Star Trac Pro S, Pro Elite, Pro STM Treadmill User Manual

Star Trac Pro S

TM

Treadmill

Star T rac Pro

TM

T readmill

Star Trac Pro Elite

TM

Treadmill

OWNER’S MANUAL

Introduction

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1

Chapter 1: Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Vieligheidsinstructies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Mesures de Precaution . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Sicherheitsvorschriften . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Instruzioni di Sicurezza . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Instruções de Segurança . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Instrucciones de Seguridad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Sikkerhedsinstruktioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Chapter 2: Assembly and Setup

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Chapter 3: Operating Instructions (Pro / Pro Elite) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Display Control Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Hints and Tips for Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Preset Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Cooldown Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Using the Weight Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Heart Rate Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Chapter 4: Operating Instructions (Pro S) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Display Control Panel Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Hints and Tips for Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Preset Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

Cooldown Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Heart Rate Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Chapter 5: Personal Trainer StudioTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Personal Trainer StudioTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Using Personal Trainer StudioTM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Maintaining PIN Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Managing Custom Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Chapter 6: Training Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

The First Step to a Better Lifestyle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Getting Started - Walkers and Runners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Climbing the Conditioning Ladder - Suggested Programs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Program Variation on the PRO S / PRO / PRO ELITE Treadmill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Tips to Stay Motivated . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Chapter 7: Preventative Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Daily Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Weekly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Bi-Weekly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Monthly Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Rewax Belt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Chapter 8: Engineering and Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Manager Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Maintenance Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Calibrate Scale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Speed Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Elevation Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Club Naming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

CSAFE Company Naming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Chapter 9: Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Chapter 10: Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

FCC and Other Domestic / International Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

International Regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

I

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

TABLE OF CONTENTS

4

Welcome to the world of STAR TRAC. This Owner’s Manual will acquaint you with the assembly, operation and maintenance of
your STAR TRAC PRO S / PRO / PRO ELITE TREADMILL, so that you may begin reaching your fitness goals.

The PRO S / PRO / PRO ELITE Treadmills provide the most comprehensive integration of user needs with the Club’s needs in the
Club’s most used cardio vascular product, the Treadmill. Users will appreciate the multifunctional display of the Pro series for its
style and utility. With a Walkman rest, reading rack, bottle holder and towel hanger stylishly integrated into the display, it is obvi­ous that the design was generated with the user in mind. Further, the simplicity of these programmable treadmills understates
their usability and feature-rich design.

We highly recommend that you read this owner’s manual prior to setting up and using your treadmill. The information on the fol­lowing pages will enable you to begin easily, quickly and safely.

I

NTRODUCTION

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

1

WARNING

Your STAR TRAC PRO S / PRO / PRO ELITE TREADMILL is designed for aerobic exercise

in a gymnasium or health club environment.

Please check with your physician prior to beginning any exercise program.

Do not push yourself to excess. Stop if you are feeling faint, dizzy, or exhausted. Use common sense when walking

or running on treadmill. Please read the owner’s manual in its entirety before operating the treadmill.

IMPORTANT SAFETY INSTRUCTIONS

WARNING:

This product will be wired for either 120 VAC nominal power input OR 230 VAC nominal input. It is factory-equipped
with a specific electric cord and plug to permit connection to the proper electric circuit. Make sure that the product
is connected to a dedicated power line having an outlet with the same configuration as that of the plug. NO adapter
should be used with this product. If the product must be reconnected for use on a different type of electric circuit, the
reconnection should be made by qualified service personnel.

SAVE THESE INSTRUCTIONS

ATTENTION EQUIPMENT INSTALLERS

Star Trac recommends that treadmills be spaced a minimum of 20.0 inches (0.5 m) apart to allow safe and easy
ingress and egress. More importantly, there must be at least 48 inches (1.25 m) of free space behind the treadmills.

As with any motorized equipment, the area where treadmills are located must be free of obstructions and fixtures
with sharp edges to prevent injury in the event that a user trips or loses balance and falls.

NOTE

The STAR TRAC Pro Elite treadmills are equipped with a system of measuring a user’s static weight. By no

means is this system to be considered for use in trade, or for medical application

This chapter includes fitness safeguards and precautions for the installation and use of the Pro / Pro S Treadmill. These safety
notes are directed to you as the owner of the Star Trac Pro / Pro S Treadmill. Please read this chapter carefully before installing
or using your equipment and be sure to train all your members and fitness staff to follow these safety instructions.

Safety instructions are provided in the following languages (in the order shown):

■

Dutch

■

English

■

French

■

German

■

Italian

■

Portuguese

■

Spanish

■

Swedish

S

AFETYINSTRUCTIONS

C

HAPTER

1

2 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

V

EILIGHEIDSINSTRUCTIES

Deze veiligheidsinstructies zijn aan u gericht als de eigenaar van de STAR TRAC PRO S / PRO / PRO ELITE-HARDLOOP-
BAND. Train uw leden en fitness-personeel om deze veiligheidsinstructies te volgen.

LEES ALLE INSTRUCTIES VOORDAT U DE HARDLOOPBAND GEBRUIKT.
WAARSCHUWING: Om het resico van een elektrische schok te verminderen, dient u de stekker van de hardloopband ALTIJD

uit het stopcontact te nemen voordat u hem schoonmaakt.

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

3

DOE DIT WEL

Stop de bediening van de hardloopband als u zich duizelig
voelt of het gevoel heeft dat u flauwvalt.

Weet hoe ver u kunt gaan.
(INSERT “C”) Do keep the belt surface clean and dry.
Neem de stekker uit het stopcontact voordat u de band

reinigt of welk onderdeel dan ook verwijdert of vervangt.
Gebruik dit product alleen voor het doeleinde vaarvoor het
bestemd is.

(INSERT “B”) Do be aware of the location and proper use of
the emergency S

TOP switch.

Verricht regelmatig preventief onderhoud.
Houd het snoer bij verwarmingssystemen vandaan.
Wacht totdat de lopende band stil staat voordat u van de

hardloopband stapt.
Houd luchtopeningen vrij van pluizen, haar etc. Bedien de

hardloopband nooit met beblokkeerde luchtopeningen.
Schakel de stroom uit bij de contactschakelaar.

DOE DIT NIET

Laat kinderen niet zonder toezicht de hardloopband bedi­enen.

(INSERT “D”) Do not exceed the maximum allowable weight
limit (350 lbs. / 159 kg) for the treadmill.

Ga de band niet op af terwijl deze loopt.
Niet buiten gebruiken.
(INSERT “A”) Do not wear loose or hanging clothing while

using the treadmill.
Draai de lopende band niet te strak aan.
Bedien de hardloopband niet als deze een beschadigd snoer of

stekker heeft, als hij niet goed werkt of als hij gevallen of
beschadigd is. Neem contact op met uw geautoriseerde STAR

TRAC detailhandelaar of de onderhoudsafdeling van STAR
TRAC op [phone] of bezoek onze website op

http://www.startrac.com voor een onmiddellijke inspectie of
reparatie.

Gebruid de hardloopband niet zonder gymschoenen. Laat
nooit objecten in het apparaat vallen en steek geen objecten,
handen of voeten in welke opening van het apparaat dan ook
of onder het apparaat.

Plaats geen waterflessen of bekers op uw hardloopband tenz­ij u een houder heeft die speciaal ontworpen is voor hard­loopbanden. Gebruik uw hardloopband niet in een omgeving
waar spuitbussen worden gebruikt of waar zuurstof wordt
toegediend.

Bedien het aparaat niet zonder de motorafscherming of pas
het apparaat op geen enkele wijze aan.

WAARSCHUWING

Dit prodkt is voor gebruik op een circuit met een nominale waarde van 120 volt en is in de fabriek uitgerust met
een speciaal elektrisch snoer en stekker om verbinding met een passend elektrisch circuit toe te staan. Zorg ervoor
dat dit produkt verbonden is met een stopcontact dat dezelfde configuratie heeft als de stekker. GEBRUIK GEEN
ADAPTER BIJ DIT PRODUKT. Als het produkt opnieuw verbonden moet worden met een ander type van elek­trisch circuit, dan moet deze verbinding gemaakt worden door gekwalificeerd onderhoudspersoneel.

STOPPEN (VAN ACTIE)

WISSELSTROOM

AAN

UIT

VOORZICHTIG: NEEM DE STEKKER UIT HET
STOPCONTACT VOOR HET RENIGEN OF
ONDERHOULD.

VOORZICHTIG: LEES HET INSTRUCTIEHAND­BOEK VOORDAT U DE MACHINE BEDIENT.

(INSERT “E”) CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE TREAD­MILL WHEN OPERATING

ON

I

O

OFF

P

RECAUTIONS

These safety notes are directed to you as the owner of the STAR TRAC PRO S / PRO / PRO ELITE TREADMILL. For safety
purposes, please train all your members and fitness staff to follow these safety instructions.

4 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

DO

Do encourage your members to discuss their health program
or fitness regimen with a health care professional, especially
if they have not exercised for several years, are over 35, or
have known health conditions.

Do read all instructions in this manual before using your
treadmill.

Do use your treadmill only for its intended use, as described
in this manual.

Do check to ensure the belt is not moving prior to using the
treadmill.

Do keep the belt surface clean and dry.
Do stop operating your treadmill if you feel dizzy, faint or

exhausted.
Do exercise slowly until you reach a level of comfort and secu-

rity.
Do be aware of the location and proper use of the emergency

S

TOP key.

Do perform regular preventive maintenance as suggested in
the manual.

Do keep the electrical cord away from sources of excessive
heat.

Do keep the treadmill air openings free of lint, hair, etc.
Do unplug your treadmill before doing any maintenance or

cleaning.
Do warm up and cool down before and after each workout.
Do set your goals (see Getting Started in Chapter 6).
Do complement your walking, jogging, and running with a

nutritious diet.
Do try charting your progress using the feedback from your

treadmill.
Do try using the incline feature to burn more calories and

strengthen your lower-body muscles.

DO NOT

Do not let children operate your treadmill. Supervise invalids
or disabled persons who use your treadmill.

Do not exceed the maximum allowable weight limit (350 lbs. /

159 kg) for the treadmill.

Do not leave your treadmill unattended when it is plugged in.
Unplug it from the outlet when it is not in use, and before you
remove or replace any parts or accessories.

Do not use your treadmill without athletic shoes.
Do not wear loose or hanging clothing while using the tread-

mill.
Do not step or jump on or off your treadmill if the belt is mov-

ing.
Do not use or store your treadmill outdoors or in an enclosed

pool environment.
Do not ever drop or insert any object, hands, or feet into any

opening, or underneath this equipment.
Do not place water bottles or cups on your treadmill unless

you are using the designed holders for the treadmill. Do not
use your treadmill where aerosol (spray) products are being
used or where oxygen is being administered.

Do not use attachments or parts not recommended by the
manufacturer.

Do not run the equipment with the motor shroud removed, or
modify the equipment in any way.

Do not overtighten the running belt.
Do not operate your treadmill if it has a damaged cord or

plug, if it is not working properly, if it has been dropped or
damaged, or if the display shows an error code.Call your deal­er or Unisen at [phone], or USA 1-714-669-1660 for
service.

STOP (OF ACTION)

ALTERNATING CURRENT

ON

OFF

CAUTION: READ THE OWNER’S MANUAL COM­PLETELY BEFORE OPERATING THIS TREAD­MILL

CAUTION: BEFORE CLEANING OR SERVICING,
DISCONNECT POWER SUPPLY

CAUTION: MOVING PARTS, KEEP HANDS AND
FEET FROM UNDER THE TREADMILL WHEN
OPERATING

ON

I

O

OFF

M

ESURES DEPRECAUTION

Ces instructions sont destinées su propriétaire du TAPIS STAR TRAC PRO S / PRO / PRO ELITE. Assurez vous que votr per-
sonnel et vos adhérents les suivent toujours.

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

5

Encouragez vos adhérents à parler de leur programme d’en­traînement à un médecin ou un entraîneur, en particulier s’ils
n’ont pas eu d’activité sportive pendant plusieurs années, s’ils
ont plus de 35 ans ou s’ils ont des kilos superflus.

Lisez le manuel avant fair fonctionner le tapis.
Utilisez le tapis exclusivement aux fins don’t il est destiné.

N’utilisez pas d’accessoires qui n’ont pas été recommandés
par le fabricant.

Attachez toujours vos lacets ets vêtements quand vous courez
sur le tapis.

(INSERT “C”) Do keep the belt surface clean and dry.
Arrêtez si vous êtes pris de vertiges ou épuisé.
Commencez toujours à une vitesse lente.
Respectez les périodes d’échauffement et de récupération.
(INSERT “B”) Do be aware of the location and proper use of

the emergency STOP switch.
Entrez vos objectifs (voir chapitre 6).
Complétez votre entraînement par un régime alimentaire.
Suivez votre progrès grâce aux informations du tableau de

bord.
Essayez d’utiliser l’inclinaison afin de brûler plus de calories

et de renforcer les muscles de membres inférieurs.
Effectuez régulièrement l’entretien préventif du tapis.
Mettez les fils électriques à l’abri de chaleur.
Enlevez poussière, cheveux etc. de l’aération.

Ne laissez pas d’enfants non-accompagnés sur le tapis. Une
surveillance très stricte est néecessaire si des personnes
invalides ou handicapées utilisent le tapis.

(INSERT “D”) Do not exceed the maximum allowable weight
limit (350 lbs. / 159 kg) for the treadmill.

Ne laissez jamais le tapis sans surveillance s’il est branché.
Débranchez le tapis si vous ne l’utilisez pas ou avant de mon­ter ou démonter des pièces.

(INSERT “A”) Do not wear loose or hanging clothing while
using the treadmill.

Utilisez le tapis uniquement avec des chaussures appropriées.
Ne descendez pas ou ne montez pas sur un tapis qui est en

fonction.
N’utilisez ou ne stockez jamais le tapis à l’extérieur ou près

d’une piscine.
Ne laissez rien rentrer dans les ouvertures. Ne posez pas vos

pieds sous l’appareil.
Ne posez pas de bouteilles ou verres d’eau sur l’appareil sans

être équipé avec le ( ) en option.
N’utilisez pas le tapis dans les endroits ou des aérosols ou de

l’oxygène ont été utilisés.
Débranchez le tapis avant le nettoyage ou le changement de

fusibles.
N’enlevez pas de vis, ne modifiez pas l’appareil.
Ne serrez pas trop fort la suface caoutchoutée.
N’utilisez pas cet appareil si les fils ou la fiche sont endom-

magés, s’il est tombé ou cassé. Appelez votre distributeur pour
une révision ou réparation.

ARRÊT (MISE HORS SERVICE)

COURANT ALTERNATIF

OUVRE

FERME

ATTENTION: .LISEZ SOIGNEUSEMENT LE
MANUEL D’UTILISATION AVANT D’UTILISER CE
TAPIS ROULANT

ATTENTION: DÉBRANCHEZ A LA SOURCE
AVANT D’EFFCTUER UN ENTRETIEN DU UNE
RÉPARATION

ATTENTION: NE PAS GLÍSSER LAS MAÍNS DU
LES PIADS SOUS LE TAPIS ROULANT EN
ACTION

ON

I

O

OFF

S

ICHERHEITSVORSCHRIFTEN

Diese

Sicherheitshinweise sind an Sie, den Besitzer des Laufbandes STAR TRAC PRO S / PRO / PRO ELITE, gerichtet. Bitte weisen
Sie Ihre Mitglieder und Ihre Fitneß-Mitarbeiter an, sich an die folgenden Sicherheitsvorschriften zu halten.

LESEN SIE ALLE ANWEISUNGEN VOR DER BENUTZUNG DEL LAUFBANDES.

WARNUNG: Um das Risiko eines elektrischen Schlages zu vermeiden, nehmen Sie den Stecker des Laufbands vor dem Reinigen
IMMER aus der Netzsteckdose.

6 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

WARNUNG

Dieses Produkt ist für den Gebrauch an einer passenden Netzsteckdose mit 220 Volt Spannung bestimmt und werkseit­ig mit einer dafür vorgesehenen Netzleitung und einem Netzstecker ausgerüstet. Stellen Sie sicher, daß das Gerät nur an
einem Anschluß mit gleicher Bauart wie der Stecker angeschlossen wird. VERWENDEN SIE DEINEN ADAPTER FÜR
DEN BETRIEB DES PRO / PRO S. Wenn das Gerät zum Betrieb an einem anderen Stromnetz auf einen anderen
Netzstecker umgerüstet werden muß, sollte die Umrüstung durch einen qualifizierten Elektriker durchgeführt werden.

SIE SOLLTEN…

Die Benutzung des Laufbandes beenden, wenn Schwindel
oder Benommenheit aufritt.

Au Ihre Grenzen denken.
Das Laufband vor jeglichen Wartungsund Reinigungsarbeiten

abschalten.
Das Gerät nur für den vorgesehenen Verwendungszweck

benutzen.
(INSERT “C”) Do keep the belt surface clean and dry.
(INSERT “B”) Do be aware of the location and proper use of

the emergency STOP

switch.
Regelmäßige vorbeugende Wartungsarbeiten durchführen.
Die elektrischen Leitungen von Wärmequellen fernhalten.
Den Stillstand des Laufriemens abwarten, bevor Sie das

Laufband auseinanderbauen.
Die Lüftungsöffnungen frei von Staub, Haaren und Ähn-

lichem halten.
Das Laufband niemals mit verdeckten Lüftungsschlitzen

betreiben.
Die Stromversorgung immer am Netzschalter abschalten.

SIE SOLLTEN NIEMALS…

Kinder das Laufband unbeausfsichtigt benutzen lassen.
(INSERT “D”) Do not exceed the maximum allowable weight

limit (350 lbs. / 159 kg) for the treadmill.
Schutzvorrichtungen entfernen oder das Gerät umbauen.
(INSERT “A”) Do not wear loose or hanging clothing while

using the treadmill.
Das Gerät im Freien benutzen.
Den Laufriemen überspannen.
Das Laufband mit beschädigter Netzleitung betreiben, wenn es

nicht richtig funktioniert, heruntergefallen ist oder beschädigt
wurde. Für sofortige Reparaturunterstützung kontaktieren
Sie einen autorisierten Händler oder den Kundendienst von
STAR TRAC telefonisch unter [phone],bzw.Benutzen
Sie unsere Web-Seite unter http://www.startrac.com.

Das Laufband ohne die passenden Sportschuhe benutzen.
Gegenstände in eine Öffnung am Gerät hineinfallen lassen.
Gegenstände, Hände oder Füße in eine Öffnung am Gerät

stecken oder diese unter das Gerät legen.
Wasserflaschen oder Trinkbecher auf das Laufband stellen,

es sei denn, Sie haben ein speziell für diesen Zweck und für
dieses Laufband gedachtes Zubehörteil.

Das Laufband in Räumlichkeiten benutzen, in denen
Produkte in Aerosoldosen (Sprays) angewandt werden oder in
denen Sauerstoff verabreicht wird.

Das Laufband mit abgenommener Motorabdeckung laufen
lassen, oder das Gerät auf irgendeine Art und Weise verändern.

BEDIENUNG UNTERBRECHEN

WECHSELSTROM

EIN

AUS

ACHTUNG: GERÄT VOR DEM REINIGEN ODER
WARTEN VON DER STROMVERSORGUNG TREN­NEN

ACHTUNG: VOR DER BENUTZUNG SICHER­HEITSVORCHRIFTEN LESEN

(INSERT “E”) CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE TREAD­MILL WHEN OPERATING

ON

I

O

OFF

I

STRUZIONI DISICUREZZA

Queste indicazioni sono indirizzate ai proprietari del TREADMILL STAR TRAC PRO S / PRO / PRO ELITE. Chiedete a tutti
I membri della vostra palestra e al vostro staff di seguire queste istruzioni di sicurezza.

LEGGETE TUTTE LE ISTRUZIONI PRIMA DI USARE IL TREADMILL.
ATTENZIONE: per redurre il rischio di scossa elettrica, staccate SEMPRE la spina della corrente del treadmill prima di pulirlo.

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

7

ATTENZIONE

Questo prodotto è da usare su un circuito elettrico con una tensione nominale di 220 volt ed è fornito dalla fabbri­ca con un cavo elettrico e spina specifici per permettere il collegamento ad un circuito elettrico appropriato.
Assicuratevi che il prodotto sia collegato ad una presa che abbia la stessa configurazione della spina. NESSUN
ADATTATORE DEVE ESSERE USATO CON QUESTO PRODOTTO. Se il prodotto deve essere recollegato per
l’uso su un circuito elettrico diverso, il ricollegamento deve essere effettuato da un elettricista qualificato.

DA FARE

Fermate il treadmill se vi sentite svenire o avete capogiri.
Siate coscienti dei vostri limiti.
(INSERT “C”) Do keep the belt surface clean and dry.
Staccate la spina prima di pulire, spostare o cambiare qualsi-

asi parte del treadmill.
Usate questo prodotto solo per l’uso inteso.
(INSERT “B”) Do be aware of the location and proper use of

the emergency STOP

switch.
Eseguite la manutenzione regolare.
Mantenete la corda elettrica lontana da fonti di calore.
Aspettate fino a quando il nastro è completamente fermo

prima di scendere dal treadmill.
Pulite le prese d’aria da polvere, capelli e simili. Non usate

mai il treadmill con le prese d’aria bloccate.
Spegnete la macchina tramite l’interruttore.

DA NON FARE

Non permettete a bambini di usare il treadmill senza sorveg­lianza.

(INSERT “D”) Do not exceed the maximum allowable weight
limit (350 lbs. / 159 kg) for the treadmill.

Non salite o scendete dal treadmill mentre è in funzione.
Non usatelo all’aperto.
(INSERT “A”) Do not wear loose or hanging clothing while

using the treadmill.
Non tirate troppo il nastro.
Non usate il treadmill se il cavo elettrico o las spina sono

danneggiati, se non funziona come dovrebbe o se è caduto o è
danneggiato. Contattate il volstro rivenditore autorizzato
STAR TRAC o l’assistenze clienti dello STAR TRAC al
numero [phone] o visitate il nostro sito Internet a
http://www.startrac.com, per esame o riparazione immediata.

Usate il treadmill solo se calzate scarpe da ginnastica.
Non lasciate cadere oggetti e non inserite mani or piedi nelle

aperture o al di sotto del treadmill.
Non appoggiate bottiglie d’acqua o bicchieri sul treadmill a

meno che non stiate usando un supporto progettato apposita­mente per il treadmill.

Non usate il treadmill in posti dove sono usati prodotti aerosol
(spray) o dove è somministrato dell’ossigeno.

Non accendete il treadmill con il coperchio del motore remosso,
e non modificatelo in nessun modo.

FERMA IL MOVIMENTO

CORRENTE ALTERNATA

ACCESO

SPENTO

ATTENZIONE: PRIMA DI PULIRE O ESEGUIRE
LA MANUTENZIONE, TOGLIETE LA SPINA

ATTENZIONE: PRIMA DI USARE LEGGETTE IL
MANUALE DELLE ISTRUZIONI

(INSERT “E”) CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE TREAD­MILL WHEN OPERATING

ON

I

O

OFF

I

NSTRUÇÕES DESEGURANÇA

Estas observações de segurança destinam-se à você, proprietário de ESTEIRA STAR TRAC PRO S / PRO / PRO ELITE. Treine
todos os membros e funcionários que utilizarão o equipamento para que sigam estas instruções de segurança.

LEIA TODAS AS INSTRUÇÕES ANTES DE USAR SUA ESTEIRA
ADVERTÊNCIA: para reduzir os rescos de choque elétrico, SEMPRE desconecte a esteira da tomada antes de limpá-la

8 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

ADVERTÊNCIA

Este produto deve ser usado em um circuito com tensão nominal de 220 volts. Ele foi fabricado com um cabo de ali­mentação e plugue específicos para permitir a sua conexão com um circuito elétrico apropriado. Certifique-se de
que o produto esteja conectado a uma tomada com as mesmas configurações do plugue. NÃO UTILIZE ADAPTA­DORES PARA ESTE PRODUTO. Se for necessário reconectar a produto para utilização em um tipo diferente de
circuito elétrico, este procedimento deverá ser executado por pessoal qualificado.

Pare de usar a esteira se você se sentir fraco ou com tontura.
(INSERT “C”) Do keep the belt surface clean and dry.
Reconheça seus limites.
Desconecte a esteira da tomada antes de limpá-la ou antes de

remover ou substituir qualquer peça.
Utilize este equipamento única e exclusivament para o seu

devido fim.
(INSERT “B”) Do be aware of the location and proper use of

the emergency STOP switch.
Faça manutenção preventiva regularmente.
Mantenha o fio afastado de superfícies aquecidas.
Espere até que a esteira esteja completamente parada antes

de descer do aparelho.
Mantenha as saídas de ar desobstruídas de fiapos de tecidos,

cabelos e outros objetos. Nunca opere a esteira coma as saídas
de ar bloqueadas.

Desligue o aparelho com o interruptor de força.

Não permita que crianças operem a esteira sem supervisão de
um adulto.

(INSERT “D”) Do not exceed the maximum allowable weight
limit (350 lbs. / 159 kg) for the treadmill.

Não suba ou desça da esteira enquanto ela estiver em movi­mento.

(INSERT “A”) Do not wear loose or hanging clothing while
using the treadmill.

Não utilize a esteira ao ar livre.
Não estique demais o tapete da esteira.
Não opere esta esteira se o cabo de alimentação ou o plugue

da tomada estiverem danificados, se ela não estiver funcio­nando perfeitamente ou se tiver sofrido queda ou danos.
Procure seu revendedor autorizado STAR TRAC ou o depar­tamento de assistência técnica STAR TRAC pelo telefone
1 714 669 1660 ou acesse nosso “web site” no endereço
http://www.startrac.com para fazer uma consulta ou conserto
imediato.

Não utilize a esteira sem calçar tênis.
Não deixe cair nem introduza nenhum objeto, as mãos ou pés

em nenhuma abertura do equipamento ou debaixo deste.
Não coloque garrafas d’água nem copos na esteira se não

estiver utilizando o devido acessório projetado para esse fim.
Não utilize a esteira onde estejam sendo usados produtos de
aerosol (spray) ou em lugares onde esteja sendo administrado
oxigênio. Não opere o equipamento com a tampa do motor
removida nem faça nenhuma modificação no equipamento.

PARE (A AÇÃO)

CORRENTE ALTERNADA

I LIGAR

O DESLIGAR

ATTENÇÃO: ANTES DE LIMPAR OU FAZER
MANUTENÇÃO, DESCONECTE O APARELHO DA
TOMA DA

ATTENÇÃO: LEIA O MANUAL DE INSTRUÇÕES
ANTES DE OPERAR A ESTEIRA

(INSERT “E”) CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE TREAD­MILL WHEN OPERATING

ON

I

O

OFF

I

NSTRUCCIONES DESEGURIDAD

Estas notas sobre seguridad van dirigidas a Vd. Como propietario del TAPIZ RODANTE STAR TRAC PRO S / PRO / PRO

ELITE. Haga que todos los usuarios y preparadores físicos cumplan estas instrucciones de seguridad.

LEA TODAS LAS INSTRUCCIONES ANTES DE UTILIZAR SU TAPIZ RODANTE.
ADVERTENCIA: Para reducir los riegos de sufrir una descarga eléctrica, desenchufe SIEMPRE el tapiz rodante antes de

limpiarlo.

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

9

ADVERTENCIA

Este producto está preparado para utilizarse en un circuito de 220 voltios y se suministra equipado de fábrica con
un cable y un enchufe eléctricos específicos para permitir su conexión a un circuito eléctrico apropiado. Asegúrese
de que el producto se conecte a una toma de corriente con la misma configuración que el enchufe. NO UTILICE
NINGÚN ADAPTADOR CON ESTE PRODUCTO. Si este producto necesita ser modificado eléctricamente para
utilizarse en un tipo diferente de circuito eléctrico, dicha modificación debe ser realizada únicamente por el per­sonal de servicio calificado.

QUÉ HACER

Detenga el tapiz rodante si se nota desfallecido o mareado.
(INSERT “C”) Do keep the belt surface clean and dry.
Conozca sus limitaciones.
Desenchufe el tapiz rodante antes de limpiar, quitar o cam-

biar alguna pieza.
(INSERT “B”) Do be aware of the location and proper use of

the emergency STOP switch.
Utilice este producto sólo para los usos que está diseñado.
Realice un mantenimiento preventivo de manera regular.
Mantenga el cable separado de fuentes de calor.
Espere a que la cinta móvil haya parado antes de descender

del tapiz rodante.
Mantenga las entradas de aire libres de pelusa, pelo y simi-

lares. No utilice nunca el tapiz rodante con las entradas de
aire bloqueadas.

Desconecte de la corriente por medio del disyuntor.

QUÉ NO HACER

No permita que los niños utilicen el tapiz rodante sin super­visión.

(INSERT “D”) Do not exceed the maximum allowable weight
limit (350 lbs. / 159 kg) for the treadmill.

No suba o baje del tapiz rodante mientras está funcionando.
(INSERT “A”) Do not wear loose or hanging clothing while

using the treadmill.
No debe utilizarse en exteriores.
No tense demasiado la cinta móvil.
No utilice este tapiz rodante si tiene el cable o el enchufe daña-

dos, si no funciona adecuadamente o si ha sufrido algún golpe
o deterioro. Póngase en contacto con su vendedor autorizado
de STAR TRAC, con el departamento de servicios de STAR
TRAC llamando al número [phone] o accediendo a
nuestra página de la web en http://www.startrac.com, para un
examen o reparación immediatos.

No utilice el tapiz rodante sin calzado deportivo.
No deje caer ni introduzca ningún objeto, manos o pies en

ninguna abertura del aparato o debajo del mismo.
No deje botellas de agua ni tazas sobre su tapiz rodante

excepto si utiliza el accesorio adicional diseñado para este fin.
No. utilice su tapiz rodante en lugares en los que se están
usando productos aerosoles (en spray) o en los que se está
administrando oxígeno.

No encienda este aparato con la cubierta del motor retirada,
ni lo modifique de ninguna manera.

PARAR (EL FUNCTIONAMIENTO)

CORRIENTE ALTERNA

ENCENDIDO

APAGADO

ATENCIÓN: DESCONECTE EL SUMINISTRO DE
CORRIENTE ANTES DE LIMPIAR O REPARAR

ATENCIÓN: LEA EL MANUAL DE INSTRUC­CIONES ANTES DE SU UTILIZACIÓN

(INSERT “E”) CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE TREAD­MILL WHEN OPERATING

ON

I

O

OFF

S

IKKERHEDSINSTRUKTIONER

Disse sikkerhedsbemærkninger henvendes til ejeren af STAR TRAC PRO S / PRO / PRO ELITE-TRÆDEMØLLEN. Sørg venligst
for, at alle medlemmer og alt kondipersonale kender og følger disse sikkerhedsregler.

LÆS ALLE INSTRUKTIONERNE, FØR DU BRUGER DIN TRÆDEMØLLE.
ADVARSEL: For at mindske risikoen for at få elektrisk stød, skal du ALTID trække trædemøllens stik ud af kontakten, før du

gør den ren.

10 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

ADVARSEL

Dette produkt er beregnet til brug i forbindelse med et el-net med nominel effekt på 220 volt. Det leveres med
særlig ledning og stik fra fabrikken, som kun passer til den korrekte type el-net. Sørg for, at produktet er sat til en
stikkontakt, som har samme konfiguration som stikket. DER MÅ IKKE BRUGES ADAPTER TIL DETTE PRO­DUKT. Hvis produktet absolut skal omstilles til en anden slags el-net, skal omstillingen foretages af kvalificeret
servicepersonale.

SKAL

Stig af trædemøllen, hvis du bliver mat i kroppen eller svim­mel.

Kend dine begrænsninger.
(INSERT “C”) Do keep the belt surface clean and dry.
Træk trædemøllens stik ud af kontakten, før du gør den ren,

eller fjerner eller udskifter en del.
Brug kun produktet til det formål, det er beregnet til.
Foretag forebyggende vedligeholdelse med regelmæssige

mellemrum.
(INSERT “B”) Do be aware of the location and proper use of

the emergency STOP switch.
Holdledningen fri af varmeanlæg.
Vent til løbebåndet standser, før du stiger af trædemøllen.
Hold ventilationsåbningerne fri for fnug, hår og lignende.

Brug aldrig trædemøllen med blokerede luftventilationsåb­ninger.

Sluk for elektriciteten på afbryderkontakten.

MÅ IKKE

Tillad ikke børn uden opsyn at bruge trædemøllen.
(INSERT “D”) Do not exceed the maximum allowable weight

limit (350 lbs. / 159 kg) for the treadmill.
Stig ikke på eller af trædemøllen, mens den kører.
(INSERT “A”) Do not wear loose or hanging clothing while

using the treadmill.
Brug ikke trædemøllen udendørs.
Stram ikke løbebåndet for meget.
Brug ikke trædemøllen, hvis ledningen eller stikket er

beskadiget, hvis trædemøllen ikke fungerer rigtigt, eller hvis
den er faldet ned eller væltet og er blevet beskadiget. Kontakt
den autoreserede STAR TRAC, forhandler eller ser­viceafdelingen hos STAR TRAC Ring på [phone]
eller du kan få fat i os på vores web-site: http://www.star­trac.com for øjeblikkeligt eftersyn eller reperation.

Brug ikke trædemøllen uden kondisko.
Undgå at tabe eller at stikke genstande, hænder eller fødder

ind i en åbning i eller under udstyret.
Stil ikke vandflasker eller kopper på trædemøllen, medmin-

dre du har dertil beregnet tilbehør, som er specielt designet til
trædemøllen. Brug ikke trædemøllen på steder, hvor der
bruges aerosolprodukter (spray), eller hvor der administreres
ilt.

Udstyret må ikke køre uden motorafskærmning, og det er
ikke tilladt at ændre udstyret på nogen måde.

STOP (AF FUNKTION)

VEKSELSTRØM

TÆND

SLUK

FORSIGTIG: AFBRYD EL-KABLET, FØR DU GØR
RENT ELLER SERVICERER.

FORSIGTIG: LÆS INSTRUKTIONSHÅNDBOGEN
FØR BRUG

(INSERT “E”) CAUTION: MOVING PARTS, KEEP
HANDS AND FEET FROM UNDER THE TREAD­MILL WHEN OPERATING

ON

I

O

OFF

UNPACKING

Remove all parts from the shipping crate and verify that the following parts were included in your shipment:

Description Qty.

Frame Assembly w/ Motor Shroud . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Top Rail with Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Neck . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Side Rail w/ STOP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Side Rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Button, Plastic** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Screw, Button Head Socket Cap, 1/4”-28 UNC x 3/8”* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Screw, Socket Head Cap, 5/16”-18 UNC x 1.0”* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Bolt, Hex-head, 5/16”-18 UNC_ x 3.0”** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Washer, Flat, 5/16” I.D. x 1.5" O.D. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Washer, Flat, 5/16” I.D. x 1.2” O.D.** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Washer, Split Lock, 5/16”** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Screw, 5/16”-18 x 7.5”** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Hex (Allen) key, 1/4”** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Hex (Allen) key, 5/32”** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Screwdriver, Phillips, #2** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Screwdriver (blade-tip), 3/32”** . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Owner’s Manual with Warranty Registration Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

*Pre-inserted into frame assembly
**Part of included STAR TRAC tool kit.

Should any component not be present or if you have any operational questions, please call Star Trac’s Service department at (800)
503-1221 or USA 1-714-669-1660. Specifically refer to your treadmill serial number and model number listed below:

Serial No._________________________________________________________________________
Model No._________________________________________________________________________

NOTE: The following assembly procedure applies to the PRO S, PRO and PRO ELITE Treadmills. Illustrations show the PRO
ELITE Treadmill only.

ASSEMBLY

The following toools are required for assembly: Hex (Allen) Key, 1/4”; Hex (Allen) Key, 5/32”; Screwdriver, Phillips; Wrench, 1/2”
(not provided). To assemble your STAR TRAC PRO S / PRO / PRO ELITE TREADMILL, just follow these steps.

NOTE: Don’t fully tighten bolts and screws until all parts are assembled.

1. Unpacking and Positioning the Frame
Assembly

Remove all the packaging material so the treadmill is sitting,
ready for assembly, on the shipping crate platform. With a helper,
lift the treadmill frame assembly from the shipping crate platform
and place it in the location where it will be used. Make sure the
unit is placed near a power outlet.

Caution: The motor shroud end of the frame assembly is very
heavy. Two people may be needed to lift this end when moving the
frame assembly.

A

SSEMBLY AND

S

ETUP

C

HAPTER

2

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

11

Step 1

2. Installing the Neck

Remove the four pre-installed neck mounting screws and washers
from the motor shroud end of the frame assembly.

Position the neck in place on the motor shroud end of the frame
assembly, and re-install the four screws and washers to secure.

3. Removing the Motor Shroud

Remove the 10-24 screws securing the motor shroud to the frame assembly, and lift the motor shroud off of the frame
assembly. Retain the screws for use when re-installing the motor shroud.

4. Installing the Display

Caution: To ensure proper routing of the display cables, it may be necessary to have one person support and position
the display while a second person feeds the display cables through the neck assembly.

With two people supporting the display, carefully feed the display cables into the neck. Reposition the display as needed
during this step to ensure the display cables do not bunch or kink in the neck. Ensure the display cables feed completely
through, and out the bottom, of the neck.

12 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

Step 2b

Step 2a

NECK MOUNTING

SCREWS AND WASHERS

Step 3

MOTOR

SHROUD

Position the display on the neck, taking care not to pinch the
cables between the neck and the display. Once the display is prop­erly positioned, install the two 5/16”-18 bolts to secure the display
to the neck.

Once the display has been secured in place, route the display
cables through the cutout in the neck, and into the motor com­partment.

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

13

Step 4a

Step 4b

Step 4c

Step 4d

5. Installing the Handrails

Locate the left handrail (the handrail with the STOP switch).
Connect the STOP switch cable from the handrail to the display
cable extending from the display handrail stub.

Insert the handrail connecting tube into the display handrail stub,
taking care not to pinch the STOP switch cable between the
handrail pieces. Make sure the handrail bottoms fully against the
display handrail stub.

Rotate the handrail, if necessary, to align the drilled hole in the
display handrail stub with the threaded hole in the handrail con­necting tube. Secure the handrail to the display handrail stub
using two 1/4”-28 x 3/8” screws.

Install the right handrail in a similar manner, as described in
steps 5b and 5c, omitting instructions related to the S

TOP switch

cable.

14 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

Step 5a

Step 5b

Step 5c

Step 5d

Position the bottom of each handrail over its associated mounting hole in the frame assembly. Insert one 5/16” x 7.5” screw,
with a flat washer installed, through the bottom of the frame assembly, and thread into each handrail. Use 9 1/2” wrench
to tighten the screws.

6. Connecting the Display Cables

For units with fans (PRO / PRO ELITE), connect the cables tagged 715-3444 and 715-3419 from the display to connectors
J3A and P4A, respectively, on the 715-3441 PCB in the motor compartment. The display cable connectors are keyed, and
can only be installed in one direction only.

Connect the cable tagged 715-3411 from the display to connector
P3 on the 715-3397 (for 110-volt) or 715-3398 (for 220-volt) PCB in
the motor compartment. The display cable connector is keyed, and
can only be installed in one direction only.

STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

15

Step 5e

Step 6a

Step 6b

For units with scale system (PRO ELITE), connect the cables
tagged 715-3418 RIGHT and 715-3418 LEFT from the display to
connectors P1 and P2, respectively, on the load cell interface.

7. Final Assembly

Re-install the shroud over the motor compartment, and secure in place with the previously removed screws. Insert the
four plastic buttons into the screw access holes at the bottom of the neck assembly.

Securely tighten all hardware installed during assembly. If neces­sary, level your treadmill using the two adjustable feet under the
tailroller. Loosen the lock nuts, rotate the feet until the treadmill is
stabilized, and retighten the lock nuts.

NOTE: Perform a visual inspection, and test the features and func­tions of the unit, prior to use.The weight scale system on your STAR

TRAC PRO ELITE Treadmill has undergone a detailed system cal­ibration at our factory and does

not require calibration after the

unit has been removed fro its original factory packaging.

You have now completed the assembly of your STAR TRAC PRO S /

PRO / PRO ELITE TREADMILL.

16 STAR TRAC PRO S / PRO / PRO ELITE TREADMILL O

WNER’SMANUAL

Step 6c

Step 7a Step 7b
