StarTech TB3DKDPMAW, TB3DKDPMAWUE User Manual

Thunderbolt 3 Dual - 4K Docking Station for Laptops | Mac | Windows
Actual product may vary from photos
User Manual
For the latest information and specications visit
www.startech.com/TB3DKDPMAW
www.startech.com/TB3DKDMAWUE
Manual Revision: 11/14/2019

Compliance Statements

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected
• Consult the dealer or an experienced radio/TV technician for help
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
1

Safety Statements

Safety Measures
• Wiring terminations should not be made with the product and/or electric lines under power.
• Cables (including power and charging cables) should be placed and routed to avoid creating electric, tripping or safety hazards.
Mesures de sécurité
• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit et/ou les câbles électriques sont sous tension.
• Les câbles (y compris les câbles d’alimentation et de chargement) doivent être placés et acheminés de façon à éviter tout risque électrique, de chute ou de sécurité
安全対策
• 電源が入っている状態の製品または電線の終端処理を行わないでくださ い。
• ケーブル(電源ケーブルと充電ケーブルを含む)は、適切な配置と引き回し を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう にしてください 。
Misure di sicurezza
• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le linee elettriche sotto tensione.
• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o pericoli per la sicurezza.
Säkerhetsåtgärder
• Montering av kabelavslutningar får inte göras när produkten och/eller elledningarna är strömförda.
• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
2
Table of Contents
Compliance Statements ........................................................................1
Safety Statements ..................................................................................2
Product Diagram ....................................................................................4
Front View ....................................................................................................................................................4
Back View ..................................................................................................................................................... 5
Product Information ..............................................................................6
Package Content ....................................................................................................................................... 6
Requirements ............................................................................................................................................. 6
Powering the Docking Station ............................................................................................................. 7
Connecting the Docking Station ......................................................................................................... 8
Installing the Remaining Drivers ......................................................................................................... 9
Charging a Device ..................................................................................9
Conguring a Display Device ...............................................................10
Connect a display to the DisplayPort port ....................................................................................... 11
Connect a display to the Thunderbolt 3 USB-C port .................................................................... 11
Connect multiple Thunderbolt 3 displays in a daisy chain ........................................................12
Supported Video Resolutions ..............................................................13
Bandwidth Allocation ............................................................................14
Troubleshooting .....................................................................................16
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
3

Product Diagram

Front View

1
2
USB-A Port (Fast Charge and
Sync)
USB-C Port
2
1
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
4

Back View

4
1 2 3 5 6 7 8
1 RJ45 Port 5 Thunderbolt 3 Host
Port
2 USB-A 6 Thunderbolt 3 Port
3 Microphone Input Port 7 DisplayPort Port
4 Audio Output Port 8 DC In Port
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
5

Product Information

Package Content

Thunderbolt 3 Docking Station x 1
Thunderbolt 3 Cable (40Gbps - 0.5m) x 1
Universal Power Adapter x 1
Power Cords (NA/JP and ANZ for TB3DKDPMAW) (EU and UK
for TB2DKDPMAWUE) x 2
User Manual x 1

Requirements

Requirements are subject to change. For the latest requirements, please visit www.startech.com/TB3DKDPMAW or
www.startech.com/TB3DKDPMAWUE.
Host Computer
An available Thunderbolt 3 port.
Notes: In order to use multiple displays, the Thunderbolt 3 port on the Host Computer must support dual external displays.
The Docking Station is not compatible with USB-C only computers.
Dispay
DisplayPort equipped display(s) with cable(s) (for additional
external display).
Thunderbolt 3 equipped display(s) with cable(s) (for
additional external display).
For 4K (4096 x 2160p) resolution, a 4K-capable display is
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
6
required.
Operating System
Windows® 10, 8, 8.1 or 7.
macOS 10.14, 10.13 or 10.12.
Installation

Powering the Docking Station

1. Select the appropriate power cord for your region and
connect it to the power adapter.
2. Connect the power adapter to an AC electrical outlet and
then to the docking station’s DC IN (power input) port.
3. Connect the provided Thunderbolt 3 Cable to a Thunderbolt
3 Port on the on the docking station and the other end to a Thunderbolt 3 port on the Host Computer.
Note: The Docking Station does not support Power Delivery. Use the power adapter that came with the connected Host Computer in order to charge the Host Computer.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
7

Connecting the Docking Station

1. Connect a USB Peripheral Device to either the USB-A Ports
or Thunderbolt 3 Port on the back of the Docking Station. Devices may include USB peripherals, headset, microphone, etc.
Notes: The three USB ports located at the back of the dock­ing station (2 x USB-A, 1 x Thunderbolt 3) are standard USB
3.0 throughput ports. When the dock is connected to a Host Computer, these ports provide a trickle charge to a con­nected device.
The docking station supports DP Alt Mode, you can con­nect Thunderbolt 3 or USB-C based video devices, cables, or adapters to the secondary Thunderbolt 3 port on the rear of the docking station.
2. Connect a CAT6/5e Cable to the RJ45 Port on the Docking
Station and the other end to a Network Device.
3. Connect an Thunderbolt 3 Cable to the Thunderbolt 3 Port
on the Docking Station and the other end to a Display Device.
4. For a second display, connect a DisplayPort Cable to the
DisplayPort Port on the Docking Station and the other end to a Display Device.
- or -
Connect an Thunderbolt 3 Cable to the Thunderbolt 3 Port on the Docking Station and the other end to a Display Device.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
8
Notes: Video output capabilities are dependent on the video card and hardware specications of your connected Host Computer.

Installing the Remaining Drivers

Depending on your operating system, the dock will automatically install some of the required drivers once connected to your Host Computer. Follow the below instructions to complete the full driver installation process.
1. Using a Web browser navigate to www.startech.com/
TB3DKDPMAW.
2. Click the Support tab.
3. Download the drivers.
4. When the download is complete, extract the contents of the
compressed le(s) that you downloaded.
5. Double-click the appropriate driver for the version of
Windows that you are running and follow the on-screen instructions to complete the installation.
Note: If you are prompted to restart your computer, do so to complete the installation.

Charging a Device

If using the front USB-A port to charge a device, a connection to a Host Computer isn’t required.
Connect a USB device to the USB-A port located on the front
of the docking station.
Notes: This front USB-A port can only fast-charge connected
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
9
devices that comply with USB Battery Charging Specication Revision 1.2.
When the docking station is connected to a Host Computer, the front USB-A port functions as a Charging Downstream Port (CDP), which has simultaneous charge and sync capa­bilities.
Conguring a Display Device
Use your Windows operating system to adjust display settings for multiple monitors. Your laptop hardware must support dual external displays.
You can set up dual displays by using the video output ports
(1x DisplayPort and 1x HDMI).
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
10

Connect a display to the DisplayPort port

The docking station’s DisplayPort connection supports DisplayPort 1.2, as well as DP++. Because the port supports DP++, you can use passive adapters or cables to connect dierent types of monitors to the DisplayPort port.
Type of Display Adapter
DisplayPort None
HDMI DisplayPort to HDMI 4K Audio/Video
Converter (DP2HD4KS)
DVI DisplayPort to DVI Adapter (DP2DVI2)
VGA DisplayPort to VGA Adapter (DP2VGA2)

Connect a display to the Thunderbolt 3 USB-C port

You can also connect a display (or a display adapter) to one of the docking station’s Thunderbolt 3 ports. One of the docking station’s Thunderbolt 3 ports must remain connected to your Host Computer.
Type of Display Adapter
DisplayPort None
HDMI USB-C to DisplayPort Adapter Cable
(CDP2DPMM1MB)
DVI USB-C to HDMI Adapter (CDP2HD4K60)
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
11
VGA USB-C to VGA Adapter (CDP2VGA)
Visit www.StarTech.com/AV/usb-c-video-adapters/ for a range of USB-C video adapters and cables.
Notes:
The docking station lets you connect two 4K displays.
The maximum available resolution might be limited if
your monitor is connected through a video adapter. Check the documentation of the video adapter to determine its maximum supported resolution.

Connect multiple Thunderbolt 3 displays in a daisy chain

You can also set up dual displays using multiple Thunderbolt 3 displays in a daisy-chain conguration. For example, you can connect a Thunderbolt 3 display to the Thunderbolt 3 port on the docking station. You can then connect another Thunderbolt 3 device, such as a second Thunderbolt 3 display, through the rst Thunderbolt 3 display.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
12

Supported Video Resolutions

Thunderbolt technology supports both video and data throughput. However, it prioritizes video bandwidth to help ensure seamless display performance. The performance of the remaining dock functions depends entirely on the display conguration you used.
The docking station supports the follow maximum resolutions:
Number of
Displays
Ports Maximum Resolution
1 DisplayPort port 4096 x 2160p
1
Thunderbolt 3 port
4096 x 2160p (60Hz)
(Thunderbolt 3 monitor only)
Thunderbolt
1
USB-C port (using DP alt
4096 x 2160p
mode)
DisplayPort port
2
and Thunderbolt
4096 x 2160p
3 USB-C port
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
13
3840 x 2160p resolution, found on most standard 4K
monitors, is also a fully supported resolution
Depending on the conguration and the supported
resolutions of your connected monitor(s), the docking station can support video resolutions lower than specied above.
In a multi-display conguration, set the refresh rates on each
of your connected monitors to the same values, otherwise your monitors might not properly display.
Video output capabilities are dependent on the video
card and hardware specications of your connected Host Computer.
Certain monitors may be limited to 4K at 30Hz when
connecting through DisplayPort. (See Troubleshooting for further details).

Bandwidth Allocation

Thunderbolt technology carries video and data bandwidth, and it prioritizes video bandwidth to help ensure seamless display performance. The performance of the remaining dock ports (for example, the USB 3.0 ports) depends entirely on the display and I/O (input and output) conguration that you have used.
When multiple high-resolution displays are connected, the docking station needs to allocate additional bandwidth to the displays, and the extra bandwidth is reallocated from the other I/O ports on the docking station. In this situation there is less bandwidth available for the remaining ports (for example, the USB 3.0 ports).
The bandwidth allocation table outlines the approximate
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
14
download bandwidth allocation values. The allocation amount depends on the number and the resolution of your connected displays.
Video and I/O
Conguration
DisplayPort
Resolution
Thunderbolt
3 USB-C
Resolution
I/O Bandwidth Remaining
Download:
Data only (No Displays)
N/A N/A
22Gbps
Upload: 22Gbps
DisplayPort (Single Display
- 4K)
Thunderbolt 3 USB-C (Single Display - 4K)
4096 x 2160p (4K)
N/A
N/A
4096 x 2160p (4K - 60Hz)
DisplayPort and Thunderbolt 3 USB-C (Two
4096 x 2160p (4K)
4096 x 2160p
(4K) Displays ­Dual-4K )
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Download: 22Gbps
Upload: 22Gbps
Download: 22Gbps
Upload: 22Gbps
Download: 8Gbps
Upload: 22Gbps
15
The bandwidth values are approximate and depend on
several variables including the number, type, resolution, and refresh rate of your connected display(s).
When connecting a display to one of the Thunderbolt
3 USB-C ports, a USB-C video adapter may be required, depending on the input of your display.

Troubleshooting

If you are experiencing issues, there are some quick tests that you can complete to narrow down the source of the issue.
Update your computer to use Thunderbolt 3
Visit http://thunderbolttechnology.net/updates and look for your computer in the list of aected computers. If your computer is listed, then you must update your computer for its Thunderbolt 3 ports to function properly. To update your computer, follow the instructions on the website or contact your manufacturer.
Verify that your components are Thunderbolt compliant
6. Make sure that you are using Thunderbolt 3 certied cables.
7. Make sure that the port on your computer is Thunderbolt
3 compliant. Thunderbolt 3 uses the USB-C connector type, but not all USB-C connectors are compatible with Thunderbolt 3. If you are using a USB-C port that is not Thunderbolt 3 compliant, switch to a port that is Thunderbolt 3 compliant.
8. Make sure that your peripheral is Thunderbolt compliant. If
you’re not sure, check with the manufacturer.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
16
Replace the Thunderbolt cable
Use the Thunderbolt peripheral with a dierent cable that is
Thunderbolt compliant.
Test the Thunderbolt peripheral
1. Use a second Thunderbolt peripheral, and see if it works.
Ideally, the second peripheral is one that you know works in other setups. If the second peripheral works in the current setup, then there is probably an issue with the rst Thunderbolt peripheral.
2. Use the Thunderbolt peripheral with a second setup. If it
works in the second setup, then there is probably an issue with the rst setup.
Important operation notes
Certain monitors may be limited to 4K at 30Hz when
connecting through DisplayPort. These monitors include the following models: Dell P2715Q, Viewsonic VX2475Smhl­4K, Philips 288P6LJEB, LG 31MU97C-B, Asus PB287Q (these models will need to be set to 4K at 30Hz).
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
17
Warranty Information
This product is backed by a three-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall it be the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
18
18
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From the latest technology to legacy products — and all the parts that bridge the old and new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
Reviews
Share your experiences using StarTech.com products, including product applications and setup, what you love about the products, and areas for improvement.
StarTech.com Ltd.
45 Artisans Cres.
London, Ontario
N5V 5E9
Canada
FR: fr.startech.com
DE: de.startech.com
StarTech.com LLP
2500 Creekside Pkwy.
Lockbourne, Ohio
43137
U.S.A.
ES: es.startech.com
NL: nl.startech.com
StarTech.com Ltd.
Unit B, Pinnacle
15 Gowerton Rd., Brackmills
Northampton
NN4 7BW
United Kingdom
IT: it.startech.com
JP: jp.startech.com
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
Loading...
