on the track will be represented by a corresponding folder part (see below). You can also create sub-folders by moving one folder track into another. For example, you could have a folder containing all the vocals in a project, and each vocal part could have a folder containing all the takes for easier handling etc.

This function is available when one or several audio events or selection ranges are selected. It creates a region in the corresponding clip, with the start and end position of the region determined by the start and end position of the event or selection range within the clip.

This function is available if you have selected an audio event whose clip contains regions within the boundaries of the event. The function will remove the original event and replace it with event(s) positioned and sized according to the Region(s).

The Project window

• Removing tracks from a folder

Drag a track out of the folder and release it in the Track list to remove it from the folder.

• Hiding/showing tracks in a folder

Click on the “Expand/Collapse Folder” button (the folder icon) to hide or show the tracks located in a folder or use the corresponding options in the Track Folding submenu of the Project menu (see “Track folding” on

page 39). Hidden tracks are played back as usual.

• Muting and soloing folder tracks

Click the Mute or Solo button on the folder track to mute or solo all tracks in the folder as one unit.

Working with folder parts

A folder part is a graphic representation of events and parts on the tracks in the folder. Folder parts indicate the position and length of the events and parts, as well as on which track they are (their vertical position). If part colors are used, these are also shown in the folder part.

Any Project window editing you perform to a folder part affects all the events and parts it contains. You can select several folder parts if you like – this allows you to handle and edit them together. The editing you can perform includes:

• Moving a folder part. This will move its contained events and parts (possibly resulting in other folder parts, depending on how the parts overlap).

• Using cut, copy and paste.

• Deleting a folder part. This will delete its contained events and parts.

• Splitting a folder part with the Scissors tool.

• Gluing folder parts together with the Glue tube tool. This will only work if the adjacent folder parts contain events or parts on the same track.

• Resizing a folder part resizes the contained events and parts according to the selected resizing method, see “Resizing

events” on page 46.

Page 54

• Muting a folder part. This will mute its contained events and parts.

Tracks inside a folder can be edited as one entity by performing the editing directly on the folder part containing the tracks. You can also edit individual tracks within the folder by showing the contained tracks, selecting parts and opening editors as usual.

Double-clicking a folder part opens the editors for the corresponding track classes present in the folder. The following applies:

• All MIDI parts located on the tracks within the folder are

displayed as if they were on the same track, just like when opening the Key Editor with several MIDI parts selected.

To be able to easily discern the different tracks in the editor, give each track a different color in the Project window and use the “Part Colors” option in the editor (see “Coloring notes and events” on page 344).

• If the folder contains tracks with audio events and/or au-

dio parts, the Sample and/or Audio Part Editors are opened with each audio event and audio part in a separate window.

Markers

Markers are used to locate certain positions quickly. If you often find yourself jumping to a specific position within a project, you should insert a marker at this position. There are two types of markers:

• Cycle markers allow you to store the start and end posi-

tions of a range.

On the Marker track they are shown as two markers bridged by a horizontal line. They are ideal for setting sections of a song, for example “Intro”, “Verse”, and “Chorus”, this enables you to quickly navigate to the song sections, and also to optionally repeat the section (by activating Cycle on the Transport panel). Cycle markers can freely overlap.

• Standard markers store a specific position.

Ö The left and right locators are handled separately – see “The left and right locators” on page 62.

Editing markers in the Marker window

The Marker window lists the markers in the order in which they occur in the project. To open the Marker window, select “Markers” from the Project menu, click the “Show” button in the Marker section on the Transport panel or use the key command (by default [Ctrl]/[Command]-[M]).

The Marker window is divided into six columns:

Column Description

Locate (leftmost column)

ID In this column you can edit marker ID numbers. Each time

Position In this column you can view and edit the markers’ time

End In this column you can view and edit the end positions of

Length In this column you can view and edit the length of cycle

Description Here you can enter names or descriptions for markers.

If you click in this column the project cursor will be moved to the corresponding marker position. A blue arrow indicates the marker at the project cursor position (or the closest marker before the project cursor).

you add a marker, it is automatically and sequentially assigned an ID number, starting from ID 1. IDs for cycle markers are shown in brackets and start from [1]. The nine first markers (1 to 9) can be recalled by using key commands (by default [Shift]-[1] to [9] on the typewriter part of the keyboard).

positions (or start positions for cycle markers).

cycle markers.

markers.

Click on a column heading to sort the marker list by that column. The Marker columns can also be reordered by dragging and dropping the column headers.

The Project window

Page 55

The following actions can be performed in the Marker

Cycle markerMarkers

Locators

Add Marker/Add Cycle Marker buttons

window:

• Adding markers

Click the Add button or press [Insert] (Windows only) on the computer keyboard to add position markers at the current project cursor position Select “Cycle Markers” from the Show pop-up menu and click the Add button to add a cycle marker between the left and right locator.

• Removing markers

Select a marker and click the Remove button to remove it.

• Moving marker positions

Set the project cursor to the position to which you want to move (or reprogram) a marker, select the marker that you want to change in the Marker window and click the Move button. If a cycle marker is selected, the Move operation affects the cycle marker start position, the length of the range is not affected. You can also move markers by editing their position numerically in the Position column.

Editing markers on the Marker track

The Marker track is used for viewing and editing markers. Any changes made on the Marker track are reflected in the Marker window and vice versa. Standard position markers are shown as vertical lines with the marker name (if assigned) and number beside it. If you select the Marker track, all markers are shown in the Inspector.

To add the Marker track to the Project, select “Marker” from the Add Track submenu of the Project menu (or right-click in the Track list and select “Add Marker Track”). You can only have one Marker track in a project.

The following editing functions can be performed directly on the Marker track:

• Adding markers

Press the [Insert] key (Win) or the “Add Marker” button in the Track list, to add a position marker at the current cursor position during playback. Click the “Add Cycle Marker” button in the Track list, to add a cycle marker at the left and right locator positions.

• Selecting markers

Use the standard techniques.

• Drawing markers

Use the Pencil tool (or press [Alt]/[Option] and use the Arrow tool) to draw position markers. Snap is taken into account. Hold down [Ctrl]/[Command] while using the Pencil or the Arrow tool to draw cycle markers. Snap is taken into account.

• Resizing

Select and drag a cycle marker by the handles that appear at the bottom of the start and end events to resize it. This can also be done numerically on the info line.

• Moving

Click and drag, or edit the positions on the info line to move a marker. Snap is taken into account if activated.

• Removing

Select a position marker and press [Delete] or use the Erase tool to remove it. Click with the Eraser tool to delete a cycle marker. If you hold down [Alt]/ [Option] when you click, all consecutive markers will also be deleted.

• Naming

Select a marker and enter a name on the info line.

• Moving the left and right locators

Double-click on a cycle marker or select it from the Cycle pop-up menu in the Track list, to move the left and right locators to encompass the cycle marker. Use the numeric pad keys [1] and [2] to move the project cursor position to the start or the end of the cycle marker. You can also use key commands for this – see “Editing markers using key commands” on page 55.

• Zooming

Select a cycle marker on the Zoom pop-up menu, to zoom in the event display to encompass the selected range only (see the section “Zoom

presets and Cycle markers” on page 36).

You can also do this by pressing [Alt]/[Option] and double-clicking on the cycle marker in the event display.

• Making range selections in the Project window

Double-click with the Range Selection tool between any two markers to create a selection range between the markers, spanning all tracks in the project. This is a quick way to move or copy (hold down [Alt]/[Option]) complete sections of the project (on all tracks).

Editing markers using key commands

You can use key commands for marker operations, see

“Transport category” on page 486.

The Project window

Page 56

Editing markers in the Project Browser

If you have a Marker track in the Project window, you can create and edit all marker parameters, including marker IDs, in the Project Browser. For details about editing markers in the Project Browser see “Editing the Marker

track” on page 418.

Options

The Snap function

The Snap function helps you to find exact positions when editing in the Project window. It does this by restricting horizontal movement and positioning to certain positions. Operations affected by Snap include moving, copying, drawing, sizing, splitting, range selection, etc.

• You turn Snap on or off by clicking the Snap icon in the

toolbar.

Snap activated.

When you are moving audio events with Snap activated, it isn’t necessarily the beginning of the event that is used as Snap position reference. Instead, each audio event has a snap point, which you can set to a relevant position in the audio (such as a downbeat, etc.).

The snap point is preferably set in the Sample Editor since it allows for a higher degree of precision (see “Adjusting

the snap point” on page 226). You can however also set

the snap point directly in the Project window, in the following way:

1. Select an event.

2. Place the project cursor at the desired position within

the selected audio event.

3. Pull down the Audio menu and select “Snap Point To

Cursor”.

The snap point is set at the cursor position.

The snap point for an event is displayed as a blue line in the Project window.

Exactly how Snap works depends on which mode is selected on the Snap mode pop-up menu.

The following sections describe the different Snap modes:

Grid

In this mode, the Snap positions are set with the Grid Type pop-up menu to the right. The options depend on the display format selected for the ruler. For example, if the ruler is set to show bars and beats, the grid can be set to bars, beats or the quantize value set with the next pop-up menu to the right. If a time or frame-based ruler format is selected, the Grid Type pop-up menu contains time or frame-based grid options, etc.

When Seconds is selected as ruler format, the Grid Type pop-up menu contains time-based grid options.

Grid Relative

When you move events and parts in this mode they will not be “magnetic” to the grid. Rather, the grid determines the step size for moving the events. This means that a moved event will keep its original position relative to the grid.

For example, if an event starts at the position 3.04.01 (one beat before bar 4), Snap is set to Grid Relative and the Grid Type pop-up menu is set to “Bar”, you can move the event in steps of one bar – to the positions 4.04.01,

5.04.01 and so on. The event will keep its relative position to the grid, i.e. stay one beat before the bar lines.

• This only applies when dragging existing events or parts – when you create new events or parts this mode works like the Grid mode.

The Project window

Page 57

Events

12345

52431

Dragging event 2 past event 4…

…changes the order of events 2, 3 and 4.

In this mode, the start and end positions of other events and parts become “magnetic”. This means that if you drag an event to a position near the start or end of another event, it is automatically aligned with the start or end of the other event. For audio events, the position of the snap point is also magnetic (see “Adjusting the snap point” on

page 226).

• Note that this includes marker events on the marker track.

This allows you to snap events to marker positions, and vice versa.

Shuffle

Shuffle mode is useful when you want to change the order of adjacent events. If you have two adjacent events and drag the first one to the right, past the second event, the two events will change places.

Grid + Cursor

This is a combination of the “Grid” and “Magnetic Cursor” modes.

Events + Cursor

This is a combination of the “Events” and “Magnetic Cursor” modes.

Events + Grid + Cursor

This is a combination of the “Events”, “Grid” and “Magnetic Cursor” modes.

Snap to Zero Crossing

When this option is activated on the toolbar or in the Preferences (Editing–Audio page), splitting and sizing of audio events is done at zero crossings (positions in the audio where the amplitude is zero). This helps you avoid pops and clicks which might otherwise be caused by sudden amplitude changes.

Autoscroll

The same principle works when changing the order of more than two events:

Magnetic Cursor

When this mode is selected, the project cursor becomes “magnetic”. Dragging an event near the cursor causes the event to be aligned with the cursor position.

“Autoscroll” and “Suspend Autoscroll when Editing” are activated

When the Autoscroll option is activated, the waveform display will scroll during playback, keeping the project cursor visible in the window. You can find the Autoscroll button in the toolbars of the Project window and all editors.

• If the option “Stationary Cursors” is activated in the Preferences (Transport page), the project cursor will be positioned in the middle of the screen (if possible).

Suspending autoscroll

When editing parts or events during playback with Autoscroll enabled, you may suddenly “loose sight” of the edited material as the display follows the project cursor.

If you don’t want the Project window display to change when editing during playback, you can activate the “Suspend Autoscroll when Editing” button. You will find this button right next to the Autoscroll button. When this option is enabled, autoscrolling is suspended as soon as you click anywhere in the event display during playback.

The Project window

Page 58

Proceed as follows:

1. Open a project that contains audio or MIDI parts/

events.

2. Enable both the “Autoscroll” and the “Suspend Auto-

scroll when Editing” buttons (both buttons turn blue).

3. Start playback.

4. Edit an audio or MIDI part/event of your project (e.g.

click and drag it to a different location on its track).

The Autoscroll button will turn orange.

Autoscrolling is now suspended, i.e. when the project cursor moves to the right edge of the Project window, the display will not follow to keep the cursor visible.

As soon as playback stops, or when you click the Autoscroll button again (so it turns blue), Cubase will return to the normal Autoscroll behavior.

The Project window

Page 59

Playback and the Transport panel

Page 60

Background

Octave Offset

Note Velocity Level

Change Virtual Keyboard Display Type

Activates Auto Quantize

Record mode pop-up menu

Cycle Record mode pop-up menu

CPU load and Disk Cache meters

Right locator

Punch In

Left locator

Post-roll: value and on/off

Shuttle speed

Jog Wheel

Nudge +/- 1 Frame

Pre-roll: value and on/off

Punch Out

Primary Time Display

Position slider

Record

Play

Fast forward

Go to next marker/ project end

Nudge position right/left

Go to previous marker/ project start

Secondary Time Display

Exchange time formats

Cycle on/off

Stop

Rewind

Active Arranger chain

Activate Arranger Mode

First/Last repeat of current Arranger event

Previous/Next Arranger event

Arranger Selector

Current Arranger event

Tempo track on/off

Synchronization on/off

The tempo and time signature display

Metronome click on/off

Show Markers (opens Marker window)

Jump to Marker

Precount on/off

MIDI In/Out activity (left/right)

Output Level Control

Clipping indicators

Audio input/output activity

This chapter describes the various methods available for controlling Playback and Transport functions in Cubase.

The Transport panel

Below you can find a brief description of each item on the Transport panel.

The pictures below show the Transport panel with all controls visible (note that the Jog/Shuttle control is available in Cubase only). The Transport panel is divided into the following sections, from left to right.

Ö Note that the Output Activity and Clipping indicator as well as the Output Level Control refer to the Control Room channel (Cubase only), if the Control Room is activated. If the Control Room is disabled, these controls refer to the Main Mix Output bus as defined on the Outputs tab in the VST Connections window. For information on the Control Room, see the chapter “Control Room (Cubase only)” on

page 135. In Cubase Studio, the Main Mix bus is always

used for monitoring.

• The main Transport functions (Cycle/Stop/Play/Record) can also be shown on the toolbar.

In addition, various play options are available on the Transport menu.

Hiding and showing the Transport Panel

The Transport panel is shown automatically when you launch a new project. To hide or show it, select “Transport Panel” on the Transport menu (or use a key command – by default [F2]).

Playback and the Transport panel

Page 61

About Pre-roll and Post-roll

These items are described in the chapter “Recording”, see “About Pre-roll and Post-roll” on page 84.

Changing the Transport panel setup

You can customize the appearance of the Transport panel by right-clicking anywhere on the panel and selecting/deselecting the corresponding options on the context menu.

This is described in detail in the section “The setup con-

text menus” on page 471.

The numeric keypad

In the default Key Command settings, various Transport panel operations are assigned to the numeric keypad on the computer keyboard. The keypads are slightly different on PC and Macintosh computers:

Numeric Key Function

[Enter] Play [+] Fast Forward [-] Rewind [*] Record [÷] (Win)/[/] (Mac) Cycle On/Off [,] Return to Zero [0] Stop [1] Go to Left Locator [2] Go to Right Locator [3-9] Go to marker 3 to 9

Operations

Setting the project cursor position

There are several ways to move the project cursor position:

• By using Fast Forward and Rewind.

• By using the Jog/Shuttle/Nudge control on the Trans-

port panel (Cubase only – see “The Shuttle Speed control

(Cubase only)” on page 63).

• By dragging the project cursor in the lower part of the

ruler.

• By clicking in the ruler.

Double-clicking in the ruler moves the cursor and starts/stops playback.

• If the option “Locate when Clicked in Empty Space” is activated in the Preferences (Transport page) you can click anywhere in an empty section of the Project window to move the cursor position.

• By changing the value in any of the position displays.

• By using the position slider above the transport buttons

in the Transport panel.

The range of the slider relates to the Length setting in the Project Setup dialog. Hence, moving the slider all the way to the right will take you to the end of the project.

• By using markers (see “Markers” on page 54).

• By using playback options (see “Playback functions” on

page 64).

• By using the Arranger function (see “The Arranger

track” on page 96).

• By using functions on the Transport menu. The following functions are available:

Function Description

Locate Selection/ Locate Selection End

Locate Next/ Previous Marker

Locate Next/ Previous Event

Moves the project cursor to the beginning or end of the current selection. For this to be available, you must have selected one or more events or parts, or made a selection range.

This moves the project cursor to the closest marker to the right or left (see “Marker tracks” on page 31).

This moves the project cursor forwards or backwards respectively, to the closest beginning or end of any event on the selected track(s).

Ö If Snap is activated when dragging the project cursor, the Snap value is taken into account. This is helpful for finding exact positions quickly.

Ö There are also numerous key commands available for moving the project cursor (in the Transport category in the Key Commands dialog).

For example, you can assign key commands to the “Step Bar” and “Step Back Bar” functions, allowing you to move the project cursor in steps of one bar, backwards and forwards.

Playback and the Transport panel

Page 62

About the Transport panel display formats

Primary time display (left) and secondary time display (right)

The time unit shown in the ruler can be independent from the time unit shown in the main time display on the Transport panel. This means that you can display timecode in the transport position display and bars and beats in the ruler, for example. In addition, there is a secondary time display to the right of the primary time display which is also independent, giving you three different time units shown at the same time (in the Project window, you can also create additional ruler tracks – see “Using multiple

rulers – ruler tracks (Cubase only)” on page 33).

The following rules apply:

• If you change the time format of the primary time display

on the Transport panel, the time format of the ruler will be changed as well.

This is the same as changing the display format in the Project Setup. Therefore, to have different display formats in the ruler and the main time display you should change the format in the ruler.

• The primary time display format is set on the pop-up

menu to the right in the main position display.

• This setting also determines the time format displayed

for the left and right locators on the Transport panel.

• The secondary time display is completely independent,

and the display format is set on the pop-up menu to the right in the secondary time display.

• You can swap time formats between the primary and

secondary time displays by clicking the double arrow symbol between them.

The left and right locators

The left and right locators are a pair of position markers used for specifying punch-in and punch-out positions during recording, and as boundaries for cycle playback and recording.

Ö When cycle mode is activated on the Transport panel, the area between the left and right locator will be repeated (cycled) on playback.

However, if the right locator is positioned before the left, this will work as a “jump” or “skip mode” – when the project cursor reaches the right locator it will immediately jump to the left locator position and continue playback from there.

There are several ways to set locator positions:

• To set the left locator, press [Ctrl]/[Command] and click at the desired position in the ruler.

Similarly, pressing [Alt]/[Option] and clicking in the ruler sets the right locator. You can also drag the locator “handles” directly in the ruler.

The locators are indicated by the “flags” in the ruler. The area between the locators is highlighted in the ruler and in the Project window (see

“Appearance” on page 474). Note that if the right locator is before the

left locator, the color of the ruler between the locators will change (from blue to red).

• Click and drag in the upper half of the ruler to “draw” a locator range.

If you click on an existing locator range, you can drag to move it.

• Pressing [Ctrl]/[Command] and pressing [1] or [2] on the numeric keypad sets the left or right locator to the project cursor position.

Similarly, you can press [1] or [2] on the numeric keypad (without [Ctrl]/ [Command]) to set the project cursor position to the left or right locator position. Note that these are default key commands – you can change these if you like.

• By creating cycle markers you can store any number of left and right locator positions, which can be recalled by simply double-clicking on the corresponding marker (see

“Editing markers on the Marker track” on page 55).

• The “Locators to Selection” item on the Transport menu (default key command [P]) sets the locators to encompass the current selection.

This is available if you have selected one or several events or made a selection range.

• You can also adjust the locators numerically on the Transport panel.

Clicking the L/R buttons in the locator section on the Transport panel will move the project cursor to the respective locator. If you press [Alt]/[Option] and click the L or R button, the corresponding locator will be set to the current project cursor position.

Playback and the Transport panel

Page 63

The Shuttle Speed control (Cubase only)

The shuttle speed control (the outer wheel on the Transport panel) allows you to play the project at any playback speed, forwards or backwards. This provides a quick way to locate or “cue” to any position in the project.

• Turn the shuttle speed wheel to the right to start play-

back.

The further to the right you move the wheel, the faster the playback speed.

• If you turn the wheel to the left instead, the project will

play backwards.

Similarly, the playback speed depends on how far to the left you turn the wheel.

Project scrubbing – the Jog Wheel (Cubase only)

The middle wheel on the Transport panel serves as a jog wheel. By clicking and dragging it to the right or left you will move the playback position manually forwards or backwards – much like scrubbing on a tape deck. This helps you pinpoint exact locations in the project.

• Note that the jog wheel is an “endless rotary encoder” –

you can turn it as many times as needed to move to the desired location.

The faster you turn the wheel, the faster the playback speed.

• If you click the jog wheel during playback, playback will

automatically stop.

Options and Settings

The “Return to Start Position on Stop” preference

This setting is found on the Transport page in the Preferences (found on the File menu under Windows, or on the Cubase menu under Mac OS X).

• If “Return to Start Position on Stop” is activated when you stop playback, the project cursor will automatically return to the position where recording or playback last started.

• If “Return to Start Position on Stop” is deactivated, the project cursor will remain at the position where you stop playback.

Pressing Stop again will return the project cursor to the position where recording or playback last started.

About track disable/enable

For audio tracks, the track context menu contains an item named “Disable Track”. This shuts down all disk activity for the track, as opposed to using Mute, which merely turns down the output volume for a track. For example, if you often record “alternative takes” you can easily build up a large number of takes on different tracks. Even though these tracks are muted, they are actually still “playing back” from the hard disk during playback. This puts an unnecessary load on your disk system, so using “Disable Track” is recommended for such situations.

• Select “Di sable Track” for tracks that you want to keep in the project for later use but do not want to play back now.

The track color changes to indicate that the track is disabled.

• Select “Enable Track” from the track context menu to re-enable disabled tracks.

The nudge position buttons (Cubase only)

The + and – buttons in the middle of the Shuttle/Jog section allow you to nudge the project cursor position one frame at a time to the right or left.

Playback and the Transport panel

Page 64

Playback functions

Apart from the standard transport controls on the Transport panel, you can also find a number of functions on the Transport menu that can be used to control playback. The items have the following functionality:

Option Description

Post-roll from Selection Start/End

Pre-roll to Selection Start/End

Play from Selection Start/End

Play until Selection Start/End

Play until Next Marker This activates playback from the project cursor and

Play Selection Range This activates playback from the start of the current

Loop Selection This activates playback from the start of the current

Starts playback from the beginning or end of the currently selected range and stops after the time set in the Post-roll field on the Transport panel.

Starts playback from a position before the start or end of the currently selected range and stops at the selection start or end, respectively. The playback start position is set in the Pre-roll field on the Transport panel.

Activates playback from the beginning or end of the current selection.

Activates playback two seconds before the start or end of the current selection and stops at the selection start or end, respectively.

stops at the next marker.

selection and stops at the selection end.

selection and keeps starting over again when reaching the selection end.

The functions listed above (except “Play until Next Marker”) are only available if you have selected one or more events or made a selection range.

Ö In the Preferences dialog (Editing–Audio page) you will find the option “Treat Muted Audio Events like Deleted”. When you activate this option, any events overlapped by a muted event will become audible.

About Chase

Chase is a function that makes sure your MIDI instruments sound as they should when you locate to a new position and start playback. This is accomplished by the program transmitting a number of MIDI messages to your instruments each time you move to a new position in the project, making sure all MIDI devices are set up correctly with regard to program change, controller messages (such as MIDI Volume), etc.

For example, let’s say you have a MIDI track with a program change event inserted at the beginning. This event makes a synth switch to a piano sound.

At the beginning of the first chorus you have another program change event which makes the same synth switch to a string sound.

You now play back the song. It begins with the piano sound and then switches to the string sound. In the middle of the chorus you stop and rewind to some point between the beginning and the second program change. The synth will now still play the string sound although in this section it really should be a piano!

The Chase function takes care of that. If program change events are set to be chased, Cubase will track the music back to the beginning, find the first program change and transmit it to your synth, setting it to the correct sound.

The same thing can apply to other event types as well. The Chase Events settings in the Preferences dialog (MIDI page) determine which event types will be chased when you locate to a new position and start playback.

Ö Event types for which the checkbox is activated here will be chased.

• In this section of the Preferences dialog, you will also find the option “Chase not limited to Part Boundaries”.

When you activate this option, MIDI controllers are also chased outside the part boundaries, i.e. the Chase will be performed on the part touched by the cursor as well as on all the parts to the left of it. Please note that this option should be deactivated for very large projects, as it considerably slows down operations such as positioning and soloing. When you deactivate this option, the MIDI controllers are only chased within the parts under the position cursor.

Playback and the Transport panel

Page 65

The Virtual Keyboard

The Virtual Keyboard can be displayed in the Transport panel. It allows you to play and record MIDI notes by using your computer keyboard or mouse. This is useful if you have no external MIDI instrument at hand and you do not want to draw in notes with the Pencil tool. The Virtual Keyboard can perform all functions that can be controlled by external MIDI keyboards, e.g. playing and recording MIDI notes.

When the Virtual Keyboard is displayed, the usual key commands are blocked because they are reserved for the Virtual Keyboard. The only exceptions are: [Ctrl]/ [Command]-[S] (Save), Num [*] (Start/Stop Record), [Space] (Start/Stop Playback), Num [1] (Jump to left locator), [Delete] or [Backspace] (Delete), Num [/] (Cycle on/off), [F2] (Show/Hide Transport panel), and [Alt]/[Option]-[K] (Show/Hide Virtual Keyboard).

• You can choose between two different keyboard dis-

play modes: computer keyboard and piano roll. To switch between these two modes, click the “Change Virtual Keyboard Display Type” button or use the [Tab] key.

The Virtual Keyboard in computer keyboard display mode

3. Activate the Record button and press a key on your computer keyboard to enter a note.

You can also click on the keys of the Virtual Keyboard to enter notes.

• You can also press several keys simultaneously to enter polyphonic parts. The maximum number of notes that can be played at one time varies between the different operating systems and hardware configurations.

4. Use the fader “Note velocity level” to the right of the virtual keyboard to adjust the volume.

You can also use the up and down arrow keys for this.

5. Enter the desired notes this way.

6. When you are done, hit the Stop button and close the

Virtual Keyboard.

When the Virtual Keyboard is hidden, all key commands are available again.

Options and settings

• In piano roll mode, you have a wider range of keys at your disposal, allowing you to enter two voices simultaneously, for example bass and lead voice or bass drums and HiHats.

In computer keyboard mode, you can use the two rows of keys that are displayed on the Virtual Keyboard to enter notes. In piano roll mode, you can also use the two rows of keys below these.

• You have seven full octaves at your disposal. Use the “Octave Offset” buttons at the bottom of the virtual keyboard to offset the octave range of the keyboard.

You can also use the left and right arrow keys to switch the keyboard range to a lower or higher octave, respectively.

The Virtual Keyboard in piano roll display mode

To record MIDI using the Virtual Keyboard, proceed as follows:

1. Create or choose a MIDI or an instrument track and ac-

tivate the “Record Enable” button for it.

2. Open the Virtual Keyboard by selecting “Virtual Key-

board” on the Devices menu or by pressing [Alt]/[Option][K]. You can also open the Virtual Keyboard by right-clicking on the Transport panel and selecting “Virtual Keyboard”

• In piano roll mode, you can use the two sliders to the left of the keyboard to introduce pitchbend (left slider) or modulation (right slider).

You can also click on a key, hold the mouse button pressed until the mouse pointer becomes a crosshair tool and drag upwards/downward to introduce modulation or left/right to create pitchbend.

on the context menu.

The Virtual Keyboard is displayed in the Transport panel.

Playback and the Transport panel

Page 66

Recording

Page 67

Background

This chapter describes the various recording methods that you can use in Cubase. As it is possible to record both audio and MIDI tracks, both recording methods are covered in this chapter.

Before you start

This chapter assumes that you are reasonably familiar with certain basic recording concepts, and that the following initial preparations have been made:

• You have properly set up, connected and calibrated

your audio hardware.

• You have opened a project and set the project setup

parameters to your specifications.

Project setup parameters determine the record format, sample rate, project length etc. that affect the audio recordings you make during the course of the project. See “The Project Setup dialog” on page 34.

• If you plan to record MIDI, your MIDI equipment should

be set up and connected correctly.

Basic recording methods

This section describes the general methods used for recording. However, there are additional preparations and procedures that are specific to audio and MIDI recording respectively. Make sure to read these sections before you start recording (see “Audio recording specifics” on page

69 and “MIDI recording specifics” on page 79).

Record Enable in the Inspector, Track list and mixer

Ö If the option “Enable Record on Selected Track” is activated in the Preferences (Editing–Project & Mixer page), tracks are automatically record-enabled when you select them in the Track list.

Ö You can set up key commands to record-enable all audio tracks simultaneously and to deactivate Record Enable for all audio tracks (Arm/Disarm all Audio Tracks). You will find these commands in the Key Commands dialog, in the Mixer category (see “Setting up key commands” on page 480).

Ö The exact number of audio tracks you can record simultaneously depends on your computer CPU and hard disk performance.

In the Preferences (VST page), you can find the option “Warn on Processing Overloads”. When this is activated, a warning message will be displayed as soon as the CPU clip indicator (on the Transport panel) lights up during recording.

Record-enabling tracks

Cubase can record on a single track or on several tracks (audio and/or MIDI) simultaneously. To make a track ready for recording, click the Record Enable button for the track in the Track list, in the Inspector or in the mixer. When activated, the buttons turn red, indicating record ready mode.

Recording

Manually activating recording

You activate recording by clicking the Record button on the Transport panel or toolbar or by using the corresponding key command (by default [*] on the numeric keypad).

Recording can be activated in Stop mode (from the current cursor position or from the left locator) or during playback:

• If you activate recording in Stop mode, and the option “Start Record at Left Locator” is activated on the Transport menu, recording will start from the left locator.

The pre-roll setting or the metronome count-in will be applied (see

“About Pre-roll and Post-roll” on page 84).

• If you activate recording in Stop mode, and “Start Record at Left Locator” is deactivated, recording will start from the current project cursor position.

Page 68

• If you activate recording during playback, Cubase will

immediately enter Record mode and start recording from the current project cursor position.

This is known as “manual punch in”.

Activating recording in Sync mode

If you are synchronizing the Cubase transport to external equipment (Sync is activated on the Transport panel) and you activate recording, the program will go into “record ready” mode (the record button on the Transport panel will light up). In this case, recording will start when a valid timecode signal is received (or when you click the Play button). See the chapter “Synchronization” on page 427 for more information.

Automatically activating recording

Cubase can automatically switch from playback to recording at a given position. This is known as “automatic punch in”. A typical use for this would be if you need to replace a section of a recording, and want to listen to what is already recorded, up to the recording start position.

1. Set the left locator to the position where you want re-

cording to start.

2. Activate the Punch In button on the Transport panel.

Punch In activated

3. Activate playback from some position before the left

locator.

When the project cursor reaches the left locator, recording is automatically activated.

Stopping recording

Again, this can be done automatically or manually:

• If you click the Stop button on the Transport panel (or

use the corresponding key command, by default [0] on the numeric keypad), recording is deactivated and Cubase goes into Stop mode.

• If you click the Record button (or use the key command

for recording, by default [*]), recording is deactivated but playback continues.

This is known as “manual punch out”.

• If the Punch Out button is activated on the Transport panel, recording will be deactivated when the project cursor reaches the right locator.

This is known as “automatic punch out”. By combining this with automatic punch in, you can set up a specific section to record – again very useful if you want to replace a certain part of a recording. See also “Stop

after Automatic Punch Out” on page 84.

Punch In and Out activated

Cycle recording

Cubase can record and play back in a cycle – a loop. You specify where the cycle starts and ends by setting the left and right locators. When the cycle is active, the selected section is seamlessly repeated until you hit Stop or deactivate cycle mode.

• To activate cycle mode, click the cycle button on the Transport panel.

Cycle activated

• To record in cycle mode, you can start recording from the left locator, from before the locators or from within the cycle, in Stop mode or during playback.

As soon as the project cursor reaches the right locator, it will jump back to the left locator and continue recording a new lap.

• The results of cycle recording depend on the selected cycle record mode and are different for audio (see “Re-

cording audio in cycle mode” on page 75) and MIDI (see “Recording MIDI in cycle mode” on page 81).

Recording

Page 69

Audio pre-record

This feature allows you to capture up to 1 minute of any incoming audio you play in Stop mode or during playback, “after the fact”. This is possible because Cubase can capture audio input in buffer memory, even when not recording.

Proceed as follows:

1. Open the Preferences (Record–Audio page).

2. Specify a time (up to 60 seconds) in the “Audio Pre-

Record Seconds” field.

This activates the buffering of audio input, making Pre-Record possible.

3. Make sure an audio track is record-enabled and re-

ceives audio from the signal source.

4. When you have played some audio material you want

to capture (either in Stop mode or during playback), click the Record button.

5. After a few seconds stop the recording.

An audio event is created, starting at where the cursor position was when you activated recording. This means that if you were in stop mode, and the cursor was at the beginning of the project, you may have to move the event to the right in the next step. If you were playing along to a project you should leave the event where it is.

6. Select the Arrow tool and place the cursor on the bot-

tom left edge of the event so that a double arrow appears, then click and drag to the left.

Now the event is extended and the audio you played before activating record is inserted – this means that if you played along during playback, the captured notes will end up exactly where you played them in relation to the project.

Audio recording specifics

Selecting a recording file format

The format for recorded files is set in the Project Setup dialog on the Project menu. There are three settings: sample rate, record format (bit depth) and record file type. While the sample rate is set once and for all when you start working on a new project, the bit depth and file type can be changed at any time.

Record file type

The Record File Type setting determines which type of files will be created when you record:

File type Description

Wave File Wave files have the extension “.wav” and are a common

Wave 64 File (Cubase only)

Broadcast Wave File

AIFF File Audio Interchange File Format, a standard defined by Ap-

• If you select Broadcast Wave File or AIFF format, you can specify Author, Description and Reference text strings that will be embedded in the recorded file.

This is done on the Record–Audio–Broadcast Wave page in the Preferences.

file format on the PC platform. Wave 64 is a proprietary format developed by Sonic

Foundry Inc. Audio-wise it is identical to the Wave format, but the internal file structure makes much larger file sizes possible. This is useful e.g. for long live recordings in surround format, where the audio files can become huge.

In terms of audio content, the same as regular Wave files, but with embedded text strings for supplying additional information about the file (see below).

ple Inc. AIFF files have the extension “.aif” and are used on most computer platforms. Like Broadcast Wave files, AIFF files can contain embedded text strings (see below).

The recording was activated at the start of bar 9. This is indicated by a blue line in the audio event.

Recording

Record format (bit depth)

The available options are 16 bit, 24 bit and 32 bit float. Use the following guidelines:

• Normally, select the record format according to the bit depth delivered by your audio hardware.

For example, if your audio hardware has 20 bit A/D converters (inputs), you may want to record at 24 bit resolution to capture the full bit depth. On the other hand, if your hardware has 16 bit inputs, it is pointless to record with a higher bit depth – this will only make the audio files larger, with no difference in audio quality. The exception is if you record with effects – see “Recording with effects (Cubase only)” on page 78.

Page 70

• The higher the bit depth, the larger the files and the

Click here to select an input bus for the track.

Click here to show/hide the Inspector.

Click here to select an input bus for the track.

Click here to show or hide the input and output settings.

more strain is put on the disk system.

If this is an issue, you may want to lower the record format setting.

For further information on the options in the Project Setup dialog, see “The Project Setup dialog” on

page 34.

Setting up the track

Creating a track and selecting the channel configuration

Audio tracks can be configured as mono, stereo or surround tracks (Cubase only). This allows you to record or import a file containing multiple channels and treat it as one entity, with no need to split it up into several mono files etc. The signal path for an audio track maintains its channel configuration all the way from the input bus, via EQ, level and other mixer settings to the output bus.

You specify the channel configuration for a track when you create it:

1. Select “Add Audio Track” from the Track list context

menu or the Project menu (or, if an audio track is already selected, double-click in an empty area of the Track list).

A dialog appears with a channel configuration pop-up menu.

2. Select the desired format from the pop-up menu.

In Cubase Studio, you choose between mono and stereo. In Cubase, the most common formats are listed directly on the pop-up menu, with the remaining surround formats listed on the “More…” submenu. For a list of the available surround formats, see “Output bus configuration” on page 182.

• The Browse item in this dialog allows you to browse

your disk(s) for created Track Presets, which can be used as a basis (or template) for tracks.

This is described in detail in the chapter “Working with Track Presets” on

page 288.

3. Click OK.

A track appears, set to the specified channel configuration. In the mixer, a corresponding channel strip appears. You cannot change the channel configuration for a track.

Selecting an input bus for a track

Here we assume that you have added and set up the required input busses (see “Setting up busses” on page 14). Before you record, you need to specify from which input bus the track should record. You can do this in the Inspector or in the mixer:

• In the Inspector, you select an input bus on the Input Routing pop-up menu in the top section.

As described in the section “The Inspector” on page 29, the Inspector shows the settings for the selected track. You show or hide the Inspector by clicking the “Show/Hide Inspector” button on the Project window toolbar.

• In the mixer, you select an input bus on the Input Routing pop-up menu at the top of the track’s channel strip.

If this pop-up menu is not shown, you need to open the Mixer Routing View by clicking the “Show Routing” button in the extended Mixer common panel or by selecting “Show Routing View” from the Window submenu on the Mixer context menu. See “Configuring the mixer” on page 112 for more information about the mixer.

Recording

Page 71

Recording from busses

You can also select an output bus, a group bus or an FX channel bus as an Input for your recording.

Let’s assume you want to create a downmix of separate tracks, e.g. bass drum, hihats, snare etc.

Proceed as follows:

1. Set up your separate tracks as desired and add a

group track.

2. For each of the drum tracks, open the Output Routing

pop-up menu and select the Group track as output.

3. Create a new audio track, open the Input Routing pop-

up menu for it and select the Group track as input for this audio track.

4. Record enable this audio track and start recording.

Now, the output of the group track will be recorded on the new track and you will get a mix of your separate tracks.

Note that you can also select an FX channel as recording source. In this case, only the output of the FX channel will be recorded.

For more information about the routing possibilities, see

“Routing” on page 18.

Selecting a folder for the recorded audio files (Cubase only)

Each Cubase project has a project folder containing (among other things) an “Audio” folder. By default, this is where recorded audio files are stored. However, you can select record folders independently for each audio track if needed.

Proceed as follows:

1. To select the same record folder for several audio

tracks, select them by pressing [Shift] or [Ctrl]/[Command] and clicking on them in the Track list.

2. Right-click in the Track list for one of the tracks to

bring up the context menu.

3. Select “Set Record Folder”.

4. Use the file dialog that appears to navigate to the de-

sired folder (or create a new folder with the Create button).

Tip: if you want to have separate folders for different types of material (speech, ambient sounds, music, etc.), you can create subfolders within the Project’s “Audio” folder and assign different tracks to different subfolders. This way, all audio files will still reside within the project folder, which will make managing the Project easier.

• It is possible to have different tracks record to totally different locations, even on different disks. However, if you need to move or archive the project, there is a risk of missing some files. The solution is to use the “Prepare Archive” function in the Pool to gather all external files into the project folder first, see “Prepare Archive” on page 271.

Setting input levels

When recording digital sound, it is important to set the input levels correctly – loud enough to ensure low noise and high audio quality, but not so loud that clipping (digital distortion) occurs.

Clipping typically occurs in the audio hardware when a too loud analog signal is converted to digital in the hardware’s A/D converters.

• If you are using Cubase, it is also possible to get clipping when the signal from the input bus is written to a file on your hard disk.

This is because in Cubase, you can make settings for the input bus, adding EQ, effects, etc. to the signal as it is being recorded. This may raise the level of the signal, causing clipping in the recorded audio file.

The procedure for checking the signal level coming into the audio hardware is slightly different depending on whether you are using Cubase or Cubase Studio:

Cubase

In Cubase, you check the input level at the input channel. To check the level of the “unprocessed” signal coming into

the audio hardware, you need to switch the level meters to “Meter Input”. In this mode, the input channel level meters will show the level of the signal at the input of the bus, before any adjustments such as input gain, EQ, effects, level or pan:

1. Right-click in the Mixer window.

The Mixer context menu appears.

2. Select the Global Meter Settings submenu and make sure “Meter Input” is activated.

Recording

Page 72

3. Play back the audio and check the level meter for the

input channel.

The signal should be as loud as possible without exceeding 0dB (the Clipping indicator for the input bus should not light up).

The Clipping indicator

4. If necessary, adjust the input level in one of the follow-

ing ways:

• Adjust the output level of the sound source or external

mixer.

• Use the audio hardware’s own application program to

set the input levels (if possible).

See the documentation for the audio hardware.

• If your audio hardware supports the ASIO Control Panel

function, it may be possible to make input level settings.

To open the ASIO control panel, open the Device Setup dialog via the Devices menu and, in the list to the left (below “VST Audio System”), select your audio card. When this is selected, you can open the Control Panel by clicking on the Control Panel button in the settings section to the right.

The next step is to check the level of the audio being written to a file on your hard disk. This is only necessary if you have made any adjustments to the input channel (level settings, EQ, insert effects, etc.).

Also note the following:

• If you record in 32 bit float format, the bit depth will not

be reduced – which means there is no risk of clipping at this stage.

Also, this preserves the signal quality perfectly. Therefore, you should consider using 32 bit float format when you are recording with effects (see “Recording with effects (Cubase only)” on page 78).

• If you record in 16 or 24 bit format, the available head-

room is lower, which means clipping can occur if the signal is too loud. To avoid this, set the signal level in the following way:

1. Bring up the mixer context menu, open and select Glo-

bal Meter Settings “Meter Post-Fader”.

2. Set up the input channel, by adding EQ and/or effects.

With some effects you may want to adjust the level of the signal going into the effect – use the Input Gain knob for this. Note that you need to press [Shift] or [Alt]/[Option] to adjust the Input Gain.

Adjusting the Input Gain.

3. Play back the audio and check the level meter of the input channel.

The signal should be reasonably loud but should not reach 0dB (the Clipping indicator for the input bus should not light up).

4. If necessary, use the input channel fader to adjust the signal level.

Cubase Studio

In Cubase Studio, the input channels are not shown in the mixer. Instead, you need to check the level at the channel strip for the track on which you are recording:

1. Locate the channel strip for the track you’re about to record on.

2. Activate monitoring for the channel by clicking the speaker button next to the fader.

When monitoring is activated, the meter shows the level of the incoming audio signal.

3. Play the audio source that you want to record and check the level meter for the channel.

4. Adjust the output level of your audio source so that the meters go reasonably high without reaching 0.0dB.

Check the numerical peak level indicator below the meter in the bus channel strip. To reset the peak level indicator, click on it.

Ö You must adjust the output level of the audio source – you cannot use the faders in Cubase Studio to adjust the input level!

Ö An alternative way of checking the input levels would be to use the control panel for your audio hardware (if it features input level meters). It may also be possible to adjust the input level in the control panel.

See the documentation of your audio hardware for details.

Recording

Page 73

Monitoring

In this context, “monitoring” means listening to the input signal during recording. There are three fundamentally different ways to do this: via Cubase, externally (by listening to the signal before it reaches Cubase), or by using ASIO Direct Monitoring (which is a combination of both other methods – see below).

Monitoring via Cubase

If you monitor via Cubase, the input signal is mixed in with the audio playback. The advantage of this is that you can adjust the monitoring level and panning in the mixer, and add effects and EQ to the monitor signal just as during playback (using the track’s channel strip – not the input bus!).

The disadvantage of monitoring via Cubase is that the monitored signal will be delayed according to the latency value (which depends on your audio hardware and drivers). Therefore, monitoring via Cubase requires an audio hardware configuration with a low latency value. You can check the latency of your hardware in the Device Setup dialog (VST Audio System page).

Ö If you are using plug-in effects with large inherent delays, the automatic delay compensation function in Cubase will increase the latency.

If this is a problem, you can use the Constrain Delay Compensation function while recording, see “Constrain Delay Compensation” on page 179.

When monitoring via Cubase, you can select one of four Auto Monitoring modes in the Preferences (VST page):

• Manual.

This option allows you to turn input monitoring on or off by clicking the Monitor button in the Inspector, the Track list or in the mixer.

• While Record Enabled.

With this option, you will hear the audio source connected to the channel input whenever the track is record enabled.

• While Record Running.

This option switches to input monitoring only during recording.

• Tapemachine Style.

This option emulates standard tapemachine behavior: input monitoring in Stop mode and during recording, but not during playback.

• Cubase only: In the Preferences (VST–Metering page) you can find the option “Map Input Bus Metering to Audio Track (in Direct Monitoring)”.

When Direct Monitoring is activated in the Device Setup dialog, this option allows you to map the input bus metering to monitor-enabled audio tracks. This gives you the opportunity to watch the input levels of your audio tracks when working in the Project window.

When Direct Monitoring is activated in the Device Setup dialog, this function works as follows:

• When “Map Input Bus Metering to Audio Track (in Direct Monitoring)” is activated, audio tracks show the metering signal from the input bus they are routed to as soon as the track is record-enabled. Note that the tracks are mirroring the input bus signal, i.e. you will see the same signal in both places. When using mapped metering, any functions (e.g. trimming) you apply to the audio track are not reflected in its meters.

• When “Map Input Bus Metering to Audio Track (in Direct Monitoring)” is not activated, metering works as usual.

• In Cubase Studio, the audio tracks always show the in-

put bus metering, see “Cubase Studio” on page 72.

External monitoring

External monitoring (listening to the input signal before it goes into Cubase) requires some sort of external mixer for mixing the audio playback with the input signal. This can be a stand-alone physical mixer or a mixer application for your audio hardware, if this has a mode in which the input audio is sent back out again (usually called “Thru”, “Direct Thru” or similar).

When using external monitoring, you cannot control the level of the monitor signal from within Cubase or add VST effects or EQ to the monitor signal. The latency value of the audio hardware configuration does not affect the monitor signal in this mode.

Recording

Page 74

Ö If you want to use external monitoring, you need to make sure that monitoring via Cubase is not activated as well.

Select the “Manual” monitoring mode in the Preferences (VST page) and do not activate the Monitor buttons.

ASIO Direct Monitoring

If your audio hardware is ASIO 2.0 compatible, it may support ASIO Direct Monitoring (this feature may also be available for audio hardware with Mac OS X drivers). In this mode, the actual monitoring is done in the audio hardware, by sending the input signal back out again. However, monitoring is controlled from Cubase. This means that the audio hardware’s direct monitoring feature can be turned on or off automatically by Cubase, just as when using internal monitoring.

• To activate ASIO Direct Monitoring, open the Device Setup dialog on the Devices menu and activate the Direct Monitoring checkbox on the page for your audio hardware.

If the checkbox is grayed out, your audio hardware (or its driver) does not support ASIO Direct Monitoring. Consult the audio hardware manufacturer for details.

• When ASIO Direct Monitoring is activated, you can select a monitoring mode in the Preferences (VST page), as when monitoring via Cubase (see “Monitoring via Cubase” on page 73).

• Depending on the audio hardware, it may also be possible to adjust the monitoring level and panning from the mixer (including the Control Room section, but excluding the Talkback and External Return channels) by adjusting the volume faders, the input gain controls and the send levels for Control Room studios.

Consult the documentation of the audio hardware if in doubt.

• VST effects and EQ cannot be applied to the monitor signal in this mode, since the monitor signal does not pass through Cubase.

• Depending on the audio hardware, there may be special restrictions as to which audio outputs can be used for direct monitoring.

For details on the routing of the audio hardware, see its documentation.

The latency value of the audio hardware configuration does not affect the monitor signal when using ASIO Direct Monitoring.

When using Steinberg hardware (MR816 series) in combination with ASIO Direct Monitoring, monitoring will be virtually latency-free.

Ö If you are using RME Audio Hammerfall DSP audio hardware, make sure that the pan law is set to -3dB in the card’s preferences.

Recording

Recording is done using any of the general recording methods (see “Basic recording methods” on page 67). When you finish recording, an audio file is created in the Audio folder within the project folder. In the Pool, an audio clip is created for the audio file, and an audio event that plays the whole clip appears on the recording track. Finally, a waveform image is calculated for the audio event. If the recording was very long, this may take a while.

Ö If the option “Create Audio Images During Record” is activated in the Preferences (Record–Audio page), the waveform image will be calculated and displayed during the actual recording process.

This realtime calculation uses some processing power – if your processor is slow or you are working on a CPU-intensive project, you should consider turning this option off.

Undoing recording

If you decide that you do not like what you just recorded, you can delete it by selecting Undo from the Edit menu. The following will happen:

• The event(s) you just created will be removed from the Project window.

• The audio clip(s) in the Pool will be moved to the Trash folder.

• The recorded audio file(s) will not be removed from the hard disk.

However, since their corresponding clips are moved to the Trash folder, you can delete the files by opening the Pool and selecting “Empty Trash” from the Media menu, see “Deleting from the hard disk” on page 264.

Recording

Page 75

Recording overlapping events

The basic rule for audio tracks is that each track can play back a single audio event at a time. This means that if two or more events are overlapping, only one of them will be heard at any given time.

What happens when you record overlapping events (record in an area where there are already events on the track) depends on the Linear Record Mode setting on the Transport panel:

• In “Normal” or “Merge” mode, recording where something has already been recorded creates a new audio event that overlaps the previous one(s).

When you record audio, there is no difference between “Normal” and “Merge” mode – the difference only applies to MIDI recording (see

“About overlap and the Record Mode setting” on page 81).

• In “Replace” mode, existing events (or portions of events) that are overlapped by the new recording will be removed.

This means that if you record a section in the middle of a longer existing recording, the original event will be cut into two events with a gap for the new event.

Which event will be heard?

If two or more events are overlapping, you will only hear the events (or portions of events) that are actually visible. Overlapped (hidden) events or sections are not played back.

• The functions “Move to Front” and “Move to Back” on the Edit menu (Move submenu, see “Moving events” on

page 44) are useful for managing overlapping events, as is

the “To Front” function (see below).

Recording audio in cycle mode

If you are recording audio in cycle mode, the result depends on two factors:

• The “Cycle Record Mode” setting on the Transport panel.

• The “Audio Cycle Record Mode” setting in the Prefe-

rences (Record–Audio page).

Cycle Record Modes on the Transport panel

There are five different modes on the Transport panel, but the first two modes only apply to MIDI recording. For audio cycle recording, the following applies:

• If “Keep Last” is selected, the last complete “take” (the

last completely recorded lap) is kept as an audio event.

In reality, all laps you recorded are saved in one audio file divided into regions – one region for each take. You can easily select a previous take for playback – this is done as when recording in “Create Regions” mode (see “Create Regions mode (Preferences)” on page 76).

• If “Stacked” is selected, each take will appear as an

event on a separate “lane” on the track.

This is useful when you want to view and edit the different takes and eventually combine them to one recording. In this mode, the Audio Cycle Record Mode preference does not matter. Stacked 2 (No Mute) is the same as Stacked, except that all the takes will be audible. See “Recor-

ding audio in Stacked mode” on page 77.

• If any of the other cycle recording modes is selected,

the result depends entirely on the “Audio Cycle Record Mode” setting in the Preferences (Record–Audio page).

These options are described below.

Recording

Page 76

Create Events mode (Preferences)

When “Audio Cycle Record Mode” is set to “Create Events” in the Preferences (Record–Audio page), the following will happen when you record audio in cycle mode:

• One continuous audio file is created during the entire recording process.

• For each recorded lap of the cycle, one audio event is created.

The events will have the name of the audio file plus the text “Take *”, where “*” indicates the number of the take.

• The last take (the last recorded lap) will be on top (and will thus be the one you hear when you activate playback).

To select another take for playback, proceed a follows:

1. Holding [Alt]/[Option], right-click the event and select “To Front” on the context menu.

Whether a right click opens the context menu or the toolbox is determined by the “Popup Toolbox on Right Click” option in the Preferences dialog (Editing–Tools page). Depending on this setting the context menu is opened by right-clicking or by right-clicking holding any modifier key.

The events after splitting. Note that since the original take events overlap each other, clicking with the Scissors tool will split all takes at the same position.

2. For each section of the take, use the “To Front” func-

tion to bring the best take to the front.

This way, you can quickly combine the best sections of each take, using the first vocal line from one take, the second line from another take, and so on.

You can also compile a “perfect” take in the Audio Part Editor, see “Assembling a “perfect take”” on page 258.

Create Regions mode (Preferences)

When Audio Cycle Record Mode is set to “Create Regions” in the Preferences (Record–Audio page), the following will happen when you record audio in cycle mode:

• One continuous audio file is created during the entire

recording process.

• The audio event in the Project window shows the name

of the audio file plus the text “Take *” (with “*” being the number of the last completed cycle lap).

• If you play back the recorded event, you will only hear

what was recorded during the last lap of the cycle recording.

The previous “takes” recorded in the cycle are still available, however.

• The audio clip is divided into regions (called takes), one

for each lap of the cycle that was recorded.

If you locate the audio file you just recorded in the Pool, and click on the plus sign beside it, you can see the regions that have been created, one for each lap of the cycle that was completed during recording.

The “To Front” submenu, listing all the other (obscured) events.

2. Select the desired take.

The corresponding event is brought to front.

This method allows you to quickly combine the best parts of each take, in the following way:

1. Use the Scissors tool to split the events in several sections, one for each part of the take.

For example, if you recorded four lines of vocals (in each take), you can split the events so that each line gets a separate event.

Recording

“Take” regions in the Pool window

Page 77

To play back the different “takes”, proceed as follows:

1. In the Project window, holding [Alt]/[Option], rightclick the event that was created during cycle recording.

Provided that the “Popup Toolbox on Right Click” option in the Preferences dialog (Editing–Tools page) is activated, this brings up the context menu.

2. Select the “Set To Region” menu item.

A submenu appears with the takes you recorded during cycle record.

3. Now you can select any of the takes from the submenu and it will replace the previous take event in the Project window.

Use this method to listen through the various takes. Select the best single take, or compile a “perfect” take by cutting out the best bits from each take and putting them together (see “Assembling a “perfect take”” on page 258).

Create Events + Regions mode (Preferences)

In this mode, both events and regions are created. If you work with the takes as events in this mode, you can edit the events freely (e.g. splitting them), see “Create Events

mode (Preferences)” on page 76. However, in case you

want to go back to the original takes, they are still available as regions (on the “Set To Region” submenu, in the Pool or in the Sample Editor).

Recording audio in Stacked mode

When you record audio in cycle mode and the “Stacked” Cycle Record Mode is selected on the Transport panel, the following happens:

• Each complete recorded cycle lap is turned into a separate audio event.

• The track is divided into “lanes”, one for each cycle lap.

• The events are stacked above each other, each on a different lane.

This makes it easy to create a “perfect take” by combining the best parts from the different cycle laps:

1. Zoom in so you can work comfortably with the stacked

events. If you play back the recorded section, only the lowest

(last) take will be heard.

2. To audition another take, either mute the lower take(s)

with the Mute tool or move the takes between the lanes.

This can be done by dragging or by using the functions Move to Front/ Back on the context menu or the Edit menu.

3. Edit the takes so that only the parts you want to keep

can be heard.

You can cut events with the Scissors tool, resize them, mute them or delete them.

The sections that will be heard are indicated in green.

4. When you are satisfied with the result, select all events

on all lanes and select “Delete Overlaps” from the Advanced submenu on the Audio menu.

This puts all events back on a single lane and resizes events so that overlapped sections are removed.

Recording

Page 78

5. To turn off the lane display mode for the track, click the Lane Display Type button in the Track list and select “Lanes Off”.

If the button is hidden, you can bring it to view in the Track Controls Settings dialog – see “Customizing track controls” on page 472.

The Lane Display Type button

Recording with effects (Cubase only)

Normally you record the audio signals “dry” and add effects non-destructively during playback as described in the chapter “Audio effects” on page 150. However, Cu- base also allows you to add effects (and/or EQ) directly while recording. This is done by adding insert effects and/ or making EQ settings for the input channel in the mixer.

Ö This will make the effects become part of the audio file itself – you cannot change the effect settings after recording.

About the record format

When you record with effects, you should consider setting the record format (bit depth) to 32 Bit Float. This is done in the Project Setup dialog on the Project menu. Note that this is not required in any way – you can also record with effects in 24 or 16 Bit format.

However, there are two advantages to 32 Bit Float format:

• With 32 Bit Float recording, you do not risk clipping (digital distortion) in the recorded files.

This can of course be avoided with 24 or 16 Bit recording as well, but requires more care with the levels.

• Cubase processes audio internally in 32 Bit Float format – recording in the same format means the audio quality will be kept absolutely pristine.

The reason is that the effect processing in the input channel (as well as any level or EQ settings you make there) is done in 32 Bit Float format. If you record at 16 or 24 Bit, the audio will be converted to this lower resolution when it is written to file – with possible signal degradation as a result.

Note also that it does not matter at which actual resolution your audio hardware works. Even if the signal from the audio hardware is in 16 Bit resolution, the signal will be 32 Bit Float after the effects are added in the input channel.

An example

This example shows how to apply the “SoftClipper” effect while recording. Note that this is only an example. The principle is the same for all effects (or combinations of effects).

1. Set up an audio track for recording and select the de-

sired input bus.

For best results, you should also activate monitoring as this allows you to hear and try out your settings before actually recording. See “Monitoring

via Cubase” on page 73 for a description of monitoring via Cubase.

2. Open the Mixer and make sure the full extended view

is shown.

To show the extended mixer view, either click the arrow icon (“Show Extended Mixer”) in the Common Panel, select “Show Extended View” from the Window submenu on the Mixer context menu or use a key command (this can be set in the Key Commands dialog, see “Setting up key com-

mands” on page 480).

3. Locate the input channel (bus) from which you record.

If the input channels are hidden, click on the Show/Hide Input Channels button to the left.

4. Check the input level (of the signal coming into the au-

dio hardware) as described in the section “Setting input

levels” on page 71 and adjust the level of the source audio

if necessary.

5. Pull down the View Options pop-up menu for the input

channel and select “Inserts”.

The View Options pop-up menu is opened by clicking the arrow button between the fader panel and the extended panel.

Recording

Page 79

Now the extended panel for the input channel shows the

Record Enable button Monitor button

insert slots.

6. Click on an insert slot and select an effect from the context menu.

As you see, the included effects are sorted into submenus – you will find the SoftClipper effect on the “Distortion” submenu.

The effect is loaded and activated and its control panel is automatically opened.

7. Adjust the effect parameters to your liking.

For detailed information on the Effect parameters, see the separate manual “Plug-in Reference”.

8. When the effect is set up as desired, you can check the level of the input channel by setting the Meters to post-fader (see “Setting input levels” on page 71).

Use the input channel fader to adjust the level if needed.

9. Activate recording.

10. When you’re finished, you can play back the recorded

audio track.

As you can hear, the effect you applied is now a part of the actual audio file.

11. If you do not want to record more with the same plugin, you should deactivate it by clicking in the insert slot and selecting “No Effect”.

MIDI recording specifics

Activating MIDI Thru

Normally, when working with MIDI, you will have MIDI Thru activated in Cubase, and Local Off selected in your MIDI Instrument(s). In this mode, everything you play during recording will be “echoed” back out again on the MIDI output and channel selected for the recording track.

1. Make sure the option “MIDI Thru Active” is activated in the Preferences (MIDI page).

2. Record enable the track(s) on which you want to record.

Now, incoming MIDI is “echoed” back out again for all record-enabled MIDI tracks.

Ö If you just want to use the Thru function for a MIDI track without recording, activate the monitor button for the track instead.

This is useful e.g. if you want to try out different sounds or play a VST instrument in realtime without recording your playing.

Setting MIDI channel, input and output

Setting the MIDI channel in the instrument

Most MIDI synthesizers can play several sounds at the same time, each on a different MIDI channel. This is the key to playing back several sounds (bass, piano etc.) from the same instrument. Some devices (such as General MIDI compatible sound modules) always receive on all 16 MIDI channels. If you have such an instrument, there is no specific setting you need to make in the instrument. On other instruments, you will have to use the front panel controls to set up a number of “Parts”, “Timbres” or similar so that they receive on one MIDI channel each. See the manual that came with your instrument for more information.

Naming MIDI ports in Cubase

MIDI inputs and outputs are often displayed with unnecessarily long and complicated names. However, you can rename your MIDI ports to more descriptive names:

1. Open the Device Setup dialog from the Devices menu.

2. Select the MIDI Port Setup item in the Device list.

The available MIDI inputs and outputs are listed. Under Windows, which device to choose depends on your system.

3. To change the name of a MIDI port, click in the “Show

As” column and type in a new name.

After closing the dialog, the new name will appear on the MIDI Input and Output Routing pop-up menus.

Setting the MIDI input in the Inspector

You select MIDI inputs for tracks in the Inspector (the area to the left of the Track list in the Project window):

1. If the Inspector is hidden, click the Show Inspector

button on the toolbar.

2. Select the track(s) by clicking in the Track list.

To select multiple tracks, press [Shift] or [Ctrl]/[Command] and click. The Inspector shows the settings for the first selected track (for details, see

“The Inspector” on page 29).

Recording

Page 80

3. Click the track name in the Inspector to make sure the topmost section is shown.

4. Pull down the Input Routing pop-up menu and select an input.

The available MIDI inputs are shown. The items on the menu depend on the type of MIDI interface you are using, etc.

• If you select the “All MIDI Inputs” option, the track will receive MIDI data from all available MIDI inputs.

• If you hold down [Shift]-[Alt]/[Option] and select a MIDI input, this will be used for all selected MIDI tracks.

Setting the MIDI channel and output

The MIDI channel and output settings determine where the recorded MIDI is routed during playback, but are also relevant for MIDI Thru in Cubase. Channel and output can be selected in the Track list or in the Inspector. The procedure below describes how to make the settings in the Inspector, but it can be done in largely the same manner in the Track list as well.

1. To select the track(s) and show the settings in the Inspector, proceed as when selecting a MIDI input (see above).

2. Pull down the Output Routing pop-up menu and select an output.

The available MIDI outputs are shown. The items on the menu depend on what type of MIDI interface you are using etc.

• If you hold down [Shift]-[Alt]/[Option] and select a MIDI

output, this is selected for all selected MIDI tracks.

3. Use the Channel pop-up menu to select a MIDI chan-

nel for the track.

• If you set the track to MIDI channel “Any”, each MIDI

event on the track will be sent out on the channel stored in the event itself.

In other words, the MIDI material will be played back on the channel(s) used by the MIDI input device (the MIDI instrument you play during recording).

Selecting a sound

You can select sounds from within Cubase by instructing the program to send Program Change and Bank Select messages to your MIDI device. This is done using the “Patch Selector” and “Bank Selector” fields in the Inspector or Track list.

Program Change messages give access to 128 different program locations. If your MIDI instruments have more than 128 programs, Bank Select messages (set in the “Bank Selector” field) allow you to select different banks, each containing 128 programs.

Ö Bank Select messages are recognized differently by different MIDI instruments. The structure and numbering of banks and programs may also vary. Consult the documentation of your MIDI instruments for details.

Ö Note that it is also possible to select sounds by name. For descriptions of how to set this up, see the separate “MIDI Devices” PDF document.

Recording

Page 81

Recording

Recording MIDI is done according to the basic recording methods (see “Basic recording methods” on page 67). When you finish recording, a part containing MIDI events is created in the Project window.

About overlap and the Record Mode setting

MIDI tracks are different from audio tracks when it comes to overlapping parts:

Ö All events in overlapping parts are always played back.

If you record several parts at the same locations (or move parts so that they overlap), you will hear the events in all parts on playback, even though some of the parts are obscured in the Project window.

When recording overlapping parts, the result depends on the Linear Record Mode setting on the Transport panel:

• If the record mode is set to “Normal”, overdub recording works as with audio tracks, i.e. if you record again where something has already been recorded, you get a new part that overlaps the previous one(s).

• If the record mode is set to “Merge”, the overdubbed events are added to the existing part.

• If the record mode is set to “Replace”, the new recording replaces any existing events in the area on that track.

About punch in and out on MIDI tracks

Performing and setting up manual and automatic punch in/out recording for MIDI tracks is done in exactly the same way as for audio tracks. There is one thing to note, however:

• Punching in and out on recordings with Pitchbend or

controller data (modulation wheel, sustain pedal, volume etc.) may lead to strange effects (apparently hanging notes, constant vibrato etc.).

If this happens, you may need to use the Reset item on the MIDI menu (see “The Reset function” on page 83).

About the Automatic MIDI Record Quantize function

If Auto Quantize is activated on the Transport panel (the “Auto Q” button), the notes you record are automatically quantized according to the current Quantize settings. For more information about quantizing, see “The Quantizing

functions” on page 326.

Recording MIDI in cycle mode

When you record MIDI in cycle mode, the result depends on which Cycle Record mode is selected on the Transport panel:

Cycle Record mode: Mix (MIDI)

For each completed lap, everything you record is added to what was previously recorded in the same part. This is useful for building up rhythm patterns, for example. Record a hi-hat part on the first lap, the bass drum part on the second lap etc.

Cycle Record mode: Overwrite (MIDI)

As soon as you play a MIDI note (or send any MIDI message), all MIDI you have recorded on previous laps is overwritten from that point on in the part. An example:

1. You start recording in an eight bar cycle.

2. The first take was not good enough – you start directly

with a new take on the next cycle lap and overwrite the first take.

3. After recording the second take you let the recording roll on and listen, without playing anything.

You find that the take was good up until bar seven, for example.

4. On the next lap, you wait until bar seven and start playing.

This way you will overwrite the last two bars only.

5. Make sure you stop playing before the next lap begins – otherwise you will overwrite the entire take.

Cycle Record mode: Keep Last

Each completed lap replaces the previously recorded lap. Note the following:

• The cycle lap must be completed – if you deactivate recording or press Stop before the cursor reaches the right locator, the previous take will be kept.

• If you do not play or input any MIDI during a lap, nothing happens (the previous take will be kept).

Recording

Page 82

Cycle Record mode: Stacked/Stacked 2 (No Mute)

In this mode, the following happens:

• Each recorded cycle lap is turned into a separate MIDI part.

• The track is divided into “lanes”, one for each cycle lap.

• The parts are stacked above each other, each on a different lane.

• All takes but the last one are muted (Stacked).

• If Stacked 2 is selected, no muting takes place.

Recording different types of MIDI messages

You can decide exactly which event types should be recorded by using the MIDI filters – see “Filtering

MIDI” on page 84.

Notes

When you press and release a key on your synth or other MIDI keyboard, a Note On (key down) and a Note Off (key up) message are sent out. The MIDI note message also contains the information which MIDI channel was used. Normally, this information is overridden by the MIDI channel setting for the track, but if you set the track to MIDI channel “Any”, the notes will be played back on their original channels.

This makes it easy to create a “perfect take” by combining the best parts from the different cycle laps. You can edit the parts in the Project window (by cutting, resizing and deleting) or you can use a MIDI editor as in the following example:

1. Unmute the muted takes by clicking the parts with the

Mute tool.

2. Select all takes (parts) and open them in the Key Edi-

tor for example.

3. Use the part list pop-up menu on the toolbar to select

which part to edit.

See “Handling several parts” on page 339.

4. Remove or edit notes as desired.

5. When you are happy with the result, close the editor.

6. To turn it all into a single MIDI part (containing your

“perfect take”), select all parts and select “Merge MIDI in Loop” from the MIDI menu.

7. In the dialog that appears, activate the Erase Destina-

tion option and click OK.

The remaining events in the parts are merged together into a single part.

Continuous messages

Pitchbend, aftertouch and controllers (like modulation wheel, sustain pedal, volume etc.) are considered as MIDI continuous events (as opposed to the momentary key down and key up messages). If you move the Pitchbend wheel on your synthesizer while recording, this movement is recorded together with the key (Note On and Note Off messages), just as you’d expect. But the continuous messages can also be recorded after the notes have been recorded (or even before). They can also be recorded on their own tracks, separately from the notes to which they belong.

Say, for instance, that you record one or several bass parts on track 2. If you now set another track, like track 55, to the same output and MIDI channel as track 2, you can make a separate recording of just pitchbends for the bass parts on track 55. This means that you activate recording as usual and only move the pitchbend wheel during the take. As long as the two tracks are set to the same output and MIDI channel, it will appear to the MIDI instrument as if the two recordings were made at the same time.

Program Change messages

Normally, when you switch from one program to another on your keyboard (or whatever you use to record), a number corresponding to that program is sent out via MIDI as a Program Change message. These can be recorded on the fly with the music, recorded afterwards on a separate track, or manually entered in the Key or List Editors.

Recording

Page 83

System Exclusive messages

System Exclusive (SysEx) is a special type of MIDI message used to send data that only makes sense to a unit of a certain make and type. SysEx can be used to transmit a list of the numbers that make up the settings of one or more sounds in a synth. For more about viewing and editing SysEx messages, see the chapter “Working with Sys-

tem Exclusive messages” on page 368.

The Reset function

The Reset function on the MIDI menu sends out note-off messages and resets controllers on all MIDI channels. This is sometimes necessary if you experience hanging notes, constant vibrato, etc.

There are two other options to perform a reset:

• Cubase can automatically perform a MIDI reset on stop.

You can turn this function on or off in the Preferences (MIDI page).

• Cubase can automatically insert a reset event at the end

of a recorded part.

Open the Preferences (MIDI page) and activate the option “Insert Reset Events after Record”. The inserted Reset event will reset controller data such as Sustain, Aftertouch, Pitchbend, Modulation, Breath Control, etc. This is useful if a MIDI part is recorded and e.g. the Sustain pedal is still held after stopping recording. Usually, this would cause all following parts to be played with Sustain, as the Pedal Off command was not recorded. This can be prevented by activating “Insert Reset Events after Record”.

Retrospective Record

This feature allows you to capture any MIDI notes you play in Stop mode or during playback and turn them into a MIDI part “after the fact”. This is possible due to the fact that Cubase can capture MIDI input in buffer memory, even when not recording.

Proceed as follows:

1. Enable the Retrospective Record option in the Prefe-

rences (Record–MIDI page).

This activates the buffering of MIDI input, making Retrospective Record possible.

2. Make sure a MIDI track is record-enabled.

3. When you have played some MIDI material you want

to capture (either in Stop mode or during playback), select Retrospective Record from the Transport menu (or use the key command, by default [Shift]-Num[*]).

The content of the MIDI buffer (i.e. what you just played) is turned into a MIDI part on the record enabled track. The part will appear where the project cursor was when you started playing – this means that if you played along during playback, the captured notes will end up exactly where you played them in relation to the project.

• The Retrospective Record Buffer Size setting in the Preferences (Record–MIDI page) determines how much data can be captured.

MIDI Preferences

There are several other options and settings in the Preferences that affect MIDI recording and playback:

MIDI page

• Length Adjustment

Adjusts the length of notes so that there is always a short time between the end of one note and the start of another (of the same pitch and on the same MIDI channel). The time is set in ticks. By default there are 120 ticks per 1/16 note, but you can adjust this with the MIDI Display Resolution setting on the same page.

Record–MIDI page

• Snap MIDI Parts to Bars

When this is activated, recorded MIDI parts will automatically be lengthened to start and end at whole bar positions. If you are working in a Bars+Beats-based context, this can make editing (moving, duplicating, repeating, etc.) easier.

• Solo Record in MIDI Editors

If this is activated and you open a part for editing in a MIDI editor, its track is automatically record-enabled. Furthermore, Record Enable is deactivated for all other MIDI tracks until you close the editor again. This makes it easier to record MIDI data when you’re editing a part – you will always be sure the recorded data ends up in the edited part and not on any other track.

• MIDI Record Catch Range in ms

When you record starting at the left locator, this setting helps you make sure the very start of the recording is included. A very annoying scenario is when you have recorded a perfect MIDI take, only to find out that the very first note was not included – because you started playing a little bit too early! If you raise the Record Catch Range, Cubase will catch the events played just before the recording start point, eliminating this problem.

For a description of the other options, click the Help button in the Preferences.

Recording

Page 84

Filtering MIDI

Post-roll value field and on/off switch.

Pre-roll value field and on/off switch.

The MIDI–MIDI Filter page in the Preferences allows you to prevent certain MIDI messages from being recorded and/or “thruput” (echoed by the MIDI Thru function).

The dialog is divided into four sections:

Section Description

Record Activating any of these options prevents that type of MIDI

Thru Activating any of these options prevents that type of MIDI

Channels If you activate a channel button, no MIDI messages on

Controller Allows you to prevent certain MIDI controller types from

message from being recorded. It can, however, be thruput, and if already recorded, it will play back normally.

message from being thruput. It can, however, be recorded and played back normally.

that MIDI channel will be recorded or thruput. Already recorded messages will, however, be played back normally.

being recorded or thruput. To filter out a controller type, select it from the list at the top of the Controller section and click “Add”. It will appear on the list below. To remove a controller type from the list (allow it to be recorded and thruput), select it in the lower list and click “Remove”.

Options and Settings

Recording-related Transport Preferences

A couple of settings in the Preferences (Transport page) are relevant for recording. Set these according to your preferred method of work:

Deactivate Punch In on Stop

If this is activated, punch in on the Transport panel is automatically deactivated whenever you enter Stop mode.

Stop after Automatic Punch Out

If this is activated, playback will automatically stop after automatic punch out (when the project cursor reaches the right locator and punch out is activated on the Transport panel). If the post-roll value on the Transport panel is set to a value other than zero, playback will continue for the set time before stopping (see below).

About Pre-roll and Post-roll

The pre-roll and post-roll value fields (below the left/right locator fields) on the Transport panel have the following functionality:

• By setting a pre-roll value, you instruct Cubase to “roll back” a short section whenever playback is activated.

This applies whenever you start playback, but is perhaps most relevant when recording from the left locator (punch in activated on the Transport panel) as described below.

• By setting a post-roll value, you instruct Cubase to play back a short section after automatic punch out before stopping.

This is only relevant when punch out is activated on the Transport panel and “Stop after Automatic Punch Out” is activated in the Preferences (Transport page).

• To turn pre-roll or post-roll on or off, click the corresponding button on the Transport panel (next to the pre/ post-roll value) or use the “Use Pre-roll” and “Use Postroll” options on the Transport menu.

Recording

Page 85

An example:

Click on/off

Precount on/off

1. Set the locators to where you want to start and end re-

cording.

2. Activate Punch in and Punch out on the Transport

panel.

3. Activate the option “Stop after Automatic Punch Out”

in the Preferences (Transport page).

4. Set suitable pre-roll and post-roll times by clicking in

the corresponding fields on the Transport panel and typing in time values.

5. Activate pre-roll and post-roll by clicking the buttons

next to the pre-roll and post-roll times so that they light up.

6. Activate recording.

The project cursor “rolls back” by the time specified in the pre-roll field and playback starts. When the cursor reaches the left locator, recording is automatically activated. When the cursor reaches the right locator, recording is deactivated, but playback continues for the time set in the post-roll field before stopping.

Using the metronome

The metronome can output a click that can be used as a timing reference. The two parameters that govern the timing of the metronome are tempo and time signature, as set on the tempo track and signature track, or in the Tempo Track Editor (see “Editing the tempo curve” on page 404).

You can use the metronome for a click during recording and/or playback or for a precount (count-in) that will be heard when you start recording from Stop mode. Click and precount are activated separately:

• To activate the metronome, click the Click button on the

Transport panel.

You can also activate the “Metronome On” option on the Transport menu or use the corresponding key command (by default [C]).

• To activate the precount, click the Precount button on

the Transport panel.

You can also activate the “Precount On” option on the Transport menu or set up a key command for this.

Metronome settings

You make settings for the metronome in the Metronome Setup dialog, opened from the Transport menu.

The metronome can use either an audio click played back via the audio hardware, send MIDI data to a connected device which will play back the click or do both.

The following metronome settings can be made in the dialog:

Metronome Options

Metronome in Record / Play

Use Count Base

Precount Options

Precount Bars Sets the number of bars the metronome will count in be-

Use Time Signature at Record Start Time

Description

Allows you to specify whether the metronome should be heard during playback, recording or both (when Click is activated on the Transport panel).

If this option is activated, a field appears to the right where you specify the “rhythm” of the metronome. Normally, the metronome plays one click per beat, but setting this to e.g. “1/8” gives you eighth notes – two clicks per beat. It is also possible to create unusual metronome rhythms such as triplets etc.

Description

fore it starts recording if precount is activated on the Transport panel.

When this is activated, the precount will automatically use the time signature and tempo set at the position where you start recording.

Recording

Page 86

Precount

Options

Use Time Signature at Project Time

Use Signature This lets you set a time signature for the precount. In this

MIDI Click Description

Activate MIDI Click

MIDI Port/ Channel

Hi Note/ Velocity

Lo Note/ Velocity

Audio Click Description

Activate Audio Click

Beeps When this is selected, the audio clicks will be beeps

Sounds When this is selected, you can click in the “Sound” fields

Description

When this is activated, the precount will be in the time signature set on the tempo track. Furthermore, any tempo changes on the tempo track during the precount will be applied.

mode, tempo changes on the tempo track will not affect the precount.

Selects whether or not the metronome will sound via MIDI.

This is where you select a MIDI output and channel for the metronome click. Note that you can select a VST Instrument previously set up in the VST Instruments window from this menu, allowing you to use a VST Instrument sound for the Metronome click.

Sets the MIDI note number and velocity value for the “high note” (the first beat in a bar).

Sets the MIDI note number and velocity for the “low notes” (the other beats).

Selects whether or not the metronome will sound via the audio hardware.

generated by the program. Adjust the pitch and level of the beeps for the “Hi” (first) beat and “Lo” (other) beats using the sliders below.

below to load any audio files for use as the “Hi” and “Lo” metronome sounds. The sliders set the level of the click.

Lock and Unlock Record

During recording it can happen that you accidentally deactivate the record mode, e.g. by pressing [Space]. In order to prevent this, you can set up a key commands for this in the Key Commands dialog. If you use the Lock Record key command, the Record button will turn gray and the record mode is locked until you use the Unlock Record key command or enter Stop mode.

• If Lock Record is activated and you want to enter Stop

mode (by clicking Stop or pressing [Space]), you will see a dialog in which you need to confirm that you want to stop recording. You can also use the Unlock Record key command first and then enter Stop mode as usual.

• By default, no key commands are assigned to these functions. In the Key Commands dialog, you will find the corresponding key command entries in the Transport category (see the chapter “Key commands” on page 479 for more information on how to set up key commands).

Ö These key commands are especially useful when combined with other commands (e.g. with Record/Stop) using the macro functions. That way you will receive powerful macros that can greatly enhance your workflow.

Ö Note that an automatic punch-out at the right locator position that you may have set on the transport panel, will be ignored in Lock Record mode.

Remaining Record Time Display

The Remaining Record Time Display lets you see how much time you have left for recording. The available time depends on the current setup, for example, on the amount of tracks that are record-enabled, your project setup (e.g. the sample rate), and the amount of hard disk space available.

You can show and hide the display by using the Remaining Record Time Display option on the Devices menu.

Ö The remaining record time is also shown in the status bar below the Track list.

If you are storing your tracks on different drives (by using individual record folders), the time display refers to the medium with the least storage space available.

Recording

Page 87

Recovery of audio recordings after

system failure

Normally, when a computer crashes, all changes made to your current project since you last saved it will be lost. Usually, there is no quick and easy way to recover your work.

With Cubase, when your system crashes while you are recording (because of a power cut or other mishap), you will find that your recording is still available, from the moment when you started recording to the time when your computer crashed.

When you experience a computer crash during a recording, simply relaunch the system and check the project record folder (by default this is the Audio subfolder inside the project folder). It should contain the audio file you were recording at the time of the crash.

This feature does not constitute an “overall” guarantee by Steinberg. While the program itself was improved in such a way that audio recordings can be recovered after a system failure, it is always possible that a computer crash, power cut, etc. might have damaged another component of the computer, making it impossible to save or recover any of the data.

Please do not try to actively bring about this kind of situation to test this feature. Although the internal program processes have been improved to cope with such situations, Steinberg cannot guarantee that other parts of the computer are not damaged as a consequence.

Recording

Page 88

Fades, crossfades and envelopes

Page 89

Creating fades

There are two main types of fade-ins and fade-outs in audio events in Cubase: fades created by using the fade handles (see below) and fades created by processing (see “Fades created by processing” on page 90).

Fades created by using the fade handles

Selected audio events have blue handles in the upper left and right corners. These can be dragged to create a fadein or fade-out respectively.

Creating a fade-in. The fade is automatically reflected in the shape of the event’s waveform, giving you a visual feedback of the result when you drag the fade handle.

Fades created with the handles are not applied to the audio clip as such but calculated in realtime during playback. This means that several events referring to the same audio clip can have different fade curves. It also means that having a huge number of fades may demand a lot of processor power.

• If you select multiple events and drag the fade handles

on one of them, the same fade will be applied to all selected events.

• A fade can be edited in the Fade dialog, as described

on the following pages.

You open the dialog by double-clicking in the area above the fade curve, or by selecting the event and selecting “Open Fade Editor(s)” from the Audio menu (note that this will open two dialogs if the event has both fade-in and fade-out curves). If you adjust the shape of the fade curve in the Fade dialog, this shape will be maintained when you later adjust the length of a fade.

• You can make the fade longer or shorter at any time, by

dragging the handle.

You can actually do this even without selecting the event first, i.e. without visible handles. Just move the mouse pointer along the fade curve until the cursor turns into a bidirectional arrow, then click and drag.

• If the option “Fade Handles always on Top” is activated in the Preferences dialog (Event Display–Audio page), the fade handles stay at the top of the event, and vertical help lines indicate the exact end or start points of fades.

This is useful in situations where you want the event volume to be very low, as this option allows you to still see the fade handles.

• If the option “Show Event Volume Curves Always” is activated in the Preferences (Event Display–Audio page), the fade curves will be shown in all events, regardless of whether they are selected or not.

If the option is deactivated, the fade curves are shown in selected events only.

• If the option “Thick Fade Lines” is activated in the Preferences dialog (Event Display–Audio page), the fade lines and volume curve are thicker, increasing their visibility.

Fade handles on top of the event and thicker fade and volume lines allow you to edit and view fades even in situations where event volume is very low.

• When the option “Use Mouse Wheel for Event volume and Fades” is activated in the Preferences dialog (Editing–Audio page), you can use the mouse wheel to move the volume curve up or down. When you hold down [Shift] while moving the mouse wheel, this will change the fade curves. This is useful in situations where the fade handles are not visible (e.g. because of a very high zoom factor).

When you position the mouse pointer somewhere in the left half of the event, the fade in end point is moved. When the mouse pointer is in the right half of the event, the fade out start point will move.

Ö You can set up key commands for changing the event volume curve and any fade curves, if you do not want to use the mouse for this.

You will find these commands in the Key Commands dialog, in the Audio category. See “Key commands” on page 479.

Ö As an alternative to dragging the fade handles, you can use the items “Fade In to Cursor” and “Fade Out to Cursor” on the Audio menu to create fades (Cubase only).

Position the project cursor on an audio event where you want a fade in to end or a fade out to begin, and select the appropriate option from the Audio menu. A fade will then be created, ranging from the event’s start or end to the position of the cursor.

Fades, crossfades and envelopes

Page 90

Creating and adjusting fades with the Range Selection

Drag the Volume handle up or down to change the volume of the event.

The volume change is displayed numerically on the info line.

The event waveform reflects the volume change.

tool

“Handle-type” fades can also be created and adjusted with the Range Selection tool, in the following way:

1. Select a section of the audio event with the Range Se-

lection tool.

The result depends on your selection:

• If you select a range from the beginning of the event, a fade-in will be created within the range.

• If you select a range that reaches the end of an event, a fadeout will be created in the range.

• If you select a range encompassing a middle section of the event, but not reaching neither the start nor the end, both a fade-in and a fade-out will be created outside of the selected range. In other words, the fade-in will cover the area from the beginning of the event to the beginning of the selected range, and the fade-out will cover the area from the end of the selected range to the end of the event.

2. Pull down the Audio menu and select “Adjust Fades to

Range”.

The fade areas are adjusted according to the selection range.

You can select multiple audio events on separate tracks with the Range Selection tool, and apply the fade to all of them simultaneously.

About the volume handle

A selected audio event also has a blue handle in the top middle. This is the volume handle, and it provides a quick way of changing the volume of an event, directly in the Project window. It is linked directly to the volume setting on the info line, that is, dragging the volume handle also changes the value on the info line.

Removing fades

To remove the fades for an event, select the event and select “Remove Fades” from the Audio menu.

You can also use the Range Selection tool to remove fades and crossfades within the selected range this way.

Fades created by processing

If you have selected an audio event or a section of an audio event (using the Range Selection tool), you can apply a fade-in or fade-out to the selection by using the “Fade In” or “Fade Out” functions on the Process submenu on the Audio menu. These functions open the corresponding Fade dialog, allowing you to specify a fade curve.

Note that the length of the fade area is determined by your selection. In other words, you specify the length of the fade before you enter the Fade dialog.

Also note that you can select multiple events and apply the same processing to all of them simultaneously.

Fades created this way are applied to the audio clip rather than to the event. Please note the following:

• If you later create new events that refer to the same clip, these will have the same fades.

• You can remove or modify the fades at any time using the Offline Process History (see “The Offline Process History dialog” on page 214).

If other events refer to the same audio clip, you will be asked whether you want the processing to be applied to these events or not.

• Continue will apply the processing to all events that refer to the audio clip.

• New Version will create a separate, new version of the audio clip for the selected event.

• You can also activate the option “Do not show this mes-

sage again”. Regardless of whether you then choose “Continue” or “New Version”, any further processing will conform to the option you select.

You can change this setting at any time in the Preferences (Editing–Audio page), under “On Processing Shared Clips”.

Fades, crossfades and envelopes

Page 91

The Fade dialogs

The Fade dialogs appear when you edit an existing fade or use the “Fade In”/“Fade Out” functions on the Process submenu on the Audio menu. The picture below shows the Fade In dialog; the Fade Out dialog has identical settings and features.

• If you open the Fade dialog(s) with several events selected, you can adjust the fade curves for all these events at the same time.

This is useful if you want to apply the same type of fade-in to more than one event, etc.

Curve Kind

These buttons determine whether the fade curve should consist of spline curve segments (left button), damped spline segments (middle button) or linear segments (right button).

Fade display

The Fade display shows the shape of the fade curve. The resulting waveform shape is shown in dark gray, with the current waveform shape in light gray.

You can click on the curve to add points, and click and drag existing points to change the shape. To remove a point from the curve, drag it outside the display.

Curve shape buttons

These buttons give you quick access to some common curve shapes.

Restore button

The Restore button (to the right above the fade display) is only available when editing fades made by dragging the fade handles. Click this to cancel any changes you have made since opening the dialog.

As Default button

The “As Default” button is only available when editing fades made by dragging the fade handles. Click this to store the current settings as the default fade. This shape will be used whenever you create new fades.

Fade Length Value

The Fade Length Value is only available when editing fades made by dragging the fade handles. It can be used to enter fade lengths numerically. The format of values displayed here are determined by the Primary Time Display in the Transport Panel.

When you activate the “Apply Length” option, the value entered in the Fade Length value field will be used when clicking “Apply” or “OK”. This setting is deactivated by default.

When you set the current Fade as the Default fade, the length value is included as part of the default settings.

Presets

If you have set up a fade in or fade out curve that you may want to apply to other events or clips, you can store it as a preset by clicking the Store button.

• To apply a stored preset, select it from the pop-up

menu.

• To rename the selected preset, double-click on the

name and type a new one.

• To remove a stored preset, select it from the pop-up

menu and click Remove.

Stored fade in presets will only appear in the Fade In dialog, and fade out presets will only appear in the Fade Out dialog.

Fades, crossfades and envelopes

Page 92

Preview, Apply and Process

The Edit Fade dialog The Process Fade dialog

Overlapping section

Audio clips

Audio events

The buttons in the bottom row are different depending on whether you are editing a fade made with the fade handles or applying a fade using processing:

The Edit Fade dialogs have the following buttons:

Button Function

OK Applies the set fade curve to the event, and closes the dialog. Cancel Closes the dialog. Apply Applies the set fade curve to the event, without closing the

dialog.

The Process Fade dialogs have the following buttons:

Button Function

Preview Plays back the fade area. Playback will repeat until you click

Process Applies the set fade curve to the clip, and closes the dialog. Cancel Closes the dialog without applying any fade.

the button again (the button is labeled “Stop” during playback).

Creating crossfades

Overlapping audio material on the same track can be crossfaded, for smooth transitions or special effects. You create a crossfade by selecting two consecutive audio events and selecting the Crossfade command on the Audio menu (or by using the corresponding key command, by default [X]). The result depends on whether the two events overlap or not:

• If the events overlap, a crossfade is created in the overlapping area.

The crossfade will be of the default shape – initially a linear, symmetric crossfade, but you can change this as described below.

• If the events do not overlap but are directly consecutive

(lined up end-to-start, with no gap) it is still possible to crossfade them – provided that their respective audio clips overlap! In this case, the two events are resized so that they overlap, and a crossfade of the default length and shape is applied.

The default crossfade length and shape are set in the Crossfade dialog (see “Default buttons” on page 94).

An example:

The events themselves do not overlap, but their clips do. Therefore, the events can be resized so that they overlap, which is required for a crossfade to be created.

When you select the Crossfade function, the two events are resized so that they overlap, and a default crossfade is created in the overlapping section.

• If the events do not overlap, and cannot be resized

enough to overlap, a crossfade cannot be created.

• Cubase only: You can specify the length of the cross-

fade using the Range Selection tool: make a selection range covering the desired crossfade area and use the Crossfade command.

The crossfade is applied in the selected range (provided that the events or their clips overlap, as described above). You can also make a selection range after creating the crossfade and use the function “Adjust fades to Range” on the Audio menu.

Fades, crossfades and envelopes

Page 93

• Once you have created a crossfade, you can edit it by

selecting one or both crossfaded events, and selecting “Crossfade” from the Audio menu again (or by doubleclicking in the crossfade zone).

This opens the Crossfade dialog, see below.

Removing crossfades

To remove a crossfade, proceed as follows:

• Select the events and select “Remove Fades” from the Audio menu.

You can also use the Range Selection tool: drag the Range Selection tool so that the selection encloses all the fades and crossfades you wish to remove, and select “Remove Fades” from the Audio menu.

• You can also remove a crossfade by clicking and dragging it outside the track.

The Crossfade dialog

The Crossfade dialog contains separate, but identical, sections for the fade-in and fade-out curve settings in the crossfade on the left, and common settings on the right.

Fade Displays

Shows the shape of the fade-out and fade-in curve, respectively. You can click on the curve to add points, and click and drag existing points to change the shape. To remove a point from the curve, drag it outside the display.

Curve kind buttons

These buttons determine whether the corresponding fade curve should consist of spline curve segments (left button), damped spline segments (middle button) or linear segments (right button).

Curve shape buttons

These buttons give you quick access to some common curve shapes.

Equal Power and Gain

• If you activate the “Equal Gain” checkbox, the fade

curves are adjusted so that the summed fade-in and fadeout amplitudes will be the same all along the crossfade region. This is often suitable for short crossfades.

• If you activate the “Equal Power” checkbox, the fade

curves are adjusted, so that the energy (power) of the crossfade will be constant all along the crossfade region.

Equal Power curves have only one editable curve point. You cannot use the Curve kind buttons or the presets when this mode is selected.

Play buttons

• The “Play Fade Out” and “Play Fade In” buttons allow

you to audition the fade-out or fade-in part only, without the crossfade.

• The “Play Crossfade” button plays back the whole

crossfade. You can also use the Transport panel controls to play back

the crossfaded audio events. However, that method will play back all unmuted audio events on other tracks as well.

Pre-roll and Post-roll

When auditioning with the Play buttons, you can choose to activate pre-roll and/or post-roll. Pre-roll lets you start playback before the fade area, and post-roll lets you stop playback after the fade area. This can be useful for auditioning the fade in a context.

• To specify how long the pre-roll and post-roll should be,

click in the time fields and enter the desired time (in seconds and milliseconds).

• To activate pre-roll and post-roll, click the respective

button. To deactivate it, click the button again.

Fades, crossfades and envelopes

Page 94

Length settings

You can adjust the length of the crossfade area numerically in the “Length” field. If possible, the length change will be applied equally to “both sides” of the crossfade (i.e. Cubase tries to “center” the crossfade).

To be able to resize a crossfade this way, it must be possible to resize the corresponding event. For example, if the left crossfaded event already plays its audio clip to the end, its endpoint cannot be moved any further to the right.

Auto Fades and Crossfades

Cubase features an Auto Fade function that can be set both globally, i.e. for the entire project, and separately for each audio track. The idea behind the Auto Fade function is to create smoother transitions between events by applying short (1–500ms) fade-ins and fade-outs.

As mentioned earlier, fades are calculated in realtime during playback. This means that the larger the number of audio tracks with Auto Fades activated in a project, the higher the demands on the processor.

Presets

If you have set up a crossfade shape that you may want to apply to other events, you can store it as a preset by clicking the Store button.

• To apply a stored preset, select it from the pop-up menu.

• To rename the selected preset, double-click on the

name and type in a new one.

• To remove a stored preset, select it from the pop-up menu and click Remove.

Default buttons

• Clicking the “As Default” button stores all of the current settings as the default crossfade. These settings will then be used whenever you create new crossfades.

• The Crossfade Length setting is included in the Default settings. However, it is only applied if the events to be crossfaded do not overlap, otherwise the crossfade will be in the overlap area (see “Creating crossfades” on page 92).

• Clicking the “Recall Default” button copies the curves and settings of the Default crossfade to the Crossfade dialog.

Note that auto fades are not indicated by the fade lines!

Making global Auto Fade settings

1. To make Auto Fades settings globally for the project,

select “Auto Fades Settings…” from the Project menu.

This opens the Auto Fades dialog for the project.

2. Use the checkboxes in the upper right corner to acti-

vate or deactivate Auto Fade In, Auto Fade Out and Auto Crossfades, respectively.

3. Use the Length value field to specify the length of the

Auto Fade or Crossfade (1–500ms).

4. To adjust the shapes of Auto Fade In and Auto Fade

Out, select the “Fades” tab and make settings as in the regular Fade dialogs.

5. To adjust the shape of the Auto Crossfade, select the

“Crossfades” tab and make settings as in the regular Crossfade dialog.

Fades, crossfades and envelopes

Page 95

6. If you want to use the settings you have made in future projects, click the “As Default” button.

The next time you create a new project, it will use these settings by default.

7. Click OK to close the dialog.

Making Auto Fade settings for a separate track

By default, all audio tracks will use the settings you have made in the project’s Auto Fades dialog. However, since Auto Fades use computing power, a better approach may be to turn Auto Fades off globally and activate them for individual tracks, as needed:

1. Right-click the track in the Track list and select “Auto Fades Settings…” from the context menu (or select the track and click the “Auto Fades Settings” button in the Inspector).

The Auto Fades dialog for the track opens. This is identical to the project’s Auto Fades dialog, with the addition of a “Use Project Settings” option.

2. Deactivate the “Use Project Settings” option.

Now, any settings you make will be applied to the track only.

3. Set up the Auto Fades as desired and close the dialog.

Reverting to project settings

If you want a track to use the global Auto Fade settings, open the Auto Fades dialog for the track and activate the “Use Project Settings” checkbox.

Event Envelopes

An envelope is a volume curve for an audio event. It is similar to the realtime fades, but allows you to create volume changes within the event, not only at the start or end. To create an envelope for an audio event, proceed as follows:

1. Zoom in on the event so that you can view its waveform

properly.

2. Select the Pencil tool.

When you move the Pencil tool over an audio event, a small volume curve symbol is shown next to the tool.

3. To add an envelope point, click in the event with the

Pencil tool.

A blue envelope curve and a curve point appear.

4. Drag the curve point to adjust the envelope shape.

The waveform image reflects the volume curve.

• You can add as many curve points as you like.

• To remove a curve point from the envelope, click on it

and drag it outside the event.

• The envelope curve is a part of the audio event – it will

follow when you move or copy the event.

After copying an event with an envelope, you can make independent adjustments to the envelopes in the original event and the copy.

Ö It is also possible to apply an envelope to the audio clip using the Envelope function on the Process submenu on the Audio menu.

See “Envelope” on page 206.

Ö To remove an event envelope curve from a selected event, open the Audio menu and select the Remove Volume Curve option.

Fades, crossfades and envelopes

Page 96

The Arranger track

Page 97

Introduction

The Arranger track allows you to work with sections of your project in a non-linear fashion, to simplify arranging to the maximum extent. Instead of moving, copying and pasting events in the Project window to create a linear project, you can define how different sections are to be played back, like a playlist.

For this, you can define arranger events, order them in a list, and add repeats as desired. This offers a different and more pattern-oriented way of working, which complements the usual linear editing methods in the Project window.

You can create several Arranger chains, making it possible to store different versions of a song within the project without sacrificing the original version. When you have created an Arranger chain that you like, you have the option of “flattening” the list, which creates a normal linear project based on the Arranger chain.

You can also use the Arranger track for live performances on the stage, in clubs or at parties.

Setting up the Arranger track

Let’s say you have prepared a number of audio files that form the base of a typical pop song, with introduction, verse, chorus and bridge. Now you want to arrange these files.

The first step is to create an Arranger track. On the Arranger track, you define specific sections of the project by creating arranger events. These can be of any length, may overlap and are not bound to the start or end of existing events and parts. Proceed as follows:

1. Open the project for which you want to create arranger events.

2. Open the Project menu and select “Arranger” from the Add Track submenu (or right-click in the Track list and select Add Arranger track).

An Arranger track is added. There can be only one Arranger track in a project, but you can set up more than one Arranger chain for this track, see “Managing Arranger chains” on page 99.

3. On the Project window toolbar, make sure that Snap

is activated, and that the Grid resolution is set to a mode that allows your arranger events to snap to appropriate positions in the project.

Snap to events is activated, i.e. when drawing in the Project window, new events will snap to existing events.

4. On the Arranger track, use the Pencil tool to draw an

event of the desired length.

An Arranger event is added, called “A” by default. Any following events will be named in alphabetical order.

• You can rename an Arranger event by selecting it and

changing its name in the Project window info line or by holding down [Alt]/[Option], double-clicking on the name in the Arranger chain (see below) and entering a new name.

You may want to name your arranger events according to the structure of your project, e.g. Verse, Chorus etc.

5. Create as many events as you need for your project.

In this example, arranger events have been created that correspond to a classic pop song structure. Note how there is no realtime line in the project: the music sequence is determined by the arranger events.

Events can be moved, resized and deleted using the standard techniques. Please note:

• If you want to change the length of an event, select the

Arrow tool and click and drag the lower corners of the event in the desired direction.

• If you copy an Arranger event (by [Alt]/[Option]-drag-

ging or by using copy/paste), a new event will be created with the same name as the original.

However, this new event will be totally independent from the original event.

• Double-clicking on an arranger event adds it to the cur-

rent Arranger chain.

The Arranger track

Page 98

Working with arranger events

Click the “e” button…

…to open the Arranger Editor.

You now have a number of arranger events that form the basic building blocks for your arrangement. The next step is to arrange these events using the functions of the Arranger Editor.

Creating an Arranger chain

You can set up an Arranger chain in the Arranger Editor or in the Inspector for the Arranger track. The Arranger Editor is opened by clicking the “e” button in the Inspector or in the Track list.

To the right in the Arranger Editor, the available arranger events are listed, in the order they appear on the time line. To the left you find the actual Arranger chain, which shows in which order the events will be played back, from top to bottom, and how many times they should be repeated.

Initially the Arranger chain will be empty – you set up the Arranger chain by adding events from the right list to the Arranger chain. There are several ways to add events to the Arranger chain.

• Double-clicking on the name of an event in the window

section on the right (or in the project window).

When an event is selected in the Arranger chain on the left, this will add the event above the selected event. When no events are selected in the Arranger chain, the event will be added at the end of the list.

• By selecting one or more events in the right list, right-

clicking and selecting “Append Selected In Arranger Chain”.

This will add the selected events at the end of the list.

• By dragging and dropping arranger events from the

right list to the left list.

A blue insertion line shows you where the dragged event will end up.

Here, the Verse event is dragged into the Arranger chain and placed after the first chorus.

• By dragging arranger events from the Project window

into the Arranger chain. If you followed our example, you should now have arranger

events arranged in a very basic pop song pattern. However, we have used audio files that are only a few bars long – to turn our pattern into a “song” (or at least into a basic sketch of the song structure), these files must be looped. This is where the Repeats function comes in.

If you want an event to repeat several times, proceed as follows:

• Click in the Repeats field for an event, type in the de-

sired number of repeats and press [Enter].

When playing back the Arranger chain, the Counter column indicates which repeat of this event is currently playing.

The Arranger track

Page 99

• Click in the Mode field for an event and select the de-

First repeat of current chain stepPrevious chain step

Next chain step Last repeat of current chain step

sired repeat mode.

Option Button Description

Normal In this mode, the Arranger chain will be played

Repeat forever

Pause after Repeats

back just as you set it up.

In this mode, the current Arranger event will be repeated in a loop until you either click on another event in the Arranger Editor or press play once again.

In this mode, the playback of the Arranger chain will be stopped after having played back all repeats of the current Arranger event.

When you now play back the Arranger chain, you will hear the complete arrangement. Proceed as follows:

1. Make sure that Arranger mode is activated.

When Arranger mode is activated, the project will be played back using the Arranger settings.

2. Position the Arranger Editor window so that you can see the Arranger track in the Project window, and click in the arrow column for the event at the top of the list so that the arrow becomes blue.

You should see the project cursor jump to the beginning of the first event specified in the Arranger chain.

3. Activate playback, either from the Arranger Editor or on the Transport panel.

The events are played back in the specified order.

Editing the Arranger chain

In the Arranger chain on the left, you can do the following:

• Select multiple events by [Ctrl]/[Command]-clicking or [Shift]-clicking as usual.

• Drag events to move them in the list.

• Drag events while holding [Alt]/[Option] to create cop-

ies of the selected items.

The insert location for both move and copy operations is indicated by a blue or red line in the list. A blue line indicates that the move or copy is possible; a red line indicates that if the current position were to be used, a move or copy is not allowed.

• Use the Repeats column to specify how many times

each event should be repeated.

• Click the arrow to the left of an event in the Arranger

chain to move the playback position to the start of that event.

• To remove an event from the list, right-click on it and se-

lect “Remove Touched” from the context menu. To remove several events, select them, right-click and select “Remove Selected”.

Navigating

To navigate between arranger events, you use the Arranger transport buttons:

These controls are available in the Arranger Editor, on the Project window toolbar, and on the Transport panel.

In the Arranger Editor, the event that is currently played back is indicated by an arrow in the leftmost column, and the indicators in the Counter column.

Managing Arranger chains

You can create several Arranger chains. This way, you can create alternative versions for playback. In the Arranger Editor, the toolbar buttons on the right are used for this:

Button Description

Click this to rename the current Arranger chain.

Creates a new, empty Arranger chain.

Creates a duplicate of the current Arranger chain, containing the same events.

Removes the currently selected Arranger chain. Only available if you have created more than one Arranger chain.

The Arranger track

Page 100

• In the Inspector, these functions are accessed from the

Arranger pop-up menu (opened by clicking on the Arranger name field).

The Arranger chains you create will be listed on the Name pop-up menu, found in the Arranger Editor to the left of the buttons, at the top of the Arranger track Inspector, and in the Track list. Please note that to be able to select another Arranger chain from the pop-up menu, the Arranger mode must be activated.

2. In the window that appears, select the desired options.

Flattening the Arranger chain

When you have found an Arranger chain that suits your purposes, you can “flatten” it, i.e. convert the list into a linear project. Proceed as follows:

1. Click the Flatten button (or select Flatten Chain from the pop-up menu in the Inspector for the Arranger track).

The events and parts in the project are reordered, repeated, resized, moved and/or deleted (if these are not within the boundaries of any used Arranger event), so that they correspond exactly to the Arranger chain.

The Flatten button

2. Activate Playback.

The project will now play back exactly as in Arranger mode, but you can view it and work with it as usual.

Flattening the Arranger chain may remove events and parts from the project. Only use the Flatten function when you know you do not want to edit the Arranger track/chain any more. If in doubt, save a copy of the project before flattening the Arranger chain.

Flattening options

Sometimes it might be useful to keep the original Arranger events even after flattening the Arranger track. By using flattening options you can define which chain should be flattened, where it should be stored and how it should be named together with other options.

1. Click the Flattening options button.

In the Source section you can specify which Arranger chain should be flattened. The available options are:

Option Description

Current Chain If you activate this option, only the current chain will be

Checked Chains…

All Chains If you activate this option, all arranger chains of the

flattened. If you activate this option, you can select the arranger

chains you want to flatten in the list to the left.

current project will be flattened.

The Destination section allows you to choose where the result of the flattening should be saved. The available options are:

Option Description

Current Project

New Project

This is only available if you have selected “Current Chain” as Source. If you activate this option, the result of the flattening of the current chain will be saved in the current project.

If you activate this option, you can flatten one or several chains in a new project. In this case it might be useful to use naming options. If you activate “Append Chain Name”, the Chain Names will be appended in brackets to the project name. If you activate “Use Chain Name”, the new projects will have the name of the current Arranger chains. If you activate “Add Number”, the new projects will be named like the old ones and a number will be appended in brackets.

In the Options section you can make further settings. The available options are:

Option Description

Keep Arranger Track

Make Real Event Copies

If you activate this option, the Arranger Track will be kept when flattening the Arranger chain. Activate “Rename Arranger Events” to append a number to the events, according to their use. If e.g. you use Arranger event “A” two times, the first occurrence will be renamed “A 1” and the second “A 2”.

Normally, you will get shared copies when flattening the Arranger track. If you activate this option, real copies will be created instead.

100

The Arranger track

Steinberg Cubase 5.0 Operation Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

About this manual

Welcome!

About this chapter

Setting up busses

Using the busses

Setting up Group and FX channels

About monitoring

External instruments/effects (Cubase only)

The Project window

Background

Window Overview

Operations

Options

Playback and the Transport panel

Background

Operations

Options and Settings

The Virtual Keyboard

Recording

Background

Basic recording methods

Audio recording specifics

MIDI recording specifics

Options and Settings

Fades, crossfades and envelopes

Creating fades

The Fade dialogs

Creating crossfades

The Crossfade dialog

Auto Fades and Crossfades

Event Envelopes

The Arranger track

Introduction

Setting up the Arranger track

Working with arranger events

Flattening the Arranger chain
