Thunderbolt 3 Dual-4K Docking Station for Laptops
- Windows Only
Product ID: TB3DK2DPWUE
This Thunderbolt™ 3 dock is the first docking station to use revolutionary Thunderbolt 3 technology. Plus,
it’s the first dock available that supports two 4K Ultra HD displays.
The high-quality dock merges performance with
simplicity, to create a single-cable solution that
caters to creative professionals such as video
producers, graphic and web designers, engineers,
architects, and many more.
www.startech.com
1 800 265 1844
Finish your work faster with Thunderbolt 3
You can quickly integrate the dock into your workspace and boost your productivity. With up to 40Gbps of
throughput, you can add extra displays to your laptop, access files faster, and reduce waiting, so you can
accomplish more in the same amount of time.
It’s the fastest connection available, and it supports multiple video channels and data, without impacting
system performance. It’s easy to access and edit large uncompressed files such as videos and images on
the fly, making it ideal for dynamic on-site production.
Multitask at the highest resolution
If you need a larger, higher-resolution viewing area, this dock can help. It’s one of the first docking
stations to support two 4K Ultra HD displays, so it’s perfect for anyone working with high-bandwidth or
graphics-intensive multimedia. And, unlike most traditional docking stations, the Thunderbolt 3 dock
supports 4K resolutions (3840 x 2160p or 4096 x 2160p) at up to 60Hz when you use a single
Thunderbolt 3 display. With a faster 60Hz refresh rate, your 4K content is delivered in stunning detail,
even when you’re running resource-demanding applications.
You can extend your desktop onto two 4K monitors and stream independent content to each display. This
makes it easier to multitask when you’re working with high-definition video, CAD drawings, medical
imagery, or other complex work. Creative professionals can be more productive with the freedom to edit
4K video on one display, with a full-size video preview on the second 4K display.
Connect your peripherals with just a single cable
Using a single cable and a single port on your laptop, you can transform your Windows laptop into a full-
size workstation with access to new and legacy technologies through a number of different port types. The
dock is ideal for virtually all Windows based Thunderbolt 3 equipped laptops such as the Dell™ Precision,
Dell XPS, Asus Zenbook Pro Ux501vw, HP Zbook 15 G3, and Lenovo P50.
www.startech.com
1 800 265 1844
The dock features two Thunderbolt 3 USB-C ports
for connecting to Thunderbolt devices and other
peripherals that use the USB-C connector, as well
as DisplayPort video output. For dual 4K video
capability, you can use a 4K capable video adapter
to connect a second 4K display to one of the
dock’s Thunderbolt 3 USB-C peripheral ports.
Convenient connections prepare you for the future
You can keep your mobile device charged and ready to go using the dock’s convenient, always-on USB
fast-charge and sync port (compliant with USB Battery Charging Specification 1.2). Plus, it offers a variety
of other connections that are often missing from port-limited laptops, such as an extra USB-C port (5Gbps
- data only), and a Gigabit Ethernet port.
With three total USB 3.0 ports, you have plenty of ports to connect modern and legacy devices. (USB 3.0
is also known as USB 3.1 Gen 1). Now, you can rest assured knowing you’re ready for the current and
next generation of universal connectivity.
The rear-panel DP and USB-C port can be used with dual monitors that support lower resolutions, such as
4K 30Hz or 1080p. Now you can connect dual monitors using new and legacy displays. StarTech.com
offers a variety of USB-C video adapters, such as HDMI and VGA.
Maximum Supported Resolutions*
Video Output Configuration Max DisplayPort Resolution
Max Thunderbolt 3 USB-C
Resolution
DisplayPort and Thunderbolt 3 USB-C
(Two Displays - Dual-4K )
3840 x 2160p or 4096 x 2160p
(4K)
3840x 2160p or 4096 x 2160p
(4K)
DisplayPort
(Single Display - 4K)
3840 x 2160p or 4096 x 2160p
(4K)
N/A
Thunderbolt 3 USB-C
(Single Display - 4K)
N/A
3840 x 2160p or 4096 x 2160p
(4K - 60Hz)
Thunderbolt 3 USB-C Daisy Chain N/A
Dependent on the number of
Thunderbolt 3 displays
*Lower resolutions are also supported.
*When connecting a display to one of the Thunderbolt 3 USB-C ports, a USB-C video adapter may be required depending on the input of
your display.
*DisplayPort connectivity may be limited to 4K at 30Hz depending on monitor used (see technical specifications for more detail)
www.startech.com
1 800 265 1844
The TB3DK2DPWUE features a rugged aluminum casing, and is backed by a StarTech.com 3-year
warranty and free lifetime technical support.
Note: This docking station will not charge your host laptop
Your computer’s Thunderbolt 3 ports might not function properly until you update one or more of the
following on your computer:
• BIOS
• Thunderbolt firmware
• Thunderbolt 3 controller drivers
• Thunderbolt 3 software
The required updates will vary depending on your computer.
For an up-to-date list of affected computers and instructions, visit
http://thunderbolttechnology.net/updates. If your manufacturer isn’t listed on the Thunderbolt website,
contact your manufacturer.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Ideal for creative professionals working with high-resolution, highbandwidth, and graphically intensive images, video, CAD drawings,
and medical imagery
• Recommended for video producers, graphic and web designers,
engineers, architects, and more
• Access and edit large, uncompressed files such as videos and images
on the fly, for dynamic on-site production
• Transfer a 4K movie in under 30 seconds, or 3 hours of 4K GoPro®
video in less than a minute
• Edit 4K video on one display, with a full-size video preview on the
second 4K display
• Dock and undock quickly, with a single cable for data and external
displays
Features
• Improve your workflow with single-cable docking and up to 40Gbps
bandwidth
• Supports dual-4K monitors, with 3840 x 2160p or 4096 x 2160p on
each display
• Connects to your laptop’s Thunderbolt 3 USB-C port, so you can
access multiple displays and peripherals
• Fast charge your phone or tablet with the always-on USB 3.0 fastcharge and sync port
• Includes three USB 3.0 ports (USB-C, 2x USB-A), two Thunderbolt 3
USB-C ports, 3.5mm audio out, 3.5mm microphone in, and GbE
• Thunderbolt Certified and includes a Thunderbolt 3 host cable (0.5
m)
• This docking station will not charge your host laptop
www.startech.com
1 800 265 1844
Warranty 3 Years
Hardware 4K Support Yes
Bus Type Thunderbolt 3
Chipset ID Intel - Alpine Ridge DSL6540
Fresco - FL1100EX
Texas Instruments - PCM2912A
Intel - WGI210AT
Texas Instruments - TPS65982
Displays Supported 2
Fast-Charge Port(s) Yes
Industry Standards Thunderbolt 3
USB Battery Charging Specification Rev. 1.2
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
USB 3.0 - Backward compatible with USB 2.0 and 1.1
Performance Auto MDIX Yes
Compatible Networks 10/100/1000 Mbps
Full Duplex Support Yes
Maximum Data Transfer Rate 40 Gbps (Thunderbolt 3)
10 Gbps (USB 3.1 Gen 2)
5 Gbps (USB 3.0)
2 Gbps (Ethernet; Full-Duplex)
Maximum Digital Resolutions Single display - DisplayPort - 4096 x 2160p / 3840 x 2160p
Single display - Thunderbolt 3 USB-C - 4096 x 2160p / 3840
x 2160p
Dual displays - DisplayPort - 4096 x 2160p / 3840 x 2160p and Thunderbolt 3 USB-C - 4096 x 2160p / 3840 x 2160p
Type and Rate Thunderbolt 3 - 40 Gbit/s
UASP Support Yes
Connector(s) Connector Type(s) 2 - Thunderbolt™ 3 USB-C (24-pin) Female
1 - DisplayPort (20 pin) Female
1 - USB Type-C (24 pin) USB 3.0 Female
1 - USB 3.0 A (Fast-Charge, 9 pin, SuperSpeed) Female
1 - USB Type-A (9 pin) USB 3.0 Female
2 - 3.5 mm Mini-Jack (3 Position) Female
1 - RJ-45 Female
Software OS Compatibility Windows® 10 (32-bit or 64-bit), 8 / 8.1 (32-bit or 64-bit), 7
(32-bit or 64-bit)
www.startech.com
1 800 265 1844
Special Notes /
Requirements
Note This docking station will not charge your host laptop.
A 4K-capable display is required to achieve 4K x 2K
resolution (4K is also known as 4K x 2K).
Certain monitors may be limited to 4K at 30Hz when
connecting through DisplayPort. These monitors include the
following models: Dell P2715Q, Viewsonic VX2475Smhl-4K,
Philips 288P6LJEB, LG 31MU97C-B, Asus PB287Q (these
models will need to be set to 4K at 30Hz).
When connecting a display to one of the Thunderbolt 3 USBC ports, a USB-C video adapter may be required depending
on the input of your display.
USB 3.0 is also known as USB 3.1 Gen 1; this connectivity
standard offers speeds up to 5Gbps. USB 3.1 Gen 2 offers
speeds up to 10Gbps.
The DisplayPort output port on this dock does not support
MST.
System and Cable Requirements Thunderbolt 3 equipped computer with a Thunderbolt 3 port
- Windows only.
The docking station does not support Mac or Linux operating
systems.
Power Center Tip Polarity Positive
Input Current 1.5 A
Input Voltage 100 ~ 240 AC
Output Current 6 A
Output Voltage 12 DC
Plug Type N
Power Consumption (In Watts) 72
Power Source AC Adapter Included
Environmental Humidity 5~95% RH (Non-condensing)
Operating Temperature 5°C to 40°C (41°F to 104°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Physical
Characteristics
Cable Length 520 mm [20.5 in]
Color Gray and Black
Enclosure Type Aluminum and Plastic
Product Height 27 mm [1.1 in]
www.startech.com
1 800 265 1844
Product Length 220 mm [8.7 in]
Product Weight 442 g [15.6 oz]
Product Width 80 mm [3.1 in]
Packaging
Information
Shipping (Package) Weight 1.4 kg [3 lb]
What's in the Box Included in Package 1 - Thunderbolt™ 3 dual-4K docking station for laptops
1 - Thunderbolt 3 cable - 40Gbps - 0.5m
1 - universal power adapter
2 - power cords (EU/UK)
1 - instruction manual
Product appearance and specifications are subject to change without notice.
