Thunderbolt™ 3 to 10GBase-T Ethernet Adapter
Product ID: TB310G
This Thunderbolt™ 3 to 10Gb Ethernet adapter connects Thunderbolt 3 enabled devices to a wired
Ethernet network, with support for 10Gb/s, 5Gb/s, 2.5Gb/s, 1Gb/s and 100Mb/s Base-T speeds.
Accelerated Network Connection
Increase your data transfer speeds by harnessing the performance of Thunderbolt 3. This Ethernet
adapter adds a single RJ45 Ethernet port with 10 Gigabit support to help easily access very large files
over the network at increased 10Gbps speeds.
Advanced Technology for Optimal Performance with Thunderbolt 3
The 5-speed Thunderbolt 3 to 10GbE adapter uses premium chipsets, providing a low-power, high-
performance NBASE-T solution. The 10GBASE-T standard supports 10Gbps speeds over existing CAT6a or
better cabling at distances of up to 100 m. The Tehuti™ TN4010 controller chipset is compliant with
802.3az Energy Efficient Ethernet and ensures peak operating efficiency with reduced power consumption
in bandwidth-intensive workstation applications.
www.startech.com
1 800 265 1844
Quiet & Compact Design
This Thunderbolt 3 NIC is an easy addition to any modern workstation. Taking up only 12 square inches of
desk space and fully bus-powered, it's extremely portable with a small footprint. The fanless design
means the adapter is noiseless (0dB), so you can set up in an open office space without being disruptive.
It’s ideal for virtually any type of workspace or environment, including remote desks and modern open-
concept offices.
This Thunderbolt 3 to 10GbE adapter is backed by a 2-year warranty and free lifetime North American
based technical support.
www.startech.com
1 800 265 1844
Certifications, Reports
and Compatibility
Applications
• Home offices or remote work stations
• Modern open office setups
• For Thunderbolt 3 enabled computers
Features
• Supports auto-negotiation for 10Gb/s, 5Gb/s, 2.5Gb/s, 1Gb/s and
100Mb/s Base-T speeds
• Provides an RJ45 10Gbps Ethernet connection
• Reversible USB Type C™ connector with a Thunderbolt 3™ interface
• Achieves 10Gbps over 100m with CAT6a cable
• Fanless design with aluminum chassis
www.startech.com
1 800 265 1844
Warranty 2 Years
Hardware Bus Type Thunderbolt 3
Chipset ID Intel - Alpine Ridge DSL6340
Tehuti TN4010
Marvell 88X3310PA1
Industry Standards IEEE 802.3an (10GBASE-T)
IEEE 802.3ab (1000BASE-T )
IEEE 802.3u (100BASE-TX )
NBase-T (5GBASE-T)
NBase-T (2.5GBASE-T)
IEEE 802.1q (VLAN Tagging)
IEEE 802.3ad (Link Aggregation)
Performance Auto MDIX Yes
Auto-Negotiation Yes
Compatible Networks 10 Gbps/5G/2.5G/1G/100 Mbps
Full Duplex Support Yes
Jumbo Frame Support 9K max.
Promiscuous Mode Yes
PXE No
Connector(s) Connector Type(s) 1 - Thunderbolt™ 3 USB-C (24-pin) Female
External Ports 1 - RJ-45 Female
Software OS Compatibility Windows 7
Windows 8/8.1
Windows 10
Windows Server 2008 R2
Windows Server 2012 R2
Windows Server 2016
Mac OS 10.11
Mac OS 10.12
Mac OS 10.13
Special Notes /
Requirements
Note Due to technical limitations of the IC solution, max
bandwidth is limited to about 7.5 Gbps
System and Cable Requirements Requires a Thunderbolt 3 port with 15W of power
Indicators LED Indicators 1 - Solid White - Thunderbolt 3 is connected to host laptop
1 - Solid Green - RJ45 link speed of 1G, 2.5G, or 5G
1 - Solid Orange - RJ45 link speed of 10G
Environmental Humidity 20%RH ~ 80%RH
Operating Temperature 5°C ~ 35°C
www.startech.com
1 800 265 1844
Storage Temperature -20°C ~ 50°C
Physical
Characteristics
Color Black
Enclosure Type Aluminum
Form Factor Separate Cable
Product Height 1.1 in [29 mm]
Product Length 4 in [102 mm]
Product Weight 12.4 oz [350 g]
Product Width 3 in [75 mm]
Packaging
Information
Shipping (Package) Weight 15.9 oz [450 g]
What's in the Box Included in Package 1 - Network Adapter
1 - Thunderbolt 3 Cable
1 - Travel Pouch
1 - Quick-Start Guide
Product appearance and specifications are subject to change without notice.
